Icom IC-7300 User manual

NOTE: Use these amended pages as one addendum set.
Do not mix them up with the previous master pages.
SERVICE MANUAL
ADDENDUM
October 2016
i7 3 0 0
CONTENTS
REPLACEMENT PAGES:
ADJUSTMENT PROCEDURES………………………………………………… 4-5
AMENDED PAGES:
PARTS LIST ………………………………………………………………………… 1
BOARD LAYOUTS ………………………………………………………………… 21
BLOCK DIAGRAMS ……………………………………………………………… 29
SCHEMATIC DIAGRAMS ………………………………………………………… 32

4-5
(Replacement page)
October 2016
4-4 TX POWER ADJUSTMENTS (continued)
ADJUSTMENT ITEM TRANSCEIVER'S CONDITION OPERATION ADJUST
POINT VALUE
TX POWER & POWER
METER SETTING
(70 MHz band)
18 Display: "TX Total 70M Gain"•
Transmit (automatic)•
−
[MAIN
DIAL]
25 W
(A beep sounds, and
then another beeps
sound 0.5 sec. later.)
19 Display: "POWER 70M 1%"•
Transmit (automatic)•
2 W
(A beep sounds, and
then another beeps
sound 0.5 sec. later.)
20 Display: "POWER 70M 10%"•
Transmit (automatic)•
7.5 W
(A beep sounds, and
then another beeps
sound 0.5 sec. later.)
21 Display: "POWER 70M TUNE"•
Transmit (automatic)•
10 W
(A beep sounds, and
then another beeps
sound 0.5 sec. later.)
22 Display: "POWER 70M 50%"•
Transmit (automatic)•
27.5 W
(A beep sounds, and
then another beeps
sound 0.5 sec. later.)
23 Display: "POWER 70M 100%"•
Transmit (automatic)•
52.5 W
(A beep sounds, and
then another beeps
sound 0.5 sec. later.)
AM CARRIER POWER
(70 MHz band)
Only for [#03], [#05],
and [#06]
24 Display: "POWER AM Ratio•
70M"
Transmit (automatic)•
1) Touch [SET ].
(Automatically starts to transmit.)
2) Adjust the TX power by rotating
[MAIN DIAL], and then touch
[SET].
12.5 W
(A beep sounds, and
then another beeps
sound 0.5 sec. later.)
Push [EXIT] to return to the main adjustment menu.•
4-5 TX AMPLIFIER ADJUSTMENTS
• Touch [TX/ID] on the main adjustment menu screen.
NOTE: The transceiver automatically transmits when a TX adjustment item is selected.
ADJUSTMENT ITEM TRANSCEIVER'S CONDITION OPERATION VALUE
PREPARATION 1Display:“TXPOWERSET”•
Receive•
1) Connect the audio generator with
the millivoltmeter to [MIC], and
then set it to;
Frequency: 1.5 kHz
Level: 30 mV rms
2) Connect the power meter to the
antenna connector.
3) Touch [ALC] on the TX adjustment
menu, to enter to the TX amplifier
adjustment mode.
−
ALC METER 2 Display: "ALC HF"•
Transmit (automatic)•
−Touch [SET].
(A beep sounds, and then another
beeps sound 3 sec. later.)
3 Display: "ALC 50M"•
Transmit (automatic)•
Only for [#03], [#05],
and [#06] 4 Display: "ALC 70M"• Transmit (automatic)•
DRIVE AMP GAIN 5 Display: "DRIVE HF"•
Transmit (automatic)•
Touch [SET].
(A beep sounds, and then another
beeps sound 10 sec. later.)
6 Display: "DRIVE 50M"•
Transmit (automatic)•
Touch [SET].
(A beep sounds, and then another
beeps sound 3 sec. later.)
7 Display: "DRIVE 70M"•
Transmit (automatic)•
Touch [SET].
(A beep sounds, and then another
beeps sound 1 sec. later.)
SWR METER 8Display:"SWR2(HF)"•
Transmit (automatic)•
Connect the• 100 Ωdummy load to
the antenna connector.
Touch [SET].
(A beep sounds, and then another
beeps sound 3 sec. later.)
9Display:"SWR2(50M)"•
Transmit (automatic)•
Only for [#03], [#05],
and [#06] 10 Display: "SWR2 (70M)"• Transmit (automatic)•
Id APC 11 D is pl ay : " I D -A PC "•
Transmit (automatic)•
−Touch [SET].
(A beep sounds, and then another
beeps sound 2 sec. later.)
Push [EXIT] to return to the main adjustment menu.•
The underlined parts have been updated from
the previous version of the addendum.

SECTION §PARTS LIST
1
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[MAIN UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
IC121 1130016460 S.IC R2A20169SA T 58.5/64.0
IC125 1110008550 S.IC NJM2904CRB1-TE1-#HMZR T 28.5/70.4
IC135 1110008550 S.IC NJM2904CRB1-TE1-#HMZR T 34.3/73.7
IC141 1130010550 S.IC SN74AHC595PWR T 58.5/53.2
IC151 1110008550 S.IC NJM2904CRB1-TE1-#HMZR T 27.0/77.1
IC201 6910022360 S.DC TPS62110RSAR T 24.9/57.2
IC211 1180004830 S.REG XC6222A331MR-G T 30.0/45.3
IC216 1180004830 S.REG XC6222A331MR-G T 31.6/40.4
IC221 6910024090 S.DC ADP2370ACPZ-R7 T 34.7/51.5
IC231 1180004390 S.REG TLV70025DCKR T 64.2/92.1
IC241 1180004230 S.REG XC6222A321MR-G T 67.1/4.5
IC251 6910022360 S.DC TPS62110RSAR T 16.4/57.2
IC261 6910022360 S.DC TPS62110RSAR T 9.6/44.7
IC271 1180003500 S.REG NJM7808DL1A-TE1-#FZZB T 6.6/15.1
IC276 1180003500 S.REG NJM7808DL1A-TE1-#FZZB T 17.8/9.5
IC301 1140017540 S.IC R7S721000VCFP T 83.0/30.0
IC351 1130016621 S.IC GT24C128B-2ZLI-TR T 109.5/23.5
IC361 1110007780 S.IC NJU7704F3-28A-TE1-#ZZZH T 96.5/10.0
IC371 1110007780 S.IC NJU7704F3-28A-TE1-#ZZZH T 57.3/31.5
IC381 1130018410 S.IC RX-8803LC UB T 105.1/11.0
IC391 1130018090 S.IC EN25QH64A-104HIP T 106.7/43.6
IC611 1180004490 S.REG XC6209F332MR-G T 51.4/172.5
IC 621 119 0002 911 S .IC TU SB2 0 46BIV FRG 4 T 58.0/16 4.5
IC641 1190002730 S.IC CP2102-GMR T 43.1/161.7
IC661 1190002240 S.IC PCM2901E/2K T 55.5/151.0
IC662 1130012260 S.IC SN74AHC1G32DCKR T 51.5/157.4
IC681 1130007021 S.IC TC7S66FU (TE85LF) T 39.6/150.7
IC691 1130009581 S.IC TC7W66FU (TE12LF) T 15.3/158.5
IC701 1130018160 S.IC 74VHC04FT (BE) T 19.5/173.5
IC721 1190003450 S.IC MP7741DQ-LF-P T 92.6/159.7
IC791 1110008550 S.IC NJM2904CRB1-TE1-#HMZR T 25.5/176.5
IC901 1140015962 S.IC TMS320C6745DPTPA3 T 87.6/72.5
IC902 1130018080 S.IC EN25QH32A-104HIP T 110.8/84.7
IC961 1180004430 S.REG XC6209F502MR-G T 38.0/160.5
IC971 1110008060 S.IC PCM1754DBQR T 34.5/139.0
IC972 1110008550 S.IC NJM2904CRB1-TE1-#HMZR T 33.5/155.0
IC991 1110008060 S.IC PCM1754DBQR T 51.5/134.9
IC992 1110006570 S.IC TS462CPT T 45.0/144.5
IC1001 1190004280 S.IC PCM1802DBR T 62.1/138.5
IC1002 1110006570 S.IC TS462CPT T 71.3/142.8
IC1003 1130009981 S.IC TC7W53FK (TE85LF) T 72.9/133.7
IC1211 1130 012610 S.IC SN74A H C1GU04D CKR T 50.3/ 93.6
IC1212 1130017950 S.IC SN65LVDS1DBVR T 50.3/97.8
IC1221 1130011930 S.IC SN74LVC1G04DCKR T 69.1/130.8
IC1241 1180004430 S.REG XC6209F502MR-G T 95.6/118.6
I C12 61 111 00 0 919 0 S .I C LTC 6 401I UD - 20 # T RP BF T 10 2. 2 /112 .1
IC1301 1190004340 S.IC LTC2208IUP-14#TRPBF T 86.9/106.8
IC1315 1130017950 S.IC SN65LVDS1DBVR T 76.7/130.4
IC1318 1180002020 S.REG BA033FP-E2 T 102.6/101.8
IC1321 1180004490 S.REG XC6209F332MR-G T 88.2/129.1
IC1325 1180004490 S.REG XC6209F332MR-G T 70.2/86.9
IC1331 1190004300 S.IC ISL5857IAZ T 72.9/123.6
IC1351 1130016150 S.IC EP4CE55F23I7N T 50.0/113.0
IC1401 1130018130 S.IC 23LC1024T-I/SN T 31.9/126.7
Q45 1530004210 S.TRA DSC7004S0L T 15.1/74.3
Q111 1550000260 S.FET RZR040P01TL T 73.5/7.5
Q112 1590004690 S.TRA LDTC143ZET1G T 67.0/7.5
Q641 1590004690 S.TRA LDTC143ZET1G T 44.6/168.0
Q642 1590004690 S.TRA LDTC143ZET1G T 42.3/167.3
Q643 1590004690 S.TRA LDTC143ZET1G T 56.7/172.7
Q644 1590004310 S.TRA LDTA114EET1G T 45.2/155.2
Q645 1590004310 S.TRA LDTA114EET1G T 41.0/155.2
Q661 1590004690 S.TRA LDTC143ZET1G T 54.3/158.2
Q691 1530004140 S.TRA L2SC4081RT1G T 23.0/159.3
Q692 1510001200 S.TRA L2SA1576ART1G T 20.5/167.1
Q711 1530004140 S.TRA L2SC4081RT1G T 20.5/159.3
Q712 1510001200 S.TRA L2SA1576ART1G T 23.0/167.1
Q746 1550000240 S.FET TPCF8107 (TE85LF) T 105.5/171.8
Q747 1560001730 S.FET RUE002N02 TL T 102.0/167.9
Q801 1590004310 S.TRA LDTA114EET1G T 29.1/159.7
Q802 1530004140 S.TRA L2SC4081RT1G T 27.1/156.5
Q803 1530004210 S.TRA DSC7004S0L T 29.0/166.5
Q821 1530004140 S.TRA L2SC4081RT1G T 24.5/183.0
Q831 1590004690 S.TRA LDTC143ZET1G T 24.5/186.4
Q851 1590004310 S.TRA LDTA114EET1G T 15.6/164.5
Q852 1590004690 S.TRA LDTC143ZET1G T 18.1/164.5
Q971 1530004140 S.TRA L2SC4081RT1G T 33.1/161.3
Q972 1530004140 S.TRA L2SC4081RT1G T 30.6/151.0
Q1001 1590004690 S.TRA LDTC143ZET1G T 71.5/136.9
Q1201 1530004340 S.TRA 2SC3356L-B-AE3-R T 49.0/85.0
Eqv. 1530004560 S.TRA 2SC3356G-B-AE2-R
Q1202 1510001200 S.TRA L2SA1576ART1G T 53.0/85.0
Q1231 1590004690 S.TRA LDTC143ZET1G T 96.5/122.5
Q1232 1590004310 S.TRA LDTA114EET1G T 96.1/124.8
Q1234 1590004690 S.TRA LDTC143ZET1G T 94.2/122.5
Q1235 1590004310 S.TRA LDTA114EET1G T 92.1/124.8
Q1273 1590004690 S.TRA LDTC143ZET1G T 82.8/95.3
Q1274 1590004310 S.TRA LDTA114EET1G T 85.1/95.3
D151 1750001810 S.DIO L1SS400T1G T 23.6/75.8
D152 1750001810 S.DIO L1SS400T1G T 29.4/74.8
D241 1750002110 S.DIO LRB551V-30T1G T 64.7/7.5
D381 1750001810 S.DIO L1SS400T1G T 100.5/8.9
D401 1750001810 S.DIO L1SS400T1G T 107.2/28.6
D402 1750001810 S.DIO L1SS400T1G T 109.7/28.6
(Amended page)
October 2016
D403 1750001810 S.DIO L1SS400T1G T 112.2/28.6
D404 1750001810 S.DIO L1SS400T1G Only [#12] T 107.2/29.8
D405 1750001810 S.DIO L1SS400T1G T 109.7/29.8
D407 1750001810 S.DIO L1SS400T1G [#05] T 107.2/31.0
1750001810 S.DIO L1SS400T1G [#06]
1750001810 S.DIO L1SS400T1G [#07]
1750001810 S.DIO L1SS400T1G [#08]
D408 1750001810 S.DIO L1SS400T1G T 109.7/31.0
D410 1750001810 S.DIO L1SS400T1G [#03] T 107.2/32.2
1750001810 S.DIO L1SS400T1G [#07]
1750001810 S.DIO L1SS400T1G [#08]
D411 1750001810 S.DIO L1SS400T1G T 109.7/32.2
D413 1750001810 S.DIO L1SS400T1G [#02] T 107.2/33.4
1750001810 S.DIO L1SS400T1G [#06]
1750001810 S.DIO L1SS400T1G [#08]
1750001810 S.DIO L1SS400T1G [#12]
D414 1750001810 S.DIO L1SS400T1G T 109.7/33.4
D416 1750001810 S.DIO L1SS400T1G T 107.2/34.6
D417 1750001810 S.DIO L1SS400T1G [#03] T 109.7/34.6
1750001810 S.DIO L1SS400T1G [#05]
1750001810 S.DIO L1SS400T1G [#06]
D419 1750001810 S.DIO L1SS400T1G T 107.2/35.8
D422 1750001810 S.DIO L1SS400T1G T 107.2/37.0
D431 1750001820 S.DIO LRB706F-40T1G T 63.7/47.6
D432 1750001820 S.DIO LRB706F-40T1G T 66.3/47.6
D451 1750001820 S.DIO LRB706F-40T1G T 51.0/30.6
D452 1750001820 S.DIO LRB706F-40T1G T 53.5/30.6
D453 1750001820 S.DIO LRB706F-40T1G T 48.5/30.6
D454 1750001820 S.DIO LRB706F-40T1G T 46.0/30.6
D455 1750001820 S.DIO LRB706F-40T1G T 53.3/35.7
D456 1750001820 S.DIO LRB706F-40T1G T 50.8/35.7
D457 1750001820 S.DIO LRB706F-40T1G T 48.3/35.7
D458 1750001820 S.DIO LRB706F-40T1G T 45.8/35.7
D621 1750001820 S.DIO LRB706F-40T1G T 66.4/172.7
D622 1750001820 S.DIO LRB706F-40T1G T 62.1/172.7
D691 1750001810 S.DIO L1SS400T1G T 21.1/162.2
D711 1750001810 S.DIO L1SS400T1G T 22.4/162.2
D721 1750002130 S.ZEN DZ2J062M0L T 93.7/154.8
D722 1750001810 S.DIO L1SS400T1G T 90.6/154.8
D801 1750001810 S.DIO L1SS400T1G T 27.1/162.5
D821 1750001810 S.DIO L1SS400T1G T 29.4/183.0
D841 1750001820 S.DIO LRB706F-40T1G T 15.5/178.2
D851 1750001820 S.DIO LRB706F-40T1G T 15.5/168.5
D1231 1790001621 S.DIO 1SV308 (TPL3F) T 107.7/123.7
Eqv. 1790001622 S.DIO 1SV308L3F
D1232 1790001621 S.DIO 1SV308 (TPL3F) T 104.9/129.4
Eqv. 1790001622 S.DIO 1SV308L3F
D1251 1750003070 S.DIO BAP70Q T 105.6/118.7
D1273 1790001621 S.DIO 1SV308 (TPL3F) T 97.0/108.2
Eqv. 1790001622 S.DIO 1SV308L3F
FI1221 2010002660 S.XTA FL-391 (124.032 MHz) T 63.6/128.2
X301 6050014170 S.XTA CR-1017 (48.000 MHz) T 60.6/24.4
X621 6050014180 S.XTA CR-1019 (6.000 MHz) T 67.4/163.7
X661 6050014190 S. XTA CR-1020 (12.00 0 MHz) T 54.9/141.8
X901 6050014200 S.XTA CR-1021 (12.288 MHz) T 107.2/66.4
X1201 6050013360 S.XTA CR-932 (41.344 MHz) T 50.0/78.2
L221 6200014470 S.COI LQH44PN100MP0L T 35.2/45.0
L222 6190002110 S.COI 7E03LA-2R7N-RB-0231 T 33.4/55.5
L251 6180003501 S.COI SLF6028T-100M1R3-PF T 16.1/51.2
L252 6200014470 S.COI LQH44PN100MP0L T 14.1/41.6
L261 6200014470 S.COI LQH44PN100MP0L T 5.1/42.4
L262 6180003501 S.COI SLF6028T-100M1R3-PF T 9.1/50.8
L263 6200014470 S.COI LQH44PN100MP0L T 9.1/58.6
L721 6200014460 S.COI SLF12555T-680M1R3-PF T 80.0/156.5
L731 6200014430 S.COI YC12575T*330MS T 95.5/145.8
L732 6200014430 S.COI YC12575T*330MS T 104.9/159.0
L1231 6200016010 S.COI NLFV25T-101K-PF T 101.1/123.4
L1232 6200016010 S.COI NLFV25T-101K-PF T 104.7/121.9
L1233 6200016010 S.COI NLFV25T-101K-PF T 101.8/127.7
L1251 6200016010 S.COI NLFV25T-101K-PF T 110.7/122.1
L1252 6200016010 S.COI NLFV25T-101K-PF T 110.7/119.6
L1253 6200016010 S.COI NLFV25T-101K-PF T 110.7/117.1
L1261 6140004680 S.COI LR-528 4KBL T 109.2/111.1
L1273 6200011410 S.COI C2520C-82NG-A T 96.7/110.8
L1281 6200011680 S.COI LQW18ANR12G00D T 97.2/129.4
L1282 6200011680 S.COI LQW18ANR12G00D T 95.2/128.7
L1331 6140005470 S.COI LR-592 4KBL-S130709 T 86.5/122.7
R4 7030004980 S.RES ERJ2GEJ 101 X (100) T 22.3/90.7
R10 7030004980 S.RES ERJ2GEJ 101 X (100) T 22.3/96.1
R12 7030004980 S.RES ERJ2GEJ 101 X (100) T 22.3/97.9
R13 7030004980 S.RES ERJ2GEJ 101 X (100) T 22.3/98.8
R15 7030004980 S.RES ERJ2GEJ 101 X (100) T 21.7/100.6
R16 7030009530 S.RES ERJ2GEJ 270 X (27) T 21.7/101.5
R17 7030009530 S.RES ERJ2GEJ 270 X (27) T 21.7/102.4
R18 7030009530 S.RES ERJ2GEJ 270 X (27) T 21.7/103.3
R24 7030004980 S.RES ERJ2GEJ 101 X (100) T 23.6/127.6
R25 7030004980 S.RES ERJ2GEJ 101 X (100) T 23.6/126.7
R26 7030009530 S.RES ERJ2GEJ 270 X (27) T 23.6/125.8
R27 7030009530 S.RES ERJ2GEJ 270 X (27) T 23.6/124.9
R28 7030004980 S.RES ERJ2GEJ 101 X (100) T 23.6/124.0

2
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[MAIN UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
R29 7030009530 S.RES ERJ2GEJ 270 X (27) T 23.6/123.1
R30 7030004980 S.RES ERJ2GEJ 101 X (100) T 23.2/122.2
R31 7030004980 S.RES ERJ2GEJ 101 X (100) T 22.8/121.3
R40 7030004980 S.RES ERJ2GEJ 101 X (100) T 35.0/78.4
R41 7030004980 S.RES ERJ2GEJ 101 X (100) T 34.4/80.0
R45 7030005000 S.RES ERJ2GEJ 471 X (470) T 15.8/77.3
R53 7030004980 S.RES ERJ2GEJ 101 X (100) T 13.3/31.4
R54 7030004980 S.RES ERJ2GEJ 101 X (100) T 13.3/30.5
R55 7030004980 S.RES ERJ2GEJ 101 X (100) T 13.3/29.6
R56 7030004980 S.RES ERJ2GEJ 101 X (100) T 13.3/28.7
R57 7030004980 S.RES ERJ2GEJ 101 X (100) T 13.3/27.8
R64 7030004980 S.RES ERJ2GEJ 101 X (100) T 14.3/19.1
R71 7030004980 S.RES ERJ2GEJ 101 X (100) T 25.8/13.0
R72 7030004980 S.RES ERJ2GEJ 101 X (100) T 26.3/7.0
R73 7030004980 S.RES ERJ2GEJ 101 X (100) T 26.8/13.0
R74 7030004980 S.RES ERJ2GEJ 101 X (100) T 27.3/7.0
R75 7030009530 S.RES ERJ2GEJ 270 X (27) T 28.3/16.3
R78 7030004980 S.RES ERJ2GEJ 101 X (100) T 29.3/6.3
R79 7030010040 S.RES ERJ2GEJ-JPW T 29.9/16.3
R80 7030009530 S.RES ERJ2GEJ 270 X (27) T 30.4/3.9
R81 7030009530 S.RES ERJ2GEJ 270 X (27) T 31.1/16.3
R82 7030009530 S.RES ERJ2GEJ 270 X (27) T 31.6/3.9
R83 7030009530 S.RES ERJ2GEJ 270 X (27) T 32.3/16.3
R84 7030009530 S.RES ERJ2GEJ 270 X (27) T 32.8/3.9
R85 7030009530 S.RES ERJ2GEJ 270 X (27) T 33.5/16.3
R86 7030009530 S.RES ERJ2GEJ 270 X (27) T 34.0/3.9
R87 7030009530 S.RES ERJ2GEJ 270 X (27) T 34.7/16.3
R88 7030009530 S.RES ERJ2GEJ 270 X (27) T 35.2/3.9
R89 7030009530 S.RES ERJ2GEJ 270 X (27) T 35.9/16.3
R90 7030009530 S.RES ERJ2GEJ 270 X (27) T 36.4/3.9
R91 7030009530 S.RES ERJ2GEJ 270 X (27) T 37.1/16.3
R92 7030009530 S.RES ERJ2GEJ 270 X (27) T 37.6/3.9
R93 7030009530 S.RES ERJ2GEJ 270 X (27) T 38.3/16.3
R94 7030009530 S.RES ERJ2GEJ 270 X (27) T 38.8/3.9
R95 7030009530 S.RES ERJ2GEJ 270 X (27) T 39.5/16.3
R101 7030004980 S.RES ERJ2GEJ 101 X (100) T 80.1/4.3
R102 7030004980 S.RES ERJ2GEJ 101 X (100) T 80.2/10.1
R103 7030009530 S.RES ERJ2GEJ 270 X (27) T 81.1/4.3
R104 7030009530 S.RES ERJ2GEJ 270 X (27) T 82.0/10.1
R105 7030009530 S.RES ERJ2GEJ 270 X (27) T 83.7/10.1
R107 7030009530 S.RES ERJ2GEJ 270 X (27) T 84.1/4.3
R108 7030009530 S.RES ERJ2GEJ 270 X (27) T 87.1/8.5
R109 7030009530 S.RES ERJ2GEJ 270 X (27) T 85.1/4.3
R110 7410001340 S.ARR EXB28V473JX T 76.5/7.5
R111 7410001340 S. ARR E X B28V473JX T 9 0.8 /10.1
R112 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 69.8/7.5
R113 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 68.8/7.5
R121 7410001230 S.ARR EXB28V101JX T 52.7/66.5
R122 7410001230 S.ARR EXB28V101JX T 52.6/63.4
R123 7410001230 S.ARR EXB28V101JX T 52.6/60.9
R125 7030004980 S.RES ERJ2GEJ 101 X (100) T 26.1/68.6
R127 7030004980 S.RES ERJ2GEJ 101 X (100) T 30.8/68.3
R131 7030006610 S.RES ERJ2GEJ 394 X (390 k) T 25.4/70.1
R132 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 24.5/71.0
R133 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 25.4/71.8
R134 7030004980 S.RES ERJ2GEJ 101 X (100) T 24.2/69.6
R135 7030004980 S.RES ERJ2GEJ 101 X (100) T 36.5/74.4
R136 7030004980 S.RES ERJ2GEJ 101 X (100) T 31.9/72.9
R137 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 35.1/70.6
R138 7030004980 S.RES ERJ2GEJ 101 X (100) T 31.8/74.1
R139 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 36.5/75.8
R151 7030004980 S.RES ERJ2GEJ 101 X (100) T 24.7/73.5
R152 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 31.1/76.3
R153 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 31.1/77.9
R154 7030007340 S.RES ERJ2GEJ 153 X (15 k) T 30.2/77.9
R155 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 23.1/77.8
R156 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 23.6/79.9
R157 7030008290 S.RES ERJ2GEJ 183 X (18 k) T 23.1/78.7
R158 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 30.2/76.3
R159 7030004980 S.RES ERJ2GEJ 101 X (100) T 22.5/74.6
R160 7030004980 S.RES ERJ2GEJ 101 X (100) T 27.3/74.8
R202 7030010040 S.RES ERJ2GEJ-JPW T 27.1/60.5
R203 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 26.2/60.5
R204 7030010080 S.RES ERJ2RHD 1003X (100 k) T 23.5/44.7
R205 7030013680 S.RES ERJ2RHD 3902X (39 k) T 23.5/46.3
R221 7030010040 S.RES ERJ2GEJ-JPW T 36.5/49.3
R223 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 34.6/48.4
R225 7030005681 S.RES ERA3YKD 473V (47 k) T 34.7/58.0
R226 7030010080 S.RES ERJ2RHD 1003X (100 k) T 36.7/57.2
R241 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 63.7/4.5
R242 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 63.3/7.6
R243 7030005000 S.RES ERJ2GEJ 471 X (470) T 62.3/7.6
R251 7030010040 S.RES ERJ2GEJ-JPW T 17.1/60.4
R253 7030012260 S.RES ERJ2RKD 4703X (470 k) T 14.0/44.6
R254 7030013680 S.RES ERJ2RHD 3902X (39 k) T 14.0/46.4
R255 7030010080 S.RES ERJ2RHD 1003X (100 k) T 14.0/47.3
R262 7030010040 S.RES ERJ2GEJ-JPW T 7.9/41.5
R263 7030007051 S.RES ERA3YKD 513V (51 k) T 12.5/59.3
R264 7030010040 S.RES ERJ2GEJ-JPW T 12.1/57.3
R265 7030014250 S.RES ERJ2RKF5603X (560 k) T 12.1/56.4
R271 7030014120 S.RES LTR50UZPJ6R8 T 2.6/32.2
R276 7030013960 S.RES LTR50UZPJ100 T 22.3/17.9
R302 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 101.0/22.5
R303 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 101.0/40.0
R304 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 90.0/46.5
R305 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 84.5/49.2
R308 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 82.0/49.2
R309 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 80.8/49.3
R310 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 80.8/48.4
R311 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 70.4/12.0
R312 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 64.0/21.9
R313 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 65.9/24.6
R314 7030009290 S.RES ERJ2GEJ 562 X (5.6 k) T 65.9/28.2
R315 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 65.7/37.4
R317 7030005000 S.RES ERJ2GEJ 471 X (470) T 62.6/23.5
R351 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 104.0/23.5
R352 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 105.0/23.5
R361 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 96.6/12.3
R362 7030005720 S.RES ERJ2GEJ 563 X (56 k) T 92.7/10.0
R363 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 93.7/10.0
R371 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 55.3/31.1
R372 7030005070 S.RES ERJ2GEJ 683 X (68 k) T 57.5/28.7
R373 7030009290 S.RES ERJ2GEJ 562 X (5.6 k) T 55.7/29.7
R382 7030007300 S.RES ERJ2GEJ 332 X (3.3 k) T 100.1/7.6
R383 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 100.1/9.9
R384 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 100.1/10.8
R385 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 100.1/11.7
R391 7410001340 S.ARR EXB28V473JX T 108.8/39.3
R392 7410001340 S.ARR EXB28V473JX T 100.6/43.9
R401 7410001340 S.ARR EXB28V473JX T 107.2/26.5
R431 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 64.1/50.5
R432 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 68.0/49.0
R433 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 65.8/49.6
R434 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 64.1/49.6
R435 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 90.1/50.2
R437 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 91.0/50.2
R438 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 99.3/42.0
R439 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 101.0/21.5
R441 7410001220 S.ARR EXB28V103JX T 86.6/49.3
R442 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 65.9/52.9
R451 7410001130 S.ARR EXB28V102JX T 54.8/40.0
R452 7410001340 S.ARR EXB28V473JX T 54.8/43.7
R453 7410001130 S.ARR EXB28V102JX T 52.3/40.0
R454 7410001130 S.ARR EXB28V102JX T 52.3/43.7
R455 7030013140 S.RES ERJ2RKF 1001X (1 k) T 50.5/41.9
R456 7030012490 S.RES ERJ2RKF 4701X (4.7 k) T 50.5/40.1
R491 7410001220 S.ARR EXB28V103JX T 104.6/16.3
R492 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 104.6/14.5
R493 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 112.4/16.7
R501 7410001140 S.ARR EXB28V104JX T 78.7/51.7
R502 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 67.5/52.9
R503 7410001140 S.ARR EXB28V104JX T 74.8/51.4
R504 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 84.5/51.4
R505 7410001140 S.ARR EXB28V104JX T 72.2/51.4
R506 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 98.7/44.0
R507 7410001140 S.ARR EXB28V104JX T 91.2/52.1
R508 7410001140 S.ARR EXB28V104JX T 98.7/51.9
R511 7030007250 S.RES ERJ2GEJ 220 X (22) T 95.4/52.5
R512 7030007250 S.RES ERJ2GEJ 220 X (22) T 96.3/52.5
R601 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 58.5/173.5
R621 7030009530 S.RES ERJ2GEJ 270 X (27) T 64.3/172.7
R622 7030009530 S.RES ERJ2GEJ 270 X (27) T 60.0/172.7
R623 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 58.5/172.5
R624 7030005030 S.RES ERJ2GEJ 152 X (1.5 k) T 64.7/170.9
R625 7030005030 S.RES ERJ2GEJ 152 X (1.5 k) T 64.1/163.6
R626 7030005160 S.RES ERJ2GEJ 105 X (1 M) T 64.1/165.4
R627 7030007340 S.RES ERJ2GEJ 153 X (15 k) T 50.1/166.0
R628 7030007340 S.RES ERJ2GEJ 153 X (15 k) T 50.1/164.0
R629 7030009530 S.RES ERJ2GEJ 270 X (27) T 51.5/165.5
R630 7030009530 S.RES ERJ2GEJ 270 X (27) T 51.5/164.5
R631 7030009530 S.RES ERJ2GEJ 270 X (27) T 59.0/158.0
R632 7030007340 S.RES ERJ2GEJ 153 X (15 k) T 58.5/156.6
R633 7030009530 S.RES ERJ2GEJ 270 X (27) T 60.0/158.0
R634 7030007340 S.RES ERJ2GEJ 153 X (15 k) T 60.4/156.6
R635 7030005030 S.RES ERJ2GEJ 152 X (1.5 k) T 54.3/156.6
R641 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 44.6/166.2
R642 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 44.6/165.2
R643 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 41.0/158.2
R644 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 45.2/158.2
R645 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 55.1/172.3
R646 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 40.7/167.3
R647 7030007250 S.RES ERJ2GEJ 220 X (22) T 43.6/154.3
R648 7030007250 S.RES ERJ2GEJ 220 X (22) T 42.6/154.3
R649 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 45.2/153.4
R650 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 42.6/152.5
R651 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 42.6/156.1
R652 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 43.6/156.1
R653 7030007250 S.RES ERJ2GEJ 220 X (22) T 45.2/157.0
R654 7030007250 S.RES ERJ2GEJ 220 X (22) T 41.0/157.0
R661 7030005160 S.RES ERJ2GEJ 105 X (1 M) T 49.7/160.3
R662 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 54.0/143.9
R663 7030005160 S.RES ERJ2GEJ 105 X (1 M) T 54.0/144.9
R664 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 49.7/159.3
R681 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 39.6/147.4
R682 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 41.4/148.9
R683 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 42.7/150.3
R684 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 41.7/150.3
R685 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 39.6/152.5
R686 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) T 39.6/153.5
R687 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 37.1/153.2
R691 7030008290 S.RES ERJ2GEJ 183 X (18 k) T 19.8/163.9
R692 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 20.5/165.1
R693 7030008010 S.RES ERJ2GEJ 123 X (12 k) T 23.3/157.2
R694 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 18.1/168.5
R695 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 17.5/159.4
R696 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 14.4/161.9
R711 7030008290 S.RES ERJ2GEJ 183 X (18 k) T 23.5/163.7
R712 7030008010 S.RES ERJ2GEJ 123 X (12 k) T 20.1/157.2
R713 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 23.0/165.1
R714 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 18.1/167.6
R715 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 18.3/155.4
R716 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 20.5/155.4
R717 7030007250 S.RES ERJ2GEJ 220 X (22) T 20.3/153.8
R718 7030007250 S.RES ERJ2GEJ 220 X (22) T 18.3/153.8
R721 7030007340 S.RES ERJ2GEJ 153 X (15 k) T 89.0/157.5
R722 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 89.4/159.5
R723 7030007160 S.RES ERJ12YJ3R3U (3.3) T 76.5/166.1
R724 7030007160 S.RES ERJ12YJ3R3U (3.3) T 72.4/166.1
(Amended page)
October 2016

