IBM x 340 Series Owner's manual

IBM
Hardware Maintenance Manual
xSeries 340 Model 6RY

IBM
Hardware Maintenance Manual
xSeries 340 Model 6RY

Note: Before using this information and the product it supports, be sure to read the general information under
“Notices”on page 177.
Second Edition (November 2000)
The following paragraph does not apply to the United Kingdom or any country were such provisions are inconsistant
with local law:
INTERNATIONAL BUSINESS MACHINES CORPORATION PROVIDES THIS PUBLICATION "AS IS" WITHOUT
WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Some states do not allow
disclaimer of express or implied warranties in certain transactions, therefore, this statement may not apply to you.
This publication could include technical inaccuracies or typographical errors. Changes are periodically made to the
information herein; these changes will be incorporated in new editions of the publication. IBM may make improvements
and/or changes in the product(s) and/or the program(s) described in this publication at any time.
This publication was developed for products and services offered in the United States of America. IBM may not offer the
products, services, or features discussed in this document in other countries, and the information is subject to change
without notice. Consult your local IBM representative for information on the products, services, and features available in
your area.
Requests for technical information about IBM products should be made to your IBM reseller or IBM marketing
representative.
© Copyright International Business Machines Corporation 2000. All rights reserved.
US Government Users Restricted Rights –Use, duplication or disclosure restricted by GSA ADP Schedule Contract with
IBM Corp.

© Copyright IBM Corp. 2000 iii
About this manual
This manual contains diagnostic information, a Symptom-to-FRU index, service
information, error codes, error messages, and configuration information for the IBM®
xSeries 340.
Important: This manual is intended for trained servicers who are familiar with IBM
PC Server products.
Important safety information
Be sure to read all caution and danger statements in this book before performing any
of the instructions.
Leia todas as instruções de cuidado e perigo antes de executar qualquer operação.

iv Hardware Maintenance Manual: xSeries 340 Model 6RY
Prenez connaissance de toutes les consignes de type Attention et
Danger avant de procéder aux opérations décrites par les instructions.
Lesen Sie alle Sicherheitshinweise, bevor Sie eine Anweisung ausführen.
Accertarsi di leggere tutti gli avvisi di attenzione e di pericolo prima di effettuare
qualsiasi operazione.
Lea atentamente todas las declaraciones de precaución y peligro ante de llevar a cabo
cualquier operación.
Online support
Use the World Wide Web (WWW) to download Diagnostic, BIOS Flash, and Device
Driver files, and documents.
The web address is:
http://www.ibm.com/pc/support

