IBM CI5VGM Series User manual

CI5VGM Series
Full-Size Pentium All-in-one CPU Card
Version 1.0A
Industrial CPU Card
PC-Based Computer Boards for Industrial Automation
User’s Manual

ii CI5VGM User’s Manual
Copyright Notice
This publication is protected by copyright and all rights are reserved. No
part of it may be reproduced or transmitted by any means or in any form,
without prior consent of the original manufacturer.
The information in this document has been carefully checked and is
believed to be accurate. However, the original manufacturer assumes no
responsibility for any inaccuracies that may appear in this manual. In no
event will the original manufacturer be liable for direct, indirect, special,
exemplary, incidental, incidental or consequential damages resulting
from any defect or omission in this manual, even if advised of possibility
of such damages. The material contained herein is for informational
purposes only.
Acknowledgments
Award is a registered trademark of Award Software International, Inc.
Cyber 9520/25 is a trademark of Trident Technologies Inc.
IBM, PS/2 are trademarks of International Business Machines
Corporation.
Intel and Pentium are registered trademarks of Intel Corporation.
Microsoft Windows is a registered trademark of Microsoft Corporation.
MVP3 is a registered trademark of VIA Technologies Inc.
All other product names or trademarks are properties of their respective
owners.

Contents
CI5VGM User’s Manual iii
Contents
Chapter 1 Introduction............................................. 1
Checklist.....................................................................3
Description.................................................................3
Features......................................................................4
Specifications.............................................................4
Intelligence.................................................................7
Board Dimensions .....................................................8
Chapter 2 Installations........................................... 10
CPU Installation......................................................11
Memory Installation................................................12
Jumpers on the CI5VGM.......................................14
Connectors on the CI5VGM...................................24
Watchdog Timer Configuration ............................37
Chapter 3 BIOS Configuration.............................. 38
Chapter 4 Audio Driver Installation Guide.......... 65
Chapter 5 VGA Driver Installation Guide........... 77
Chapter 6 System Monitor Utility......................... 97
Chapter 7 LANDesk Client Manager ................. 105
Chapter 8 Ethernet Setup User’s Guide............. 113
Appendix................................................................. 126
A. I/O Port Address Map.....................................127
B. Interrupt Request Lines (IRQ).......................128

Chapter 1 Introduction
CI5VGM User’s Manual 1
Below are additional information for LCD Panel Type Select
and settings for newer CPUs
SW3: LCD Panel Type Select
1 2 3 4 TFT LCD Panel
ON ON ON ON 640x480 –18
OFF ON ON ON 800x600 –18
ON OFF ON ON 1024x768 –18
OFF OFF ON ON 1024x768 –18+18
ON ON OFF ON 1280x1024 –18+18
1 2 3 4 DSTN LCD Panel
ON ON ON OFF 640x480 –16
OFF ON ON OFF 800x600 –16
ON OFF ON OFF 1024x768 –16
OFF OFF ON OFF 1024x768 –24
ON ON OFF OFF 1280x1024 –24
Settings for New Cyrix/AMD CPUs
on off off on off off off off
95MHz 63MHz 3.5x
MII-400
(333MHz)
off off off on off off off off
100MHz 66MHz 3.5x
MII-433
(350MHz)
on off off on on off on off
95MHz 63MHz 4x
MII-450
(380MHz)
off off off on on off on off
100MHz 66MHz 4x
MII-466
(400MHz)
on off off on off on on off
95MHz 63MHz 5x K6-2/475
K6-3/475
off off off on off on on off
100MHz 66MHz 5x K6-2/500
K6-3/500

Chapter 1 Introduction
2 CI5VGM User’s Manual
1
Introduction
This manual is designed to give you information on the CI5VGM CPU
card. It is divided into the following sections:
Checklist.......................................................................................3
Description....................................................................................3
Features.........................................................................................4
Specifications................................................................................4
Intelligence ...................................................................................7
Board Dimensions.........................................................................8
The topics covered in this chapter are as follows:
 Checklist
 Description
 Features
 Specifications
 Layout of Key Components and Dimensions