3
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[MAIN UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
R725 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 95.7/157.0
R726 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 89.4/161.1
R727 7030008290 S.RES ERJ2GEJ 183 X (18 k) T 89.3/155.9
R729 7030005600 S.RES ERJ2GEJ 273 X (27 k) T 90.2/163.9
R730 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 92.9/163.7
R731 7030005530 S.RES ERJ2GEJ 100 X (10) T 96.2/155.8
R732 7030005530 S.RES ERJ2GEJ 100 X (10) T 97.3/161.3
R733 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) T 111.5/168.2
R746 7030005110 S.RES ERJ2GEJ 224 X (220 k) T 105.5/168.4
R747 7030005110 S.RES ERJ2GEJ 224 X (220 k) T 103.9/168.4
R748 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 99.2/168.1
R749 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 104.7/174.0
R750 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 102.8/169.3
R751 7030007280 S.RES ERJ2GEJ 331 X (330) T 104.7/176.0
R761 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 90.9/173.6
R790 7030010080 S.RES ERJ2RHD 1003X (100 k) T 22.9/179.7
R791 7030004980 S.RES ERJ2GEJ 101 X (100) T 27.1/174.3
R792 7030010080 S.RES ERJ2RHD 1003X (100 k) T 21.7/180.2
R793 7030005080 S.RES ERJ2GEJ 823 X (82 k) T 22.4/178.7
R794 7030012270 S.RES ERJ2RKD 1203X (120 k) T 24.5/179.7
R795 7030004980 S.RES ERJ2GEJ 101 X (100) T 24.5/178.7
R796 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 29.4/175.0
R797 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 29.4/176.0
R798 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 29.4/177.0
R799 7030005000 S.RES ERJ2GEJ 471 X (470) T 29.4/178.0
R801 7030007270 S.RES ERJ2GEJ 151 X (150) T 29.1/161.5
R802 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 29.1/155.6
R803 7030007340 S.RES ERJ2GEJ 153 X (15 k) T 27.1/158.6
R804 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 29.1/162.5
R805 7030005060 S.RES ERJ2GEJ 333 X (33 k) T 27.1/159.6
R806 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 27.1/160.6
R811 7030009140 S.RES ERJ2GEJ 272 X (2.7 k) T 37.6/154.4
R812 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 38.5/155.3
R821 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 24.5/181.0
R822 7030007340 S.RES ERJ2GEJ 153 X (15 k) T 22.4/183.0
R823 7030005060 S.RES ERJ2GEJ 333 X (33 k) T 24.5/184.8
R824 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 27.0/184.0
R831 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 29.4/186.0
R841 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 19.8/179.2
R842 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 18.0/178.2
R843 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 19.8/178.2
R851 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 15.5/176.4
R852 7030005160 S.RES ERJ2GEJ 105 X (1 M) T 16.2/171.0
R853 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 18.0/166.2
R901 7030005160 S.RES ERJ2GEJ 105 X (1 M) T 104.2/67.0
R902 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 102.8/68.3
R905 7030007250 S.RES ERJ2GEJ 220 X (22) T 104.7/76.0
R906 7030007250 S.RES ERJ2GEJ 220 X (22) T 104.8/76.9
R907 7030007250 S.RES ERJ2GEJ 220 X (22) T 104.8/78.2
R908 7030007250 S.RES ERJ2GEJ 220 X (22) T 102.8/82.4
R909 7030007250 S.RES ERJ2GEJ 220 X (22) T 102.8/83.3
R910 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 105.1/67.0
R912 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 99.0/88.4
R913 7030008290 S.RES ERJ2GEJ 183 X (18 k) T 93.5/87.7
R914 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 99.0/87.4
R915 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 90.4/89.6
R916 7030008290 S.RES ERJ2GEJ 183 X (18 k) T 90.5/87.7
R917 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 92.4/87.7
R921 7410001240 S.ARR EXB28V220JX T 97.2/90.1
R922 7410001230 S.ARR EXB28V101JX T 95.1/55.0
R923 7030007250 S.RES ERJ2GEJ 220 X (22) T 91.7/90.1
R924 7410001230 S.ARR EXB28V101JX T 91.2/55.3
R925 7410001230 S.ARR EXB28V101JX T 88.7/55.3
R926 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 108.6/91.5
R927 7410001240 S.ARR EXB28V220JX T 110.4/91.6
R928 7410001230 S.ARR EXB28V101JX T 81.1/55.4
R929 7030007250 S.RES ERJ2GEJ 220 X (22) T 110.2/78.9
R930 7030007250 S.RES ERJ2GEJ 220 X (22) T 108.9/78.9
R932 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 94.4/89.5
R933 7030008290 S.RES ERJ2GEJ 183 X (18 k) T 88.1/88.2
R935 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 89.6/87.7
R971 7410001240 S.ARR EXB28V220JX T 38.8/137.3
R972 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 35.3/158.5
R973 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 35.7/155.0
R974 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 34.1/150.5
R975 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 33.6/149.1
R976 7030004980 S.RES ERJ2GEJ 101 X (100) T 32.0/159.0
R977 7030004980 S.RES ERJ2GEJ 101 X (100) T 31.1/152.8
R978 7030013680 S.RES ERJ2RHD 3902X (39 k) T 33.5/158.5
R979 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 32.7/151.0
R980 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 33.5/159.4
R981 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 30.6/149.2
R982 7030004980 S.RES ERJ2GEJ 101 X (100) T 31.3/157.4
R991 7410001240 S.ARR EXB28V220JX T 55.5/134.8
R992 7030004980 S.RES ERJ2GEJ 101 X (100) T 40.5/143.4
R993 7030009270 S.RES ERJ2GEJ 821 X (820) T 44.1/138.7
R994 7030008410 S.RES ERJ2GEJ 392 X (3.9 k) T 48.6/139.2
R995 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 43.9/141.0
R996 7030008010 S.RES ERJ2GEJ 123 X (12 k) T 46.2/141.1
R997 7030005210 S.RES ERJ2GEJ 822 X (8.2 k) T 42.3/141.0
R998 7030008410 S.RES ERJ2GEJ 392 X (3.9 k) T 48.0/141.1
R999 7030004980 S.RES ERJ2GEJ 101 X (100) T 41.7/142.2
R1000 7030004980 S.RES ERJ2GEJ 101 X (100) T 48.0/142.1
R1001 7410001240 S.ARR EXB28V220JX T 57.0/137.3
R1002 7030007250 S.RES ERJ2GEJ 220 X (22) T 57.0/139.1
R1003 7030004980 S.RES ERJ2GEJ 101 X (100) T 68.4/144.8
R1004 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 67.0/137.2
R1005 7030008290 S.RES ERJ2GEJ 183 X (18 k) T 74.1/139.6
R1006 7030008290 S.RES ERJ2GEJ 183 X (18 k) T 74.1/140.5
R1007 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 67.7/147.6
R1008 7030008010 S.RES ERJ2GEJ 123 X (12 k) T 68.4/138.2
R1009 7030007570 S.RES ERJ2GEJ 122 X (1.2 k) T 68.7/147.6
R1010 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 74.1/138.7
R1011 7030007340 S.RES ERJ2GEJ 153 X (15 k) T 70.2/138.2
R1012 7030005070 S.RES ERJ2GEJ 683 X (68 k) T 70.7/147.6
R1013 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 69.7/136.7
R1015 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 71.7/147.6
R1016 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 73.2/136.5
R1017 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 75.4/136.2
R1018 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 76.4/136.2
R1019 7030008290 S.RES ERJ2GEJ 183 X (18 k) T 74.4/136.2
R1020 7030010040 S.RES ERJ2GEJ-JPW T 77.4/136.2
R1021 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 71.2/148.9
R1022 7030004990 S.RES ERJ2GEJ 221 X (220) T 62.0/152.8
R1201 7030005060 S.RES ERJ2GEJ 333 X (33 k) T 51.6/75.3
R1202 7030005720 S.RES ERJ2GEJ 563 X (56 k) T 51.6/76.2
R1203 7030005070 S.RES ERJ2GEJ 683 X (68 k) T 50.4/75.8
R1204 7030007340 S.RES ERJ2GEJ 153 X (15 k) T 46.8/85.0
R1205 7030008290 S.RES ERJ2GEJ 183 X (18 k) T 49.0/82.8
R1206 7030005000 S.RES ERJ2GEJ 471 X (470) T 50.8/82.8
R1207 7030004990 S.RES ERJ2GEJ 221 X (220) T 51.2/84.1
R1211 7030004970 S.RES ERJ2GEJ 470 X (47) T 52.0/90.1
R1212 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 52.0/93.7
R1213 7030004970 S.RES ERJ2GEJ 470 X (47) T 50.6/95.6
R1221 7030004970 S.RES ERJ2GEJ 470 X (47) T 60.0/128.1
R1222 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 69.6/129.1
R1223 7030004980 S.RES ERJ2GEJ 101 X (100) T 65.0/130.9
R1224 7030010040 S.RES ERJ2GEJ-JPW T 67.2/130.4
R1225 7030004980 S.RES ERJ2GEJ 101 X (100) T 61.2/127.4
R1231 7030012990 S.RES ERJ8GEYJ 561V (560) T 104.6/124.2
R1232 7030009160 S.RES ERJ2GEJ 181 X (180) T 107.2/122.1
R1233 7030009160 S.RES ERJ2GEJ 181 X (180) T 104.1/128.1
R1236 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 93.6/124.5
R1238 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 98.5/124.5
R1251 7030008370 S.RES ERJ2GEJ 561 X (560) T 101.5/118.1
R1252 7030008400 S.RES ERJ2GEJ 182 X (1.8 k) T 103.3/119.9
R1253 7030008400 S.RES ERJ2GEJ 182 X (1.8 k) T 103.3/118.1
R1254 7030008370 S.RES ERJ2GEJ 561 X (560) T 108.1/119.7
R1255 7030010040 S.RES ERJ2GEJ-JPW T 108.1/118.7
R1256 7030008370 S.RES ERJ2GEJ 561 X (560) T 108.1/117.7
R1258 7030007270 S.RES ERJ2GEJ 151 X (150) T 113.6/130.2
R1261 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 103.9/107.7
R1273 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 95.4/107.8
R1274 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 97.3/107.2
R1275 7030007250 S.RES ERJ2GEJ 220 X (22) T 99.7/111.3
R1276 7030007250 S.RES ERJ2GEJ 220 X (22) T 99.7/112.9
R1279 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 87.1/96.2
R1291 7030009320 S.RES ERJ2GEJ 4R7 X (4.7) T 93.2/106.4
R1292 7030009320 S.RES ERJ2GEJ 4R7 X (4.7) T 93.2/107.3
R1302 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 87.5/99.3
R1303 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 88.4/99.3
R1304 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 89.3/99.3
R1308 7030004980 S.RES ERJ2GEJ 101 X (100) T 90.6/101.1
R1313 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 90.4/113.9
R1314 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 92.0/100.9
R1315 7030004990 S.RES ERJ2GEJ 221 X (220) T 92.2/115.1
R1316 7030010040 S.RES ERJ2GEJ-JPW T 93.1/115.1
R1318 7030010260 S.RES ERJ1TYJ 3R3 U T 63.2/88.6
R1319 7030010260 S.RES ERJ1TYJ 3R3 U T 63.2/84.9
R1321 7030004980 S.RES ERJ2GEJ 101 X (100) T 87.7/113.9
R1331 7030011450 S.RES ERJ2RKF 49R9X (49.9) T 81.1/123.6
R1334 7030005710 S.RES ERJ2GEJ 121 X (120) T 78.3/120.0
R1335 7030008400 S.RES ERJ2GEJ 182 X (1.8 k) T 77.8/121.2
R1351 7030004980 S.RES ERJ2GEJ 101 X (100) T 64.7/105.4
R1352 7030004980 S.RES ERJ2GEJ 101 X (100) T 62.9/106.2
R1353 7030004980 S.RES ERJ2GEJ 101 X (100) T 64.7/107.4
R1354 7030004980 S.RES ERJ2GEJ 101 X (100) T 64.7/109.6
R1355 7030004980 S.RES ERJ2GEJ 101 X (100) T 62.9/110.4
R1356 7030004980 S.RES ERJ2GEJ 101 X (100) T 64.7/111.6
R1357 7030004980 S.RES ERJ2GEJ 101 X (100) T 62.9/112.4
R1358 7030004980 S.RES ERJ2GEJ 101 X (100) T 62.9/113.8
R1359 7030004980 S.RES ERJ2GEJ 101 X (100) T 62.9/108.4
R1361 7030004980 S.RES ERJ2GEJ 101 X (100) T 56.8/128.1
R1363 7410001220 S.ARR EXB28V103JX T 68.5/95.8
R1366 7030007250 S.RES ERJ2GEJ 220 X (22) T 57.0/126.5
R1367 7030007250 S.RES ERJ2GEJ 220 X (22) T 52.8/125.5
R1368 7030004980 S.RES ERJ2GEJ 101 X (100) T 74.6/95.1
R1369 7030004980 S.RES ERJ2GEJ 101 X (100) T 74.6/96.0
R1371 7030004980 S.RES ERJ2GEJ 101 X (100) T 50.3/100.0
R1380 7030004980 S.RES ERJ2GEJ 101 X (100) T 62.9/104.2
R1381 7030004980 S.RES ERJ2GEJ 101 X (100) T 64.9/103.4
R1382 7030004980 S.RES ERJ2GEJ 101 X (100) T 66.2/102.5
R1383 7030004980 S.RES ERJ2GEJ 101 X (100) T 64.9/101.1
R1384 7030004980 S.RES ERJ2GEJ 101 X (100) T 66.2/100.3
R1385 7030004980 S.RES ERJ2GEJ 101 X (100) T 64.9/98.9
R1386 7030004980 S.RES ERJ2GEJ 101 X (100) T 52.0/100.0
R1387 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 86.5/94.1
R1388 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 88.1/93.1
R1401 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 28.9/123.7
C1 4030019990 S.CER C1005 JB 1C 104K-T T 21.2/78.7
C2 4030019990 S.CER C1005 JB 1C 104K-T T 22.5/83.3
C3 4030017460 S.CER C1005 JB 1H 102K-T T 24.5/89.8
C4 4030017460 S.CER C1005 JB 1H 102K-T T 24.5/90.7
C6 4030017460 S.CER C1005 JB 1H 102K-T T 24.5/92.5
C8 4030017460 S.CER C1005 JB 1H 102K-T T 24.5/94.3
C9 4030017460 S.CER C1005 JB 1H 102K-T T 24.5/95.2
C10 4030017460 S.CER C1005 JB 1H 102K-T T 24.5/96.1
C11 4030017460 S.CER C1005 JB 1H 102K-T T 24.5/97.0
C12 4030017460 S.CER C1005 JB 1H 102K-T T 24.5/97.9
C13 4030017460 S.CER C1005 JB 1H 102K-T T 24.5/98.8
C14 4030019990 S.CER C1005 JB 1C 104K-T T 23.9/99.7
C15 4030017460 S.CER C1005 JB 1H 102K-T T 23.9/100.6
C16 4030017400 S.CER C1005 CH 1H 220J-T T 23.9/101.5
C17 4030017400 S.CER C1005 CH 1H 220J-T T 25.5/101.2
C18 4030017400 S.CER C1005 CH 1H 220J-T T 24.8/102.7
C19 4030017460 S.CER C1005 JB 1H 102K-T T 24.5/88.9
(Amended page)
October 2016

4
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[MAIN UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
C20 4510010570 S.ELE 16 CE 470 LX T 45.0/41.5
C21 4030019990 S.CER C1005 JB 1C 104K-T T 24.6/131.1
C22 4030019990 S.CER C1005 JB 1C 104K-T T 25.3/129.9
C23 4030019990 S.CER C1005 JB 1C 104K-T T 25.3/128.7
C24 4030017460 S.CER C1005 JB 1H 102K-T T 25.8/127.6
C25 4030017460 S.CER C1005 JB 1H 102K-T T 25.8/126.7
C26 4030017400 S.CER C1005 CH 1H 220J-T T 25.8/125.8
C27 4030017400 S.CER C1005 CH 1H 220J-T T 25.8/124.9
C28 4030017460 S.CER C1005 JB 1H 102K-T T 25.8/124.0
C29 4030017400 S.CER C1005 CH 1H 220J-T T 25.8/123.1
C30 4030017460 S.CER C1005 JB 1H 102K-T T 25.4/122.2
C31 4030017460 S.CER C1005 JB 1H 102K-T T 25.0/121.3
C32 4030017460 S.CER C1005 JB 1H 102K-T T 25.0/120.4
C33 4030017460 S.CER C1005 JB 1H 102K-T T 24.2/119.5
C34 4030017460 S.CER C1005 JB 1H 102K-T T 24.2/118.6
C35 4030017460 S.CER C1005 JB 1H 102K-T T 24.2/117.7
C36 4030017460 S.CER C1005 JB 1H 102K-T T 24.2/116.8
C37 4030017460 S.CER C1005 JB 1H 102K-T T 23.8/115.9
C38 4030017460 S.CER C1005 JB 1H 102K-T T 23.8/115.0
C39 4030017460 S.CER C1005 JB 1H 102K-T T 23.6/114.1
C45 4510010570 S.ELE 16 CE 470 LX T 18.6/67.4
C46 4030019990 S.CER C1005 JB 1C 104K-T T 13.4/70.8
C48 4030016790 S.CER C1005 JB 1E 103K-T T 17.3/76.8
C49 4030019990 S.CER C1005 JB 1C 104K-T T 19.2/75.8
C51 4030019990 S.CER C1005 JB 1C 104K-T T 15.7/35.7
C52 4030019990 S.CER C1005 JB 1C 104K-T T 15.7/33.4
C53 4030017460 S.CER C1005 JB 1H 102K-T T 15.5/31.4
C54 4030017460 S.CER C1005 JB 1H 102K-T T 15.5/30.5
C55 4030017460 S.CER C1005 JB 1H 102K-T T 15.5/29.6
C56 4030017460 S.CER C1005 JB 1H 102K-T T 15.5/28.7
C57 4030017460 S.CER C1005 JB 1H 102K-T T 15.5/27.8
C58 4030017430 S.CER C1005 CH 1H 101J-T T 15.9/25.4
C59 4030017430 S.CER C1005 CH 1H 101J-T T 15.9/24.5
C60 4030017430 S.CER C1005 CH 1H 101J-T T 16.5/23.2
C61 4030017430 S.CER C1005 CH 1H 101J-T T 16.5/22.3
C62 4030017430 S.CER C1005 CH 1H 101J-T T 16.5/21.4
C63 4030017430 S.CER C1005 CH 1H 101J-T T 16.5/20.2
C64 4030017460 S.CER C1005 JB 1H 102K-T T 16.5/19.1
C71 4030017460 S.CER C1005 JB 1H 102K-T T 25.8/15.1
C72 4030017400 S.CER C1005 CH 1H 220J-T T 26.3/4.8
C73 4030017400 S.CER C1005 CH 1H 220J-T T 26.8/15.1
C74 4030017460 S.CER C1005 JB 1H 102K-T T 27.3/4.8
C96 4030019990 S.CER C1005 JB 1C 104K-T T 41.8/17.0
C97 4030019990 S.CER C1005 JB 1C 104K-T T 42.3/3.0
C98 4030019990 S.CER C1005 JB 1C 104K-T T 44.3/2.8
C106 4030019990 S.CER C1005 JB 1C 104K-T T 82.7/4.8
C111 4 03 0019120 S.C ER G RM18 8B 31E105 K A75 D T 71.0 / 7. 5
C121 4030019990 S.CER C1005 JB 1C 104K-T T 61.0/60.0
C122 4030019990 S.CER C1005 JB 1C 104K-T T 57.0/60.0
C125 4030019990 S.CER C1005 JB 1C 104K-T T 27.0/67.7
C135 4030019990 S.CER C1005 JB 1C 104K-T T 36.5/72.8
C141 4030019990 S.CER C1005 JB 1C 104K-T T 59.2/49.7
C151 4030019990 S.CER C1005 JB 1C 104K-T T 25.6/74.9
C201 4030019560 S.CER GRM21BB31C106KE15L T 28.1/55.8
C202 4030019560 S.CER GRM21BB31C106KE15L T 29.9/55.8
C203 4030019120 S.CER GRM188B31E105KA75D T 24.5/60.7
C204 4030019560 S.CER GRM21BB31C106KE15L T 26.1/41.1
C205 4030019560 S.CER GRM21BB31C106KE15L T 26.1/42.9
C206 4030019560 S.CER GRM21BB31C106KE15L T 26.1/44.7
C207 4030019560 S.CER GRM21BB31C106KE15L T 26.1/46.5
C208 4030017620 S.CER C1005 CH 1H 100C-T T 22.6/44.7
C211 4030019120 S.CER GRM188B31E105KA75D T 29.6/47.7
C212 4030019620 S.CER GRM188B31C225KE14D T 32.3/44.9
C216 4030019120 S.CER GRM188B31E105KA75D T 30.6/42.8
C217 4030019620 S.CER GRM188B31C225KE14D T 34.1/40.7
C221 4030019560 S.CER GRM21BB31C106KE15L T 32.0/49.7
C222 4030019560 S.CER GRM21BB31C106KE15L T 30.5/53.2
C223 4030019560 S.CER GRM21BB31C106KE15L T 36.6/55.1
C231 4030019120 S.CER GRM188B31E105KA75D T 66.4/92.3
C232 4030019120 S.CER GRM188B31E105KA75D T 61.1/92.3
C241 4030019120 S.CER GRM188B31E105KA75D T 69.7/4.5
C242 4030019990 S.CER C1005 JB 1C 104K-T T 64.7/4.5
C243 4510010460 ELE DXN-5R5H334U
C251 4030020190 S.CER GRM32EB31C476KE15L T 20.2/57.0
C252 4030019120 S.CER GRM188B31E105KA75D T 15.4/60.5
C253 4030020190 S.CER GRM32EB31C476KE15L T 18.7/46.1
C254 4030020190 S.CER GRM32EB31C476KE15L T 18.7/43.1
C255 4030017620 S.CER C1005 CH 1H 100C-T T 14.0/45.5
C256 4030020190 S.CER GRM32EB31C476KE15L T 18.7/40.1
C257 4510010570 S.ELE 16 CE 470 LX T 36.0/25.7
C261 4030019560 S.CER GRM21BB31C106KE15L T 4.1/46.6
C262 4030019560 S.CER GRM21BB31C106KE15L T 5.9/46.6
C263 4030019120 S.CER GRM188B31E105KA75D T 10.5/41.3
C264 4030019560 S.CER GRM21BB31C106KE15L T 5.3/55.0
C265 4030019560 S.CER GRM21BB31C106KE15L T 4.9/52.3
C266 4030019560 S.CER GRM21BB31C106KE15L T 5.3/58.6
C267 4030019560 S.CER GRM21BB31C106KE15L T 5.3/56.8
C268 4030017620 S.CER C1005 CH 1H 100C-T T 12.1/58.2
C271 4030019560 S.CER GRM21BB31C106KE15L T 2.6/20.9
C272 4030019620 S.CER GRM188B31C225KE14D T 3.9/10.2
C273 4030019990 S.CER C1005 JB 1C 104K-T T 3.6/19.3
C274 4030019990 S.CER C1005 JB 1C 104K-T T 3.6/11.3
C275 4510010570 S.ELE 16 CE 470 LX T 21.0/146.4
C276 4030019560 S.CER GRM21BB31C106KE15L T 18.6/16.6
C277 4030019990 S.CER C1005 JB 1C 104K-T T 19.2/15.2
C278 4030019620 S.CER GRM188B31C225KE14D T 15.3/15.6
C279 4030019990 S.CER C1005 JB 1C 104K-T T 16.5/15.1
C301 4030019560 S.CER GRM21BB31C106KE15L T 66.7/15.4
C302 4030019990 S.CER C1005 JB 1C 104K-T T 101.0/23.5
C303 4030019990 S.CER C1005 JB 1C 104K-T T 101.0/24.5
C304 4030019990 S.CER C1005 JB 1C 104K-T T 101.0/26.7
C305 4030019990 S.CER C1005 JB 1C 104K-T T 101.0/27.6
C306 4030019990 S.CER C1005 JB 1C 104K-T T 101.0/29.7
C307 4030019990 S.CER C1005 JB 1C 104K-T T 101.0/31.4
C308 4030019990 S.CER C1005 JB 1C 104K-T T 101.0/33.2
C309 4030019990 S.CER C1005 JB 1C 104K-T T 101.8/34.1
C310 4030019990 S.CER C1005 JB 1C 104K-T T 101.4/35.7
C311 4030019990 S.CER C1005 JB 1C 104K-T T 101.0/41.1
C312 4030019560 S.CER GRM21BB31C106KE15L T 64.6/44.0
C313 4030019990 S.CER C1005 JB 1C 104K-T T 94.4/12.0
C314 4030019990 S.CER C1005 JB 1C 104K-T T 94.1/47.5
C315 4030019990 S.CER C1005 JB 1C 104K-T T 92.8/47.4
C316 4030019990 S.CER C1005 JB 1C 104K-T T 92.4/12.0
C317 4030019990 S.CER C1005 JB 1C 104K-T T 89.7/12.0
C318 4030019990 S.CER C1005 JB 1C 104K-T T 88.8/47.4
C319 4030019990 S.CER C1005 JB 1C 104K-T T 87.6/12.0
C320 4030019990 S.CER C1005 JB 1C 104K-T T 87.2/47.4
C321 4030019990 S.CER C1005 JB 1C 104K-T T 84.6/47.4
C322 4030019990 S.CER C1005 JB 1C 104K-T T 84.0/12.0
C323 4030019990 S.CER C1005 JB 1C 104K-T T 82.8/47.4
C324 4030019990 S.CER C1005 JB 1C 104K-T T 82.4/12.0
C325 4030019990 S.CER C1005 JB 1C 104K-T T 81.4/47.2
C326 4030019990 S.CER C1005 JB 1C 104K-T T 79.0/12.0
C327 4030019990 S.CER C1005 JB 1C 104K-T T 77.2/12.0
C328 4030019990 S.CER C1005 JB 1C 104K-T T 77.6/47.2
C329 4030019990 S.CER C1005 JB 1C 104K-T T 76.0/47.4
C330 4030019990 S.CER C1005 JB 1C 104K-T T 74.6/12.0
C331 4030019990 S.CER C1005 JB 1C 104K-T T 71.6/12.0
C332 4030019990 S.CER C1005 JB 1C 104K-T T 71.6/47.2
C333 4030019990 S.CER C1005 JB 1C 104K-T T 70.0/47.2
C334 4030019990 S.CER C1005 JB 1C 104K-T T 64.0/19.4
C335 4030019990 S.CER C1005 JB 1C 104K-T T 64.0/20.5
C336 4030019990 S.CER C1005 JB 1C 104K-T T 64.0/22.8
C337 4030019990 S.CER C1005 JB 1C 104K-T T 64.0/23.7
C338 4030019990 S.CER C1005 JB 1C 104K-T T 64.0/26.4
C339 4030019990 S.CER C1005 JB 1C 104K-T T 64.0/27.5
C340 4030019990 S.CER C1005 JB 1C 104K-T T 64.0/28.5
C341 4030019990 S.CER C1005 JB 1C 104K-T T 64.0/29.4
C342 4030019990 S.CER C1005 JB 1C 104K-T T 65.9/31.0
C343 4030019990 S.CER C1005 JB 1C 104K-T T 65.9/32.1
C344 4030019990 S.CER C1005 JB 1C 104K-T T 65.9/33.3
C345 4030019990 S.CER C1005 JB 1C 104K-T T 65.3/34.2
C346 4030019990 S.CER C1005 JB 1C 104K-T T 65.7/36.4
C347 4030017640 S.CER C1005 CH 1H 150J-T T 58.6/25.3
C348 4030017640 S.CER C1005 CH 1H 150J-T T 58.6/23.5
C351 4030019990 S.CER C1005 JB 1C 104K-T T 107.0/21.1
C361 4030021250 S.CER C1005 JB 1A 334K-T T 96.2/7.9
C362 4030019990 S.CER C1005 JB 1C 104K-T T 94.7/10.0
C371 4030017920 S.CER C1005 JB 1A 683K-T T 59.4/31.1
C372 4030019990 S.CER C1005 JB 1C 104K-T T 57.5/29.7
C383 4030019120 S.CER GRM188B31E105KA75D T 103.2/8.3
C391 4030019990 S.CER C1005 JB 1C 104K-T T 106.9/40.2
C401 4030017440 S.CER C1005 CH 1H 221J-T T 62.0/13.8
C402 4030017440 S.CER C1005 CH 1H 221J-T T 66.0/11.8
C403 4030017440 S.CER C1005 CH 1H 221J-T T 62.0/14.8
C404 4030017440 S.CER C1005 CH 1H 221J-T T 66.0/9.8
C405 4030017440 S.CER C1005 CH 1H 221J-T T 62.0/15.8
C406 4030017440 S.CER C1005 CH 1H 221J-T T 62.0/10.8
C407 4030017440 S.CER C1005 CH 1H 221J-T T 80.6/12.0
C408 4030017440 S.CER C1005 CH 1H 221J-T T 62.0/11.8
C409 4030017440 S.CER C1005 CH 1H 221J-T T 66.0/10.8
C410 4030017440 S.CER C1005 CH 1H 221J-T T 62.0/12.8
C411 4030017440 S.CER C1005 CH 1H 221J-T T 76.8/10.8
C412 4030017440 S.CER C1005 CH 1H 221J-T T 75.0/10.8
C413 4030017440 S.CER C1005 CH 1H 221J-T T 76.2/12.0
C414 4030017440 S.CER C1005 CH 1H 221J-T T 72.9/10.2
C415 4030017440 S.CER C1005 CH 1H 221J-T T 73.6/12.0
C416 4030017440 S.CER C1005 CH 1H 221J-T T 71.2/10.6
C418 4030017440 S.CER C1005 CH 1H 221J-T T 66.1/38.9
C419 4030017440 S.CER C1005 CH 1H 221J-T T 65.2/39.2
C420 4030017440 S.CER C1005 CH 1H 221J-T T 65.2/40.8
C421 4030017440 S.CER C1005 CH 1H 221J-T T 66.3/41.1
C451 4030016790 S.CER C1005 JB 1E 103K-T T 47.6/25.2
C452 4030016790 S.CER C1005 JB 1E 103K-T T 48.6/25.2
C453 4030016790 S.CER C1005 JB 1E 103K-T T 51.9/27.3
C454 4030016790 S.CER C1005 JB 1E 103K-T T 52.8/27.3
C455 4030016790 S.CER C1005 JB 1E 103K-T T 49.5/25.2
C456 4030016790 S.CER C1005 JB 1E 103K-T T 49.3/27.3
C457 4030016790 S.CER C1005 JB 1E 103K-T T 51.0/27.3
C458 4030016790 S.CER C1005 JB 1E 103K-T T 53.7/27.3
C461 4030017400 S.CER C1005 CH 1H 220J-T T 78.0/49.3
C462 4030017430 S.CER C1005 CH 1H 101J-T T 78.3/48.4
C463 4030017430 S.CER C1005 CH 1H 101J-T T 76.8/50.2
C464 4030017430 S.CER C1005 CH 1H 101J-T T 76.6/52.0
C604 4030017460 S.CER C1005 JB 1H 102K-T T 56.7/174.5
C611 4030019620 S.CER GRM188B31C225KE14D T 51.4/170.1
C612 4030019120 S.CER GRM188B31E105KA75D T 51.4/174.9
C623 4030019560 S.CER GRM21BB31C106KE15L T 63.4/156.8
C624 4030017650 S.CER C1005 CH 1H 270J-T T 64.1/161.8
C625 4030019990 S.CER C1005 JB 1C 104K-T T 58.5/170.5
C626 4030019990 S.CER C1005 JB 1C 104K-T T 58.5/171.5
C627 4030017650 S.CER C1005 CH 1H 270J-T T 64.1/167.2
C628 4030017400 S.CER C1005 CH 1H 220J-T T 51.5/166.5
C629 4030017400 S.CER C1005 CH 1H 220J-T T 51.5/163.5
C630 4030019990 S.CER C1005 JB 1C 104K-T T 63.3/160.4
C631 4030017400 S.CER C1005 CH 1H 220J-T T 57.9/158.0
C632 4030017400 S.CER C1005 CH 1H 220J-T T 61.0/158.0
C641 4030019120 S.CER GRM188B31E105KA75D T 42.3/165.4
C642 4030019120 S.CER GRM188B31E105KA75D T 48.5/161.9
C643 4030019990 S.CER C1005 JB 1C 104K-T T 47.3/161.9
C661 4030019560 S.CER GRM21BB31C106KE15L T 62.8/148.7
C662 4030019990 S.CER C1005 JB 1C 104K-T T 61.4/148.7
C663 4030019560 S.CER GRM21BB31C106KE15L T 57.6/144.5
C664 4030017650 S.CER C1005 CH 1H 270J-T T 55.8/143.9
C665 4030019560 S.CER GRM21BB31C106KE15L T 45.0/149.2
C666 4030019560 S.CER GRM21BB31C106KE15L T 45.0/151.0
C667 4030019560 S.CER GRM21BB31C106KE15L T 48.0/154.5
C668 4030019560 S.CER GRM21BB31C106KE15L T 48.2/151.0
(Amended page)
October 2016

