SERVICE MANUAL
ADDENDUM
CONTENTS
REPLACEMENT PAGE . . . . . . . . . . . . . . . . . . . . . . . 5-3
PARTS LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
VOLTAGE DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . 21
Jun. 2011

5 - 3
5-3 RECEIVER ADJUSTMENT
ADJUSTMENT ADJUSTMENT CONDITIONS MEASUREMENT VALUE
ADJUSTMENT
POINT
UNIT LOCATION UNIT ADJUST
PIN ATT 1 • Frequency : 14.10000 MHz
• Mode : USB
• Receiving
RF-C Connect a digital
multimeter to CP1.
1.7 V RF-C R63
HF
SENSITIVITY
1 • Frequency : 14.09850 MHz
• Mode : USB
• [10dB] : ON
• [AGC] : Fast
• Connect an SSG to the antenna connector
for 0.1–30 MHz (50 ΩANT) and set as;
Frequency : 14.10000 MHz
Level* : 0.56 µV (–112 dBm)
Modulation : OFF
• Receiving
Rear
panel
Connect an AC
voltmeter to the [EXT
SP] with an 8 Ω load.
Maximum output
level
Adjust in
sequence
L65, L66,
L63, L62
(repeatedly)
2 • Set the SSG as;
Level : OFF
• Receiving
Minimum output
level
R77
1ST MIXER
BIAS VOLTAGE
1 • Frequency : 173.00000 MHz
• Receiving
RF-D Connect a digital
multimeter to CP1.
2.9–3.1 V RF-D R109
HPF SHIFT
VOLTAGE
1 • Frequency : 1300.00000 MHz
• Mode : FM
• Receiving
CONV-B Connect a digital
multimeter to CP2.
14.5 V CONV-B R55
2 • Frequency : 1100.00000 MHz
• Receiving
2.0–4.0 V Verify
NOTE: Before adjusting WFM SENSITIVITY, 5-4 RF-C BPF TUNED VOLTAGE must be adjusted.
SENSITIVITY
(WFM)
1 • Frequency : 173.02000 MHz
• Mode : WFM
• Connect an SSG to the antenna connector
for 30–2000 MHz and set as;
Frequency : 173.02000 MHz
Level* : 3.2 µV (–97 dBm)
Modulation : 1 kHz
Deviation : ±75 kHz
• Receiving
MAIN-A Connect a digital
multimeter to CP4.
Minimum
level
(Note the voltage
as the reference)
MAIN-A Adjust in
sequence
L7, L8, L9,
L10
(repeatedly)
(FM) 2 • Frequency : 173.02000 MHz
• Mode : FM
• Connect an SSG to the antenna connector
for 30–2000 MHz and set as;
Frequency : 173.02000 MHz
Level* : 3.2 µV (–97 dBm)
Modulation : 1 kHz
Deviation : ±5 kHz
• Receiving
Front
panel
S-meter Maximum
level
MAIN-A Adjust in
sequence
L14, L17,
L22, L25,
L26
(repeatedly)
3 • Set the SSG as;
Level* : 32 µV (–77 dBm)
Modulation : None
MAIN-A Connect a digital
multimeter to CP5.
The same voltage
on "SENSITIVITY
(WFM)."
MAIN-A R60
4 • Set the SSG as;
Level : OFF
Front
panel
The center
indicator
disappears.
1ST IF
NOTCH
1 • Frequency : 788.60000 MHz
• Mode : FM
• Connect an SSG to the antenna connector
for 30–2000 MHz and set as;
Frequency : 810.00000 MHz
Level* : 32 mV (–17 dBm)
Modulation : 1 kHz
Deviation : ±75 kHz
• Receiving
Front
panel
S-meter Maximum
level
MIX-A L15
*; This output level of the SSG is indicated as SSG's terminated circuit.
RECV
AFC
Center indicator
(Replacement page)
Jun. 2011

Jun. 2011
1
SECTION 6
.
PARTS LIST
IC1 1130007700 S.IC BU4094BCF-E2 T 70/53.8
IC2 1130007700 S.IC BU4094BCF-E2 T 85.6/53.8
IC3 1140007881 S.IC
TC190G08EFG0046JDZ/
SC1246A T 74.1/89.9
IC4 1130003831 S.IC TC7S04F(TE85R,F) T 90.2/98.6
IC5 1140006720 S.IC LMX2316TMX/NOPB T 133.6/98.5
IC6 1110003310 S.IC UPC1688G-T1 T 218.9/89.2
IC7 1130003831 S.IC TC7S04F(TE85R,F) T 57.8/91.5
IC8 1110000960 S.IC NJM4558M-TE1-#FMZB T 99.5/32.6
IC9 1110004080 S.IC UPC2709T-E3 T 213.9/81.4
IC10 1140006720 S.IC LMX2316TMX/NOPB T 126/27.5
IC11 1120002820 S.IC SN74LS90NSR T 74.4/32.2
IC12 1110003310 S.IC UPC1688G-T1 T 142.1/30.2
IC13 1140014960 S.IC TC190G02EFG-0058/SC1287A T 21.5/81
IC15 1140014960 S.IC TC190G02EFG-0058/SC1287A T 27.4/48.3
IC16 1180001072 S.IC TA7805F(TE16L1,NQ) T 218.7/10.5
IC17 1180001521 S.IC MC7808CD2TR4G T 221.5/29.5
IC18 1130003831 S.IC TC7S04F(TE85R,F) T 38.9/51.2
IC19 1130003831 S.IC TC7S04F(TE85R,F) T 24/69.4
IC20 1140003831 S.IC TC4W66F(TE12L,F) T 133.3/75.6
IC21 1130003831 S.IC TC7S04F(TE85R,F) T 55.6/37.4
IC22 1110004460 S.IC UPB1509GV-E1 T 232.2/66.8
IC23 1110004460 S.IC UPB1509GV-E1 T 163.7/11
IC24 1180001072 S.IC TA7805F(TE16L1,NQ) T 231.9/19.3
Q2 1560000331 S.FET 2SK210-GR(TE85R,F) T 112.5/83.6
Q3 1530002060 S.TRA 2SC4081 T106 R T 117/85.1
Q7 1590000430 S.TRA DTC144EUA T106 T 89/62.4
Q8 1590000430 S.TRA DTC144EUA T106 T 75.2/45.2
Q9 1590000720 S.TRA DTA144EUA T106 T 75.2/42.6
Q10 1590001001 S.TRA RN2427(TE85L,F) T 168.7/41.2
Q11 1590000680 S.TRA DTC114EUA T106 T 166.8/44
Q12 1590001001 S.TRA RN2427(TE85L,F) T 181.2/41.1
Q13 1590000720 S.TRA DTA144EUA T106 T 84.6/46
Q14 1560000401 S.FET 2SK536-TB-E T 114.6/26.8
Q15 1530002051 S.TRA 2SC3661-TB-E T 107.9/25.1
Q21 1590000430 S.TRA DTC144EUA T106 T 88.2/40.1
Q22 1590000720 S.TRA DTA144EUA T106 T 85.6/39.4
Q24 1590000430 S.TRA DTC144EUA T106 T 87.4/45.2
Q25 1590000720 S.TRA DTA144EUA T106 T 87.2/42.6
Q28 1530002060 S.TRA 2SC4081 T106 R T 18.1/94.1
Q31 1530002060 S.TRA 2SC4081 T106 R T 14.5/44.8
Q32 1510000510 S.TRA 2SA1576A T106R T 133.2/80.5
Q33 1530002060 S.TRA 2SC4081 T106 R T 125.6/81
Q34 1530002051 S.TRA 2SC3661-TB-E T 7/14.4
Q36 1590000680 S.TRA DTC114EUA T106 T 179.2/44.1
Q37 1590000430 S.TRA DTC144EUA T106 T 81.6/46.2
Q38 1510000510 S.TRA 2SA1576A T106R T 130.6/79.6
Q39 1530002060 S.TRA 2SC4081 T106 R T 125.6/78.5
Q40 1590000720 S.TRA DTA144EUA T106 T 140.9/71.1
Q41 1590000680 S.TRA DTC114EUA T106 T 140.9/68.1
Q42 1530002060 S.TRA 2SC4081 T106 R T 133.1/83.5
Q43 1510000510 S.TRA 2SA1576A T106R T 125.9/83.6
Q44 1510000510 S.TRA 2SA1576A T106R T 105.9/98.4
Q45 1530002060 S.TRA 2SC4081 T106 R T 102.1/99.9
Q46 1590000430 S.TRA DTC144EUA T106 T 197.4/44.8
Q47 1590001021 S.TRA RN2424(TE85R,F) T 201/43.8
Q48 1530002060 S.TRA 2SC4081 T106 R T 230.8/73.5
Q49 1590000430 S.TRA DTC144EUA T106 T 155.8/35.4
Q50 1590001021 S.TRA RN2424(TE85R,F) T 152.8/34.4
Q51 1530002060 S.TRA 2SC4081 T106 R T 170.1/12.7
Q52 1590000430 S.TRA DTC144EUA T106 T 186.2/33.8
Q53 1590000720 S.TRA DTA144EUA T106 T 189.2/33.8
Q54 1590000430 S.TRA DTC144EUA T106 T 186.2/36.4
Q55 1590000720 S.TRA DTA144EUA T106 T 189.2/36.4
D1 1790000540 S.VAR MA338(TX) T 102.5/80.3
D2 1790000540 S.VAR MA338(TX) T 104.6/80.3
D4 1750000111 S.DIO 1SS272(TE85R,F) T 78.7/41
D5 1750000111 S.DIO 1SS272(TE85R,F) T 175.1/42.1
D6 1750000111 S.DIO 1SS272(TE85R,F) T 187.4/42.1
D7 1750000211 S.DIO 1SV237(TE85R,F) T 219.8/76.4
D8 1750000111 S.DIO 1SS272(TE85R,F) T 108.5/21.3
D17 1750000211 S.DIO 1SV237(TE85R,F) T 141.3/22.7
D18 1750000211 S.DIO 1SV237(TE85R,F) T 134.1/9.3
D19 1750000211 S.DIO 1SV237(TE85R,F) T 117.7/10.5
D20 1730002421 S.ZEN MAZ8160GHL T 11.1/17.8
D23 1750000111 S.DIO 1SS272(TE85R,F) T 165.1/41.2
D25 1750000211 S.DIO 1SV237(TE85R,F) T 215.8/75.4
D26 1750000211 S.DIO 1SV237(TE85R,F) T 216.1/52.4
D27 1750000550 S.DIO 1SS355 TE-17 T 72.4/23.6
FI1 2020002000 CER SFSRA6M50CF00-B0
X1 6050011950 XTA CR-452. TCXO 30.200 MHz
L1 6200001831 S.COI NLV32T-100J T 61.8/54.8
L2 6200003950 S.COI HF50ACC 322513-T T 62/81.3
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[PLL-B UNIT]
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[PLL-B UNIT]
L4 6200001831 S.COI NLV32T-100J T 86.3/99
L5 6200003261 S.COI NLV32T-101J T 102.5/84.8
L6 6180003510 COI SP0406-6R8K-6
L7 6200003261 S.COI NLV32T-101J T 113.7/97.9
L8 6200001831 S.COI NLV32T-100J T 117.8/79.5
L10 6200003331 S.COI NLV32T-1R0J T 116.7/90.9
L11 6200003331 S.COI NLV32T-1R0J T 117.5/94.5
L12 6200003261 S.COI NLV32T-101J T 128.8/89
L13 6200003261 S.COI NLV32T-101J T 138.6/91.8
L14 6200003331 S.COI NLV32T-1R0J T 204.1/48.9
L17 6200003261 S.COI NLV32T-101J T 6.6/11.3
L18 6200003331 S.COI NLV32T-1R0J T 77.8/48.5
L19 6200001831 S.COI NLV32T-100J T 61.1/92.3
L20 6200005501 S.COI NLV32T-471J T 172/41.6
L21 6200005501 S.COI NLV32T-471J T 184.3/41.6
L22 6200003331 S.COI NLV32T-1R0J T 131.6/17.4
L23 6200003331 S.COI NLV32T-1R0J T 198.6/52.6
L24 6200003331 S.COI NLV32T-1R0J T 204.1/51.9
L25 6200003021 S.COI NLV32T-R33J T 217.2/80.9
L26 6200005341 S.COI LL1608-FSL8N2J T 212.2/69.3
L27 6200012040 S.COI LL1608-FSL5N6S T 212.2/66.6
L28 6200012040 S.COI LL1608-FSL5N6S T 212.2/63.9
L29 6200005301 S.COI LL1608-FSL3N9S T 214.8/61.2
L30 6200005311 S.COI LL1608-FSL4N7S T 214.8/58.5
L31 6200012040 S.COI LL1608-FSL5N6S T 214.8/55.8
L32 6200003261 S.COI NLV32T-101J T 115.5/32.9
L33 6200003261 S.COI NLV32T-101J T 134.5/27.3
L37 6200001831 S.COI NLV32T-100J T 68.4/31.6
L40 6200003331 S.COI NLV32T-1R0J T 138.4/28.6
L41 6200003331 S.COI NLV32T-1R0J T 114/13.6
L42 6200005401 S.COI LL1608-FSL27NJ T 126/11
L43 6200005411 S.COI LL1608-FSL33NJ T 124.1/11.5
L44 6200005411 S.COI LL1608-FSL33NJ T 121.4/12.4
L45 6200003331 S.COI NLV32T-1R0J T 114.2/6.3
L46 6200005351 S.COI LL1608-FSL10NJ T 123.1/7.1
L47 6200005361 S.COI LL1608-FSL12NJ T 120.4/7.1
L48 6200001831 S.COI NLV32T-100J T 69.3/24.6
L49 6200009300 S.COI ELJPA 100KF 10U T 12.8/70.9
L50 6200003331 S.COI NLV32T-1R0J T 12/94.2
L51 6200003151 S.COI NLV32T-180J T 29.9/95.2
L52 6200003151 S.COI NLV32T-180J T 23.8/95.8
L60 6200003261 S.COI NLV32T-101J T 38.9/47.4
L61 6200009300 S.COI ELJPA 100KF 10U T 37.5/39.1
L62 6200001711 S.COI NLV32T-220J T 14.4/38.7
L63 6200005501 S.COI NLV32T-471J T 11.8/56.6
L64 6200005501 S.COI NLV32T-471J T 12.7/50.5
L66 6200003261 S.COI NLV32T-101J T 75.2/22.5
L70 6200003331 S.COI NLV32T-1R0J T 150.2/40.8
L72 6200003331 S.COI NLV32T-1R0J T 81.8/32.2
L73 6200005361 S.COI LL1608-FSL12NJ T 215.4/94.1
L74 6200005351 S.COI LL1608-FSL10NJ T 216/96.7
L75 6200005361 S.COI LL1608-FSL12NJ T 218.7/96.7
L77 6200005361 S.COI LL1608-FSL12NJ T 124.9/7.2
L78 6200003331 S.COI NLV32T-1R0J T 14.6/90.7
L79 6200003151 S.COI NLV32T-180J T 17.9/41.3
L80 6200003151 S.COI NLV32T-180J T 38.2/96.5
L81 6200003141 S.COI NLV32T-150J T 34.7/96.1
L82 6200003261 S.COI NLV32T-101J T 20.8/69.3
L83 6200003031 S.COI NLV32T-R47J T 136.9/62.4
L84 6200003031 S.COI NLV32T-R47J T 131.5/62.4
L85 6200005491 S.COI NLV32T-331J T 18.8/63.5
L86 6200005501 S.COI NLV32T-471J T 15.3/64.1
L87 6200003251 S.COI NLV32T-R39J T 76.7/19.2
L88 6200003261 S.COI NLV32T-101J T 55/40.8
L89 6200003261 S.COI NLV32T-101J T 110.6/99.6
L90 6200003261 S.COI NLV32T-101J T 143.9/68
L91 6200003261 S.COI NLV32T-101J T 204.1/45.9
L92 6200003261 S.COI NLV32T-101J T 198.6/48.3
L93 6200005361 S.COI LL1608-FSL12NJ T 219.6/69.3
L94 6200005351 S.COI LL1608-FSL10NJ T 219.6/66.6
L95 6200005341 S.COI LL1608-FSL8N2J T 219.6/63.9
L96 6200006040 S.COI LQP18MN5N6C02D T 217/61.2
L97 6200005331 S.COI LL1608-FSL6N8J T 217/58.5
L98 6200006060 S.COI LQP18MN8N2C02D T 217/55.8
L99 6200003431 S.COI NLV32T-R10J T 232.7/78.7
L100 6200006160 S.COI LQP21MN68NG01L
(LQP21A 68NG00) T 231.9/82.3
L101 6200003431 S.COI NLV32T-R10J T 232.4/85.6
L102 6200003331 S.COI NLV32T-1R0J T 234.4/56.8
L103 6200003261 S.COI NLV32T-101J T 227.6/58.1
L104 6200003261 S.COI NLV32T-101J T 154.7/15.9
L105 6200003011 S.COI NLV32T-R27J T 175.3/10.8
L106 6200003011 S.COI NLV32T-R27J T 178.8/11.7
L107 6200003001 S.COI NLV32T-R22J T 182.5/11.1
L108 6200003331 S.COI NLV32T-1R0J T 153.4/9.1
L109 6200005411 S.COI LL1608-FSL33NJ T 128.6/14.2
L110 6200005401 S.COI LL1608-FSL27NJ T 125.9/14.2
L111 6200005351 S.COI LL1608-FSL10NJ T 130.1/6.5
L112 6200005341 S.COI LL1608-FSL8N2J T 128.2/5.8
L113 6200003261 S.COI NLV32T-101J T 138.5/87.4
R1 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 66.8/60

Jun. 2011
2
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[PLL-B UNIT]
R2 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 69.4/60
R3 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 72/60
R4 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 74.6/60
R5 7030003860 S.RES ERJ3GE JPW V T 81.6/36.9
R6 7030003860 S.RES ERJ3GE JPW V T 132.1/26.5
R7 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 121.6/32.1
R8 7030003860 S.RES ERJ3GE JPW V T 122.5/29.9
R9 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 87.2/49.3
R10 7030007230 S.RES ERA3YED 102V (1K) T 65.8/69.4
R11 7030007230 S.RES ERA3YED 102V (1K) T 69.7/68.2
R12 7030007230 S.RES ERA3YED 102V (1K) T 69.6/69.5
R13 7030007230 S.RES ERA3YED 102V (1K) T 72.4/68.2
R14 7030007230 S.RES ERA3YED 102V (1K) T 72.4/69.5
R15 7030007230 S.RES ERA3YED 102V (1K) T 75.1/68.2
R16 7030007210 S.RES ERA3YEB 102V (1K) T 75.1/69.5
R17 7030007210 S.RES ERA3YEB 102V (1K) T 77.8/68.2
R18 7030007210 S.RES ERA3YEB 102V (1K) T 77.8/69.5
R19 7030007210 S.RES ERA3YEB 102V (1K) T 80.5/68.2
R20 7030007210 S.RES ERA3YEB 102V (1K) T 80.5/69.5
R21 7030007220 S.RES ERA3YED 202V (2K) T 63.1/69.5
R22 7030007220 S.RES ERA3YED 202V (2K) T 63.9/71.4
R23 7030007220 S.RES ERA3YED 202V (2K) T 67.5/70.7
R24 7030007220 S.RES ERA3YED 202V (2K) T 69.4/71.4
R25 7030007220 S.RES ERA3YED 202V (2K) T 70.7/71.4
R26 7030007220 S.RES ERA3YED 202V (2K) T 72/71.4
R27 7030007220 S.RES ERA3YED 202V (2K) T 73.3/71.4
R28 7030007220 S.RES ERA3YED 202V (2K) T 74.6/71.4
R29 7030007200 S.RES ERA3YEB 202V (2K) T 75.9/71.4
R30 7030007200 S.RES ERA3YEB 202V (2K) T 77.2/71.4
R31 7030007200 S.RES ERA3YEB 202V (2K) T 78.5/71.4
R32 7030007200 S.RES ERA3YEB 202V (2K) T 79.8/71.4
R33 7030007200 S.RES ERA3YEB 202V (2K) T 81.1/71.4
R34 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 84.9/91.5
R35 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 75.1/99.4
R36 7030003860 S.RES ERJ3GE JPW V T 129.4/100.6
R37 7030003860 S.RES ERJ3GE JPW V T 136.2/94.1
R38 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 129.3/92.2
R39 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 129.3/93.5
R40 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 129.3/94.8
R41 7030003400 S.RES ERJ3GEYJ 471 V (470) T 90.7/88.6
R42 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 90.4/101
R43 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 103.8/95.8
R44 7030003320 S.RES ERJ3GEYJ 101 V (100) T 103.8/92.9
R45 7030003360 S.RES ERJ3GEYJ 221 V (220) T 113.3/86.6
R46 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 112.1/86.5
R47 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 112.1/79
R48 7030003340 S.RES ERJ3GEYJ 151 V (150) T 115.7/79
R49 7030003320 S.RES ERJ3GEYJ 101 V (100) T 113.7/88.8
R50 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 115.1/85.2
R51 7030003280 S.RES ERJ3GEYJ 470 V (47) T 118.9/88.6
R52 7030003340 S.RES ERJ3GEYJ 151 V (150) T 119.4/84.1
R53 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 121.6/33.4
R54 7030003290 S.RES ERJ3GEYJ 560 V (56) T 119.1/100.4
R55 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 121.6/34.7
R57 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 126/89.1
R58 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 130.1/98
R59 7030003320 S.RES ERJ3GEYJ 101 V (100) T 143.7/70.8
R66 7030003370 S.RES ERJ3GEYJ 271 V (270) T 212.5/94.8
R67 7030003230 S.RES ERJ3GEYJ 180 V (18) T 211.8/91.7
R68 7030003370 S.RES ERJ3GEYJ 271 V (270) T 213.1/91.7
R69 7030003320 S.RES ERJ3GEYJ 101 V (100) T 214.9/91.9
R70 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) T 74.3/47.8
R72 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 58.1/89
R77 7030003800 S.RES ERJ3GEYJ 105 V (1M) T 137.4/69.7
R79 7030003370 S.RES ERJ3GEYJ 271 V (270) T 220.7/80.6
R80 7030003230 S.RES ERJ3GEYJ 180 V (18) T 219.4/80.6
R81 7030003370 S.RES ERJ3GEYJ 271 V (270) T 219.8/78.7
R82 7030003420 S.RES ERJ3GEYJ 681 V (680) T 213/77
R83 7030003320 S.RES ERJ3GEYJ 101 V (100) T 213.1/74.9
R84 7030003370 S.RES ERJ3GEYJ 271 V (270) T 212.6/50
R85 7030003230 S.RES ERJ3GEYJ 180 V (18) T 215.3/50.2
R86 7030003370 S.RES ERJ3GEYJ 271 V (270) T 218.2/50
R87 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 120.6/30.6
R88 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 127.5/32.7
R91 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) T 111.1/25.7
R92 7030003400 S.RES ERJ3GEYJ 471 V (470) T 115.7/23.6
R93 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 111.1/21.8
R94 7030003450 S.RES ERJ3GEYJ 122 V (1.2K) T 111.1/24.4
R95 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 108/28.7
R96 7030003360 S.RES ERJ3GEYJ 221 V (220) T 101.4/26.8
R100 7030003320 S.RES ERJ3GEYJ 101 V (100) T 149.6/44.2
R106 7030003320 S.RES ERJ3GEYJ 101 V (100) T 96.4/45.4
R116 7030003420 S.RES ERJ3GEYJ 681 V (680) T 137/21.3
R117 7030003360 S.RES 220 ERJ3GE T 138.6/34.4
R118 7030003240 S.RES 22 ERJ3GE T 140.5/33.6
R119 7030003360 S.RES 220 ERJ3GE T 142.4/32.8
R120 7030003320 S.RES ERJ3GEYJ 101 V (100) T 83.6/41.1
R121 7030003320 S.RES ERJ3GEYJ 101 V (100) T 84.4/43
R122 7030003350 S.RES ERJ3GEYJ 181 V (180) T 133.7/14.2
R123 7030003260 S.RES ERJ3GEYJ 330 V (33) T 134.5/12.3
R124 7030003350 S.RES ERJ3GEYJ 181 V (180) T 135.8/6.3
R125 7030003420 S.RES ERJ3GEYJ 681 V (680) T 133.2/12.3
R127 7030003420 S.RES ERJ3GEYJ 681 V (680) T 134.5/6.2
R129 7030003370 S.RES ERJ3GEYJ 271 V (270) T 115.5/8.9
R130 7030003230 S.RES ERJ3GEYJ 180 V (18) T 114.7/10.8
R131 7030003370 S.RES ERJ3GEYJ 271 V (270) T 113.9/8.9
R133 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 60.8/35
R135 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) T 63.4/35
R139 7030003320 S.RES ERJ3GEYJ 101 V (100) T 61.6/40.2
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[PLL-B UNIT]
R140 7030007220 S.RES ERA3YED 202V (2K) T 35.8/71.4
R141 7030007220 S.RES ERA3YED 202V (2K) T 35.8/72.7
R142 7030007220 S.RES ERA3YED 202V (2K) T 36.2/75.3
R143 7030007220 S.RES ERA3YED 202V (2K) T 36.5/77.9
R144 7030007220 S.RES ERA3YED 202V (2K) T 36.5/80.5
R145 7030007220 S.RES ERA3YED 202V (2K) T 36.1/82.5
R146 7030007220 S.RES ERA3YED 202V (2K) T 36.1/83.8
R147 7030007200 S.RES ERA3YEB 202V (2K) T 36.1/86.4
R148 7030007200 S.RES ERA3YEB 202V (2K) T 36.1/87.7
R149 7030007200 S.RES ERA3YEB 202V (2K) T 36.1/90.3
R150 7030007220 S.RES ERA3YED 202V (2K) T 39.2/71.5
R151 7030007230 S.RES ERA3YED 102V (1K) T 37.9/72.2
R152 7030007230 S.RES ERA3YED 102V (1K) T 39.2/74.1
R153 7030007230 S.RES ERA3YED 102V (1K) T 38.1/76
R154 7030007230 S.RES ERA3YED 102V (1K) T 38.4/79.2
R155 7030007230 S.RES ERA3YED 102V (1K) T 38/82.4
R156 7030007230 S.RES ERA3YED 102V (1K) T 39.3/83.7
R157 7030007210 S.RES ERA3YEB 102V (1K) T 38/85.1
R158 7030007210 S.RES ERA3YEB 102V (1K) T 39.3/86.3
R159 7030007210 S.RES ERA3YEB 102V (1K) T 38/88.4
R160 7030003360 S.RES ERJ3GEYJ 221 V (220) T 18.8/90.3
R161 7030003710 S.RES ERJ3GEYJ 184 V (180K) T 18.2/92.2
R162 7030003420 S.RES ERJ3GEYJ 681 V (680) T 20.3/96.6
R163 7030003370 S.RES ERJ3GEYJ 271 V (270) T 21/94.6
R164 7030003340 S.RES ERJ3GEYJ 151 V (150) T 19/96.6
R168 7030003320 S.RES ERJ3GEYJ 101 V (100) T 11.8/103.8
R176 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 36.5/49.9
R179 7030007220 S.RES ERA3YED 202V (2K) T 39.6/61.4
R180 7030007220 S.RES ERA3YED 202V (2K) T 38.3/61.4
R181 7030007220 S.RES ERA3YED 202V (2K) T 34.4/61.4
R182 7030007220 S.RES ERA3YED 202V (2K) T 33.1/61.4
R183 7030007220 S.RES ERA3YED 202V (2K) T 30.7/63.3
R184 7030007220 S.RES ERA3YED 202V (2K) T 28.8/61.4
R185 7030007220 S.RES ERA3YED 202V (2K) T 26.2/61.4
R186 7030007200 S.RES ERA3YEB 202V (2K) T 24.9/61.4
R187 7030007200 S.RES ERA3YEB 202V (2K) T 23.6/61.4
R188 7030007200 S.RES ERA3YEB 202V (2K) T 21/61.4
R189 7030007220 S.RES ERA3YED 202V (2K) T 39.4/64.6
R190 7030007230 S.RES ERA3YED 102V (1K) T 38.8/63.3
R191 7030007230 S.RES ERA3YED 102V (1K) T 36.7/64.6
R192 7030007230 S.RES ERA3YED 102V (1K) T 34.9/63.3
R193 7030007230 S.RES ERA3YED 102V (1K) T 33.6/64.6
R194 7030007230 S.RES ERA3YED 102V (1K) T 30.7/64.6
R195 7030007230 S.RES ERA3YED 102V (1K) T 28/64.6
R196 7030007210 S.RES ERA3YEB 102V (1K) T 26.7/63.3
R197 7030007210 S.RES ERA3YEB 102V (1K) T 25.1/64.6
R198 7030007210 S.RES ERA3YEB 102V (1K) T 22.8/63.3
R199 7030003430 S.RES ERJ3GEYJ 821 V (820) T 12.1/47
R200 7030003360 S.RES ERJ3GEYJ 221 V (220) T 18.3/45.6
R201 7030003710 S.RES ERJ3GEYJ 184 V (180K) T 16.4/44.9
R202 7030003360 S.RES ERJ3GEYJ 221 V (220) T 14.1/47.7
R203 7030003340 S.RES ERJ3GEYJ 151 V (150) T 12/45.7
R204 7030003860 S.RES ERJ3GE JPW V T 234.6/62.5
R205 7030003860 S.RES ERJ3GE JPW V T 233.3/62.5
R207 7030003320 S.RES ERJ3GEYJ 101 V (100) T 14.2/31.7
R212 7030003370 S.RES ERJ3GEYJ 271 V (270) T 82.2/24.7
R213 7030003230 S.RES ERJ3GEYJ 180 V (18) T 80.4/23.9
R214 7030003370 S.RES ERJ3GEYJ 271 V (270) T 82.2/23
R215 7030007510 S.RES ERJ12YJ270U (27) T 212.3/18.3
R216 7030007510 S.RES ERJ12YJ270U (27) T 208.6/18.3
R217 7030007510 S.RES ERJ12YJ270U (27) T 204.9/18.3
R222 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 80.9/59.2
R223 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 83.8/59.4
R224 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 79.6/58.1
R225 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 87.4/59.2
R226 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) T 9.4/13.5
R227 7030003200 S.RES ERJ3GEYJ 100 V (10) T 5.4/17.4
R228 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 82.2/59.2
R231 7030003320 S.RES ERJ3GEYJ 101 V (100) T 15.1/42.8
R232 7030003320 S.RES ERJ3GEYJ 101 V (100) T 16.1/93.5
R237 7030003280 S.RES ERJ3GEYJ 470 V (47) T 130.7/10.2
R239 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 104.7/86.9
R240 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 83.7/68.7
R241 7030003280 S.RES ERJ3GEYJ 470 V (47) T 79.6/34.3
R243 7030003280 S.RES ERJ3GEYJ 470 V (47) T 211.2/88.9
R244 7030003280 S.RES ERJ3GEYJ 470 V (47) T 213.1/89.5
R245 7030003320 S.RES ERJ3GEYJ 101 V (100) T 215.8/89.4
R246 7030003280 S.RES ERJ3GEYJ 470 V (47) T 139.2/98.5
R247 7030003380 S.RES ERJ3GEYJ 331 V (330) T 142.3/25.2
R248 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 39.3/88.9
R249 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 21.8/64.6
R250 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 23.1/71.9
R251 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 133.8/86.3
R252 7030003800 S.RES ERJ3GEYJ 105 V (1M) T 135.6/85.6
R253 7030003800 S.RES ERJ3GEYJ 105 V (1M) T 131.2/86.3
R254 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 135.6/84.3
R255 7030003450 S.RES ERJ3GEYJ 122 V (1.2K) T 131.1/83.6
R256 7030003510 S.RES ERJ3GEYJ 392 V (3.9K) T 128/84
R257 7510001410 S.THE NTCG20 3FH 222JT T 129.6/83.7
R258 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 125.8/85.6
R259 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) T 135.2/79.9
R260 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) T 123.5/79.6
R261 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 138.8/71.4
R262 7030003320 S.RES ERJ3GEYJ 101 V (100) T 129.4/77.2
R263 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) T 127/75.2
R266 7030003800 S.RES ERJ3GEYJ 105 V (1M) T 58/37.8
R267 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 101/38
R268 7030003620 S.RES ERJ3GEYJ 333 V (33K) T 107.4/100.5
R269 7030003550 S.RES ERJ3GEYJ 822 V (8.2K) T 105.5/101.2

