IconBiT XDS42GL User manual

iconBIT XDS42GL
User Manual

iconBIT XDS42GL English
2
Contents
1. Introduction................................................................................................................................................3
1.1 General Information..................................................................................................................... 3
1.2 Key Features ................................................................................................................................... 3
1.3 Packing List...................................................................................................................................... 3
1.4 Safety instructions........................................................................................................................ 4
2. About the player........................................................................................................................................6
2.1 Power ON/OFF ................................................................................................................................ 6
2.2 Installing Internal 2.5" SATA HDD.......................................................................................... 6
2.3 How to Connect.............................................................................................................................. 6
2.4 Menu Language.............................................................................................................................. 8
2.5 External HDD Format................................................................................................................... 8
3. Upgrading the Firmware.........................................................................................................................9
4. Frequently Asked Questions ...............................................................................................................10
5. Appendices ................................................................................................................................................11
5.1 Warranty Information ................................................................................................................11
5.2 GNU General Public License (“GPL”) ....................................................................................11
5.3 Copyrights and Trademarks ....................................................................................................15

iconBIT XDS42GL English
3
1. Introduction.
1.1 General Information
Dear Customer!
Thank you for choosing the iconBIT device. We hope that you will be satisfied by using our
device for home entertainment. The iconBIT multimedia HD-player allows playing high-
quality digital video, audio and photo from different sources on an analogue TV, HDTV (TV
supporting high-definition video), home theater and other devices.
1.2 Key Features
This iconBIT Multimedia HD-player has the following functions:
Audio/Video outputs
•HDMI V1.3 for high-definition video and digital audio
•Composite & component video and stereo audio for analog audio-visual connection
•S/PDIF optical interface for high-fidelity digital audio
•Adjustable video output resolution (NTSC, PAL, 480p, 576p, 720p, 1080i, 1080p)
Multimedia Playback
•Supports major audio, video and image file formats (1080p HD video decoding)
•Movie format: AVI/MKV/TS/TP/TRP/M2TS/MPG/MP4/M4V/MOV/VOB/ISO/IFO/WMV/
RM/RMVB
•Music format: MP3/OGG/AAC/WMA/WAV/FLAC/APE
•Photo format: HD JPEG/BMP/GIF/PNG
•Photo slide show with background music
Interfaces Support
•2 x USB 2.0 HOST port (for external USB storage devices)
•USB 2.0 DEVICE port (for computer connection)
•SD card slot
Network Feature
•A/V streaming/transmission via Ethernet (10M/100M/1000M) & Wi-Fi (802.11b/g/n,
optional)
•File sharing via Samba server
•A/V streaming via UPnP Media Server
•BitTorrent download (controlled and managed via web server)
•Digital Radio (SHOUTcast)
File Copy
•Supports copying & moving files among Card, USB, HDD, and Network.
Note: All the information contained in this manual was correct at the time of publication.
However, as our engineers are always updating and improving the product, your device’s
software may have a slightly different appearance or modified functionality than presented
in this manual.
1.3 Packing List
Part Quantity
Multimedia player 1
Remote Control 1
A/V cable 1
AC/DC adaptor 1
Quick Start Guide (printed) 1
Note: The actual contents in the package might be different from the packing list in this
manual.

