IBM DS Storage Systems
Quick Reference Guide
IBM System Storage™DS3500 Express
Offers substantial performance and functionality starting at entry-level prices
Building the DS3500
START with the DS3500 // Four 6 Gbps SAS host connectors in a dual controller configuration
• Cost-effective high performance storage for up to two direct-attached servers in a Highly Available conguration
• Connectivity to redundant 16-port SAS switches supports up to eight servers in a Highly Available conguration
• Provides booting and shared storage for IBM BladeCenter®
DS3524 – Best t for environments requiring highest performance, best price/performance, or lowest power/cooling
DS3512 – Best t for environments requiring highest capacity, or a high capacity/high performance blend
Add a host card to expand SAS connectivity or support additional interface technology
SAS host card – adds two more 6 Gbps SAS host connectors per controller
• Further expands shared DAS or networked capabilities with support for eight SAS connectors (dual controller)
• Interface of choice for low cost, high performance “in-the-rack” connectivity
FC host card – adds four 8 Gbps FC host ports per controller
• Seamless integration into existing FC SAN implementations for workgroups, departments or remote sites
• Supports enhanced remote mirroring between DS3500 systems, or with DS5000, DS4000 and/or DCS3700
iSCSI host card – adds four 1 Gbps or two 10 Gbps iSCSI host ports per controller
• Simple and straightforward IP SAN solution that’s well suited for low-cost storage networking requirements
• 10Gbps iSCSI interface provides native connectivity into high-performance IP SAN infrastructures
• Enables use of low-cost IP based disaster recovery solutions with new premium feature key
Add an expansion unit to increase capacity or performance
• EXP3524 for maximum performance; EXP3512 for maximum capacity; or intermix as needed!
Mention DS3500 storage when your customers
• Purchase any System x, BladeCenter or Power Systems
servers
• Require a backup/recovery or disaster recovery strategy using
either Fibre Channel or IP based replication
• Want worry-free, high performance data protection using IBM
Dynamic Disk Pooling versus standard higher maintenance RAID
• Implement Microsoft applications
• Find their servers are running out of internal storage capacity
• Implement server or storage consolidation projects
• Install a VMware or Hyper-V solutions
Key Value Propositions
• Affordable storage with midrange performance and scalability
• Simple yet powerful storage management software
• Concurrent host connectivity and mixed drive types lower
hardware investments
• Turbo performance premium feature provides increased
throughput for more bandwidth-demanding applications
• IBM Dynamic Disk Pooling (DDP) delivers many advantages
over standard RAID congurations including simple, fast,
automatic rebalancing during drives failures
• Enhanced FlashCopy and Mirroring features deliver greater,
faster copy services support and low cost IP replication
• Thin provisioning delivers up to 33% greater storage utilization
services support
• NEBs and ETSI support for ruggedized environments
Now with
Simplified
Feature
Structure
Free Features Included with Firmware Update
Upgrading to the newest IBM 7.84 rmware for the DS3500
Express includes numerous features at no additional cost.
The DS3500 now has these additional features included in the
base system, delivering even greater value!
• 128 Partitions
• Volume Copy
• Encryption
• 32 Enhanced FlashCopies
These new software features are in
addition to:
• Dynamic Disk Pools (DDP)
• Thin Provisioning with DDP
• VAAI
• ALUA
And if additional features are required, they can now be ordered
through the new simplied premium features.
New Premium Feature Key Choices
IBM has reduced the complexity of premium software feature
choices to make it easier to understand and purchase keys for
specic infrastructure goals.