Jun. 2011
3
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[PLL-B UNIT]
R270 7030003570 S.RES ERJ3GEYJ 123 V (12K) T 104/100
R271 7030003570 S.RES ERJ3GEYJ 123 V (12K) T 102.4/103.8
R272 7030003420 S.RES ERJ3GEYJ 681 V (680) T 213.5/72
R273 7030003420 S.RES ERJ3GEYJ 681 V (680) T 218.3/72
R274 7030003420 S.RES ERJ3GEYJ 681 V (680) T 213.7/52.8
R275 7030003420 S.RES ERJ3GEYJ 681 V (680) T 219.1/53.5
R276 7030003420 S.RES ERJ3GEYJ 681 V (680) T 234.6/59.7
R277 7030003280 S.RES ERJ3GEYJ 470 V (47) T 235.9/62.5
R278 7030003360 S.RES ERJ3GEYJ 221 V (220) T 234.7/70.5
R279 7030003320 S.RES ERJ3GEYJ 101 V (100) T 232.7/73
R280 7030003530 S.RES ERJ3GEYJ 562 V (5.6K) T 234/74.5
R281 7030003460 S.RES ERJ3GEYJ 152 V (1.5K) T 228/74.2
R282 7030003280 S.RES ERJ3GEYJ 470 V (47) T 228/75.6
R283 7030003420 S.RES ERJ3GEYJ 681 V (680) T 227.8/88.4
R284 7030005280 S.RES ERJ3GEYJ 6R8V (6.8) T 230.8/88.4
R285 7030003420 S.RES ERJ3GEYJ 681 V (680) T 235.4/87.4
R286 7030003420 S.RES ERJ3GEYJ 681 V (680) T 155.9/9.2
R287 7030003280 S.RES ERJ3GEYJ 470 V (47) T 160/9.2
R288 7030003360 S.RES ERJ3GEYJ 221 V (220) T 167.4/8.7
R289 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) T 169.1/10.7
R290 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 171.3/10
R291 7030003530 S.RES ERJ3GEYJ 562 V (5.6K) T 170.9/15.1
R292 7030003420 S.RES ERJ3GEYJ 681 V (680) T 185.4/15.7
R293 7030005280 S.RES ERJ3GEYJ 6R8V (6.8) T 185.1/12.7
R294 7030003420 S.RES ERJ3GEYJ 681 V (680) T 183.4/8.6
R295 7030003280 S.RES ERJ3GEYJ 470 V (47) T 172.2/15.5
R296 7030003420 S.RES ERJ3GEYJ 681 V (680) T 118.7/12.9
R297 7030003420 S.RES ERJ3GEYJ 681 V (680) T 118.5/7.5
R298 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 117.5/103
R299 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) T 127.6/77.2
R300 7030003380 S.RES ERJ3GEYJ 331 V (330) T 60/41.6
R301 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) T 127/71.4
R302 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 78.9/103.6
R400 7030003860 S.RES ERJ3GE JPW V T 159/7.3
R401 7030003860 S.RES ERJ3GE JPW V T 158.7/9.2
C1 4030006880 S.CER C1608 JB 1H 472K-T T 64/55.4
C2 4030006880 S.CER C1608 JB 1H 472K-T T 65.5/60
C3 4030006880 S.CER C1608 JB 1H 472K-T T 68.1/60
C4 4030006880 S.CER C1608 JB 1H 472K-T T 70.7/60
C5 4030006880 S.CER C1608 JB 1H 472K-T T 73.3/60
C6 4030006880 S.CER C1608 JB 1H 472K-T T 79.6/55.4
C7 4030006860 S.CER C1608 JB 1H 102K-T T 128.8/32.7
C8 4030011600 S.CER C1608 JB 1E 104K-T T 121.5/27.5
C9 4030011600 S.CER C1608 JB 1E 104K-T T 128.8/98
C10 4030006880 S.CER C1608 JB 1H 472K-T T 127.5/98
C11 4030008920 S.CER C1608 JB 1H 473K-T T 61.8/83.6
C12 4030008920 S.CER C1608 JB 1H 473K-T T 63.3/91.6
C13 4030008920 S.CER C1608 JB 1H 473K-T T 63.6/94.9
C14 4030008920 S.CER C1608 JB 1H 473K-T T 66.9/79.3
C15 4030008920 S.CER C1608 JB 1H 473K-T T 80.1/78.7
C16 4030008920 S.CER C1608 JB 1H 473K-T T 82.9/78.7
C17 4030008920 S.CER C1608 JB 1H 473K-T T 84.4/83.8
C18 4030008920 S.CER C1608 JB 1H 473K-T T 84.4/86.6
C19 4030008920 S.CER C1608 JB 1H 473K-T T 86.5/89.5
C20 4030008920 S.CER C1608 JB 1H 473K-T T 87.5/93.5
C21 4030008920 S.CER C1608 JB 1H 473K-T T 85.4/96.8
C22 4030008920 S.CER C1608 JB 1H 473K-T T 71.6/101.1
C23 4030008920 S.CER C1608 JB 1H 473K-T T 75.1/100.7
C24 4030008920 S.CER C1608 JB 1H 473K-T T 79.1/100.2
C25 4030006900 S.CER C1608 JB 1H 103K-T T 82.4/71.4
C28 4030006900 S.CER C1608 JB 1H 103K-T T 90/90.5
C29 4030010210 S.CER C3216 JB 1C 105M-T T 89.8/95.8
C30 4550003220 S.TAN TEESVA 1E 105M8R T 102.1/95.9
C31 4550000510 S.TAN TEESVA 1V 473M8R T 102.1/90.8
C32 4030007030 S.CER C1608 CH 1H 150J-T T 106.3/81.4
C33 4030007090 S.CER C1608 CH 1H 470J-T T 110.9/86.5
C34 4030008920 S.CER C1608 JB 1H 473K-T T 113.3/79
C35 4030007150 S.CER C1608 CH 1H 151J-T T 112.8/81.2
C36 4510008500 S.ELE EEE1CA101WP T 109.3/93.5
C37 4030007150 S.CER C1608 CH 1H 151J-T T 114.5/79
C38 4030007010 S.CER C1608 CH 1H 100D-T T 115.1/82
C40 4030008920 S.CER C1608 JB 1H 473K-T T 119.1/96.7
C41 4030008920 S.CER C1608 JB 1H 473K-T T 119.3/86.7
C42 4030007150 S.CER C1608 CH 1H 151J-T T 118.9/91.3
C43 4030010040 S.CER C1608 JB 1H 561K-T T 120.1/88.6
C44 4030009580 S.CER C1608 JB 1H 681K-T T 120.1/91.3
C45 4030007130 S.CER C1608 CH 1H 101J-T T 115.5/103.5
C46 4030007090 S.CER C1608 CH 1H 470J-T T 119.1/101.7
C48 4030008920 S.CER C1608 JB 1H 473K-T T 119.1/98
C50 4030006880 S.CER C1608 JB 1H 472K-T T 131.5/90.4
C51 4030006880 S.CER C1608 JB 1H 472K-T T 131.5/103.7
C52 4030006900 S.CER C1608 JB 1H 103K-T T 133.3/103.1
C53 4030006860 S.CER C1608 JB 1H 102K-T T 138.7/100.5
C57 4550003220 S.TAN TEESVA 1E 105M8R T 136.9/79.7
C58 4030006860 S.CER C1608 JB 1H 102K-T T 138.6/79.9
C60 4030007010 S.CER C1608 CH 1H 100D-T T 211.2/94.8
C61 4030007010 S.CER C1608 CH 1H 100D-T T 215.8/88.1
C62 4030006860 S.CER C1608 JB 1H 102K-T T 218.1/92.9
C63 4030006860 S.CER C1608 JB 1H 102K-T T 216.2/91.9
C69 4030006860 S.CER C1608 JB 1H 102K-T T 13.6/11.8
C70 4030006860 S.CER C1608 JB 1H 102K-T T 25.4/18.8
C71 4030006860 S.CER C1608 JB 1H 102K-T T 75.6/47.8
C72 4030006880 S.CER C1608 JB 1H 472K-T T 58.7/97.4
C73 4030010210 S.CER C3216 JB 1C 105M-T T 58.5/95.7
C74 4030006860 S.CER C1608 JB 1H 102K-T T 175.9/45.5
C75 4510008500 S.ELE EEE1CA101WP T 171.7/48.3
C76 4030006860 S.CER C1608 JB 1H 102K-T T 188.4/45.5
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[PLL-B UNIT]
C77 4510008500 S.ELE EEE1CA101WP T 184.2/48.3
C78 4030006860 S.CER C1608 JB 1H 102K-T T 133.1/20.4
C79 4030006860 S.CER C1608 JB 1H 102K-T T 211.8/74.9
C80 4030007010 S.CER C1608 CH 1H 100D-T T 211.6/81.3
C81 4030006860 S.CER C1608 JB 1H 102K-T T 214/79.1
C82 4030006860 S.CER C1608 JB 1H 102K-T T 219.8/82.7
C83 4030006860 S.CER C1608 JB 1H 102K-T T 216/77.6
C84 4030009910 S.CER C1608 CH 1H 040B-T T 214.8/72
C85 4030009520 S.CER C1608 CH 1H 020B-T T 214.8/69.3
C86 4030009540 S.CER C1608 CH 1H 1R5B-T T 214.8/66.6
C88 4030006990 S.CER C1608 CH 1H 080D-T T 213.5/69.3
C89 4030007030 S.CER C1608 CH 1H 150J-T T 213.5/66.6
C90 4030007090 S.CER C1608 CH 1H 470J-T T 213.5/63.9
C91 4030009520 S.CER C1608 CH 1H 020B-T T 212.2/61.2
C92 4030009520 S.CER C1608 CH 1H 020B-T T 213.5/61.2
C93 4030009910 S.CER C1608 CH 1H 040B-T T 212.2/58.5
C94 4030009510 S.CER C1608 CH 1H 010B-T T 213.5/58.5
C95 4030009910 S.CER C1608 CH 1H 040B-T T 212.2/55.8
C97 4030006860 S.CER C1608 JB 1H 102K-T T 115.9/30.7
C98 4030006860 S.CER C1608 JB 1H 102K-T T 130.8/26.5
C100 4030006860 S.CER C1608 JB 1H 102K-T T 125.4/23.1
C101 4030006860 S.CER C1608 JB 1H 102K-T T 138.2/23.2
C102 4030006880 S.CER C1608 JB 1H 472K-T T 111.1/27
C103 4550000550 S.TAN TEESVA 1V 224M8R T 111.9/30.4
C104 4550000550 S.TAN TEESVA 1V 224M8R T 109.7/30.4
C105 4550000510 S.TAN TEESVA 1V 473M8R T 106.2/29.1
C106 4550000510 S.TAN TEESVA 1V 473M8R T 113.9/22.4
C107 4510008690 S.ELE EEE1EA330SP T 96.7/25.1
C108 4510008500 S.ELE EEE1CA101WP T 155.4/41.4
C117 4030008920 S.CER C1608 JB 1H 473K-T T 68.2/29
C118 4030006860 S.CER C1608 JB 1H 102K-T T 79.6/27.8
C119 4030007170 S.CER C1608 CH 1H 221J-T T 79.6/30.6
C121 4030007170 S.CER C1608 CH 1H 221J-T T 81.6/34.8
C122 4030006860 S.CER C1608 JB 1H 102K-T T 96/35.4
C123 4510008690 S.ELE EEE1EA330SP T 94.5/40.3
C131 4030006860 S.CER C1608 JB 1H 102K-T T 142.3/27.8
C132 4030007050 S.CER C1608 CH 1H 220J-T T 139.1/32.1
C133 4030006860 S.CER C1608 JB 1H 102K-T T 142.3/26.5
C134 4030006860 S.CER C1608 JB 1H 102K-T T 135.8/12.3
C135 4030006860 S.CER C1608 JB 1H 102K-T T 131.8/13.4
C137 4030006860 S.CER C1608 JB 1H 102K-T T 133.2/6.2
C139 4030007000 S.CER C1608 CH 1H 090D-T T 125.7/12.9
C140 4030009550 S.CER C1608 CH 1H 2R5B-T T 124.1/10.2
C141 4030007010 S.CER C1608 CH 1H 100D-T T 123.5/13.3
C142 4030009540 S.CER C1608 CH 1H 1R5B-T T 121.4/11.1
C143 4030006990 S.CER C1608 CH 1H 080D-T T 121.4/13.7
C145 4030006970 S.CER C1608 CH 1H 060D-T T 124.9/5.4
C146 4030009500 S.CER C1608 CH 1H 0R5B-T T 123.1/8.4
C147 4030006980 S.CER C1608 CH 1H 070D-T T 122/5.8
C148 4030009570 S.CER C1608 CH 1H 0R3B-T T 120.4/8.4
C149 4030009530 S.CER C1608 CH 1H 030B-T T 118.9/5.6
C151 4030006860 S.CER C1608 JB 1H 102K-T T 112/10.8
C153 4030006880 S.CER C1608 JB 1H 472K-T T 29.4/18.6
C154 4030006880 S.CER C1608 JB 1H 472K-T T 69.1/20.7
C155 4030007010 S.CER C1608 CH 1H 100D-T T 62.1/35
C156 4030006860 S.CER C1608 JB 1H 102K-T T 59.4/39.4
C158 4030011600 S.CER C1608 JB 1E 104K-T T 20.4/73.2
C159 4510008540 S.ELE EEE1CA100SR T 16.7/70.6
C160 4030011600 S.CER C1608 JB 1E 104K-T T 12.9/75.3
C161 4030011600 S.CER C1608 JB 1E 104K-T T 25.7/72.6
C162 4030011600 S.CER C1608 JB 1E 104K-T T 12.9/82
C163 4030011600 S.CER C1608 JB 1E 104K-T T 20.1/89.8
C164 4030011600 S.CER C1608 JB 1E 104K-T T 24.8/89.8
C165 4030007170 S.CER C1608 CH 1H 221J-T T 14/88.5
C166 4030007100 S.CER C1608 CH 1H 560J-T T 14.2/93.6
C167 4030007020 S.CER C1608 CH 1H 120J-T T 31.7/97.4
C168 4030009350 S.CER C1608 CH 1H 3R5B-T T 29.1/97.4
C169 4030007050 S.CER C1608 CH 1H 220J-T T 27.3/95.4
C170 4030009540 S.CER C1608 CH 1H 1R5B-T T 26/95.4
C171 4030007020 S.CER C1608 CH 1H 120J-T T 21.6/96.6
C172 4030011600 S.CER C1608 JB 1E 104K-T T 16.4/96.2
C173 4030006900 S.CER C1608 JB 1H 103K-T T 21/93.3
C175 4030006880 S.CER C1608 JB 1H 472K-T T 17.7/96.6
C177 4030006900 S.CER C1608 JB 1H 103K-T T 13.1/103.8
C191 4030006880 S.CER C1608 JB 1H 472K-T T 43.8/52.4
C192 4030010210 S.CER C3216 JB 1C 105M-T T 38/54
C194 4030011600 S.CER C1608 JB 1E 104K-T T 36.5/47.1
C195 4510008540 S.ELE EEE1CA100SR T 37.9/43
C196 4030011600 S.CER C1608 JB 1E 104K-T T 33.1/39.7
C197 4030011600 S.CER C1608 JB 1E 104K-T T 35.9/52.1
C198 4030011600 S.CER C1608 JB 1E 104K-T T 26.4/39.7
C199 4030011600 S.CER C1608 JB 1E 104K-T T 18.6/46.9
C200 4030011600 S.CER C1608 JB 1E 104K-T T 18.6/51.6
C201 4030009880 S.CER C1608 JB 1H 682K-T T 20.1/40.7
C202 4030009980 S.CER C1608 JB 1H 152K-T T 15/40.9
C203 4030010760 S.CER C1608 CH 1H 331J-T T 12.6/61.4
C204 4030007110 S.CER C1608 CH 1H 680J-T T 14/56.6
C205 4030006850 S.CER C1608 JB 1H 471K-T T 13.2/54
C206 4030007060 S.CER C1608 CH 1H 270J-T T 13.2/52.7
C207 4030010760 S.CER C1608 CH 1H 331J-T T 12.1/48.3
C208 4030011600 S.CER C1608 JB 1E 104K-T T 12/44.4
C209 4030011600 S.CER C1608 JB 1E 104K-T T 15.4/47.7
C210 4030006860 S.CER C1608 JB 1H 102K-T T 227.7/67.4
C211 4030006880 S.CER C1608 JB 1H 472K-T T 12.4/43.1
C212 4030006900 S.CER C1608 JB 1H 103K-T T 15/33.6
C213 4030006900 S.CER C1608 JB 1H 103K-T T 12.2/34.2
C214 4030006860 S.CER C1608 JB 1H 102K-T T 228.5/65.5
C215 4030006860 S.CER C1608 JB 1H 102K-T T 234/64.4
C216 4030006860 S.CER C1608 JB 1H 102K-T T 235.9/65.6

Jun. 2011
4
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[PLL-B UNIT]
C217 4030006900 S.CER C1608 JB 1H 103K-T T 72.4/20.6
C218 4030006900 S.CER C1608 JB 1H 103K-T T 78.5/23.1
C219 4030008920 S.CER C1608 JB 1H 473K-T T 211.5/13.3
C220 4510008540 S.ELE EEE1CA100SR T 202.9/13
C221 4510008540 S.ELE EEE1CA100SR T 209.5/7.8
C222 4030008920 S.CER C1608 JB 1H 473K-T T 214.3/6.6
C223 4030006860 S.CER C1608 JB 1H 102K-T T 214.3/5.4
C227 4030008920 S.CER C1608 JB 1H 473K-T T 215.2/33.8
C228 4510008540 S.ELE EEE1CA100SR T 207.2/32.9
C229 4510008540 S.ELE EEE1CA100SR T 207.2/26.7
C230 4030008920 S.CER C1608 JB 1H 473K-T T 215.2/25.1
C231 4030006860 S.CER C1608 JB 1H 102K-T T 215.2/23.7
C232 4030006880 S.CER C1608 JB 1H 472K-T T 10/11.6
C233 4030018980 S.CER C1608 JB 1H 104K-T T 11.1/15.8
C234 4510008690 S.ELE EEE1EA330SP T 8.3/22.5
C235 4030018980 S.CER C1608 JB 1H 104K-T T 9.2/27.1
C236 4510008690 S.ELE EEE1EA330SP T 15/26.9
C237 4030006860 S.CER C1608 JB 1H 102K-T T 83.9/29.2
C239 4030009570 S.CER C1608 CH 1H 0R3B-T T 213.5/55.8
C240 4030009550 S.CER C1608 CH 1H 2R5B-T T 211.8/53.6
C242 4030007050 S.CER C1608 CH 1H 220J-T T 75.7/77.4
C243 4030007050 S.CER C1608 CH 1H 220J-T T 79.9/76.1
C244 4030008920 S.CER C1608 JB 1H 473K-T T 80.2/103.6
C246 4550006050 S.TAN TEESVA 0J 106M8R T 62.6/77.2
C247 4030006860 S.CER C1608 JB 1H 102K-T T 83.5/101.2
C248 4030006860 S.CER C1608 JB 1H 102K-T T 86.2/101.2
C249 4030006860 S.CER C1608 JB 1H 102K-T T 90.2/94.1
C250 4030011600 S.CER C1608 JB 1E 104K-T T 115.7/29.4
C251 4030011600 S.CER C1608 JB 1E 104K-T T 120.2/28.7
C252 4030011600 S.CER C1608 JB 1E 104K-T T 129.5/26.5
C253 4030011600 S.CER C1608 JB 1E 104K-T T 130.2/103.7
C254 4030010210 S.CER C3216 JB 1C 105M-T T 132.7/88.7
C255 4030011600 S.CER C1608 JB 1E 104K-T T 126/90.4
C256 4550006050 S.TAN TEESVA 0J 106M8R T 228.6/61.8
C257 4550006050 S.TAN TEESVA 0J 106M8R T 158.4/14.9
C258 4030007170 S.CER C1608 CH 1H 221J-T T 82/26.1
C263 4030009920 S.CER C1608 CH 1H 050B-T T 213.3/96.7
C264 4030009530 S.CER C1608 CH 1H 030B-T T 215.4/95.4
C265 4030009920 S.CER C1608 CH 1H 050B-T T 218.1/94.2
C266 4030009540 S.CER C1608 CH 1H 1R5B-T T 218.7/95.5
C267 4030009910 S.CER C1608 CH 1H 040B-T T 220.6/94.8
C269 4030007160 S.CER C1608 CH 1H 181J-T T 14.2/96.3
C270 4030008770 S.CER C1608 JB 1H 562K-T T 12.3/40.9
C271 4550003220 S.TAN TEESVA 1E 105M8R T 17/33
C281 4030007050 S.CER C1608 CH 1H 220J-T T 60.7/84.9
C282 4030007050 S.CER C1608 CH 1H 220J-T T 64.6/91.6
C283 4030007050 S.CER C1608 CH 1H 220J-T T 63.6/96.2
C284 4030007050 S.CER C1608 CH 1H 220J-T T 65.1/78
C285 4030007050 S.CER C1608 CH 1H 220J-T T 80.1/77.4
C286 4030007050 S.CER C1608 CH 1H 220J-T T 82.9/77.4
C287 4030007050 S.CER C1608 CH 1H 220J-T T 84.4/82.5
C288 4030007050 S.CER C1608 CH 1H 220J-T T 84.4/85.3
C289 4030007050 S.CER C1608 CH 1H 220J-T T 86.5/88.2
C290 4030007050 S.CER C1608 CH 1H 220J-T T 86.2/93.5
C291 4030007050 S.CER C1608 CH 1H 220J-T T 86/95.5
C292 4030007050 S.CER C1608 CH 1H 220J-T T 71.6/102.4
C293 4030007050 S.CER C1608 CH 1H 220J-T T 75.1/102
C294 4030007050 S.CER C1608 CH 1H 220J-T T 79.1/101.5
C296 4030007050 S.CER C1608 CH 1H 220J-T T 81.5/103.6
C297 4030007050 S.CER C1608 CH 1H 220J-T T 83.5/102.5
C298 4030007050 S.CER C1608 CH 1H 220J-T T 86.2/102.5
C299 4030007050 S.CER C1608 CH 1H 220J-T T 87.8/91.6
C300 4030007050 S.CER C1608 CH 1H 220J-T T 219.1/91.6
C301 4030006860 S.CER C1608 JB 1H 102K-T T 58.1/94
C302 4030007050 S.CER C1608 CH 1H 220J-T T 20.4/71.9
C303 4030007050 S.CER C1608 CH 1H 220J-T T 12.9/74
C304 4030007050 S.CER C1608 CH 1H 220J-T T 27/72.6
C305 4030007050 S.CER C1608 CH 1H 220J-T T 12.9/83.3
C306 4030007050 S.CER C1608 CH 1H 220J-T T 21.4/89.8
C307 4030007050 S.CER C1608 CH 1H 220J-T T 26.1/90.2
C308 4030007050 S.CER C1608 CH 1H 220J-T T 23.1/73.2
C309 4030007010 S.CER C1608 CH 1H 100D-T T 32.2/71.8
C310 4030007010 S.CER C1608 CH 1H 100D-T T 35.9/74
C311 4030007010 S.CER C1608 CH 1H 100D-T T 36.2/76.6
C312 4030007010 S.CER C1608 CH 1H 100D-T T 36.5/79.2
C313 4030007010 S.CER C1608 CH 1H 100D-T T 32.2/78.7
C314 4030007010 S.CER C1608 CH 1H 100D-T T 32.2/81.4
C315 4030007010 S.CER C1608 CH 1H 100D-T T 36.1/85.1
C316 4030007010 S.CER C1608 CH 1H 100D-T T 32.2/85.2
C317 4030007010 S.CER C1608 CH 1H 100D-T T 36.1/89
C318 4030007010 S.CER C1608 CH 1H 100D-T T 32.2/89.2
C319 4030006860 S.CER C1608 JB 1H 102K-T T 39.1/55.7
C320 4030007050 S.CER C1608 CH 1H 220J-T T 10.5/103.8
C321 4030007050 S.CER C1608 CH 1H 220J-T T 35.2/47.1
C322 4030007050 S.CER C1608 CH 1H 220J-T T 34.4/39.7
C323 4030007050 S.CER C1608 CH 1H 220J-T T 33.9/54.3
C324 4030007050 S.CER C1608 CH 1H 220J-T T 25.1/39.7
C325 4030007050 S.CER C1608 CH 1H 220J-T T 18.6/48.2
C326 4030007050 S.CER C1608 CH 1H 220J-T T 18.6/52.9
C327 4030007050 S.CER C1608 CH 1H 220J-T T 35.2/49.9
C328 4030007050 S.CER C1608 CH 1H 220J-T T 36.3/55.7
C329 4030007050 S.CER C1608 CH 1H 220J-T T 37/61.4
C330 4030007050 S.CER C1608 CH 1H 220J-T T 35.7/61.4
C331 4030007050 S.CER C1608 CH 1H 220J-T T 31.8/61.4
C332 4030007050 S.CER C1608 CH 1H 220J-T T 30.5/61.4
C333 4030007050 S.CER C1608 CH 1H 220J-T T 25.9/57.2
C334 4030007050 S.CER C1608 CH 1H 220J-T T 27.5/61.4
C335 4030007050 S.CER C1608 CH 1H 220J-T T 23.4/58.1
C336 4030007050 S.CER C1608 CH 1H 220J-T T 22.3/61.4
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[PLL-B UNIT]
C337 4030007050 S.CER C1608 CH 1H 220J-T T 21.8/56.8
C338 4030007050 S.CER C1608 CH 1H 220J-T T 13.5/33.6
C339 4030007050 S.CER C1608 CH 1H 220J-T T 11.8/76.6
C340 4030007050 S.CER C1608 CH 1H 220J-T T 11.2/78.5
C341 4030007050 S.CER C1608 CH 1H 220J-T T 11.8/80.4
C342 4030007050 S.CER C1608 CH 1H 220J-T T 24/91.8
C343 4030006860 S.CER C1608 JB 1H 102K-T T 8.1/92.6
C344 4030007020 S.CER C1608 CH 1H 120J-T T 37.4/94.3
C345 4030007130 S.CER C1608 CH 1H 101J-T T 32.5/95.2
C346 4030009990 S.CER C1608 CH 1H 200J-T T 31.7/93
C347 4030006880 S.CER C1608 JB 1H 472K-T T 26.4/69.2
C348 4030010210 S.CER C3216 JB 1C 105M-T T 30/70.7
C349 4030006860 S.CER C1608 JB 1H 102K-T T 28.3/71
C350 4030007050 S.CER C1608 CH 1H 220J-T T 16.6/51.2
C351 4030006860 S.CER C1608 JB 1H 102K-T T 7.9/47.8
C352 4510008510 S.ELE EEE1CA471P T 29.5/10.2
C353 4550006050 S.TAN TEESVA 0J 106M8R T 137.5/97.4
C354 4550006050 S.TAN TEESVA 0J 106M8R T 131.2/30.1
C355 4030007070 S.CER C1608 CH 1H 330J-T T 132.5/86.3
C356 4550000550 S.TAN TEESVA 1V 224M8R T 125.3/70.6
C358 4030006860 S.CER C1608 JB 1H 102K-T T 128/63.1
C359 4030007090 S.CER C1608 CH 1H 470J-T T 128/61.8
C360 4030011280 S.CER C1608 CH 1H 271J-T T 18.9/60.6
C361 4030009580 S.CER C1608 JB 1H 681K-T T 16.6/61.4
C362 4030006850 S.CER C1608 JB 1H 471K-T T 14.7/60.6
C363 4030007140 S.CER C1608 CH 1H 121J-T T 78.5/21.9
C364 4030007140 S.CER C1608 CH 1H 121J-T T 80.6/17.8
C365 4030010210 S.CER C3216 JB 1C 105M-T T 167.5/13.7
C366 4030007050 S.CER C1608 CH 1H 220J-T T 232/59.7
C367 4030010210 S.CER C3216 JB 1C 105M-T T 229.2/70.9
C368 4030006880 S.CER C1608 JB 1H 472K-T T 58.8/35.8
C369 4030010210 S.CER C3216 JB 1C 105M-T T 52.8/36.9
C370 4030006860 S.CER C1608 JB 1H 102K-T T 52.4/40.8
C371 4530000410 S.ARR EZANCE 471M 470P T 22.2/24.6
C372 4530000410 S.ARR EZANCE 471M 470P T 21.6/16.3
C373 4530000400 S.ARR EZANCE 220M 22P T 21.6/8
C374 4030011600 S.CER C1608 JB 1E 104K-T T 108.2/98.4
C375 4030009530 S.CER C1608 CH 1H 030B-T T 214.8/63.9
C376 4030006860 S.CER C1608 JB 1H 102K-T T 212.2/72
C377 4030006860 S.CER C1608 JB 1H 102K-T T 211.8/52.3
C378 4030006980 S.CER C1608 CH 1H 070D-T T 217/72
C379 4030006990 S.CER C1608 CH 1H 080D-T T 218.3/69.3
C380 4030009530 S.CER C1608 CH 1H 030B-T T 217/69.3
C381 4030007000 S.CER C1608 CH 1H 090D-T T 218.3/66.6
C382 4030009550 S.CER C1608 CH 1H 2R5B-T T 217/66.6
C383 4030007100 S.CER C1608 CH 1H 560J-T T 218.3/63.9
C384 4030009350 S.CER C1608 CH 1H 3R5B-T T 217/63.9
C385 4030009550 S.CER C1608 CH 1H 2R5B-T T 219.6/61.2
C386 4030009520 S.CER C1608 CH 1H 020B-T T 218.3/61.2
C387 4030006970 S.CER C1608 CH 1H 060D-T T 219.6/58.5
C388 4030009500 S.CER C1608 CH 1H 0R5B-T T 218.3/58.5
C389 4030006970 S.CER C1608 CH 1H 060D-T T 220.2/56.6
C390 4030009570 S.CER C1608 CH 1H 0R3B-T T 218.3/55.8
C391 4030009350 S.CER C1608 CH 1H 3R5B-T T 220.2/55
C392 4030006860 S.CER C1608 JB 1H 102K-T T 219.6/72
C393 4030006860 S.CER C1608 JB 1H 102K-T T 219.1/52.2
C394 4030008750 S.CER C1608 CH 1H 360J-T T 229.2/84
C395 4030007020 S.CER C1608 CH 1H 120J-T T 230/86.2
C396 4030007070 S.CER C1608 CH 1H 330J-T T 227.8/82.7
C397 4030007090 S.CER C1608 CH 1H 470J-T T 227.8/85.4
C398 4030007080 S.CER C1608 CH 1H 390J-T T 227.8/87
C399 4030006860 S.CER C1608 JB 1H 102K-T T 235.9/59.7
C400 4030006860 S.CER C1608 JB 1H 102K-T T 233.3/59.7
C401 4030006860 S.CER C1608 JB 1H 102K-T T 232/62.5
C402 4030006860 S.CER C1608 JB 1H 102K-T T 233.5/69.2
C403 4030006860 S.CER C1608 JB 1H 102K-T T 228.4/68.7
C404 4030006860 S.CER C1608 JB 1H 102K-T T 228/72.6
C405 4030006860 S.CER C1608 JB 1H 102K-T T 235.3/72.4
C406 4030006860 S.CER C1608 JB 1H 102K-T T 230.2/76.4
C407 4030006860 S.CER C1608 JB 1H 102K-T T 157.2/9.2
C408 4030006860 S.CER C1608 JB 1H 102K-T T 160/11.6
C409 4030006860 S.CER C1608 JB 1H 102K-T T 160.7/14.2
C410 4030006860 S.CER C1608 JB 1H 102K-T T 165.7/16.9
C411 4030006860 S.CER C1608 JB 1H 102K-T T 169.4/15.1
C412 4030006860 S.CER C1608 JB 1H 102K-T T 168.7/8.7
C413 4030006900 S.CER C1608 JB 1H 103K-T T 173/13.3
C414 4030006990 S.CER C1608 CH 1H 080D-T T 176/13.1
C415 4030007110 S.CER C1608 CH 1H 680J-T T 175.2/15.7
C416 4030007140 S.CER C1608 CH 1H 121J-T T 179.5/15.7
C417 4030007030 S.CER C1608 CH 1H 150J-T T 181/14.2
C418 4030007130 S.CER C1608 CH 1H 101J-T T 182.4/15.7
C419 4030006860 S.CER C1608 JB 1H 102K-T T 156.2/7.3
C420 4030006860 S.CER C1608 JB 1H 102K-T T 130.2/12.2
C421 4030007000 S.CER C1608 CH 1H 090D-T T 128.9/12.2
C422 4030007110 S.CER C1608 CH 1H 680J-T T 127.6/12.2
C423 4030007030 S.CER C1608 CH 1H 150J-T T 128.1/10.2
C424 4030006860 S.CER C1608 JB 1H 102K-T T 118.7/14.2
C425 4030006860 S.CER C1608 JB 1H 102K-T T 130.8/8.4
C426 4030009530 S.CER C1608 CH 1H 030B-T T 128.2/8.4
C427 4030007060 S.CER C1608 CH 1H 270J-T T 128.2/7.1
C428 4030009920 S.CER C1608 CH 1H 050B-T T 126.3/7.2
C429 4030006860 S.CER C1608 JB 1H 102K-T T 117.2/7.5
C430 4030008920 S.CER C1608 JB 1H 473K-T T 225.1/20.3
C431 4510008540 S.ELE EEE1CA100SR T 201.1/7.7
C432 4030008920 S.CER C1608 JB 1H 473K-T T 224.3/17.5
C433 4030006860 S.CER C1608 JB 1H 102K-T T 224.3/16.1
C434 4030006860 S.CER C1608 JB 1H 102K-T T 135.6/83
C435 4030007050 S.CER C1608 CH 1H 220J-T T 65.1/76.7
C436 4030007050 S.CER C1608 CH 1H 220J-T T 68.1/76.9