© Copyright IBM Corp. 2000 v
Contents
About this manual . . . . . . . . . . . . . . . . . . . iii
Important safety information . . . . . . . . . . . . . . . . . . . . . . iii
Online support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
General checkout. . . . . . . . . . . . . . . . . . . . . 1
General information. . . . . . . . . . . . . . . . . . . 3
Features and specifications . . . . . . . . . . . . . . . . . . . . . . . . 3
Server features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Reliability, availability, and serviceability features . . . . 6
Controls and indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Operator information panel. . . . . . . . . . . . . . . . . . . . . . . 10
Diagnostics. . . . . . . . . . . . . . . . . . . . . . . . . 11
Diagnostic tools overview . . . . . . . . . . . . . . . . . . . . . . . . 11
Identifying problems using LEDs. . . . . . . . . . . . . . . . . . 11
Power supply LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Light path diagnostics. . . . . . . . . . . . . . . . . . . . . . . . . 11
Diagnostics panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Light path diagnostics table . . . . . . . . . . . . . . . . . . . . 12
POST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
POST error messages. . . . . . . . . . . . . . . . . . . . . . . . . . 13
Event/error logs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Small computer system interface messages . . . . . . . . . 13
Diagnostic programs and error messages . . . . . . . . . . . 13
Text messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Starting the diagnostic programs . . . . . . . . . . . . . . . 14
Viewing the test log . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Diagnostic error message tables . . . . . . . . . . . . . . . . 15
Recovering BIOS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Troubleshooting the Ethernet controller . . . . . . . . . . . . 16
Network connection problems. . . . . . . . . . . . . . . . . . 16
Ethernet controller troubleshooting chart . . . . . . . . 17
Ethernet controller messages. . . . . . . . . . . . . . . . . . . . . . 19
Novell NetWare or IntraNetWare server ODI driver
messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Network driver interface specification 2.01 (OS/2)
driver messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
NDIS 4.0 (Windows NT) driver messages . . . . . . . . 23
UNIX messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Power checkout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Replacing the battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Temperature checkout . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Configuring the server . . . . . . . . . . . . . . . 29
Using the Configuration/Setup Utility program . . . . . 29
Starting the Configuration/Setup Utility program 29
Choices available from the Configuration/Setup main
menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Using passwords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Power-on password . . . . . . . . . . . . . . . . . . . . . . . . 33
Administrator password . . . . . . . . . . . . . . . . . . . . 35
Using the SCSISelect utility program. . . . . . . . . . . . . . . 35
Starting the SCSISelect utility program . . . . . . . . . . 35
Choices available from the SCSISelect menu . . . . . 36
Installing options. . . . . . . . . . . . . . . . . . . . 39
Exploded view of the xSeries 340 server . . . . . . . . . . . . 39
System board layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
System board options connectors . . . . . . . . . . . . . . . 40
System board internal cable connectors . . . . . . . . . . 41
System board external port connectors . . . . . . . . . . 41
System board switches and jumpers. . . . . . . . . . . . . 42
System board LED locations. . . . . . . . . . . . . . . . . . . . 44
Before you begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
System reliability considerations. . . . . . . . . . . . . . . . 45
Working inside a server with power on . . . . . . . . . . 46
Handling static-sensitive devices. . . . . . . . . . . . . . . . 46
Removing the cover and bezel. . . . . . . . . . . . . . . . . . . . . 47
Working with adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Adapter considerations . . . . . . . . . . . . . . . . . . . . . . . . 48
Adapter installation instructions. . . . . . . . . . . . . . . . . . . 49
Installing internal drives. . . . . . . . . . . . . . . . . . . . . . . . . . 50
Internal drive bays . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
SCSI drives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
SCSI IDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Installing a hot-swap drive . . . . . . . . . . . . . . . . . . . . . . . 52
Installing a non-hot-swap drive . . . . . . . . . . . . . . . . . . . 53
Installing a microprocessor . . . . . . . . . . . . . . . . . . . . . . . 55
Installing a hot-swap power supply. . . . . . . . . . . . . . . . 57
Replacing a hot-swap fan assembly . . . . . . . . . . . . . . . . 59
Installing the server cover and bezel . . . . . . . . . . . . . . . 60
Connecting external options . . . . . . . . . . . . . . . . . . . . . . 61
Cabling requirements . . . . . . . . . . . . . . . . . . . . . . . . . 61
Setting SCSI IDs for external devices . . . . . . . . . . . . 61
Installation procedure . . . . . . . . . . . . . . . . . . . . . . . . . 61
Input/Output ports. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Parallel port. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Viewing or changing the parallel-port assignments
62
Parallel port connector. . . . . . . . . . . . . . . . . . . . . . 63
Video port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Keyboard port. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Auxiliary-device (pointing device) port . . . . . . . . . . 65
Ultra3 SCSI ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
SCSI cabling requirements. . . . . . . . . . . . . . . . . . . 65
Setting SCSI IDs . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
SCSI connector pin-number assignments . . . . . . 66
Serial ports. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Viewing or changing the serial-port assignments 67
Serial-port connectors. . . . . . . . . . . . . . . . . . . . . . . 68
Universal Serial Bus ports. . . . . . . . . . . . . . . . . . . . . . 68
USB cables and hubs. . . . . . . . . . . . . . . . . . . . . . . . 68
USB-port connectors. . . . . . . . . . . . . . . . . . . . . . . . 68
Ethernet port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Configuring the Ethernet controller. . . . . . . . . . . 69
Failover for redundant Ethernet . . . . . . . . . . . . . . 69
Ethernet port connector . . . . . . . . . . . . . . . . . . . . . 73
Advanced System Management ports . . . . . . . . . . . 73
Cabling the server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Netfinity Manager . . . . . . . . . . . . . . . . . . . 75
Managing your IBM Netfinity server with Netfinity
Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Netfinity Manager documentation . . . . . . . . . . . . . . . . . 75
Netfinity Manager system requirements . . . . . . . . . . . . 76
Netfinity Manager for OS/2 system requirements . 76
Netfinity Manager for Windows 95 and Windows 98
system requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Netfinity Manager for Windows NT system
requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

