IBM 3745 Series Quick setup guide

I
3745 Communication Controller All Models
3746 Nways Multiprotocol Controller Model 900
Connection and Integration Guide
-~-.-
----
- - ---
---
- -. ---
--- ---
-----
----,-
SA33-0129-10

'0
"
o
o
o
o
3745 Communication Controller All Models
3746 Nways Multiprotocol Controller Model 900
Connection and Integration Guide
----
----
-- ---
---
-- ---
- -- ---
-----
--_.-
SA33-0129-10

Note! --------------------------------------------------------------------~
Before using this information and the product it supports, be sure to read the general information under
"Notices" on page xi.
Eleventh Edition (May 1997)
The information contained in this guide is subject to change from time to time. Any such changes will be reported in later revisions.
Order publications through your IBM representative or the IBM branch office serving your locality. Publications are not stocked at the
address given below.
A form for readers' comments appears at the back of this publication. If the form has been removed, address your comments
to:
IBM France
.Centre d'Etudes et Recherches
Service 0798 -BP 79
06610 La Gaude,
France
• FAX: [phone]
• E-mail: FRIBMQF5 at IBMMAIL
• IBM Internal Use: LGERCF at LGEPROFS
• Internet: [email protected]
When you send information to IBM, you grant IBM a non-exclusive right to use or distribute the information
in any way it believes
appropriate without incurring any obligation to you.
© Copyright International Business Machines Corporation 1988, 1997. All rights reserved.
Note to U.S. Government Users -Documentation related to restricted rights -Use, duplication or disclosure is subject to
restrictions set forth in GSA ADP Schedule Contract with IBM Corp.
o
,
•
o

o Contents
Figures
....... vii
Tables
........ ix
Notices .......................................... xi
European Union (EU) Statement ............................ xi
Electronic Emission Notices ............................... xi
• Trademarks and Service Marks
........................... xii
Safety
.......................................... xiii
Safety Notices for United Kingdom
........................ xiii
About this Guide ................................... xv
c Conventions Used
in this Guide ........................... xv
Who Should Use this Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . .
.. xv
How this Guide
is Organized ............................. xvi
What is New
in this Guide ............................. " xvi
Where to Find More Information
........................... xvii
World Wide Web
.................................. xvii
Part 1. Connecting
o Chapter 1. 3745 Models 210
to 61A: Connecting LICs and Cables 1-1
Getting Started ..................................... 1-2
Unplugging or Plugging
In an Ethernet LAN AUI Cable .............. 1-7
Unplugging or Plugging
In a Token-Ring Adapter (TRA) Cable ........ 1-11
Unplugging or Plugging In a High-Speed Scanner (HSS) Cable ........ 1-13
Unplugging or Plugging
In an Operator Console Cable ............. 1-15
Unplugging or Plugging
In the Remote Support Facility (RSF) Cable ..... 1-16
I Removing or Installing the Customer Power Control (CPC) Cable
...... 1-18
Removing or Installing a Line Interface Coupler (LlC) or Its Cable
...... 1-18
10
Chapter 2. 3745 Models 130 to 17A: Connecting LlCs and Cables 2-1
Getting Started ..................................... 2-2
Unplugging or Plugging
In an Ethernet LAN AUI Cable .............. 2-4
Unplugging or Plugging
In a Token-Ring Adapter (TRA) Cable ......... 2-7
Unplugging or Plugging In a High-Speed Scanner (HSS) Cable
......... 2-8
Unplugging or Plugging
In an Operator Console Cable .............. 2-9
Unplugging or Plugging
In the Remote Support Facility (RSF) Cable ..... 2-11
Removing or Installing the Customer Power Control (CPC) Cable
...... 2-12
Removing or Installing a Line Interface Coupler (LlC) or Its Cable
...... 2-13
Chapter 3. 3746-900: Installing LCBs and ARCs, Connecting Cables ... 3-1
Connection Tasks ................................... 3-2
Starting Connection Tasks
.............................. 3-2
Unplugging or Plugging
in a TIC3 Cable ...................... 3-5
o Unplugging or Plugging
in LlC Cables ........................ 3-7
Unplugging or Plugging
In an Ethernet LAN Cable ................ 3-9
Unplugging or Plugging
In an AUI Cable ..................... 3-9
Unplugging
or Plugging In a 10BASE-T Cable ................ 3-11
© Copyright IBM Corp. 1988, 1997 iii