Chapter 1 Introduction
CI5VGM User’s Manual 3
Checklist
Please check that your package is complete and contains the items below.
If you discover damaged or missing items, please contact your dealer.
•
••
•
The CI5VGM Industrial CPU Card
•
••
•
This User’s Manual
•
••
•
1 IDE Ribbon Cable
•
••
•
1 Floppy Ribbon Connector
•
••
•
2 Serial Port Ribbon Cable and 1 Parallel Port Attached to a
Mounting Bracket
•
••
•
1 Audio Output Ribbon Cable and EXTVGM Daughter Card
Audio I/O Connector (supplied onlyif the CPU card has the audio
capability)
•
••
•
1 Diskette Containing VIA PCI IDE Driver and Flash Memory
Utility, VIA IRQ Routing Driver, VIA VxD Driver
•
••
•
2 Diskettes Containing Trident 9520/25 VGA Driver
•
••
•
2 Diskettes Containing Intel 82558B LAN Driver
•
••
•
5 Diskettes Containing YAMAHA 715 Audio Driver
•
••
•
1 Diskette Containing System Monitor Utility
•
••
•
1 Optional CD containing Intel LANDesk Client Manager
Description
The CI5VGM is a Pentium Industrial CPU card based on the VIAMVP3
chipset and is fully designed for harsh industrial environment. It features
a Socket 7 processor connector that is compatible with Pentium-level
processors from Intel, Cyrix, AMD and IDT. With three DIMM sockets
on board, this card accommodates up to 384MB of system memory.
The CI5VGM comes with Winbond’s W83781D hardware monitoring
device that monitors system and CPU temperature, system voltages, and
CPU and chassis fan speeds to prevent system crashes by warning the
user of adverse conditions. The power management feature provides
power savings by slowing down the CPU clock, turning off the monitor
screen and stopping the HDD spindle motor.

Chapter 1 Introduction
4 CI5VGM User’s Manual
Features
•
••
•
Socket 7, CPU Speed 90~550MHz
•
••
•
Bus Speed 60/66/75/83/95/100MHz
•
••
•
VIA MVP3 AGPset
•
••
•
Up to 384MB of system memory, ECC function supported
•
••
•
Trident 9520/25 AGP VGA chipset for LCD & CRT display
•
••
•
YAMAHA 715 Audio Chip
•
••
•
16 level programmable watchdog timer, from 0-30 seconds
•
••
•
High speed bi-directional SPP/ECP/EPP parallel port
•
••
•
ISA High Drive
•
••
•
2MB~72MB DiskOnChip support
•
••
•
Hardware Monitoring
•
••
•
Win95 shut-off, Modem ring-on via ATX power
•
••
•
10/100M Base-T Ethernet interface, IEEE 802.3 compliance
specification
•
••
•
Port 80 display LED
•
••
•
COM2 supports RS232/433/485
Specifications
•
••
•
Processor Socket: Socket 7 connector
•
••
•
Processor:
Intel Pentium 120/133/150/166/200
Intel Pentium MMX (P55C) 166/200/233
Cyrix 6x86/6x86L P150+/P166+/P200+
Cyrix 6x86MX PR166/PR200/PR233/PR266
Cyrix 6x86MII PR266/PR300/PR333/PR366
AMD K5 PR166
AMD K6 166/200/233/266/300
AMD K6-2/300/333/350/366/380/400/450
IDT WinChip C6 180/200/225MHz
IDT WinChip2-3D 200/225/266MHz
•
••
•
Chipset: VIA MVP3 AGPset with PCI EIDE and RTC built-in
•
••
•
Secondary Cache: 1 MB

Chapter 1 Introduction
CI5VGM User’s Manual 5
•
••
•
Memory Sockets:
Three 168-pin DIMM sockets
Memory types: SDRAM (Synchronous DRAM)
DIMMs: EDO DRAM or SDRAM (Synchronous DRAM)
DIMM Size: 8MB, 16MB, 32MB, 64MB, 128MB
•
••
•
BIOS: Y2K compliant Award BIOS, PnP support
•
••
•
FLASH EEPROM (256KB) for BIOS update
•
••
•
ISA Plug and Play (PnP) extension
•
••
•
Power management
•
••
•
DMI BIOS Support:
Desktop Management Interface (DMI) allows users to download
system hardware-level information such as CPU type, CPU
speed, internal/external frequencies and memory size.
•
••
•
Multi I/O: Winbond W83877TF
•
••
•
Parallel Port: One high-speed parallel port, SPP/EPP/ECP mode
•
••
•
Serial Port: Two 16550 UART compatible ports with COM1 as
RS232 and COM2 jumper configurable as RS232/422/485
•
••
•
Enhanced IDE: Two Bus Mastering EIDE mode, up to 4 devices,
Two EIDE interfaces for up to four devices, support PIO Mode 3/4
or Ultra DMA/33 IDE Hard Disk, LS-120 and ATAPI CD-ROM.
•
••
•
FDD Interface: Two floppy drives (360KB, 720KB, 1.2MB,
1.44MB, 2.88MB)
•
••
•
AGP bus CRT/LCD: Trident 9520/25 chipset
•
••
•
Embedded 2MB/2.5MB (9520/9525) SDRAM display
memory
•
••
•
Simultaneous CRT & LCD display
•
••
•
LCD panel supports DSTN/TFT
•
••
•
1600x1200x256 colors CRT resolution
•
••
•
Up to 1280x1024x64K colors resolution for color active
matrix TFT panels (12, 18, and 24bit analog) or (12+12),
(18+18) double pixel/CLK interface
•
••
•
USB Interface: Two USB pin-header connectors, compliant with
USB Specification Rev. 1.0