vi Hardware Maintenance Manual: xSeries 340 Model 6RY
Starting the Netfinity Manager installation program . 78
Netfinity Manager database support . . . . . . . . . . . . . . . 83
DB2 database support . . . . . . . . . . . . . . . . . . . . . . . . . 84
System requirements . . . . . . . . . . . . . . . . . . . . . . . 84
Installing and configuring the database . . . . . . . 84
Activating the database . . . . . . . . . . . . . . . . . . . . . 85
Granting and revoking database privileges . . . . 85
Deleting the database. . . . . . . . . . . . . . . . . . . . . . . 87
Lotus Notes database support . . . . . . . . . . . . . . . . . . 88
System requirements . . . . . . . . . . . . . . . . . . . . . . . 88
Installing the database. . . . . . . . . . . . . . . . . . . . . . 88
Browsing the Netfinity Manager Lotus Notes
database . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
ODBC database support . . . . . . . . . . . . . . . . . . . . . . . 90
System requirements . . . . . . . . . . . . . . . . . . . . . . . 90
ODBC database configuration . . . . . . . . . . . . . . . 90
Creating the Netfinity Manager tables . . . . . . . . 91
Supported and certified databases. . . . . . . . . . . . 92
Starting Netfinity Manager . . . . . . . . . . . . . . . . . . . . . . . 93
Netfinity Manager Service Manager. . . . . . . . . . . . . 93
Netfinity Manager service descriptions . . . . . . . . . . 94
Advanced System Management. . . . . . . . . . . . . . 94
Alert Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Alert on LAN configuration . . . . . . . . . . . . . . . . . 95
Capacity Management. . . . . . . . . . . . . . . . . . . . . . 95
Cluster Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Critical File Monitor . . . . . . . . . . . . . . . . . . . . . . . . 95
DMI Browser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
ECC Memory Setup . . . . . . . . . . . . . . . . . . . . . . . . 95
Event Scheduler . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
File Transfer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Power-On Error Detect . . . . . . . . . . . . . . . . . . . . . 96
Predictive Failure Analysis . . . . . . . . . . . . . . . . . . 96
Process Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
RAID Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Remote Session . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Remote System Manager. . . . . . . . . . . . . . . . . . . . 96
Remote Workstation Control . . . . . . . . . . . . . . . . 97
Screen View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Security Manager . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Serial Connection Control . . . . . . . . . . . . . . . . . . . 97
Service Configuration Manager . . . . . . . . . . . . . . 97
Software Inventory. . . . . . . . . . . . . . . . . . . . . . . . . 97
System Diagnostics Manager . . . . . . . . . . . . . . . . 97
System Information Tool . . . . . . . . . . . . . . . . . . . . 98
System Monitor. . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
System Partition Access. . . . . . . . . . . . . . . . . . . . . 98
System Profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Update Connector Manager . . . . . . . . . . . . . . . . . 98
Web Manager Configuration . . . . . . . . . . . . . . . . 98
Delaying Netfinity Manager startup on OS/2 systems
99
Getting more information about Netfinity Manager . . 99
Installation options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
Automated installation . . . . . . . . . . . . . . . . . . . . . . . 100
Customized installation . . . . . . . . . . . . . . . . . . . . . . 101
FRU information (service only) . . . . . . . 105
Removing the LED cover . . . . . . . . . . . . . . . . . . . . . . . . 105
Removing the on/off reset board . . . . . . . . . . . . . . . . . 106
Removing the diskette/CDROM drive . . . . . . . . . . . . 106
Removing the LED board. . . . . . . . . . . . . . . . . . . . . . . . 107
Removing the SCSI backplane assembly . . . . . . . . . . . 107
Removing the hot-swap hard disk drive backplane . 108
Removing the power supply backplane. . . . . . . . . . . . 109
Removing the AC Distribution Box . . . . . . . . . . . . . . . 109
Removing the system board. . . . . . . . . . . . . . . . . . . . . . 110
Symptom-to-FRU index. . . . . . . . . . . . . . 111
Beep symptoms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
No Beep symptoms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
Information panel system error LED . . . . . . . . . . . . . . 114
Diagnostic error codes . . . . . . . . . . . . . . . . . . . . . . . . . . 115
Error symptoms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
Power supply LED errors. . . . . . . . . . . . . . . . . . . . . . . . 119
POST error codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
SCSI error codes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
Temperature error messages . . . . . . . . . . . . . . . . . . . . . 126
Fan error messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
Power error messages . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
System shutdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
Voltage related system shutdown . . . . . . . . . . . . . . 128
Temperature related system shutdown. . . . . . . . . . 129
DASD checkout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
Host Built-In Self Test (BIST) . . . . . . . . . . . . . . . . . . . . . 129
Bus fault messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
Undetermined problems . . . . . . . . . . . . . . . . . . . . . . . . 130
Parts listing (xSeries 340). . . . . . . . . . . . 133
Keyboards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
Power cords. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
Related service information . . . . . . . . . . 137
Safety information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
General safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
Electrical safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
Safety inspection guide . . . . . . . . . . . . . . . . . . . . . . . 139
Handling electrostatic discharge-sensitive devices 140
Grounding requirements. . . . . . . . . . . . . . . . . . . . . . 141
Safety notices (multi-lingual translations) . . . . . . . 141
Send us your comments! . . . . . . . . . . . . . . . . . . . . . . . . 176
Problem determination tips . . . . . . . . . . . . . . . . . . . . . . 177
Notices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177
Trademarks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 178