iconBIT XDS42GL English
4
1.4 Safety instructions
Please read the safety instructions carefully prior to using the device. Keep the
instructions in an easily accessible location for further use.
Warning signs
The lightning flash with
arrowhead symbol, within an
equilateral triangle, is intended
to alert the user to the presence
of uninsulated dangerous voltage
within the product’s enclosure
the may be of sufficient
magnitude to constitute a risk of
electric shock to persons.
ALERT: To reduce the risk of electric shock,
do not remove the back cover. No user
serviceable parts inside. Refer servicing to
qualified service personnel.
The exclamation point within an
equilateral triangle, is intended
to alert the user to the presence
of important and maintenance
(servicing) instructions in the
literature accompanying the
appliance.
Precautions concerning power supply:
- Do not plug many devices into one electric socket. This may lead to an overcharge,
combustion or electrical trauma.
- Do not touch the plug with wet hands. This may lead to electrical trauma, short circuiting
and combustion.
- When connecting an electric cable, make sure that the cable is protected from damaging
and is not being subject to any tension.
- It is essential to use the recommended power unit type with characteristics that comply
with the specification.
- If you are not planning to use the media player for a long time, you should disconnect it
from the power system in terms of safety and energy saving. Keep in mind, that even being
in standby mode the device consumes electric energy.
- You should not connect the device to the power system immediately after bringing it from
a cold surrounding to a warm one. Unpack the device and leave it in the warm environment
for 2 to 3 hours to let the condensate evaporate from the inner parts of the device.
Effect of radio interference and magnetic field:
- In case of absence of adequate screening virtually any electronic device becomes subject
to radio interference. In some conditions the radio interferences may affect the operation of
the media player.
- The iconBIT media player is designed in compliance with the FCC/CE standard, as well as
the following statements:
a. This player does not produce any harmful interference or emission;
b. When placed close to a source of strong radio interference the player may not be able to
function properly.
- Do not locate the device close to sources of strong magnetic fields. Such field may
damage data on your hard disk. In such case we will not be responsible for integrity of data
on your hard disk.
Installation precautions:
- The device is designed for indoor usage. Do not expose it to direct sunlight; do not locate
it next to any heat sources, heaters, radiators or refrigerating equipment. The operational
temperature should be within the range of +5°С to +35°С.
- Protect the device from getting wet as this may lead to combustion or electrical trauma.
- Do not place any containers with liquid on top or next to the player.
- Do not use the device in high humidity, e.g. in a bathroom or a swimming pool.

iconBIT XDS42GL English
5
- When installing the device in an enclosed space, make sure there is enough space for the
device to cool via heat emission. Do not cover vent holes of the device, so that sufficient
amounts of air could enter the device body.
- Do not place the device on an uneven or unsteady surface. Do not drop the device and
protect it from other objects getting dropped onto it.
Comments on the use of the remote control (RC):
-Point the RC directly at the infrared receiver of the device. Otherwise the RC may not
function properly.
-Handle the RC with care. In case of loss of RC, contact the service centre to order a new
one. A large portion of functions of the device is accessible only via the RC.
Operation precautions:
- Other devices and associated equipment should be connected via audio and video cables
only when the devices are switched off.
- Do not use the device during thunder to prevent breakdown.
- Do not use the player together with any devices, which it does not support – this may lead
to player breakdown.
- Do not push the player buttons to hard.
- When disconnecting the device from PC USB hub, always use the “Safely Remove
Hardware” functionality to prevent data loss.
Using hard disk drive (HDD) – precautions:
- If the device can be provided with an internal HDD for data storage, the device should not
be exposed to severe external impact. This may lead to HDD or player outage.
- Make sure the HDD has cooled down prior to extracting it. The heat emitted by the HDD
may burn the skin.
- The manufacturer is not responsible for loss of personal or any other confidential
information stored on your HDD resulting from physical impact, electric shock, voltage
jumps, formatting etc.
- We recommend periodic backup copying to prevent data loss.
- In case of HDD productivity slowdown or other problems we recommend performing a
check for bad sectors on the HDD and complete defragmentation.
Maintenance:
- When cleaning the device, always unplug the power cable. Use a soft cotton tissue or
similar, that does not produce electrostatic charge.
- Never use gasoline or any other dissolvent for cleaning the player, as they might damage
the device.
- In case of severe dirtying wet wipes for computers may be used.
Comments on equipment repairs:
- It is forbidden for users to modify the design of the device. Do not disassemble the player.
In case of device breakdown due to self-performed repairs or modification, no warranty
service will be provided.
- Should any malfunction appear, the device must be taken to an authorized service centre,
where personnel will perform diagnostics and repair.
Do not dispose the device. The product is recyclable. Utilization
requirements should be met. In some countries utilization of electronic
devices is in the scope of specialized guidelines; please refer to relevant
local organizations for additional information.

