IBASE Technology MPT-1000V User manual

MPT-1000V
Multi-Purpose In-Vehicle System
User’s Manual
Version 1.0
(August 2021)

ii MPT-1000V User’s Manual
Copyright
© 2021 IBASE Technology, Inc. All rights reserved.
No part of this publication may be reproduced, copied, stored in a retrieval system, translated
into any language or transmitted in any form or by any means, electronic, mechanical,
photocopying, or otherwise, without the prior written consent of IBASE Technology, Inc.
(hereinafter referred to as “IBASE”).
Disclaimer
IBASE reserves the right to make changes and improvements to the products described in this
document without prior notice. Every effort has been made to ensure the information in the
document is correct; however, IBASE does not guarantee this document is error-free.
IBASE assumes no liability for incidental or consequential damages arising from
misapplication or inability to use the product or the information contained herein, nor for any
infringements of rights of third parties, which may result from its use.
Trademarks
All the trademarks, registrations and brands mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

MPT-1000V User’s Manual ii
i
Compliance
This product has passed CE tests for environmental specifications and limits. This
product is in accordance with the directives of the Union European (EU). If users
modify and/or install other devices in this equipment, the CE conformity declaration
may no longer apply.
This product has been tested and found to comply with the limits for a Class B device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with manufacturer’s instructions, may cause harmful
interference to radio communications.
This product holds the official approval as a certified in-vehicle device in accordance
with ECE type approval E24.
WEEE
This product must not be disposed of as normal household waste, in
accordance with the EU directive of for waste electrical and electronic
equipment (WEEE - 2012/19/EU). Instead, it should be disposed of by
returning it to a municipal recycling collection point. Check local
regulations for disposal of electronic products.
Green IBASE
This product is compliant with the current RoHS restrictions and
prohibits use of the following substances in concentrations exceeding
0.1% by weight (1000 ppm) except for cadmium, limited to 0.01% by
weight (100 ppm).
• Lead (Pb)
• Mercury (Hg)
• Cadmium (Cd)
• Hexavalent chromium (Cr6+)
• Polybrominated biphenyls (PBB)
• Polybrominated diphenyl ether (PBDE)

iv MPT-1000V User’s Manual
Important Safety Information
Carefully read the precautions before using the device.
Environmental conditions:
 Lay the device horizontally on a stable and solid surface in case the device may
fall, causing serious damage.
 Use this product in environments with ambient temperatures as indicated in the
Specifications in this user’s manual.
Care for your IBASE products:
 Before cleaning the device, turn it off and unplug all cables such as power in case
a small amount of electrical current may still flow.
 Use neutral cleaning agents or diluted alcohol to clean the device chassis with a
cloth. Then wipe the chassis with a dry cloth.
 Vacuum the dust with a computer vacuum cleaner to prevent the air vent or slots
from being clogged.
WARNING
Attention during use:
 Do not use this product near water.
 Do not spill water or any other liquids on your device.
 Do not place heavy objects on the top of the device.
 Operate this device from the type of power indicated on the marking label. If you
are not sure of the type of power available, consult your distributor or local power
company.
 Do not walk on the power cord or allow anything to rest on it.
 If you use an extension cord, make sure that the total ampere rating of the
product plugged into the extension cord does not exceed its limits.
Avoid Disassembly
You are not suggested to disassemble, repair or make any modification to the device.
Disassembly, modification, or any attempt at repair could generate hazards and cause
damage to the device, even bodily injury or property damage, and will void any
warranty.

MPT-1000V User’s Manual
v
CAUTION
Danger of explosion if internal lithium-ion battery is replaced by an incorrect type.
Replace only with the same or equivalent type recommended by the manufacturer.
Dispose of used batteries according to the manufacturer’s instructions.
Warranty Policy
 IBASE standard products:
24-month (2-year) warranty from the date of shipment. If the date of shipment
cannot be ascertained, the product serial numbers can be used to determine the
approximate shipping date.
 3rd-party parts:
12-month (1-year) warranty from delivery for the 3rd-party parts that are not
manufactured by IBASE, such as CPU, memory, HDD, power adapter, panel
and touchscreen.
＊ PRODUCTS, HOWEVER, THAT FAILS DUE TO MISUSE, ACCIDENT,
IMPROPER INSTALLATION OR UNAUTHORIZED REPAIR SHALL BE
TREATED AS OUT OF WARRANTY AND CUSTOMERS SHALL BE BILLED
FOR REPAIR AND SHIPPING CHARGES.
Technical Support & Services
1. Visit the IBASE website at www.ibase.com.tw to find the latest information about
the product.
2. If you need any further assistance from your distributor or sales representative,
prepare the following information of your product and elaborate upon the
problem.
 Product model name
 Product serial number
 Detailed description of the problem
 The error messages in text or in screenshots if there is any
 The arrangement of the peripherals
 Software in use (such as OS and application software, including the version
numbers)
3. If repair service is required, you can download the RMA form at
http://www.ibase.com.tw/english/Supports/RMAService/. Fill out the form and
contact your distributor or sales representative.