Chapter 1 Introduction
6 CI5VGM User’s Manual
•
••
•
Onboard Audio (optional): The onboard audio consists of a
YAMAHA YMF715-S (OPL3-SA3) single audio chip that
integrates OPL3 and its DAC, 16bit Sigma-delta CODEC,
MPU401 MIDI interface, joystick with timer, and a 3D enhanced
controller including all the analog components which is suitable
for multimedia application.
•
••
•
DiskOnChip: The M-Systems flask disk supports systemboot and
storage capacity from 2MB to 72MB.
•
••
•
Watchdog Timer: 16-level, programmable
•
••
•
I/O port 0443H to enable watchdog.
•
••
•
I/O port 0441H to disable watchdog.
•
••
•
Time-out timing select 0/2/4/6/8/10/12/14/16/18/20/22/
24/26/28/30 seconds (+/-20%).
•
••
•
PCI Bus Ethernet Interface: Intel 82558B
•
••
•
PCI local bus Ethernet controller
•
••
•
IEEE802.3u auto-negotiation for automatic speed selection
•
••
•
10/100Mbps operation in a single port PCI bus master
architecture
•
••
•
Wake On LAN function support on board
•
••
•
Green Function: Power management via BIOS, activated through
mouse/keyboard movement
•
••
•
Keyboard and Mouse Connectors: PS/2 type mini-DIN that
supports PC/AT; supports a 5-pin external keyboard connector
•
••
•
IrDA Interface: Pin-header connector for the optional IrDA
external connector
•
••
•
PICMG Compliance: Fully compliant to PICMG standards
•
••
•
Environmental and Mechanical:
•
••
•
AT Power Supply: Max. 15A @+5V
•
••
•
ATX Power Supply: Min 1A @+5VSB, Max15A@+5V
•
••
•
Temperature: 0°C to 60°C
•
••
•
Humidity: 5% to 95%
•
••
•
Dimensions: 338mm x 122mm

Chapter 1 Introduction
CI5VGM User’s Manual 7
Intelligence
•
••
•
Temperature Monitoring and Alert: A sensor for the CPU
temperature on the CI5VGM monitors the CPU temperature and
alerts the user through the speaker or buzzer when temperature
exceeds the safe heat level.
•
••
•
Windows 95 shut-off: Allows shut-off control from within
Windows 95 and through an ATX power supply.
•
••
•
Modem ring-on: Allows system powering on through an external
modem and through an ATX power supply.
•
••
•
Year 2000 Compliant BIOS: The onboard Award BIOS is Year
2000 Compliant and will pass software applications that have the
tendency to invoke INT1AH function 04H such as year2000.exe
utility released by NSTL.

Chapter 1 Introduction
8 CI5VGM User’s Manual
Board Dimensions

Chapter 1 Introduction
CI5VGM User’s Manual 9
This page is intentionally left blank .

Chapter 2 Installations
10 CI5VGM User’s Manual
2
Installations
This chapter provides information on how to use the jumpers and
connectors on the CI5VGM in order to set up a workable system. The
topics covered are:
CPU Installation..........................................................................11
Memory Installation....................................................................12
Jumpers on the CI5VGM............................................................14
Connectors on the CI5VGM.......................................................24
Watchdog Timer Configuration..................................................37

Chapter 2 Installations
CI5VGM User’s Manual 11
CPU Installation
The CI5VGM Industrial CPU Card supports a ZIF processor socket for
Pentium-level processors.
Unlike PGA sockets, ZIF (Zero Insertion Force) sockets come with a
lever to secure the processor. Make sure the notch on the corner of the
CPU corresponds with the notch on the inside of the socket.
After you have installed the processor into the ZIF socket, check if the
jumpers for the CPU type and speed are correct.
NOTE: Ensure that the CPU heat sink and the CPU top surface are in
total contact to avoid CPU overheating problem that would
cause your system to hang or be unstable.

