Hytronik HIR28 User manual

EMC standard (EMC)
Safety standard (LVD)
Certication
EN55015, EN61000
Semko, CB, CE , EMC, LVD, RCM
EN60669-1, EN60669-2-1
Safety and EMC
Input Characteristics
Stand-by power
Resistive 800W
Model No. HIR28
220~240VAC 50/60Hz
Mains voltage
Load ratings:
<1W
400W
Capacitive
20s Warming-up
Technical Data
IP20
Applications
Ofce, classroom and commercial interior spaces where on/off control is required.
HIR28 with on/off relay control
Designed with a low prole for aesthetically demanding architectural projects providing
a high quality sensor for simple on/off occupancy control or providing semi-automatic
(absence detection) control.
An intelligent photocell is also included to prevent switching of the lights when natural
daylight is availible
Set-up of the sensor is carried out using a remote control handset with program memory
allowing one-key commissioning where common settings are used for multiple devices.
Ofce / Commercial Lighting
Classrooms
Stairwells / Corridors
One-Key
Commissioning
Photocell
Intelligent
5 Year, 50,000hr Warranty
Features
Zero crossing detection to reduce in-rush current and maximise relay life.
Store settings in the remote for easy commissioning when programming multiple sensors.
Intelligent photocell - lights and sensors only operate when needed, natural light has proirity.
Environment
Operation temperature Ta: -20
O
C~ +50
O
C
IP20
IP rating
HIR28 HIR28/R HIR28/H HIR28/RH
Low-bay Reinforced Low-bay High-bay Reinforced High-bay
Flush Mount PIR Motion Sensor PIR
HIR28/H
HIR28 HIR28/R
HIR28/RH
(3-pyro)
Subject to change without notice. Edition: 30 Jun. 2021 Ver. A0 Page 1/9
Sensor Data
Model No.
360O
PIR detectionSensor Model
Detection range (Max.)*
HIR28/H
Detection angle
Installation height：15m (forklift)
12m (person)
Detection range (Ø)：24m
Detection range (Max.)*
HIR28
Installation Height : 6m
Detection Range(Ø) :9m
Detection range (Max.)*
HIR28/R
Installation Height : 6m
Detection Range(Ø) :10m
Detection range (Max.)*
HIR28/RH
Installation height：15m (forklift)
12m (person)
Detection range (Ø)：40m
HIR28
* For more details of detection range, please refer to “detection pattern” section.

Mechanical Structure
75.2
78
70.5
62
1. Ceiling (drill hole65mm)
2. Carefully prise off the cable clamps.
3. Make connections to the pluggable
terminal blocks.
4. Insert plug connectorsand secure using
the provided cableclamps, then clip
terminal covers to the base.
5. Fitdetection blind (if required) and
desired lens.
6. Clip fascia to body.
7. Bend back springs and insert into ceiling.
4
5
2
3
1
65mm
* Install lens as required
7
21
* Install blind as required
A B
6
3
21
Wire Preparation
0.75 - 2.5mm
8mm
(min 6mm, max 11mm)
Pluggable screw terminal. It is recommended to make
connections to the terminal before tting to the sensor.
Subject to change without notice. Edition: 30 Jun. 2021 Ver. A0 Page 2/9
Note:We recommend the mounting distance between sensor to sensor should be more than 2m to prevent sensors
from false-triggering.