5
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[MAIN UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
C669 4030019990 S.CER C1005 JB 1C 104K-T T 49.6/151.0
C670 4030017650 S.CER C1005 CH 1H 270J-T T 55.8/144.9
C671 4030019990 S.CER C1005 JB 1C 104K-T T 52.2/145.5
C672 4030019560 S.CER GRM21BB31C106KE15L T 50.8/144.1
C673 4030019560 S.CER GRM21BB31C106KE15L T 50.8/142.3
C674 4030019560 S.CER GRM21BB31C106KE15L T 48.4/147.7
C675 4030019120 S.CER GRM188B31E105KA75D T 49.3/157.4
C676 4030019990 S.CER C1005 JB 1C 104K-T T 51.5/159.3
C681 4030019990 S.CER C1005 JB 1C 104K-T T 38.7/148.9
C682 4030019560 S.CER GRM21BB31C106KE15L T 42.9/147.4
C683 4030019560 S.CER GRM21BB31C106KE15L T 37.1/150.7
C692 4030017460 S.CER C1005 JB 1H 102K-T [#03] T 68.4/185.8
4030017460 S.CER C1005 JB 1H 102K-T [#05]
4030017460 S.CER C1005 JB 1H 102K-T [#06]
C693 4030017620 S.CER C1005 CH 1H 100C-T T 68.4/183.7
C695 4030019990 S.CER C1005 JB 1C 104K-T T 17.5/157.6
C701 4030019990 S.CER C1005 JB 1C 104K-T T 16.2/173.5
C720 4510010570 S.ELE 16 CE 470 LX T 73.9/173.4
C721 4510010570 S.ELE 16 CE 470 LX T 80.5/144.5
C722 4030019120 S.CER GRM188B31E105KA75D T 93.7/156.5
C723 4030019620 S.CER GRM188B31C225KE14D T 90.2/157.6
C724 4030017400 S.CER C1005 CH 1H 220J-T T 96.7/165.0
C725 4030019990 S.CER C1005 JB 1C 104K-T T 90.3/161.4
C726 4030019560 S.CER GRM21BB31C106KE15L T 95.2/160.2
C727 4030019620 S.CER GRM188B31C225KE14D T 91.4/162.7
C728 4030019570 S.CER C1608 CH 1H 332J-T T 94.0/162.7
C731 4030020020 S.CER C1005 CH 1H 391J-T T 96.6/157.0
C732 4030021340 S.CER C1608 JB 1H 474KT ATEX T 96.6/162.7
C733 4030019990 S.CER C1005 JB 1C 104K-T T 96.9/160.1
C734 4030021530 S.CER C1608 JB 1E 224K-T T 96.6/163.9
C735 4 030021530 S.CER C1608 JB 1E 2 24K-T T 111. 5/16 9.4
C741 4510010570 S.ELE 16 CE 470 LX T 107.5/146.7
C746 4030019120 S.CER GRM188B31E105KA75D T 105.5/169.4
C747 4030019990 S.CER C1005 JB 1C 104K-T T 100.4/167.9
C751 4510010570 S.ELE 16 CE 470 LX T 98.5/173.0
C752 4030017430 S.CER C1005 CH 1H 101J-T T 104.7/177.0
C753 4030016790 S.CER C1005 JB 1E 103K-T T 104.7/175.0
C754 4030016790 S.CER C1005 JB 1E 103K-T T 89.2/176.5
C761 4030017460 S.CER C1005 JB 1H 102K-T T 92.3/169.6
C762 4030017460 S.CER C1005 JB 1H 102K-T T 92.3/170.9
C763 4030017460 S.CER C1005 JB 1H 102K-T T 92.3/172.2
C764 4030017460 S.CER C1005 JB 1H 102K-T T 92.3/173.1
C771 4030016790 S.CER C1005 JB 1E 103K-T T 25.3/173.0
C773 4030016790 S.CER C1005 JB 1E 103K-T T 33.0/168.0
C774 4030016790 S.CER C1005 JB 1E 103K-T T 27.1/171.8
C775 4030016790 S.CER C1005 JB 1E 103K-T T 27.1/179.0
C776 4030016790 S.CER C1005 JB 1E 103K-T T 27.0/180.0
C778 4030016790 S.CER C1005 JB 1E 103K-T T 52.6/178.2
C779 4030016790 S.CER C1005 JB 1E 103K-T T 27.0/181.0
C780 4030016790 S.CER C1005 JB 1E 103K-T T 27.0/185.0
C781 4030016790 S.CER C1005 JB 1E 103K-T T 52.3/183.6
C782 4030017460 S.CER C1005 JB 1H 102K-T T 52.3/182.6
C783 4030016790 S.CER C1005 JB 1E 103K-T T 27.0/187.0
C791 4030019990 S.CER C1005 JB 1C 104K-T T 25.3/174.3
C801 4030016790 S.CER C1005 JB 1E 103K-T T 29.1/163.5
C811 4030019620 S.CER GRM188B31C225KE14D T 50.5/180.7
C812 4030019620 S.CER GRM188B31C225KE14D T 51.8/180.7
C901 4030017400 S.CER C1005 CH 1H 220J-T T 109.2/66.1
C902 4550007200 S.TAN F930J476MBABMA T 102.7/58.1
C903 4550007200 S.TAN F930J476MBABMA T 99.4/56.0
C904 4030017400 S.CER C1005 CH 1H 220J-T T 106.8/68.7
C905 4030019990 S.CER C1005 JB 1C 104K-T T 102.8/61.4
C906 4030019990 S.CER C1005 JB 1C 104K-T T 102.8/69.6
C907 4030019990 S.CER C1005 JB 1C 104K-T T 102.8/70.8
C908 4030019990 S.CER C1005 JB 1C 104K-T T 102.8/72.2
C909 4030019990 S.CER C1005 JB 1C 104K-T T 102.8/74.0
C910 4030019990 S.CER C1005 JB 1C 104K-T T 102.8/74.9
C911 4030019990 S.CER C1005 JB 1C 104K-T T 102.8/75.8
C912 4030019990 S.CER C1005 JB 1C 104K-T T 102.8/77.6
C913 4030019990 S.CER C1005 JB 1C 104K-T T 102.8/78.8
C914 4030019990 S.CER C1005 JB 1C 104K-T T 102.8/81.3
C915 4030019990 S.CER C1005 JB 1C 104K-T T 102.8/64.8
C916 4030016790 S.CER C1005 JB 1E 103K-T T 102.8/65.8
C917 4550007200 S.TAN F930J476MBABMA T 104.7/91.5
C918 4550007200 S.TAN F930J476MBABMA T 104.6/87.9
C919 4030019990 S.CER C1005 JB 1C 104K-T T 96.2/58.0
C920 4030019990 S.CER C1005 JB 1C 104K-T T 97.1/87.7
C921 4030019990 S.CER C1005 JB 1C 104K-T T 95.3/88.6
C922 4030019990 S.CER C1005 JB 1C 104K-T T 92.4/57.6
C923 4030019990 S.CER C1005 JB 1C 104K-T T 91.4/87.7
C924 4030019990 S.CER C1005 JB 1C 104K-T T 89.8/57.6
C925 4030019990 S.CER C1005 JB 1C 104K-T T 88.1/87.3
C926 4030019990 S.CER C1005 JB 1C 104K-T T 86.8/57.6
C927 4030019990 S.CER C1005 JB 1C 104K-T T 85.9/87.7
C928 4030019990 S.CER C1005 JB 1C 104K-T T 84.9/87.7
C929 4030019990 S.CER C1005 JB 1C 104K-T T 84.4/57.6
C930 4030019990 S.CER C1005 JB 1C 104K-T T 82.4/87.7
C931 4030019990 S.CER C1005 JB 1C 104K-T T 82.3/57.8
C932 4030019990 S.CER C1005 JB 1C 104K-T T 79.9/87.7
C933 4030019990 S.CER C1005 JB 1C 104K-T T 78.8/57.6
C934 4030019990 S.CER C1005 JB 1C 104K-T T 77.4/57.6
C935 4030019990 S.CER C1005 JB 1C 104K-T T 77.4/87.7
C936 4550007200 S.TAN F930J476MBABMA T 70.0/63.4
C937 4550007200 S.TAN F930J476MBABMA T 76.9/55.2
C938 4030019990 S.CER C1005 JB 1C 104K-T T 107.4/84.7
C939 4550007200 S.TAN F930J476MBABMA T 67.6/71.8
C940 4030019990 S.CER C1005 JB 1C 104K-T T 72.4/62.3
C941 4030019990 S.CER C1005 JB 1C 104K-T T 72.4/65.3
C942 4030019990 S.CER C1005 JB 1C 104K-T T 72.4/67.3
C943 4030019990 S.CER C1005 JB 1C 104K-T T 72.4/68.3
C944 4030019990 S.CER C1005 JB 1C 104K-T T 72.4/70.3
C945 4030019990 S.CER C1005 JB 1C 104K-T T 72.4/71.3
C946 4030019990 S.CER C1005 JB 1C 104K-T T 72.4/72.3
C947 4030019990 S.CER C1005 JB 1C 104K-T T 72.4/73.3
C948 4030019990 S.CER C1005 JB 1C 104K-T T 72.4/75.3
C949 4030019990 S.CER C1005 JB 1C 104K-T T 72.4/76.8
C950 4030019990 S.CER C1005 JB 1C 104K-T T 72.4/77.8
C951 4030019990 S.CER C1005 JB 1C 104K-T T 72.4/79.3
C952 4030019990 S.CER C1005 JB 1C 104K-T T 72.4/80.8
C953 4030019990 S.CER C1005 JB 1C 104K-T T 72.4/81.7
C954 4550007200 S.TAN F930J476MBABMA T 67.6/75.8
C955 4030017430 S.CER C1005 CH 1H 101J-T T 96.9/55.4
C961 4030019620 S.CER GRM188B31C225KE14D T 38.0/158.0
C962 4030019620 S.CER GRM188B31C225KE14D T 37.9/163.0
C971 4030019560 S.CER GRM21BB31C106KE15L T 33.6/134.0
C972 4030019990 S.CER C1005 JB 1C 104K-T T 34.2/143.5
C973 4030019560 S.CER GRM21BB31C106KE15L T 34.2/144.9
C974 4030017700 S.CER C1005 CH 1H 151J-T T 36.1/156.9
C975 4030017700 S.CER C1005 CH 1H 151J-T T 34.1/151.5
C976 4030019990 S.CER C1005 JB 1C 104K-T T 31.3/155.0
C977 4030019990 S.CER C1005 JB 1C 104K-T T 29.0/149.7
C981 4030019990 S.CER C1005 JB 1C 104K-T T 32.4/149.2
C991 4030019560 S.CER GRM21BB31C106KE15L T 47.8/133.2
C992 4030019990 S.CER C1005 JB 1C 104K-T T 47.8/136.0
C993 4030019560 S.CER GRM21BB31C106KE15L T 46.4/136.9
C994 4030019560 S.CER GRM21BB31C106KE15L T 39.1/145.0
C995 4030019570 S.CER C1608 CH 1H 332J-T T 43.5/139.9
C996 4030019570 S.CER C1608 CH 1H 332J-T T 46.7/139.9
C997 4030019990 S.CER C1005 JB 1C 104K-T T 40.5/145.6
C998 4030019990 S.CER C1005 JB 1C 104K-T T 49.6/145.9
C999 4030017700 S.CER C1005 CH 1H 151J-T T 43.6/142.0
C1000 4030020980 S.CER C1005 CH 1H 821JT T 46.2/142.1
C1001 4030019560 S.CER GRM21BB31C106KE15L T 39.6/141.6
C1002 4030019560 S.CER GRM21BB31C106KE15L T 50.8/140.5
C1003 4030019990 S.CER C1005 JB 1C 104K-T T 60.8/133.6
C1004 4030019560 S.CER GRM21BB31C106KE15L T 60.7/131.5
C1005 4030019990 S.CER C1005 JB 1C 104K-T T 64.0/143.9
C1006 4030019990 S.CER C1005 JB 1C 104K-T T 62.2/143.9
C1007 4030019560 S.CER GRM21BB31C106KE15L T 65.1/146.2
C1008 4030019560 S.CER GRM21BB31C106KE15L T 62.5/145.3
C1009 4030019560 S.CER GRM21BB31C106KE15L T 68.5/142.5
C1010 4030019620 S.CER GRM188B31C225KE14D T 68.2/146.0
C1011 4030019620 S.CER GRM188B31C225KE14D T 67.0/139.6
C1012 4030017690 S.CER C1005 CH 1H 121J-T T 69.7/147.6
C1013 4030017440 S.CER C1005 CH 1H 221J-T T 69.3/138.2
C1014 4030019990 S.CER C1005 JB 1C 104K-T T 73.2/135.5
C1015 4030019560 S.CER GRM21BB31C106KE15L T 74.1/142.8
C1016 4030019620 S.CER GRM188B31C225KE14D T 72.8/148.1
C1017 4510010570 S.ELE 16 CE 470 LX T 69.0/153.9
C1018 4030019560 S.CER GRM21BB31C106KE15L T 63.4/153.3
C1019 4030019990 S.CER C1005 JB 1C 104K-T T 66.8/148.5
C1020 4030019560 S.CER GRM21BB31C106KE15L T 69.0/134.9
C1021 4030017420 S.CER C1005 CH 1H 470J-T T 106.8/76.0
C1022 4030017420 S.CER C1005 CH 1H 470J-T T 107.4/76.9
C1023 4030017420 S.CER C1005 CH 1H 470J-T T 106.9/78.2
C1024 4030017420 S.CER C1005 CH 1H 470J-T T 105.7/82.3
C1025 4030017420 S.CER C1005 CH 1H 470J-T T 105.7/83.2
C1201 4030016790 S.CER C1005 JB 1E 103K-T T 51.8/77.5
C1202 4030019990 S.CER C1005 JB 1C 104K-T T 49.3/75.9
C1203 4030017460 S.CER C1005 JB 1H 102K-T T 48.2/77.5
C1204 4030019990 S.CER C1005 JB 1C 104K-T T 52.8/76.6
C1205 4030017460 S.CER C1005 JB 1H 102K-T T 49.3/80.6
C1206 4030017600 S.CER C1005 CH 1H 080C-T T 50.5/80.2
C1207 4030016790 S.CER C1005 JB 1E 103K-T T 49.5/87.2
C1208 4030017530 S.CER C1005 CH 1H 0R5B-T T 50.5/81.1
C1209 4030016790 S.CER C1005 JB 1E 103K-T T 51.2/85.9
C1211 4030017460 S.CER C1005 JB 1H 102K-T T 52.0/91.9
C1212 4030019990 S.CER C1005 JB 1C 104K-T T 48.5/94.0
C1213 4030016790 S.CER C1005 JB 1E 103K-T T 52.7/97.5
C1220 4030019620 S.CER GRM188B31C225KE14D T 68.6/132.9
C1221 4030019990 S.CER C1005 JB 1C 104K-T T 71.0/131.2
C1222 4030017460 S.CER C1005 JB 1H 102K-T T 58.4/128.1
C1223 4030017460 S.CER C1005 JB 1H 102K-T T 66.3/130.4
C1224 4030017460 S.CER C1005 JB 1H 102K-T T 63.4/130.9
C1231 4030019990 S.CER C1005 JB 1C 104K-T T 106.1/127.5
C1232 4030019990 S.CER C1005 JB 1C 104K-T T 97.6/124.5
C1233 4030019990 S.CER C1005 JB 1C 104K-T T 94.6/124.5
C1235 4030019990 S.CER C1005 JB 1C 104K-T T 102.8/129.4
C1236 4030019990 S.CER C1005 JB 1C 104K-T T 97.4/121.0
C1237 4030019990 S.CER C1005 JB 1C 104K-T T 95.1/121.0
C1241 4030019620 S.CER GRM188B31C225KE14D T 93.0/118.6
C1242 4030019620 S.CER GRM188B31C225KE14D T 98.1/118.8
C1251 4030019990 S.CER C1005 JB 1C 104K-T T 100.6/117.2
C1252 4030019990 S.CER C1005 JB 1C 104K-T T 101.9/120.3
C1253 4030019990 S.CER C1005 JB 1C 104K-T T 102.4/117.2
C1254 4030019990 S.CER C1005 JB 1C 104K-T T 107.7/120.9
C1255 4030019990 S.CER C1005 JB 1C 104K-T T 107.2/116.4
C1256 4030019990 S.CER C1005 JB 1C 104K-T T 112.8/117.3
C1261 4030019990 S.CER C1005 JB 1C 104K-T T 102.5/115.4
C1262 4030019990 S.CER C1005 JB 1C 104K-T T 101.6/115.4
C1263 4030017460 S.CER C1005 JB 1H 102K-T T 103.4/115.4
C1266 4030017460 S.CER C1005 JB 1H 102K-T T 101.1/108.7
C1267 4030017460 S.CER C1005 JB 1H 102K-T T 102.8/108.7
C1268 4030019990 S.CER C1005 JB 1C 104K-T T 101.1/109.6
C1269 4030019990 S.CER C1005 JB 1C 104K-T T 102.8/109.6
C1270 4030019560 S.CER GRM21BB31C106KE15L T 101.4/107.2
C1273 4030017460 S.CER C1005 JB 1H 102K-T T 99.3/110.1
C1274 4030017460 S.CER C1005 JB 1H 102K-T T 98.4/113.3
C1277 4030017420 S.CER C1005 CH 1H 470J-T T 98.8/112.1
C1278 4030019990 S.CER C1005 JB 1C 104K-T T 83.3/96.8
C1279 4030019990 S.CER C1005 JB 1C 104K-T T 87.1/95.3
C1281 4030017660 S.CER C1005 CH 1H 330J-T T 99.1/129.9
C1283 4030017680 S.CER C1005 CH 1H 820J-T T 92.9/129.0
C1285 4030017660 S.CER C1005 CH 1H 330J-T T 93.1/127.8
C1294 4030019560 S.CER GRM21BB31C106KE15L T 94.0/102.7
C1300 4030019990 S.CER C1005 JB 1C 104K-T T 59.2/132.3
C1301 4030019560 S.CER GRM21BB31C106KE15L T 96.0/103.7
C1302 4030019990 S.CER C1005 JB 1C 104K-T T 93.4/110.5
(Amended page)
October 2016