Jun. 2011
5
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[PLL-B UNIT]
C437 4030007050 S.CER C1608 CH 1H 220J-T T 68.5/75.6
C438 4030007050 S.CER C1608 CH 1H 220J-T T 71.2/75.3
C439 4030007050 S.CER C1608 CH 1H 220J-T T 72/78.2
C440 4030007050 S.CER C1608 CH 1H 220J-T T 72.5/76.6
C441 4030007050 S.CER C1608 CH 1H 220J-T T 75.2/78.7
C442 4030007050 S.CER C1608 CH 1H 220J-T T 76.2/76.1
C443 4030007050 S.CER C1608 CH 1H 220J-T T 76.2/74.8
C444 4030007050 S.CER C1608 CH 1H 220J-T T 79.3/74.8
C445 4550006050 S.TAN TEESVA 0J 106M8R T 58.7/81
C446 4030011600 S.CER C1608 JB 1E 104K-T T 160.7/12.9
C447 4030006860 S.CER C1608 JB 1H 102K-T T 219.5/50.3
C448 4030006860 S.CER C1608 JB 1H 102K-T T 107.4/101.7
C449 4030006860 S.CER C1608 JB 1H 102K-T T 102.7/102
C450 4030006860 S.CER C1608 JB 1H 102K-T T 105/95.8
C451 4030007170 S.CER C1608 CH 1H 221J-T T 105/83.3
C452 4030006860 S.CER C1608 JB 1H 102K-T T 166.1/8.7
C453 4030006860 S.CER C1608 JB 1H 102K-T T 161.3/9.2
C454 4030007050 S.CER C1608 CH 1H 220J-T T 58.1/87.7
C455 4550000510 S.TAN TEESVA 1V 473M8R T 131.6/70.8
C456 4030006900 S.CER C1608 JB 1H 103K-T T 128.3/71.4
C457 4030007090 S.CER C1608 CH 1H 470J-T T 207.9/50.3
C458 4030007090 S.CER C1608 CH 1H 470J-T T 200.8/41.4
C459 4030007090 S.CER C1608 CH 1H 470J-T T 201.3/52.6
C460 4030007090 S.CER C1608 CH 1H 470J-T T 207.9/47.5
C461 4030007090 S.CER C1608 CH 1H 470J-T T 207.9/53.1
C462 4030007090 S.CER C1608 CH 1H 470J-T T 199.3/50.5
C463 4030007090 S.CER C1608 CH 1H 470J-T T 149.6/47
C464 4030006860 S.CER C1608 JB 1H 102K-T T 161.8/7.3
C465 4030006860 S.CER C1608 JB 1H 102K-T T 164.2/14.9
CP1 6910009670 S.CHE HK3-S-T T 104.1/89.9
CP3 6910009670 S.CHE HK3-S-T T 106.9/32.6
J7 6510018450 CON TMP-S01X-B1
W21 8900004510 CAB OPC-452 A
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[VCO-C UNIT]
Q1 1560001311 S.FET MMBFU310LT1G T 35.3/37.4
Q2 1530003451 S.TRA 2SC4835GRL T 41.2/28.6
Q3 1560001311 S.FET MMBFU310LT1G T 37.3/11.2
Q4 1530003451 S.TRA 2SC4835GRL T 41/12.7
D1 1720000261 S.VAR 1SV214(TPH2,F) T 6.4/34.2
D2 1720000261 S.VAR 1SV214(TPH2,F) T 8.2/34.2
D3 1720000261 S.VAR 1SV214(TPH2,F) T 6.6/27.2
D4 1720000261 S.VAR 1SV214(TPH2,F) T 8.4/27.2
D5 1750000531 S.DIO 1SV271(TPH3,F) T 48.8/25.8
D6 1720000261 S.VAR 1SV214(TPH2,F) T 6.6/15.6
D7 1720000261 S.VAR 1SV214(TPH2,F) T 8.4/15.6
D8 1790000540 S.VAR MA338(TX) T 4.1/8.7
D9 1790000540 S.VAR MA338(TX) T 7.1/8.7
D10 1750000531 S.DIO 1SV271(TPH3,F) T 48.8/20.6
L1 6200003001 S.COI NLV32T-R22J T 4/31.7
L3 6200003331 S.COI NLV32T-1R0J T 38.3/40.9
L4 6200003251 S.COI NLV32T-R39J T 36.8/28.4
L5 6200003331 S.COI NLV32T-1R0J T 48/30.2
L6 6200003331 S.COI NLV32T-1R0J T 42.6/21.8
L7 6200003001 S.COI NLV32T-R22J T 4.1/13.2
L9 6200003331 S.COI NLV32T-1R0J T 38.2/5.6
L10 6200003251 S.COI NLV32T-R39J T 38/17.8
L11 6200003331 S.COI NLV32T-1R0J T 47.6/16.8
L12 6200008080 S.COI LQW2BHNR22J03L T 32.1/37.4
L13 6200002400 S.COI LQW31HNR10J03L T 33.5/11
R2 7030003200 S.RES ERJ3GEYJ 100 V (10) T 44.2/36.6
R3 7030003320 S.RES ERJ3GEYJ 101 V (100) T 36.8/32
R4 7030003320 S.RES ERJ3GEYJ 101 V (100) T 44/31.6
R5 7030003510 S.RES ERJ3GEYJ 392 V (3.9K) T 39.9/30.9
R6 7030003460 S.RES ERJ3GEYJ 152 V (1.5K) T 39.2/28.6
R7 7030003320 S.RES ERJ3GEYJ 101 V (100) T 41/26.4
R8 7030003460 S.RES 1.5K ERJ3GE T 39/21.8
R10 7030003200 S.RES ERJ3GEYJ 100 V (10) T 43.6/9
R11 7030003320 S.RES ERJ3GEYJ 101 V (100) T 37.8/15
R12 7030003320 S.RES ERJ3GEYJ 101 V (100) T 44.6/13.6
R13 7030003510 S.RES ERJ3GEYJ 392 V (3.9K) T 41.5/15.8
R14 7030003460 S.RES ERJ3GEYJ 152 V (1.5K) T 40.2/15.8
R15 7030003320 S.RES ERJ3GEYJ 101 V (100) T 44.1/15.8
R16 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 4.7/16.5
R17 7030003860 S.RES ERJ3GE JPW V T 4.7/28.3
C1 4030011340 S.CER C1608 CH 1H 471J-T T 2.9/27.8
C2 4030011340 S.CER C1608 CH 1H 471J-T T 2.9/17.1
C4 4030006850 S.CER C1608 JB 1H 471K-T T 34/41.4
C5 4030006850 S.CER C1608 JB 1H 471K-T T 34/40
C6 4030009500 S.CER 0.5P C1608 CH B T 35.5/34.7
C7 4030009530 S.CER C1608 CH 1H 030B-T T 34/33.5
C8 4030009500 S.CER C1608 CH 1H 0R5B-T T 38/32
C9 4510008500 S.ELE EEE1CA101WP T 46.4/41.2
C10 4030006850 S.CER C1608 JB 1H 471K-T T 40.6/33
C11 4030006850 S.CER C1608 JB 1H 471K-T T 43.1/27.2
C12 4030006970 S.CER C1608 CH 1H 060D-T T 44.3/27.2
C13 4030006850 S.CER C1608 JB 1H 471K-T T 35.6/7
C14 4030006850 S.CER C1608 JB 1H 471K-T T 35.6/8.2
C15 4030009530 S.CER C1608 CH 1H 030B-T T 35.2/13.8
C16 4030009530 S.CER C1608 CH 1H 030B-T T 34.4/15.8
C17 4030009500 S.CER C1608 CH 1H 0R5B-T T 38.2/13.6
C18 4510008500 S.ELE EEE1CA101WP T 46/4.4
C19 4030006860 S.CER C1608 JB 1H 102K-T T 42.8/15.8
C20 4030006970 S.CER C1608 CH 1H 060D-T T 45.4/16.8
C24 4030007050 S.CER C1608 CH 1H 220J-T T 2.9/18.4
C25 4030009500 S.CER 0.5P C1608 CH B T 47.6/34.4
C26 4030006860 S.CER C1608 JB 1H 102K-T T 47.6/33
C27 4030007050 S.CER C1608 CH 1H 220J-T T 47.8/13.6
C28 4030006860 S.CER C1608 JB 1H 102K-T T 47.8/12.2
C29 4030007050 S.CER C1608 CH 1H 220J-T T 42/32.4
C30 4030018630 S.CER C2012 CH 1H 472J-T T 2.8/25.8
C31 4030018630 S.CER C2012 CH 1H 472J-T T 2.8/20.4
J1 6510004960 CON 3022-02B
J3 6910008021 CON IPS-1323-PT
J4 6510004960 CON 3022-02B
J5 6910008021 CON IPS-1323-PT

Jun. 2011
6
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN-A UNIT]
IC2 1110006751 S.IC TK14570L GH T 177.6/72.7
IC3 1110002700 S.IC NJM2904M-TE1-#FMZB T 173.8/64.9
IC4 1110003800 S.IC NJM2904V-TE1-#FMZB T 161.2/72
IC5 1110006880 S.IC UPC3217GV-E1 T 222.3/47.1
IC6 1110006730 S.IC NJM2594V-TE1-#ZZZB T 170.9/38.7
IC7 1110006730 S.IC NJM2594V-TE1-#ZZZB T 92.9/70
IC8 1110003491 S.IC TA31136FNG(D,EL) T 110/80.4
IC9 1110000960 S.IC NJM4558M-TE1-#FMZB B 124.1/99.5
IC10 1110003800 S.IC NJM2904V-TE1-#FMZB T 42.5/87.2
IC11 1130011170 S.IC BU4001BF-E2 B 52.2/92.9
IC12 1110003800 S.IC NJM2904V-TE1-#FMZB T 62/91.1
IC13 1110003800 S.IC NJM2904V-TE1-#FMZB T 152.4/73.5
IC15 1130007700 S.IC BU4094BCF-E2 T 165.1/9.2
IC16 1130007700 S.IC BU4094BCF-E2 T 155.6/9.2
IC17 1180001072 S.IC TA7805F(TE16L1,NQ) T 13.8/3.6
IC18 1130007700 S.IC BU4094BCF-E2 T 174.7/9.2
IC19 1130007690 S.IC BU4066BCF-E2 B 73/79.1
IC20 1110006300 S.IC NJM2172V-TE1-#ZZZB T 36.1/66.3
IC21 1110002550 IC TA7252AP
IC22 1180001531 IC PQ30RV31J00H
IC23 1110002031 IC TA7808S(Q)
IC24 1180001252 S.IC TA7808F(TE16L1,NQ) T 62.6/34
IC25 1180001510 S.IC AN78L24M-(E1) B 76.2/42.3
IC26 1180001500 S.IC AN79L08M-(E1) B 92.2/23.6
IC27 1130005721 S.IC TC7W04F(TE12L,F) T 247.9/72.3
IC28 1120002510 S.IC DS14C232TM S B 240.6/80
IC29 1130007680 S.IC BU4053BCF-E2 B 61.9/70.4
IC30 1130007680 S.IC BU4053BCF-E2 B 75/69.4
IC31 1110003780 S.IC NJM2902V-TE1-#ZZZB T 63.7/60.5
IC32 1110003800 S.IC NJM2904V-TE1-#FMZB T 80.4/67.2
IC33 1140012701 S.IC HD64F3334YF16V(RX1768D) T 246.6/57.5
IC34 1140005612 S.IC HN58C256AFP10E B 245.5/66
IC35 1130011180 S.IC BU4081BF-E2 B 253.2/79.7
IC37 1110005711 S.IC S-80842CLUA-B63-T2G T 255.4/14.8
IC38 1180001072 S.IC TA7805F(TE16L1,NQ) T 235.8/14
IC39 1130013391 S.IC CAT5113VI-50-GT3 B 72.4/57.4
IC40 1130005591 S.IC TC74HC86AF(F) S B 88.1/95.4
IC41 1130005121 S.IC TC74HC74AF(EL,F) B 77.1/95.4
IC42 1110005711 S.IC S-80842CLUA-B63-T2G B 40.1/55.5
IC43 1130005641 S.IC TC4W53F(TE12L,F) B 167/70
Q1 1530002280 S.TRA 2SC4081 T106 S T 184.8/99.8
Q2 1580000540 S.FET 3SK131-T2-LA B 207.5/85.6
Q3 1590001330 S.TRA DTA114EUA T106 T 183.7/78.4
Q4 1580000540 S.FET 3SK131-T2-LA B 205.7/71.9
Q5 1530002981 S.TRA 2SC3650-TD-E T 166.2/90.8
Q6 1530002280 S.TRA 2SC4081 T106 S B 173.2/62.1
Q7 1590004600 S.TRA DMC561030 T 158.3/79.2
Q8 1590004510 S.TRA DMA561040 T 183.2/32.9
Q9 1560000561 S.FET 2SK882-GR(TE85L,F) B 213/56.8
Q10 1590004390 S.TRA DMG504010 T 211.2/39.2
Q11 1560000561 S.FET 2SK882-GR(TE85L,F) B 220.2/38.9
Q12 1530002280 S.TRA 2SC4081 T106 S T 215.4/43.4
Q13 1590004400 S.TRA DMG564010 T 211.1/44.8
Q14 1530002280 S.TRA 2SC4081 T106 S B 205.5/53.4
Q15 1580000540 S.FET 3SK131-T2-LA B 199.1/56.3
Q16 1580000540 S.FET 3SK131-T2-LA B 114.3/63.7
Q17 1580000540 S.FET 3SK131-T2-LA B 102.7/63.2
Q18 1530002280 S.TRA 2SC4081 T106 S T 99.2/73.9
Q20 1590000430 S.TRA DTC144EUA T106 T 124.1/100.9
Q21 1510000771 S.TRA 2SA1586-GR(TE85L,F) T 120.1/100.9
Q23 1510000771 S.TRA 2SA1586-GR(TE85L,F) B 108/98.3
Q25 1590001330 S.TRA DTA114EUA T106 T 118.8/95.7
Q26 1590004600 S.TRA DMC561030 T 122/95.7
Q27 1530002280 S.TRA 2SC4081 T106 S B 101/85.6
Q28 1590001451 S.FET 2SJ144-GR (TE85R,F) B 65/98.5
Q29 1590004600 S.TRA DMC561030 T 124.9/92.4
Q30 1590000430 S.TRA DTC144EUA T106 T 53.5/84.2
Q31 1590000430 S.TRA DTC144EUA T106 B 155.7/72.1
Q32 1590001330 S.TRA DTA114EUA T106 T 169/20.2
Q33 1590004600 S.TRA DMC561030 T 168.9/16.6
Q34 1590004600 S.TRA DMC561030 T 166.3/16.2
Q35 1590001001 S.TRA RN2427(TE85L,F) T 145.6/6
Q36 1590000430 S.TRA DTC144EUA T106 T 150.1/10.4
Q37 1590004600 S.TRA DMC561030 T 177.4/16.7
Q39 1590001001 S.TRA RN2427(TE85L,F) T 182/23.2
Q40 1590004600 S.TRA DMC561030 T 180/16.7
Q41 1590004510 S.TRA DMA561040 T 177.4/20.8
Q42 1590004600 S.TRA DMC561030 T 174.1/16.7
Q43 1590004510 S.TRA DMA561040 T 174.3/20.8
Q44 1590004600 S.TRA DMC561030 T 171.5/16.7
Q45 1590004510 S.TRA DMA561040 T 171.5/20.2
Q46 1590001330 S.TRA DTA114EUA T106 T 67.1/79.1
Q47 1530002280 S.TRA 2SC4081 T106 S T 61/74.4
Q48 1530002280 S.TRA 2SC4081 T106 S B 44.2/70.4
Q49 1530002280 S.TRA 2SC4081 T106 S T 35.6/83.3
Q50 1530002280 S.TRA 2SC4081 T106 S B 37.8/4.2
Q51 1530002801 S.TRA 2SC2873-Y(TE12R,CF) T 62.8/26
Q52 1530002801 S.TRA 2SC2873-Y(TE12R,CF) T 62.8/20.8
Q53 1590004390 S.TRA DMG504010 T 242/72.3
Q54 1590004600 S.TRA DMC561030 T 61.5/66.5
Q55 1590001330 S.TRA DTA114EUA T106 T 138.7/16.1
Q56 1590001330 S.TRA DTA114EUA T106 T 180.1/20.6
Q57 1530002280 S.TRA 2SC4081 T106 S T 243.8/19.6
Q58 1590004400 S.TRA DMG564010 T 201.4/42.6
Q59 1590000430 S.TRA DTC144EUA T106 B 128.7/95.4
Q60 1590000430 S.TRA DTC144EUA T106 T 122/98.3
Q61 1590000430 S.TRA DTC144EUA T106 B 169.2/78.3
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN-A UNIT]
Q62 1530002280 S.TRA 2SC4081 T106 S T 51.5/72
Q63 1590000430 S.TRA DTC144EUA T106 T 69/75.1
Q64 1530002280 S.TRA 2SC4081 T106 S B 104.9/72.3
Q65 1560000561 S.FET 2SK882-GR(TE85L,F) B 101.1/95.2
Q66 1530002280 S.TRA 2SC4081 T106 S B 85/84.8
Q67 1530002280 S.TRA 2SC4081 T106 S B 76.2/88.3
Q68 1590000430 S.TRA DTC144EUA T106 B 79.6/88.3
Q69 1590004400 S.TRA DMG564010 T 85.5/93.5
Q70 1590000430 S.TRA DTC144EUA T106 T 150.8/65.5
Q71 1510000701 S.TRA 2SA1736(TE12R,F) B 17/79
Q72 1560000831 S.FET 2SK2036 (TE85L,F) B 18.5/73.6
Q73 1560000831 S.FET 2SK2036 (TE85L,F) B 33.1/56.9
Q74 1590000430 S.TRA DTC144EUA T106 B 135.5/97.1
Q75 1590000430 S.TRA DTC144EUA T106 B 138.6/86.9
Q491 1560000831 S.FET 2SK2036 (TE85L,F) T 254/75.2
D1 1790000450 S.DIO MA862(TX) B 184.3/91.3
D2 1790000450 S.DIO MA862(TX) B 217.2/78.8
D3 1790000450 S.DIO MA862(TX) B 217.2/75
D4 1750000550 S.DIO 1SS355 TE-17 T 256.4/39.3
D5 1750000111 S.DIO 1SS272(TE85R,F) T 183.3/36.4
D6 1790000450 S.DIO MA862(TX) B 186.4/36.6
D7 1790000450 S.DIO MA862(TX) B 177.4/36.7
D8 1790000450 S.DIO MA862(TX) B 186.4/40.8
D9 1790000450 S.DIO MA862(TX) B 177.4/40.8
D10 1790001211 S.DIO 1SS375-TL-E B 219.5/46.1
D11 1790000450 S.DIO MA862(TX) B 143.8/53.3
D12 1790000450 S.DIO MA862(TX) B 115.9/56.4
D13 1790000450 S.DIO MA862(TX) B 139.9/77.7
D14 1790000450 S.DIO MA862(TX) B 119.3/76.6
D15 1790001211 S.DIO 1SS375-TL-E T 93.4/77.7
D16 1790001211 S.DIO 1SS375-TL-E B 134/94.5
D17 1750000550 S.DIO 1SS355 TE-17 T 125.1/98.3
D18 1750000520 S.DIO DAN222TL T 127.8/100.9
D19 1750000111 S.DIO 1SS272(TE85R,F) T 119.9/91.1
D20 1790001211 S.DIO 1SS375-TL-E B 100.9/77.7
D21 1750000520 S.DIO DAN222TL T 124.9/94.8
D23 1750000550 S.DIO 1SS355 TE-17 T 153/87.5
D24 1750000520 S.DIO DAN222TL T 258.4/39
D25 1750000111 S.DIO 1SS272(TE85R,F) T 57.3/86.9
D26 1750000520 S.DIO DAN222TL T 74.6/85.3
D27 1750000550 S.DIO 1SS355 TE-17 T 63.9/85.9
D28 1750000520 S.DIO DAN222TL T 150.8/68.1
D29 1750000550 S.DIO 1SS355 TE-17 T 253.8/39.3
D31 1750000520 S.DIO DAN222TL T 71.4/79.1
D32 1750000520 S.DIO DAN222TL T 73.1/80.7
D33 1750000550 S.DIO 1SS355 TE-17 T 69.4/78.2
D34 1790000700 DIO DSA3A1
D35 1790000700 DIO DSA3A1
D38 1750000550 S.DIO 1SS355 TE-17 T 43.5/3.1
D39 1750000111 S.DIO 1SS272(TE85R,F) T 79.4/30.7
D40 1750000111 S.DIO 1SS272(TE85R,F) T 82.9/31
D41 1750000111 S.DIO 1SS272(TE85R,F) T 87/29.2
D42 1750000111 S.DIO 1SS272(TE85R,F) T 87.2/32.7
D43 1750000550 S.DIO 1SS355 TE-17 T 239.4/70
D44 1750000111 S.DIO 1SS272(TE85R,F) T 141.9/19
D45 1750000550 S.DIO 1SS355 TE-17 T 10.6/22.7
D46 1750000550 S.DIO 1SS355 TE-17 T 256.6/21.8
D47 1750000111 S.DIO 1SS272(TE85R,F) B 248/41.2
D48 1750000520 S.DIO DAN222TL T 248.7/42.3
D54 1730000431 S.ZEN RD10M-T2B-A B2 T 160.1/91.8
D55 1750000550 S.DIO 1SS355 TE-17 T 147.9/9.2
D56 1710000840 S.DIO 1SR154-400 TE25 B 26.5/47.2
D57 1710000840 S.DIO 1SR154-400 TE25 B 26.5/44.1
D59 1750000550 S.DIO 1SS355 TE-17 T 77.5/99.5
D60 1750000550 S.DIO 1SS355 TE-17 T 70.4/92.1
D61 1790000450 S.DIO MA862(TX) B 86/64
D62 1750000520 S.DIO DAN222TL T 148.7/67.7
D63 1750000520 S.DIO DAN222TL T 147.6/24.9
D64 1750000550 S.DIO 1SS355 TE-17 T 252.4/41.1
D65 1750000550 S.DIO 1SS355 TE-17 T 259.6/44.9
D66 1750000550 S.DIO 1SS355 TE-17 T 78.3/38.4
D67 1790001241 S.DIO MA2S7280GL B 213.2/53.5
D68 1790001241 S.DIO MA2S7280GL B 212/53.5
FI1 2020001170 S.CER SFECA10.7MS2-A-TC
(SFECA10.7MS2) T 190.2/70.5
FI2 2020001170 S.CER SFECA10.7MS2-A-TC
(SFECA10.7MS2) T 184.3/66.4
FI3 2010000090 FIL 10M15BA (FL-75)
FI4 2020000210 CER CFJ455K5 (FL-65)
FI5 2020001181 S.CER SFPKA455KH1A-R1 T 134.5/68.2
FI6 2020001181 S.CER SFPKA455KH1A-R1 T 124.7/68.2
FI7 2020001051 S.CER SFPKA455KE4A-R1 T 134.8/79
FI8 2020001051 S.CER SFPKA455KE4A-R1 T 124.7/79
X1 6070000250 S.DIS CDSCB10M7GF122-R0 T 171.8/74.6
X2 6070000151 S.DIS CDBKB455KCAY24-R0 T 108/72
X3 6050009661 S.XTA MA-406 9.8304 MHz-F T 239/41.1
L1 6200003051 S.COI NLV32T-R82J B 190.3/80.3
L2 6200003381 S.COI #617PT-1837=P3 T 191.1/85.5
L3 6200003381 S.COI #617PT-1837=P3 T 180.6/85.5
L4 6200003261 S.COI NLV32T-101J T 181.8/93.7
L5 6200003021 S.COI NLV32T-R33J B 180/98.9