iconBIT XDS42GL English
6
2. About the player
2.1 Power ON/OFF
Power On
After connecting the DC IN jack and press the power button on the front panel, the player
will soon enter the home screen, and the power indicator will turn blue.
Power Off
Press the power button on the front panel, the player will soon enter standby mode, and the
power indicator will turn red. Then unplug the power cord to cut off the power supply.
2.2 Installing Internal 2.5" SATA HDD
Open the HDD bay, Insert 2.5" SATA HDD (face up) and close the bay.
To ensure correct operation, it is recommended to completely power off the player (remove
power plug from the player) before installing or removing the internal 2.5" SATA HDD.
2.3 How to Connect
Rear panel
(1) Y/Pb/Pr OUT jack
(2) RJ-45 LAN socket
(3) Composite video OUT jack
(4) Analog Stereo OUT
(5) S/PDIF OPTICAL jack
(6) HDMI
(7) DC IN jack

iconBIT XDS42GL English
7
Connecting to a PC
(1) Make sure the player is powered on;
(2) Plug in the mini-USB connector of the USB cable to this player’s USB DEVICE port;
(3) Plug in the regular USB connector of the USB cable to computer.
Connecting a USB Device
(1) Make sure the player is powered on;
(2) Plug in the USB stick or USB HDD etc. to the USB HOST port of this player.
In this way, you can browse contents on the USB device.
Connection to LAN and Internet
A standard Cat.5, Cat.5e or Cat.6 Ethernet cable with RJ-45 connectors should be used (not
included).
(1) Connect one of the crystal plugs on the cable to the player’s RJ45 LAN socket;
(2) Connect the other crystal plug on the cable to a RJ45 LAN port on your router , switch,
or hub devices.
Connecting to a TV – A/V (Composite)
(1) Plug in the 3 color connector to the player’s A/V OUT jack;
(2) Plug in the 3 color connector to the TV’s A/V IN jack.
In this way, you can enjoy the content in the player on TV or other display devices.
Connecting to a TV - Y/Pb/Pr Component
(1) Plug in the 3 color connector to the player’s Y/Pb/Pr jack;
(2) Plug in the 3 color connector to the TV’s Y/Pb/Pr jack.
Audio Connection while using Y/Pb/Pr Video out:
First method: use the audio output from the A/V OUT jack;
Second method: use the audio output from the S/PDIF Optical jack.
In this way, you can also enjoy videos, music, and photos in the player on TV.
Connecting to a TV - HDMI 1.3
(1) Plug one connector on your HDMI cable to the player’s HDMI jack;
(2) Plug the other connector on your HDMI cable to the TV’s HDMI jack.
Note: The HDMI cable is an optional accessory sold separately.
In this way, you can have the highest quality video and audio via a single cable.
Connecting to an Digital Amplifier
(1) Plug in the optical connector cable on your optical cable to the player’s S/PDIF (Optical)
jack.
(2) Plug in the other connector on your optical fiber cable to the digital audio device (digital
amplifier or decoder).
Note: Optical fiber cable is not supplied.

iconBIT XDS42GL English
8
2.4 Menu Language
The system language of this player can be set to English or other languages. Change the
language you wish in the setup menu, the selected language will take effect immediately.
2.5 External HDD Format
For users who wish to use BT download, Transmission, you need format the external hard
disk on the player before usage. Please refer to the following procedures to format the hard
disk.
Step 1: Select OK on the Warning page, press OK to confirm.
Note: This page can be also accessed via Setup->System-> Format menu.
A password needed when you try to format the HDD. The default password is ‘0000’.
Step 2: Select Format, press OK, and then hard disk format will start.
The formatting procedure will be finished within a few minutes. And then you can use the
hard disk properly on the player.
Note: HDD format will remove all data stored on the hard disk drive. Please take care and
backup your data in advance!