6
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[MAIN UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
[MAIN UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
C1303 4030019990 S.CER C1005 JB 1C 104K-T T 93.4/105.3
C1304 4030019990 S.CER C1005 JB 1C 104K-T T 92.6/103.6
C1309 4030019560 S.CER GRM21BB31C106KE15L T 80.8/97.2
C1310 4030019990 S.CER C1005 JB 1C 104K-T T 81.6/101.9
C1311 4030019990 S.CER C1005 JB 1C 104K-T T 81.6/111.8
C1315 4030016790 S.CER C1005 JB 1E 103K-T T 74.1/129.5
C1316 4030017460 S.CER C1005 JB 1H 102K-T T 92.2/112.9
C1317 4030017460 S.CER C1005 JB 1H 102K-T T 93.1/112.9
C1318 4030019620 S.CER GRM188B31C225KE14D T 106.8/105.1
C1319 4030019620 S.CER GRM188B31C225KE14D T 98.4/103.2
C1321 4030019620 S.CER GRM188B31C225KE14D T 90.7/128.5
C1322 4030019620 S.CER GRM188B31C225KE14D T 84.8/130.1
C1325 4030019620 S.CER GRM188B31C225KE14D T 70.5/84.4
C1326 4030019620 S.CER GRM188B31C225KE14D T 70.0/89.3
C1332 4030019990 S.CER C1005 JB 1C 104K-T T 77.4/120.0
C1333 4030019990 S.CER C1005 JB 1C 104K-T T 77.9/124.7
C1334 4030019990 S.CER C1005 JB 1C 104K-T T 77.5/125.9
C1335 4030019560 S.CER GRM21BB31C106KE15L T 79.7/126.1
C1336 4030019990 S.CER C1005 JB 1C 104K-T T 77.5/127.5
C1337 4030019560 S.CER GRM21BB31C106KE15L T 79.7/128.1
C1338 4030017440 S.CER C1005 CH 1H 221J-T T 37.8/120.4
C1339 4030017440 S.CER C1005 CH 1H 221J-T T 37.6/122.0
C1340 4030017620 S.CER C1005 CH 1H 100C-T T 39.3/89.4
C1350 4510010570 S.ELE 16 CE 470 LX T 46.5/69.3
C1351 4550007200 S.TAN F930J476MBABMA T 39.3/93.3
C1352 4030018910 S.CER C1608 JB 0J 475K-T T 45.8/93.2
C1353 4030016790 S.CER C1005 JB 1E 103K-T T 45.7/89.6
C1354 4030018910 S.CER C1608 JB 0J 475K-T T 46.2/88.6
C1355 4030016790 S.CER C1005 JB 1E 103K-T T 54.2/96.7
C1356 4030018900 S.CER C1005 JB 0J 474K-T T 45.3/91.7
C1357 4030017460 S.CER C1005 JB 1H 102K-T T 46.2/91.7
C1358 4030018900 S.CER C1005 JB 0J 474K-T T 47.1/91.7
C1359 4030017460 S.CER C1005 JB 1H 102K-T T 55.1/96.7
C1360 4030018900 S.CER C1005 JB 0J 474K-T T 45.7/90.5
C1361 4030017460 S.CER C1005 JB 1H 102K-T T 45.5/94.3
C1362 4030017460 S.CER C1005 JB 1H 102K-T T 47.1/90.1
C1363 4030017460 S.CER C1005 JB 1H 102K-T T 43.1/91.6
C1364 4030017460 S.CER C1005 JB 1H 102K-T T 49.5/127.2
C1365 4030017460 S.CER C1005 JB 1H 102K-T T 58.2/96.9
C1366 4030017460 S.CER C1005 JB 1H 102K-T T 40.2/98.9
C1367 4030017460 S.CER C1005 JB 1H 102K-T T 54.8/125.5
C1368 4030017460 S.CER C1005 JB 1H 102K-T T 62.9/97.2
C1369 4030017460 S.CER C1005 JB 1H 102K-T T 59.1/96.9
C1370 4030017460 S.CER C1005 JB 1H 102K-T T 60.6/125.3
C1371 4030018900 S.CER C1005 JB 0J 474K-T T 43.1/94.3
C1372 4030016790 S.CER C1005 JB 1E 103K-T T 48.6/127.2
C1373 4030016790 S.CER C1005 JB 1E 103K-T T 60.0/96.9
C1374 4030016790 S.CER C1005 JB 1E 103K-T T 40.2/100.8
C1375 4030018900 S.CER C1005 JB 0J 474K-T T 43.1/93.4
C1376 4030016790 S.CER C1005 JB 1E 103K-T T 64.6/96.7
C1377 4030018900 S.CER C1005 JB 0J 474K-T T 62.3/102.6
C1378 4030018900 S.CER C1005 JB 0J 474K-T T 40.2/99.9
C1379 4030018900 S.CER C1005 JB 0J 474K-T T 43.1/92.5
C1380 4030018900 S.CER C1005 JB 0J 474K-T T 47.7/127.2
C1381 4030018900 S.CER C1005 JB 0J 474K-T T 57.0/96.4
C1382 4030018900 S.CER C1005 JB 0J 474K-T T 37.8/123.6
C1383 4030018900 S.CER C1005 JB 0J 474K-T T 53.0/126.7
C1384 4030018900 S.CER C1005 JB 0J 474K-T T 64.6/95.7
C1385 4030018900 S.CER C1005 JB 0J 474K-T T 60.9/96.9
C1386 4030018900 S.CER C1005 JB 0J 474K-T T 60.6/126.2
C1387 4030018910 S.CER C1608 JB 0J 475K-T T 55.8/125.9
C1388 4030018910 S.CER C1608 JB 0J 475K-T T 49.4/125.4
C1389 4030018910 S.CER C1608 JB 0J 475K-T T 58.3/92.3
C1390 4030018910 S.CER C1608 JB 0J 475K-T T 59.2/126.2
C1391 4030020540 S.CER GRM32EB30J107ME16L T 52.4/128.7
C1392 4030020540 S.CER GRM32EB30J107ME16L T 45.6/128.8
C1393 4030020540 S.CER GRM32EB30J107ME16L T 58.6/94.4
C1394 4030020540 S.CER GRM32EB30J107ME16L T 35.6/121.7
C1396 4550007200 S.TAN F930J476MBABMA T 41.4/96.6
C1397 4030017420 S.CER C1005 CH 1H 470J-T T 57.5/125.3
C1398 4030017430 S.CER C1005 CH 1H 101J-T T 53.9/125.5
C1399 4030019990 S.CER C1005 JB 1C 104K-T T 45.9/99.9
C1400 4030019990 S.CER C1005 JB 1C 104K-T T 45.9/100.8
C1401 4030019990 S.CER C1005 JB 1C 104K-T T 28.0/124.4
C3003 4030019990 S.CER C1005 JB 1C 104K-T T 109.2/105.0
J1 6510022472 S.CON 40FLT-SM2-TB (LF) (SN) (M) T 17.5/90.3
J21 6510021722 S.CON 30FLT-SM2-TB (LF) (SN) (M) T 17.5/122.0
J45 6510018961 S.CON B2B-PH-SM4-TB (LF) (SN) T 7.2/70.9
J51 6510021722 S.CON 30FLT-SM2-TB (LF) (SN) (M) T 8.6/28.0
J71 6510022472 S.CON 40FLT-SM2-TB (LF) (SN) (M) T 34.5/10.0
J101 6510024522 S.CON 12FLT-SM2-TB (LF) (SN) (M) T 82.4/7.4
J491 6510025142 S.CON 10FLT-SM2-TB (LF) (SN) (M) T 108.9/16.4
J601 6510026540 CON UBB-4R-D14T-4D (LF) (SN)
J691 6510025940 CON PJ-3047S
J751 6510025940 CON PJ-3047S
J752 6510014961 S.CON B2B-ZR-SM4-TF (LF) (SN) T 111.0/174.5
J761 6510018971 S.CON B4B-PH-SM4-TB (LF) (SN) T 82.0/170.5
J771 6 450001641 CON TCS50 44-0141177
J901 6510025142 S.CON 10FLT-SM2-TB (LF) (SN) (M) T 93.5/94.9
J1231 6510028210 CON SJ050010 (TMP-J01X-V6)
S371 2230001480 S.SWI LS37J2-T T 57.9/34.5
BT381 3020000390 S.LIT ML414HIV01E T 97.8/3.9
EP1 6910020910 S.BEA MPZ1608S300AT T 21.3/80.8
EP2 6910019100 S.BEA MPZ1608S101AT T 21.3/85.5
EP3 6910021240 S.BEA MMZ1005A152ET T 22.3/89.8
EP5 6910021240 S.BEA MMZ1005A152ET T 22.3/91.6
EP6 6910021240 S.BEA MMZ1005A152ET T 22.3/92.5
EP7 6910021240 S.BEA MMZ1005A152ET T 22.3/93.4
EP8 6910021240 S.BEA MMZ1005A152ET T 22.3/94.3
EP9 6910021240 S.BEA MMZ1005A152ET T 22.3/95.2
EP11 6910021240 S.BEA MMZ1005A152ET T 22.3/97.0
EP14 6910021240 S.BEA MMZ1005A152ET T 21.7/99.7
EP19 6910021240 S.BEA MMZ1005A152ET T 22.3/88.9
EP21 6910019900 S.BEA MPZ1608S601AT T 21.5/131.1
EP22 6910019900 S.BEA MPZ1608S601AT T 22.1/129.9
EP23 6910019900 S.BEA MPZ1608S601AT T 22.1/128.7
EP32 6910021240 S.BEA MMZ1005A152ET T 22.8/120.4
EP33 6910021240 S.BEA MMZ1005A152ET T 22.0/119.5
EP34 6910021240 S.BEA MMZ1005A152ET T 22.0/118.6
EP35 6910021240 S.BEA MMZ1005A152ET T 22.0/117.7
EP36 6910021240 S.BEA MMZ1005A152ET T 22.0/116.8
EP37 6910021240 S.BEA MMZ1005A152ET T 21.6/115.9
EP38 6910021240 S.BEA MMZ1005A152ET T 21.6/115.0
EP39 6910021240 S.BEA MMZ1005A152ET T 21.4/114.1
EP45 6910019900 S.BEA MPZ1608S601AT T 7.0/67.4
EP46 6910019900 S.BEA MPZ1608S601AT T 19.2/73.6
EP51 6910019100 S.BEA MPZ1608S101AT T 12.7/35.7
EP52 6910019900 S.BEA MPZ1608S601AT T 12.7/33.4
EP58 6910015970 S.BEA MMZ1608B 301CT-AS T 13.7/26.3
EP59 6910015970 S.BEA MMZ1608B 301CT-AS T 12.8/25.0
EP60 6910015970 S.BEA MMZ1608B 301CT-AS T 13.7/23.8
EP61 6910015970 S.BEA MMZ1608B 301CT-AS T 13.6/22.6
EP62 6910015970 S.BEA MMZ1608B 301CT-AS T 13.8/21.4
EP63 6910015970 S.BEA MMZ1608B 301CT-AS T 13.8/20.2
EP75 6910015970 S.BEA MMZ1608B 301CT-AS T 28.3/14.2
EP79 6910015970 S.BEA MMZ1608B 301CT-AS T 29.9/14.2
EP80 6910015970 S.BEA MMZ1608B 301CT-AS T 30.4/6.0
EP81 6910015970 S.BEA MMZ1608B 301CT-AS T 31.1/14.2
EP82 6910015970 S.BEA MMZ1608B 301CT-AS T 31.6/6.0
EP83 6910015970 S.BEA MMZ1608B 301CT-AS T 32.3/14.2
EP84 6910015970 S.BEA MMZ1608B 301CT-AS T 32.8/6.0
EP85 6910015970 S.BEA MMZ1608B 301CT-AS T 33.5/14.2
EP86 6910015970 S.BEA MMZ1608B 301CT-AS T 34.0/6.0
EP87 6910015970 S.BEA MMZ1608B 301CT-AS T 34.7/14.2
EP88 6910015970 S.BEA MMZ1608B 301CT-AS T 35.2/6.0
EP89 6910015970 S.BEA MMZ1608B 301CT-AS T 35.9/14.2
EP90 6910015970 S.BEA MMZ1608B 301CT-AS T 36.4/6.0
EP91 6910015970 S.BEA MMZ1608B 301CT-AS T 37.1/14.2
EP92 6910015970 S.BEA MMZ1608B 301CT-AS T 37.6/6.0
EP93 6910015970 S.BEA MMZ1608B 301CT-AS T 38.3/14.2
EP94 6910015970 S.BEA MMZ1608B 301CT-AS T 38.8/6.0
EP95 6910015970 S.BEA MMZ1608B 301CT-AS T 39.5/14.2
EP96 6910019900 S.BEA MPZ1608S601AT T 40.8/14.2
EP97 6910019900 S.BEA MPZ1608S601AT T 42.3/5.8
EP98 6910019900 S.BEA MPZ1608S601AT T 44.3/5.8
EP111 6910019900 S.BEA MPZ1608S601AT T 71.0/4.5
EP121 6910023350 S.BEA MMZ1005B601CT T 55.6/59.9
EP141 6910023350 S.BEA MMZ1005B601CT T 60.8/49.7
EP201 6910018930 S.BEA MPZ2012S601A T 29.0/58.2
EP202 6910018930 S.BEA MPZ2012S601A T 23.7/40.6
EP221 6910018930 S.BEA MPZ2012S601A T 35.0/59.5
EP251 6910018930 S.BEA MPZ2012S601A T 20.1/60.2
EP301 6910019900 S.BEA MPZ1608S601AT T 99.0/13.3
EP302 6910019900 S.BEA MPZ1608S601AT T 64.9/42.4
EP303 6910023350 S.BEA MMZ1005B601CT T 99.6/34.8
EP304 6910023350 S.BEA MMZ1005B601CT T 66.6/23.2
EP351 6910023350 S.BEA MMZ1005B601CT T 105.0/21.7
EP391 6910023350 S.BEA MMZ1005B601CT T 104.9/40.2
EP601 6910023350 S.BEA MMZ1005B601CT T 55.1/174.1
EP621 6910019900 S.BEA MPZ1608S601AT T 63.3/159.2
EP641 6910023350 S.BEA MMZ1005B601CT T 46.6/166.2
EP661 6910023350 S.BEA MMZ1005B601CT T 61.8/151.0
EP662 6910023350 S.BEA MMZ1005B601CT T 59.4/145.6
EP691 6910023350 S.BEA MMZ1005B601CT T 68.4/182.5
EP751 6910018930 S.BEA MPZ2012S601A T 92.5/179.5
EP752 6910018930 S.BEA MPZ2012S601A T 107.5/177.6
EP761 6910019900 S.BEA MPZ1608S601AT T 89.0/169.6
EP762 6910019900 S.BEA MPZ1608S601AT T 89.0/170.9
EP763 6910019900 S.BEA MPZ1608S601AT T 89.0/172.2
EP764 6910019900 S.BEA MPZ1608S601AT T 89.0/173.5
EP771 6910019900 S.BEA MPZ1608S601AT T 28.5/173.0
EP773 6910019900 S.BEA MPZ1608S601AT T 35.3/168.0
EP774 6910023350 S.BEA MMZ1005B601CT T 29.5/171.8
EP775 6910023350 S.BEA MMZ1005B601CT T 29.4/179.0
EP776 6910023350 S.BEA MMZ1005B601CT T 29.4/180.0
EP778 6910018930 S.BEA MPZ2012S601A T 51.4/176.5
EP779 6910023350 S.BEA MMZ1005B601CT T 29.4/181.0
EP780 6910023350 S.BEA MMZ1005B601CT T 29.4/185.0
EP781 6910023350 S.BEA MMZ1005B601CT T 50.5/183.6
EP782 6910023350 S.BEA MMZ1005B601CT T 50.5/182.6
EP783 6910023350 S.BEA MMZ1005B601CT T 29.4/187.0
EP901 6910018930 S.BEA MPZ2012S601A T 71.8/55.2
EP902 6910018930 S.BEA MPZ2012S601A T 70.0/58.5
EP904 6910019900 S.BEA MPZ1608S601AT T 103.5/63.1
EP905 6910019900 S.BEA MPZ1608S601AT T 102.3/63.1
EP906 6910019900 S.BEA MPZ1608S601AT T 112.7/78.2
EP971 6910019900 S.BEA MPZ1608S601AT T 34.2/146.5
EP991 6910019900 S.BEA MPZ1608S601AT T 44.1/137.5
EP1001 6910019900 S.BEA MPZ1608S601AT T 64.6/133.2
EP1002 6910019900 S.BEA MPZ1608S601AT T 59.9/143.9
EP1003 6910019900 S.BEA MPZ1608S601AT T 56.8/132.0
EP1201 6910023420 S.BEA MMZ1005A222ET T 48.2/75.9
EP1203 6910023350 S.BEA MMZ1005B601CT T 46.8/86.6
EP1211 6910018460 S.BEA MMZ1005Y102C-T T 49.0/95.6
EP1212 6910018460 S.BEA MMZ1005Y102C-T T 52.7/95.7
EP1221 6910018460 S.BEA MMZ1005Y102C-T T 71.9/131.2
EP1235 6910018460 S.BEA MMZ1005Y102C-T T 93.8/125.7
EP1236 6910018460 S.BEA MMZ1005Y102C-T T 97.8/125.7
EP1251 6910018460 S.BEA MMZ1005Y102C-T T 100.6/119.0
EP1252 6 910 018460 S.B E A M M Z1005Y10 2C-T T 112.8 /118 .9
(Amended page)
October 2016

7
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[MAIN UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
[RF UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
EP1261 6910018460 S.BEA MMZ1005Y102C-T T 101.9/105.6
EP1300 6910026020 E.O CMBA0210101402-00
EP1301 6910021230 S.BEA MMZ2012Y102BT T 96.4/101.3
EP1302 6910018460 S.BEA MMZ1005Y102C-T T 78.8/96.3
EP1315 6910018460 S.BEA MMZ1005Y102C-T T 74.1/131.3
EP1331 6910018460 S.BEA MMZ1005Y102C-T T 85.1/128.9
EP1332 6910018460 S.BEA MMZ1005Y102C-T T 85.1/128.0
EP1351 6910019900 S.BEA MPZ1608S601AT T 44.6/86.7
EP1352 6910019900 S.BEA MPZ1608S601AT T 45.8/86.7
EP1353 6910019900 S.BEA MPZ1608S601AT T 45.0/97.6
EP1354 6910019900 S.BEA MPZ1608S601AT T 63.1/94.6
EP1355 6910019900 S.BEA MPZ1608S601AT T 61.8/94.6
EP1364 6910018460 S.BEA MMZ1005Y102C-T T 41.4/77.3
EP1365 6910018460 S.BEA MMZ1005Y102C-T T 42.3/77.3
EP1401 6910018460 S.BEA MMZ1005Y102C-T T 28.0/122.8
IC1031 1110008080 S.IC BGA2866115 T 96.6/24.2
IC1061 1180004430 S.REG XC6209F502MR-G T 64.3/9.3
IC1301 1130010550 S.IC SN74AHC595PWR T 27.2/19.9
IC1302 1130010550 S.IC SN74AHC595PWR T 17.6/19.9
IC1303 1130010550 S.IC SN74AHC595PWR T 8.1/19.9
IC1501 1110005320 S.IC NJM13403V-TE1-#ZZZB T 48.6/26.2
IC1502 1110008550 S.IC NJM2904CRB1-TE1-#HMZR T 37.2/27.7
Q101 1590004690 S.TRA LDTC143ZET1G T 104.9/11.2
Q1001 1590004690 S.TRA LDTC143ZET1G T 70.9/6.2
Q1051 1530004140 S.TRA L2SC4081RT1G T 86.3/30.7
Q1061 1590004310 S.TRA LDTA114EET1G T 61.5/11.1
Q1062 1590004690 S.TRA LDTC143ZET1G T 61.5/8.7
Q1091 1590004690 S.TRA LDTC143ZET1G T 4.5/75.3
Q1092 1590004690 S.TRA LDTC143ZET1G T 4.5/77.7
Q1093 1590004310 S.TRA LDTA114EET1G T 7.0/77.7
Q1094 1590004310 S.TRA LDTA114EET1G T 7.0/74.8
Q1095 1590004310 S.TRA LDTA114EET1G T 7.0/72.6
Q1096 1590004690 S.TRA LDTC143ZET1G T 4.5/73.1
Q1097 1590004690 S.TRA LDTC143ZET1G T 58.3/12.9
Q1098 1590004690 S.TRA LDTC143ZET1G T 56.1/12.9
Q1099 1590004310 S.TRA LDTA114EET1G T 58.6/15.3
Q1110 1590004310 S.TRA LDTA114EET1G T 56.6/15.3
Q1111 159 0 0 04 69 0 S .TR A L DT C14 3Z ET1G T 31.0 /31. 5
Q1121 1590004690 S.TRA LDTC143ZET1G T 5.8/31.5
Q1131 1590004690 S.TRA LDTC143ZET1G T 6.9/27.7
Q1141 1590004690 S.TRA LDTC143ZET1G T 9.4/31.5
Q1151 1590004690 S.TRA LDTC143ZET1G T 10.5/27.7
Q1161 1590004690 S.TRA LDTC143ZET1G T 13.0/31.5
Q1171 1590004690 S.TRA LDTC143ZET1G T 14.1/27.7
Q1181 1590004690 S.TRA LDTC143ZET1G T 16.6/31.5
Q1191 1590004690 S.TRA LDTC143ZET1G T 17.7/27.7
Q1201 1590004690 S.TRA LDTC143ZET1G T 20.2/31.5
Q1211 1590004690 S.TRA LDTC143ZET1G T 21.3/27.7
Q1221 1590004690 S.TRA LDTC143ZET1G T 23.8/31.5
Q1231 1590004690 S.TRA LDTC143ZET1G T 25.0/27.7
Q1241 1590004690 S.TRA LDTC143ZET1G T 27.4/31.5
Q1261 1590004690 S.TRA LDTC143ZET1G [#03] T 28.6/27.7
1590004690 S.TRA LDTC143ZET1G [#05]
1590004690 S.TRA LDTC143ZET1G [#06]
Q1411 1530004340 S.TRA 2SC3356L-B-AE3-R T 55.0/77.9
Eqv. 1530004560 S.TRA 2SC3356G-B-AE2-R
Q1412 1590004690 S.TRA LDTC143ZET1G T 40.8/85.9
Q1413 1590004690 S.TRA LDTC143ZET1G T 40.8/83.0
Q1511 1590004310 S.TRA LDTA114EET1G T 33.6/24.6
Q1512 1590004690 S.TRA LDTC143ZET1G T 31.5/24.0
Q1513 1560002190 S.FET RUM002N02T2L T 31.2/22.0
Q1521 1510001200 S.TRA L2SA1576ART1G T 47.9/17.2
Q1561 1590004310 S.TRA LDTA114EET1G T 33.3/30.9
Q1562 1530003960 S.TRA KTC2875-B-RTK/P T 36.0/32.8
Q1563 1560002190 S.FET RUM002N02T2L T 42.0/31.0
Q1571 1530004140 S.TRA L2SC4081RT1G T 54.0/20.4
D101 1750001810 S.DIO L1SS400T1G T 106.6/11.3
D1001 1790001621 S.DIO 1SV308 (TPL3F) T 72.0/11.5
Eqv. 1790001622 S.DIO 1SV308L3F
D1021 1750003070 S.DIO BAP70Q T 93.5/12.0
D1041 1750003070 S.DIO BAP70Q T 91.6/27.5
D1051 1750003100 S.DIO BAR64-02V T 83.7/26.5
D1052 1750003100 S.DIO BAR64-02V T 82.7/30.4
D1053 1790001621 S.DIO 1SV308 (TPL3F) T 77.9/21.5
Eqv. 1790001622 S.DIO 1SV308L3F
D1081 1790001621 S.DIO 1SV308 (TPL3F) T 75.5/16.7
Eqv. 1790001622 S.DIO 1SV308L3F
D1082 1790001621 S.DIO 1SV308 (TPL3F) T 74.7/18.5
Eqv. 1790001622 S.DIO 1SV308L3F
D1083 1790001621 S.DIO 1SV308 (TPL3F) T 72.1/18.5
Eqv. 1790001622 S.DIO 1SV308L3F
D1091 1750001810 S.DIO L1SS400T1G T 5.6/79.3
D1101 1790001621 S.DIO 1SV308 (TPL3F) T 73.8/23.5
Eqv. 1790001622 S.DIO 1SV308L3F
D1111 179 0 0 01621 S.DI O 1SV3 0 8 ( TPL 3F) T 77.9/22 .7
Eqv. 1790001622 S.DIO 1SV308L3F
D1112 1790001621 S.DIO 1SV308 (TPL3F) T 96.2/57.9
Eqv. 1790001622 S.DIO 1SV308L3F
D1121 1790001621 S.DIO 1SV308 (TPL3F) T 12.9/39.3
Eqv. 1790001622 S.DIO 1SV308L3F
D1122 1790001621 S.DIO 1SV308 (TPL3F) T 15.0/68.5
Eqv. 1790001622 S.DIO 1SV308L3F
D1131 1790001621 S.DIO 1SV308 (TPL3F) T 17.4/40.1
Eqv. 1790001622 S.DIO 1SV308L3F
D1132 1790001621 S.DIO 1SV308 (TPL3F) T 18.6/67.7
Eqv. 1790001622 S.DIO 1SV308L3FT
D1141 1790001621 S.DIO 1SV308 (TPL3F) T 26.8/40.1
Eqv. 1790001622 S.DIO 1SV308L3F
D1142 1790001621 S.DIO 1SV308 (TPL3F) T 25.2/66.8
Eqv. 1790001622 S.DIO 1SV308L3F
D1151 1790001621 S.DIO 1SV308 (TPL3F) T 30.2/40.1
Eqv. 1790001622 S.DIO 1SV308L3F
D1152 1790001621 S.DIO 1SV308 (TPL3F) T 30.3/66.8
Eqv. 1790001622 S.DIO 1SV308L3F
D1161 1790001621 S.DIO 1SV308 (TPL3F) T 37.0/40.1
Eqv. 1790001622 S.DIO 1SV308L3F
D1162 1790001621 S.DIO 1SV308 (TPL3F) T 35.4/66.8
Eqv. 1790001622 S.DIO 1SV308L3F
D1171 1790001621 S.DIO 1SV308 (TPL3F) T 39.6/40.1
Eqv. 1790001622 S.DIO 1SV308L3F
D1172 1790001621 S.DIO 1SV308 (TPL3F) T 40.4/66.8
Eqv. 1790001622 S.DIO 1SV308L3F
D1181 1790001621 S.DIO 1SV308 (TPL3F) T 47.8/40.1
Eqv. 1790001622 S.DIO 1SV308L3F
(Amended page)
October 2016

8
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[RF UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
[RF UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
D1182 1790001621 S.DIO 1SV308 (TPL3F) T 45.5/66.5
Eqv. 1790001622 S.DIO 1SV308L3F
D1191 1790001621 S.DIO 1SV308 (TPL3F) T 49.9/40.1
Eqv. 1790001622 S.DIO 1SV308L3F
D1192 1790001621 S.DIO 1SV308 (TPL3F) T 50.7/66.5
Eqv. 1790001622 S.DIO 1SV308L3F
D1201 1790001621 S.DIO 1SV308 (TPL3F) T 56.3/40.1
Eqv. 1790001622 S.DIO 1SV308L3F
D1202 1790001621 S.DIO 1SV308 (TPL3F) T 54.7/66.5
Eqv. 1790001622 S.DIO 1SV308L3F
D1211 1790001621 S.DIO 1SV308 (TPL3F) T 92.0/39.9
Eqv. 1790001622 S.DIO 1SV308L3F
D1212 1790001621 S.DIO 1SV308 (TPL3F) T 90.8/58.9
Eqv. 1790001622 S.DIO 1SV308L3F
D1214 1790001621 S.DIO 1SV308 (TPL3F) T 65.6/43.0
Eqv. 1790001622 S.DIO 1SV308L3F
D1221 1790001621 S.DIO 1SV308 (TPL3F) T 83.4/39.9
Eqv. 1790001622 S.DIO 1SV308L3F
D1222 1790001621 S.DIO 1SV308 (TPL3F) T 78.7/71.0
Eqv. 1790001622 S.DIO 1SV308L3F
D1231 1790001621 S.DIO 1SV308 (TPL3F) T 85.5/39.9
Eqv. 1790001622 S.DIO 1SV308L3F
D1232 1790001621 S.DIO 1SV308 (TPL3F) T 86.6/68.7
Eqv. 1790001622 S.DIO 1SV308L3F
D1241 1790001621 S.DIO 1SV308 (TPL3F) T 64.6/45.2
Eqv. 1790001622 S.DIO 1SV308L3F
D1242 1790001621 S.DIO 1SV308 (TPL3F) T 60.0/74.5
Eqv. 1790001622 S.DIO 1SV308L3F
D1243 1790001621 S.DIO 1SV308 (TPL3F) [#03] T 63.8/49.3
Eqv. 1790001622 S.DIO 1SV308L3F [#03]
D1243 1790001621 S.DIO 1SV308 (TPL3F) [#05] T 63.8/49.3
Eqv. 1790001622 S.DIO 1SV308L3F [#05]
D1243 1790001621 S.DIO 1SV308 (TPL3F) [#06] T 63.8/49.3
Eqv. 1790001622 S.DIO 1SV308L3F [#06]
D1261 1790001621 S.DIO 1SV308 (TPL3F) [#03] T 72.4/39.1
Eqv. 1790001622 S.DIO 1SV308L3F [#03]
D1261 1790001621 S.DIO 1SV308 (TPL3F) [#05] T 72.4/39.1
Eqv. 1790001622 S.DIO 1SV308L3F [#05]
D1261 1790001621 S.DIO 1SV308 (TPL3F) [#06] T 72.4/39.1
Eqv. 1790001622 S.DIO 1SV308L3F [#06]
D1262 1790001621 S.DIO 1SV308 (TPL3F) [#03] T 73.3/74.5
Eqv. 1790001622 S.DIO 1SV308L3F [#03]
D1262 1790001621 S.DIO 1SV308 (TPL3F) [#05] T 73.3/74.5
Eqv. 1790001622 S.DIO 1SV308L3F [#05]
D1262 1790001621 S.DIO 1SV308 (TPL3F) [#06] T 73.3/74.5
Eqv. 1790001622 S.DIO 1SV308L3F [#06]
D1401 1790001621 S.DIO 1SV308 (TPL3F) T 36.5/68.4
Eqv. 1790001622 S.DIO 1SV308L3F
D1402 1790001621 S.DIO 1SV308 (TPL3F) T 34.6/78.3
Eqv. 1790001622 S.DIO 1SV308L3F
D1411 1790001621 S.DIO 1SV308 (TPL3F) T 49.8/68.1
Eqv. 1790001622 S.DIO 1SV308L3F
D1412 1790001621 S.DIO 1SV308 (TPL3F) T 34.6/80.8
Eqv. 1790001622 S.DIO 1SV308L3F
D1413 1790001621 S.DIO 1SV308 (TPL3F) T 50.4/82.8
Eqv. 1790001622 S.DIO 1SV308L3F
D1414 1790001621 S.DIO 1SV308 (TPL3F) T 48.8/82.8
Eqv. 1790001622 S.DIO 1SV308L3F
D1415 1790001621 S.DIO 1SV308 (TPL3F) T 61.2/82.1
Eqv. 1790001622 S.DIO 1SV308L3F
D1416 1790001621 S.DIO 1SV308 (TPL3F) T 61.2/84.9
Eqv. 1790001622 S.DIO 1SV308L3F
D1501 1750001810 S.DIO L1SS400T1G T 50.5/18.1
D1521 1750002230 S.DIO LRB751S-40T1G T 44.1/19.1
D1522 1750002230 S.DIO LRB751S-40T1G T 45.3/17.5
D1523 1730002890 S.ZEN DZ2J033M0L T 46.3/20.0
D1531 1750001810 S.DIO L1SS400T1G T 46.1/22.7
D1541 1750001810 S.DIO L1SS400T1G T 54.4/29.4
D1542 1750001810 S.DIO L1SS400T1G T 49.5/31.0
D1543 1750001810 S.DIO L1SS400T1G T 52.5/32.3
D1561 1750002230 S.DIO LRB751S-40T1G T 41.6/29.5
D1563 1750001810 S.DIO L1SS400T1G T 47.5/33.5
L1022 6200002041 S.COI NLV25T-101J-PF T 95.6/16.1
L1023 6200002041 S.COI NLV25T-101J-PF T 93.1/17.0
L1041 6200002041 S.COI NLV25T-101J-PF T 93.0/23.4
L1042 6200002041 S.COI NLV25T-101J-PF T 88.0/22.5
L1043 6200002041 S.COI NLV25T-101J-PF T 90.5/22.5
L1051 6200002041 S.COI NLV25T-101J-PF T 86.2/27.4
L1052 6200002041 S.COI NLV25T-101J-PF T 85.3/22.9
L1053 6200002041 S.COI NLV25T-101J-PF T 81.3/24.9
L1081 6200002041 S.COI NLV25T-101J-PF T 72.5/13.7
L1082 6200002041 S.COI NLV25T-101J-PF T 69.1/20.4
L1083 6200002041 S.COI NLV25T-101J-PF T 66.4/24.6
L1101 6200003241 S.COI NLV32T-221J-PF T 76.2/25.8
L1102 6200003241 S.COI NLV32T-221J-PF T 75.2/32.7
L1103 6200001851 S.COI NLV32T-5R6J-PF T 70.9/27.9
L1104 6200002961 S.COI NLV32T-4R7J-PF T 70.1/31.5
L1105 6200010680 S.COI C2520C-R22G-A (0.22U) T 64.8/40.2
L1106 6200010680 S.COI C2520C-R22G-A (0.22U) T 61.1/42.2
L1111 6200002041 S.COI NLV25T-101J-PF T 94.3/41.1
L1112 6200010800 S.COI C2520C-4R7G-A T 95.3/45.8
L1113 6200010800 S.COI C2520C-4R7G-A T 96.1/50.4
L1114 6200002041 S.COI NLV25T-101J-PF T 94.9/55.0
L1121 6200015770 S.COI 1812CS-392XJLC T 10.0/42.7
L1122 6200015780 S.COI 1812CS-103XJLC T 10.8/60.8
L1123 6200015770 S.COI 1812CS-392XJLC T 10.1/68.5
L1131 6200015790 S.COI 1812CS-222XJLC T 16.6/47.0
L1132 6200015800 S.COI 1812CS-682XJLC T 15.9/54.6
L1133 6200015790 S.COI 1812CS-222XJLC T 16.5/63.5
L1141 6200015810 S.COI 1812CS-102XJLC T 22.5/43.3
L1142 6200011820 S.COI 1812CS-562XJLC T 22.1/53.5
L1143 6200015810 S.COI 1812CS-102XJLC T 23.0/62.8
L1151 6200010530 S.COI C2520C-R56G-A (0.56U) T 28.9/46.6
L1152 6200015770 S.COI 1812CS-392XJLC T 28.1/56.5
L1153 6200010530 S.COI C2520C-R56G-A (0.56U) T 28.9/64.2
L1161 6200010960 S.COI C2520C-R47G-A (0.47U) T 34.7/42.0
L1162 6200015820 S.COI 1812CS-272XJLC T 33.8/51.3
L1163 6200010960 S.COI C2520C-R47G-A (0.47U) T 33.7/63.3
L1171 6200010530 S.COI C2520C-R56G-A (0.56U) T 39.1/46.5
L1172 6200015790 S.COI 1812CS-222XJLC T 39.8/56.5
L1173 6200010530 S.COI C2520C-R56G-A (0.56U) T 39.0/64.1
L1181 6200010870 S.COI C2520C-R33G-A (0.33U) T 44.7/42.0
L1182 6200015830 S.COI 1812CS-152XJLC T 44.6/50.5
L1183 6200010870 S.COI C2520C-R33G-A (0.33U) T 43.7/62.9
L1191 6200010670 S.COI C2520C-R18G-A (0.18U) T 50.2/47.6
L1192 6200015810 S.COI 1812CS-102XJLC T 50.2/56.0
L1193 6200010670 S.COI C2520C-R18G-A (0.18U) T 49.2/63.3
L1201 6200010660 S.COI C2520C-R15G-A (0.15U) T 54.4/43.6
L1202 6200010770 S.COI C2520C-R68G-A T 54.7/51.3
L1203 6200010660 S.COI C2520C-R15G-A (0.15U) T 53.5/62.9
L1211 6200010680 S.COI C2520C-R22G-A (0.22U) T 89.2/41.2
L1212 6200010660 S.COI C2520C-R15G-A (0.15U) T 89.5/49.9
L1213 6200010680 S.COI C2520C-R22G-A (0.22U) T 89.9/56.0
L1221 6200013000 S.COI 0.25-1.9-13TL 135N T 80.3/41.2
L1222 6200013000 S.COI 0.25-1.9-13TL 135N T 78.3/46.3
L1223 6200010680 S.COI C2520C-R22G-A (0.22U) T 78.4/51.3
L1224 6200013000 S.COI 0.25-1.9-13TL 135N T 79.1/57.4
L1225 6200013000 S.COI 0.25-1.9-13TL 135N T 78.4/62.7
L1226 6200002041 S.COI NLV25T-101J-PF T 78.0/68.7
L1231 6200002041 S.COI NLV25T-101J-PF T 84.5/45.1
L1233 6200012510 S.COI 0.25-1.9-8TL 72.0N T 84.7/50.5
L1234 6200012990 S.COI 0.25-1.9-9TL 84.0N T 84.4/66.7
L1241 6200013030 S.COI 0.35-1.6-6TL 31.0N T 62.1/46.0
L1242 6200010520 S.COI C2520C-R75G-A (0.75U) T 63.8/54.6
L1243 6200013030 S.COI 0.35-1.6-6TL 31.0N T 63.6/58.8
L1244 6200012690 S.COI 0.30-2.5-7TL 100N T 63.6/63.0
L1245 6200013000 S.COI 0.25-1.9-13TL 135N T 62.8/67.8
L1246 6200010660 S.COI C2520C-R15G-A (0.15U) T 62.3/72.4
L1261 6200012760 S.COI 0.35-1.6-7TL 37.5N [#03] T 71.9/41.1
6200012760 S.COI 0.35-1.6-7TL 37.5N [#05]
6200012760 S.COI 0.35-1.6-7TL 37.5N [#06]
L1262 6200010870 S.COI C2520C-R33G-A (0.33U) [#03] T 72.1/48.2
6200010870 S.COI C2520C-R33G-A (0.33U) [#05]
6200010870 S.COI C2520C-R33G-A (0.33U) [#06]
L1263 6200012760 S.COI 0.35-1.6-7TL 37.5N [#03] T 67.3/48.2
6200012760 S.COI 0.35-1.6-7TL 37.5N [#05]
6200012760 S.COI 0.35-1.6-7TL 37.5N [#06]
L1264 6200012510 S.COI 0.25-1.9-8TL 72.0N [#03] T 71.3/53.3
6200012510 S.COI 0.25-1.9-8TL 72.0N [#05]
6200012510 S.COI 0.25-1.9-8TL 72.0N [#06]
L1265 6200012690 S.COI 0.30-2.5-7TL 100N [#03] T 71.3/58.5
6200012690 S.COI 0.30-2.5-7TL 100N [#05]
6200012690 S.COI 0.30-2.5-7TL 100N [#06]
L1267 6200010660 S.COI C2520C-R15G-A (0.15U) [#03] T 69.8/63.8
6200010660 S.COI C2520C-R15G-A (0.15U) [#05]
6200010660 S.COI C2520C-R15G-A (0.15U) [#06]
L1268 6200013080 S.COI 0.25-1.9-10TL 97.0N [#03] T 68.8/68.8
6200013080 S.COI 0.25-1.9-10TL 97.0N [#05]
6200013080 S.COI 0.25-1.9-10TL 97.0N [#06]
L1269 6200013080 S.COI 0.25-1.9-10TL 97.0N [#03] T 67.5/73.5
6200013080 S.COI 0.25-1.9-10TL 97.0N [#05]
6200013080 S.COI 0.25-1.9-10TL 97.0N [#06]
L1270 6200002041 S.COI NLV25T-101J-PF [#03] T 70.8/74.4
6200002041 S.COI NLV25T-101J-PF [#05]
6200002041 S.COI NLV25T-101J-PF [#06]
L1291 6200013080 S.COI 0.25-1.9-10TL 97.0N T 84.0/56.5
L1292 6200013080 S.COI 0.25-1.9-10TL 97.0N T 83.8/61.4
L1401 6200002041 S.COI NLV25T-101J-PF T 29.5/70.9
L1402 6200002041 S.COI NLV25T-101J-PF T 29.5/74.5
L1411 6200002041 S.COI NLV25T-101J-PF T 41.0/69.6
L1412 6140005310 S.COI LR-589 (4KBL-S120062) T 50.4/75.1
L1413 6200015400 S.COI LQH43MN102J03L T 43.8/75.1
L1414 6200002041 S.COI NLV25T-101J-PF T 41.0/72.1
L1415 6140005310 S.COI LR-589 (4KBL-S120062) T 55.8/83.6
L1416 6200005501 S.COI NLV32T-471J-PF T 45.8/84.8
L1417 6200002041 S.COI NLV25T-101J-PF T 34.2/83.9
L1418 6200002041 S.COI NLV25T-101J-PF T 60.7/79.3
L1419 6200002041 S.COI NLV25T-101J-PF T 44.6/81.3
L1431 6200002041 S.COI NLV25T-101J-PF T 30.9/78.2
R101 7030010040 S.RES ERJ2GEJ-JPW T 99.8/62.7
R102 7030010040 S.RES ERJ2GEJ-JPW T 106.9/26.5
R103 7030008280 S.RES ERJ2GEJ 271 X (270) T 101.8/15.1
R201 7030010040 S.RES ERJ2GEJ-JPW T 102.4/68.2
R1001 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 70.2/7.6
R1002 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 71.4/8.1
R1003 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 73.5/10.3
R1004 7030004980 S.RES ERJ2GEJ 101 X (100) T 70.6/9.4
R1011 7030010040 S.RES ERJ2GEJ-JPW T 85.6/12.7
R1016 7030010040 S.RES ERJ2GEJ-JPW T 87.8/13.1
R1021 7030008400 S.RES ERJ2GEJ 182 X (1.8 k) T 91.7/9.2
R1022 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 95.3/9.2
R1023 7030008400 S.RES ERJ2GEJ 182 X (1.8 k) T 94.4/9.2
R1024 7030008370 S.RES ERJ2GEJ 561 X (560) T 91.4/13.6
R1025 7030008370 S.RES ERJ2GEJ 561 X (560) T 95.7/13.6
R1026 7030004980 S.RES ERJ2GEJ 101 X (100) T 93.5/14.5
R1027 7030009140 S.RES ERJ2GEJ 272 X (2.7 k) T 93.9/8.0
R1031 7030005530 S.RES ERJ2GEJ 100 X (10) T 94.8/23.8
R1041 7030008400 S.RES ERJ2GEJ 182 X (1.8 k) T 92.4/30.2
R1042 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 92.8/31.4
R1043 7030008400 S.RES ERJ2GEJ 182 X (1.8 k) T 89.7/30.2
R1044 7030008370 S.RES ERJ2GEJ 561 X (560) T 93.7/25.9
R1045 7030008370 S.RES ERJ2GEJ 561 X (560) T 89.4/25.9
R1046 7030004980 S.RES ERJ2GEJ 101 X (100) T 91.1/25.1
R1047 7030009140 S.RES ERJ2GEJ 272 X (2.7 k) T 92.8/32.3
(Amended page)
October 2016