Jun. 2011
7
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN-A UNIT]
L6 6200000020 S.COI LQH32MN101K23L T 174.6/91.3
L7 6150004170 COI LS-476
L8 6150004170 COI LS-476
L9 6150004200 COI LS-479
L10 6150004210 COI LS-480
L13 6200003151 S.COI NLV32T-180J T 165.2/66.3
L14 6150004200 COI LS-479
L17 6150004210 COI LS-480
L18 6150004170 COI LS-476
L20 6200003261 S.COI NLV32T-101J T 222.6/34.9
L21 6150004170 COI LS-476
L22 6150004170 COI LS-476
L23 6200003261 S.COI NLV32T-101J T 164.9/39.2
L24 6200005501 S.COI NLV32T-471J B 114.8/71.5
L25 6150002271 COI LS-451
L26 6150002291 COI LS-450
L27 6200003261 S.COI NLV32T-101J T 116.1/76.3
L28 6200003950 S.COI HF50ACC 322513-T T 73.8/12.6
L29 6200003261 S.COI NLV32T-101J T 183.8/16.6
L30 6200003261 S.COI NLV32T-101J T 44.8/8.3
L31 6200003261 S.COI NLV32T-101J T 70.8/12.3
L32 6200003261 S.COI NLV32T-101J T 187.9/16.7
L33 6200003261 S.COI NLV32T-101J T 191.8/28.5
L34 6200003950 S.COI HF50ACC 322513-T T 191.8/25.5
L37 6200003950 S.COI HF50ACC 322513-T T 228.5/6.9
L38 6200003261 S.COI NLV32T-101J T 28.8/65
L39 6170000140 COI LW-15
L40 6200003021 S.COI NLV32T-R33J B 173.6/91.8
L41 6200003950 S.COI HF50ACC 322513-T T 155.3/91.4
L42 6200003950 S.COI HF50ACC 322513-T T 22.6/90.4
L43 6200003950 S.COI HF50ACC 322513-T T 22.6/93.8
L44 6180002690 COI SK-17P-070-110
L45 6200005160 S.COI 7A06L-101K-A T 54.5/23.1
L46 6200005170 S.COI 7010-2N-1768 T 74.9/23.1
L47 6200001851 S.COI NLV32T-5R6J B 224.3/41.5
L48 6200005160 S.COI 7A06L-101K-A T 52.9/42.3
L49 6200003261 S.COI NLV32T-101J T 104/95.8
L50 6200003261 S.COI NLV32T-101J T 100.6/98.3
L51 6200003261 S.COI NLV32T-101J T 82.1/98.8
L52 6200003261 S.COI NLV32T-101J T 69.2/49.9
L53 6200000020 S.COI LQH32MN101K23L T 171.6/91.3
L54 6200002861 S.COI NLV25T-4R7J T 170.6/78.4
R2 7030003320 S.RES ERJ3GEYJ 101 V (100) B 191.1/85.9
R3 7030003360 S.RES ERJ3GEYJ 221 V (220) B 181/85.5
R4 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) B 186.1/93.6
R5 7030003740 S.RES ERJ3GEYJ 334 V (330K) T 185.1/97.9
R6 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 183.2/96.6
R7 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) T 185.8/101.7
R8 7030003590 S.RES ERJ3GEYJ 183 V (18K) B 204.3/80
R9 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 206/81.9
R10 7030003240 S.RES ERJ3GEYJ 220 V (22) B 205/85.7
R11 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 206.5/88.6
R12 7030003330 S.RES ERJ3GEYJ 121 V (120) B 208/82.1
R14 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 211.2/85.1
R15 7030003320 S.RES ERJ3GEYJ 101 V (100) T 209.9/81.9
R16 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) B 219.5/85.3
R17 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) B 221.9/77.7
R18 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) B 215.9/70.6
R19 7030003680 S.RES ERJ3GEYJ 104 V (100K) B 212.7/72.1
R20 7030003510 S.RES ERJ3GEYJ 392 V (3.9K) B 208.4/72.1
R21 7030003580 S.RES ERJ3GEYJ 153 V (15K) B 207.1/75.1
R22 7030003400 S.RES ERJ3GEYJ 471 V (470) B 206.1/68.8
R23 7030003320 S.RES ERJ3GEYJ 101 V (100) B 201.2/76.4
R24 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) T 204.5/72
R25 7030003400 S.RES ERJ3GEYJ 471 V (470) B 205.4/75.1
R26 7030000340 S.RES MCR10EZHJ 470 (471) T 166/87
R27 7030003860 S.RES ERJ3GE JPW V B 199.1/71.6
R33 7030003410 S.RES ERJ3GEYJ 561 V (560) T 189.3/67.6
R34 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) T 166.1/74.7
R35 7030003860 S.RES ERJ3GE JPW V B 170.9/76.4
R36 7030003660 S.RES ERJ3GEYJ 683 V (68K) B 168.3/76.4
R37 7030003510 S.RES ERJ3GEYJ 392 V (3.9K) B 172.4/75.1
R38 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) B 163.9/85.7
R39 7030003470 S.RES ERJ3GEYJ 182 V (1.8K) B 163.1/83.8
R40 7030003590 S.RES ERJ3GEYJ 183 V (18K) T 175.3/76.9
R41 7030003590 S.RES ERJ3GEYJ 183 V (18K) T 177.9/75.7
R42 7030003490 S.RES ERJ3GEYJ 272 V (2.7K) T 175.5/60.9
R43 7030003540 S.RES ERJ3GEYJ 682 V (6.8K) T 173.5/60.2
R44 7030003430 S.RES ERJ3GEYJ 821 V (820) B 172.1/78.3
R49 7030003600 S.RES ERJ3GEYJ 223 V (22K) B 175.2/62
R50 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 176.6/62
R52 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 171.6/60.3
R55 7030003630 S.RES ERJ3GEYJ 393 V (39K) B 157.1/79
R56 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 155.1/83.9
R57 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 156.7/83.9
R58 7030003490 S.RES ERJ3GEYJ 272 V (2.7K) B 161.1/82.3
R59 7030003670 S.RES ERJ3GEYJ 823 V (82K) B 162/77.5
R60 7310004880 S.TRI EVM-3YSX50 B55 (504) T 162.8/79.1
R61 7030003740 S.RES ERJ3GEYJ 334 V (330K) B 160.6/77.5
R62 7030003750 S.RES ERJ3GEYJ 394 V (390K) T 161.2/76.6
R65 7030003680 S.RES ERJ3GEYJ 104 V (100K) B 155.9/74.9
R67 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) B 227.3/74.3
R68 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 188.8/40.7
R69 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) B 184.1/35.4
R70 7030003320 S.RES ERJ3GEYJ 101 V (100) B 181.9/34.6
R71 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) B 179.7/35.4
R72 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) B 178.9/33
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN-A UNIT]
R73 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) B 184.1/40.5
R74 7030003320 S.RES ERJ3GEYJ 101 V (100) B 181.9/41.3
R75 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) B 179.7/40.5
R76 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) B 180.5/42.6
R77 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 174.4/39.9
R78 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 181.8/30.9
R79 7030003510 S.RES ERJ3GEYJ 392 V (3.9K) B 199.6/63
R80 7030003680 S.RES ERJ3GEYJ 104 V (100K) B 192.2/60.1
R81 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 194/59.6
R82 7030003680 S.RES ERJ3GEYJ 104 V (100K) B 212.9/58.8
R83 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) B 214.5/53.6
R85 7030003530 S.RES ERJ3GEYJ 562 V (5.6K) T 210/37.1
R88 7030003680 S.RES ERJ3GEYJ 104 V (100K) B 222.1/39
R89 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) B 216.4/38.4
R90 7030003320 S.RES ERJ3GEYJ 101 V (100) B 215.6/42.5
R91 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 215.3/41.4
R92 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) B 212.1/45
R93 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) B 208.2/47.7
R94 7030003620 S.RES ERJ3GEYJ 333 V (33K) B 215.2/47.1
R95 7030003400 S.RES ERJ3GEYJ 471 V (470) T 211.1/42.7
R96 7030003320 S.RES ERJ3GEYJ 101 V (100) B 211.3/51
R97 7030003240 S.RES ERJ3GEYJ 220 V (22) B 210.1/44.7
R98 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 208.2/45.5
R99 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 207.4/49.2
R101 7030003330 S.RES ERJ3GEYJ 121 V (120) B 202.3/56.3
R102 7030003240 S.RES ERJ3GEYJ 220 V (22) B 199/58.7
R103 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 196/56.6
R104 7030003600 S.RES ERJ3GEYJ 223 V (22K) B 200.2/49.1
R106 7030003320 S.RES ERJ3GEYJ 101 V (100) T 202.6/53.9
R107 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) T 165.6/37.1
R108 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) B 140.2/66.8
R110 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) B 140.6/52.3
R111 7030003320 S.RES ERJ3GEYJ 101 V (100) B 136.6/52.3
R113 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) B 117/53.1
R114 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 119.6/51.5
R115 7030003360 S.RES ERJ3GEYJ 221 V (220) B 141.4/59.9
R116 7030003540 S.RES ERJ3GEYJ 682 V (6.8K) B 140.6/54.3
R117 7030003320 S.RES ERJ3GEYJ 101 V (100) B 137.7/54.3
R118 7030003860 S.RES ERJ3GE JPW V B 118.2/60.3
R119 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) B 118.2/57.6
R120 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 119/55.4
R121 7030003860 S.RES ERJ3GE JPW V B 138.5/72.3
R122 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) B 136.9/76.7
R123 7030003320 S.RES ERJ3GEYJ 101 V (100) B 134.2/76.7
R124 7030003860 S.RES ERJ3GE JPW V B 121.6/73.6
R125 7030003460 S.RES ERJ3GEYJ 152 V (1.5K) B 122.4/75.6
R126 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 126.2/75.9
R127 7030003860 S.RES ERJ3GE JPW V B 139.7/81.9
R128 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) B 136.9/78.7
R129 7030003320 S.RES ERJ3GEYJ 101 V (100) B 134.2/78.7
R130 7030003860 S.RES ERJ3GE JPW V B 121.6/79.6
R131 7030003460 S.RES ERJ3GEYJ 152 V (1.5K) B 122.4/77.6
R132 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 126.2/79.5
R133 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) B 119/63.4
R134 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 116.6/66.9
R135 7030003400 S.RES ERJ3GEYJ 471 V (470) B 114.7/60.6
R136 7030003320 S.RES ERJ3GEYJ 101 V (100) T 114.1/67.4
R137 7030003330 S.RES ERJ3GEYJ 121 V (120) B 114.3/66.9
R138 7510001390 S.THE NTCG20 3FH 332JT T 103.4/65.7
R139 7310004820 S.TRI EVM-3YSX50 B33 (302) T 103.6/61.2
R140 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 105.8/67.3
R141 7030003400 S.RES ERJ3GEYJ 471 V (470) B 102.7/59.7
R142 7030003320 S.RES ERJ3GEYJ 101 V (100) T 101.8/66.1
R143 7030003330 S.RES ERJ3GEYJ 121 V (120) B 101.8/67.4
R144 7030003680 S.RES ERJ3GEYJ 104 V (100K) B 112.7/74.3
R145 7030003580 S.RES ERJ3GEYJ 153 V (15K) B 115.4/75.6
R146 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) B 92.5/72.3
R147 7030003540 S.RES ERJ3GEYJ 682 V (6.8K) B 93.3/74.2
R148 7030003540 S.RES ERJ3GEYJ 682 V (6.8K) B 92.5/78.9
R149 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 89.7/78.9
R150 7030003590 S.RES ERJ3GEYJ 183 V (18K) B 89.7/76.9
R151 7030003320 S.RES ERJ3GEYJ 101 V (100) T 86/64
R152 7030003720 S.RES ERJ3GEYJ 224 V (220K) T 101.1/74
R153 7030003400 S.RES ERJ3GEYJ 471 V (470) T 100/70.7
R154 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 97.3/74
R155 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 91.4/78.8
R156 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 93.5/82.2
R157 7030003660 S.RES ERJ3GEYJ 683 V (68K) T 93.5/80.9
R158 7030003540 S.RES ERJ3GEYJ 682 V (6.8K) T 91.5/83
R159 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 88.6/83
R160 7030003470 S.RES ERJ3GEYJ 182 V (1.8K) B 107.2/80.1
R163 7030003650 S.RES ERJ3GEYJ 563 V (56K) T 114.9/82.2
R164 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 113.4/85.2
R165 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 113.4/87.8
R166 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 110.7/90.8
R167 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 78.2/75.3
R168 7030003600 S.RES ERJ3GEYJ 223 V (22K) B 137.9/96
R169 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 137.9/98.9
R170 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 161.3/71.7
R173 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 160.5/67.5
R174 7030003320 S.RES ERJ3GEYJ 101 V (100) B 158.6/73.5
R175 7030003600 S.RES ERJ3GEYJ 223 V (22K) B 160.3/66.8
R176 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 126.1/100.9
R178 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 114.9/100.8
R179 7030003400 S.RES ERJ3GEYJ 471 V (470) T 110.2/100.2
R180 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 110.2/97.3
R181 7030003610 S.RES ERJ3GEYJ 273 V (27K) B 111.6/100
R182 7030003550 S.RES ERJ3GEYJ 822 V (8.2K) B 114.2/93.9
R183 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) B 116.3/96.3

Jun. 2011
8
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN-A UNIT]
R184 7030003840 S.RES ERJ3GEYJ 225 V (2.2M) B 108.3/93.3
R186 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 120.5/93.5
R187 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 101.8/87.7
R188 7030003660 S.RES ERJ3GEYJ 683 V (68K) B 100.9/80.8
R190 7030003320 S.RES ERJ3GEYJ 101 V (100) T 92.3/52.6
R191 7030003620 S.RES ERJ3GEYJ 333 V (33K) B 117.1/102.1
R192 7510001390 S.THE NTCG20 3FH 332JT B 114.1/102.4
R193 7030005451 S.RES ERA3YED 153V (15K) T 128.7/98.4
R194 7030003540 S.RES ERJ3GEYJ 682 V (6.8K) B 119/102.2
R195 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 118.7/100.2
R196 7030003800 S.RES ERJ3GEYJ 105 V (1M) B 121.8/95.3
R197 7030003840 S.RES ERJ3GEYJ 225 V (2.2M) B 118.2/97.9
R199 7030003320 S.RES ERJ3GEYJ 101 V (100) T 137.6/91.6
R200 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 47.5/86.4
R201 7030003320 S.RES ERJ3GEYJ 101 V (100) B 47.7/83.2
R202 7030003400 S.RES ERJ3GEYJ 471 V (470) B 43.1/89.1
R203 7030003680 S.RES ERJ3GEYJ 104 V (100K) B 46.4/84.8
R204 7030003600 S.RES ERJ3GEYJ 223 V (22K) B 41.8/85.4
R205 7030003680 S.RES ERJ3GEYJ 104 V (100K) B 45.2/90.6
R206 7030003400 S.RES ERJ3GEYJ 471 V (470) B 38.6/90.3
R207 7030003720 S.RES ERJ3GEYJ 224 V (220K) T 41.6/89.9
R208 7030003580 S.RES ERJ3GEYJ 153 V (15K) B 58.5/93.5
R209 7030003580 S.RES ERJ3GEYJ 153 V (15K) B 51.3/87.3
R210 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 51.7/95.7
R211 7030003760 S.RES ERJ3GEYJ 474 V (470K) B 66.4/95.1
R212 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 58.5/92.3
R213 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 64.5/95.9
R214 7030003680 S.RES ERJ3GEYJ 104 V (100K) B 62.8/98.6
R215 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 72.1/85.9
R216 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) B 61.4/91
R217 7030003590 S.RES ERJ3GEYJ 183 V (18K) T 55.4/89.8
R218 7030003400 S.RES ERJ3GEYJ 471 V (470) T 58.3/90
R219 7030003400 S.RES ERJ3GEYJ 471 V (470) T 56.5/91.7
R220 7030003600 S.RES ERJ3GEYJ 223 V (22K) B 57.6/88.7
R221 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) T 60.7/85.9
R222 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 65.1/89.4
R224 7030003660 S.RES ERJ3GEYJ 683 V (68K) B 56.8/85.7
R225 7030003740 S.RES ERJ3GEYJ 334 V (330K) T 56.4/84.5
R226 7030003400 S.RES ERJ3GEYJ 471 V (470) T 72.1/84.6
R227 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 60.7/85.7
R228 7030003810 S.RES ERJ3GEYJ 125 V (1.2M) B 59/89.5
R229 7030003680 S.RES ERJ3GEYJ 104 V (100K) B 53.5/87.3
R230 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 131.7/90.5
R231 7030003590 S.RES ERJ3GEYJ 183 V (18K) B 151.9/73.1
R232 7030003590 S.RES ERJ3GEYJ 183 V (18K) T 153.5/68
R233 7310004870 S.TRI EVM-3YSX50 B54 (503) T 154.8/65
R234 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 154.4/78.2
R235 7030003680 S.RES ERJ3GEYJ 104 V (100K) B 151/76
R236 7030003320 S.RES ERJ3GEYJ 101 V (100) B 151.8/79.3
R237 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 149.8/68.9
R238 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 155.8/70.2
R240 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 250.9/23.8
R244 7030007510 S.RES ERJ12YJ270U (27) B 30/3.3
R245 7030007510 S.RES ERJ12YJ270U (27) B 26.3/3.3
R246 7410001070 S.ARR EXB-V8V 221V (220) T 166.2/21.9
R247 7030003600 S.RES ERJ3GEYJ 223 V (22K) T 75.7/72.8
R248 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) B 65.9/78.3
R249 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 64.5/77.5
R250 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 65.3/75.3
R251 7030003530 S.RES ERJ3GEYJ 562 V (5.6K) B 56.4/72.3
R252 7310005480 TRI VZ067TL1 B503 (50K)
R253 7030003680 S.RES ERJ3GEYJ 104 V (100K) B 48/73.3
R254 7310005480 TRI VZ067TL1 B503 (50K)
R255 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 46.4/73.3
R256 7030003760 S.RES ERJ3GEYJ 474 V (470K) B 44.2/72.5
R257 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 43.9/76.4
R258 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) B 44.2/68.2
R259 7030003600 S.RES ERJ3GEYJ 223 V (22K) T 44.7/63.9
R260 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 43.4/59.7
R261 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 43.5/62.4
R262 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 41.1/67.4
R263 7030003360 S.RES ERJ3GEYJ 221 V (220) T 45.3/71.7
R264 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 36.8/71.3
R265 7030003320 S.RES ERJ3GEYJ 101 V (100) T 27.3/59.3
R266 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) T 48.3/84.2
R267 7030003570 S.RES ERJ3GEYJ 123 V (12K) T 33.4/76.4
R268 7030003650 S.RES ERJ3GEYJ 563 V (56K) T 37.7/81.3
R269 7030003600 S.RES ERJ3GEYJ 223 V (22K) T 37.7/84
R270 7030003360 S.RES ERJ3GEYJ 221 V (220) T 41.8/77.2
R271 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) T 35.5/81.2
R272 7030003420 S.RES ERJ3GEYJ 681 V (680) T 35.5/85.2
R273 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 33.4/85.9
R274 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 23.8/64.1
R275 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 23.8/65.4
R276 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 17.5/73.9
R277 7030003200 S.RES ERJ3GEYJ 100 V (10) T 18.8/69.8
R278 7030004050 S.RES ERJ3GEYJ 1R0 V (1) T 30.4/78.5
R279 7030003400 S.RES ERJ3GEYJ 471 V (470) T 4.9/33.5
R280 7310004780 S.TRI EVM-3YSX50 B13 (102) T 9/33.5
R281 7030003510 S.RES ERJ3GEYJ 392 V (3.9K) T 13.1/32.5
R282 7030010540 S.RES ERJ1TYJ 330U (33) B 12.2/29.9
R283 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 37.8/1
R284 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 37.8/2.3
R285 7030010540 S.RES ERJ1TYJ 330U (33) B 12.2/25.8
R286 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 59.5/23.2
R287 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 59.4/26.7
R288 7030006220 S.RES ERJ12YJ470U (47) B 74.7/35.6
R289 7030003200 S.RES ERJ3GEYJ 100 V (10) T 86.8/37.9
R290 7030007510 S.RES ERJ12YJ270U (27) B 86.6/23.1
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN-A UNIT]
R291 7030003200 S.RES ERJ3GEYJ 100 V (10) T 95.1/30.5
R292 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 251.4/70.9
R293 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 244.4/72.3
R294 7030003590 S.RES ERJ3GEYJ 183 V (18K) T 242.8/74.2
R295 7030003540 S.RES ERJ3GEYJ 682 V (6.8K) T 239.5/72.3
R296 7030003620 S.RES ERJ3GEYJ 333 V (33K) T 238.2/72.3
R297 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 58.2/66.1
R298 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 64.3/69.7
R299 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 66.7/75.8
R300 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 69.3/71.5
R301 7030003650 S.RES ERJ3GEYJ 563 V (56K) T 68.9/59.3
R302 7030003660 S.RES ERJ3GEYJ 683 V (68K) T 65.1/71
R303 7030003570 S.RES ERJ3GEYJ 123 V (12K) T 65.1/72.3
R304 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 67.9/55.7
R305 7030003630 S.RES ERJ3GEYJ 393 V (39K) T 68.9/57.3
R306 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 64/56.2
R307 7030003700 S.RES ERJ3GEYJ 154 V (150K) T 63.7/63.9
R308 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 62.7/56.2
R309 7030003670 S.RES ERJ3GEYJ 823 V (82K) B 69.1/68.6
R310 7030003580 S.RES ERJ3GEYJ 153 V (15K) B 70.5/65.8
R311 7030003700 S.RES ERJ3GEYJ 154 V (150K) T 58.2/61
R312 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 61.4/56.2
R315 7030003430 S.RES ERJ3GEYJ 821 V (820) T 112.4/73.4
R316 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 112.1/85.2
R317 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 106/84.5
R318 7030003760 S.RES ERJ3GEYJ 474 V (470K) B 107.8/83.7
R319 7030003470 S.RES ERJ3GEYJ 182 V (1.8K) B 123.7/95.3
R320 7030003490 S.RES ERJ3GEYJ 272 V (2.7K) B 125.1/95.3
R322 7030003680 S.RES ERJ3GEYJ 104 V (100K) B 128.7/99.1
R323 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) B 86.1/58.7
R324 7030003320 S.RES ERJ3GEYJ 101 V (100) T 95.5/84.1
R325 7030003320 S.RES ERJ3GEYJ 101 V (100) B 40.4/6.9
R326 7030003320 S.RES ERJ3GEYJ 101 V (100) T 46.2/56.4
R329 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 127.6/93.3
R330 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 246.6/54.1
R331 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 246.6/52.8
R332 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 246.6/51.5
R333 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 258.8/19.2
R334 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 258.8/15.8
R335 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 247.6/20.8
R336 7030003720 S.RES ERJ3GEYJ 224 V (220K) T 251.9/21.6
R337 7030003760 S.RES ERJ3GEYJ 474 V (470K) T 253.8/20.8
R338 7030003720 S.RES ERJ3GEYJ 224 V (220K) T 250/20.8
R339 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 252.8/38.3
R340 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 252.3/33.5
R341 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 252.3/36.9
R342 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 258.3/68.5
R343 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 259.1/70.5
R344 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 255.2/33
R345 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 253.6/25.1
R346 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 253.6/23.8
R347 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 258.6/61.4
R348 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 255.2/30.4
R349 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 247.7/46.1
R350 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 249.3/40.6
R351 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 236.2/51.1
R352 7030003630 S.RES ERJ3GEYJ 393 V (39K) T 253.8/71.7
R353 7030003860 S.RES ERJ3GE JPW V B 257/62.4
R354 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 254.4/26.5
R355 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 254.4/27.8
R356 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 255.2/29.1
R357 7030010610 S.RES ERJ1TYJ 470U (47) T 233.5/5.1
R358 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 253.8/72.9
R359 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 250/4.9
R361 7030003600 S.RES ERJ3GEYJ 223 V (22K) T 153.6/84.5
R362 7510001380 S.THE NTCG20 3JH 472JT T 153.8/82.9
R364 7030003680 S.RES ERJ3GEYJ 104 V (100K) B 124.4/93.3
R365 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) B 71.8/62.5
R366 7030003490 S.RES ERJ3GEYJ 272 V (2.7K) B 66.1/58.8
R367 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 105/66.3
R368 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) B 97.2/62.1
R370 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 82.3/61.4
R371 7030003410 S.RES ERJ3GEYJ 561 V (560) B 183.3/37.5
R372 7030003400 S.RES ERJ3GEYJ 471 V (470) B 209.3/43.2
R373 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) T 196.3/81.8
R374 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) B 221.9/76.1
R375 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 184.5/30.9
R376 7030003320 S.RES ERJ3GEYJ 101 V (100) T 170.4/34.7
R377 7030003680 S.RES ERJ3GEYJ 104 V (100K) B 68.9/58
R378 7030003800 S.RES ERJ3GEYJ 105 V (1M) B 61.8/60.5
R379 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 49.1/72.2
R380 7030003700 S.RES ERJ3GEYJ 154 V (150K) T 51.5/70
R381 7030003320 S.RES ERJ3GEYJ 101 V (100) T 51.5/73.9
R382 7030003320 S.RES ERJ3GEYJ 101 V (100) T 48.3/70
R383 7030003550 S.RES ERJ3GEYJ 822 V (8.2K) T 89.4/81
R384 7030003350 S.RES ERJ3GEYJ 181 V (180) B 222.2/52.4
R385 7030003340 S.RES ERJ3GEYJ 151 V (150) B 191.1/88
R386 7030003270 S.RES ERJ3GEYJ 390 V (39) B 189/88.8
R387 7030003340 S.RES ERJ3GEYJ 151 V (150) B 191.1/89.6
R388 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) B 201.7/84.9
R389 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 129.7/70.3
R390 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 89/56.2
R391 7030003590 S.RES ERJ3GEYJ 183 V (18K) B 91.1/57
R392 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 119.7/98.3
R393 7030003600 S.RES ERJ3GEYJ 223 V (22K) T 122.1/100.9
R394 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 125/96.5
R395 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 58.2/67.9
R396 7030003600 S.RES ERJ3GEYJ 223 V (22K) T 72.7/72.8
R397 7030003600 S.RES ERJ3GEYJ 223 V (22K) T 72.7/71.4

Jun. 2011
9
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN-A UNIT]
R398 7030003600 S.RES ERJ3GEYJ 223 V (22K) T 75.5/71
R399 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) B 110.3/100
R400 7030003680 S.RES ERJ3GEYJ 104 V (100K) B 112.9/100
R401 7030003670 S.RES ERJ3GEYJ 823 V (82K) B 114.9/99.2
R402 7030003320 S.RES ERJ3GEYJ 101 V (100) B 39/6.9
R403 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 173.5/76.4
R404 7030003400 S.RES ERJ3GEYJ 471 V (470) B 107.9/88.4
R406 7030003320 S.RES ERJ3GEYJ 101 V (100) T 144/91.7
R407 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) B 47.2/69.6
R408 7030003800 S.RES ERJ3GEYJ 105 V (1M) B 63.7/63.3
R409 7030003320 S.RES ERJ3GEYJ 101 V (100) T 58.8/54.3
R410 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 74.3/50.1
R411 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 39.9/84.6
R412 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 37.9/84.9
R413 7030003650 S.RES ERJ3GEYJ 563 V (56K) B 107/90.8
R414 7030003510 S.RES ERJ3GEYJ 392 V (3.9K) T 81.8/72.7
R415 7030003760 S.RES ERJ3GEYJ 474 V (470K) T 79/72.5
R416 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 78.1/62.4
R417 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 106.9/72.2
R418 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 106.9/69.3
R419 7030003420 S.RES ERJ3GEYJ 681 V (680) B 109.7/74.3
R420 7030003360 S.RES ERJ3GEYJ 221 V (220) B 106.9/74.3
R421 7030003430 S.RES ERJ3GEYJ 821 V (820) B 108.9/70.1
R423 7030003860 S.RES ERJ3GE JPW V B 33.7/66.8
R424 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 78.5/61.1
R425 7030003660 S.RES ERJ3GEYJ 683 V (68K) B 30.6/66.8
R426 7030003320 S.RES ERJ3GEYJ 101 V (100) B 100/100.5
R427 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 100/97.8
R428 7030003680 S.RES ERJ3GEYJ 104 V (100K) B 101.1/93.3
R429 7030003360 S.RES ERJ3GEYJ 221 V (220) B 89.2/86.8
R430 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 87.1/84.7
R431 7030003590 S.RES ERJ3GEYJ 183 V (18K) B 87.1/81.8
R432 7030003420 S.RES ERJ3GEYJ 681 V (680) B 86.5/86.8
R433 7030003400 S.RES ERJ3GEYJ 471 V (470) B 89.2/82.6
R435 7030003840 S.RES ERJ3GEYJ 225 V (2.2M) B 93.3/98.6
R436 7030003320 S.RES ERJ3GEYJ 101 V (100) B 92.5/100.6
R437 7030003840 S.RES ERJ3GEYJ 225 V (2.2M) B 94.6/94.6
R438 7030003320 S.RES ERJ3GEYJ 101 V (100) B 93.3/94.6
R439 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 81.1/101.5
R440 7030003320 S.RES ERJ3GEYJ 101 V (100) B 82.7/94.5
R441 7030003320 S.RES ERJ3GEYJ 101 V (100) B 82.9/98.6
R442 7030003720 S.RES ERJ3GEYJ 224 V (220K) B 71.9/98.8
R443 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 71.9/95.5
R444 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) B 70.3/92.4
R445 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 72.5/90.4
R446 7030003320 S.RES ERJ3GEYJ 101 V (100) T 72.8/92.1
R447 7310004860 S.TRI EVM-3YSX50 B53 (502) T 67.7/95.1
R448 7030003600 S.RES ERJ3GEYJ 223 V (22K) T 72.8/90.8
R450 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) B 84.7/60
R451 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) B 88.9/66.2
R452 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) B 84.3/66.4
R454 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) B 101.7/82.8
R455 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 72.9/50.1
R456 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 245.5/46.1
R457 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 253.6/33.5
R458 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 252.4/45.8
R459 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 253.7/45.8
R460 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 240.4/44.5
R461 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 241.7/44.1
R462 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 241.3/47.1
R463 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 240/47.5
R464 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 242.3/49.3
R465 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 242.3/50.6
R466 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 242.8/51.9
R467 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 243.2/53.2
R468 7030003320 S.RES ERJ3GEYJ 101 V (100) T 255.7/66.1
R469 7030003320 S.RES ERJ3GEYJ 101 V (100) T 255.5/67.4
R470 7030003320 S.RES ERJ3GEYJ 101 V (100) T 255.2/68.7
R471 7030003320 S.RES ERJ3GEYJ 101 V (100) T 251.2/68.6
R472 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 237.2/52.9
R473 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 238.5/52.9
R474 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 239.8/52.9
R475 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 250.4/38.3
R476 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 249.1/38.3
R477 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) B 112.5/97.2
R478 7510001410 S.THE NTCG20 3FH 222JT B 114.1/96.9
R480 7030003510 S.RES ERJ3GEYJ 392 V (3.9K) T 114.9/83.4
R481 7030007510 S.RES ERJ12YJ270U (27) B 33.7/3.3
R482 7030003320 S.RES ERJ3GEYJ 101 V (100) T 68.1/61.3
R483 7030000440 S.RES MCR10EZHJ 3.3K (332) B 14.1/74.7
R484 7030000440 S.RES MCR10EZHJ 3.3K (332) B 16/74.7
R485 7030003720 S.RES ERJ3GEYJ 224 V (220K) B 22/71.8
R486 7030003680 S.RES ERJ3GEYJ 104 V (100K) B 35.6/56.3
R487 7030003580 S.RES ERJ3GEYJ 153 V (15K) B 193.4/55.9
R488 7510001370 S.THE NTCG20 3NH 153JT B 191.8/55.7
R490 7510001400 S.THE NTCG20 3BH 152JT B 115.1/77.2
R491 7030007510 S.RES ERJ12YJ270U (27) B 15/84
R492 7030003600 S.RES ERJ3GEYJ 223 V (22K) T 84.8/71.9
R493 7030003590 S.RES ERJ3GEYJ 183 V (18K) T 83/72.7
R494 7030003760 S.RES ERJ3GEYJ 474 V (470K) T 253.8/77.6
R495 7030003400 S.RES ERJ3GEYJ 471 V (470) B 95.8/72.7
R496 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 251.9/76.4
R497 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) B 160.3/68.3
R498 7030003580 S.RES ERJ3GEYJ 153 V (15K) B 163.2/66.8
R499 7510001370 S.THE NTCG20 3NH 153JT B 163.5/65.2
R500 7510001360 S.THE NTCG20 3SH 333JT B 119.3/95.5
R502 7510001400 S.THE NTCG20 3BH 152JT B 207.1/78.3
R503 7030003360 S.RES ERJ3GEYJ 221 V (220) B 108.3/96.1
R504 7310004860 S.TRI EVM-3YSX50 B53 (502) T 208.1/85.9
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN-A UNIT]
R505 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) T 30.4/84.7
R506 7030003620 S.RES ERJ3GEYJ 333 V (33K) T 251.9/73.8
R507 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) T 107.2/67.5
R508 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) B 104.8/87.1
R509 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 153.3/85.9
R510 7030006200 S.RES ERJ12YJ2R7U (2.7) B 8.8/83.3
R511 7030003600 S.RES ERJ3GEYJ 223 V (22K) B 139.4/95.4
R512 7030003510 S.RES ERJ3GEYJ 392 V (3.9K) B 141.6/96.2
R513 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 163.5/71.5
R514 7030003400 S.RES ERJ3GEYJ 471 V (470) B 171.3/72
R515 7030004050 S.RES ERJ3GEYJ 1R0 V (1) T 169.4/89.5
R516 7030003500 S.RES ERJ3GEYJ 332 V (3.3K)
[EUR-02] only T 257.7/76
R518 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) T 257.7/73.2
R519 7030003860 S.RES ERJ3GE JPW V T 256.9/79.4
R520 7030003320 S.RES ERJ3GEYJ 101 V (100) T 224.1/55.2
R521 7030003320 S.RES ERJ3GEYJ 101 V (100) T 223.4/52.8
R525 7030003660 S.RES ERJ3GEYJ 683 V (68K) T 178.3/63.6
R526 7030003510 S.RES ERJ3GEYJ 392 V (3.9K) T 179.5/63.6
R527 7030003510 S.RES ERJ3GEYJ 392 V (3.9K) T 176.2/68.4
R528 7030003510 S.RES ERJ3GEYJ 392 V (3.9K) T 178.3/67.6
R529 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) T 177.5/61.7
R530 7030003320 S.RES ERJ3GEYJ 101 V (100) B 168.5/64.4
R531 7030005280 S.RES ERJ3GEYJ 6R8V (6.8) T 221.3/44.1
R532 7030003280 S.RES ERJ3GEYJ 470 V (47) T 218.8/41.5
R533 7030003860 S.RES ERJ3GE JPW V T 218/39.6
R534 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 223/32.7
R535 7030003680 S.RES ERJ3GEYJ 104 V (100K) B 226.6/48.9
R536 7030003680 S.RES ERJ3GEYJ 104 V (100K) B 226.6/51.8
R537 7030003460 S.RES ERJ3GEYJ 152 V (1.5K) B 185.3/98.4
R538 7030005280 S.RES ERJ3GEYJ 6R8V (6.8) B 224/44.9
R539 7030004010 S.RES ERJ3GEYJ 2R2 V (2.2) B 222.2/46.9
R540 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 215.4/40.1
R1004 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) T 129.6/82.1
C1 4030010760 S.CER C1608 CH 1H 331J-T B 193.1/78.8
C2 4030010760 S.CER C1608 CH 1H 331J-T B 193.1/81.8
C3 4030008920 S.CER C1608 JB 1H 473K-T B 185.3/95.8
C4 4030006860 S.CER C1608 JB 1H 102K-T T 185.2/94.3
C5 4030008920 S.CER C1608 JB 1H 473K-T T 185.1/96.6
C6 4030008920 S.CER C1608 JB 1H 473K-T T 182.7/101.6
C7 4030007170 S.CER C1608 CH 1H 221J-T T 179.4/100.3
C8 4030007110 S.CER C1608 CH 1H 680J-T T 181.8/99.5
C9 4030007170 S.CER C1608 CH 1H 221J-T T 179.4/98.7
C10 4030008920 S.CER C1608 JB 1H 473K-T T 178.4/94.9
C11 4030008920 S.CER C1608 JB 1H 473K-T B 198.7/80
C12 4030008920 S.CER C1608 JB 1H 473K-T B 203/80
C13 4030009000 S.CER C2012 JB 1C 224K-T B 208.1/89.1
C14 4030008920 S.CER C1608 JB 1H 473K-T B 209.3/82.1
C15 4030008920 S.CER C1608 JB 1H 473K-T T 208.5/80.3
C16 4030008920 S.CER C1608 JB 1H 473K-T B 211.2/82.1
C17 4030008920 S.CER C1608 JB 1H 473K-T B 219.5/88
C18 4030006860 S.CER C1608 JB 1H 102K-T B 219.6/76.9
C19 4030011600 S.CER C1608 JB 1E 104K-T B 217.2/69
C20 4030011600 S.CER C1608 JB 1E 104K-T B 208.4/75.1
C21 4030006880 S.CER C1608 JB 1H 472K-T B 207.4/68.8
C22 4030011600 S.CER C1608 JB 1E 104K-T B 202.8/75.1
C23 4030006880 S.CER C1608 JB 1H 472K-T B 204.1/75.1
C24 4030011600 S.CER C1608 JB 1E 104K-T B 199/73.4
C25 4030006880 S.CER C1608 JB 1H 472K-T B 196.4/71.6
C26 4030011600 S.CER C1608 JB 1E 104K-T T 169.2/87.5
C27 4030011600 S.CER C1608 JB 1E 104K-T T 162.8/91.8
C28 4510008500 S.ELE EEE1CA101WP T 159.7/85.6
C30 4030011600 S.CER C1608 JB 1E 104K-T T 181.2/69.8
C31 4510009280 S.ELE EEE1EA4R7SR T 169.1/69.7
C32 4030006880 S.CER C1608 JB 1H 472K-T T 172.6/70.5
C33 4030006900 S.CER C1608 JB 1H 103K-T T 181.7/72.9
C34 4030006900 S.CER C1608 JB 1H 103K-T T 167.4/78.4
C38 4030006900 S.CER C1608 JB 1H 103K-T B 166.4/77.1
C39 4030008880 S.CER C1608 JB 1H 223K-T T 164.6/83.7
C40 4030006850 S.CER C1608 JB 1H 471K-T T 177.9/76.9
C41 4030011600 S.CER C1608 JB 1E 104K-T T 173.5/61.5
C43 4030011600 S.CER C1608 JB 1E 104K-T B 154.5/74.9
C44 4030011600 S.CER C1608 JB 1E 104K-T B 86.1/57.4
C45 4030011600 S.CER C1608 JB 1E 104K-T T 163.3/75.7
C46 4030011600 S.CER C1608 JB 1E 104K-T B 225.2/76.5
C47 4030011600 S.CER C1608 JB 1E 104K-T B 189.6/38.7
C48 4030011600 S.CER C1608 JB 1E 104K-T B 183.3/33.3
C50 4030009530 S.CER C1608 CH 1H 030B-T B 216.9/65
C52 4030011600 S.CER C1608 JB 1E 104K-T B 178.9/31.7
C53 4030011600 S.CER C1608 JB 1E 104K-T T 183.4/42.9
C54 4030011600 S.CER C1608 JB 1E 104K-T B 183.3/42.6
C55 4030011600 S.CER C1608 JB 1E 104K-T B 180.5/43.9
C56 4030011600 S.CER C1608 JB 1E 104K-T T 177.7/33
C57 4030011600 S.CER C1608 JB 1E 104K-T B 195.8/59.5
C58 4030009520 S.CER C1608 CH 1H 020B-T B 208.6/60.6
C59 4030011600 S.CER C1608 JB 1E 104K-T B 214.5/50.4
C60 4030006880 S.CER C1608 JB 1H 472K-T B 213.2/50.4
C61 4030011600 S.CER C1608 JB 1E 104K-T T 224.9/53.3
C62 4030011600 S.CER C1608 JB 1E 104K-T T 224.1/50.9
C63 4030011600 S.CER C1608 JB 1E 104K-T T 220/44.1
C64 4030011600 S.CER C1608 JB 1E 104K-T T 218.8/44.1
C65 4550003240 S.TAN TEESVB 1E 335M12R T 209.8/32.8
C66 4030011600 S.CER C1608 JB 1E 104K-T T 225/44.7
C68 4030006880 S.CER C1608 JB 1H 472K-T B 213.3/38.4
C69 4030011600 S.CER C1608 JB 1E 104K-T B 214.8/40.4
C70 4030007140 S.CER C1608 CH 1H 121J-T B 218/41.6
C71 4030007170 S.CER C1608 CH 1H 221J-T B 217.6/46.2