iconBIT XDS42GL English
9
3. Upgrading the Firmware
The firmware is the operating system (OS) installed on the device. Firmware upgrades can
bring new features, improvements and bug fixes.
Step 1: Copy ‘install.img’ to the root directory of a USB stick, and connect it to the USB
HOST port of the player.
Step 2:Press and hold the power / standby button on the front panel, and do not loosen.
Step 3: Plug the power cable into the DC IN jack, wait for about 5 seconds or more, and
then loosen your finger on the power / standby button;
Firmware installation will start. There is another way for upgrading via player menu.

iconBIT XDS42GL English
10
4. Frequently Asked Questions
Question 1. When I try to disconnect the USB device, I keep on getting “The device
‘Generic volume’ cannot be stopped right now. Try stopping the device again
later.” message, what should I do?
Answer:
Close any program that might be accessing data on the player, including Windows®
Explorer. If it does not work, close all programs and wait for another 20 seconds, then try
the green arrow icon again. If it still does not work, you should shut down the player and
disconnect the USB cable.
Question 2. I find new file names and folder names that I never created before or
they have strange gibberish names.
Answer:
Most likely, the player’s file allocation table (FAT) has been corrupted. This might be due to
the player shutting down (due to low battery power) while reading or writing to your
computer by the USB connection. Windows and Macintosh often write extra files to the hard
disk such as finder.def or System volume info. These are normal and will not do any harm to
the player.
Question 3. I used my player to transfer files back and forth between different
computers. Will defragmenting the player hard disk do any harm to it?
Answer:
Defragmenting the player hard disk may be useful after having transferred many files to and
from the player. It is never harmful to use the defragment on the player. Make sure no other
programs are running while using the Windows® defragment utility. Make sure you have
connected the player with the external power adapter during this procedure.
Question 4. My files have disappeared from the player.
Answer:
Make sure that you browse your files via the correct browser mode which means correct
filtered views such as Photos, Music, or Movies.
Question 5. During power on, why does the TV will have a short flashing, blue
screen or screensaver?
Answer:
This is normal, when the system initializes, it will setup the corresponding parameters so it
can output the correct video signal to the TV, during the initializing time, the TV will receive
incorrect signals or the signals will not be stable and will cause the TV screen to flash, some
TV’s will treat this as no signal, and will display a blue screen or screensaver.
Question6. Why couldn’t the player find the hard disc?
Answer:
You need format the hard disk on the player before usage. If hard disc failure occurs in file
manager, please backup your data and format your HDD on the player.
Question7. Why I can’t find my USB drive in file manager?
Answer:
Try to replace a short USB cable or plug in the power cable to your USB drive. You are
suggested to plug in one USB drive at the same time.