© Copyright IBM Corp. 2000 1
General checkout
The server diagnostic programs are stored in upgradable read-only memory (ROM)
on the system board. These programs are the primary method of testing the major
components of the server: the system board, Ethernet controller, video controller,
RAM, keyboard, mouse (pointing device), diskette drive, serial ports, hard drives,
and parallel port. You can also use them to test some external devices. See
“Diagnostic programs and error messages”on page 13.
Also, if you cannot determine whether a problem is caused by the hardware or by the
software, you can run the diagnostic programs to confirm that the hardware is
working properly.
When you run the diagnostic programs, a single problem might cause several error
messages. When this occurs, work to correct the cause of the first error message.
After the cause of the first error message is corrected, the other error messages might
not occur the next time you run the test.
A failed system might be part of a shared DASD cluster (two or more systems sharing
the same external storage device(s)). Prior to running diagnostics, verify that the
failing system is not part of a shared DASD cluster.
A system might be part of a cluster if:
•The customer identifies the system as part of a cluster.
•One or more external storage units are attached to the system and at least one of
the attached storage units is additionally attached to another system or
unidentifiable source.
•One or more systems are located near the failing system.
If the failing system is suspected to be part of a shared DASD cluster, all diagnostic
tests can be run except diagnostic tests which test the storage unit (DASD residing in
the storage unit) or the storage adapter attached to the storage unit.
Notes:
1. For systems that are part of a shared DASD cluster, run one test at a time in
looped mode. Do not run all tests in looped mode, as this could enable the DASD
diagnostic tests.
2. If multiple error codes are displayed, diagnose the first error code displayed.
3. If the computer hangs with a POST error, go to “POST error codes”on page 120.
4. If the computer hangs and no error is displayed, go to “Undetermined problems”
on page 130.
5. Power supply problems, see “Power supply LED errors”on page 119.
6. Safety information, see “Safety information”on page 137.
7. For intermittent problems, check the error log; see “Event/error logs”on page 13.
1. IS THE SYSTEM PART OF A CLUSTER?
YES. Schedule maintenance with the customer. Shut down all systems related to the
cluster. Run storage test. NO. Go to step 2.
2. IS THE SYSTEM NOT PART OF A CLUSTER?
•Power-off the computer and all external devices.