Jun. 2011
10
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN-A UNIT]
C72 4510009280 S.ELE EEE1EA4R7SR T 210.7/49
C73 4030006880 S.CER C1608 JB 1H 472K-T T 208.9/43.5
C74 4510008540 S.ELE EEE1CA100SR T 211.8/54.5
C75 4030011600 S.CER C1608 JB 1E 104K-T B 211.2/48.7
C76 4030006880 S.CER C1608 JB 1H 472K-T B 196.2/54.2
C77 4030011600 S.CER C1608 JB 1E 104K-T B 202.3/53.1
C78 4030011600 S.CER C1608 JB 1E 104K-T B 203.3/45.4
C79 4030011600 S.CER C1608 JB 1E 104K-T B 174.3/37.7
C80 4030007030 S.CER C1608 CH 1H 150J-T B 167.7/37.4
C81 4030011600 S.CER C1608 JB 1E 104K-T T 175.4/37.5
C82 4030011600 S.CER C1608 JB 1E 104K-T T 168.9/36
C83 4030006860 S.CER C1608 JB 1H 102K-T T 163.2/41.4
C84 4030011600 S.CER C1608 JB 1E 104K-T T 163.2/42.6
C85 4030011600 S.CER C1608 JB 1E 104K-T B 138.6/51.5
C86 4030011600 S.CER C1608 JB 1E 104K-T B 118.3/51.5
C87 4030011600 S.CER C1608 JB 1E 104K-T B 138/56.3
C88 4030011600 S.CER C1608 JB 1E 104K-T B 119/54.1
C89 4030011600 S.CER C1608 JB 1E 104K-T B 136.1/74.8
C90 4030011600 S.CER C1608 JB 1E 104K-T B 124.9/75.9
C91 4030011600 S.CER C1608 JB 1E 104K-T B 136.1/80.6
C92 4030011600 S.CER C1608 JB 1E 104K-T B 124.9/79.5
C93 4030011600 S.CER C1608 JB 1E 104K-T B 117.4/64.7
C94 4030011600 S.CER C1608 JB 1E 104K-T B 115.8/68.8
C95 4030006880 S.CER C1608 JB 1H 472K-T B 113.4/60.6
C96 4030011600 S.CER C1608 JB 1E 104K-T B 113/66.9
C97 4030011600 S.CER C1608 JB 1E 104K-T B 111.6/57.6
C98 4030011600 S.CER C1608 JB 1E 104K-T T 109.9/67.5
C99 4030011600 S.CER C1608 JB 1E 104K-T B 104.5/65.6
C100 4030006880 S.CER C1608 JB 1H 472K-T B 101.4/59.7
C101 4030011600 S.CER C1608 JB 1E 104K-T B 101.8/66.1
C102 4030011600 S.CER C1608 JB 1E 104K-T B 99.5/57.5
C103 4030011600 S.CER C1608 JB 1E 104K-T B 115.4/74.3
C104 4030007170 S.CER C1608 CH 1H 221J-T B 92.6/71
C105 4030006850 S.CER C1608 JB 1H 471K-T B 86.9/67.2
C106 4030011600 S.CER C1608 JB 1E 104K-T T 88.3/71.4
C107 4030011600 S.CER C1608 JB 1E 104K-T T 95/67.4
C108 4030006880 S.CER C1608 JB 1H 472K-T B 91.7/74.2
C109 4030011600 S.CER C1608 JB 1E 104K-T B 93.3/76.9
C110 4030006880 S.CER C1608 JB 1H 472K-T B 91.7/76.9
C111 4030007170 S.CER C1608 CH 1H 221J-T T 102.5/74
C112 4030011600 S.CER C1608 JB 1E 104K-T B 104.9/75.1
C113 4030011600 S.CER C1608 JB 1E 104K-T T 98.5/71.9
C114 4030007150 S.CER C1608 CH 1H 151J-T B 97.7/74.6
C115 4030006880 S.CER C1608 JB 1H 472K-T T 93.5/75.7
C116 4030011600 S.CER C1608 JB 1E 104K-T T 95.5/81.4
C117 4030006880 S.CER C1608 JB 1H 472K-T T 93.5/79.6
C118 4030011600 S.CER C1608 JB 1E 104K-T T 90.2/83
C120 4030011600 S.CER C1608 JB 1E 104K-T B 109.7/83
C122 4030011600 S.CER C1608 JB 1E 104K-T T 112.4/70.6
C123 4030007130 S.CER C1608 CH 1H 101J-T T 109.1/75.9
C124 4030006900 S.CER C1608 JB 1H 103K-T T 113.5/77.4
C125 4510008540 S.ELE EEE1CA100SR T 115.4/71.9
C126 4030006900 S.CER C1608 JB 1H 103K-T T 115.6/80.3
C127 4030008900 S.CER C1608 JB 1H 333K-T B 114.6/85.2
C128 4030008900 S.CER C1608 JB 1H 333K-T B 112.1/89.5
C129 4030011600 S.CER C1608 JB 1E 104K-T T 79.8/75.3
C130 4030011600 S.CER C1608 JB 1E 104K-T B 136.5/93.9
C131 4510008540 S.ELE EEE1CA100SR T 156.8/72.5
C132 4030011600 S.CER C1608 JB 1E 104K-T B 160.3/65.4
C133 4030008920 S.CER C1608 JB 1H 473K-T B 116.8/100
C134 4510008530 S.ELE EEE1HA2R2SR T 114.2/101.2
C135 4510008540 S.ELE EEE1CA100SR T 114.2/96.3
C136 4030011600 S.CER C1608 JB 1E 104K-T B 108.3/94.7
C137 4550002890 S.TAN TEESVA 1A 225M8R B 110.7/96
C138 4030011810 S.CER C1608 JB 1A 224K-T B 101.8/89.2
C139 4030007130 S.CER C1608 CH 1H 101J-T T 100.9/77.3
C140 4510009150 S.ELE EEE1EA470WP T 100.9/81.5
C141 4030006860 S.CER C1608 JB 1H 102K-T B 119.5/97.9
C142 4510008540 S.ELE EEE1CA100SR T 136.8/95.2
C143 4030006880 S.CER C1608 JB 1H 472K-T B 45.1/86.4
C144 4510009150 S.ELE EEE1EA470WP T 41.5/100.2
C145 4030008920 S.CER C1608 JB 1H 473K-T B 41.8/88.3
C146 4510008530 S.ELE EEE1HA2R2SR T 39.6/93.6
C147 4030006880 S.CER C1608 JB 1H 472K-T B 39.5/87.1
C148 4030006900 S.CER C1608 JB 1H 103K-T T 44.3/89.9
C149 4030006900 S.CER C1608 JB 1H 103K-T T 48.5/95.7
C150 4030006900 S.CER C1608 JB 1H 103K-T B 45.2/92.8
C151 4510008860 S.ELE EEE1AA100NR T 56.7/95.4
C152 4510009280 S.ELE EEE1EA4R7SR T 62/99.5
C153 4030010210 S.CER C3216 JB 1C 105M-T B 65/101.2
C154 4030009110 S.CER C3216 JB 1C 474K-T B 63.2/93.6
C155 4510008500 S.ELE EEE1CA101WP T 50.7/91.4
C157 4510008530 S.ELE EEE1HA2R2SR T 67.7/85.9
C158 4510008540 S.ELE EEE1CA100SR T 147/78.5
C159 4510008540 S.ELE EEE1CA100SR T 147.8/71.9
C160 4030006880 S.CER C1608 JB 1H 472K-T B 148.6/70.2
C161 4030006860 S.CER C1608 JB 1H 102K-T T 74.1/9.6
C162 4030006860 S.CER C1608 JB 1H 102K-T T 78.9/1.7
C163 4030006860 S.CER C1608 JB 1H 102K-T T 80.2/1.7
C164 4030006860 S.CER C1608 JB 1H 102K-T T 81.5/1.7
C165 4030006860 S.CER C1608 JB 1H 102K-T T 186.7/19.2
C166 4030006860 S.CER C1608 JB 1H 102K-T T 187.6/2
C167 4030006860 S.CER C1608 JB 1H 102K-T T 193.6/2
C168 4030006860 S.CER C1608 JB 1H 102K-T T 45.4/4.9
C169 4030006860 S.CER C1608 JB 1H 102K-T T 186.3/2
C170 4030006860 S.CER C1608 JB 1H 102K-T T 204.9/16.4
C172 4030006860 S.CER C1608 JB 1H 102K-T T 44.1/11.7
C180 4030006860 S.CER C1608 JB 1H 102K-T T 71.1/9.6
C186 4030006860 S.CER C1608 JB 1H 102K-T T 180.9/8.5
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN-A UNIT]
C187 4030006860 S.CER C1608 JB 1H 102K-T B 259.1/71.8
C188 4030006860 S.CER C1608 JB 1H 102K-T T 189/28.7
C189 4030006860 S.CER C1608 JB 1H 102K-T T 188.2/23.3
C191 4030011600 S.CER C1608 JB 1E 104K-T T 227.7/9.4
C193 4030011600 S.CER C1608 JB 1E 104K-T T 247.8/68.9
C194 4030011600 S.CER C1608 JB 1E 104K-T T 80.5/60
C196 4030006900 S.CER C1608 JB 1H 103K-T T 162.1/2.7
C197 4030006900 S.CER C1608 JB 1H 103K-T T 152.6/2.7
C198 4030010210 S.CER C3216 JB 1C 105M-T B 20.8/2.8
C199 4030011600 S.CER C1608 JB 1E 104K-T T 21/5
C200 4510008500 S.ELE EEE1CA101WP T 15.6/10.5
C201 4030006900 S.CER C1608 JB 1H 103K-T T 171.7/2.7
C202 4030006900 S.CER C1608 JB 1H 103K-T B 78.3/79.9
C203 4030006880 S.CER C1608 JB 1H 472K-T T 67.2/77.2
C204 4030009000 S.CER C2012 JB 1C 224K-T T 64.6/80.7
C206 4030011600 S.CER C1608 JB 1E 104K-T B 47.2/71
C207 4510008540 S.ELE EEE1CA100SR T 37/77.6
C208 4030011600 S.CER C1608 JB 1E 104K-T B 46.4/67.4
C209 4030009110 S.CER C3216 JB 1C 474K-T T 42.8/66.2
C210 4510008540 S.ELE EEE1CA100SR T 35.2/61.2
C211 4510008830 S.ELE EEE1CA221P T 20.6/58.6
C212 4550006080 S.TAN TEESVB2 1C 106M8R T 41.1/71.7
C213 4030006850 S.CER C1608 JB 1H 471K-T T 36.8/69.8
C215 4030009000 S.CER C2012 JB 1C 224K-T T 28.8/62.2
C216 4030006880 S.CER C1608 JB 1H 472K-T T 31.5/66.4
C217 4030006880 S.CER C1608 JB 1H 472K-T T 50.9/84.2
C218 4030011600 S.CER C1608 JB 1E 104K-T T 33.4/79.4
C219 4510009150 S.ELE EEE1EA470WP T 42.5/81.6
C220 4030011600 S.CER C1608 JB 1E 104K-T T 33.4/82.9
C221 4030006880 S.CER C1608 JB 1H 472K-T T 35.6/86.7
C222 4030006860 S.CER C1608 JB 1H 102K-T T 15.6/63.8
C223 4510009150 S.ELE EEE1EA470WP T 11/61.7
C224 4510008830 S.ELE EEE1CA221P T 12/69.8
C225 4510009150 S.ELE EEE1EA470WP T 11.8/77.9
C226 4510008510 S.ELE EEE1CA471P T 25.4/72.4
C227 4510004601 ELE 16 ME 1000 HC
C228 4030011600 S.CER C1608 JB 1E 104K-T B 9/89
C229 4030011600 S.CER C1608 JB 1E 104K-T T 31.2/80.5
C230 4030006880 S.CER C1608 JB 1H 472K-T T 30.4/86.3
C231 4030007090 S.CER C1608 CH 1H 470J-T B 170.2/92.4
C232 4030006860 S.CER C1608 JB 1H 102K-T B 157.8/93
C233 4510009280 S.ELE EEE1EA4R7SR T 19.3/65.4
C235 4030006880 S.CER C1608 JB 1H 472K-T T 25.4/98.2
C236 4030006900 S.CER C1608 JB 1H 103K-T T 25.4/99.6
C238 4030006880 S.CER C1608 JB 1H 472K-T T 15/95.7
C239 4030018980 S.CER C1608 JB 1H 104K-T B 5.4/20.5
C240 4030018980 S.CER C1608 JB 1H 104K-T B 6.3/26.6
C241 4510009150 S.ELE EEE1EA470WP T 11.7/27.8
C242 4510004510 ELE 25 ME 470 HC
C243 4030018980 S.CER C1608 JB 1H 104K-T B 27.8/40
C244 4510008540 S.ELE EEE1CA100SR T 17.4/51.1
C245 4030011600 S.CER C1608 JB 1E 104K-T T 9.4/50.9
C246 4030011600 S.CER C1608 JB 1E 104K-T T 9.4/54.2
C247 4510008540 S.ELE EEE1CA100SR T 12.6/54.2
C248 4510008830 S.ELE EEE1CA221P T 62.3/42.1
C249 4030011600 S.CER C1608 JB 1E 104K-T T 57.8/38.2
C250 4030011600 S.CER C1608 JB 1E 104K-T T 54/27.1
C251 4510008830 S.ELE EEE1CA221P T 52.2/33.1
C252 4340000530 S.MYL ECHU1H333JX5 T 67.3/23.3
C253 4510008740 S.ELE EEE1HA330P T 73.2/33.3
C254 4510008740 S.ELE EEE1HA330P T 73.2/42.1
C255 4030018980 S.CER C1608 JB 1H 104K-T B 72.6/41.3
C256 4030018980 S.CER C1608 JB 1H 104K-T B 79.8/41.3
C257 4510008880 S.ELE EEE1VA330WP T 83.1/41.5
C258 4510008880 S.ELE EEE1VA330WP T 90.4/41.5
C259 4510009150 S.ELE EEE1EA470WP T 86.8/22.3
C260 4510008570 S.ELE EEE1CA220SR T 93.3/21.9
C261 4030011600 S.CER C1608 JB 1E 104K-T B 91.9/28.8
C262 4030011600 S.CER C1608 JB 1E 104K-T B 93.7/28.9
C263 4510008540 S.ELE EEE1CA100SR T 92/28.1
C264 4510008540 S.ELE EEE1CA100SR T 92/32.9
C265 4030006900 S.CER C1608 JB 1H 103K-T T 243.6/70.4
C266 4510008540 S.ELE EEE1CA100SR T 243.5/82.1
C267 4510008540 S.ELE EEE1CA100SR T 237.5/82.1
C268 4510008540 S.ELE EEE1CA100SR T 237.4/77.3
C269 4510008540 S.ELE EEE1CA100SR T 243.4/77.3
C270 4030006900 S.CER C1608 JB 1H 103K-T B 246.6/83.2
C271 4030009110 S.CER C3216 JB 1C 474K-T B 67.1/66.4
C272 4030006900 S.CER C1608 JB 1H 103K-T T 58.2/69.6
C273 4510008540 S.ELE EEE1CA100SR T 42.5/54.5
C274 4030009110 S.CER C3216 JB 1C 474K-T B 67.1/71.5
C275 4030006900 S.CER C1608 JB 1H 103K-T B 77.1/63.4
C276 4030006860 S.CER C1608 JB 1H 102K-T B 61.8/61.8
C277 4030006860 S.CER C1608 JB 1H 102K-T T 58.2/58.2
C279 4510008540 S.ELE EEE1CA100SR T 54.4/52.1
C281 4030006850 S.CER C1608 JB 1H 471K-T B 110.9/85.2
C282 4030007170 S.CER C1608 CH 1H 221J-T B 107.2/86.5
C283 4030007170 S.CER C1608 CH 1H 221J-T B 108.4/86.5
C284 4030006900 S.CER C1608 JB 1H 103K-T T 111.6/85.8
C285 4030006880 S.CER C1608 JB 1H 472K-T B 131.5/97.9
C287 4030011600 S.CER C1608 JB 1E 104K-T B 242.6/55.4
C288 4030007020 S.CER C1608 CH 1H 120J-T T 245.6/39.7
C289 4030007020 S.CER C1608 CH 1H 120J-T T 245.6/42.5
C290 4030009000 S.CER C2012 JB 1C 224K-T T 256.6/20
C291 4030006880 S.CER C1608 JB 1H 472K-T B 252.3/35.6
C292 4030006880 S.CER C1608 JB 1H 472K-T T 258/25.1
C293 4030006880 S.CER C1608 JB 1H 472K-T T 257.6/23.8
C294 4030006880 S.CER C1608 JB 1H 472K-T T 260.3/33
C295 4030006880 S.CER C1608 JB 1H 472K-T T 258.9/61.5

Jun. 2011
11
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN-A UNIT]
C296 4030006880 S.CER C1608 JB 1H 472K-T T 259.5/30.4
C297 4030010210 S.CER C3216 JB 1C 105M-T B 260.4/66.4
C298 4030006880 S.CER C1608 JB 1H 472K-T T 258.7/27.8
C299 4030006880 S.CER C1608 JB 1H 472K-T T 258.2/26.5
C300 4030006880 S.CER C1608 JB 1H 472K-T T 259.2/29.1
C301 4030006900 S.CER C1608 JB 1H 103K-T B 251/84.9
C303 4510004510 ELE 25 ME 470 HC
C304 4030018980 S.CER C1608 JB 1H 104K-T B 239.8/10.1
C305 4030011600 S.CER C1608 JB 1E 104K-T T 243.5/16.2
C306 4510009150 S.ELE EEE1EA470WP T 236.5/21.1
C307 4030006900 S.CER C1608 JB 1H 103K-T B 75.8/59.2
C308 4030006880 S.CER C1608 JB 1H 472K-T T 254/4.9
C309 4030007090 S.CER C1608 CH 1H 470J-T T 177.7/96.3
C310 4030009000 S.CER C2012 JB 1C 224K-T T 167/83.9
C311 4030011600 S.CER C1608 JB 1E 104K-T B 120.3/72
C312 4030011600 S.CER C1608 JB 1E 104K-T B 120.3/81.2
C313 4030011600 S.CER C1608 JB 1E 104K-T B 180.5/37.5
C314 4030010210 S.CER C3216 JB 1C 105M-T B 67/60.6
C315 4030010210 S.CER C3216 JB 1C 105M-T B 68.6/62.9
C316 4030010210 S.CER C3216 JB 1C 105M-T B 62.2/58.8
C317 4030006880 S.CER C1608 JB 1H 472K-T T 53.8/70.5
C318 4510008540 S.ELE EEE1CA100SR T 51.3/66.2
C319 4510008540 S.ELE EEE1CA100SR T 223.3/39.6
C320 4030007070 S.CER C1608 CH 1H 330J-T B 225/38.1
C321 4030009920 S.CER C1608 CH 1H 050B-T B 223.6/38.1
C322 4030006880 S.CER C1608 JB 1H 472K-T T 93.5/83.8
C323 4030011600 S.CER C1608 JB 1E 104K-T B 193.8/89.6
C324 4030011600 S.CER C1608 JB 1E 104K-T B 138.5/73.8
C325 4030011600 S.CER C1608 JB 1E 104K-T B 139.7/80.6
C326 4030006900 S.CER C1608 JB 1H 103K-T T 181.7/74.1
C328 4510008530 S.ELE EEE1HA2R2SR T 44.5/93.6
C330 4030006860 S.CER C1608 JB 1H 102K-T B 109.9/87.7
C331 4510008540 S.ELE EEE1CA100SR T 141.6/94.8
C332 4030006900 S.CER C1608 JB 1H 103K-T B 108.8/90
C333 4030008880 S.CER C1608 JB 1H 223K-T T 81.2/75.3
C334 4030008880 S.CER C1608 JB 1H 223K-T T 80.6/72.7
C335 4030011600 S.CER C1608 JB 1E 104K-T B 105.6/69.3
C336 4030011600 S.CER C1608 JB 1E 104K-T B 108.9/73
C337 4030011600 S.CER C1608 JB 1E 104K-T B 108.9/71.4
C338 4030011600 S.CER C1608 JB 1E 104K-T B 177/85.5
C339 4510008540 S.ELE EEE1CA100SR T 105.8/100.8
C340 4030011600 S.CER C1608 JB 1E 104K-T B 101.3/97.8
C341 4030007090 S.CER C1608 CH 1H 470J-T T 95.8/76.5
C342 4030010020 S.CER C1608 JB 1H 122K-T T 97.8/98.3
C343 4510008540 S.ELE EEE1CA100SR T 86.6/100.3
C344 4030007090 S.CER C1608 CH 1H 470J-T B 95.3/97.8
C345 4030011600 S.CER C1608 JB 1E 104K-T B 89.2/85.5
C346 4030007090 S.CER C1608 CH 1H 470J-T B 85.7/81.8
C347 4030011600 S.CER C1608 JB 1E 104K-T B 89.2/83.9
C348 4030007170 S.CER C1608 CH 1H 221J-T B 96.1/93
C349 4030006880 S.CER C1608 JB 1H 472K-T B 75.7/101.7
C350 4030006880 S.CER C1608 JB 1H 472K-T B 71.9/92.4
C351 4030006880 S.CER C1608 JB 1H 472K-T B 72.5/89
C352 4510008530 S.ELE EEE1HA2R2SR T 67.7/100.6
C353 4030009000 S.CER C2012 JB 1C 224K-T B 79.9/85.2
C354 4030011600 S.CER C1608 JB 1E 104K-T B 86.1/61.3
C355 4030011600 S.CER C1608 JB 1E 104K-T B 91.7/66.2
C356 4030011600 S.CER C1608 JB 1E 104K-T B 83.5/64.4
C357 4530000400 S.ARR EZANCE 220M 22P T 87.6/11.9
C358 4530000410 S.ARR EZANCE 471M 470P T 79.3/11.9
C359 4530000410 S.ARR EZANCE 471M 470P T 65.4/12.2
C360 4530000410 S.ARR EZANCE 471M 470P T 57.1/11.4
C361 4530000400 S.ARR EZANCE 220M 22P T 187.2/12.2
C362 4530000400 S.ARR EZANCE 220M 22P T 195.3/13.2
C363 4030007090 S.CER C1608 CH 1H 470J-T T 250.6/38.7
C364 4030007090 S.CER C1608 CH 1H 470J-T T 248.6/38.7
C365 4510004601 ELE 16 ME 1000 HC
C367 4030011600 S.CER C1608 JB 1E 104K-T T 117.5/83.4
C368 4550003240 S.TAN TEESVB 1E 335M12R B 6.5/33.3
C369 4530000410 S.ARR EZANCE 471M 470P T 48.8/12.2
C370 4530000410 S.ARR EZANCE 471M 470P T 215.3/13
C371 4530000410 S.ARR EZANCE 471M 470P T 207/13
C372 4530000400 S.ARR EZANCE 220M 22P T 215.5/24.3
C373 4530000410 S.ARR EZANCE 471M 470P T 206.9/24.3
C374 4530000410 S.ARR EZANCE 471M 470P T 193.6/21.3
C375 4030011600 S.CER C1608 JB 1E 104K-T B 94.1/91.4
C376 4030011600 S.CER C1608 JB 1E 104K-T T 65.3/56.2
C377 4510008540 S.ELE EEE1CA100SR T 60.1/50.4
C378 4030010210 S.CER C3216 JB 1C 105M-T B 21.6/75.9
C379 4030008880 S.CER C1608 JB 1H 223K-T B 55.5/76.2
C380 4030009110 S.CER C3216 JB 1C 474K-T B 243.3/10.2
C381 4030011600 S.CER C1608 JB 1E 104K-T B 71.9/101.6
C382 4030011600 S.CER C1608 JB 1E 104K-T T 256.9/55.6
C383 4030006880 S.CER C1608 JB 1H 472K-T B 106/87.1
C384 4030010210 S.CER C3216 JB 1C 105M-T B 139.8/99.4
C385 4550006480 S.TAN TEESVA 1C 475M8R B 172/68.6
C386 4030011600 S.CER C1608 JB 1E 104K-T B 168.5/66.1
C387 4030007090 S.CER C1608 CH 1H 470J-T B 27/27.9
C388 4030007090 S.CER C1608 CH 1H 470J-T B 23/27.9
C389 4030007090 S.CER C1608 CH 1H 470J-T B 13.9/92.9
C390 4030007090 S.CER C1608 CH 1H 470J-T B 6.4/38
C391 4030007090 S.CER C1608 CH 1H 470J-T B 8.5/36.1
C392 4030007090 S.CER C1608 CH 1H 470J-T B 14.3/38.1
C393 4030007090 S.CER C1608 CH 1H 470J-T B 16.5/35.5
C525 4510008540 S.ELE EEE1CA100SR T 167.4/61.9
C526 4030006880 S.CER C1608 JB 1H 472K-T T 168.3/65
RL1 6330001060 REL APQ 3311 (APQ3311K1)
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN-A UNIT]
CP1 6910009670 S.CHE HK3-S-T T 175.6/79.7
CP2 6910009670 S.CHE HK3-S-T T 216/47.5
CP3 6910009670 S.CHE HK3-S-T T 154.8/61.1
CP4 6910009670 S.CHE HK3-S-T T 145.1/82
CP5 6910009670 S.CHE HK3-S-T T 160.6/64.9
J1 6510007020 CON TMP-J01X-V6
J2 6510007020 CON TMP-J01X-V6
J3 6510018450 CON TMP-S01X-B1
J4 6510007020 CON TMP-J01X-V6
J5 6510019761 S.CON 52610-1571(1590) T 82.2/6
J6 6510019141 S.CON 52610-1071(1090) T 190.1/6.4
J7 6510019761 S.CON 52610-1571(1590) T 57.9/5.2
J8 6510019141 S.CON 52610-1071(1090) T 209.4/6.4
J9 6510003441 CON B08B-EH-S(LF)(SN)
J10 6510007860 CON PI28A-07M
J12 6510019191 S.CON 52365-0871 T 79.7/56.7
J14 6510023650 CON HEC0740-010618
J15 6510011431 CON B3P-VH(LF)(SN)
J16 6510011441 CON B4P-VH(LF)(SN)
J17 6450000150 CON JPJ2545-01-510
J18 6450000150 CON JPJ2545-01-510
J19 6510007100 CON PI28A-06M
J20 6510007170 CON PI28A-03M
J21 6450000140 CON HSJ0807-01-010
J22 6450000140 CON HSJ0807-01-010
J23 6510019651 CON DBLC-J25SAF-23L8E
J28 6450001560 CON PD-72
J29 6450001560 CON PD-72
J30 6450001560 CON PD-72
J31 6450001560 CON PD-72
J32 6510014191 CON A4B-3PA-2DSA(71)
P1 6510014180 CON A3-SP(A)
F1 5210000221 FUS FGMB 125V 3A PBF
F2 6510020300 HOL OF-429P