iconBIT XDS42GL English
11
5. Appendices
5.1 Warranty Information
Obtaining Service
iconBIT values your business and always attempts to provide you the very best of service. If
this Product requires maintenance, either contact the dealer from whom you originally
purchased the Product or visit our product support Web site at www.iconbit.com. Your
original box and packaging materials should be kept for storing or shipping your iconBIT
product. iconBIT shall have no liability for lost data regardless of the cause, recovery of lost
data, or data contained in any Product placed in its possession.
Limited Warranty
iconBIT warrants that the Product, in the course of its normal use, will for the term defined
below, be free from defects in material and workmanship and will conform to specification
therefore. The term of your limited warranty is 1 (one) year. The term of your limited
warranty period shall commence on the purchase date appearing on your purchase receipt.
Subject to the limitations specified below, your sole and exclusive warranty shall be, during
the period of warranty specified above and at iconBIT’s option, the repair or replacement of
the Product.
Warranty does not cover:
- Acts of nature, such as fire, static discharge.
- Damage from unauthorized repair, alteration or accident.
- Damage from misuse or neglect.
- A unit that has been modified or incorporated into other products or is used for
institutional or other commercial purposes.
- Loss of customer’s software, firmware, information, or memory data.
- Improper handling or installation.
- The serial number of the product is defaced or missing.
The foregoing limited warranty is iconBIT’s sole warranty and is applicable only to products
sold as new. The remedies provided herein are in lieu of a) any and all other remedies and
warranties, whether expressed, implied or statutory, including but not limited to, any
implied warranty of merchantability or fitness for a particular purpose, and b) any and all
obligations and liabilities of iconBIT for damages including, but not limited to accidental,
consequential, or special damages, or any financial loss, lost profits or expenses, or lost
data arising out of or in connection with the purchase, use, or performance of the Product,
even if iconBIT has been advised of the possibility of such damages.
5.2 GNU General Public License (“GPL”)
Firmware incorporated into this product may includes third party copyrighted software
licensed under the GPL (“GPL Software”). The Free Software is copyrighted by Free Software
Foundation, Inc. and the program is licensed “As is” without warranty of any kind.
You may re-use, re-distribute, and modify the GPL Software. Users are free to download the
base source code of the iconBIT players at the following Address: www.iconbit.com. The
source code can be sent to your address via mail for a charge of actual expense executed.
Please contact us at [email protected].
GNU GENERAL PUBLIC LICENSE
Version 2, June 1991
Copyright (C) 1989, 1991 Free Software Foundation, Inc.
51 Franklin Street, Fifth Floor, Boston, MA 02110-1301, USA
Everyone is permitted to copy and distribute verbatim copies
of this license document, but changing it is not allowed.

iconBIT XDS42GL English
12
Preamble
The licenses for most software are designed to take away your freedom to share and change it. By contrast, the
GNU General Public License is intended to guarantee your freedom to share and change free software--to make
sure the software is free for all its users. This General Public License applies to most of the Free Software
Foundation's software and to any other program whose authors commit to using it. (Some other Free Software
Foundation software is covered by the GNU Lesser General Public License instead.) You can apply it to your
programs, too.
When we speak of free software, we are referring to freedom, not price. Our General Public Licenses are designed
to make sure that you have the freedom to distribute copies of free software (and charge for this service if you
wish), that you receive source code or can get it if you want it, that you can change the software or use pieces of it
in new free programs; and that you know you can do these things.
To protect your rights, we need to make restrictions that forbid anyone to deny you these rights or to ask you to
surrender the rights. These restrictions translate to certain responsibilities for you if you distribute copies of the
software, or if you modify it.
For example, if you distribute copies of such a program, whether gratis or for a fee, you must give the recipients all
the rights that you have. You must make sure that they, too, receive or can get the source code. And you must
show them these terms so they know their rights.
We protect your rights with two steps: (1) copyright the software, and (2) offer you this license which gives you
legal permission to copy, distribute and/or modify the software.
Also, for each author's protection and ours, we want to make certain that everyone understands that there is no
warranty for this free software. If the software is modified by someone else and passed on, we want its recipients
to know that what they have is not the original, so that any problems introduced by others will not reflect on the
original authors' reputations.
Finally, any free program is threatened constantly by software patents. We wish to avoid the danger that
redistributors of a free program will individually obtain patent licenses, in effect making the program proprietary.
To prevent this, we have made it clear that any patent must be licensed for everyone's free use or not licensed at
all.
The precise terms and conditions for copying, distribution and modification follow.
TERMS AND CONDITIONS FOR COPYING, DISTRIBUTION AND MODIFICATION
0. This License applies to any program or other work which contains a notice placed by the copyright holder saying
it may be distributed under the terms of this General Public License. The "Program", below, refers to any such
program or work, and a "work based on the Program" means either the Program or any derivative work under
copyright law: that is to say, a work containing the Program or a portion of it, either verbatim or with modifications
and/or translated into another language. (Hereinafter, translation is included without limitation in the term
"modification".) Each licensee is addressed as "you".
Activities other than copying, distribution and modification are not covered by this License; they are outside its
scope. The act of running the Program is not restricted, and the output from the Program is covered only if its
contents constitute a work based on the Program (independent of having been made by running the Program).
Whether that is true depends on what the Program does.
1. You may copy and distribute verbatim copies of the Program's source code as you receive it, in any medium,
provided that you conspicuously and appropriately publish on each copy an appropriate copyright notice and
disclaimer of warranty; keep intact all the notices that refer to this License and to the absence of any warranty;
and give any other recipients of the Program a copy of this License along with the Program.
You may charge a fee for the physical act of transferring a copy, and you may at your option offer warranty
protection in exchange for a fee.
2. You may modify your copy or copies of the Program or any portion of it, thus forming a work based on the
Program, and copy and distribute such modifications or work under the terms of Section 1 above, provided that
you also meet all of these conditions:
a) You must cause the modified files to carry prominent notices stating that you changed the files and the date of
any change.
b) You must cause any work that you distribute or publish, that in whole or in part contains or is derived from the
Program or any part thereof, to be licensed as a whole at no charge to all third parties under the terms of this