9
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[RF UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
[RF UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
R1051 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 83.5/31.9
R1052 7030008290 S.RES ERJ2GEJ 183 X (18 k) T 86.8/32.5
R1053 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 85.4/32.9
R1054 7030004970 S.RES ERJ2GEJ 470 X (47) T 84.4/27.8
R1055 7030004970 S.RES ERJ2GEJ 470 X (47) T 82.8/27.8
R1056 7030010040 S.RES ERJ2GEJ-JPW T 83.1/21.5
R1057 7030005710 S.RES ERJ2GEJ 121 X (120) T 81.6/22.0
R1058 7030010040 S.RES ERJ2GEJ-JPW T 80.4/21.5
R1059 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 84.0/25.0
R1081 7030009160 S.RES ERJ2GEJ 181 X (180) T 75.0/14.2
R1082 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 70.0/13.2
R1083 7030009200 S.RES ERJ2GEJ 390 X (39) T 73.3/15.6
R1084 7030009200 S.RES ERJ2GEJ 390 X (39) T 73.9/16.9
R1085 7030011010 S.RES ERJ2GEJ 8R2 X (8.2) T 72.9/16.9
R1086 7030009160 S.RES ERJ2GEJ 181 X (180) T 70.4/17.5
R1087 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 68.1/17.4
R1088 7030012990 S.RES ERJ8GEYJ 561V (560) T 73.5/20.4
R1089 7030012990 S.RES ERJ8GEYJ 561V (560) T 70.2/22.7
R1091 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 8.7/75.2
R1092 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 9.1/73.4
R1111 703 0 009160 S.RES ERJ2GEJ 181 X (18 0) T 9 6.3/42 .1
R1113 7030009160 S.RES ERJ2GEJ 181 X (180) T 96.5/56.7
R1114 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 29.4/31.7
R1121 7030005710 S.RES ERJ2GEJ 121 X (120) T 9.1/40.0
R1122 7030009160 S.RES ERJ2GEJ 181 X (180) T 9.1/65.2
R1123 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 5.3/33.4
R1131 7030005710 S.RES ERJ2GEJ 121 X (120) T 15.5/42.7
R1132 7030009160 S.RES ERJ2GEJ 181 X (180) T 15.4/60.2
R1133 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 5.4/27.9
R1141 7030005710 S.RES ERJ2GEJ 121 X (120) T 22.1/39.9
R1142 7030009160 S.RES ERJ2GEJ 181 X (180) T 20.5/58.0
R1143 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 7.8/31.7
R1151 7030005710 S.RES ERJ2GEJ 121 X (120) T 29.2/42.5
R1152 7030009160 S.RES ERJ2GEJ 181 X (180) T 27.3/60.8
R1153 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 9.0/27.9
R1161 7030005710 S.RES ERJ2GEJ 121 X (120) T 32.2/42.2
R1162 7030009160 S.RES ERJ2GEJ 181 X (180) T 33.0/56.1
R1163 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 11.4/31.7
R1171 7030005710 S.RES ERJ2GEJ 121 X (120) T 38.9/44.4
R1172 7030009160 S.RES ERJ2GEJ 181 X (180) T 37.6/60.2
R1173 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 12.6/27.9
R1181 7030005710 S.RES ERJ2GEJ 121 X (120) T 42.4/40.9
R1182 7030009160 S.RES ERJ2GEJ 181 X (180) T 43.6/55.9
R1183 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 15.0/31.7
R1191 7030005710 S.RES ERJ2GEJ 121 X (120) T 47.6/46.1
R1192 7030009160 S.RES ERJ2GEJ 181 X (180) T 47.6/59.3
R1193 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 16.2/27.9
R1201 7030005710 S.RES ERJ2GEJ 121 X (120) T 52.1/40.8
R1202 7030009160 S.RES ERJ2GEJ 181 X (180) T 53.9/56.0
R1203 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 18.6/31.7
R1211 7030005710 S.RES ERJ2GEJ 121 X (120) T 88.5/44.4
R1212 7030009160 S.RES ERJ2GEJ 181 X (180) T 88.9/53.5
R1213 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 19.8/27.9
R1221 7030005710 S.RES ERJ2GEJ 121 X (120) T 77.3/42.2
R1222 7030009160 S.RES ERJ2GEJ 181 X (180) T 76.9/71.3
R1223 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 22.2/31.7
R1231 7030005710 S.RES ERJ2GEJ 121 X (120) T 83.9/46.9
R1232 7030009160 S.RES ERJ2GEJ 181 X (180) T 83.6/63.4
R1233 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 23.4/27.9
R1241 7030005710 S.RES ERJ2GEJ 121 X (120) T 61.3/48.5
R1242 7030009160 S.RES ERJ2GEJ 181 X (180) T 60.8/53.6
R1243 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 25.8/31.7
R1244 7030005120 S.RES ERJ2GEJ 102 X (1 k) [#03] T 62.6/51.2
7030005120 S.RES ERJ2GEJ 102 X (1 k) [#05]
7030005120 S.RES ERJ2GEJ 102 X (1 k) [#06]
R1261 7030005710 S.RES ERJ2GEJ 121 X (120) [#03] T 69.6/40.9
7030005710 S.RES ERJ2GEJ 121 X (120) [#05]
7030005710 S.RES ERJ2GEJ 121 X (120) [#06]
R1262 7030009160 S.RES ERJ2GEJ 181 X (180) [#03] T 72.9/72.8
7030009160 S.RES ERJ2GEJ 181 X (180) [#05]
7030009160 S.RES ERJ2GEJ 181 X (180) [#06]
R1263 7030005220 S.RES ERJ2GEJ 223 X (22 k) [#03] T 27.0/27.9
7030005220 S.RES ERJ2GEJ 223 X (22 k) [#05]
7030005220 S.RES ERJ2GEJ 223 X (22 k) [#06]
R1311 7030004980 S.RES ERJ2GEJ 101 X (100) T 43.3/7.9
R1312 7030004980 S.RES ERJ2GEJ 101 X (100) T 42.8/14.3
R1313 7030004980 S.RES ERJ2GEJ 101 X (100) T 42.3/7.9
R1314 7030009530 S.RES ERJ2GEJ 270 X (27) T 41.8/14.3
R1315 7030004980 S.RES ERJ2GEJ 101 X (100) T 41.3/7.9
R1316 7030004980 S.RES ERJ2GEJ 101 X (100) T 40.8/14.3
R1317 7030004980 S.RES ERJ2GEJ 101 X (100) T 40.3/7.9
R1318 7030004980 S.RES ERJ2GEJ 101 X (100) T 39.8/14.3
R1401 7030012990 S.RES ERJ8GEYJ 561V (560) T 33.9/70.9
R1402 7030012990 S.RES ERJ8GEYJ 561V (560) T 33.9/74.5
R1411 7030012990 S.RES ERJ8GEYJ 561V (560) T 45.4/69.6
R1412 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) T 50.9/69.6
R1413 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) T 50.9/71.3
R1414 7030005530 S.RES ERJ2GEJ 100 X (10) T 54.2/75.5
R1415 7030005590 S.RES ERJ2GEJ 680 X (68) T 57.9/78.9
R1416 7030008370 S.RES ERJ2GEJ 561 X (560) T 47.3/82.8
R1417 7030008370 S.RES ERJ2GEJ 561 X (560) T 47.3/81.9
R1418 7030004980 S.RES ERJ2GEJ 101 X (100) T 48.7/85.1
R1419 7030008370 S.RES ERJ2GEJ 561 X (560) T 63.8/82.6
R1420 7030008370 S.RES ERJ2GEJ 561 X (560) T 61.7/86.6
R1421 7030004980 S.RES ERJ2GEJ 101 X (100) T 62.6/84.3
R1422 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 42.8/85.9
R1423 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 42.8/83.0
R1424 7030012990 S.RES ERJ8GEYJ 561V (560) T 37.0/82.3
R1431 7030009160 S.RES ERJ2GEJ 181 X (180) T 32.5/80.3
R1432 7030010040 S.RES ERJ2GEJ-JPW T 28.1/80.8
R1433 7030010040 S.RES ERJ2GEJ-JPW T 25.8/80.3
R1501 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 51.3/19.5
R1502 7030009140 S.RES ERJ2GEJ 272 X (2.7 k) T 50.8/16.9
R1503 7030012230 S.RES ERJ2GEJ 475 X (4.7 M) T 50.4/19.5
R1504 7030004980 S.RES ERJ2GEJ 101 X (100) T 47.8/29.9
R1505 7030004980 S.RES ERJ2GEJ 101 X (100) T 40.0/27.3
R1511 7030005700 S.RES ERJ2GEJ 274 X (270 k) T 35.2/24.1
R1521 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 44.1/17.1
R1522 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 49.5/19.5
R1523 7030005110 S.RES ERJ2GEJ 224 X (220 k) T 48.5/19.5
R1524 7030005000 S.RES ERJ2GEJ 471 X (470) T 46.4/15.6
R1531 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 42.1/23.5
R1532 7030005230 S.RES ERJ2GEJ 334 X (330 k) T 41.8/25.3
R1533 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 43.0/24.5
R1534 7030005700 S.RES ERJ2GEJ 274 X (270 k) T 44.2/24.0
R1535 7030005000 S.RES ERJ2GEJ 471 X (470) T 43.9/22.7
R1541 7510001511 S.THE NTCG16 4LH 223JT T 52.3/30.2
R1542 7030008300 S.RES ERJ2GEJ 184 X (180 k) T 55.5/29.1
R1543 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 54.3/27.8
R1544 7030007350 S.RES ERJ2GEJ 393 X (39 k) T 50.9/29.5
R1545 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 53.1/26.6
R1546 7030008310 S.RES ERJ2GEJ 564 X (560 k) T 53.1/28.2
R1547 7030004980 S.RES ERJ2GEJ 101 X (100) T 53.3/30.6
R1552 7030008290 S.RES ERJ2GEJ 183 X (18 k) T 39.5/23.1
R1553 7030012220 S.RES ERJ2GEJ 185 X (1.8 M) T 39.1/24.4
R1554 7030007310 S.RES ERJ2GEJ 155 X (1.5 M) T 37.6/23.8
R1555 7030005070 S.RES ERJ2GEJ 683 X (68 k) T 40.0/26.4
R1556 7030005170 S.RES ERJ2GEJ 474 X (470 k) T 40.0/25.5
R1557 7030012350 S.RES ERJ2GEJ 335 X (3.3 M) T 36.4/24.4
R1558 7030005030 S.RES ERJ2GEJ 152 X (1.5 k) T 34.9/26.5
R1560 7030007310 S.RES ERJ2GEJ 155 X (1.5 M) T 44.3/26.6
R1561 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) T 41.1/28.3
R1562 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 43.3/28.4
R1563 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 43.1/27.4
R1564 7030005080 S.RES ERJ2GEJ 823 X (82 k) T 43.1/25.6
R1565 7030008300 S.RES ERJ2GEJ 184 X (180 k) T 45.7/29.7
R1566 7030005230 S.RES ERJ2GEJ 334 X (330 k) T 46.6/29.7
R1567 7030007280 S.RES ERJ2GEJ 331 X (330) T 46.6/31.4
R1568 7030009270 S.RES ERJ2GEJ 821 X (820) T 46.2/32.3
R1569 7030009140 S.RES ERJ2GEJ 272 X (2.7 k) T 33.8/32.9
R1571 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 53.6/24.4
R1573 7030005070 S.RES ERJ2GEJ 683 X (68 k) T 53.6/23.5
R1574 7030004980 S.RES ERJ2GEJ 101 X (100) T 52.0/22.6
R1575 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 53.1/17.7
C102 4030016790 S.CER C1005 JB 1E 103K-T T 106.2/13.0
C103 4030016790 S.CER C1005 JB 1E 103K-T T 103.9/13.0
C201 4030016790 S.CER C1005 JB 1E 103K-T T 100.5/66.0
C202 4030016790 S.CER C1005 JB 1E 103K-T T 99.4/66.0
C1001 4030019120 S.CER GRM188B31E105KA75D T 74.7/11.5
C1002 4030019120 S.CER GRM188B31E105KA75D T 70.3/10.5
C1003 4030016790 S.CER C1005 JB 1E 103K-T T 70.2/8.5
C1020 4030017780 S.CER C1005 JB 1H 472K-T T 89.9/13.1
C1021 4030019990 S.CER C1005 JB 1C 104K-T T 92.6/9.2
C1022 4030019990 S.CER C1005 JB 1C 104K-T T 93.5/9.2
C1023 4030019990 S.CER C1005 JB 1C 104K-T T 96.2/8.3
C1024 4030019990 S.CER C1005 JB 1C 104K-T T 93.1/19.6
C1031 4030017780 S.CER C1005 JB 1H 472K-T T 97.3/15.7
C1033 4030019990 S.CER C1005 JB 1C 104K-T T 96.1/22.3
C1034 4030017760 S.CER C1005 JB 1H 222K-T T 95.4/26.4
C1041 4030019990 S.CER C1005 JB 1C 104K-T T 91.5/30.2
C1042 4030019990 S.CER C1005 JB 1C 104K-T T 90.6/30.2
C1043 4030019990 S.CER C1005 JB 1C 104K-T T 94.1/31.8
C1044 4030019990 S.CER C1005 JB 1C 104K-T T 92.2/20.9
C1045 4030019990 S.CER C1005 JB 1C 104K-T T 88.2/26.4
C1051 4030016790 S.CER C1005 JB 1E 103K-T T 84.4/31.9
C1052 4030019990 S.CER C1005 JB 1C 104K-T T 83.3/29.1
C1053 4030019990 S.CER C1005 JB 1C 104K-T T 80.6/30.4
C1055 4030019990 S.CER C1005 JB 1C 104K-T T 83.5/23.6
C1056 4030019990 S.CER C1005 JB 1C 104K-T T 80.7/27.0
C1061 4030019460 S.CER C1608 JB 0J 106M-T T 65.1/11.8
C1062 4030019620 S.CER GRM188B31C225KE14D T 64.1/6.7
C1071 4030019990 S.CER C1005 JB 1C 104K-T T 75.5/12.9
C1081 4030019120 S.CER GRM188B31E105KA75D T 70.7/15.6
C1082 4030019990 S.CER C1005 JB 1C 104K-T T 75.0/15.1
C1083 4030019120 S.CER GRM188B31E105KA75D T 68.6/18.5
C1084 4030019990 S.CER C1005 JB 1C 104K-T T 75.5/22.3
C1085 4030019990 S.CER C1005 JB 1C 104K-T T 68.2/26.1
C1091 4030019990 S.CER C1005 JB 1C 104K-T T 6.8/76.2
C1092 4030019990 S.CER C1005 JB 1C 104K-T T 4.2/71.5
C1101 4030019120 S.CER GRM188B31E105KA75D T 76.5/29.4
C1102 4030019990 S.CER C1005 JB 1C 104K-T T 73.8/25.8
C1103 4030018600 S.CER C1608 CH 1H 152J-T T 73.8/28.0
C1104 4030020930 S.CER C1608 CH 1H 682JT T 73.1/30.0
C1105 4030020840 S.CER C1608 CH 1H 272J-T T 72.4/32.0
C1106 4030011540 S.CER C1608 CH 1H 750J-T T 67.0/39.4
C1107 4030007140 S.CER C1608 CH 1H 121J-T T 62.4/39.4
C1108 4030011540 S.CER C1608 CH 1H 750J-T T 59.7/39.4
C1111 403001999 0 S.CER C1005 JB 1C 104K-T T 93.8/ 39.0
C1112 4030019990 S.CER C1005 JB 1C 104K-T T 96.3/43.4
C1113 4030018600 S.CER C1608 CH 1H 152J-T T 94.2/43.4
C1115 4030019570 S.CER C1608 CH 1H 332J-T T 93.2/49.1
C1117 4030018600 S.CER C1608 CH 1H 152J-T T 95.4/53.1
C1121 4030019990 S.CER C1005 JB 1C 104K-T T 8.2/39.1
C1122 4030019990 S.CER C1005 JB 1C 104K-T T 7.5/40.0
C1123 4030018620 S.CER C1608 CH 1H 222J-T T 11.4/46.7
C1125 4030017810 S.CER C1608 CH 1H 102J-T T 10.8/56.6
C1127 4030018620 S.CER C1608 CH 1H 222J-T T 10.8/65.6
C1129 4030019990 S.CER C1005 JB 1C 104K-T T 6.2/68.5
C1131 4030019990 S.CER C1005 JB 1C 104K-T T 14.2/42.2
C1132 4030019990 S.CER C1005 JB 1C 104K-T T 15.1/44.1
C1133 4030018620 S.CER C1608 CH 1H 222J-T T 17.6/42.9
C1135 4030017870 S.CER C1608 CH 1H 681J-T T 16.3/50.4
C1137 4030018620 S.CER C1608 CH 1H 222J-T T 17.1/60.7
C1139 4030019990 S.CER C1005 JB 1C 104K-T T 14.4/66.4
C1141 4030019990 S.CER C1005 JB 1C 104K-T T 22.1/38.9
C1142 4030019990 S.CER C1005 JB 1C 104K-T T 20.3/39.9
(Amended page)
October 2016