Unplugging or Plugging in a Multiaccess Enclosure Adapter Cable ...... 3-12 '(.),"
Installing an LC8 ................................... 3-13 "'__ '
Removing
or Installing ARC Assembly A . . . . . . . . . . . . . . . . . . .. 3-18
Removing
or Installing ARC Assembly 8 . . . . . . . . . . . . . . . . . . .. 3-24
Part 2. Integrating
Chapter 4. Starting the 3745 Integration 4-1
Starting Procedure .......... . 4-1
If
Chapter 5. Integration Procedures
5-1
MOSS-E Integration Functions (3746-900 Only) . 5-1
Initial Installation ........................ .
5-1
Updating the Active CDF-E (3746-900 Only) ........... .
5-1
Saving the Controller Configuration .... . 5-5
MOSS Integration Procedures . . . . . . . . . . . . . . . . 5-5
Integrating an Initial Installation ............... . 5-6
\"---- /
Integrating a Later Modification ........... . 5-6
Conventions Used
in this Chapter for the MOSS ..... . 5-6
Upgrading
or Updating CDF .................. . 5-7
When to Use Upgrade or Update
.............. . 5-7
Upgrade Procedure
............ . . . . . 5-8
Update Procedure
....................... . 5-10
Changing Passwords on the 3745 MOSS ............. . 5-14
Setting Power On Schedule ..................... . 5-16
Updating Link IPL Ports
....................... . 5-17
IPL Ports on 3745 (All Models) ............... . 5-17
Link IPL Ports on 3746-900. .
................ . 5-18
IPL and Loading the Network Control Program ....... . 5-18
Saving MOSS from Fixed Disk onto Diskettes
........ . 5-19
Putting the MOSS On-Line .................... .
5-21
Part 3. Appendices
Appendix A. LSS Characteristics and Line Weights ............ A-1
Characteristics of the LSSs ............................. A-1
Line Weight Calculation ............................... A-1
Scanner Capacity ............. ;. . . . . . . . . . . . . . . . . . . .. A-2
Mixing Line Interface Couplers
......................... A-3
Spare Lines
....... . . . . . . . . . . . . . . . . A-3
Selective Scanning . . . . . . . . . . . . . . . . . . . . . . . . . . . .. A-3
Appendix B. Communication Line Processor Characteristics and Line
Weights
........................... ...... 8-1
Characteristics of the CLPs ............................. 8-1
Communication Line Processor Connectivity ................. 8-1
Characteristics of L1C Types 11, 12, and 16 .. . . . . . . . . . . . . . . .. 8-2
Maximum Configuration of a 3745 with a 3746-900
............. 8-3
Configuring Communication Lines
on the 3746-900 (Line Weights) .. 8-4
CF3745 Hardware Configurator (Standard Line Weights)
...... 8-4
Appendix C. Bibliographies
C-1
iv 3745 All Models &3746-900: CIG

o
•
o
o
o
o
Customer Documentation for the IBM 3745 (Models 210,310,410,610, 21A,
31A, 41A, and 61A), and 3746 (Model 900)
.... . . . . . . . . . . . . . .. C-1
Additional Customer Documentation for the IBM 3745 Models 130, 150, 160,
170, and 17A
.................................... C-5
Abbreviations, Glossary, and Index
List of Abbreviations
X-1
Glossary X-3
Index .......................................... X-9
Contents V

•