2 Hardware Maintenance Manual: xSeries 340 Model 6RY
•Check all cables and power cords.
•Set all display controls to the middle position.
•Power-on all external devices.
•Power-on the computer.
•Record any POST error messages displayed on the screen. If an error is
displayed, look up the first error in the“POST error codes”on page 120.
•Check the information LED panel System Error LED; if on, see “Information
panel system error LED”on page 114.
•Check the System Error Log. If an error was recorded by the system,
see“Chapter . Symptom-to-FRU index,”on page 111.
•Start the Diagnostic Programs. See “Starting the diagnostic programs”on
page 14.
•Check for the following responses:
a. One beep.
b. Readable instructions or the Main Menu.
3. DID YOU RECEIVE BOTH OF THE CORRECT RESPONSES?
NO. Find the failure symptom in“Chapter . Symptom-to-FRU index,”on page 111.
YES. Run the Diagnostic Programs. If necessary, refer to “Starting the diagnostic
programs”on page 14.
If you receive an error, go to“Chapter . Symptom-to-FRU index,”on page 111.
If the diagnostics completed successfully and you still suspect a problem, see
“Undetermined problems”on page 130.

© Copyright IBM Corp. 2000 3
General information
The xSeries 340 server is a high-performance server that supports symmetric
multiprocessing (SMP). It is ideally suited for networking environments that require
superior microprocessor performance, efficient memory management, flexibility, and
large amounts of reliable data storage.
Performance, ease of use, reliability, and expansion capabilities were key
considerations during the design of your server. These design features make it
possible for you to customize the system hardware to meet your needs today, while
providing flexible expansion capabilities for the future.
Features and specifications
The following table provides a summary of the features and specifications for your
xSeries 340 Model 6RY:
Microprocessor:
•Intel®Pentium III
•256 KB Level-2 cache
•Supports up to two microprocessors
Memory:
•Maximum: 4 GB
•Type: ECC, SDRAM, Registered DIMMs
•Slots: 4 non-interleaved
Drives standard:
•Diskette: 1.44 MB
•CD-ROM: 24X IDE
Expansion bays:
•Hot-swap: 3 slim high
•Non-hot-swap: Two 5.25-inch
PCI expansion slots:
•Three 33 MHz/64-bit
•Two 33 MHz/32-bit
Hot-swap power supplies:
•270 Watt (115-230 Vac)
•Minimum: One
•Maximum: Two, second power supply provides redundant power
Redundant cooling:
•Three hot-swap fans
Video:
•S3 video controller
•Compatible with SVGA and VGA
•8 MB video memory

4 Hardware Maintenance Manual: xSeries 340 Model 6RY
Size (Rack Model)
•Height: 13.4 mm (5.25 in.)
•Depth: 66.1 mm (26 in.)
•Width: 41.5 mm (16.3 in.)
•Weight: 22.7 to 29.5 (50 to 65lbs.) depending upon configuration
Integrated functions:
•Advanced System Management processor
•Dual channel Ultra SCSI controller (two internal channels)
•One 10BASE-T/100BASE-TX AMD Ethernet controller
•Two serial ports
•One parallel port
•Two universal serial bus ports
•Keyboard port
•Mouse port
•Video port
Acoustical noise emissions:
•Sound power, idling: 5.9 bel maximum
•Sound power, operating: 6.1 bel maximum
•Sound pressure, operating: 47.5 dBa maximum
Environment:
•Air temperature:
—Server on: 10ºto 35ºC (50ºto 95ºF). Altitude: 0 to 914 m (2998 ft.)
—Server on: 10ºto 32ºC (50ºto 89.6ºF). Altitude: 914 m (2998 ft.) to 2133 m
(6998 ft.)
—Server off: 10ºto 43ºC (50ºto 109.4ºF). Maximum altitude: 2133 m (6998 ft.)
•Humidity:
—Server on: 8% to 80%
—Server off: 8% to 80%
Heat output:
•Approximate heat output in British Thermal Units (BTU) per hour
—Minimum configuratrion 375 BTU (110 watts)
—Maximum configuration 897.4 BTU (375 watts)
Electrical input:
•Sine-wave input (50-60 Hz) required
•Input voltage low range:
—Minimum: 90 V ac
—Maximum: 137 V ac
•Input voltage high range:
—Minimum: 180 V ac
—Maximum: 265 V ac
•Input kilovolt-amperes (kVA) approximately:
—Minimum: 0.08 kVA
—Maximum: 0.42 kVA