LED Driver
Push L’ N L
Max. 400W
L N LED+ LED--
LED Driver
L N LED+ LED--
Detection Pattern & Optional Accessories
Radial (B)
Tangential (A)
2.5m
Mount height
Valid Range
6m
5m
4m
3m
insensitive sensitive insensitive sensitive
A: Tangential movement
Tangential: max. 9m
h = max.6m
A
B: Radial movement
Radial: max. 4m
h = max.6m
B
HIR28: Low-bay at lens detection pattern for single person @ Ta = 20
O
C
(Recommended ceiling mount installation height 2.5m-6m)
max 64m2 (Ø = 9m)max 13m2 (Ø = 4m)
max 13m2 (Ø = 4m)
max 13m2 (Ø = 4m)
max 13m2 (Ø = 4m)
max 13m2 (Ø = 4m)
max 50m2 (Ø = 8m)
max 38m2 (Ø = 7m)
max 38m2 (Ø = 7m)
max 38m2 (Ø = 7m)
Blind Option 1 --- Aisle Detection
Optional Accessory --- Ceiling/Surface Mount Box: HA03
Optional Accessory --- Blind Insert for Blocking Certain Detection Angles
75
Ø 94
Blind Option 2 --- 180
O
Detection
1. HIR28 (Low-bay)
Valid Range
Wiring Diagram
Subject to change without notice. Edition: 30 Jun. 2021 Ver. A0 Page 3/9

Radial (B)
Tangential (A)
2.5m
Mount height
6m
5m
4m
3m
HIR28/R: Low-bay convex lens detection pattern for single person @ Ta = 20
O
C
(Recommended ceiling mount installation height 2.5m-6m)
max 79m2 (Ø = 10m)
max 79m2 (Ø = 10m)
max 64m2 (Ø = 9m)
max 50m2 (Ø = 8m)
max 50m2 (Ø = 8m)
max 20m2 (Ø = 5m)
max 20m2 (Ø = 5m)
max 20m2 (Ø = 5m)
max 20m2 (Ø = 5m)
max 20m2 (Ø = 5m)
2. HIR28/R (Reinforced Low-bay)
A: Tangential movement
Tangential: max. 10m
h = max.6m
A
B: Radial movement
Radial: max. 5m
h = max.6m
B
Optional Accessory --- Ceiling/Surface Mount Box: HA03
Optional Accessory --- Blind Insert for Blocking Certain Detection Angles
75
Ø 94
Valid Range
Blind Option 1 --- Aisle Detection Blind Option 2 --- 180
O
Detection
Valid Range
insensitive sensitive insensitive sensitive
Subject to change without notice. Edition: 30 Jun. 2021 Ver. A0 Page 4/9

3. HIR28/H (High-bay)
Tangential: max. 20m
h = max.12m
A
Radial: max. 3m
h = max.12m
B
Radial (B)
Tangential (A)
10m
Mount height
14m
15m
13m
12m
11m max 452m2 (Ø = 24m)
max 380m2 (Ø = 22m)
max 452m2 (Ø = 24m)
max 452m2 (Ø = 24m)
max 452m2 (Ø = 24m)
max 452m2 (Ø = 24m)
max 201m2 (Ø = 16m)
max 201m2 (Ø = 16m)
max 201m2 (Ø = 16m)
max 177m2 (Ø = 15m)
max 133m2 (Ø = 13m)
max 113m2 (Ø = 12m)
A: Tangential movement
Tangential: max. 24m
h = max.15m
A
B: Radial movement
Radial: max. 16m
h = max.15m
B
HIR28/H: High-bay lens detection pattern for forklift @ Ta = 20
O
C
(Recommended ceiling mount installation height
10m-15m )
Optional Accessory --- Ceiling/Surface Mount Box: HA03
Optional Accessory --- Blind Insert for Blocking Certain Detection Angles
75
Ø 94
Valid Range
Blind Option 1 --- Aisle Detection Blind Option 2 --- 180
O
Detection
Valid Range
Radial (B)
Tangential (A)
2.5m
Mount height
11m
12m
10m
8m
6m max 104m2 (Ø = 11.5m)
max 50m2 (Ø = 8m)
max 154m2 (Ø = 14m)
max 227m2 (Ø = 17m)
max 269m2 (Ø = 18.5m)
max 314m2 (Ø = 20m)
max 7m2 (Ø = 3m)
max 7m2 (Ø = 3m)
max 7m2 (Ø = 3m)
max 7m2 (Ø = 3m)
max 7m2 (Ø = 3m)
max 7m2 (Ø = 3m)
A: Tangential movement B: Radial movement
HIR28/H: High-bay lens detection pattern for single person @ Ta = 20
O
C
(Recommended ceiling mount installation height
2.5m-12m )
insensitive sensitive insensitive sensitive
insensitive sensitive insensitive sensitive
Subject to change without notice. Edition: 30 Jun. 2021 Ver. A0 Page 5/9

