Hytronik HC005S/BT Quick guide

Installation and Instruction Manual
3. Installation
Mechanical Structure & Dimensions
HC005S/BT
Built-in Microwave Motion Sensor with 5.0 SIG Mesh
2. Download the App
Free App for set-up and commissioning
HC005S/BT-20200302-A0
1. Technical Specifications
ON/OFF CONTROL
Protocol
4 dBm
2.4 GHz - 2.483 GHz
Operation frequency
Transmission power
Range (Typical indoor)
10~30m
Stand-by power
Operating voltage
< 1W
220~240VAC 50/60Hz
Load ratings
20sWarming-up
300VA(capacitive),400W(resistive)
EMC standard (EMC)
Safety standard (LVD)
Certification
EN55015, EN61000, EN61547
Semko,CB, CE , EMC, RED, RCM,UKCA
EN60669-1/-2-1
AS/NZS60669-1/-2-1
RED EN300328, EN301489-1/-17,EN62479,
30°~150°
Ta:-20
OC~+50OC
Sensor principle
Detection range (Max.)*
Detection angle
Operation temperature
IP20IP rating
5.0 SIG Mesh
Max installation height: 6m
Max detection range：10m (diameter)
High Frequency (microwave)
Tc:+75°Case temperature(MAX.)
4.2
36.5
65
71.7
80.5
26
12.1
23.8 24.9
Bluetooth module
Antenna module
Photocell AdvanceTM
Daylight sensor
Power supply
220-240V out control
26
23.8
50
43.8
36.5
65
4.2
Bluetooth module
Antenna module
Photocell AdvanceTM
Daylight sensor
Power supply
220-240V out control
5.0 SIG mesh
Web app/platform: www.iot.koolmesh.com
Koolmesh Pro app for iPad
Smartphone app for both iOS & Android platform
for iOS for Android
for iPad
for Web
Web
iOS
Android

HC005S/BT-20200302-A0
Subject to change without notice.
5. Additional Information / Documents
4. Detection Pattern
Wiring Diagram
Control gear
Control gear
Control gear
Wire Preparation
0.75 - 1.5mm
8mm
To make or release the wire from the terminal,
use a screwdriver to push down the button.
Ceiling mounted detection pattern (m)
Ceiling mounted height(m)
50
6
10%
30%
75%
50%
Wall mounted height (m)
Wall mounted detection pattern (m)
9
4
0
10%
30%
75%
50%
1. For full explanation of Hytronik Photocell AdvanceTM technology, please kindly refer to www.hytronik.com/download ->knowledge ->Introduction of Photocell Advance
2. To learn more about detailed product features/functions, please refer to www.hytronik.com/download ->knowledge ->Introduction of App Scenes and Product Functions
3. Regarding precautions for Bluetooth product installation and operation, please kindly refer to www.hytronik.com/download ->knowledge ->Bluetooth Products - Precautions for Product Installation and Operation
4. Regarding precautions for microwave sensor installation and operation, please kindly refer to www.hytronik.com/download ->knowledge ->Microwave Sensors - Precautions for Product Installation and Operation
5. Data sheet is subject to change without notice. Please always refer to the most recent release on www.hytronik.com/products/bluetooth technology ->Bluetooth Sensors
6. Regarding Hytronik standard guarantee policy, please refer to www.hytronik.com/download ->knowledge ->Hytronik Standard Guarantee Policy