General information 5
Server features
The xSeries 340 is designed to be cost-effective, powerful, and flexible. Your server
offers:
•Impressive performance using an innovative approach to SMP
Your server supports up to two Intel Pentium III microprocessors. Your server
comes with one microprocessor installed; you can install an additional
microprocessor to enhance performance and provide SMP capability.
•Large data-storage and hot-swap capabilities
All models of the server support up to three hot-swap hard disk drives. This hot-
swap feature enables you to remove and replace hard disk drives without turning
off the server. A 3-Pack hard-disk drive option is available to add an additional
three drive bays.
•Optional PCI adapters
Your server uses peripheral component interconnect (PCI) bus architecture to
provide compatibility with a wide range of existing hardware devices and
software applications. Your server supports up to five PCI adapters in the
expansion slots on the system board.
•Redundant cooling capability
The redundant cooling capability of the hot-swap fans in your server allow
continued operation if one of the fans fails. You can also replace a failing hot-swap
fan without turning off the server.
•Optional redundant power capability
You can install an additional 270-watt power supply in your server to provide
redundant power for your server. The Power Non-Redundant light emitting
diode (LED) in the group of diagnostic LEDs on the system board is lit when the
power load is 270 watts or greater with two power supplies installed.
•Large system memory
The memory bus in your server supports up to 4GB of system memory. The
memory controller provides error correcting code (ECC) support for up to four
industry standard PC133, 3.3 V, 168-pin, 8-byte, registered, synchronous-
dynamic-random access memory (SDRAM) dual inline memory modules
(DIMMs) (Intel PC-Registered SDIMM Specifications, Revision 1.0 or later).
•System-management capabilities
Your server comes with an Advanced System Management Processor on the
system board. This processor, in conjunction with the Netfinity Manager™
software provided on your ServerGuide CDs, allows you to manage the functions
of the server locally and remotely. The Advanced System Management Processor
also provides system monitoring, event recording, and dial-out alert capability.
Note: The Advanced System Management Processor is sometimes referred to as
the service processor.
•Integrated network environment support
Your server comes with an Ethernet controller on the system board. This Ethernet
controller has an interface for connecting to 10-Mbps or 100-Mbps networks. The
server automatically selects between 10BASE-T and 100BASE-TX. The controller
provides full-duplex (FDX) capability, which allows simultaneous transmission
and reception of data on the Ethernet local area network (LAN).
•Redundant network-interface card
The addition of an optional, redundant network interface card (NIC) provides a
failover capability to a redundant Ethernet connection. If a problem occurs with

6 Hardware Maintenance Manual: xSeries 340 Model 6RY
the primary Ethernet connection, all Ethernet traffic associated with this primary
connection is automatically switched to the redundant NIC. This switching occurs
without data loss and without user intervention.
•Optional digital linear tape drive
The addition of an optional digital linear tape drive (DLT) allows quick backup of
large amounts of data.
•IBM ServerGuide CDs
The ServerGuide CDs included with your xSeries 340 provide programs to help
you set up your server and install the network operating system (NOS). The
ServerGuide program detects the hardware options installed, and provides the
correct configuration programs and device drivers. In addition, the ServerGuide
CDs include a variety of application programs for your server. See
SERVERGUIDE for more information.
Reliability, availability, and serviceability features
Three of the most important features in server design are reliability, availability, and
serviceability (RAS). These factors help to ensure the integrity of the data stored on
your server; that your server is available when you want to use it; and that should a
failure occur, you can easily diagnose and repair the failure with minimal
inconvenience.
The following is an abbreviated list of the RAS features that your server supports.
•Menu-driven setup, system configuration, RAID configuration, and diagnostic
programs
•Power-on self-test (POST)
•Integrated Advanced System Management Processor
•Predictive failure alerts
•System auto-configuring from configuration menu
•Remote system problem-determination support
•Power and temperature monitoring
•Fault-resilient startup
•Hot-swap drive bays
•Error codes and messages
•System error logging
•Upgradable BIOS, diagnostics, and Advanced System Management Processor
code
•Automatic restart after a power failure
•Parity checking on the SCSI and PCI buses
•Error checking and correcting (ECC) memory
•Redundant hot-swap power supply option
•Redundant hot-swap cooling option
•Redundant Ethernet capabilities (with optional adapter)
•Vital Product Data (VPD) on processor complex, system board, power backplane,
SCSI backplane, and each power supply
•Operator information panel and group of diagnostic LEDs on the system board
•Remote Connect
Statement 5