Chapter 2 Installations
12 CI5VGM User’s Manual
Memory Installation
The CI5VGM Industrial CPU Card supports three 168-pin DIMM
sockets for a maximum total memory of 384MB. The memory modules
can come in sizes of 16MB, 32MB, 64MB, 128MB in EDO DRAM or
SDRAM type.
In populating the DIMM sockets, DIMM1, DIMM2 or DIMM3 can be
populated first. Refer to the following table on how to configure the
memory.
NOTE: You must install memory modules of the same type, either all
SDRAM or all EDO DRAM.
168Pin DIMM (3.3V) - SDRAM or EDO DRAM
(DIMM3) (DIMM2) (DIMM1) Total Memory
8MB ----- ----- 8MB
16MB ----- ----- 16MB
32MB ----- ----- 32MB
64MB ----- ----- 64MB
128MB ----- ----- 128MB
8MB 8MB ----- 16MB
16MB 8MB ----- 24MB
32MB 8MB ----- 40MB
64MB 8MB ----- 72MB
128MB 8MB ----- 136MB
8MB 8MB 8MB 24MB
16MB 8MB 8MB 32MB
32MB 8MB 8MB 48MB
64MB 8MB 8MB 80MB
128MB 8MB 8MB 144MB
16MB 16MB ----- 32MB
32MB 16MB ----- 48MB
64MB 16MB ----- 80MB
128MB 16MB ----- 144MB
16MB 16MB 8MB 40MB
32MB 16MB 8MB 56MB
64MB 16MB 8MB 88MB
128MB 16MB 8MB 152MB

Chapter 2 Installations
CI5VGM User’s Manual 13
168Pin DIMM (3.3V) - SDRAM or EDO DRAM (continued)
(DIMM3) (DIMM2) (DIMM1) Total Memory
16MB 16MB 16MB 48MB
32MB 16MB 16MB 64MB
64MB 16MB 16MB 96MB
128MB 16MB 16MB 160MB
32MB 32MB ----- 64MB
64MB 32MB ----- 96MB
128MB 32MB ----- 160MB
32MB 32MB 8MB 72MB
64MB 32MB 8MB 104MB
128MB 32MB 8MB 168MB
32MB 32MB 16MB 80MB
64MB 32MB 16MB 112MB
128MB 32MB 16MB 176MB
32MB 32MB 32MB 96MB
64MB 32MB 32MB 128MB
128MB 32MB 32MB 192MB
64MB 64MB ----- 128MB
128MB 64MB ----- 192MB
64MB 64MB 8MB 136MB
128MB 64MB 8MB 200MB
64MB 64MB 16MB 144MB
128MB 64MB 16MB 208MB
64MB 64MB 32MB 160MB
128MB 64MB 32MB 224MB
64MB 64MB 64MB 192MB
128MB 64MB 64MB 256MB
128MB 128MB 128MB 384MB

Chapter 2 Installations
14 CI5VGM User’s Manual
Jumpers on the CI5VGM
The jumpers on the CI5VGM allows you to configure your CPU card
according to the needs of your applications. If you have doubts about the
best jumper configuration for your needs, contact your dealer or sales
representative. The following table lists the connectors on CI5VGM and
their respective functions.
Jumper Locations on the CI5VGM ....................................15
SW1(1-8): CPU Frequency Selector..................................16
JP2: SDRAM Operating Frequency...................................19
SW2(1-4): CPU Voltage Selector ......................................19
JP3: LCD Power Setting.....................................................21
JP4: CRT/LCD Display Selection......................................21
JP6: DiskOnChip BIOS Expansion Address Select ...........22
J11: RS232/422/485 (COM2) Selection.............................22
J24: Clear CMOS Content..................................................23
W1: Power Supply Select..................................................23

Chapter 2 Installations
CI5VGM User’s Manual 15
Jumper Locations on the CI5VGM

Chapter 2 Installations
16 CI5VGM User’s Manual
SW1(1-8): CPU Frequency Selector
For Intel Pentium, IDT WinChip 2-3D / C6
SW1 CPU
Clock AGP Clock Multiplier CPU FREQ.
on on on off off off off on 60MHz 60MHz 1.5x P54C-90
off on on off off off off on 66MHz 66MHz 1.5x P54C-100
on on on offon offoff on 60MHz 60MHz 2x P54C-120
off on on off on off off on 66MHz 66MHz 2x P54C-133
on on on off on on offon 60MHz 60MHz 2.5x P54C-150
off on on off on on off on 66MHz 66MHz 2.5x P54C/P55C-16
6
on on on off off onoff on 60MHz 60MHz 3x
C6-180
off on on off off on off on 66MHz 66MHz 3x
P54C/P55C-200
WinChip 2-3D
/ C6-200
off on on off off off off on 66MHz 66MHz 3.5x P55C-233
off off on off off on off on 75MHz 75MHz 3x
WinChip 2-3D
/ C6-225
off on on off on off on on 66MHz 66MHz 4x
WinChip 2-3D
266