10
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[RF UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
[RF UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
C1143 4030018620 S.CER C1608 CH 1H 222J-T T 26.0/42.0
C1145 4030011330 S.CER C1608 CH 1H 391J-T T 21.5/48.9
C1147 4030018620 S.CER C1608 CH 1H 222J-T T 22.6/58.0
C1149 4030019990 S.CER C1005 JB 1C 104K-T T 20.5/59.3
C1151 4030019990 S.CER C1005 JB 1C 104K-T T 28.7/41.2
C1152 4030019990 S.CER C1005 JB 1C 104K-T T 28.8/43.8
C1153 4030018600 S.CER C1608 CH 1H 152J-T T 28.1/48.8
C1155 4030007170 S.CER C1608 CH 1H 221J-T T 26.7/52.2
C1157 4030018600 S.CER C1608 CH 1H 152J-T T 29.1/61.9
C1159 4030019990 S.CER C1005 JB 1C 104K-T T 26.9/62.1
C1161 4030019990 S.CER C1005 JB 1C 104K-T T 31.8/41.0
C1162 4030019990 S.CER C1005 JB 1C 104K-T T 32.2/43.5
C1163 4030018590 S.CER C1608 CH 1H 122J-T T 33.4/45.9
C1165 4030010750 S.CER C1608 CH 1H 201J-T T 32.9/48.0
C1167 4030018590 S.CER C1608 CH 1H 122J-T T 33.9/60.1
C1169 4030019990 S.CER C1005 JB 1C 104K-T T 32.6/57.7
C1171 4030019990 S.CER C1005 JB 1C 104K-T T 38.0/43.5
C1172 4030019990 S.CER C1005 JB 1C 104K-T T 37.1/44.4
C1173 4030017870 S.CER C1608 CH 1H 681J-T T 39.5/50.0
C1175 4030007160 S.CER C1608 CH 1H 181J-T T 38.9/51.8
C1177 4030017870 S.CER C1608 CH 1H 681J-T T 39.6/61.8
C1179 4030019990 S.CER C1005 JB 1C 104K-T T 37.1/61.8
C1181 4030019990 S.CER C1005 JB 1C 104K-T T 41.4/40.9
C1182 4030019990 S.CER C1005 JB 1C 104K-T T 42.0/42.1
C1183 4030017800 S.CER C1608 CH 1H 561J-T T 46.9/42.5
C1185 4030007140 S.CER C1608 CH 1H 121J-T T 43.3/46.8
C1187 4030017800 S.CER C1608 CH 1H 561J-T T 44.3/60.0
C1189 4030019990 S.CER C1005 JB 1C 104K-T T 43.1/57.3
C1191 4030019990 S.CER C1005 JB 1C 104K-T T 47.2/44.9
C1192 4030019990 S.CER C1005 JB 1C 104K-T T 47.2/47.5
C1193 4030011330 S.CER C1608 CH 1H 391J-T T 49.3/45.3
C1195 4030007120 S.CER C1608 CH 1H 820J-T T 49.0/51.8
C1197 4030011330 S.CER C1608 CH 1H 391J-T T 49.3/61.0
C1199 4030019990 S.CER C1005 JB 1C 104K-T T 47.1/61.0
C1201 4030019990 S.CER C1005 JB 1C 104K-T T 51.1/40.8
C1202 4030019990 S.CER C1005 JB 1C 104K-T T 51.6/42.0
C1203 4030011280 S.CER C1608 CH 1H 271J-T T 54.4/40.9
C1205 4030007110 S.CER C1608 CH 1H 680J-T T 54.2/48.0
C1207 4030011280 S.CER C1608 CH 1H 271J-T T 54.6/58.4
C1209 4030019990 S.CER C1005 JB 1C 104K-T T 53.4/57.3
C1211 4030019990 S.CER C1005 JB 1C 104K-T T 87.3/44.0
C1212 4030019990 S.CER C1005 JB 1C 104K-T T 88.1/45.6
C1213 4030007100 S.CER C1608 CH 1H 560J-T T 90.2/44.7
C1215 4030007120 S.CER C1608 CH 1H 820J-T T 91.0/46.5
C1217 4030007100 S.CER C1608 CH 1H 560J-T T 90.7/53.8
C1219 4030019990 S.CER C1005 JB 1C 104K-T T 88.0/53.5
C1220 4030019990 S.CER C1005 JB 1C 104K-T T 76.9/70.4
C1221 4030019990 S.CER C1005 JB 1C 104K-T T 76.9/41.0
C1222 4030019990 S.CER C1005 JB 1C 104K-T T 76.9/43.5
C1223 4030007100 S.CER C1608 CH 1H 560J-T T 81.1/44.1
C1224 4030007170 S.CER C1608 CH 1H 221J-T T 79.2/43.4
C1225 4030011540 S.CER C1608 CH 1H 750J-T T 80.4/46.7
C1226 4030007100 S.CER C1608 CH 1H 560J-T T 77.4/53.8
C1227 4030007070 S.CER C1608 CH 1H 330J-T T 78.1/55.2
C1228 4030007110 S.CER C1608 CH 1H 680J-T T 77.4/59.7
C1229 4030007040 S.CER C1608 CH 1H 180J-T T 80.6/62.7
C1230 4030007080 S.CER C1608 CH 1H 390J-T T 77.7/65.8
C1231 4030019990 S.CER C1005 JB 1C 104K-T T 82.7/47.6
C1232 4030019990 S.CER C1005 JB 1C 104K-T T 84.1/43.4
C1233 4030007110 S.CER C1608 CH 1H 680J-T T 85.1/48.3
C1234 4030009990 S.CER C1608 CH 1H 200J-T T 85.1/52.7
C1235 4030007090 S.CER C1608 CH 1H 470J-T T 82.4/53.9
C1239 4030019990 S.CER C1005 JB 1C 104K-T T 83.6/64.3
C1241 4030019990 S.CER C1005 JB 1C 104K-T T 60.0/49.0
C1242 4030019990 S.CER C1005 JB 1C 104K-T T 60.0/48.1
C1243 4030010750 S.CER C1608 CH 1H 201J-T T 63.8/48.1
C1245 4030007000 S.CER C1608 CH 1H 090D-T T 64.6/51.2
C1247 4030010750 S.CER C1608 CH 1H 201J-T T 61.1/56.0
C1249 4030019990 S.CER C1005 JB 1C 104K-T T 60.3/57.6
C1250 4030007090 S.CER C1608 CH 1H 470J-T T 60.3/60.6
C1251 4030007110 S.CER C1608 CH 1H 680J-T T 61.0/62.5
C1252 4030007130 S.CER C1608 CH 1H 101J-T T 60.3/64.4
C1253 4030007070 S.CER C1608 CH 1H 330J-T T 62.9/65.7
C1254 4030007120 S.CER C1608 CH 1H 820J-T T 60.3/65.7
C1255 4030007060 S.CER C1608 CH 1H 270J-T T 64.6/71.8
C1256 4030007090 S.CER C1608 CH 1H 470J-T T 60.0/71.9
C1257 4030019990 S.CER C1005 JB 1C 104K-T [#03] T 62.6/50.3
4030019990 S.CER C1005 JB 1C 104K-T [#05]
4030019990 S.CER C1005 JB 1C 104K-T [#06]
C1261 4030019990 S.CER C1005 JB 1C 104K-T [#03] T 69.2/39.7
4030019990 S.CER C1005 JB 1C 104K-T [#05]
4030019990 S.CER C1005 JB 1C 104K-T [#06]
C1262 4030019990 S.CER C1005 JB 1C 104K-T [#03] T 69.1/42.1
4030019990 S.CER C1005 JB 1C 104K-T [#05]
4030019990 S.CER C1005 JB 1C 104K-T [#06]
C1263 4030007130 S.CER C1608 CH 1H 101J-T [#03] T 69.6/43.6
4030007130 S.CER C1608 CH 1H 101J-T [#05]
4030007130 S.CER C1608 CH 1H 101J-T [#06]
C1265 4030007020 S.CER C1608 CH 1H 120J-T [#03] T 72.8/44.3
4030007020 S.CER C1608 CH 1H 120J-T [#05]
4030007020 S.CER C1608 CH 1H 120J-T [#06]
C1267 4030007130 S.CER C1608 CH 1H 101J-T [#03] T 67.9/50.7
4030007130 S.CER C1608 CH 1H 101J-T [#05]
4030007130 S.CER C1608 CH 1H 101J-T [#06]
C1269 4030007070 S.CER C1608 CH 1H 330J-T [#03] T 67.9/54.1
4030007070 S.CER C1608 CH 1H 330J-T [#05]
4030007070 S.CER C1608 CH 1H 330J-T [#06]
C1270 4030007030 S.CER C1608 CH 1H 150J-T [#03] T 70.9/55.7
4030007030 S.CER C1608 CH 1H 150J-T [#05]
4030007030 S.CER C1608 CH 1H 150J-T [#06]
C1271 4030011540 S.CER C1608 CH 1H 750J-T [#03] T 67.9/55.8
4030011540 S.CER C1608 CH 1H 750J-T [#05]
4030011540 S.CER C1608 CH 1H 750J-T [#06]
C1272 4030006990 S.CER C1608 CH 1H 080D-T [#03] T 68.6/58.1
4030006990 S.CER C1608 CH 1H 080D-T [#05]
4030006990 S.CER C1608 CH 1H 080D-T [#06]
C1273 4030007090 S.CER C1608 CH 1H 470J-T [#03] T 67.9/60.3
4030007090 S.CER C1608 CH 1H 470J-T [#05]
4030007090 S.CER C1608 CH 1H 470J-T [#06]
C1274 4030007120 S.CER C1608 CH 1H 820J-T [#03] T 72.5/61.9
4030007120 S.CER C1608 CH 1H 820J-T [#05]
4030007120 S.CER C1608 CH 1H 820J-T [#06]
C1275 4030007090 S.CER C1608 CH 1H 470J-T [#03] T 70.2/61.5
4030007090 S.CER C1608 CH 1H 470J-T [#05]
4030007090 S.CER C1608 CH 1H 470J-T [#06]
C1276 4030007070 S.CER C1608 CH 1H 330J-T [#03] T 72.5/64.7
4030007070 S.CER C1608 CH 1H 330J-T [#05]
4030007070 S.CER C1608 CH 1H 330J-T [#06]
C1277 4030007130 S.CER C1608 CH 1H 101J-T [#03] T 71.0/66.6
4030007130 S.CER C1608 CH 1H 101J-T [#05]
4030007130 S.CER C1608 CH 1H 101J-T [#06]
C1278 4030007060 S.CER C1608 CH 1H 270J-T [#03] T 71.8/68.7
4030007060 S.CER C1608 CH 1H 270J-T [#05]
4030007060 S.CER C1608 CH 1H 270J-T [#06]
C1279 4030010760 S.CER C1608 CH 1H 331J-T [#03] T 71.0/71.1
4030010760 S.CER C1608 CH 1H 331J-T [#05]
4030010760 S.CER C1608 CH 1H 331J-T [#06]
C1280 4030007090 S.CER C1608 CH 1H 470J-T [#03] T 73.3/70.2
4030007090 S.CER C1608 CH 1H 470J-T [#05]
4030007090 S.CER C1608 CH 1H 470J-T [#06]
C1291 4030008560 S.CER C1608 CH 1H 300J-T T 85.1/53.9
C1292 4030007160 S.CER C1608 CH 1H 181J-T T 85.1/59.1
C1293 4030007080 S.CER C1608 CH 1H 390J-T T 86.6/61.3
C1294 4030007120 S.CER C1608 CH 1H 820J-T T 85.9/63.8
C1295 4030007090 S.CER C1608 CH 1H 470J-T T 86.6/65.7
C1301 4030019990 S.CER C1005 JB 1C 104K-T T 30.7/18.6
C1302 4030019990 S.CER C1005 JB 1C 104K-T T 21.1/18.6
C1303 4030019990 S.CER C1005 JB 1C 104K-T T 11.6/18.6
C1311 4030017460 S.CER C1005 JB 1H 102K-T T 43.3/5.7
C1312 4030017460 S.CER C1005 JB 1H 102K-T T 42.8/16.4
C1313 4030017400 S.CER C1005 CH 1H 220J-T T 42.3/5.7
C1314 4030017400 S.CER C1005 CH 1H 220J-T T 41.8/16.4
C1315 4030017460 S.CER C1005 JB 1H 102K-T T 41.3/5.7
C1316 4030017400 S.CER C1005 CH 1H 220J-T T 40.8/16.4
C1317 4030017460 S.CER C1005 JB 1H 102K-T T 40.3/5.7
C1318 4030017460 S.CER C1005 JB 1H 102K-T T 39.8/16.4
C1319 4030017460 S.CER C1005 JB 1H 102K-T T 39.3/5.7
C1320 4030017460 S.CER C1005 JB 1H 102K-T T 38.8/16.4
C1321 4030017460 S.CER C1005 JB 1H 102K-T T 38.3/5.7
C1322 4030017460 S.CER C1005 JB 1H 102K-T T 37.8/16.4
C1323 4030017460 S.CER C1005 JB 1H 102K-T T 37.3/5.7
C1324 4030017460 S.CER C1005 JB 1H 102K-T T 36.8/16.4
C1325 4030017460 S.CER C1005 JB 1H 102K-T T 36.3/5.7
C1326 4030017460 S.CER C1005 JB 1H 102K-T T 35.8/16.4
C1401 4030019990 S.CER C1005 JB 1C 104K-T T 35.4/72.7
C1402 4030019990 S.CER C1005 JB 1C 104K-T T 26.7/70.9
C1411 4030019990 S.CER C1005 JB 1C 104K-T T 38.5/69.6
C1412 4030019560 S.CER GRM21BB31C106KE15L T 53.6/71.3
C1413 4030019120 S.CER GRM188B31E105KA75D T 52.0/70.1
C1414 4030019120 S.CER GRM188B31E105KA75D T 48.8/70.1
C1415 4030019120 S.CER GRM188B31E105KA75D T 50.4/80.3
C1416 4030019120 S.CER GRM188B31E105K A75D T 48.8/80.3
C1417 4030019120 S.CER GRM188B31E105KA75D T 38.9/75.1
C1418 4030017640 S.CER C1005 CH 1H 150J-T T 54.6/74.3
C1419 4030019120 S.CER GRM188B31E105KA75D T 59.8/82.0
C1420 4030019120 S.CER GRM188B31E105KA75D T 59.8/84.9
C1421 4030019120 S.CER GRM188B31E105KA75D T 62.6/82.1
C1422 4030019990 S.CER C1005 JB 1C 104K-T T 41.0/84.5
C1423 4030019120 S.CER GRM188B31E105KA75D T 51.0/85.1
C1424 4030019990 S.CER C1005 JB 1C 104K-T T 44.8/86.8
C1425 4030019990 S.CER C1005 JB 1C 104K-T T 41.0/81.6
C1426 4030019120 S.CER GRM188B31E105KA75D T 51.0/86.4
C1431 4030019990 S.CER C1005 JB 1C 104K-T T 31.1/80.8
C1501 4030019990 S.CER C1005 JB 1C 104K-T T 49.0/29.5
C1502 4030019990 S.CER C1005 JB 1C 104K-T T 35.0/28.3
C1513 4030019120 S.CER GRM188B31E105KA75D T 33.5/19.6
C1551 4030019620 S.CER GRM188B31C225KE14D T 36.3/21.7
C1553 4030017460 S.CER C1005 JB 1H 102K-T T 36.4/23.5
C1561 4030016790 S.CER C1005 JB 1E 103K-T T 41.8/26.9
C1562 4030019990 S.CER C1005 JB 1C 104K-T T 43.1/26.5
C1565 4030019120 S.CER GRM188B31E105KA75D T 41.6/33.2
C1569 4030008770 S.CER C1608 JB 1H 562K-T T 43.6/30.3
C1571 4030019990 S.CER C1005 JB 1C 104K-T T 54.9/17.7
RL101 6330002020 REL FTR-B4CA009Z
J101 6450002520 CON RL-1515-2(B.B)-L
J201 6510031660 CON LGR4609-7100F
J1001 6510028210 CON SJ050010 (TMP-J01X-V6)
J1071 6510028210 CON SJ050010 (TMP-J01X-V6)
J1311 6510021722 S.CON 30FLT-SM2-TB (LF) (SN) (M) T 42.0/11.0
J1431 6510028210 CON SJ050010 (TMP-J01X-V6)
EP101 6910023350 S.BEA MMZ1005B601CT T 97.5/37.1
EP102 6910018930 S.BEA MPZ2012S601A T 103.8/26.4
EP201 6910023350 S.BEA MMZ1005B601CT T 100.5/68.1
EP202 6910023350 S.BEA MMZ1005B601CT T 99.4/68.1
EP1021 6910018460 S.BEA MMZ1005Y102C-T T 94.3/19.1
EP1022 6910018460 S.BEA MMZ1005Y102C-T T 96.2/9.9
EP1041 6910018460 S.BEA MMZ1005Y102C-T T 93.4/21.3
EP1042 6910018460 S.BEA MMZ1005Y102C-T T 93.3/30.2
EP1051 6910018460 S.BEA MMZ1005Y102C-T T 81.5/31.5
EP1053 6910018460 S.BEA MMZ1005Y102C-T T 81.9/27.5
EP1311 6910019900 S.BEA MPZ1608S601AT T 50.0/7.6
(Amended page)
October 2016

11
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[RF UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
[PA UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
EP1312 6910019900 S.BEA MPZ1608S601AT T 49.4/14.0
EP1313 6910023350 S.BEA MMZ1005B601CT T 46.8/14.3
EP1314 6910021240 S.BEA MMZ1005A152ET T 39.3/7.9
EP1315 6910021240 S.BEA MMZ1005A152ET T 38.8/14.3
EP1316 6910021240 S.BEA MMZ1005A152ET T 38.3/7.9
EP1317 6910021240 S.BEA MMZ1005A152ET T 37.8/14.3
EP1318 6910021240 S.BEA MMZ1005A152ET T 37.3/7.9
EP1319 6910021240 S.BEA MMZ1005A152ET T 36.8/14.3
EP1320 6910021240 S.BEA MMZ1005A152ET T 36.3/7.9
EP1321 6910021240 S.BEA MMZ1005A152ET T 35.8/14.3
IC211 1110007950 S.IC INA199A2DCKR T 98.6/90.2
IC221 1180002080 S.REG BA09FP-E2 T 105.4/72.7
IC751 1130010550 S.IC SN74AHC595PWR T 20.5/81.0
IC981 1110008550 S.IC NJM2904CRB1-TE1-#HMZR T 9.9/72.1
Q101 1560001091 S.FET 2SK2854 (T2LICOMF) T 19.3/165.5
Q111 1560001550 S.FET RD01MUS2-T113 T 30.0/161.9
Q121 1560001530 FET RD15HVF1-101
Q131 1560001591 FET RD70HVF1C-121
Q132 1560001591 FET RD70HVF1C-121
Q221 1590005140 S.FET TJ50S06M3L T 107.0/82.3
Q222 1560002190 S.FET RUM002N02T2L T 112.5/81.8
Q341 1590004690 S.TRA LDTC143ZET1G T 10.9/103.8
Q342 1590004310 S.TRA LDTA114EET1G T 13.2/103.8
Q771 1590004690 S.TRA LDTC143ZET1G T 28.0/73.7
Q772 1590004690 S.TRA LDTC143ZET1G T 28.0/75.8
Q773 1590004690 S.TRA LDTC143ZET1G T 28.0/77.9
Q774 1590004690 S.TRA LDTC143ZET1G T 28.0/80.0
Q775 1590004690 S.TRA LDTC143ZET1G T 28.0/82.1
Q776 1590004690 S.TRA LDTC143ZET1G T 28.0/84.2
Q777 1590004690 S.TRA LDTC143ZET1G T 28.0/86.3
Q778 1590004690 S.TRA LDTC143ZET1G T 28.0/88.4
Q781 1590004040 S.TRA LDTA123YET1G T 30.4/73.2
Q782 1590004040 S.TRA LDTA123YET1G T 30.4/75.3
Q783 1590004040 S.TRA LDTA123YET1G T 30.4/77.4
Q784 1590004040 S.TRA LDTA123YET1G T 30.4/79.5
Q785 1590004040 S.TRA LDTA123YET1G T 30.4/81.6
Q786 1590004040 S.TRA LDTA123YET1G T 30.4/83.7
Q787 1590004040 S.TRA LDTA123YET1G T 30.4/85.8
Q811 1530003960 S.TRA KTC2875-B-RTK/P T 44.2/4.7
D101 1750001180 S.DIO KDS122 RTK/P T 12.3/157.8
D102 1750001180 S.DIO KDS122 RTK/P T 14.8/157.8
D171 1750001810 S.DIO L1SS400T1G T 66.4/126.3
D172 1750001810 S.DIO L1SS400T1G T 37.5/126.3
D201 1750002000 S.ZEN DZ2J180M0L T 86.4/132.6
D202 1710000831 S.DIO DF30SC4M-7072 T 97.5/130.4
D203 1750003510 S.ZEN TPSMD15A T 79.0/142.5
D301 1750002230 S.DIO LRB751S-40T1G T 76.6/133.4
D302 1750002230 S.DIO LRB751S-40T1G T 27.4/133.4
D801 1750001180 S.DIO KDS122 RTK/P T 76.9/6.8
D811 1750003100 S.DIO BAR64-02V T 50.7/4.8
D812 1750003100 S.DIO BAR64-02V T 47.3/4.8
D820 1750001180 S.DIO KDS122 RTK/P T 41.7/58.3
D840 1750001180 S.DIO KDS122 RTK/P T 99.5/64.8
D860 1750001180 S.DIO KDS122 RTK/P T 87.3/64.8
D880 1750001180 S.DIO KDS122 RTK/P T 53.6/58.3
D900 1750001180 S.DIO KDS122 RTK/P T 15.2/58.8
D92 0 175 00 0118 0 S. DI O K DS12 2 R TK / P T 111. 4/ 64 .8
D940 1750001180 S.DIO KDS122 RTK/P T 29.1/58.3
D961 1750002230 S.DIO LRB751S-40T1G T 84.3/2.2
D962 1750002230 S.DIO LRB751S-40T1G T 98.1/2.2
D965 1750001810 S.DIO L1SS400T1G T 24.3/88.9
D966 1750001810 S.DIO L1SS400T1G T 24.3/87.6
L101 6200005051 S.COI NLV25T-330J-PF B 65.0/49.2
L112 6200005131 S.COI NLC453232T-101K-PF T 32.8/156.5
L121 6200010160 S.COI AS080440-22N T 43.6/150.8
L131 6140005580 COI LR-606
L132 6140005300 COI LR-580 (TRB10X5X5 6DB)
L133 6140005570 COI LR-605
L134 6140004570 COI LR-507
L306 6110001730 COI LA-262
L331 6200003241 S.COI NLV32T-221J-PF T 12.3/140.4
L332 6200003241 S.COI NLV32T-221J-PF T 12.3/143.4
L711 6200002041 S.COI NLV25T-101J-PF T 102.4/66.9
L801 6200010650 S.COI C2520C-R12G-A (0.12U) T 62.3/4.0
L802 6200010650 S.COI C2520C-R12G-A (0.12U) T 66.7/5.0
L803 6200002041 S.COI NLV25T-101J-PF T 76.9/4.3
L820 6200002041 S.COI NLV25T-101J-PF T 38.9/58.7
L822 6110002900 COI LA-479
L823 6140003460 COI LR-388 (T50-10)
L831 6200002041 S.COI NLV25T-101J-PF T 52.5/11.3
L840 6200002041 S.COI NLV25T-101J-PF T 96.7/65.1
L841 6140001820 COI LR-218 (T50-10)
L842 6140001800 COI LR-216 (T50-2)
L851 6200002041 S.COI NLV25T-101J-PF T 97.3/18.0
L860 6200002041 S.COI NLV25T-101J-PF T 82.6/65.1
L861 6110003980 COI LA-604
L862 6110003880 COI LA-590
L863 6110003550 COI LA-547 (LA-214A)
L871 6200002041 S.COI NLV25T-101J-PF T 82.7/17.4
L880 6200002041 S.COI NLV25T-101J-PF T 50.8/58.7
L881 6140002570 COI LR-294 (T50-2)
L882 6140002580 COI LR-295 (T50-2)
L891 6200002041 S.COI NLV25T-101J-PF T 67.3/10.4
L900 6200002041 S.COI NLV25T-101J-PF T 12.4/59.4
L901 6140002560 COI LR-293 (T50-10)
L902 6140002560 COI LR-293 (T50-10)
L903 6140002560 COI LR-293 (T50-10)
L911 6200002041 S.COI NLV25T-101J-PF T 23.0/11.3
L920 6200002041 S.COI NLV25T-101J-PF T 108.6/64.3
L921 6140001800 COI LR-216 (T50-2)
L922 6140001780 COI LR-214 (T50-2)
L931 6200002041 S.COI NLV25T-101J-PF T 112.0/18.6
L940 6200002041 S.COI NLV25T-101J-PF T 26.3/58.7
L942 6140003540 COI LR-396
L943 6140002020 COI LR-229 (T50-10)
L951 6200002041 S.COI NLV25T-101J-PF T 37.8/11.3
L952 6200002041 S.COI NLV25T-101J-PF T 3.3/58.5
L961 6140004721 COI LR-532A
(Amended page)
October 2016

12
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[PA UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
[PA UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
L981 6200002041 S.COI NLV25T-101J-PF T 14.1/71.0
R101 7030008280 S.RES ERJ2GEJ 271 X (270) T 12.1/159.9
R102 7030010090 S.RES ERJ2GEJ 180 X (18) T 15.0/159.9
R103 7030008280 S.RES ERJ2GEJ 271 X (270) T 16.8/159.9
R104 7030005590 S.RES ERJ2GEJ 680 X (68) T 15.9/163.0
R105 7030009270 S.RES ERJ2GEJ 821 X (820) T 20.4/162.3
R106 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) T 15.1/165.5
R107 7030005290 S.RES ERJ2GEJ 682 X (6.8 k) T 15.9/164.2
R108 7030005000 S.RES ERJ2GEJ 471 X (470) T 24.9/164.8
R109 7030008190 S.RES ERJ12YJ330U (33) T 14.2/153.2
R111 7030005580 S.RES ERJ2GEJ 560 X (56) T 26.3/165.4
R112 7030009140 S.RES ERJ2GEJ 272 X (2.7 k) T 26.9/167.8
R113 7030005290 S.RES ERJ2GEJ 682 X (6.8 k) T 25.4/166.4
R114 7030009270 S.RES ERJ2GEJ 821 X (820) T 26.8/160.9
R115 7030005000 S.RES ERJ2GEJ 471 X (470) T 26.6/157.2
R121 7030005580 S.RES ERJ2GEJ 560 X (56) T 37.2/163.9
R122 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 34.1/164.0
R123 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 35.5/165.5
R124 7030004980 S.RES ERJ2GEJ 101 X (100) T 35.5/166.5
R125 7030006230 S.RES ERJ12YJ151U (150) T 37.8/152.8
R131 7030010520 S.RES ERJ1TYJ 101U (100) T 52.0/131.6
R132 7030009300 S.RES ERJ1WY0R00U T 62.5/132.0
R133 7030009300 S.RES ERJ1WY0R00U T 41.5/132.0
R134 7030013970 S.RES LTR50UZPJ220 T 72.5/132.4
R135 7030004980 S.RES ERJ2GEJ 101 X (100) T 78.9/133.4
R136 7030013970 S.RES LTR50UZPJ220 T 31.5/132.4
R137 7030004980 S.RES ERJ2GEJ 101 X (100) T 25.1/133.4
R138 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) T 64.1/126.2
R139 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) T 39.9/126.2
R140 7030013980 S.RES LTR50UZPJ270 T 56.2/124.9
R141 7030013970 S.RES LTR50UZPJ220 T 56.2/119.3
R142 7030013940 S.RES ERJB1BJR68U (0.68) T 72.5/128.6
R143 7030013940 S.RES ERJB1BJR68U (0.68) T 31.5/128.6
R144 7030013970 S.RES LTR50UZPJ220 T 47.8/119.3
R145 7030013980 S.RES LTR50UZPJ270 T 47.8/124.9
R146 7030014120 S.RES LTR50UZPJ6R8 T 52.0/124.9
R147 7030013960 S.RES LTR50UZPJ100 T 71.6/85.5
R148 7030013960 S.RES LTR50UZPJ100 T 71.6/80.0
R211 7030012720 S.RES PMR50HZPFV1L00 (0.001) T 99.0/94.2
R212 7030004980 S.RES ERJ2GEJ 101 X (100) T 100.4/90.9
R213 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 96.9/89.9
R221 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 112.5/85.2
R222 7030005080 S.RES ERJ2GEJ 823 X (82 k) T 112.5/83.5
R223 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 112.5/80.3
R224 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 112.5/79.0
R225 7030010570 S.RES ERJ1TYJ 4R7U (4.7) T 99.0/81.0
R301 7030004980 S.RES ERJ2GEJ 101 X (100) T 12.9/91.8
R302 7030004980 S.RES ERJ2GEJ 101 X (100) T 6.5/92.3
R303 7030004980 S.RES ERJ2GEJ 101 X (100) T 6.5/93.3
R304 7030004980 S.RES ERJ2GEJ 101 X (100) T 12.9/95.8
R305 7030004980 S.RES ERJ2GEJ 101 X (100) T 6.5/97.3
R306 7030004980 S.RES ERJ2GEJ 101 X (100) T 12.9/97.8
R307 7030004980 S.RES ERJ2GEJ 101 X (100) T 6.5/98.3
R308 7030004980 S.RES ERJ2GEJ 101 X (100) T 12.9/98.8
R351 7510001470 S.THE NTCG20 4AG 473JT T 20.0/105.5
R352 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 18.2/106.5
R811 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 40.9/3.4
R812 7030007570 S.RES ERJ2GEJ 122 X (1.2 k) T 42.3/5.2
R813 7030009280 S.RES ERJ2GEJ 391 X T 41.1/5.6
R814 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 52.9/4.7
R815 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 52.9/3.1
R816 7030005030 S.RES ERJ2GEJ 152 X (1.5 k) T 51.7/2.9
R817 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 49.6/2.9
R961 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 82.3/8.4
R962 7030007180 S.RES ERJ12YJ150U (15) T 80.5/3.8
R963 7030007180 S.RES ERJ12YJ150U (15) T 100.8/3.8
R964 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 98.7/8.4
R981 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 7.5/75.1
R982 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 9.4/75.7
R983 7030005720 S.RES ERJ2GEJ 563 X (56 k) T 10.4/76.8
R984 7030005060 S.RES ERJ2GEJ 333 X (33 k) T 10.8/75.3
R985 7030007280 S.RES ERJ2GEJ 331 X (330) T 12.6/75.3
R986 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 13.0/76.8
R987 7030010040 S.RES ERJ2GEJ-JPW T 7.4/69.4
R988 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 8.4/68.4
R989 7030005720 S.RES ERJ2GEJ 563 X (56 k) T 9.4/67.5
R990 7030005060 S.RES ERJ2GEJ 333 X (33 k) T 9.9/68.8
R991 7030007280 S.RES ERJ2GEJ 331 X (330) T 11.7/68.8
R992 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 12.1/67.4
C102 4030019990 S.CER C1005 JB 1C 104K-T T 15.9/161.4
C103 4030019990 S.CER C1005 JB 1C 104K-T T 16.1/165.5
C104 4030016790 S.CER C1005 JB 1E 103K-T T 18.3/162.3
C105 4030019990 S.CER C1005 JB 1C 104K-T T 19.5/161.3
C106 4510010570 S.ELE 16 CE 470 LX T 20.5/155.5
C107 4030019990 S.CER C1005 JB 1C 104K-T T 17.0/150.6
C111 4030019990 S.CER C1005 JB 1C 104K-T T 26.3/164.4
C112 4030019990 S.CER C1005 JB 1C 104K-T T 25.9/167.8
C113 4030016790 S.CER C1005 JB 1E 103K-T T 26.8/163.0
C114 4030019990 S.CER C1005 JB 1C 104K-T T 25.4/157.2
C115 4030019990 S.CER C1005 JB 1C 104K-T T 25.4/153.7
C116 4510009920 S.ELE 16 CE 100 LH T 30.0/149.4
C121 4030019990 S.CER C1005 JB 1C 104K-T T 36.9/162.9
C122 4030019990 S.CER C1005 JB 1C 104K-T T 35.1/164.3
C123 4030017460 S.CER C1005 JB 1H 102K-T T 36.0/164.3
C124 4030017460 S.CER C1005 JB 1H 102K-T T 38.0/166.5
C125 4030018640 S.CER C2012 CH 1H 103J-T T 35.6/157.7
C131 4030018340 S.CER GRM31A5C2J331JW01D T 52.0/152.1
C132 4030006900 S.CER C1608 JB 1H 103K-T T 64.8/154.9
C133 4030017320 S.CER GRM21BB11H104KA01L T 63.0/154.9
C134 4510010570 S.ELE 16 CE 470 LX T 70.1/157.1
C135 4030019990 S.CER C1005 JB 1C 104K-T T 74.5/148.8
C141 4030018750 S.CER C3225 CH 2J 682K-T T 68.2/131.0
C142 4030018750 S.CER C3225 CH 2J 682K-T T 35.8/131.0
C143 4030019990 S.CER C1005 JB 1C 104K-T T 78.4/132.0
C144 4030019990 S.CER C1005 JB 1C 104K-T T 79.4/132.0
C145 4030019990 S.CER C1005 JB 1C 104K-T T 25.6/132.0
C146 4030019990 S.CER C1005 JB 1C 104K-T T 24.6/132.0
C147 4030018750 S.CER C3225 CH 2J 682K-T T 61.0/126.5
C148 4030018750 S.CER C3225 CH 2J 682K-T T 43.0/126.5
C151 4030021020 S.CER GRM31A5C2J101JW01D T 76.3/98.8
C154 4030021020 S.CER GRM31A5C2J101JW01D T 27.7/98.8
C156 4320001070 S.MIC UC342H 3300J-T T 52.0/98.8
C157 4320001050 S.MIC UC342H 3900J-T T 52.0/95.1
C158 4030011070 S.CER GRM31M2C2H5R0CY21L T 89.0/82.0
C160 4030019990 S.CER C1005 JB 1C 104K-T T 79.1/79.0
C161 4030017460 S.CER C1005 JB 1H 102K-T T 78.0/79.0
C162 4510010570 S.ELE 16 CE 470 LX T 78.7/84.4
C171 4030019990 S.CER C1005 JB 1C 104K-T T 65.3/125.7
C172 4030019990 S.CER C1005 JB 1C 104K-T T 38.7/125.7
C201 4030017460 S.CER C1005 JB 1H 102K-T T 86.4/135.0
C202 4030016790 S.CER C1005 JB 1E 103K-T T 86.4/134.0
C203 4510010570 S.ELE 16 CE 470 LX T 99.0/120.7
C204 4030019990 S.CER C1005 JB 1C 104K-T T 99.0/98.2
C205 4030016790 S.CER C1005 JB 1E 103K-T T 99.0/97.2
C206 4030017460 S.CER C1005 JB 1H 102K-T T 99.0/96.2
C207 4510010570 S.ELE 16 CE 470 LX T 99.0/111.9
C208 4510010570 S.ELE 16 CE 470 LX T 99.0/103.1
C212 4030019990 S.CER C1005 JB 1C 104K-T T 100.4/88.6
C213 4030017430 S.CER C1005 CH 1H 101J-T T 97.5/87.8
C214 4030019990 S.CER C1005 JB 1C 104K-T T 97.5/86.9
C221 4030019550 S.CER C1608 JB 1E 334K-T T 100.2/74.1
C223 4550007350 S.TAN F931C226MCMBMA T 95.5/70.0
C301 4030017430 S.CER C1005 CH 1H 101J-T T 14.2/83.8
C302 4030019990 S.CER C1005 JB 1C 104K-T T 3.9/81.3
C303 4030017430 S.CER C1005 CH 1H 101J-T T 12.6/84.8
C304 4030019990 S.CER C1005 JB 1C 104K-T T 3.9/85.3
C305 4030017460 S.CER C1005 JB 1H 102K-T T 4.1/91.3
C306 4030017460 S.CER C1005 JB 1H 102K-T T 15.4/91.5
C307 4030017460 S.CER C1005 JB 1H 102K-T T 4.1/92.3
C308 4030017460 S.CER C1005 JB 1H 102K-T T 15.4/92.5
C309 4030017460 S.CER C1005 JB 1H 102K-T T 4.1/93.3
C310 4030017460 S.CER C1005 JB 1H 102K-T T 15.4/93.5
C311 4030017460 S.CER C1005 JB 1H 102K-T T 4.1/94.3
C312 4030017460 S.CER C1005 JB 1H 102K-T T 15.4/94.5
C313 4030017460 S.CER C1005 JB 1H 102K-T T 4.1/95.3
C314 4030017460 S.CER C1005 JB 1H 102K-T T 15.4/95.5
C315 4030017460 S.CER C1005 JB 1H 102K-T T 4.1/96.3
C316 4030019990 S.CER C1005 JB 1C 104K-T T 15.4/97.0
C317 4030017460 S.CER C1005 JB 1H 102K-T T 4.1/97.3
C318 4030017420 S.CER C1005 CH 1H 470J-T T 15.4/97.9
C319 4030017420 S.CER C1005 CH 1H 470J-T T 4.1/98.3
C320 4030017420 S.CER C1005 CH 1H 470J-T T 15.4/98.8
C331 4030017460 S.CER C1005 JB 1H 102K-T T 15.2/141.2
C332 4030017460 S.CER C1005 JB 1H 102K-T T 15.2/143.4
C333 4030017460 S.CER C1005 JB 1H 102K-T T 12.9/147.5
C351 4030019990 S.CER C1005 JB 1C 104K-T T 18.2/105.5
C647 4030021020 S.CER GRM31A5C2J101JW01D T 27.5/30.7
C711 4030019990 S.CER C1005 JB 1C 104K-T T 104.9/66.4
C750 4030019990 S.CER C1005 JB 1C 104K-T T 20.5/77.5
C771 4030016790 S.CER C1005 JB 1E 103K-T T 26.2/73.7
C772 4030016790 S.CER C1005 JB 1E 103K-T T 26.2/75.8
C773 4030016790 S.CER C1005 JB 1E 103K-T T 26.2/77.9
C774 4030016790 S.CER C1005 JB 1E 103K-T T 26.2/79.9
C775 4030016790 S.CER C1005 JB 1E 103K-T T 26.2/82.1
C776 4030016790 S.CER C1005 JB 1E 103K-T T 26.2/84.2
C777 4030016790 S.CER C1005 JB 1E 103K-T T 26.2/86.3
C779 4030016790 S.CER C1005 JB 1E 103K-T T 26.2/88.4
C781 4030016790 S.CER C1005 JB 1E 103K-T T 32.4/73.2
C782 4030016790 S.CER C1005 JB 1E 103K-T T 32.4/75.3
C783 4030016790 S.CER C1005 JB 1E 103K-T T 32.4/77.4
C784 4030016790 S.CER C1005 JB 1E 103K-T T 32.4/79.5
C785 4030016790 S.CER C1005 JB 1E 103K-T T 32.4/81.6
C786 4030016790 S.CER C1005 JB 1E 103K-T T 32.4/83.7
C787 4030016790 S.CER C1005 JB 1E 103K-T T 32.4/85.8
C801 4030018790 S.CER C3225 JB 2E 104K-T T 67.7/16.7
C802 4030017660 S.CER C1005 CH 1H 330J-T T 65.0/1.7
C804 4030017510 S.CER C1005 CH 1H 680J-T T 66.9/1.7
C806 4030017660 S.CER C1005 CH 1H 330J-T T 67.8/1.7
C807 4030019990 S.CER C1005 JB 1C 104K-T T 75.9/2.1
C808 4030019990 S.CER C1005 JB 1C 104K-T T 76.9/2.1
C811 4030016790 S.CER C1005 JB 1E 103K-T T 53.3/5.9
C812 4030019120 S.CER GRM188B31E105KA75D T 40.6/4.5
C821 4030019990 S.CER C1005 JB 1C 104K-T T 41.3/56.5
C824 4030021010 S.CER GRM31A5C2J390JW01D T 37.3/47.8
C825 4030020750 S.CER GRM31A5C2J220JW01D T 33.3/35.2
C826 4030021000 S.CER GRM31A5C2J100JW01D T 35.4/35.2
C827 4030020810 S.CER GRM31A5C2J820JW01D T 29.5/34.9
C828 4030020790 S.CER GRM31A5C2J560JW01D T 28.6/32.8
C831 4030019990 S.CER C1005 JB 1C 104K-T T 50.8/11.9
C833 4030021200 S.CER GRM31A5C2J120JW01D T 30.2/25.0
C835 4030020800 S.CER GRM31A5C2J680JW01D T 29.1/21.4
C841 4030019990 S.CER C1005 JB 1C 104K-T T 99.1/63.0
C842 4030018480 S.CER GRM31A5C2J221JW01D T 96.4/54.4
C843 4030021040 S.CER GRM31A5C2J271JW01D T 82.1/43.1
C844 4030018350 S.CER GRM31A5C2J151JW01D T 96.4/50.2
C846 4030018340 S.CER GRM31A5C2J331JW01D T 96.4/48.1
C849 4030018480 S.CER GRM31A5C2J221JW01D T 96.4/39.6
C850 4030018350 S.CER GRM31A5C2J151JW01D T 96.4/41.8
C851 4030019990 S.CER C1005 JB 1C 104K-T T 95.6/18.6
C855 4030020820 S.CER GRM31A5C2J121JW01D T 96.4/52.3
C856 4030018350 S.CER GRM31A5C2J151JW01D T 96.4/46.0
C857 4030020810 S.CER GRM31A5C2J820JW01D T 82.1/45.2
C858 4030020800 S.CER GRM31A5C2J680JW01D T 89.4/45.2
C861 4030019990 S.CER C1005 JB 1C 104K-T T 86.9/63.0
(Amended page)
October 2016