Jun. 2011
12
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[MIX-A UNIT]
IC1 6910013081 S.IC 5MXE14-7-LF MIX T 31/54.9
IC2 1110006990 S.IC UPC2710TB-E3 T 27.8/62.3
IC3 1110003780 S.IC NJM2902V-TE1-#ZZZB T 26.5/24.3
Q1 1590000430 S.TRA DTC144EUA T106 T 20.4/38.3
Q2 1590004600 S.TRA DMC561030 T 31/21.7
Q3 1590004180 S.TRA DMA26104 T 31/25.8
Q4 1530003451 S.TRA 2SC4835GRL T 94.2/23.5
Q5 1530003451 S.TRA 2SC4835GRL T 94.5/55.3
D1 1750000211 S.DIO 1SV237(TE85R,F) T 60.6/13.2
D2 1750000531 S.DIO 1SV271(TPH3,F) T 51.9/60
D3 1790000450 S.DIO MA862(TX) T 87/20.2
D4 1790000620 S.DIO MA77(TX) T 88.5/57.8
D5 1750000211 S.DIO 1SV237(TE85R,F) T 13.7/61.9
D6 1750000211 S.DIO 1SV237(TE85R,F) T 23.3/48.6
D11 1750000550 S.DIO 1SS355 T 97.9/23.5
D12 1750000550 S.DIO 1SS355 T 98.8/52.4
FI1 2020002280 S.DIE MBF-778A-10-J0076 T 85.9/32
FI2 2020002270 S.DIE MBF-778-10-J0075 T 85.9/47.5
L1 6200002820 S.COI LQW31HN47NJ03L T 60.9/16.9
L2 6200003331 S.COI NLV32T-1R0J T 53.4/13
L3 6200002370 S.COI LQW31HN39NJ03L T 55.8/58
L4 6200003331 S.COI NLV32T-1R0J T 52/56.2
L6 6200003331 S.COI NLV32T-1R0J T 93/18.4
L7 6200003331 S.COI NLV32T-1R0J T 93.8/58.1
L8 6200002320 S.COI LQW31HN8N8J03L T 39.2/58
L10 6180002961 S.COI NLV32T-R18J T 24.4/62.4
L11 6200003331 S.COI NLV32T-1R0J T 17.2/41.4
L12 6200005351 S.COI LL1608-FSL10NJ T 17/54.4
L13 6200005361 S.COI LL1608-FSL12NJ T 20.6/55
L14 6190001161 COI #302HEP-1926A
L15 6190001111 COI #252HEP-3076A
L16 6200012030 S.COI LL1608-FSL22NJ T 15.1/48.4
L17 6200005401 S.COI LL1608-FSL27NJ T 18.8/49
L18 6200003331 S.COI NLV32T-1R0J T 27.6/47
L19 6200003331 S.COI NLV32T-1R0J T 23.3/53.8
L21 6200005341 S.COI LL1608-FSL8N2J T 16.2/59.2
L23 6200005361 S.COI LL1608-FSL12NJ T 62.6/41.4
L120 6200003271 S.COI NLV25T-R56J T 40.1/38.2
L121 6200003271 S.COI NLV25T-R56J T 40.1/34.4
L122 6200005461 S.COI LL1608-FSL82NJ T 37.1/52.3
R1 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) T 57/14.2
R2 7030003320 S.RES ERJ3GEYJ 101 V (100) T 51.4/16.2
R3 7030003400 S.RES ERJ3GEYJ 471 V (470) T 51.4/38.6
R4 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 63.4/14.4
R5 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) T 90/20.4
R6 7030003320 S.RES ERJ3GEYJ 101 V (100) T 95.8/19.1
R7 7030003400 S.RES ERJ3GEYJ 471 V (470) T 99.2/38.2
R8 7030003470 S.RES ERJ3GEYJ 182 V (1.8K) T 57/60
R9 7030003370 S.RES ERJ3GEYJ 271 V (270) T 36.3/63.3
R10 7030003230 S.RES ERJ3GEYJ 180 V (18) T 35.5/61.3
R11 7030003370 S.RES ERJ3GEYJ 271 V (270) T 34.7/63.3
R12 7030003430 S.RES ERJ3GEYJ 821 V (820) T 20.8/63
R13 7030004030 S.RES ERJ3GEYJ 5R6 V (5.6) T 19.4/63
R14 7030003430 S.RES ERJ3GEYJ 821 V (820) T 16.5/63.4
R15 7030003380 S.RES ERJ3GEYJ 331 V (330) T 25.5/49.7
R16 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 28.6/13.8
R17 7410000730 S.ARR EXB-V8V 104JV (100K) T 26.1/11.7
R18 7030003400 S.RES ERJ3GEYJ 471 V (470) T 31.6/29.8
R19 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) T 98/23.6
R20 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) T 99.4/54.6
R21 7030003320 S.RES ERJ3GEYJ 101 V (100) T 24.8/30.4
R22 7030003320 S.RES ERJ3GEYJ 101 V (100) T 28/30.4
R23 7030003400 S.RES ERJ3GEYJ 471 V (470) T 30.2/29.8
R24 7030003360 S.RES ERJ3GEYJ 221 V (220) T 36.9/34.1
C1 4030006860 S.CER C1608 JB 1H 102K-T T 71.5/15.4
C2 4030006980 S.CER C1608 CH 1H 070D-T T 57.2/17.3
C3 4030006860 S.CER C1608 JB 1H 102K-T T 57/15.6
C4 4030006860 S.CER C1608 JB 1H 102K-T T 52.8/16.2
C6 4030009990 S.CER C1608 CH 1H 200J-T T 62.6/49
C7 4030006980 S.CER C1608 CH 1H 070D-T T 59.6/57.6
C8 4030006860 S.CER C1608 JB 1H 102K-T T 51.4/50.6
C9 4030007090 S.CER C1608 CH 1H 470J-T T 51.4/43.4
C10 4030006850 S.CER C1608 JB 1H 471K-T T 51.4/34
C11 4030006860 S.CER C1608 JB 1H 102K-T T 89.6/23.2
C12 4030007090 S.CER C1608 CH 1H 470J-T T 90/21.8
C13 4030007090 S.CER C1608 CH 1H 470J-T T 93.6/20.6
C16 4030006860 S.CER C1608 JB 1H 102K-T T 91.6/55.2
C17 4030007090 S.CER C1608 CH 1H 470J-T T 96.9/56.9
C18 4030006860 S.CER C1608 JB 1H 102K-T T 99.2/42.4
C19 4030006850 S.CER C1608 JB 1H 471K-T T 99.2/34
C20 4030006850 S.CER C1608 JB 1H 471K-T T 45/58.6
C21 4030009510 S.CER C1608 CH 1H 010B-T T 40.9/60.4
C22 4030009510 S.CER C1608 CH 1H 010B-T T 37.5/58.5
C23 4030006960 S.CER C1608 CH 1H 050C-T T 40.2/55
C28 4030006850 S.CER C1608 JB 1H 471K-T T 38.3/62.5
C29 4030006850 S.CER C1608 JB 1H 471K-T T 32.7/61.3
C30 4030006850 S.CER C1608 JB 1H 471K-T T 22.2/63
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[MIX-A UNIT]
C31 4030007090 S.CER C1608 CH 1H 470J-T T 31.4/63.4
C32 4030006860 S.CER C1608 JB 1H 102K-T T 30.1/63.4
C33 4030006850 S.CER C1608 JB 1H 471K-T T 22/42
C34 4030006960 S.CER C1608 CH 1H 050C-T T 17/57.2
C35 4030009560 S.CER C1608 CH 1H R75B-T T 17/55.8
C36 4030006960 S.CER C1608 CH 1H 050C-T T 19.2/56.6
C37 4030009500 S.CER C1608 CH 1H 0R5B-T T 18.6/53
C38 4030009530 S.CER C1608 CH 1H 030B-T T 22.2/57.6
C39 4030011600 S.CER C1608 JB 1E 104K-T T 25.8/17
C40 4030011600 S.CER C1608 JB 1E 104K-T T 26.4/31
C47 4030006960 S.CER C1608 CH 1H 050C-T T 15.1/51.2
C48 4030009910 S.CER C1608 CH 1H 040B-T T 15.1/49.8
C49 4030007010 S.CER C1608 CH 1H 100D-T T 17.4/50.6
C50 4030009530 S.CER C1608 CH 1H 030B-T T 16.8/47
C51 4030006980 S.CER C1608 CH 1H 070D-T T 20.2/49
C52 4030006860 S.CER C1608 JB 1H 102K-T T 31.2/46.2
C53 4030006850 S.CER C1608 JB 1H 471K-T T 24.1/56.7
C54 4030006860 S.CER C1608 JB 1H 102K-T T 24.1/51.6
C55 4030006860 S.CER C1608 JB 1H 102K-T T 12.4/40.8
C56 4030006860 S.CER C1608 JB 1H 102K-T T 96.7/23.6
C57 4030006860 S.CER C1608 JB 1H 102K-T T 97.3/53.9
C60 4030006850 S.CER C1608 JB 1H 471K-T T 21.4/60.8
C61 4030009520 S.CER C1608 CH 1H 020B-T T 45/63
C62 4030007090 S.CER C1608 CH 1H 470J-T
[EUR-02] only T 19.6/25.6
C63 4030007090 S.CER C1608 CH 1H 470J-T
[EUR-02] only T 19.6/27.8
C64 4030007090 S.CER C1608 CH 1H 470J-T
[EUR-02] only T 19.6/29.2
C65 4030007090 S.CER C1608 CH 1H 470J-T
[EUR-02] only T 19.6/34
C66 4030007090 S.CER C1608 CH 1H 470J-T
[EUR-02] only T 19.6/36
C67 4030007090 S.CER C1608 CH 1H 470J-T
[EUR-02] only T 17.8/38.2
C120 4030007120 S.CER C1608 CH 1H 820J-T T 38.2/39.8
C121 4030011280 S.CER C1608 CH 1H 271J-T T 38.2/36.9
C122 4030007120 S.CER C1608 CH 1H 820J-T T 38.2/34.1
J1 6510019141 S.CON 52610-1071(1090) T 5.7/32.4
J2 6510007020 CON TMP-J01X-V6
EP61 6910012350 S.BEA MMZ1608Y 102BT T 13.2/25.4
EP62 6910012350 S.BEA MMZ1608Y 102BT T 13.2/26.7
EP63 6910012350 S.BEA MMZ1608Y 102BT T 13.2/28
EP64 6910012350 S.BEA MMZ1608Y 102BT T 13.2/29.3
EP65 6910012350 S.BEA MMZ1608Y 102BT T 13.2/33.7
EP66 6910012350 S.BEA MMZ1608Y 102BT T 13.2/35
EP67 6910012350 S.BEA MMZ1608Y 102BT T 13.2/36.3
EP68 6910012350 S.BEA MMZ1608Y 102BT T 13.2/37.6

Jun. 2011
13
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[RF-C UNIT]
IC1 1110006990 S.IC UPC2710TB-E3 T 13.2/10
IC2 1110006990 S.IC UPC2710TB-E3 T 13.1/49.6
IC3 1130007700 S.IC BU4094BCF-E2 B 27.1/69.8
IC4 1130007700 S.IC BU4094BCF-E2 T 17.5/79.8
IC5 1160000132 S.IC TD62783AFG(O) T 28.6/69.8
Q1 1560000721 S.FET 2SK2171-4-TD-E B 54.7/74.4
Q2 1560000721 S.FET 2SK2171-4-TD-E T 54.6/74.6
Q3 1590004170 S.TRA DMG20401 T 56/56.9
Q4 1590001001 S.TRA RN2427(TE85L,F) B 38.5/72.4
Q5 1590001330 S.TRA DTA114EUA T106 B 34.5/72.2
Q6 1560000721 S.FET 2SK2171-4-TD-E T 26.2/41
Q7 1560000721 S.FET 2SK2171-4-TD-E T 26.2/47
Q8 1580000540 S.FET 3SK131-T2-LA T 39.2/18.7
Q9 1590004600 S.TRA DMC561030 T 27.5/80.8
Q10 1590004600 S.TRA DMC561030 T 17.5/71.5
Q11 1590001001 S.TRA RN2427(TE85L,F) T 20.4/62.1
Q12 1590001001 S.TRA RN2427(TE85L,F) T 19.3/68.3
Q13 1590004600 S.TRA DMC561030 T 27.5/78.3
Q14 1590001330 S.TRA DTA114EUA T106 B 30.6/76.8
Q15 1560000831 S.FET 2SK2036 (TE85L,F) T 82.7/74.1
Q16 1560000831 S.FET 2SK2036 (TE85L,F) T 84.5/70.4
Q17 1590001001 S.TRA RN2427(TE85L,F) B 27.4/81
D1 1750000550 S.DIO 1SS355 TE-17 B 85.5/34.6
D2 1750000550 S.DIO 1SS355 TE-17 B 73/51.5
D3 1750000211 S.DIO 1SV237(TE85R,F) T 77.8/68.8
D4 1750000531 S.DIO 1SV271(TPH3,F) T 47.1/47.6
D5 1750000531 S.DIO 1SV271(TPH3,F) T 61.2/74.2
D6 1750000531 S.DIO 1SV271(TPH3,F) T 67.6/57.6
D7 1790000620 S.DIO MA77(TX) T 68/44.1
D8 1790000450 S.DIO MA862(TX) T 68/33.2
D9 1790000450 S.DIO MA862(TX) T 68.4/21.9
D10 1790000450 S.DIO MA862(TX) T 68.4/8.8
D11 1790000620 S.DIO MA77(TX) T 46.2/45.7
D12 1790000450 S.DIO MA862(TX) T 46/37
D13 1790000450 S.DIO MA862(TX) T 45/21.6
D14 1790000450 S.DIO MA862(TX) T 46.8/8.8
D15 1790000450 S.DIO MA862(TX) T 46.2/59
D16 1750000211 S.DIO 1SV237(TE85R,F) T 46.6/51.9
D17 1790000450 S.DIO MA862(TX) T 41.9/62.9
D18 1750000431 S.DIO HSB88WSTR-E T 23.6/19.3
FI1 2010001980 XTA 48M15A 48.800 MHz
L1 6140002070 COI LR-233
L2 6200003011 S.COI NLV32T-R27J T 80/43.1
L3 6200003001 S.COI NLV32T-R22J T 78.4/38.1
L4 6200003001 S.COI NLV32T-R22J T 75.4/42.3
L5 6200003520 S.COI ELJFB 102K-F B 74.8/66.3
L6 6200003520 S.COI ELJFB 102K-F T 74.2/74.5
L7 6200001711 S.COI NLV32T-220J T 70.1/73.4
L8 6200001711 S.COI NLV32T-220J T 65.7/73.4
L10 6200001851 S.COI NLV32T-5R6J T 69.4/65.9
L11 6200003111 S.COI NLV32T-6R8J T 65/65.8
L12 6200003520 S.COI ELJFB 102K-F T 60.5/65.6
L13 6200005501 S.COI NLV32T-471J T 67.2/53.7
L14 6200005501 S.COI NLV32T-471J T 67.3/48.3
L15 6200003111 S.COI NLV32T-6R8J T 64/59.4
L16 6200002961 S.COI NLV32T-4R7J T 62.9/48.1
L17 6200005501 S.COI NLV32T-471J T 66/41.5
L18 6200002991 S.COI NLV32T-2R2J T 61/42.3
L19 6200002991 S.COI NLV32T-2R2J T 56.8/45
L20 6200002961 S.COI NLV32T-4R7J T 52.5/42.8
L21 6200003101 S.COI NLV32T-3R9J T 49.4/42.8
L22 6200003261 S.COI NLV32T-101J T 64.4/36.5
L23 6200003101 S.COI NLV32T-3R9J T 59.2/36.6
L24 6200001851 S.COI NLV32T-5R6J T 51.6/36.6
L25 6200003261 S.COI NLV32T-101J T 66.6/29.9
L26 6200003051 S.COI NLV32T-R82J T 61.4/30.6
L27 6200003061 S.COI NLV32T-1R2J T 57.2/33.2
L28 6200003081 S.COI NLV32T-1R8J T 52.8/31
L29 6200003321 S.COI NLV32T-3R3J T 49.6/30.8
L30 6200003261 S.COI NLV32T-101J T 67.1/25.2
L31 6200003061 S.COI NLV32T-1R2J T 62/24.8
L32 6200003331 S.COI NLV32T-1R0J T 57/23.4
L33 6200003051 S.COI NLV32T-R82J T 53.2/25
L34 6200003061 S.COI NLV32T-1R2J T 48.1/26
L35 6200003261 S.COI NLV32T-101J T 67.2/18.2
L36 6200003031 S.COI NLV32T-R47J T 61.4/20
L37 6200002981 S.COI NLV32T-R56J T 57.6/19
L38 6200003041 S.COI NLV32T-R68J T 53.9/20
L39 6200003051 S.COI NLV32T-R82J T 48.1/17.8
L40 6200003261 S.COI NLV32T-101J T 66.9/12.2
L41 6200003251 S.COI NLV32T-R39J T 62/12.6
L42 6200003251 S.COI NLV32T-R39J T 56.8/11.4
L43 6200003031 S.COI NLV32T-R47J T 53.2/12.8
L44 6200002981 S.COI NLV32T-R56J T 46.6/13.8
L45 6200003261 S.COI NLV32T-101J T 67.2/5.4
L46 6200003011 S.COI NLV32T-R27J T 62/6.4
L47 6200003011 S.COI NLV32T-R27J T 56.8/8
L48 6200003021 S.COI NLV32T-R33J T 53.2/6.3
L49 6200003251 S.COI NLV32T-R39J T 46.7/5.4
L50 6200003520 S.COI ELJFB 102K-F B 52.1/58
L51 6200003520 S.COI ELJFB 102K-F B 49.1/49.4
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[RF-C UNIT]
L52 6200005501 S.COI NLV32T-471J B 50.2/46
L53 6200005501 S.COI NLV32T-471J T 53.6/53.3
L54 6140000640 COI LR-86
L55 6140001540 COI LR-169
L56 6200005501 S.COI NLV32T-471J B 40.6/62.2
L57 6200003520 S.COI ELJFB 102K-F B 59.6/75.3
L58 6200003001 S.COI NLV32T-R22J T 35.6/54.3
L59 6200003001 S.COI NLV32T-R22J T 38.5/49.9
L60 6140001500 COI LR-171
L61 6200001831 S.COI NLV32T-100J B 21.7/51.4
L62 6150005520 COI LS-562 7K7
L63 6150005510 COI LS-563 7K7
L64 6200003331 S.COI NLV32T-1R0J T 16.6/9.5
L65 6150005500 COI LS-561 7K7
L66 6150000991 COI LS-424
L67 6200003381 S.COI #617PT-1837=P3 T 32.1/19.2
L68 6200003381 S.COI #617PT-1837=P3 T 15.1/19.2
L69 6200001831 S.COI NLV32T-100J B 13.7/10.6
L70 6200003011 S.COI NLV32T-R27J T 23.2/7
L71 6200003011 S.COI NLV32T-R27J T 20/11.2
L72 6200003001 S.COI NLV32T-R22J T 15.7/13.4
L73 6200003331 S.COI NLV32T-1R0J T 16.4/50.7
L74 6200001831 S.COI NLV32T-100J B 14/49.7
L75 6200003431 S.COI NLV32T-R10J T 21.8/55.8
L76 6200001471 S.COI NLV32T-R12J T 25.3/55
L77 6200003950 S.COI HF50ACC 322513-T B 19.5/62.6
L78 6200003950 S.COI HF50ACC 322513-T B 5.7/68.1
L79 6200003950 S.COI HF50ACC 322513-T T 17.1/63.6
L80 6200003321 S.COI NLV32T-3R3J B 49.7/75.6
L82 6180002961 S.COI NLV32T-R18J T 27.6/51.1
L83 6200003001 S.COI NLV32T-R22J T 15.8/55.8
L84 6200003031 S.COI NLV32T-R47J B 10.5/20.7
L85 6200003041 S.COI NLV32T-R68J B 42.8/76
L86 6200003011 S.COI NLV32T-R27J B 18.2/36.3
L87 6200001471 S.COI NLV32T-R12J B 26.5/43.3
R1 7540000130 ABS 2P-50A-301
R2 7030003600 S.RES ERJ3GEYJ 223 V (22K) T 81.8/27.2
R3 7540000130 ABS 2P-50A-301
R4 7030003600 S.RES ERJ3GEYJ 223 V (22K) T 83.8/49.5
R5 7030007650 S.RES ERJ8ENF 68R0V (68) T 76.8/33.2
R7 7030000330 S.RES MCR10EZHJ 390 (391) B 74.7/56
R8 7030000230 S.RES MCR10EZHJ 56 (560) B 78.6/55.3
R9 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) B 70.2/59.4
R10 7030007650 S.RES ERJ8ENF 68R0V (68) B 72.8/47.2
R12 7030007540 S.RES ERJ8ENF 3900V (390) B 72.8/70.5
R14 7030007530 S.RES ERJ8ENF 1800V (180) B 77.8/79.2
R18 7030000260 S.RES MCR10EZHJ 100 (101) T 74.7/68.8
R19 7030000240 S.RES MCR10EZHJ 68 (680) T 73.6/66
R20 7030000260 S.RES MCR10EZHJ 100 (101) T 72.9/68.8
R21 7030007540 S.RES ERJ8ENF 3900V (390) B 67.8/72.3
R22 7030007540 S.RES ERJ8ENF 3900V (390) B 64.1/73.8
R24 7030007540 S.RES ERJ8ENF 3900V (390) B 61.2/43.3
R26 7030007540 S.RES ERJ8ENF 3900V (390) B 47.9/41.7
R28 7030007530 S.RES ERJ8ENF 1800V (180) B 69/35.7
R30 7030007540 S.RES ERJ8ENF 3900V (390) B 60.4/31.5
R32 7030007540 S.RES ERJ8ENF 3900V (390) B 48.5/31.5
R34 7030007540 S.RES ERJ8ENF 3900V (390) B 68/24.5
R36 7030007540 S.RES ERJ8ENF 3900V (390) B 46.6/24.5
R38 7030007540 S.RES ERJ8ENF 3900V (390) B 62.6/19.5
R40 7030007540 S.RES ERJ8ENF 3900V (390) B 52.8/19.5
R42 7030007540 S.RES ERJ8ENF 3900V (390) B 62.4/12.5
R44 7030007540 S.RES ERJ8ENF 3900V (390) B 51.6/12.5
R46 7030007550 S.RES ERJ8ENF 4700V (470) B 61.5/5.1
R48 7030007550 S.RES ERJ8ENF 4700V (470) B 51.7/5.3
R50 7030007550 S.RES ERJ8ENF 4700V (470) B 54.5/44.2
R52 7030007550 S.RES ERJ8ENF 4700V (470) B 56.3/59.3
R54 7030007850 S.RES ERJ8ENF 1001V (1K) B 58.3/79.4
R56 7030007550 S.RES ERJ8ENF 4700V (470) B 64.6/66.6
R58 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 43.9/54.1
R59 7030003310 S.RES ERJ3GEYJ 820 V (82) B 52.7/51.6
R60 7030003280 S.RES ERJ3GEYJ 470 V (47) T 50.1/50.9
R61 7030003280 S.RES ERJ3GEYJ 470 V (47) T 54.5/50.9
R62 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) T 55.8/59.4
R63 7310004780 S.TRI EVM-3YSX50 B13 (102) T 56/62
R64 7030003320 S.RES ERJ3GEYJ 101 V (100) T 50/52.5
R65 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) T 57.8/52.7
R66 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 57.8/49.7
R67 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 51.6/55.5
R68 7030003570 S.RES ERJ3GEYJ 123 V (12K) T 33/61.7
R69 7030000180 S.RES MCR10EZHJ 22 (220) T 48.5/65.4
R71 7030007680 S.RES ERJ8ENF 47R0V (47) B 41.7/71.3
R73 7030006270 S.RES ERJ12YJ221U (220) B 35.9/66.4
R74 7030000340 S.RES MCR10EZHJ 470 (471) B 29/39.1
R75 7030000340 S.RES MCR10EZHJ 470 (471) B 31.3/49.2
R77 7310004860 S.TRI EVM-3YSX50 B53 (502) T 32/51.2
R78 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 22.8/47.1
R79 7030003400 S.RES ERJ3GEYJ 471 V (470) B 25.8/45.4
R80 7030003280 S.RES ERJ3GEYJ 470 V (47) T 18.6/47.1
R81 7030004850 S.RES ERJ3GEYF 913 V (91K) B 40.5/30.7
R82 7030003590 S.RES ERJ3GEYJ 183 V (18K) B 34.7/35.6
R83 7030003240 S.RES ERJ3GEYJ 220 V (22) T 39.3/21.3
R84 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 36.6/20.6
R85 7030003330 S.RES ERJ3GEYJ 121 V (120) T 38.8/15.4
R86 7030003460 S.RES ERJ3GEYJ 152 V (1.5K) T 36.4/13.2
R87 7030003320 S.RES ERJ3GEYJ 101 V (100) B 34.7/13
R88 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) B 10.2/17.4
R89 7030003370 S.RES ERJ3GEYJ 271 V (270) T 18/5

Jun. 2011
14
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[RF-C UNIT]
R90 7030003230 S.RES ERJ3GEYJ 180 V (18) T 14.4/6.2
R91 7030003370 S.RES ERJ3GEYJ 271 V (270) T 15.1/4.9
R92 7030003370 S.RES ERJ3GEYJ 271 V (270) T 27/12.6
R93 7030003230 S.RES ERJ3GEYJ 180 V (18) T 29.2/13.4
R94 7030003370 S.RES ERJ3GEYJ 271 V (270) T 27/14.2
R95 7030003370 S.RES ERJ3GEYJ 271 V (270) T 11.6/42.3
R96 7030003230 S.RES ERJ3GEYJ 180 V (18) T 13/42.3
R97 7030003370 S.RES ERJ3GEYJ 271 V (270) T 12.2/44.3
R101 7410000750 S.ARR EXB-V4V 104JV (100K) T 73.2/82.4
R102 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 70.4/30.4
R103 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 74.2/25.6
R104 7030003360 S.RES ERJ3GEYJ 221 V (220) T 18.6/51.4
R105 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 69.2/42.2
R106 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 67.2/34.6
R107 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 66.2/75.6
R108 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 75.8/80.2
R110 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 35.5/74.8
R111 7030003340 S.RES ERJ3GEYJ 151 V (150) B 19.6/40.7
R112 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 70.7/18.4
R113 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 75.6/13.7
R114 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 67.4/4.3
R115 7510001360 S.THE NTCG20 3SH 333JT B 39.3/18
R116 7030003620 S.RES ERJ3GEYJ 333 V (33K) B 39.2/16.4
R203 7030003860 S.RES ERJ3GE JPW V T 31.5/55.1
R204 7030003860 S.RES ERJ3GE JPW V B 21.7/28.7
C1 4030011600 S.CER C1608 JB 1E 104K-T T 83.1/25.6
C2 4030011600 S.CER C1608 JB 1E 104K-T T 85.2/49.5
C3 4030006860 S.CER C1608 JB 1H 102K-T B 87/34.6
C4 4030007100 S.CER C1608 CH 1H 560J-T T 80.2/46.8
C5 4030007060 S.CER C1608 CH 1H 270J-T T 77.7/43.1
C6 4030007130 S.CER C1608 CH 1H 101J-T T 80.2/40.2
C7 4030007090 S.CER C1608 CH 1H 470J-T T 78.5/35.9
C8 4030007120 S.CER C1608 CH 1H 820J-T T 74.7/39.3
C10 4030006860 S.CER C1608 JB 1H 102K-T B 69.2/51.4
C11 4030011600 S.CER C1608 JB 1E 104K-T B 70.2/60.9
C12 4030008920 S.CER C1608 JB 1H 473K-T B 70.2/58
C13 4510008540 S.ELE EEE1CA100SR T 78.5/78.7
C14 4030011600 S.CER C1608 JB 1E 104K-T T 75.3/79.2
C15 4030009630 S.CER C1608 JB 1H 822K-T T 68.7/76.4
C16 4030006860 S.CER C1608 JB 1H 102K-T T 66.3/75.6
C17 4030009880 S.CER C1608 JB 1H 682K-T T 64.1/76.4
C21 4030011600 S.CER C1608 JB 1E 104K-T T 71.3/68.9
C22 4030008470 S.CER C1608 JB 1H 272K-T T 67.1/68.8
C23 4030010760 S.CER C1608 CH 1H 331J-T T 65/68
C24 4030006870 S.CER C1608 JB 1H 222K-T T 65/69.4
C25 4030011600 S.CER C1608 JB 1E 104K-T T 63.6/63.6
C26 4030011600 S.CER C1608 JB 1E 104K-T T 61.2/70.4
C27 4030008470 S.CER C1608 JB 1H 272K-T T 64.7/55.7
C28 4030008470 S.CER C1608 JB 1H 272K-T T 63.2/55.7
C29 4030009980 S.CER C1608 JB 1H 152K-T T 64.7/52.8
C30 4030009880 S.CER C1608 JB 1H 682K-T T 63.2/51.7
C31 4030009970 S.CER C1608 JB 1H 182K-T T 65.1/48.3
C32 4030011600 S.CER C1608 JB 1E 104K-T T 67.4/51
C33 4030008920 S.CER C1608 JB 1H 473K-T T 63.3/40.3
C34 4030010020 S.CER C1608 JB 1H 122K-T T 58.8/41.7
C35 4030007150 S.CER C1608 CH 1H 151J-T T 57.4/41.7
C36 4030010020 S.CER C1608 JB 1H 122K-T T 56/41.7
C37 4030008920 S.CER C1608 JB 1H 473K-T T 52.8/45.7
C38 4030008470 S.CER C1608 JB 1H 272K-T T 54.7/41.7
C39 4030009980 S.CER C1608 JB 1H 152K-T T 49.6/45.7
C40 4030008920 S.CER C1608 JB 1H 473K-T T 47.2/41.8
C41 4030008920 S.CER C1608 JB 1H 473K-T T 62/38.5
C42 4030009970 S.CER C1608 JB 1H 182K-T T 56.2/37
C43 4030011280 S.CER C1608 CH 1H 271J-T T 54.6/37
C44 4030006860 S.CER C1608 JB 1H 102K-T T 48.6/38.1
C45 4030008920 S.CER C1608 JB 1H 473K-T T 63.8/28.6
C46 4030006850 S.CER C1608 JB 1H 471K-T T 59.1/30.1
C47 4030007110 S.CER C1608 CH 1H 680J-T T 57.8/30.1
C48 4030011280 S.CER C1608 CH 1H 271J-T T 56.4/30.1
C49 4030010020 S.CER C1608 JB 1H 122K-T T 53.4/33.8
C50 4030008770 S.CER C1608 JB 1H 562K-T T 55/29.9
C51 4030010040 S.CER C1608 JB 1H 561K-T T 50.3/33.8
C52 4030008920 S.CER C1608 JB 1H 473K-T T 47.4/30.2
C53 4030008920 S.CER C1608 JB 1H 473K-T T 66.2/27.4
C54 4030010760 S.CER C1608 CH 1H 331J-T T 58.4/26.6
C55 4030007100 S.CER C1608 CH 1H 560J-T T 59.8/25.2
C56 4030010760 S.CER C1608 CH 1H 331J-T T 57/26.6
C57 4030006860 S.CER C1608 JB 1H 102K-T T 51/23.8
C58 4030006870 S.CER C1608 JB 1H 222K-T T 55.6/26.6
C59 4030010760 S.CER C1608 CH 1H 331J-T T 48.4/23
C60 4030008920 S.CER C1608 JB 1H 473K-T T 51/26.8
C61 4030008920 S.CER C1608 JB 1H 473K-T T 66.6/15.8
C62 4030011280 S.CER C1608 CH 1H 271J-T T 64.4/16.6
C63 4030007100 S.CER C1608 CH 1H 560J-T T 62/17.8
C64 4030007150 S.CER C1608 CH 1H 151J-T T 59.8/16.6
C65 4030006850 S.CER C1608 JB 1H 471K-T T 54.8/17.8
C66 4030006860 S.CER C1608 JB 1H 102K-T T 52.6/16.8
C67 4030007170 S.CER C1608 CH 1H 221J-T T 48.5/20.1
C68 4030008920 S.CER C1608 JB 1H 473K-T T 51/16.8
C69 4030008920 S.CER C1608 JB 1H 473K-T T 66.6/14.4
C70 4030007170 S.CER C1608 CH 1H 221J-T T 58.4/14.6
C71 4030007070 S.CER C1608 CH 1H 330J-T T 59.8/13.2
C72 4030007140 S.CER C1608 CH 1H 121J-T T 57/14.6
C73 4030011280 S.CER C1608 CH 1H 271J-T T 51/13.2
C74 4030010020 S.CER C1608 JB 1H 122K-T T 55.6/14.6
C75 4030007150 S.CER C1608 CH 1H 151J-T T 47.5/11.4
C76 4030008920 S.CER C1608 JB 1H 473K-T T 49.6/14.6
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[RF-C UNIT]
C77 4030008920 S.CER C1608 JB 1H 473K-T T 64.4/4.6
C79 4030007140 S.CER C1608 CH 1H 121J-T T 59.8/4.6
C80 4030007080 S.CER C1608 CH 1H 390J-T T 58.4/5.2
C81 4030007110 S.CER C1608 CH 1H 680J-T T 57/5
C82 4030007170 S.CER C1608 CH 1H 221J-T T 55.6/5
C83 4030009490 S.CER C1608 JB 1H 821K-T T 51/4.4
C84 4030007120 S.CER C1608 CH 1H 820J-T T 51/7.8
C85 4030008920 S.CER C1608 JB 1H 473K-T T 49.7/4.4
C86 4030011600 S.CER C1608 JB 1E 104K-T T 43.9/51.2
C87 4030011600 S.CER C1608 JB 1E 104K-T T 46.1/56.3
C88 4030008920 S.CER C1608 JB 1H 473K-T T 52.3/49.9
C89 4030008920 S.CER C1608 JB 1H 473K-T T 46.7/54.3
C90 4030008920 S.CER C1608 JB 1H 473K-T T 56.5/49.7
C91 4030009000 S.CER C2012 JB 1C 224K-T T 38.3/63.9
C92 4030008920 S.CER C1608 JB 1H 473K-T T 50.1/65.8
C94 4030008920 S.CER C1608 JB 1H 473K-T B 41.7/67.4
C95 4030008920 S.CER C1608 JB 1H 473K-T B 59.1/64.1
C96 4030008920 S.CER C1608 JB 1H 473K-T B 36.9/61.6
C97 4030011600 S.CER C1608 JB 1E 104K-T T 35/56.5
C98 4030007150 S.CER C1608 CH 1H 151J-T T 35.1/52.1
C99 4030007090 S.CER C1608 CH 1H 470J-T T 37.9/52.1
C100 4030007110 S.CER C1608 CH 1H 680J-T T 40.1/52.9
C102 4030011600 S.CER C1608 JB 1E 104K-T B 28.9/37.5
C103 4030011600 S.CER C1608 JB 1E 104K-T B 31.1/50.9
C104 4030006860 S.CER C1608 JB 1H 102K-T B 22.3/49
C105 4030007020 S.CER C1608 CH 1H 120J-T T 21.5/47.1
C106 4030008920 S.CER C1608 JB 1H 473K-T T 16.6/46.3
C107 4030006960 S.CER C1608 CH 1H 050C-T T 8.5/29.3
C109 4030009530 S.CER C1608 CH 1H 030B-T B 25.9/29.6
C110 4030008920 S.CER C1608 JB 1H 473K-T B 36.1/35.6
C111 4030011600 S.CER C1608 JB 1E 104K-T T 36.6/17.8
C112 4030008920 S.CER C1608 JB 1H 473K-T T 40.2/15.4
C113 4030007040 S.CER C1608 CH 1H 180J-T T 36.4/14.6
C114 4030008920 S.CER C1608 JB 1H 473K-T T 33.6/13.2
C115 4030008920 S.CER C1608 JB 1H 473K-T B 13.7/17.4
C116 4030006860 S.CER C1608 JB 1H 102K-T T 12/6.8
C117 4030007130 S.CER C1608 CH 1H 101J-T T 23.2/13.8
C118 4030008920 S.CER C1608 JB 1H 473K-T B 17.4/9.9
C119 4030006860 S.CER C1608 JB 1H 102K-T B 16/9.9
C120 4030007040 S.CER C1608 CH 1H 180J-T T 22.4/11.6
C121 4030007140 S.CER C1608 CH 1H 121J-T T 24/11.6
C122 4030007090 S.CER C1608 CH 1H 470J-T T 14.2/52.7
C123 4030007170 S.CER C1608 CH 1H 221J-T T 17.9/53.6
C124 4030007140 S.CER C1608 CH 1H 121J-T T 13/55.5
C125 4030006860 S.CER C1608 JB 1H 102K-T T 11.8/46.3
C126 4030009520 S.CER C1608 CH 1H 020B-T T 32.8/28.4
C127 4030008920 S.CER C1608 JB 1H 473K-T T 14.6/46.3
C128 4030006860 S.CER C1608 JB 1H 102K-T T 13.2/46.3
C129 4030007070 S.CER C1608 CH 1H 330J-T T 18.6/55.5
C130 4030009650 S.CER C1608 CH 1H 240J-T T 21/53.6
C131 4030007060 S.CER C1608 CH 1H 270J-T T 28.3/56.5
C132 4030007010 S.CER C1608 CH 1H 100D-T T 27.5/54.3
C134 4530000410 S.ARR EZANCE 471M 470P T 11.8/63.7
C135 4030008920 S.CER C1608 JB 1H 473K-T B 4.9/71.9
C136 4030008920 S.CER C1608 JB 1H 473K-T B 3.9/64.8
C137 4530000400 S.ARR EZANCE 220M 22P T 11.8/71.9
C138 4030011600 S.CER C1608 JB 1E 104K-T B 32.1/66.7
C139 4030011600 S.CER C1608 JB 1E 104K-T B 16.5/84
C140 4030006860 S.CER C1608 JB 1H 102K-T B 81.6/32.8
C141 4030006860 S.CER C1608 JB 1H 102K-T B 68.1/49
C142 4030007010 S.CER C1608 CH 1H 100D-T T 23.8/9.2
C143 4030007110 S.CER C1608 CH 1H 680J-T T 26.2/10
C144 4030006880 S.CER C1608 JB 1H 472K-T T 27.8/10
C145 4030007150 S.CER C1608 CH 1H 151J-T B 13.2/19.6
C146 4030007150 S.CER C1608 CH 1H 151J-T B 7.8/19.6
C147 4030010210 S.CER C3216 JB 1C 105M-T T 25.8/62.2
C148 4030008920 S.CER C1608 JB 1H 473K-T B 3.4/67.4
RL1 6330000180 REL MZ-12HG
RL2 6330000180 REL MZ-12HG
CP1 6910009670 S.CHE HK3-S-T T 52.7/59.1
J1 6450000150 CON JPJ2545-01-510
J2 6510007020 CON TMP-J01X-V6
J3 6510007020 CON TMP-J01X-V6
J4 6510019761 S.CON 52610-1571(1590) T 5.4/66.7