vi MPT-1000V User’s Manual
TableofContents
Chapter 1 General Information ................................................................ 1
1.1Introduction ................................................................................................ 2
1.2Features .................................................................................................... 2
1.3Packing List ............................................................................................... 3
1.4Specifications ............................................................................................ 4
1.5Product View ............................................................................................. 6
1.6Dimensions ................................................................................................ 9
1.7Fuse Dimensions ....................................................................................... 9
Chapter 2 Hardware Configuration ........................................................ 10
2.1Essential Installations .............................................................................. 11
2.1.1Memory Module Installation ...................................................... 12
2.1.2SSD Storage Installation ........................................................... 13
2.1.3SIM and Micro-SD Card Installation ......................................... 14
2.1.4Mini-PCIe & M.2 Network Cards Installation ............................. 15
2.1.5WiFi / 3G / 4G Antenna Installation .......................................... 16
2.1.6Mounting Brackets Installation .................................................. 17
2.2Setting the Jumpers ................................................................................. 18
2.3Jumper & Connector Locations on Motherboard ..................................... 19
2.4Jumpers Quick Reference ....................................................................... 21
2.5Connectors Quick Reference .................................................................. 27
Chapter 3 Drivers Installation ................................................................ 45
3.1Introduction .............................................................................................. 46
3.2Intel® Chipset Software Installation Utility ................................................ 46
3.3VGA Driver Installation ............................................................................ 49
3.4HD Audio Driver Installation .................................................................... 50
3.5LAN Driver Installation ............................................................................. 52
3.6Intel® Trusted Execution Engine Installation ............................................ 54
3.7Intel® Serial I/O Drivers Installation ......................................................... 56

MPT-1000V User’s Manual vi
i
Chapter 4 BIOS Setup ............................................................................. 57
4.1Introduction .............................................................................................. 58
4.2BIOS Setup .............................................................................................. 58
4.3Main Settings ........................................................................................... 59
4.4Advanced Settings ................................................................................... 60
4.5Chipset Settings ...................................................................................... 68
4.6Security Settings ...................................................................................... 70
4.7Boot Settings ........................................................................................... 72
4.8Save & Exit Settings ................................................................................ 73
Appendix ....................................................................................................... 74
A.I/O Port Address Map .............................................................................. 75
B.Interrupt Request Lines (IRQ) ................................................................. 77
C.Watchdog Timer Configuration ................................................................ 78
D.Software Development Kit for WDT.DLL ................................................. 82
E.Motherboard MCU ISP Specifications ..................................................... 88

1
Chapter 1
General Information
The information provided in this chapter includes:
 Features
 Packing List
 Specifications
 Product View
 Dimensions

2 MPT-2000V User’s Manua
l
1.1 Introduction
The MPT-1000V is vehicle-mounted computing system supporting both car
battery and DC power modes. Its robust and rugged design is based on the
Intel® Atom™ E3950 processor (model MPT-1000V) and Intel® Celeron™
N3350 (MPT-1000VN) processor. Equipped with a variety of flexible I/O
interface, the system offers high-speed data transmission and robust
connections with reliable operation in harsh environments.
1.2 Features
 Fanless and ruggedized design
 SIM socket supports Dual WWAN
 Removable 2.5” device bay
 Ignition power-on signal control
 Isolated USB, serial, DIDO ports
 Onboard isolated CANbus
 Rich I/O interfaces for wireless, SSD, GPS, WWAN and add-on card
expansion
 Add on card slots reset function
 Quick accessible RTC battery

General Information
MPT-1000V User’s Manual 3
1
1.3 Packing List
Your MPT-1000V package should include the items listed below. If any of the
items below is missing, contact the distributor or the dealer from whom you
purchased the product.
Item Q’ty IBASE P/N
MPT-1000V 1 - -
Mounting Bracket 2 - -
Terminal block for power input and
IGN 22 (3-pin) (Dinkle 5ESDVM-03P) 1 C12165ESD03105000P
Terminal block for CANbus (4-pin)
(Dinkle EC381VM-04P) 1 C1216EC3804103000P
Flat head screw, M2*L4 (A2) 2 H0220351112200000P
Flat head screw, M3*3.8 (B21) 1 H0230321112200000P
Screw for SSD / HDD
(if HDD not pre-installed) 4 H0230561B710BN000P

4 MPT-2000V User’s Manua
l
1.4 Specifications
Product Name MPT-1000V
System
Motherboard MBT-1002V
Operating
System
 Windows 10 (64-bit)
 Linux kernel 3.8.0 or above (64-bit)
CPU  Intel® Atom™ E3950, TDP: 10W (Model MPT-1000V)
 Intel® Celeron™ N3350, TDP: 6W (Model MPT-1000VN)
Memory  4GB SKU: MPT-1000VN (N3350)
 8GB SKU: MPT-1000V8G (E3950)
Graphics Intel® HD graphics Gen. 7 with 4EU
Supports DX 11, OGL 3.0, OCL 1.2, OGLES 2.0
Front I/O
 1 x DVI-D connector for display connection
 1 x VGA DSUB15
 2 x RJ45 for GbE LAN
 1 x 3,5mm blue color audio connector for line input.
 1 x 3,5mm pink color audio connector for MIC input.
 2 x external accessible SIM socket (covered)
 1 x external micro SD card slot (covered with SIM card slot)
 1 x Stack USB connector for 2 x USB3.1 (#1/#2)
 1 x DUSB9 for COM1 RS-232/422/485 port
 1 x DUB9 for COM2 RS-485 isolated port
 1 x DSUB15 for DIDO 6in / 6out isolated
 Isolation voltage • 2500 VRMS
 1 x tack switch for system reset
 1 x tack switch for add-on cards reset
 1 x tack switch for power firmware load default
 Indicators
 1 x Green color LED for power status
 1 x White color LED for storage activity status
 1 x Blue color LED for WLAN activity status (optional)
 1 x Orange color LED for WWAN activity status (optional))
 1 x Green color LED, programmable
 1 x Red color LED for warning of wrong power voltage
 1 x Blue color LED for external battery connected