(Amended page)
13
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[PA UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
[PA UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
C862 4030020740 S.CER GRM31A5C2J180JW01D T 60.5/58.8
C863 4030021200 S.CER GRM31A5C2J120JW01D T 62.6/58.8
C864 4030021010 S.CER GRM31A5C2J390JW01D T 61.1/54.7
C865 4030011080 S.CER GRM31M2C2H6R0DV01L T 63.8/34.2
C866 4030020760 S.CER GRM31A5C2J270JW01D T 63.8/25.3
C868 4030020770 S.CER GRM31A5C2J330JW01D T 63.8/29.5
C869 4030020770 S.CER GRM31A5C2J330JW01D T 63.0/18.5
C871 4030019990 S.CER C1005 JB 1C 104K-T T 80.9/17.4
C875 4030021200 S.CER GRM31A5C2J120JW01D T 64.8/21.9
C876 4030020760 S.CER GRM31A5C2J270JW01D T 63.8/27.4
C877 4030020770 S.CER GRM31A5C2J330JW01D T 61.1/52.6
C881 4030019990 S.CER C1005 JB 1C 104K-T T 53.2/56.5
C882 4030021220 S.CER GRM31B5C2J681JW01L T 57.8/43.2
C883 4030021220 S.CER GRM31B5C2J681JW01L T 56.3/46.9
C884 4030020720 S.CER GRM31A5C2J391JW01D T 56.3/39.6
C885 4030021220 S.CER GRM31B5C2J681JW01L T 57.9/33.6
C886 4030018480 S.CER GRM31A5C2J221JW01D T 51.6/31.5
C888 4030021220 S.CER GRM31B5C2J681JW01L T 51.4/23.8
C889 4030020810 S.CER GRM31A5C2J820JW01D T 52.7/19.7
C890 4030021220 S.CER GRM31B5C2J681JW01L T 57.0/18.0
C891 4030019990 S.CER C1005 JB 1C 104K-T T 65.5/11.3
C893 4030021220 S.CER GRM31B5C2J681JW01L T 51.0/27.4
C894 4030018350 S.CER GRM31A5C2J151JW01D T 57.9/35.7
C896 4030021220 S.CER GRM31B5C2J681JW01L T 57.0/22.2
C897 4030018480 S.CER GRM31A5C2J221JW01D T 57.0/20.1
C899 4030020800 S.CER GRM31A5C2J680JW01D T 49.9/19.7
C901 4030019990 S.CER C1005 JB 1C 104K-T T 14.8/57.1
C902 4030021020 S.CER GRM31A5C2J101JW01D T 5.8/38.2
C903 4030021020 S.CER GRM31A5C2J101JW01D T 5.8/40.3
C904 4030020760 S.CER GRM31A5C2J270JW01D T 11.0/40.3
C905 4030020810 S.CER GRM31A5C2J820JW01D T 11.0/38.2
C906 4030021020 S.CER GRM31A5C2J101JW01D T 5.8/27.1
C907 4030021020 S.CER GRM31A5C2J101JW01D T 5.8/25.0
C908 4030020790 S.CER GRM31A5C2J560JW01D T 11.0/26.1
C909 4030020800 S.CER GRM31A5C2J680JW01D T 6.5/14.0
C911 4030019990 S.CER C1005 JB 1C 104K-T T 21.3/11.9
C921 4030019990 S.CER C1005 JB 1C 104K-T T 110.9/63.0
C922 4030021040 S.CER GRM31A5C2J271JW01D T 102.7/53.2
C923 4030021040 S.CER GRM31A5C2J271JW01D T 100.6/47.5
C924 4030021040 S.CER GRM31A5C2J271JW01D T 101.5/39.6
C925 4030020810 S.CER GRM31A5C2J820JW01D T 103.0/36.0
C926 4030018340 S.CER GRM31A5C2J331JW01D T 101.5/43.9
C927 4030021040 S.CER GRM31A5C2J271JW01D T 101.5/26.6
C928 4030018340 S.CER GRM31A5C2J331JW01D T 101.5/24.5
C929 4030018340 S.CER GRM31A5C2J331JW01D T 101.5/41.8
C931 4030019990 S.CER C1005 JB 1C 104K-T T 110.3/18.6
C933 4030021030 S.CER GRM31A5C2J181JW01D T 100.6/53.2
C934 4030018350 S.CER GRM31A5C2J151JW01D T 102.7/47.5
C941 4030019990 S.CER C1005 JB 1C 104K-T T 28.7/56.5
C944 4030021010 S.CER GRM31A5C2J390JW01D T 27.9/48.1
C945 4030020790 S.CER GRM31A5C2J560JW01D T 26.4/44.6
C946 4030020780 S.CER GRM31A5C2J470JW01D T 26.4/39.0
C949 4030021020 S.CER GRM31A5C2J101JW01D T 27.5/28.6
C950 4030020760 S.CER GRM31A5C2J270JW01D T 26.2/25.0
C951 4030019990 S.CER C1005 JB 1C 104K-T T 36.0/11.9
C953 4030020780 S.CER GRM31A5C2J470JW01D T 27.7/17.2
C954 4030020790 S.CER GRM31A5C2J560JW01D T 27.7/19.3
C961 4030011040 S.CER GRM31M4C2H2R0CY21L T 83.9/9.5
C962 4030009920 S.CER C1608 CH 1H 050B-T T 84.3/5.5
C963 4030011540 S.CER C1608 CH 1H 750J-T T 83.0/5.5
C966 4030008650 S.CER C1608 JB 1H 332K-T T 96.7/2.2
C969 4030011040 S.CER GRM31M4C2H2R0CY21L T 97.1/9.5
C970 4030011540 S.CER C1608 CH 1H 750J-T T 96.7/5.5
C971 4030009920 S.CER C1608 CH 1H 050B-T T 98.1/5.5
C972 4030011040 S.CER GRM31M4C2H2R0CY21L T 99.4/12.4
C983 4030017460 S.CER C1005 JB 1H 102K-T T 7.4/67.5
C985 4030019990 S.CER C1005 JB 1C 104K-T T 12.3/70.5
C986 4030017460 S.CER C1005 JB 1H 102K-T T 3.8/10.1
C987 4030017730 S.CER C1005 JB 1H 471K-T T 2.8/11.2
RL801 6330002020 REL FTR-B4CA009Z
RL820 6330002020 REL FTR-B4CA009Z
RL821 6330002020 REL FTR-B4CA009Z
RL840 6330002020 REL FTR-B4CA009Z
RL841 6330002020 REL FTR-B4CA009Z
RL860 6330002020 REL FTR-B4CA009Z
RL861 6330002020 REL FTR-B4CA009Z
RL880 6330002020 REL FTR-B4CA009Z
RL881 6330002020 REL FTR-B4CA009Z
RL900 6330002020 REL FTR-B4CA009Z
RL901 6330002020 REL FTR-B4CA009Z
RL920 6330002020 REL FTR-B4CA009Z
RL921 6330002020 REL FTR-B4CA009Z
RL940 6330002020 REL FTR-B4CA009Z
RL941 6330002020 REL FTR-B4CA009Z
J101 6510028210 CON SJ050010 (TMP-J01X-V6)
J301 6510022472 S.CON 40FLT-SM2-TB (LF) (SN) (M) T 9.5/89.0
J331 6510018971 S.CON B4B-PH-SM4-TB (LF) (SN) T 5.0/144.4
J801 6510028210 CON SJ050010 (TMP-J01X-V6)
J961 6510028210 CON SJ050010 (TMP-J01X-V6)
F2 5210000940 FUS 1205
F201 5220000400 HOL FHA010-01F
W1 8900017860 CAB OPC-1857 [#02]
8900018220 CAB OPC-1943 [#03]
8900018220 CAB OPC-1943 [#05]
8900018220 CAB OPC-1943 [#06]
8900017860 CAB OPC-1857 [#07]
8900017860 CAB OPC-1857 [#08]
8900017860 CAB OPC-1857 [#12]
EP111 6910014690 S.BEA MPZ1608S221A-T T 26.6/154.9
EP121 6910012350 S.BEA MMZ1608Y 102BT T 34.1/166.3
EP131 6910014640 S.BEA MPZ2012S221A-T T 71.8/149.1
EP132 6910014640 S.BEA MPZ2012S221A-T T 71.8/150.9
EP301 6910020910 S.BEA MPZ1608S300AT T 6.1/81.3
EP302 6910019100 S.BEA MPZ1608S101AT T 6.1/85.3
EP303 6910021240 S.BEA MMZ1005A152ET T 6.5/91.3
EP305 6910021240 S.BEA MMZ1005A152ET T 12.9/92.8
EP306 6910021240 S.BEA MMZ1005A152ET T 12.9/93.8
EP307 6910021240 S.BEA MMZ1005A152ET T 6.5/94.3
EP308 6910021240 S.BEA MMZ1005A152ET T 12.9/94.8
EP309 6910021240 S.BEA MMZ1005A152ET T 6.5/95.3
EP311 6910021240 S.BEA MMZ1005A152ET T 6.5/96.3
EP312 6910021240 S.BEA MMZ1005A152ET T 12.9/96.8
EP331 6910018930 S.BEA MPZ2012S601A T 11.9/145.8
EP332 6910018930 S.BEA MPZ2012S601A T 10.9/148.6
October 2016

14
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[TUNER UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
[TUNER UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
W2001 8970024721 1.5D 140MM-1 C31/C31
IC1701 1110008620 S.IC BA2903SFVM-TR T 14.1/48.9
IC1901 1110008550 S.IC NJM2904CRB1-TE1-#HMZR T 34.8/12.5
IC 2811 1130009670 S.IC B U20 92FV- E 2 T 22. 5 /22.6
IC2821 1130009670 S.IC BU2092FV-E2 T 13.5/22.6
IC2831 1130009670 S.IC BU2092FV-E2 T 31.5/22.6
IC2841 1130009670 S.IC BU2092FV-E2 T 40.5/22.6
Q1611 1530002691 S.TRA 2SC4116-GR (TE85RF) T 48.9/28.3
Q1621 1530002691 S.TRA 2SC4116-GR (TE85RF) T 48.9/25.8
D1011 1750001850 S.DIO LDAN222T1G T 26.7/84.2
D1021 1750001850 S.DIO LDAN222T1G T 57.6/45.5
D1201 1750002940 S.DIO MMBD452LT1G T 12.4/74.5
D1261 1750001850 S.DIO LDAN222T1G T 15.6/43.3
D1271 1750002940 S.DIO MMBD452LT1G T 48.2/16.6
D1311 1750002950 S.DIO MMBD352LT1G T 26.4/48.3
D1312 1750002950 S.DIO MMBD352LT1G T 22.3/48.3
D1341 1750001850 S.DIO LDAN222T1G T 13.8/53.8
D1505 1750002230 S.DIO LRB751S-40T1G T 51.9/15.5
D1506 1750002230 S.DIO LRB751S-40T1G T 53.2/15.5
D2311 1750001850 S.DIO LDAN222T1G T 76.5/84.9
D2321 1750001850 S.DIO LDAN222T1G T 85.6/84.9
D2331 1750001850 S.DIO LDAN222T1G T 94.6/84.9
D2341 1750001850 S.DIO LDAN222T1G T 103.7/84.9
D2351 1750001850 S.DIO LDAN222T1G T 112.8/86.9
D2361 1750001850 S.DIO LDAN222T1G T 121.9/86.9
D2371 1750001850 S.DIO LDAN222T1G T 131.0/86.9
D2381 1750001850 S.DIO LDAN222T1G T 140.0/88.9
D2391 1750001850 S.DIO LDAN222T1G T 149.1/88.9
D2411 1750001850 S.DIO LDAN222T1G T 63.1/9.8
D2421 1750001850 S.DIO LDAN222T1G T 72.3/9.8
D2431 1750001850 S.DIO LDAN222T1G T 81.3/9.8
D2441 1750001850 S.DIO LDAN222T1G T 90.4/9.8
D2451 1750001850 S.DIO LDAN222T1G T 99.5/9.8
D2461 1750001850 S.DIO LDAN222T1G T 108.6/9.8
D2471 1750001850 S.DIO LDAN222T1G T 117.6/9.8
D2481 1750001850 S.DIO LDAN222T1G T 126.7/9.8
D2491 1750001850 S.DIO LDAN222T1G T 135.8/9.8
D2511 1750001850 S.DIO LDAN222T1G T 67.4/84.2
D2521 1750001850 S.DIO LDAN222T1G T 158.2/88.2
D2551 1750001850 S.DIO LDAN222T1G T 56.2/26.7
D2561 1750001850 S.DIO LDAN222T1G T 144.8/9.8
D2581 1750001850 S.DIO LDAN222T1G T 154.0/5.8
L1009 6200010160 S.COI AS080440-22N T 60.1/66.8
L1311 6140002810 S.COI LR-317 T 24.7/54.0
L1312 6140002810 S.COI LR-317 T 24.9/42.6
L1501 6140005560 COI LR-604
L2011 6110003620 COI LA-559
L2021 6110002750 COI LA-459
L2031 6110002760 COI LA-460
L2041 6110002770 COI LA-461
L2051 6110002780 COI LA-462
L2061 6110002790 COI LA-463
L2071 6110002800 COI LA-464
L2081 6140004900 COI LR-542 T68-2
L2091 6140004870 COI LR-539 T68-2
L2099 6200010170 S.COI AS080447-33N T 147.4/67.9
R1011 7030004980 S.RES ERJ2GEJ 101 X (100) T 24.0/82.8
R1021 7030004980 S.RES ERJ2GEJ 101 X (100) T 59.8/46.1
R1031 7540000330 S.ABS CSA70-401L-T T 57.8/71.7
R1032 7030013250 S.RES ERJ8GEYJ 104V (100 k) T 58.2/75.0
R1202 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) T 11.4/76.4
R1203 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 13.0/77.3
R1251 7030007300 S.RES ERJ2GEJ 332 X (3.3 k) T 12.3/41.4
R1252 7030005290 S.RES ERJ2GEJ 682 X (6.8 k) T 11.8/40.0
R1261 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 12.6/43.6
R1263 7030005110 S.RES ERJ2GEJ 224 X (220 k) T 14.0/45.3
R1264 7030005110 S.RES ERJ2GEJ 224 X (220 k) T 13.1/45.3
R1272 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) T 49.2/14.1
R1301 7030005530 S.RES ERJ2GEJ 100 X (10) T 23.1/61.2
R1341 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 24.7/58.7
R1342 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) T 25.9/59.2
R1351 7030004970 S.RES ERJ2GEJ 470 X (47) T 24.9/35.0
R1361 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 13.3/52.2
R1362 7030005100 S.RES ERJ2GEJ 154 X (150 k) T 13.8/56.1
R1364 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 14.9/52.2
R1365 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) T 16.5/52.2
R1401 7030014150 S.RES LTR50UZPJ151 T 37.7/75.2
R1402 7030014150 S.RES LTR50UZPJ151 T 37.7/79.2
R1411 7030014150 S.RES LTR50UZPJ151 T 43.3/75.2
R1412 7030014150 S.RES LTR50UZPJ151 T 43.3/79.2
R1421 7030014150 S.RES LTR50UZPJ151 T 48.9/75.2
R1422 7030014150 S.RES LTR50UZPJ151 T 48.9/79.2
R1431 7030014140 S.RES LTR50UZPJ121 T 39.3/70.2
R1432 7030014130 S.RES LTR50UZPJ101 T 43.3/70.2
R1441 7030014140 S.RES LTR50UZPJ121 T 39.3/64.6
R1442 7030014130 S.RES LTR50UZPJ101 T 43.3/64.6
R1451 7030014140 S.RES LTR50UZPJ121 T 39.3/59.0
R1452 7030014130 S.RES LTR50UZPJ101 T 43.3/59.0
R1461 7030014170 S.RES LTR50UZPJ331 T 48.9/70.2
R1471 7030014170 S.RES LTR50UZPJ331 T 48.9/64.6
R1481 7030014160 S.RES LTR50UZPJ271 T 48.9/59.0
R1501 7030006220 S.RES ERJ12YJ470U (47) T 40.3/54.3
R1502 7030007520 S.RES ERJ8ENF 1000V (100) T 46.1/35.2
R1503 7030006220 S.RES ERJ12YJ470U (47) T 46.5/54.3
R1504 7030006220 S.RES ERJ12YJ470U (47) T 50.2/35.2
R1505 7030007520 S.RES ERJ8ENF 1000V (100) T 44.0/35.2
R1506 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 52.1/12.3
R1507 7030008300 S.RES ERJ2GEJ 184 X (180 k) T 51.2/12.3
R1611 7030004990 S.RES ERJ2GEJ 221 X (220) T 50.3/23.6
R1612 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 48.2/24.1
R1613 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 46.6/24.1
R1614 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 46.7/29.0
R1615 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 46.7/27.7
R1625 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 46.7/25.2
R1701 7030004980 S.RES ERJ2GEJ 101 X (100) T 16.7/46.3
R1805 7030004980 S.RES ERJ2GEJ 101 X (100) T 25.0/10.6
R1806 7030004980 S.RES ERJ2GEJ 101 X (100) T 24.5/3.8
R1807 7030004980 S.RES ERJ2GEJ 101 X (100) T 24.0/10.6
R1808 7030004980 S.RES ERJ2GEJ 101 X (100) T 23.5/3.8
R1809 7030004980 S.RES ERJ2GEJ 101 X (100) T 23.0/10.6
R1810 7030004980 S.RES ERJ2GEJ 101 X (100) T 22.0/10.6
R1811 7030004980 S.RES ERJ2GEJ 101 X (100) T 21.5/3.8
R1812 7030004980 S.RES ERJ2GEJ 101 X (100) T 21.0/10.6
R1813 7030004980 S.RES ERJ2GEJ 101 X (100) T 20.5/3.8
R1814 7030004980 S.RES ERJ2GEJ 101 X (100) T 20.0/10.6
R1815 7030004980 S.RES ERJ2GEJ 101 X (100) T 19.5/3.8
R1816 7030004980 S.RES ERJ2GEJ 101 X (100) T 19.0/10.6
R1901 7030004980 S.RES ERJ2GEJ 101 X (100) T 38.0/14.7
R1902 7030007280 S.RES ERJ2GEJ 331 X (330) T 38.6/12.8
R1903 7030007280 S.RES ERJ2GEJ 331 X (330) T 31.0/13.5
R2311 7030004980 S.RES ERJ2GEJ 101 X (100) T 73.8/82.8
R2321 7030004980 S.RES ERJ2GEJ 101 X (100) T 82.9/82.8
R2331 7030004980 S.RES ERJ2GEJ 101 X (100) T 92.0/82.8
R2341 7030004980 S.RES ERJ2GEJ 101 X (100) T 101.1/82.8
R2351 7030004980 S.RES ERJ2GEJ 101 X (100) T 110.2/84.8
R2361 7030004980 S.RES ERJ2GEJ 101 X (100) T 119.2/84.8
R2371 7030004980 S.RES ERJ2GEJ 101 X (100) T 128.3/84.8
R2381 7030004980 S.RES ERJ2GEJ 101 X (100) T 137.4/86.8
R2391 7030004980 S.RES ERJ2GEJ 101 X (100) T 146.5/86.8
R2411 7030004980 S.RES ERJ2GEJ 101 X (100) T 64.9/10.8
R2421 7030004980 S.RES ERJ2GEJ 101 X (100) T 74.0/10.8
R2431 7030004980 S.RES ERJ2GEJ 101 X (100) T 83.1/10.8
R2441 7030004980 S.RES ERJ2GEJ 101 X (100) T 92.2/10.8
R2451 7030004980 S.RES ERJ2GEJ 101 X (100) T 101.3/10.8
R2461 7030004980 S.RES ERJ2GEJ 101 X (100) T 110.4/10.8
R2471 7030004980 S.RES ERJ2GEJ 101 X (100) T 119.4/10.8
R2481 7030004980 S.RES ERJ2GEJ 101 X (100) T 128.5/10.8
R2491 7030004980 S.RES ERJ2GEJ 101 X (100) T 137.6/10.8
R2511 7030004980 S.RES ERJ2GEJ 101 X (100) T 64.7/82.8
R2521 7030004980 S.RES ERJ2GEJ 101 X (100) T 155.6/86.8
R2551 7030004980 S.RES ERJ2GEJ 101 X (100) T 56.5/24.1
R2561 7030004980 S.RES ERJ2GEJ 101 X (100) T 146.7/10.8
R2581 7030004980 S.RES ERJ2GEJ 101 X (100) T 156.2/6.8
R2811 7410001170 S.ARR EXB28V470JX T 20.7/28.3
R2812 7410001170 S.ARR EXB28V470JX T 23.3/28.3
R2813 7410001170 S.ARR EXB28V470JX T 23.0/17.0
R2814 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 9.5/25.5
R2821 7410001170 S.ARR EXB28V470JX T 11.3/28.4
R2822 7410001170 S.ARR EXB28V470JX T 15.3/28.2
R2823 7410001170 S.ARR EXB28V470JX T 14.0/17.0
R2831 7410001170 S.ARR EXB28V470JX T 30.7/28.2
R2832 7410001170 S.ARR EXB28V470JX T 33.3/28.2
R2833 7410001170 S.ARR EXB28V470JX T 32.0/17.0
R2841 7410001170 S.ARR EXB28V470JX T 39.7/28.2
R2842 7410001170 S.ARR EXB28V470JX T 42.3/28.2
R2843 7410001170 S.ARR EXB28V470JX T 41.0/17.0
C1002 4030011020 S.CER GRM31M4C2H1R0CY21L T 55.7/67.1
C1011 4030019990 S.CER C1005 JB 1C 104K-T T 26.9/82.8
C1012 4030019990 S.CER C1005 JB 1C 104K-T T 22.3/66.8
C1013 4030019990 S.CER C1005 JB 1C 104K-T T 29.1/84.7
C1014 4030019990 S.CER C1005 JB 1C 104K-T T 29.1/83.7
C1021 4030019990 S.CER C1005 JB 1C 104K-T T 63.4/61.2
C1022 4030019990 S.CER C1005 JB 1C 104K-T T 60.3/45.2
C1023 4030019990 S.CER C1005 JB 1C 104K-T T 55.2/45.0
C1024 4030019990 S.CER C1005 JB 1C 104K-T T 55.2/46.0
C1101 4030021000 S.CER GRM31A5C2J100JW01D T 20.2/71.2
C1102 4030017440 S.CER C1005 CH 1H 221J-T T 17.0/71.2
C1202 4030020950 S.CER C1005 CH 1H 331JT T 13.0/76.4
C1203 4030016790 S.CER C1005 JB 1E 103K-T T 31.5/11.7
C1251 4030016790 S.CER C1005 JB 1E 103K-T T 12.7/40.0
C1261 4030016790 S.CER C1005 JB 1E 103K-T T 14.0/43.2
C1262 4030016790 S.CER C1005 JB 1E 103K-T T 12.6/42.6
C1263 4030016790 S.CER C1005 JB 1E 103K-T T 15.6/45.4
C1271 4030019990 S.CER C1005 JB 1C 104K-T T 47.8/18.5
C1272 4030020950 S.CER C1005 CH 1H 331JT T 47.5/14.6
C1301 4030011070 S.CER GRM31M2C2H5R0CY21L T 20.2/69.1
C1341 4030019990 S.CER C1005 JB 1C 104K-T T 25.9/58.3
C1351 4030019990 S.CER C1005 JB 1C 104K-T T 24.9/36.6
C1361 4030016790 S.CER C1005 JB 1E 103K-T T 16.7/50.8
C1365 4030019990 S.CER C1005 JB 1C 104K-T T 16.5/53.1
C1501 4030017640 S.CER C1005 CH 1H 150J-T T 42.5/36.3
C1504 4030017660 S.CER C1005 CH 1H 330J-T T 52.6/36.6
C1505 4030019990 S.CER C1005 JB 1C 104K-T T 52.7/17.4
C1506 4030020950 S.CER C1005 CH 1H 331JT T 51.6/13.5
C1507 4030016790 S.CER C1005 JB 1E 103K-T T 38.0/11.3
C1601 4030017620 S.CER C1005 CH 1H 100C-T T 49.5/30.1
C1602 4030018070 S.CER C1005 CH 1H 300J-T T 47.6/30.1
C1611 4030019990 S.CER C1005 JB 1C 104K-T T 49.4/23.6
C1701 4030019990 S.CER C1005 JB 1C 104K-T T 16.3/47.5
C1801 4030019990 S.CER C1005 JB 1C 104K-T T 31.5/1.7
C1802 4030019990 S.CER C1005 JB 1C 104K-T T 29.5/1.7
C1805 4030019990 S.CER C1005 JB 1C 104K-T T 25.0/13.2
C1806 4030019990 S.CER C1005 JB 1C 104K-T T 24.5/1.7
C1807 4030019990 S.CER C1005 JB 1C 104K-T T 24.0/13.2
C1808 4030019990 S.CER C1005 JB 1C 104K-T T 23.5/1.7
C1809 4030019990 S.CER C1005 JB 1C 104K-T T 23.0/13.2
(Amended page)
October 2016