Jun. 2011
15
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[RF-D UNIT]
IC1 1110002700 S.IC NJM2904M-TE1-#FMZB T 21.6/93.9
IC2 1110003780 S.IC NJM2902V-TE1-#ZZZB T 22.9/78.5
IC3 1110006420 S.IC UPC2708TB-E3-A T 44.4/72.8
IC4 1190002053 S.IC SPM5001A T 22.5/20.7
IC6 1110006870 S.IC UPC2709TB-E3 T 12.7/55.4
IC7 1110002700 S.IC NJM2904M-TE1-#FMZB T 11.9/82.2
Q1 1580000800 S.FET 3SK324UG-TL-E T 94.8/21.4
Q2 1580000800 S.FET 3SK324UG-TL-E T 91.6/43
Q3 1580000800 S.FET 3SK324UG-TL-E T 91.4/63.5
Q4 1580000800 S.FET 3SK324UG-TL-E T 97.2/85.3
Q5 1590004500 S.TRA DMC561040 T 73.8/88.3
Q6 1590004600 S.TRA DMC561030 T 63.1/94.7
Q7 1590004180 S.TRA DMA26104 T 62.9/90.3
Q8 1590004600 S.TRA DMC561030 T 59.7/94.7
Q9 1590004180 S.TRA DMA26104 T 59.3/90.3
Q10 1590000430 S.TRA DTC144EUA T106 T 29.4/87.6
Q11 1560000811 S.FET 2SK1069-4-TL-E T 30.3/83
Q12 1560000811 S.FET 2SK1069-4-TL-E T 30.5/79.4
D1 1750000550 S.DIO 1SS355 TE-17 T 129.8/79.4
D2 1750000550 S.DIO 1SS355 TE-17 T 65.9/75.2
D3 1720000601 S.VAR HN2V02H-B (TE12R,F) T 104.7/22.5
D4 1720000601 S.VAR HN2V02H-B (TE12R,F) T 85.5/19.1
D5 1750002070 S.ZEN DZ2J150M T 90.5/10.3
D6 1750000531 S.DIO 1SV271(TPH3,F) T 112.6/25.7
D7 1750000531 S.DIO 1SV271(TPH3,F) T 70.8/25.8
D8 1750000531 S.DIO 1SV271(TPH3,F) T 112.4/38.4
D9 1720000681 S.VAR 1SV262(TPH2,F) T 102.6/38.3
D10 1720000681 S.VAR 1SV262(TPH2,F) T 105.5/45.4
D11 1720000681 S.VAR 1SV262(TPH2,F) T 96.6/41.6
D12 1720000681 S.VAR 1SV262(TPH2,F) T 84.3/41.1
D13 1750000531 S.DIO 1SV271(TPH3,F) T 72.5/41.4
D14 1790000620 S.DIO MA77(TX) T 112.8/60.1
D15 1720000681 S.VAR 1SV262(TPH2,F) T 95.2/60.6
D16 1720000681 S.VAR 1SV262(TPH2,F) T 85/60.8
D17 1790000620 S.DIO MA77(TX) T 70.1/60.5
D19 1720000261 S.VAR 1SV214(TPH2,F) T 109.8/83.4
D20 1720000261 S.VAR 1SV214(TPH2,F) T 102.7/83.5
D21 1720000261 S.VAR 1SV214(TPH2,F) T 102.7/80.2
D22 1720000261 S.VAR 1SV214(TPH2,F) T 88.4/84.6
D23 1720000261 S.VAR 1SV214(TPH2,F) T 88.4/81.2
D24 1750000111 S.DIO 1SS272(TE85R,F) T 22.9/87.7
D25 1750000531 S.DIO 1SV271(TPH3,F) T 40.8/59.7
D26 1750000531 S.DIO 1SV271(TPH3,F) T 41.6/39.9
D27 1750000531 S.DIO 1SV271(TPH3,F) T 28/59.7
D28 1750000531 S.DIO 1SV271(TPH3,F) T 30.2/37.1
D29 1720000261 S.VAR 1SV214(TPH2,F) T 24.4/56.5
D30 1720000261 S.VAR 1SV214(TPH2,F) T 22.6/57.3
D31 1720000261 S.VAR 1SV214(TPH2,F) T 25/49.3
D32 1720000261 S.VAR 1SV214(TPH2,F) T 23.2/47.8
D33 1720000681 S.VAR 1SV262(TPH2,F) T 93.5/58.9
D34 1720000681 S.VAR 1SV262(TPH2,F) T 83.4/58.3
L1 6200003261 S.COI NLV32T-101J T 112.4/21.1
L2 6200002981 S.COI NLV32T-R56J T 109.2/21.1
L3 6200003021 S.COI NLV32T-R33J T 104.7/17.8
L4 6200001471 S.COI NLV32T-R12J T 99.9/20.3
L5 6200001471 S.COI NLV32T-R12J T 100/16.5
L6 6200004900 S.COI ELJFC 5R6K-F T 91.7/23.4
L7 6200001471 S.COI NLV32T-R12J T 84.4/23.5
L8 6200003421 S.COI NLV32T-R15J T 81/19.6
L9 6200003011 S.COI NLV32T-R27J T 79.9/23.5
L10 6200003261 S.COI NLV32T-101J T 72.4/22.4
L11 6200001831 S.COI NLV32T-100J T 111.1/43.9
L12 6200003011 S.COI NLV32T-R27J T 108/45.5
L13 6200001471 S.COI NLV32T-R12J T 105.1/40.9
L14 6200003431 S.COI NLV32T-R10J T 102.1/44.7
L15 6200002390 S.COI LQW31HN64NJ03L T 98.6/44.2
L16 6200002100 S.COI LQW31HN17NJ03L T 98.6/39.3
L17 6200001620 S.COI ELJFC 1R0K-F T 88.5/45.1
L18 6200002370 S.COI LQW31HN39NJ03L T 82.3/43
L19 6200002820 S.COI LQW31HN47NJ03L T 82.3/38.2
L20 6200003431 S.COI NLV32T-R10J T 78.8/41
L21 6200001831 S.COI NLV32T-100J T 72.9/43.8
L23 6200003331 S.COI NLV32T-1R0J T 114.7/64.1
L24 6200002350 S.COI LQW31HN27NJ03L T 110/61
L25 6200002820 S.COI LQW31HN47NJ03L T 105.6/60
L26 6200007670 S.COI LQW2BHN10NJ03L T 101.8/64
L27 6200007670 S.COI LQW2BHN10NJ03L T 97.3/64.9
L28 6200007670 S.COI LQW2BHN10NJ03L T 98.4/60
L29 6200003251 S.COI NLV32T-R39J T 88/66.1
L30 6200002330 S.COI LQW31HN15NJ03L T 82.2/64.8
L31 6200007670 S.COI LQW2BHN10NJ03L T 78.5/62.1
L32 6200002360 S.COI LQW31HN33NJ03L T 77.5/66
L33 6200003331 S.COI NLV32T-1R0J T 70/64.9
L35 6200002350 S.COI LQW31HN27NJ03L T 110.9/85.4
L36 6200005351 S.COI LL1608-FSL10NJ T 106.5/83.7
L37 6200005301 S.COI LL1608-FSL3N9S T 104.3/83.8
L38 6200005301 S.COI LL1608-FSL3N9S T 104.3/80.5
L39 6200002820 S.COI LQW31HN47NJ03L T 94.2/87.2
L41 6200005341 S.COI LL1608-FSL8N2J T 86.8/81.2
L42 6200002330 S.COI LQW31HN15NJ03L T 83.8/82.4
L43 6200003331 S.COI NLV32T-1R0J T 40.2/73.1
L44 6200001831 S.COI NLV32T-100J T 40.2/77.3
L46 6200007670 S.COI LQW2BHN10NJ03L T 43.4/57
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[RF-D UNIT]
L47 6200002330 S.COI LQW31HN15NJ03L T 43/52.3
L48 6200002100 S.COI LQW31HN17NJ03L T 43/47.3
L49 6200001831 S.COI NLV32T-100J T 42.5/43.2
L51 6200005291 S.COI LL1608-FSL3N3S T 27.8/54.9
L52 6200002320 S.COI LQW31HN8N8J03L T 30.2/52.1
L53 6200005301 S.COI LL1608-FSL3N9S T 28/48.9
L54 6200012040 S.COI LL1608-FSL5N6S T 29.4/48.5
L55 6200005301 S.COI LL1608-FSL3N9S T 29.4/45.8
L56 6200005291 S.COI LL1608-FSL3N3S T 29.4/42.8
L57 6200003331 S.COI NLV32T-1R0J T 27.3/38
L58 6140002551 S.COI #617DB-1919=P3 T 28.2/25.2
L59 6140002551 S.COI #617DB-1919=P3 T 17/21.6
L60 6200003331 S.COI NLV32T-1R0J T 16/15.7
L61 6140002551 S.COI #617DB-1919=P3 T 28.2/18.3
L62 6200003331 S.COI NLV32T-1R0J T 23.8/13
L64 6200012030 S.COI LL1608-FSL22NJ T 13.1/51.5
L65 6200001770 S.COI ELJNC 47NK-F T 9.1/51.8
L67 6200005301 S.COI LL1608-FSL3N9S T 12.4/44.1
L69 6200012040 S.COI LL1608-FSL5N6S T 12.4/41.2
L70 6200005371 S.COI LL1608-FSL15NJ T 8.7/38.8
L72 6200005331 S.COI LL1608-FSL6N8J T 12.4/47.2
L73 6200010561 S.COI LL1608-FSL39NJ T 107.3/81.4
L74 6200012040 S.COI LL1608-FSL5N6S T 30/55.3
L75 6200007670 S.COI LQW2BHN10NJ03L T 30.3/13
L76 6200002320 S.COI LQW31HN8N8J03L T 32.2/9.5
L77 6200005331 S.COI LL1608-FSL6N8J T 35.8/9.8
L78 6200006030 S.COI LQP18MN4N7C02D T 126/87.4
L79 6200012040 S.COI LL1608-FSL5N6S T 127.4/85.8
L80 6200003031 S.COI NLV32T-R47J T 120.7/80.5
L81 6200003331 S.COI NLV32T-1R0J T 30.4/58.3
L82 6200012030 S.COI LL1608-FSL22NJ T 23.6/60.3
R1 7030003200 S.RES ERJ3GEYJ 100 V (10) T 114.7/97.8
R2 7410000590 S.ARR EXB-V4V 473JV (47K) T 104.1/26.5
R3 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 95.9/18
R4 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 97.2/18
R5 7030003250 S.RES ERJ3GEYJ 270 V (27) T 93.8/18
R6 7030003760 S.RES ERJ3GEYJ 474 V (470K) T 96.9/25.3
R7 7030003270 S.RES ERJ3GEYJ 390 V (39) T 88.5/24.4
R8 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 88/15.6
R10 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 108.2/40.2
R11 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 95.1/39.1
R12 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 86/39.2
R13 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 93.7/41.2
R14 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 95.4/46.1
R15 7030003250 S.RES ERJ3GEYJ 270 V (27) T 87.8/39.6
R16 7030003760 S.RES ERJ3GEYJ 474 V (470K) T 94/46.1
R17 7030003270 S.RES ERJ3GEYJ 390 V (39) T 85.8/46.3
R19 7030000370 S.RES MCR10EZHJ 820 (821) T 125.3/51.9
R20 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 91.9/59
R21 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 82.6/60.7
R22 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 92/69.5
R23 7030003250 S.RES ERJ3GEYJ 270 V (27) T 87/60
R24 7030003760 S.RES ERJ3GEYJ 474 V (470K) T 98.4/68.4
R25 7030003270 S.RES ERJ3GEYJ 390 V (39) T 90.2/68.8
R26 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 92.5/61.5
R27 7030000370 S.RES MCR10EZHJ 820 (821) T 57/55
R28 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 110.9/81.1
R29 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 99.3/80
R30 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 90/80.8
R31 7030003260 S.RES ERJ3GEYJ 330 V (33) T 93.6/82.2
R32 7030003270 S.RES ERJ3GEYJ 390 V (39) T 90/88.8
R33 7030003760 S.RES ERJ3GEYJ 474 V (470K) T 98.2/88.6
R34 7030003400 S.RES ERJ3GEYJ 471 V (470) T 48.4/73.6
R35 7030003200 S.RES ERJ3GEYJ 100 V (10) T 69.6/88.8
R36 7030003430 S.RES ERJ3GEYJ 821 V (820) T 37.5/70.2
R37 7030004030 S.RES ERJ3GEYJ 5R6 V (5.6) T 40.2/68.8
R38 7030003430 S.RES ERJ3GEYJ 821 V (820) T 44.2/69.9
R39 7410000750 S.ARR EXB-V4V 104JV (100K) T 15.2/95.8
R40 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 13.5/94.8
R41 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 27.1/95
R42 7030003540 S.RES ERJ3GEYJ 682 V (6.8K) T 54.7/92.1
R43 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 55.5/95.1
R44 7030003860 S.RES ERJ3GE JPW V T 54.1/96.7
R45 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 27.7/92.2
R46 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 26.3/92.2
R48 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 14.3/69.4
R49 7030003530 S.RES ERJ3GEYJ 562 V (5.6K) T 14.3/70.8
R50 7030003620 S.RES ERJ3GEYJ 333 V (33K) T 17.9/69.4
R51 7030003660 S.RES ERJ3GEYJ 683 V (68K) T 25.1/69
R52 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 17.9/70.8
R54 7030003590 S.RES ERJ3GEYJ 183 V (18K) T 14.3/73.6
R56 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) T 14.3/72.2
R57 7030003730 S.RES ERJ3GEYJ 274 V (270K) T 19.3/76.6
R58 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 18/73.6
R59 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 17.9/72.2
R62 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) T 16.3/83.2
R63 7030003620 S.RES ERJ3GEYJ 333 V (33K) T 14.5/76.4
R64 7030003630 S.RES ERJ3GEYJ 393 V (39K) T 17.1/81.2
R65 7030003700 S.RES ERJ3GEYJ 154 V (150K) T 19.3/80.4
R66 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 20.9/84.2
R67 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 98.8/83.3
R68 7410000580 S.ARR EXB-V4V 224JV (220K) T 19.6/88.4
R69 7030003760 S.RES ERJ3GEYJ 474 V (470K) T 27.9/83
R70 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 98.3/81.5
R71 7030003510 S.RES ERJ3GEYJ 392 V (3.9K) T 32.9/83.8
R72 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) T 33.1/80.2
R73 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 26.1/87.3

Jun. 2011
16
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[RF-D UNIT]
R74 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 31.5/75.8
R75 7030003660 S.RES ERJ3GEYJ 683 V (68K) T 28.2/79.2
R76 7030003710 S.RES ERJ3GEYJ 184 V (180K) T 28.2/76.4
R77 7030003760 S.RES ERJ3GEYJ 474 V (470K) T 30.5/77.2
R78 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 20.9/85.5
R79 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 27.2/97.1
R80 7410000800 S.ARR EXB-V8V 103JV (10K) T 28.3/70.8
R81 7410000800 S.ARR EXB-V8V 103JV (10K) T 61/85.6
R82 7030003430 S.RES ERJ3GEYJ 821 V (820) T 39.6/67.4
R83 7030003280 S.RES ERJ3GEYJ 470 V (47) T 45.3/41
R84 7030003430 S.RES ERJ3GEYJ 821 V (820) T 35.5/26.4
R85 7030003280 S.RES ERJ3GEYJ 470 V (47) T 23.6/38
R86 7410000750 S.ARR EXB-V4V 104JV (100K) T 27/52.4
R87 7410000590 S.ARR EXB-V4V 473JV (47K) T 23.9/53.4
R88 7030003490 S.RES ERJ3GEYJ 272 V (2.7K) T 6.8/26.8
R89 7030003620 S.RES ERJ3GEYJ 333 V (33K) T 4.8/26.8
R90 7030003430 S.RES ERJ3GEYJ 821 V (820) T 38.2/13.8
R91 7030007680 S.RES ERJ8ENF 47R0V (47) T 2/26.1
R92 7030003430 S.RES ERJ3GEYJ 821 V (820) T 40.4/13
R93 7030003430 S.RES ERJ3GEYJ 821 V (820) T 6.5/59.6
R94 7030004030 S.RES ERJ3GEYJ 5R6 V (5.6) T 8.7/58.8
R95 7030003430 S.RES ERJ3GEYJ 821 V (820) T 6.5/58
R96 7030003430 S.RES ERJ3GEYJ 821 V (820) T 8.7/49.6
R97 7030004030 S.RES ERJ3GEYJ 5R6 V (5.6) T 10.9/48.8
R98 7030003430 S.RES ERJ3GEYJ 821 V (820) T 8.7/48
R99 7030003370 S.RES ERJ3GEYJ 271 V (270) T 9.4/35.8
R100 7030003320 S.RES ERJ3GEYJ 101 V (100) T 6.5/83
R105 7030003320 S.RES ERJ3GEYJ 101 V (100) T 10.9/76.6
R106 7030003200 S.RES ERJ3GEYJ 100 V (10) T 47.8/71.4
R107 7030004030 S.RES ERJ3GEYJ 5R6 V (5.6) T 38.2/12.2
R108 7030003400 S.RES ERJ3GEYJ 471 V (470) T 47/69.2
R109 7310004790 S.TRI EVM-3YSX50 B14 (103) T 5.8/22.8
R110 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 93.8/24.6
R111 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 84.9/25.8
R112 7030003430 S.RES ERJ3GEYJ 821 V (820) T 90.5/46.3
R113 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) T 90.2/66.2
R114 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) T 83.9/67.4
R115 7030003240 S.RES ERJ3GEYJ 220 V (22) T 88.2/63
R116 7030003240 S.RES ERJ3GEYJ 220 V (22) T 92.4/84.4
R117 7030003860 S.RES ERJ3GE JPW V T 86.8/84.4
R118 7030003860 S.RES ERJ3GE JPW V T 112/16
R119 7030003860 S.RES ERJ3GE JPW V T 71.6/18.4
R120 7030003860 S.RES ERJ3GE JPW V T 111.3/46.7
R121 7030003860 S.RES ERJ3GE JPW V T 76/46.5
R122 7030003860 S.RES ERJ3GE JPW V T 111.5/66.5
R123 7030003860 S.RES ERJ3GE JPW V T 73/69
R124 7030003280 S.RES ERJ3GEYJ 470 V (47) T 96.8/21.5
C1 4030006860 S.CER C1608 JB 1H 102K-T T 129.6/81.1
C2 4030006860 S.CER C1608 JB 1H 102K-T T 122.4/52.9
C3 4030006880 S.CER C1608 JB 1H 472K-T T 110.6/24
C4 4030006850 S.CER C1608 JB 1H 471K-T T 109/25.7
C5 4030006880 S.CER C1608 JB 1H 472K-T T 112.8/18.2
C6 4030006880 S.CER C1608 JB 1H 472K-T T 90.4/16.4
C7 4030009490 S.CER C1608 JB 1H 821K-T T 96.9/23.8
C8 4030006880 S.CER C1608 JB 1H 472K-T T 92.4/18
C9 4030006860 S.CER C1608 JB 1H 102K-T T 92/26.6
C10 4030007050 S.CER C1608 CH 1H 220J-T T 90/20.6
C11 4030006880 S.CER C1608 JB 1H 472K-T T 89.3/26.6
C12 4030006880 S.CER C1608 JB 1H 472K-T T 75.8/23.6
C13 4030006880 S.CER C1608 JB 1H 472K-T T 73.8/19.4
C14 4030006860 S.CER C1608 JB 1H 102K-T T 56/57.6
C15 4030006860 S.CER C1608 JB 1H 102K-T T 110.6/41
C16 4030006860 S.CER C1608 JB 1H 102K-T T 108.2/42.4
C17 4030007030 S.CER C1608 CH 1H 150J-T T 100.9/38.4
C18 4030006860 S.CER C1608 JB 1H 102K-T T 88.2/36.8
C19 4030006850 S.CER C1608 JB 1H 471K-T T 114/45.4
C20 4030006860 S.CER C1608 JB 1H 102K-T T 96.6/38.4
C21 4030006860 S.CER C1608 JB 1H 102K-T T 92.6/46.1
C22 4030006850 S.CER C1608 JB 1H 471K-T T 90.6/39.6
C23 4030006860 S.CER C1608 JB 1H 102K-T T 87.6/48
C24 4030007010 S.CER C1608 CH 1H 100D-T T 86.7/42
C25 4030006860 S.CER C1608 JB 1H 102K-T T 82.3/47.6
C26 4030006860 S.CER C1608 JB 1H 102K-T T 84.3/37.8
C27 4030006860 S.CER C1608 JB 1H 102K-T T 74.7/39.8
C28 4030006850 S.CER C1608 JB 1H 471K-T T 76.8/43.7
C29 4030007130 S.CER C1608 CH 1H 101J-T T 112.4/63.4
C30 4030007010 S.CER C1608 CH 1H 100D-T T 107.7/64.2
C31 4030009650 S.CER C1608 CH 1H 240J-T T 105.4/64
C32 4030007070 S.CER C1608 CH 1H 330J-T T 104.6/66.2
C33 4030007130 S.CER C1608 CH 1H 101J-T T 115/67
C34 4030006850 S.CER C1608 JB 1H 471K-T T 115/68.5
C36 4030006860 S.CER C1608 JB 1H 102K-T T 95.4/69.1
C37 4030006860 S.CER C1608 JB 1H 102K-T T 89.8/60
C38 4030006850 S.CER C1608 JB 1H 471K-T T 88.4/60
C39 4030009530 S.CER C1608 CH 1H 030B-T T 85.4/63
C40 4030007130 S.CER C1608 CH 1H 101J-T T 91.8/67.3
C41 4030006850 S.CER C1608 JB 1H 471K-T T 86.5/69.2
C43 4030006860 S.CER C1608 JB 1H 102K-T T 74.1/65.2
C44 4030006850 S.CER C1608 JB 1H 471K-T T 69.8/67.6
C45 4030007130 S.CER C1608 CH 1H 101J-T T 69.8/69
C46 4030007130 S.CER C1608 CH 1H 101J-T T 81.8/58.5
C47 4030007020 S.CER C1608 CH 1H 120J-T T 114.2/81.2
C48 4030006850 S.CER C1608 JB 1H 471K-T T 89.8/78.6
C49 4030006850 S.CER C1608 JB 1H 471K-T T 96.4/81.8
C50 4030006860 S.CER C1608 JB 1H 102K-T T 95/82.2
C51 4030006850 S.CER C1608 JB 1H 471K-T T 100.3/86.4
C52 4030006860 S.CER C1608 JB 1H 102K-T T 100.3/87.8
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[RF-D UNIT]
C53 4030006850 S.CER C1608 JB 1H 471K-T T 94.1/90.4
C54 4030006850 S.CER C1608 JB 1H 471K-T T 87.3/90.2
C55 4030009520 S.CER C1608 CH 1H 020B-T T 90.8/85.8
C56 4030008560 S.CER C1608 CH 1H 300J-T T 80/82.3
C57 4030006860 S.CER C1608 JB 1H 102K-T T 47/73.6
C59 4030006860 S.CER C1608 JB 1H 102K-T T 41/70.2
C60 4030006850 S.CER C1608 JB 1H 471K-T T 43.2/75.2
C61 4030006860 S.CER C1608 JB 1H 102K-T T 43.2/76.6
C66 4030006860 S.CER C1608 JB 1H 102K-T T 31.5/92.2
C67 4030007090 S.CER C1608 CH 1H 470J-T
[EUR-02] only T 2.4/91.2
C68 4030007090 S.CER C1608 CH 1H 470J-T
[EUR-02] only T 2.3/94.1
C72 4530000410 S.ARR EZANCE 471M 470P T 43.2/85.7
C75 4030011600 S.CER C1608 JB 1E 104K-T T 16.2/91.8
C76 4030011600 S.CER C1608 JB 1E 104K-T T 22.6/97.6
C77 4030011600 S.CER C1608 JB 1E 104K-T T 26/97.1
C78 4030006860 S.CER C1608 JB 1H 102K-T T 11.1/70.4
C79 4510008550 S.ELE EEE1HA010SR T 15.1/66.4
C80 4510008550 S.ELE EEE1HA010SR T 12.1/90.7
C81 4030006860 S.CER C1608 JB 1H 102K-T T 15.8/89.6
C82 4030006860 S.CER C1608 JB 1H 102K-T T 43.4/67.9
C83 4030006950 S.CER C1608 CH 1H 040C-T T 46.6/59.1
C84 4030006950 S.CER C1608 CH 1H 040C-T T 45.8/56.9
C85 4030006990 S.CER C1608 CH 1H 080D-T T 46/54
C86 4030009520 S.CER C1608 CH 1H 020B-T T 41/52.3
C87 4030006990 S.CER C1608 CH 1H 080D-T T 46/49.8
C88 4030009500 S.CER C1608 CH 1H 0R5B-T T 41/47.2
C89 4030006950 S.CER C1608 CH 1H 040C-T T 46/45.6
C90 4030006900 S.CER C1608 JB 1H 103K-T T 45.5/43.4
C91 4030007130 S.CER C1608 CH 1H 101J-T T 46.8/43.4
C92 4030006850 S.CER C1608 JB 1H 471K-T T 48.2/42.7
C93 4030006960 S.CER C1608 CH 1H 050C-T T 26.4/54.9
C94 4030006980 S.CER C1608 CH 1H 070D-T T 26.6/48.9
C95 4030007090 S.CER C1608 CH 1H 470J-T T 22.5/51
C96 4030009520 S.CER C1608 CH 1H 020B-T T 25.8/46.6
C97 4030009510 S.CER C1608 CH 1H 010B-T T 28/45.8
C98 4030009520 S.CER C1608 CH 1H 020B-T T 25.8/45
C100 4030009540 S.CER C1608 CH 1H 1R5B-T T 28.6/40.4
C101 4030007090 S.CER C1608 CH 1H 470J-T T 25.6/40.4
C102 4030006850 S.CER C1608 JB 1H 471K-T T 22.8/40.2
C103 4030006860 S.CER C1608 JB 1H 102K-T T 32.2/24.2
C104 4030006850 S.CER C1608 JB 1H 471K-T T 14.6/12.7
C105 4030006860 S.CER C1608 JB 1H 102K-T T 14.6/11.4
C106 4030006850 S.CER C1608 JB 1H 471K-T T 17.6/25.6
C107 4030006850 S.CER C1608 JB 1H 471K-T T 15/25.6
C108 4030006850 S.CER C1608 JB 1H 471K-T T 28.5/21.4
C109 4030006850 S.CER C1608 JB 1H 471K-T T 32.2/20.5
C110 4030006850 S.CER C1608 JB 1H 471K-T T 19.8/13.6
C111 4030006860 S.CER C1608 JB 1H 102K-T T 19.8/12.2
C112 4030006850 S.CER C1608 JB 1H 471K-T T 37.4/9.8
C113 4030006860 S.CER C1608 JB 1H 102K-T
[EUR-02] only T 6.5/18.7
C114 4030006860 S.CER C1608 JB 1H 102K-T
[EUR-02] only T 1.8/15.1
C117 4030006850 S.CER C1608 JB 1H 471K-T T 10.9/58
C118 4030006850 S.CER C1608 JB 1H 471K-T T 13.1/49.6
C119 4030006850 S.CER C1608 JB 1H 471K-T T 10.2/54.9
C120 4030007010 S.CER C1608 CH 1H 100D-T T 12.1/52.9
C121 4030006850 S.CER C1608 JB 1H 471K-T T 7.3/54.9
C122 4030009520 S.CER C1608 CH 1H 020B-T T 8.7/44.9
C123 4030009520 S.CER C1608 CH 1H 020B-T T 10.9/44.1
C124 4030009550 S.CER C1608 CH 1H 2R5B-T T 8.7/43.3
C125 4030006950 S.CER C1608 CH 1H 040C-T T 13.8/39.6
C126 4030006950 S.CER C1608 CH 1H 040C-T T 11.6/36.6
C127 4030006960 S.CER C1608 CH 1H 050C-T T 11.8/38.8
C128 4030006850 S.CER C1608 JB 1H 471K-T T 13.6/35.8
C129 4030006860 S.CER C1608 JB 1H 102K-T T 7.9/83.8
C130 4510008550 S.ELE EEE1HA010SR T 6.7/89.3
C131 4030006860 S.CER C1608 JB 1H 102K-T T 89.2/39.6
C132 4030007060 S.CER C1608 CH 1H 270J-T T 112.8/83.2
C133 4030009530 S.CER C1608 CH 1H 030B-T T 79.2/84.2
C134 4030009560 S.CER C1608 CH 1H R75B-T T 10.9/41.2
C135 4030009510 S.CER C1608 CH 1H 010B-T T 8.7/40.4
C136 4510008550 S.ELE EEE1HA010SR T 21.8/69.8
C137 4030009500 S.CER C1608 CH 1H 0R5B-T T 35.5/25
C138 4030006850 S.CER C1608 JB 1H 471K-T T 33.6/24.2
C139 4030006860 S.CER C1608 JB 1H 102K-T T 13.6/25.6
C140 4030009540 S.CER C1608 CH 1H 1R5B-T T 13.7/17.8
C141 4030006950 S.CER C1608 CH 1H 040C-T T 26.5/13
C142 4030009510 S.CER C1608 CH 1H 010B-T T 28/13
C143 4030006950 S.CER C1608 CH 1H 040C-T T 28/10.1
C144 4030009520 S.CER C1608 CH 1H 020B-T T 33.6/12
C145 4030006940 S.CER C1608 CH 1H 030C-T T 35.8/12.8
C146 4030006860 S.CER C1608 JB 1H 102K-T T 90/90.2
C147 4030006860 S.CER C1608 JB 1H 102K-T T 92/89.9
C148 4030006860 S.CER C1608 JB 1H 102K-T T 109.5/79.4
C149 4030006850 S.CER C1608 JB 1H 471K-T T 96.8/79
C150 4030006850 S.CER C1608 JB 1H 471K-T T 93.1/80
C151 4030006860 S.CER C1608 JB 1H 102K-T T 132.5/82.3
C152 4030006860 S.CER C1608 JB 1H 102K-T T 117/96.4
C153 4030009520 S.CER C1608 CH 1H 020B-T T 122.7/88.3
C154 4030009520 S.CER C1608 CH 1H 020B-T T 124.6/87.4
C155 4030009520 S.CER C1608 CH 1H 020B-T T 122.9/85.7
C156 4030007130 S.CER C1608 CH 1H 101J-T T 126/84.2
C157 4030007130 S.CER C1608 CH 1H 101J-T T 126/81.4
C158 4030006850 S.CER C1608 JB 1H 471K-T T 124.1/82.1
C159 4030006850 S.CER C1608 JB 1H 471K-T T 109.4/97
C160 4030006850 S.CER C1608 JB 1H 471K-T T 100.7/96.4