General information 7
CAUTION:
The power control button on the device and the power switch on the power supply
do not turn off the electrical current supplied to the device. The device also might
have more than one power cord. To remove all electrical current from the device,
ensure that all power cords are disconnected from the power source.
Controls and indicators
The most commonly used controls and status indicators are on the front panel of the
server.
Ñ1ÖAC power light
Ñ2ÖHard Disk Status light
Ñ3ÖHard disk Activity light
Ñ4ÖSystem power light
Ñ5ÖPower control botton
Ñ6ÖReset button
System Power Light: When this green light is on, system power is present in the
server. When this light flashes, the server is in standby mode (the system power
supply is turned off and AC current is present). When this light is off, either a power
supply, AC power, or a light has failed.
Attention: If this light is off, it does not mean there is no electrical current present in
the server. The light might be burned out. To remove all electrical current
from the server, you must unplug the server power cords from the
electrical outlets or from the UPS.
Power Control Button: Press this button to manually turn the server on or off.
1
2

8 Hardware Maintenance Manual: xSeries 340 Model 6RY
Statement 5
CAUTION:
The power control button on the device and the power switch on the power supply
do not turn off the electrical current supplied to the device. The device also might
have more than one power cord. To remove all electrical current from the device,
ensure that all power cords are disconnected from the power source.
You can start the server in several ways:
•You can turn on the server by pressing the Power Control button on the front of
the server.
Note: After you plug the power cord of your server into an electrical outlet, wait
20 seconds before pressing the Power Control button. During this time the
system-management processor is initializing and the Power Control
button does not respond.
•If the server is turned on, a power failure occurs, and unattended- start mode is
enabled in the Configuration/Setup utility program, the server will start
automatically when power is restored.
•If AC power is present, the server is off, and the wake-up feature is enabled in the
Configuration/Setup utility program, the wake-up feature will turn on the server
at the set time.
•If AC power is present, the server is off, and ring signal detect is enabled in the
Configuration/Setup utility program, you can turn on the server by telephone
input.
•The Advanced System Management Processor can also turn on the server.
The server can be turned off as follows:
1
2

General information 9
•You can turn off the server by pressing the Power Control button on the front of
the server. Pressing the Power Control button starts an orderly shutdown of the
operating system, if this feature is supported by your operating system, and
places the server in standby mode.
Note: After turning off the server, wait at least 5 seconds before pressing the
Power Control button to power the server on again.
•You can press and hold the Power Control button for more than 4 seconds to
cause an immediate shutdown of the server and place the server in standby
mode. You can use this feature if the operating system hangs.
•You can disconnect the server power cords from the electrical outlets to shut off
all power to the server.
Note: Wait about 15 seconds after disconnecting the power cords for your
system to stop running. Watch for the System Power light on the operator
information panel to stop blinking.
Reset Button: Press this button to reset the server and run the power-on self-test
(POST).
AC Power Light: This light provides status information about the power supply.
During normal operation, both the AC and DC Power lights are on. For any other
combination of lights, see “Power supply LED errors”on page 119.
Operator Information Panel: The lights on this panel give status information for your
server. See “Operator information panel”on page 10 for more information.
DC Power Light: This light provides status information about the power supply.
During normal operation, both the AC and DC Power lights are on. For any other
combination of lights, see “Power supply LED errors”on page 119 .
Hard Disk Status Light: Each of the hot-swap drive bays has a Hard Disk Status light.
When this amber light is on continuously, the drive has failed. When the light flashes
slowly (one flash per second), the drive is being rebuilt. When the light flashes rapidly
(three flashes per second), the controller is identifying the drive.
Hard Disk Activity Light: Each of the hot-swap drive bays has a Hard Disk Activity
light. When this green light is flashing, the controller is accessing the drive.