15
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[TUNER UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
[TUNER UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
C1810 4030017420 S.CER C1005 CH 1H 470J-T T 22.0/13.2
C1811 4030017420 S.CER C1005 CH 1H 470J-T T 21.5/1.7
C1812 4030017420 S.CER C1005 CH 1H 470J-T T 21.0/13.2
C1813 4030017420 S.CER C1005 CH 1H 470J-T T 20.5/1.7
C1814 4030017420 S.CER C1005 CH 1H 470J-T T 20.0/13.2
C1815 4030017420 S.CER C1005 CH 1H 470J-T T 19.5/1.7
C1816 4030017460 S.CER C1005 JB 1H 102K-T T 19.0/13.2
C1901 4030019990 S.CER C1005 JB 1C 104K-T T 36.3/14.7
C2001 4030019990 S.CER C1005 JB 1C 104K-T T 63.7/84.2
C2006 4030019990 S.CER C1005 JB 1C 104K-T T 58.9/9.9
C2111 4030021850 S.CER GRM31A7U3D180JW31D T 67.5/33.9
C2112 4030021850 S.CER GRM31A7U3D180JW31D T 65.3/30.8
C2121 4030021860 S.CER GRM31A7U3D390JW31D T 72.1/33.9
C2122 4030021890 S.CER GRM31A7U3D330JW31D T 70.0/30.8
C2131 4010004800 CER DEC1X3J820JC4B
C2132 4010004790 CER DEC1X3J680JC4B
C2141 4030021870 S.CER GRM32A7U3D151JW31D T 90.7/34.0
C2142 4030021870 S.CER GRM32A7U3D151JW31D T 87.6/30.8
C2151 4030021870 S.CER GRM32A7U3D151JW31D T 95.2/34.0
C2161 4030021870 S.CER GRM32A7U3D151JW31D T 104.4/34.0
C2162 4030021870 S.CER GRM32A7U3D151JW31D T 101.4/34.0
C2171 4010008720 CER DEA1X3D271JA2B
C2172 4010008710 CER DEA1X3D331JA3B
C2183 4320001230 S.MIC UC552H 1201J-T T 125.1/33.0
C2191 4010009020 CER DEHR33F122KA3B
C2192 4010009020 CER DEHR33F122KA3B
C2281 4030021880 S.CER GRM42A7U3F560JW31L T 154.3/28.0
C2282 4030021880 S.CER GRM42A7U3F560JW31L T 156.6/25.5
C2311 4030019990 S.CER C1005 JB 1C 104K-T T 76.7/82.8
C2312 4030019990 S.CER C1005 JB 1C 104K-T T 76.7/66.3
C2313 4030019990 S.CER C1005 JB 1C 104K-T T 78.9/85.4
C2314 4030019990 S.CER C1005 JB 1C 104K-T T 78.9/84.4
C2321 4030019990 S.CER C1005 JB 1C 104K-T T 85.8/82.8
C2322 4030019990 S.CER C1005 JB 1C 104K-T T 85.8/66.3
C2323 4030019990 S.CER C1005 JB 1C 104K-T T 88.0/85.4
C2324 4030019990 S.CER C1005 JB 1C 104K-T T 88.0/84.4
C2331 4030019990 S.CER C1005 JB 1C 104K-T T 94.8/82.8
C2332 4030019990 S.CER C1005 JB 1C 104K-T T 94.9/66.3
C2333 4030019990 S.CER C1005 JB 1C 104K-T T 97.1/85.4
C2334 4030019990 S.CER C1005 JB 1C 104K-T T 97.1/84.4
C2341 4030019990 S.CER C1005 JB 1C 104K-T T 103.9/82.8
C2342 4030019990 S.CER C1005 JB 1C 104K-T T 103.9/66.3
C2343 4030019990 S.CER C1005 JB 1C 104K-T T 106.2/85.4
C2344 4030019990 S.CER C1005 JB 1C 104K-T T 106.2/84.4
C2351 4030019990 S.CER C1005 JB 1C 104K-T T 113.0/84.8
C2352 4030019990 S.CER C1005 JB 1C 104K-T T 113.0/68.3
C2353 4030019990 S.CER C1005 JB 1C 104K-T T 115.3/87.4
C2354 4030019990 S.CER C1005 JB 1C 104K-T T 115.3/86.4
C2361 4030019990 S.CER C1005 JB 1C 104K-T T 122.1/84.8
C2362 4030019990 S.CER C1005 JB 1C 104K-T T 122.1/68.3
C2363 4030019990 S.CER C1005 JB 1C 104K-T T 124.3/87.4
C2364 4030019990 S.CER C1005 JB 1C 104K-T T 124.3/86.4
C2371 4030019990 S.CER C1005 JB 1C 104K-T T 131.2/84.8
C2372 4030019990 S.CER C1005 JB 1C 104K-T T 131.1/68.3
C2373 4030019990 S.CER C1005 JB 1C 104K-T T 133.5/87.4
C2374 4030019990 S.CER C1005 JB 1C 104K-T T 133.5/86.4
C2381 4030019990 S.CER C1005 JB 1C 104K-T T 140.2/86.8
C2382 4030019990 S.CER C1005 JB 1C 104K-T T 140.3/70.3
C2383 4030019990 S.CER C1005 JB 1C 104K-T T 142.5/89.4
C2384 4030019990 S.CER C1005 JB 1C 104K-T T 142.5/88.4
C2391 4030019990 S.CER C1005 JB 1C 104K-T T 149.1/86.8
C2392 4030019990 S.CER C1005 JB 1C 104K-T T 151.6/70.3
C2393 4030019990 S.CER C1005 JB 1C 104K-T T 151.5/89.4
C2394 4030019990 S.CER C1005 JB 1C 104K-T T 151.5/88.4
C2411 4030019990 S.CER C1005 JB 1C 104K-T T 63.1/11.3
C2412 4030019990 S.CER C1005 JB 1C 104K-T T 58.7/27.7
C2413 4030019990 S.CER C1005 JB 1C 104K-T T 60.7/9.3
C2414 4030019990 S.CER C1005 JB 1C 104K-T T 60.7/10.3
C2421 4030019990 S.CER C1005 JB 1C 104K-T T 72.1/11.3
C2422 4030019990 S.CER C1005 JB 1C 104K-T T 72.4/27.8
C2423 4030019990 S.CER C1005 JB 1C 104K-T T 69.8/9.3
C2424 4030019990 S.CER C1005 JB 1C 104K-T T 69.8/10.3
C2431 4030019990 S.CER C1005 JB 1C 104K-T T 81.1/11.3
C2432 4030019990 S.CER C1005 JB 1C 104K-T T 81.4/27.8
C2433 4030019990 S.CER C1005 JB 1C 104K-T T 78.8/9.3
C2434 4030019990 S.CER C1005 JB 1C 104K-T T 78.8/10.3
C2441 4030019990 S.CER C1005 JB 1C 104K-T T 90.2/11.3
C2442 4030019990 S.CER C1005 JB 1C 104K-T T 90.5/27.8
C2443 4030019990 S.CER C1005 JB 1C 104K-T T 87.9/9.3
C2444 4030019990 S.CER C1005 JB 1C 104K-T T 87.9/10.3
C2451 4030019990 S.CER C1005 JB 1C 104K-T T 99.3/11.3
C2452 4030019990 S.CER C1005 JB 1C 104K-T T 99.6/27.8
C2453 4030019990 S.CER C1005 JB 1C 104K-T T 97.0/9.3
C2454 4030019990 S.CER C1005 JB 1C 104K-T T 97.0/10.3
C2461 4030019990 S.CER C1005 JB 1C 104K-T T 108.4/11.3
C2462 4030019990 S.CER C1005 JB 1C 104K-T T 108.7/27.8
C2463 4030019990 S.CER C1005 JB 1C 104K-T T 106.1/9.3
C2464 4030019990 S.CER C1005 JB 1C 104K-T T 106.1/10.3
C2471 4030019990 S.CER C1005 JB 1C 104K-T T 117.4/11.3
C2472 4030019990 S.CER C1005 JB 1C 104K-T T 117.8/27.8
C2473 4030019990 S.CER C1005 JB 1C 104K-T T 115.2/9.3
C2474 4030019990 S.CER C1005 JB 1C 104K-T T 115.2/10.3
C2481 4030019990 S.CER C1005 JB 1C 104K-T T 126.5/11.3
C2482 4030019990 S.CER C1005 JB 1C 104K-T T 126.9/27.8
C2483 4030019990 S.CER C1005 JB 1C 104K-T T 124.2/9.3
C2484 4030019990 S.CER C1005 JB 1C 104K-T T 124.3/10.3
C2491 4030019990 S.CER C1005 JB 1C 104K-T T 135.6/11.3
C2492 4030019990 S.CER C1005 JB 1C 104K-T T 136.0/27.8
C2493 4030019990 S.CER C1005 JB 1C 104K-T T 133.4/9.3
C2494 4030019990 S.CER C1005 JB 1C 104K-T T 133.4/10.3
C2511 4030019990 S.CER C1005 JB 1C 104K-T T 67.4/82.8
C2512 4030019990 S.CER C1005 JB 1C 104K-T T 67.6/66.3
C2513 4030019990 S.CER C1005 JB 1C 104K-T T 69.8/84.7
C2514 4030019990 S.CER C1005 JB 1C 104K-T T 69.8/83.7
C2521 4030019990 S.CER C1005 JB 1C 104K-T T 158.2/86.8
C2522 4030019990 S.CER C1005 JB 1C 104K-T T 156.5/70.3
C2523 4030019990 S.CER C1005 JB 1C 104K-T T 160.7/87.7
C2524 4030019990 S.CER C1005 JB 1C 104K-T T 160.7/88.7
C2551 4030019990 S.CER C1005 JB 1C 104K-T T 63.2/43.4
C2552 4030019990 S.CER C1005 JB 1C 104K-T T 56.6/28.4
C2553 4030019990 S.CER C1005 JB 1C 104K-T T 58.7/25.8
C2554 4030019990 S.CER C1005 JB 1C 104K-T T 57.8/25.8
C2561 4030019990 S.CER C1005 JB 1C 104K-T T 144.7/11.3
C2562 4030019990 S.CER C1005 JB 1C 104K-T T 145.0/27.8
C2563 4030019990 S.CER C1005 JB 1C 104K-T T 142.4/9.3
C2564 4030019990 S.CER C1005 JB 1C 104K-T T 142.4/10.3
C2581 4030019990 S.CER C1005 JB 1C 104K-T T 153.8/7.3
C2582 4030019990 S.CER C1005 JB 1C 104K-T T 154.1/23.8
C2583 4030019990 S.CER C1005 JB 1C 104K-T T 151.5/5.3
C2584 4030019990 S.CER C1005 JB 1C 104K-T T 151.5/6.3
C2811 4030019990 S.CER C1005 JB 1C 104K-T T 18.5/23.6
C2821 4030019990 S.CER C1005 JB 1C 104K-T T 9.5/22.9
C2831 4030019990 S.CER C1005 JB 1C 104K-T T 27.5/23.6
C2841 4030019990 S.CER C1005 JB 1C 104K-T T 36.5/23.6
RL1011 6330002060 REL EC2-9TNU
RL1021 6330002060 REL EC2-9TNU
RL2011 6330002060 REL EC2-9TNU
RL2021 6330002060 REL EC2-9TNU
RL2031 6330002060 REL EC2-9TNU
RL2041 6330002060 REL EC2-9TNU
RL2051 6330002060 REL EC2-9TNU
RL2061 6330002060 REL EC2-9TNU
RL2071 6330002060 REL EC2-9TNU
RL2081 6330002060 REL EC2-9TNU
RL2091 6330002060 REL EC2-9TNU
RL2111 6330002060 REL EC2-9TNU
RL2121 6330002060 REL EC2-9TNU
RL2131 6330002060 REL EC2-9TNU
RL2141 6330002060 REL EC2-9TNU
RL2151 6330002060 REL EC2-9TNU
RL2161 6330002060 REL EC2-9TNU
RL2171 6330002060 REL EC2-9TNU
RL2181 6330002060 REL EC2-9TNU
RL2191 6330002060 REL EC2-9TNU
RL2211 6330002060 REL EC2-9TNU
RL2221 6330002060 REL EC2-9TNU
RL2251 6330002060 REL EC2-9TNU
RL2261 6330002060 REL EC2-9TNU
RL2281 6330002060 REL EC2-9TNU
J1001 6510028210 CON SJ050010 (TMP-J01X-V6)
J1801 6510021722 S.CON 30FLT-SM2-TB (LF) (SN) (M) T 24.2/7.4
J2001 6510028210 CON SJ050010 (TMP-J01X-V6)
J2002 6510028210 CON SJ050010 (TMP-J01X-V6)
EP1801 6910019100 S.BEA MPZ1608S101AT T 31.5/3.8
EP1802 6910019900 S.BEA MPZ1608S601AT T 29.3/3.8
(Amended page)
October 2016

16
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[FRONT UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
[DISPLAY UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
DS1 5030004050 LCD RFE430H-AZH-DNS-000
W1 8910000070 FFC FFC-1008 (P0.5N6L50)
W2 8910000070 FFC FFC-1008 (P0.5N6L50)
W3 8910000070 FFC FFC-1008 (P0.5N6L50)
W4 8900018000 CAB OPC-1344A (P1N10L70)
EP1 0880001360 UNI EX-2500 #02 SENSOR
IC101 1190003620 S.IC TPS61161ADRVR B 60.8/51.7
IC152 1130017190 S.IC UC6528XBNQ4GRC B 100.0/48.7
IC 5 01 1140 017811 S.IC R5F10 4 LCAFB B 120.0/ 5 8.7
Q1 1590004690 S.TRA LDTC143ZET1G B 6.5/68.0
Q2 1590004690 S.TRA LDTC143ZET1G B 165.4/30.0
Q3 1590004690 S.TRA LDTC143ZET1G B 165.4/27.9
Q461 1510001200 S.TRA L2SA1576ART1G B 50.5/47.2
Q462 1520001010 S.TRA 2SB1132G-R-AB3-R B 45.4/51.4
Q481 1590004690 S.TRA LDTC143ZET1G B 20.8/65.5
Q491 1530004140 S.TRA L2SC4081RT1G B 38.3/49.6
Q492 1530004210 S.TRA DSC7004S0L B 30.2/52.9
Q493 1590004310 S.TRA LDTA114EET1G B 35.9/50.4
D101 1750002240 S.DIO DB2141300L B 68.2/50.1
D401 1750001820 S.DIO LRB706F-40T1G B 23.1/51.3
D471 1750002230 S.DIO LRB751S-40T1G B 33.5/50.3
D472 1750001820 S.DIO LRB706F-40T1G B 35.9/46.7
D491 1750001810 S.DIO L1SS400T1G B 35.1/53.7
L101 6200014850 S.COI LQH44PN220MP0L T 23.1/164.1
L102 6200015990 S.COI LQH32CN470K23L B 60.4/47.5
R1 7030004980 S.RES ERJ2GEJ 101 X (100) B 6.5/70.2
R2 7030004980 S.RES ERJ2GEJ 101 X (100) B 167.5/30.0
R3 7030007280 S.RES ERJ2GEJ 331 X (330) B 167.5/27.9
R11 7030005290 S.RES ERJ2GEJ 682 X (6.8 k) B 35.4/42.2
R12 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) B 41.2/41.0
R13 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 39.1/41.0
R14 7030007340 S.RES ERJ2GEJ 153 X (15 k) B 39.1/40.1
R21 7030005290 S.RES ERJ2GEJ 682 X (6.8 k) B 148.0/42.7
R22 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) B 150.4/42.7
R23 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 152.8/42.7
R24 7030007340 S.RES ERJ2GEJ 153 X (15 k) B 155.2/42.7
R31 7030005290 S.RES ERJ2GEJ 682 X (6.8 k) B 193.0/62.2
R32 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) B 195.5/62.2
R33 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 198.0/62.2
R34 7030007340 S.RES ERJ2GEJ 153 X (15 k) B 200.5/62.2
R41 7030005290 S.RES ERJ2GEJ 682 X (6.8 k) B 193.0/63.2
R42 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) B 195.5/63.2
R43 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 198.0/63.2
R44 7030007340 S.RES ERJ2GEJ 153 X (15 k) B 200.5/63.2
R50 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 58.5/66.6
R51 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 58.5/67.5
R52 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 58.5/62.2
R53 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 58.5/65.2
R54 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 58.5/64.2
R61 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 61.5/17.2
R62 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 61.5/16.2
R71 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 169.0/50.4
R72 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 173.8/44.3
R73 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 173.9/45.3
R101 7030011010 S.RES ERJ2GEJ 8R2 X (8.2) B 58.1/50.9
R102 7030005300 S.RES ERJ2GEJ 150 X (15) B 58.1/50.0
R103 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 88.7/50.7
R141 7030005530 S.RES ERJ2GEJ 100 X (10) B 91.9/47.8
R142 7030005530 S.RES ERJ2GEJ 100 X (10) B 94.0/50.3
R143 7030005530 S.RES ERJ2GEJ 100 X (10) B 93.0/47.8
R144 7030005530 S.RES ERJ2GEJ 100 X (10) B 94.8/49.0
R201 7030005080 S.RES ERJ2GEJ 823 X (82 k) B 168.0/15.8
R202 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 170.5/15.8
R203 7030005080 S.RES ERJ2GEJ 823 X (82 k) B 168.0/17.8
R204 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 170.5/17.8
R301 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 113.5/74.0
R302 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 115.5/74.0
R303 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 114.5/74.0
R401 7030005220 S.RES ERJ2GEJ 223 X (22 k) B 19.6/53.4
R402 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 20.6/53.4
R461 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 49.2/51.8
R462 7030009320 S.RES ERJ2GEJ 4R7 X (4.7) B 49.2/49.0
R463 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 48.5/47.0
R464 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 47.5/47.0
R471 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) B 34.0/48.7
R472 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 33.9/47.7
R481 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 20.8/67.1
R491 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 37.1/53.5
R492 7030005060 S.RES ERJ2GEJ 333 X (33 k) B 37.1/52.6
R493 7030007340 S.RES ERJ2GEJ 153 X (15 k) B 38.0/51.6
R494 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 35.9/48.7
R495 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 29.5/49.6
R496 7030007270 S.RES ERJ2GEJ 151 X (150) B 35.5/52.1
R501 7410001220 S.ARR EXB28V103JX B 109.5/58.2
R502 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 126.0/64.7
R503 7410001220 S.ARR EXB28V103JX B 128.5/51.2
R504 7410001220 S.ARR EXB28V103JX B 109.5/51.2
R601 7030007250 S.RES ERJ2GEJ 220 X (22) B 79.1/55.0
R602 7030007250 S.RES ERJ2GEJ 220 X (22) B 80.3/55.0
R603 7030007250 S.RES ERJ2GEJ 220 X (22) B 81.5/55.0
R604 7030007250 S.RES ERJ2GEJ 220 X (22) B 82.7/55.0
R605 7030007250 S.RES ERJ2GEJ 220 X (22) B 83.9/55.0
R606 7030007250 S.RES ERJ2GEJ 220 X (22) B 85.1/55.0
R607 7030007250 S.RES ERJ2GEJ 220 X (22) B 86.3/55.0
R608 7030007250 S.RES ERJ2GEJ 220 X (22) B 87.5/55.0
R609 7030007250 S.RES ERJ2GEJ 220 X (22) B 88.7/55.0
R610 7030007250 S.RES ERJ2GEJ 220 X (22) B 89.9/55.0
R611 7030004980 S.RES ERJ2GEJ 101 X (100) B 92.1/55.0
R612 7030007250 S.RES ERJ2GEJ 220 X (22) B 93.3/55.0
R613 7030007250 S.RES ERJ2GEJ 220 X (22) B 78.5/62.5
R614 7030007250 S.RES ERJ2GEJ 220 X (22) B 79.7/62.5
R615 7030007250 S.RES ERJ2GEJ 220 X (22) B 80.9/62.5
(Amended page)
October 2016

17
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[DISPLAY UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
[PBT UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
R616 7030007250 S.RES ERJ2GEJ 220 X (22) B 82.1/62.5
R617 7030007250 S.RES ERJ2GEJ 220 X (22) B 83.3/62.5
R618 7030007250 S.RES ERJ2GEJ 220 X (22) B 84.5/62.5
R619 7030007250 S.RES ERJ2GEJ 220 X (22) B 85.7/62.5
R620 7030007250 S.RES ERJ2GEJ 220 X (22) B 86.9/62.5
R621 7030007250 S.RES ERJ2GEJ 220 X (22) B 88.1/62.5
R622 7030007250 S.RES ERJ2GEJ 220 X (22) B 89.3/62.5
R623 7030007250 S.RES ERJ2GEJ 220 X (22) B 90.5/62.5
R624 7030007250 S.RES ERJ2GEJ 220 X (22) B 92.7/62.5
R625 7030004980 S.RES ERJ2GEJ 101 X (100) B 93.9/62.5
C50 4030016790 S.CER C1005 JB 1E 103K-T B 61.0/66.6
C51 4030016790 S.CER C1005 JB 1E 103K-T B 61.0/67.5
C52 4030016790 S.CER C1005 JB 1E 103K-T B 61.0/62.2
C53 4030016790 S.CER C1005 JB 1E 103K-T B 61.0/65.2
C54 4030016790 S.CER C1005 JB 1E 103K-T B 61.0/64.2
C61 4030019990 S.CER C1005 JB 1C 104K-T B 64.0/17.2
C62 4030019990 S.CER C1005 JB 1C 104K-T B 64.0/16.2
C71 4030016790 S.CER C1005 JB 1E 103K-T B 167.2/50.4
C72 4030016790 S.CER C1005 JB 1E 103K-T B 175.6/44.3
C73 4030016790 S.CER C1005 JB 1E 103K-T B 175.6/45.3
C101 4030021530 S.CER C1608 JB 1E 224K-T B 58.1/52.7
C102 4030021760 S.CER GRM31MB31H105KA87L B 66.4/53.0
C103 4030020270 S.CER GRM188B11A105KA61D B 61.1/49.7
C104 4030020270 S.CER GRM188B11A105KA61D B 57.3/48.1
C141 4030017460 S.CER C1005 JB 1H 102K-T B 95.5/50.3
C142 4030017460 S.CER C1005 JB 1H 102K-T B 96.5/50.7
C143 4030017460 S.CER C1005 JB 1H 102K-T B 95.1/47.8
C144 4030017460 S.CER C1005 JB 1H 102K-T B 96.1/48.3
C151 4030019990 S.CER C1005 JB 1C 104K-T B 96.9/46.6
C152 4030019990 S.CER C1005 JB 1C 104K-T B 103.5/50.2
C201 4030019990 S.CER C1005 JB 1C 104K-T B 168.0/13.8
C403 4030019620 S.CER GRM188B31C225KE14D B 25.0/51.0
C452 4030016790 S.CER C1005 JB 1E 103K-T B 20.8/62.7
C453 4030016790 S.CER C1005 JB 1E 103K-T B 20.8/61.4
C461 4030017460 S.CER C1005 JB 1H 102K-T B 48.8/50.4
C471 4030016790 S.CER C1005 JB 1E 103K-T B 37.7/47.3
C491 4030016790 S.CER C1005 JB 1E 103K-T B 28.5/49.6
C501 4030020270 S.CER GRM188B11A105KA61D B 111.5/60.2
C502 4030019990 S.CER C1005 JB 1C 104K-T B 111.5/61.8
C503 4030019990 S.CER C1005 JB 1C 104K-T B 111.5/62.8
C611 4030016790 S.CER C1005 JB 1E 103K-T B 92.1/52.5
C625 4030016790 S.CER C1005 JB 1E 103K-T B 93.9/65.0
C626 4030019990 S.CER C1005 JB 1C 104K-T B 74.8/65.0
C627 4030019990 S.CER C1005 JB 1C 104K-T B 72.0/55.8
C628 4030019990 S.CER C1005 JB 1C 104K-T B 76.2/65.0
J51 6510022692 S.CON 06FLT-SM2-TB (LF) (SN) (M) B 55.0/64.8
J61 6510022692 S.CON 06FLT-SM2-TB (LF) (SN) (M) B 57.5/16.6
J71 6510022692 S.CON 06FLT-SM2-TB (LF) (SN) (M) B 170.2/47.1
J101 6510031070 S.CON AYF534035 B 83.4/44.6
J201 6510018971 S.CON B4B-PH-SM4-TB (LF) (SN) B 177.1/16.8
J301 6510022692 S.CON 06FLT-SM2-TB (LF) (SN) (M) B 110.0/73.7
J401 6510018971 S.CON B4B-PH-SM4-TB (LF) (SN) B 15.8/50.7
J421 6510018971 S.CON B4B-PH-SM4-TB (LF) (SN) B 39.5/30.4
J451 6510019971 S.CON 52808-1071 B 7.8/60.7
J601 6510022472 S.CON 40FLT-SM2-TB (LF) (SN) (M) B 84.0/58.8
DS1 5040003500 S.LED HT-191 UYG-K828 T 8.8/76.3
DS2 5040003870 S.LED SSC-YGHR411-H T 167.8/28.8
S1 2230001480 S.SWI LS37J2-T T 9.0/72.0
S2 2230001480 S.SWI LS37J2-T T 9.0/61.7
S3 2230001480 S.SWI LS37J2-T T 9.0/51.7
S4 2230001480 S.SWI LS37J2-T T 9.0/45.7
S5 2230001480 S.SWI LS37J2-T T 28.3/45.8
S6 2230001480 S.SWI LS37J2-T T 42.7/45.8
S7 2230001480 S.SWI LS37J2-T T 28.3/41.1
S8 2230001480 S.SWI LS37J2-T T 42.7/41.1
S9 2230001480 S.SWI LS37J2-T T 68.4/3.1
S10 2230001480 S.SWI LS37J2-T T 87.9/3.1
S11 2230001480 S.SWI LS37J2-T T 107.4/3.1
S12 2230001480 S.SWI LS37J2-T T 126.9/3.1
S13 2230001480 S.SWI LS37J2-T T 146.4/3.1
S14 2230001480 S.SWI LS37J2-T T 167.1/47.8
S15 2230001480 S.SWI LS37J2-T T 165.8/14.8
S16 2230001480 S.SWI LS37J2-T T 169.0/3.1
S17 2230001480 S.SWI LS37J2-T T 191.1/74.1
S18 2230001480 S.SWI LS37J2-T T 206.2/74.1
S19 2230001480 S.SWI LS37J2-T T 221.3/74.1
S20 2230001480 S.SWI LS37J2-T T 191.1/65.8
S21 2230001480 S.SWI LS37J2-T T 206.2/65.8
S22 2230001480 S.SWI LS37J2-T T 221.3/65.8
S23 2230001480 S.SWI LS37J2-T T 191.1/59.5
S24 2230001480 S.SWI LS37J2-T T 206.2/59.5
S25 2230001480 S.SWI LS37J2-T T 222.4/59.5
EP401 6910018930 S.BEA MPZ2012S601A B 19.9/50.2
EP402 6910018930 S.BEA MPZ2012S601A B 20.8/47.7
EP451 6910018930 S.BEA MPZ2012S601A B 16.8/59.7
EP452 6910019900 S.BEA MPZ1608S601AT B 17.6/62.7
EP453 6910017350 S.BEA MMZ1608S601A-T B 17.6/61.4
EP454 6910016330 S.BEA MMZ1005S 601CT-S B 17.6/63.9
EP455 6910018930 S.BEA MPZ2012S601A B 16.8/57.9
EP456 6910016330 S.BEA MMZ1005S 601CT-S B 6.0/65.2
EP457 6910016330 S.BEA MMZ1005S 601CT-S B 5.0/65.2
EP601 6910019900 S.BEA MPZ1608S601AT B 73.7/63.0
EP602 6910019900 S.BEA MPZ1608S601AT B 75.4/55.4
EP603 6910019900 S.BEA MPZ1608S601AT B 77.3/63.0
J1 6510029480 S.CON 06FH-SM1-TB (LF) (SN) T 19.8/8.3
S1 2250000960 ENC TP90D96AE20-30.5F-3765
(Amended page)
October 2016

18
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[VR UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
[RIT UNIT]
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
R1 7210002970 VAR RV-314
J1 6510029480 S.CON 06FH-SM1-TB (LF) (SN) T 19.8/9.3
J1 6510029480 S.CON 06FH-SM1-TB (LF) (SN) T 20.0/5.6
S1 2250001010 ENC TP90N00AE20-14.5F-3765A
(Amended page)
October 2016