Jun. 2011
17
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[RF-D UNIT]
C161 4030006850 S.CER C1608 JB 1H 471K-T T 59.8/52.1
C162 4030006850 S.CER C1608 JB 1H 471K-T T 61.4/32.4
C163 4030006850 S.CER C1608 JB 1H 471K-T T 61.4/30.6
C164 4030006850 S.CER C1608 JB 1H 471K-T T 90.4/7.1
C165 4030006850 S.CER C1608 JB 1H 471K-T T 1.5/85.5
C166 4030007010 S.CER C1608 CH 1H 100D-T T 27.2/57.1
C167 4030007010 S.CER C1608 CH 1H 100D-T T 26.4/59.3
C168 4030007030 S.CER C1608 CH 1H 150J-T T 25/59.7
C171 4030009920 S.CER C1608 CH 1H 050B-T T 99/22.4
C172 4030009920 S.CER C1608 CH 1H 050B-T T 95.8/43.9
C173 4030007130 S.CER C1608 CH 1H 101J-T T 94/62.8
C174 4030009920 S.CER C1608 CH 1H 050B-T T 100.3/84.8
RL1 6330000810 REL ARK115
RL2 6330000810 REL ARK115
CP1 6910009670 S.CHE HK3-S-T T 1.8/21.9
J1 6510007020 CON TMP-J01X-V6
J2 6510007020 CON TMP-J01X-V6
J3 6510019761 S.CON 52610-1571(1590) T 41.4/95.8
J4 6510007020 CON TMP-J01X-V6
EP71 6910012350 S.BEA MMZ1608Y 102BT T 34.5/90.6
EP72 6910012350 S.BEA MMZ1608Y 102BT T 35.8/90.6
EP73 6910012350 S.BEA MMZ1608Y 102BT T 37.1/90.6
EP74 6910012350 S.BEA MMZ1608Y 102BT T 38.4/90.6
EP75 6910012350 S.BEA MMZ1608Y 102BT T 49/87
EP76 6910012350 S.BEA MMZ1608Y 102BT T 49/88.3
EP77 6910012350 S.BEA MMZ1608Y 102BT T 49/89.6
EP78 6910012350 S.BEA MMZ1608Y 102BT T 49/90.9
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[CONV-B UNIT]
IC1 1110006970 S.IC MAALSS0038TR <M/A> T 65.6/10
IC2 6910010231 S.IC 5MXF25-7-LF CONV T 65/41.7
IC3 1110006420 S.IC UPC2708TB-E3-A T 58.4/27
IC4 1140006720 S.IC LMX2316TMX/NOPB T 16/45.7
IC6 1190002380 S.IC MVE1017-42-J1803 T 27.7/26.7
IC7 1110006420 S.IC UPC2708TB-E3-A T 19.7/36.2
IC8 1110004610 S.IC UPB1508GV-E1 T 17.8/60.3
IC9 1110006870 S.IC UPC2709TB-E3 T 48/61.4
IC10 1130007700 S.IC BU4094BCF-E2 T 14.4/14.5
IC11 1160000132 S.IC TD62783AFG(O) T 27.3/9.2
Q2 1590004600 S.TRA DMC561030 T 66.9/51.6
Q3 1590001001 S.TRA RN2427(TE85L,F) T 42.5/12.6
Q4 1590000430 S.TRA DTC144EUA T106 T 44.3/6.8
Q5 1590001001 S.TRA RN2427(TE85L,F) T 28.1/18.3
Q6 1590000430 S.TRA DTC144EUA T106 T 24.5/18.6
Q7 1590004600 S.TRA DMC561030 T 38.9/13
Q10 1590001330 S.TRA DTA114EUA T106 T 42.5/9.4
Q11 1530003451 S.TRA 2SC4835GRL T 76.5/67.4
Q12 1530003451 S.TRA 2SC4835GRL T 44.6/72.9
Q13 1530002280 S.TRA 2SC4081 T106 S T 40.2/19.1
Q14 1590001001 S.TRA RN2427(TE85L,F) T 32.2/18.6
D1 1750000550 S.DIO 1SS355 TE-17 T 79.7/19.6
D3 1720000681 S.VAR 1SV262(TPH2,F) T 74.2/9.2
D4 1720000681 S.VAR 1SV262(TPH2,F) T 74.2/5.6
D5 1720000681 S.VAR 1SV262(TPH2,F) T 69.1/8.2
D6 1750000550 S.DIO 1SS355 TE-17 T 75/57.9
D7 1790000620 S.DIO MA77(TX) T 80.9/69.2
D8 1790000620 S.DIO MA77(TX) T 67.5/69.3
D9 1790000620 S.DIO MA77(TX) T 49.1/73.8
D10 1790000620 S.DIO MA77(TX) T 35.7/73.9
D11 1750000211 S.DIO 1SV237(TE85R,F) T 23.1/56.9
D12 1750000211 S.DIO 1SV237(TE85R,F) T 23.1/62.9
D13 1750000211 S.DIO 1SV237(TE85R,F) T 42.8/52.3
D14 1750000211 S.DIO 1SV237(TE85R,F) T 42.9/40.5
D15 1750000531 S.DIO 1SV271(TPH3,F) T 80.9/71.2
D16 1750000531 S.DIO 1SV271(TPH3,F) T 67.5/71.2
D17 1750000531 S.DIO 1SV271(TPH3,F) T 49.1/75.8
D18 1750000531 S.DIO 1SV271(TPH3,F) T 35.7/75.8
D19 1750000550 S.DIO 1SS355 TE-17 T 8.8/47.8
D20 1720000681 S.VAR 1SV262(TPH2,F) T 79.2/8.6
D21 1720000681 S.VAR 1SV262(TPH2,F) T 80.4/5.6
D22 1790000661 S.DIO MA2J7280GL T 40.2/21.4
L2 6200005331 S.COI LL1608-FSL6N8J T 77.6/9.8
L3 6200006050 S.COI LQP18MN6N8C02D T 76/11.2
L4 6200006040 S.COI LQP18MN5N6C02D T 71.8/9.6
L5 6200005361 S.COI LL1608-FSL12NJ T 63.6/6.4
L6 6200001620 S.COI ELJFC 1R0K-F T 56.3/13.1
L10 6200005411 S.COI LL1608-FSL33NJ T 62/26
L11 6200003331 S.COI NLV32T-1R0J T 57.7/23.6
L12 6200005301 S.COI LL1608-FSL3N9S T 74.2/51
L16 6200001981 S.COI NLV25T-1R0J T 83.8/73.1
L17 6200001981 S.COI NLV25T-1R0J T 71/79.8
L18 6200001981 S.COI NLV25T-1R0J T 71.5/67.3
L19 6200001981 S.COI NLV25T-1R0J T 64.5/70.4
L20 6200001981 S.COI NLV25T-1R0J T 53.1/75.5
L21 6200001981 S.COI NLV25T-1R0J T 52/78.3
L22 6200001981 S.COI NLV25T-1R0J T 39.7/71.9
L23 6200001981 S.COI NLV25T-1R0J T 32.7/74.9
L24 6200003550 S.COI MLF1608A 4R7K-T T 9.2/44.3
L25 6200001620 S.COI ELJFC 1R0K-F T 22.8/53.1
L27 6200003331 S.COI NLV32T-1R0J T 36.8/18.9
L28 6200001620 S.COI ELJFC 1R0K-F T 25.9/37.7
L29 6200005341 S.COI LL1608-FSL8N2J T 25/45.6
L30 6200005351 S.COI LL1608-FSL10NJ T 25.8/42.3
L31 6200001770 S.COI ELJNC 47NK-F T 10.2/56.7
L32 6200001620 S.COI ELJFC 1R0K-F T 11.4/59.2
L36 6200001770 S.COI ELJNC 47NK-F T 9.3/61.9
L40 6200001770 S.COI ELJNC 47NK-F T 23.1/59.9
L41 6200001770 S.COI ELJNC 47NK-F T 47.5/57.4
L42 6200003331 S.COI NLV32T-1R0J T 42.9/57.4
L43 6200005361 S.COI LL1608-FSL12NJ T 46.8/50.4
L44 6200005381 S.COI LL1608-FSL18NJ T 46.8/47.2
L45 6200005381 S.COI LL1608-FSL18NJ T 46.8/44
L46 6200003331 S.COI NLV32T-1R0J T 50.3/43.8
L47 6200005331 S.COI LL1608-FSL6N8J T 38.6/50.2
L48 6200005341 S.COI LL1608-FSL8N2J T 38.6/47.2
L49 6200005341 S.COI LL1608-FSL8N2J T 38.6/44.2
L50 6200001770 S.COI ELJNC 47NK-F T 35.5/43.3
L52 6200001770 S.COI ELJNC 47NK-F T 22.8/39.1
L53 6200005361 S.COI LL1608-FSL12NJ T 57.6/5.6
L54 6200005361 S.COI LL1608-FSL12NJ T 53.2/5.6
L56 6200005351 S.COI LL1608-FSL10NJ T 68.2/10.2
L57 6200003251 S.COI NLV32T-R39J T 9/40.4
L58 6200005311 S.COI LL1608-FSL4N7S T 69.8/26
L59 6200003001 S.COI NLV32T-R22J T 20.4/23.6
L60 6170000231 COI LW-25A
R1 7030003200 S.RES ERJ3GEYJ 100 V (10) T 71/32.6
R2 7030003640 S.RES ERJ3GEYJ 473 V (47K) T 78/5.6
R3 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 75.8/7.8
R4 7410000590 S.ARR EXB-V4V 473JV (47K) T 71.7/6.9
R8 7030003370 S.RES ERJ3GEYJ 271 V (270) T 60.6/5.6

Jun. 2011
18
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[CONV-B UNIT]
R9 7030003370 S.RES ERJ3GEYJ 271 V (270) T 59/5.6
R11 7030003390 S.RES ERJ3GEYJ 391 V (390) T 65.2/26
R12 7030003210 S.RES ERJ3GEYJ 120 V (12) T 66/28.2
R13 7030003390 S.RES ERJ3GEYJ 391 V (390) T 66.8/26
R14 7030003200 S.RES ERJ3GEYJ 100 V (10) T 69.4/56
R15 7030000370 S.RES MCR10EZHJ 820 (821) T 83.8/75.3
R16 7030000340 S.RES MCR10EZHJ 470 (471) T 78.7/73.8
R17 7030000240 S.RES MCR10EZHJ 68 (680) T 74.5/75
R18 7030000290 S.RES MCR10EZHJ 180 (181) T 74.5/73
R19 7030000240 S.RES MCR10EZHJ 68 (680) T 71.8/73.9
R20 7030000340 S.RES MCR10EZHJ 470 (471) T 67/73.7
R21 7030000370 S.RES MCR10EZHJ 820 (821) T 64.6/73.9
R23 7030000370 S.RES MCR10EZHJ 820 (821) T 56.9/75.6
R24 7030000340 S.RES MCR10EZHJ 470 (471) T 46.9/78.4
R25 7030000270 S.RES MCR10EZHJ 120 (121) T 42.7/79.6
R26 7030000230 S.RES MCR10EZHJ 56 (560) T 42.7/77.6
R27 7030000270 S.RES MCR10EZHJ 120 (121) T 40/78.5
R28 7030000340 S.RES MCR10EZHJ 470 (471) T 35.2/78.3
R29 7030000370 S.RES MCR10EZHJ 820 (821) T 32.8/78.5
R30 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) T 48.5/67.8
R31 7410001090 S.ARR EXB-V8V 101JV T 66.9/60.1
R32 7030003320 S.RES ERJ3GEYJ 101 V (100) T 10.4/51.3
R34 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 12.2/39.9
R37 7030003500 S.RES ERJ3GEYJ 332 V (3.3K) T 14/28
R38 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 40/23
R39 7030003370 S.RES ERJ3GEYJ 271 V (270) T 15.6/36
R40 7030003230 S.RES ERJ3GEYJ 180 V (18) T 16.4/37.9
R41 7030003370 S.RES ERJ3GEYJ 271 V (270) T 19.2/38.6
R42 7030003350 S.RES ERJ3GEYJ 181 V (180) T 25.8/41
R43 7030003280 S.RES ERJ3GEYJ 470 V (47) T 23.4/50.5
R44 7030003280 S.RES ERJ3GEYJ 470 V (47) T 25.7/54.6
R45 7030003410 S.RES ERJ3GEYJ 561 V (560) T 26.2/58.2
R46 7030003410 S.RES ERJ3GEYJ 561 V (560) T 13.4/56.1
R47 7030003410 S.RES ERJ3GEYJ 561 V (560) T 12.2/63.8
R48 7030003410 S.RES ERJ3GEYJ 561 V (560) T 35.2/60.4
R49 7030003360 S.RES ERJ3GEYJ 221 V (220) T 30.4/50.6
R50 7030003420 S.RES ERJ3GEYJ 681 V (680) T 45.2/40.4
R51 7030005280 S.RES ERJ3GEYJ 6R8V (6.8) T 47.4/39.6
R52 7030003420 S.RES ERJ3GEYJ 681 V (680) T 47.4/41
R53 7410000830 S.ARR EXB-V4V 103JV (10K) T 47.9/16.3
R54 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 47.8/8.6
R55 7310004790 S.TRI EVM-3YSX50 B14 (103) T 47.8/5.3
R56 7030003600 S.RES ERJ3GEYJ 223 V (22K) T 43.8/4.2
R57 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) T 45.2/4.2
R58 7030003370 S.RES ERJ3GEYJ 271 V (270) T 43/54.6
R61 7030003230 S.RES ERJ3GEYJ 180 V (18) T 59.8/7.6
R62 7030003280 S.RES ERJ3GEYJ 470 V (47) T 71.8/40.6
R64 7410000830 S.ARR EXB-V4V 103JV (10K) T 37.9/6.1
R65 7410000830 S.ARR EXB-V4V 103JV (10K) T 37.9/9.7
R66 7030003360 S.RES ERJ3GEYJ 221 V (220) T 70.9/11.8
R67 7030003340 S.RES ERJ3GEYJ 151 V (150) T 51/48.8
R68 7030003340 S.RES ERJ3GEYJ 151 V (150) T 35/46
R69 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) T 70.8/63
R70 7030003420 S.RES ERJ3GEYJ 681 V (680) T 42.6/63.4
R71 7030005280 S.RES ERJ3GEYJ 6R8V (6.8) T 40.4/62.6
R72 7030003420 S.RES ERJ3GEYJ 681 V (680) T 38.2/63.4
R73 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) T 11.5/37.8
R74 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 12.2/25.8
R75 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 14.8/25.8
R76 7030003350 S.RES ERJ3GEYJ 181 V (180) T 54.6/29
R77 7030003680 S.RES ERJ3GEYJ 104 V (100K) T 80/10.8
R78 7030003280 S.RES ERJ3GEYJ 470 V (47) T 27/54.6
R79 7030003350 S.RES ERJ3GEYJ 181 V (180) T 71.6/46.1
R100 7030003560 S.RES ERJ3GEYJ 103 V (10K) T 17.1/41.3
R103 7030003860 S.RES ERJ3GE JPW V T 78.4/12
R104 7030003860 S.RES ERJ3GE JPW V T 80/13.4
R106 7030003860 S.RES ERJ3GE JPW V T 69.6/11.8
R107 7030003860 S.RES ERJ3GE JPW V T 88.8/69.6
R108 7030003860 S.RES ERJ3GE JPW V T 86/69.8
R109 7030003860 S.RES ERJ3GE JPW V T 78.6/68.4
C1 4030006850 S.CER C1608 JB 1H 471K-T T 79.8/18.1
C2 4030009530 S.CER C1608 CH 1H 030B-T T 83/13.4
C6 4030009530 S.CER C1608 CH 1H 030B-T T 76.8/13.4
C8 4030009520 S.CER C1608 CH 1H 020B-T T 73.8/12.6
C9 4030006850 S.CER C1608 JB 1H 471K-T T 69.2/6.6
C11 4030007130 S.CER C1608 CH 1H 101J-T T 67.4/12.6
C14 4030007010 S.CER C1608 CH 1H 100D-T T 61.4/8.8
C16 4030006860 S.CER C1608 JB 1H 102K-T T 66.2/7.2
C17 4030007130 S.CER C1608 CH 1H 101J-T T 66.2/5.9
C18 4030008560 S.CER C1608 CH 1H 300J-T T 54/22.6
C21 4030006850 S.CER C1608 JB 1H 471K-T T 55.4/26.8
C24 4030007130 S.CER C1608 CH 1H 101J-T T 63/28.2
C25 4030006990 S.CER C1608 CH 1H 080D-T T 60.6/22.6
C26 4030007130 S.CER C1608 CH 1H 101J-T T 61.9/22.6
C27 4030009530 S.CER C1608 CH 1H 030B-T T 73.4/53.2
C29 4030006850 S.CER C1608 JB 1H 471K-T T 74.2/55.6
C34 4030006860 S.CER C1608 JB 1H 102K-T T 84.2/71.2
C36 4030006860 S.CER C1608 JB 1H 102K-T T 77.8/71.2
C37 4030006860 S.CER C1608 JB 1H 102K-T T 69.4/72.8
C38 4030006860 S.CER C1608 JB 1H 102K-T T 80.6/75.4
C39 4030006860 S.CER C1608 JB 1H 102K-T T 69.4/74.2
C40 4030007130 S.CER C1608 CH 1H 101J-T T 65.2/79.8
C41 4030006860 S.CER C1608 JB 1H 102K-T T 66.6/79.8
C42 4030007130 S.CER C1608 CH 1H 101J-T T 68/67.7
C43 4030006860 S.CER C1608 JB 1H 102K-T T 68/66.4
C44 4030006860 S.CER C1608 JB 1H 102K-T T 53/73.6
C45 4030006860 S.CER C1608 JB 1H 102K-T T 46/75.8
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[CONV-B UNIT]
C46 4030006860 S.CER C1608 JB 1H 102K-T T 37.6/77.4
C47 4030006860 S.CER C1608 JB 1H 102K-T T 48.8/80
C48 4030007130 S.CER C1608 CH 1H 101J-T T 37.6/78.8
C49 4030007130 S.CER C1608 CH 1H 101J-T T 54.4/79.2
C50 4030006860 S.CER C1608 JB 1H 102K-T T 55.8/79.2
C51 4030007130 S.CER C1608 CH 1H 101J-T T 36.2/72.3
C52 4030006860 S.CER C1608 JB 1H 102K-T T 36.2/71
C53 4030006860 S.CER C1608 JB 1H 102K-T T 33.8/71.8
C54 4030008920 S.CER C1608 JB 1H 473K-T T 11.2/49.4
C55 4030011600 S.CER C1608 JB 1E 104K-T T 9.2/45.6
C56 4030008920 S.CER C1608 JB 1H 473K-T T 10.4/47.5
C57 4030008920 S.CER C1608 JB 1H 473K-T T 40.2/3.8
C58 4030006860 S.CER C1608 JB 1H 102K-T T 41.6/3.8
C60 4550006270 S.TAN TEESVP 1A 105M8R T 25.8/49.2
C61 4030006860 S.CER C1608 JB 1H 102K-T T 16.6/50.1
C62 4030011600 S.CER C1608 JB 1E 104K-T T 14.2/52.9
C63 4030006850 S.CER C1608 JB 1H 471K-T T 12.9/54.8
C64 4550006270 S.TAN TEESVP 1A 105M8R T 8.8/51.1
C66 4030006900 S.CER C1608 JB 1H 103K-T T 14/29.4
C67 4550000530 S.TAN TEESVA 1V 104M8R T 18/28.4
C69 4030006860 S.CER C1608 JB 1H 102K-T T 36.4/22.6
C70 4030007090 S.CER C1608 CH 1H 470J-T T 37.8/22.6
C71 4510009140 S.ELE EEE1AA330SR T 38.6/28.2
C74 4030006850 S.CER C1608 JB 1H 471K-T T 17.2/36
C75 4030006850 S.CER C1608 JB 1H 471K-T T 22.9/41
C76 4030009530 S.CER C1608 CH 1H 030B-T T 25.8/43.6
C77 4030009500 S.CER C1608 CH 1H 0R5B-T T 26.6/45.6
C78 4030009530 S.CER C1608 CH 1H 030B-T T 25.8/47.7
C79 4030006860 S.CER C1608 JB 1H 102K-T T 20.7/50.5
C80 4030006850 S.CER C1608 JB 1H 471K-T T 26.2/56.9
C81 4030006850 S.CER C1608 JB 1H 471K-T T 16.4/56.1
C82 4030006850 S.CER C1608 JB 1H 471K-T T 9.2/54.8
C83 4030007090 S.CER C1608 CH 1H 470J-T T 9.2/53.5
C84 4030006860 S.CER C1608 JB 1H 102K-T T 19.2/55.3
C85 4030007090 S.CER C1608 CH 1H 470J-T T 14.1/60.7
C86 4030006850 S.CER C1608 JB 1H 471K-T T 14.1/58
C87 4030006850 S.CER C1608 JB 1H 471K-T T 14.1/63.4
C93 4030006850 S.CER C1608 JB 1H 471K-T T 12.2/62.5
C94 4030007090 S.CER C1608 CH 1H 470J-T T 12.2/61.2
C100 4030006850 S.CER C1608 JB 1H 471K-T T 37.4/61.2
C101 4030006850 S.CER C1608 JB 1H 471K-T T 26.8/61
C102 4030007090 S.CER C1608 CH 1H 470J-T T 31.2/57.6
C103 4030006850 S.CER C1608 JB 1H 471K-T T 46.2/54.6
C104 4030006850 S.CER C1608 JB 1H 471K-T T 45.6/60.4
C105 4030007090 S.CER C1608 CH 1H 470J-T T 44.2/60.4
C107 4030006860 S.CER C1608 JB 1H 102K-T T 8.1/68.2
C108 4030006860 S.CER C1608 JB 1H 102K-T T 17/71.4
C109 4030006860 S.CER C1608 JB 1H 102K-T T 16.4/83.2
C111 4030011600 S.CER C1608 JB 1E 104K-T T 19.8/3.1
C112 4030011600 S.CER C1608 JB 1E 104K-T T 7.4/16.4
C113 4030007090 S.CER C1608 CH 1H 470J-T T 23.1/37.2
C114 4030006860 S.CER C1608 JB 1H 102K-T T 23.1/35.9
C115 4030006990 S.CER C1608 CH 1H 080D-T T 44.6/49.4
C117 4030006970 S.CER C1608 CH 1H 060D-T T 44/47.2
C119 4030009530 S.CER C1608 CH 1H 030B-T T 44/44
C120 4030007090 S.CER C1608 CH 1H 470J-T T 51/46
C121 4030006850 S.CER C1608 JB 1H 471K-T T 51/47.4
C122 4030006950 S.CER C1608 CH 1H 040C-T T 40.8/49.4
C124 4030009530 S.CER C1608 CH 1H 030B-T T 41.6/47.2
C125 4030009500 S.CER C1608 CH 1H 0R5B-T T 40/44.2
C126 4030009520 S.CER C1608 CH 1H 020B-T T 41.6/44.2
C127 4030007090 S.CER C1608 CH 1H 470J-T T 34.4/40.4
C128 4030006850 S.CER C1608 JB 1H 471K-T T 35.7/40.4
C129 4030006850 S.CER C1608 JB 1H 471K-T T 50.4/39.6
C130 4030009530 S.CER C1608 CH 1H 030B-T T 72.2/11.8
C131 4030006860 S.CER C1608 JB 1H 102K-T T 74.4/67.2
C132 4030006860 S.CER C1608 JB 1H 102K-T T 42.6/71.8
C135 4030006860 S.CER C1608 JB 1H 102K-T T 17.5/23.8
C136 4030006850 S.CER C1608 JB 1H 471K-T T 82.8/19.6
C137 4030006960 S.CER C1608 CH 1H 050C-T T 58.2/8.8
C138 4030007010 S.CER C1608 CH 1H 100D-T T 56.2/6.8
C139 4030009520 S.CER C1608 CH 1H 020B-T T 55.4/8.8
C140 4030007010 S.CER C1608 CH 1H 100D-T T 53.2/9.6
C141 4030006950 S.CER C1608 CH 1H 040C-T T 54.6/6.8
C142 4030006960 S.CER C1608 CH 1H 050C-T T 46.2/52.6
C143 4030009520 S.CER C1608 CH 1H 020B-T T 48.2/50.4
C144 4030006850 S.CER C1608 JB 1H 471K-T T 44.8/62.6
C145 4030006860 S.CER C1608 JB 1H 102K-T T 12.8/37.8
C146 4030006880 S.CER C1608 JB 1H 472K-T T 14/32.1
C147 4030011600 S.CER C1608 JB 1E 104K-T T 13.5/25.8
C148 4550000460 S.TAN TEESVA 1C 105M8R T 18/26.2
C149 4030007010 S.CER C1608 CH 1H 100D-T T 53.8/26.8
C150 4030006850 S.CER C1608 JB 1H 471K-T T 73.8/30.2
C152 4030006850 S.CER C1608 JB 1H 471K-T T 55.8/10.6
C154 4030006850 S.CER C1608 JB 1H 471K-T T 66.2/4.6
C155 4530000400 S.ARR EZANCE 220M 22P T 11.6/71.5
C156 4530000400 S.ARR EZANCE 220M 22P T 11.6/80
C163 4030006860 S.CER C1608 JB 1H 102K-T T 14.4/41.3
C164 4030007140 S.CER C1608 CH 1H 121J-T T 9/37
C165 4030007140 S.CER C1608 CH 1H 121J-T T 9.2/43
C166 4030006860 S.CER C1608 JB 1H 102K-T T 11.7/41.2
C167 4030007050 S.CER C1608 CH 1H 220J-T T 14.1/39
C168 4030009500 S.CER C1608 CH 1H 0R5B-T T 40/47.2
C169 4030009500 S.CER C1608 CH 1H 0R5B-T T 45.4/47.2
C170 4030009520 S.CER C1608 CH 1H 020B-T T 69/28.2
C171 4030006860 S.CER C1608 JB 1H 102K-T T 63.2/22.6
C172 4030006860 S.CER C1608 JB 1H 102K-T T 42.9/60.4
C173 4030007010 S.CER C1608 CH 1H 100D-T T 19.2/56.6
C174 4030006860 S.CER C1608 JB 1H 102K-T T 19.9/42.7
