Hytronik DS05 Quick guide

Technical Specifications
Product type Daylight Sensor
Operating voltage 220-240VAC 50Hz
Rated load Max. 800W (Resistive)
Max. 400W (Capacitive)
Power consumption < 0.5W
Daylight threshold 2Lux, 10Lux, 30Lux, 50Lux, 100Lux, 300Lux, 500Lux, Disable
Warmming up time 20s
Operating temperature -20ºC ~ +60ºC
IP rating IP20
DS05-20170623-A1
Installation and Instruction Manual
Fixture Built-in Daylight Sensor DS05
Dimensions (mm)
2. Loop-in and loop-out
Double L N terminal makes it easy for wire loop-in and loop-out, saves the cost of terminal block and
assembly time.
1. Lux Off Function
The built-in daylight sensor can measure ambient natural light. It will switch off the fixture in 5minutes
automatically, whenever artificial light is not required (natural light lux level exceeds daylight threshold).
Note: if the daylight threshold is preset at “disable”, the fixture will never switch off even when natural
light is sufficient.
Functions
Wiring Diagram
Daylight sensor
Daylight threshold
Infrared receiver
Installation hole
LED Driver
DS05
220 - 240VAC
Settings
Daylight Threshold
Set the lux level according to the real application environment. Light keeps off if ambient daylight is
sufficient (above the threshold preset). With insufficient natural light, light will automatically turn on.
Light will never switch off when daylight threshold is set to disable.
123 4 5 6
2 Lux
10 Lux
30 Lux
123456
100 Lux
300 Lux
500 Lux
50 Lux

Description of the Button Functions
(remote control HRC-11)
HRC-11
7
5
2
4
1
3
6
8
9
DS05-20170623-A1
Hytronik Industrial Ltd. | www.hytronik.com
3rd Floor, block C, complex building, 155#, Bai'gang road south,
Bai'gang village, Xiao Jin Kou town, Huicheng district, Huizhou 516023
Tel: [phone] Fax: [phone]
RESET [ button ]
Press button , all settings go back to the DIP switch settings.
2
2
Shift [ button ]
Press button , the LED on the top left corner flashes to indicate mode selection. All values / settings in RED are
in valid for 20 seconds.
3
3
Auto Mode [ button ]
Press button to initiate automatic mode. The sensor starts working and all settings remain as before the light
was switched ON/OFF.
Note: The function of “SEMI-AUTO” is disabled.
4
4
Permanent ON/OFF [ ]
Press button to select permanent ON or permanent OFF mode.
* Press button / to resume automatic operation.
button
1
1
2 4
Ambient daylight threshold [ button ]
1. Press button Shift, the red LED flashes for indication.
2. Press button , the ambient lux level is sampled and set as the new daylight threshold.
3
7
7
7
Press buttons in zone to set the daylight threshold at 2Lux / 10Lux /50Lux / 100Lux / 300Lux /
500Lux or Disable.
Note: 1. Light will never switch off when daylight threshold is preset at disable.
2. To set daylight sensor at 100Lux / 300 Lux / 500Lux, press button Shift at first.
7
Daylight threshold [ zone ]
6
6
3
Test 2S [ zone ]
8
This button is for test purpose only, light will switch on when natural light lux level is below daylight threshold
preset; or switch off when natural light lux level exceeds daylight threshold preset for 10S.
Note: buttons in zone are disabled.
5 9