Radial (B)
Tangential (A)
10m
Mount height
14m
15m
13m
12m
11m
max 907m2 (Ø = 34m)
max 962m2 (Ø = 35m)
max 1075m2 (Ø = 37m)
max 660m2 (Ø = 29m)
max 346m2 (Ø = 21m)
max 1256m2 (Ø = 40m)
max 154m2 (Ø = 14m)
max 177m2 (Ø = 15m)
max 177m2 (Ø = 15m)
max 154m2 (Ø = 14m)
max 113m2 (Ø = 12m)
max 113m2 (Ø = 12m)
A: Tangential movement
Tangential: max. 40m
h = max.15m
A
B: Radial movement
HIR28/RH: Reinforced high-bay lens detection pattern for forklift @ Ta = 20
O
C
(Recommended ceiling mount installation height 10m-15m)
Radial: max. 15m
h = max.15m
B
Optional Accessory --- Ceiling/Surface Mount Box: HA03
75
Ø 94
4. HIR28/RH (Reinforced High-bay with 3-Pyro)
Tangential: max. 30m
h = max.12m
A
Radial: max. 4m
h = max.12m
B
Radial (B)
Tangential (A)
2.5m
Mount height
11m
12m
10m
8m
6m max 154m2 (Ø = 14m)
max 38m2 (Ø = 7m)
max 314m2 (Ø = 20m)
max 531m2 (Ø = 26m)
max 615m2 (Ø = 28m)
max 707m2 (Ø = 30m)
max 7m2 (Ø = 3m)
max 7m2 (Ø = 3m)
max 7m2 (Ø = 3m)
max 13m2 (Ø = 4m)
max 13m2 (Ø = 4m)
max 13m2 (Ø = 4m)
A: Tangential movement B: Radial movement
HIR28/RH: Reinforced high-bay lens detection pattern for single person @ Ta = 20
O
C
(Recommended ceiling mount installation height 2.5m-12m)
insensitive sensitive insensitive sensitive
insensitive sensitive insensitive sensitive
Subject to change without notice. Edition: 30 Jun. 2021 Ver. A0 Page 6/9

Functions and Features
Intelligent Photocell (daylight detection prior to motion detection)
2
The built-in photocell will also automatically turn off the light when the ambient natural light exceeds the programmed lux level for
more than 5min, regardless of whether motion is detected or not.
With insufcient natural light, the sensor
switches on the light automatically when
presence is detected.
With sufcient natural light, the light
does not switch on when presence is
detected.
The sensor switches off the light when
natural light is sufcient, even with
presence.
On/ off Control
1
This sensor is a motion switch, which turns on the light upon detection of motion, and turns off after a pre-selected hold-time when there
is no movement. A daylight sensor is also built in to prevent the light from switching on when there is sufcient natural light.
Manual Override
3
* Short Push (<1s): on/off function;
On →Off: the light turns off immediately and cannot be triggered ON by motion until the expiration of pre-set hold-time. After this
period, the sensor goes back to normal sensor mode.
Off →On: the light turns on and goes to sensor mode, no matter if ambient Lux level exceeds the daylight threshold or not.
Note: if end-user do not want this manual override function, just leave the “push” terminal unconnected to any wire.
With the help of push-switch, this sensor can be over-ridden by the end-user to manually switch on/off the light, which makes the
product more user-friendly and offers more options to t some extra-ordinary demands:
Semi-auto Mode (Absence Detection)
4
It is easy to forget to switch off the light, in ofce, corridor, even at home. And in many other cases, people do not want to have a
sensor to switch on the light automatically, for example, when people just quickly pass-by, there is no need to have the light on. The
solution is to apply this “absence detector”: motion sensor is employed, but only activated on the manual press of the push-switch, the
light keeps being ON in the presence, and switches off in the long absence.
Note: end-user can choose either function or function for application. Default function is manual override.
3 4
zero-cross point
Alternating current
Zero-cross Relay Operation
Designed in the software, sensor switches on/off the
load right at the zero-cross point, to ensure that the
in-rush current is minimised, enabling the maximum
lifetime of the relay.
5
Subject to change without notice. Edition: 30 Jun. 2021 Ver. A0 Page 7/9