General Information
MPT-1000V User’s Manual 5
1
Rear I/O
 2 x DSUB9 for COM3/4 RS232 ports
 1 x 4 pins terminal block for 2 masters CANbus
 1 x USB3.0 flag type A
 1 x audio jack for line out
 1 x tack switch for clear CMOS
 1 x open window for accessing RTC battery
 1 x 6-pin ATX connector for external battery, and 19VDC
(Max:1A) output
 1 x blade fuse socket with cover
 1 x DIP switch for selecting power mode: Car / DC
 1 x 3-pin thermal block connector for power input and IGN
Storage
 1 x accessible 2.5“ SATA space, at the front side
 1 x mSATA via miniPCIe (shared with SATA port)
 1 x micro SD slot
Expansion
 1 x mPCIe socket, support MSATA
 1 x mPCIe socket, support SIM card 2nd
 1 x M.2 Type 3042 B Key socket, USB interface only, support
SIM card 1st
Power Input
 9V ~ 32VDC input without backup battery power
 12V ~ 32VDC input with backup battery
 Ignition detection: enable(Car mode)/disable(DC mode) via
dip switch
 Reverse protection
 Red LED for power status
 Blue LED for battery charging
Dimensions
(W x H x D)
 300x158.4x66mm without side mount bracket
 332x158.4x72.5mm with side mount bracket
Environment
Temperature
 Operating:
-30°C ~70°C (w/o add on cards) MPT-1000V SKU
-10°C ~60°C (w/o add on cards) MPT-1000VN SKU
 Storage:
--40 ~ 85 °C (-40 ~ 185 °F)
Relative
Humidity 10 ~ 95% (non-condensing)
Vibration
Protection
Operating/Non-operating: 2,26 Grms (5~500 Hz) /
MIL-STD-810G composite wheeled condition (Z-axis only)
Shock
Protection
Non-operating: Sawtooth: 40G, 11 msec (Z-axis)
Operating: Sawtooth: 20G, 11msec (Z-axis)
All specifications are subject to change without prior notice.

6 MPT-2000V User’s Manua
l
1.5 Product View
Front View
No. Name No. Name
1 SwitchforAdd‐oncardsreset 8 VGAConnector
2 LineInput 9 2xUSB3.1(#1/$2)
3 MicrophoneInput A RJ45forGbE
4 DSUB15forDIDO B DSUB9forCOM1/COM2*
5 MicroSDcardslot C DVI‐DConnector
6
LEDIndicators:Power(green),
Storage(white),WLAN(blue),
WWAN(orange/option), 
Warningofwrongvoltage
connected(red)
D SSDSlot
7 Systemresetswitch E Switchforpowerfirmwareload
default
Remarks:
*COM1 (top) supports RS-232/422/485 and COM2 (bottom) supports RS-485 isolated
port.

General Information
MPT-1000V User’s Manual 7
1
Rear View
No. Name No. Name
1 CAR/DCpowermodeswitch 6 DSUB9forCOM3/4RS232
2 Terminalblockforpowerinput
andIGN22 7 USB3.0port
3 ATXconnectorforexternal
batteryand19VDC 8 Terminalblockfor2masters CANbus
4 Bladefusesocketwithcover 9 Audiojackforlineout
5 RTCbatteryaccess 0 SwitchforclearCMOS

8 MPT-2000V User’s Manua
l
Oblique View

General Information
MPT-1000V User’s Manual 9
1
1.6 Dimensions
Unit: mm
1.7 Fuse Dimensions
Littlefuse® TAC ATO® Style Blade 15A, 58V DC

10 MPT-2000V User’s Manua
l
Chapter 2
Hardware Configuration
The information provided in this chapter includes:
 Essential installations before you begin
 Information and locations of connectors

Hardware Configuration
MPT-1000V User’s Manual 11
2
2.1 Essential Installations
In general, in order to access the motherboard components, for example the
memory slot, the mPCIe slots or M.2 slot, there are a total of seven screws that
need to be removed first. After doing the necessary installation, replacement or
changes, put the screws back and tighten them. Please refer to the two
pictures below for the location of the screws to be removed.

12 MPT-1000V User’s Manual
2.1.1 Memory Module Installation
The memory of the MPT-1000V is onboard type, there is no additional memory
socket for expansion.