10 Hardware Maintenance Manual: xSeries 340 Model 6RY
Operator information panel
c 1 d SCSI Hard Disk Drive Activity light
c 2 d Ethernet Link Status light
c 3 d Ethernet Transmit/Receive Activity light
c 4 d Information light
c 5 d System Error light
SCSI Hard Disk Drive Activity Light: This green light is on when there is activity on
a hard disk drive.
Ethernet Link Status Light: When this green light is on, there is an active connection
on the Ethernet port.
Ethernet Transmit/Receive Activity Light: When this green light is on, there is
transmit or receive activity to or from the server.
Information Light: This amber light is on when the information log contains
information about certain conditions in your server that might affect performance. For
example, the light will be on if your server does not have redundant power. A light on
the diagnostic LED panel on the system board will also be on.
System Error Light: This amber light is lit when a system error occurs. An LED on the
diagnostic LED panel will also be on to further isolate the error.
LINK
OK
TX
RX

© Copyright IBM Corp. 2000 11
Diagnostics
This section provides basic troubleshooting information to help you resolve some
common problems that might occur with your server.
Diagnostic tools overview
The following tools are available to help you identify and resolve hardware-related
problems:
•POST beep codes, error messages, and error logs
The power-on self-test (POST) generates beep codes and messages to indicate
successful test completion or the detection of a problem. See “POST”on page 12
for more information.
•Diagnostic programs and error messages
The server diagnostic programs are stored in upgradable read-only memory
(ROM) on the system board. These programs are the primary method of testing
the major components of your server. See “Diagnostic programs and error
messages”on page 13 for more information.
•Light path diagnostics
Your server has light-emitting diodes (LEDs) to help you identify problems with
server components. These LEDs are part of the light-path diagnostics that are
built into your server. By following the path of lights, you can quickly identify the
type of system error that occurred. See “Light path diagnostics”for more
information.
Identifying problems using LEDs
Your server has LEDs to help you identify problems with some server components.
These LEDs are part of the light path diagnostics built into the server. By following the
path of lights, you can identify the type of system error that occurred. See the following
sections for more information.
Power supply LEDs
The AC and DC Power LEDs on the power supply provide status information about
the power supply. See “Power supply LED errors”on page 119.
Light path diagnostics
You can use the light path diagnostics built into your server to quickly identify the
type of system error that occurred. The diagnostics panel is under the "wind tunnel."
Your server is designed so that any LEDs that are illuminated remain illuminated
when the server shuts down as long as the AC power source is good and the power
supplies can supply +5V dc current to the server. This feature helps you isolate the
problem if an error causes the server to shut down. See “Light path diagnostics table”
on page 12.

12 Hardware Maintenance Manual: xSeries 340 Model 6RY
Diagnostics panel
The following illustration shows the LEDs on the diagnostics panel on the system
board. See “Light path diagnostics table”for information on identifying problems
using these LEDs.
Light path diagnostics table
The System Error LED on the operator information panel is lit when certain system
errors occur. If the System Error LED on your server is lit, use the following table to
help determine the cause of the error and the action you should take. See table in
“Information panel system error LED”on page 114.
POST
When you turn on the server, it performs a series of tests to check the operation of
server components and some of the options installed in the server. This series of tests
is called the power-on self-test or POST.
If POST finishes without detecting any problems, a single beep sounds, the first screen
of your operating system or application program appears, and the System POST
Complete (OK) light is illuminated on the operator information panel.
If POST detects a problem, more than one beep sounds and an error message appears
on your screen. See “Beep symptoms”on page 111 and “POST error messages”on
page 13 for more information.
Notes:
1. If you have a power-on password or administrator password set, you must type
the password and press Enter, when prompted, before POST will continue.
2. A single problem might cause several error messages. When this occurs, work to
correct the cause of the first error message. After you correct the cause of the first
DASD2
DASD1
VRM
PCI A
PCI B
CPU
MEM
FAN
TEMP
NMI
OVER
NON
PS3
PS2
PS1