Settings (Remote Control HRC-11)
Reset Settings
Permanent ON/OFF function
Press button “ON/OFF” to select permanent ON or permanent OFF mode.
* Press button “AUTO”, “RESET” to quit this mode.
AUTO mode
Press button “AUTO” to initiate automatic mode. The sensor starts working and all
settings remain as before the light is switched ON/OFF.
1. Press button “Shift”, the red LED ashes for indication.
2. Press button “SEMI-AUTO/AUTO” to initiate semi-auto mode. The xture is
manually turned on by pressing the push-switch, and goes off automatically in this
mode. (Absence detection mode)
ON/
OFF
SEMI-AUTO mode
Press button “Shift”, the LED on the top left corner is on to indicate mode selection.
All values / settings in RED are valid for 20 seconds.
Shift Button
Press button “RESET”, all settings go back to default values as below:
Hold-time 5min, daylight threshold Disabled
&
A
4
4 hhh
HRC-11
Detection range
These buttons are disabled
These two buttons are disabled.
These two buttons are disabled.
Power output
Brightness +/-
Scene program - 1-key commissioning
1. Press button “Start” to program.
2. Select the buttons in “Detection range”, “Daylight threshold”, “Hold-time” to set all parameters.
3. Press button “Memory” to save all the settings programmed in the remote control.
4. Press button “Apply” to set the settings to each sensor unit(s).
For example, to set detection range 100%, daylight threshold Disable, hold-time 5min, the steps should be:
Press button “Start”, button ”100%”, “Disable”, “Shift”, “5min”, “Memory”. By pointing to the sensor unit(s) and pressing “Apply”, all
settings are passed on the sensor(s).
Press buttons in zone “ Daylight threshold” to set daylight sensor at 2Lux/ 10Lux / 50Lux / 100Lux / 300Lux / 500Lux / Disable.
Note: To set daylight sensor at 100Lux / 300Lux / 500Lux, press “Shift” button rst.
Daylight threshold
Subject to change without notice. Edition: 30 Jun. 2021 Ver. A0 Page 8/9

Subject to change without notice. Edition: 30 Jun. 2021 Ver. A0 Page 9/9
1. Press button “Shift”, the red LED starts to ash.
2. Press button “Ambient”, the surrounding lux level is sampled and set as the new daylight threshold.
Ambient daylight threshold
Hold-time
Press buttons in zone “hold-time” to set the hold-time at 2s / 30s / 1min / 5min / 10min / 15min / 20min / 30min.
Note: 1. To set hold-time at 30s / 5min / 15min / 30min, press “Shift” button rst.
2. 2s is for testing purpose only, stand-by period and daylight sensor settings are disabled in this mode.
*To exit from Test mode, press button “RESET” or any button in “Hold-time”.
All buttons in zone “Stand-by time ”, “Stand-by dimming level & Auto-cong“, “Dual-tech & RF mode” are disabled.
Additional Information / Documents
1. Regarding precautions for PIR sensor installation and operation, please kindly refer to
www.hytronik.com/download ->knowledge ->PIR Sensors - Precautions for Product Installation and Operation
2. Regarding Hytronik standard guarantee policy, please refer to
www.hytronik.com/download ->knowledge ->Hytronik Standard Guarantee Policy