Performance Read Cache • SSD cache
Backup & Restore Option • 512 Enhanced FlashCopies
Disaster Recovery Option • 16 Enhanced Remote Mirrors
• 32 Enhanced Global Mirrors
• Consistency Groups
• IP Replication
Super Key • Combines all the above
features into one part number
New Features as of December 7, 2012

IBM DS Storage Systems
Quick Reference Guide
Key Part Numbers
Systems
PN / FN Description
1746A2S DS3512 – Single Controller
1746A3D DS3512 – Dual Controller
1746A4S DS3524 – Single Controller
1746A4D DS3524 – Dual Controller
1746T4D DS3524 DC power – Dual Controller
Host Interface Cards*
68Y8431 6 Gbps SAS 2 port host card
68Y8432 8 Gbps FC 4 port host card
68Y8433 1 Gbps iSCSI 4 port host card
81Y9613 10 Gbps iSCSI 2 port host card
3.5 in Drives and Enclosures
49Y1856 300GB 15K 3.5-inch
49Y1861 450GB 15K 3.5-inch
49Y1866 600GB 15K 3.5-inch
49Y1947 600GB 15K 3.5-inch SED
49Y1876 1TB 7.2K 3.5-inch NL
49Y1871 2TB 7.2K 3.5-inch NL
81Y9886 3TB 7.2K 3.5-inch NL
1746A2E EXP3512 Expansion Unit – Single ESM
69Y0245 EXP3512 Single ESM
2.5 in Drives and Enclosures
81Y9903 200GB SAS SSD 2.5-inch
81Y9907 400GB SAS SSD 2.5-inch
49Y1841 146GB 15K 2.5-inch
49Y1836 300GB 10K 2.5-inch
49Y1952 300GB 10K 2.5-inch SED
49Y1851 500GB 7.2K 2.5-inch NL
49Y2048 600GB 10K 2.5-inch
81Y9915 900GB 10K 2.5-inch
81Y9872 1TB 7.2K 2.5-inch NL
1746A4E EXP3524 Expansion Unit – Single ESM
69Y0245 EXP3524 Single ESM
1746T4E EXP3524 DC Expansion Unit – Dual
ESM
Host Kits
68Y8458 AIX/VIOS Host Kit (FC host ports only)
68Y8459 Linux on Power Kit (Power Blades only)
68Y8461 HP/UX Host Kit
94Y8434 Mac OS Host Kit
00W1463 Solaris OS Host Kit
Simplified Premium Features
00W1454 Disaster Recoveray Option
00W1455 Backup and Restore Option
00W1456 Performance Read Cache
00W1462 Super Key (includes feature codes
00W1454, 00W1455 and 00W1456)
Additional Features
69Y2871 Turbo Performance
68Y8434 2GB Cache Memory Upgrade
81Y9620 96 to 192 Drive Expansion
Competitive Overview – DS3500 Express versus:
HP P2000 G3
IBM DS3500 Advantages HP P2000 G3 Disadvantages
Provides a common management interface – minimal
learning curve across the DS5000, DS4000, DS3500
and DCS3700
No continuity across the HP storage platforms – each
array family must be learned
The DS3500 supports self-encrypting drives (SEDs)
SAS drives for securing data-at-rest
The P2000 G3 does not have any security solutions for
data-at-rest
EqualLogic
IBM DS3500 Advantages EqualLogic PS4X00 Disadvantages
Affordable – Fits most entry to small midrange custom-
ers’ shrinking budgets
Poor Value – Pricing initially appears attractive until lack
of exibility, expansion and much more is detected
Offers a range of host interface options and intermix –
SAS, iSCSI + SAS, or FC + SAS
Extremely limited host connectivity with only two iSCSI
ports
Scalability can be achieved in a cost-effective manner
by adding EXP3512 and/or EXP3524 expansion units
Scalability becomes expensive. Expansion enclosures
are not offered. A total of only two PS4000s or two
PS4100s may be congured in the same SAN.
Wide variety of RAID levels are simultaneously
supported
Signicant exibility restrictions. Only one drive type,
drive size, drive speed and RAID level per node
HP P4000 SAN Solution (Lefthand Networks)
IBM DS3500 Advantages HP P4000 Disadvantages
Competitively priced to meet restrictive budgets Pricing not within most entry-level customer budgets
and high preset drive quantities
Offers a range of host interface options and intermix –
SAS, iSCSI and SAS, or FC and SAS
Limited host interface choice with only FC and iSCSI
No incremental software costs for expansion Expansion is expensive - each expansion node requires
repurchasing of “bundled” software
A single dual controller DS3500 can provide high
availability
An additional P4000 is required to achieve redundancy
and availability
For more information, visit: www.ibmdsseries.com