iconBIT XDS42GL English
13
License.
c) If the modified program normally reads commands interactively when run, you must cause it, when started
running for such interactive use in the most ordinary way, to print or display an announcement including an
appropriate copyright notice and a notice that there is no warranty (or else, saying that you provide a warranty)
and that users may redistribute the program under these conditions, and telling the user how to view a copy of this
License. (Exception: if the Program itself is interactive but does not normally print such an announcement, your
work based on the Program is not required to print an announcement.)
These requirements apply to the modified work as a whole. If identifiable sections of that work are not derived
from the Program, and can be reasonably considered independent and separate works in themselves, then this
License, and its terms, do not apply to those sections when you distribute them as separate works. But when you
distribute the same sections as part of a whole which is a work based on the Program, the distribution of the whole
must be on the terms of this License, whose permissions for other licensees extend to the entire whole, and thus to
each and every part regardless of who wrote it.
Thus, it is not the intent of this section to claim rights or contest your rights to work written entirely by you;
rather, the intent is to exercise the right to control the distribution of derivative or collective works based on the
Program.
In addition, mere aggregation of another work not based on the Program with the Program (or with a work based
on the Program) on a volume of a storage or distribution medium does not bring the other work under the scope of
this License.
3. You may copy and distribute the Program (or a work based on it, under Section 2) in object code or executable
form under the terms of Sections 1 and 2 above provided that you also do one of the following:
a) Accompany it with the complete corresponding machine-readable source code, which must be distributed under
the terms of Sections 1 and 2 above on a medium customarily used for software interchange; or,
b) Accompany it with a written offer, valid for at least three years, to give any third party, for a charge no more
than your cost of physically performing source distribution, a complete machine-readable copy of the corresponding
source code, to be distributed under the terms of Sections 1 and 2 above on a medium customarily used for
software interchange; or,
c) Accompany it with the information you received as to the offer to distribute corresponding source code. (This
alternative is allowed only for noncommercial distribution and only if you received the program in object code or
executable form with such an offer, in accord with Subsection b above.)
The source code for a work means the preferred form of the work for making modifications to it. For an executable
work, complete source code means all the source code for all modules it contains, plus any associated interface
definition files, plus the scripts used to control compilation and installation of the executable. However, as a special
exception, the source code distributed need not include anything that is normally distributed (in either source or
binary form) with the major components (compiler, kernel, and so on) of the operating system on which the
executable runs, unless that component itself accompanies the executable.
If distribution of executable or object code is made by offering access to copy from a designated place, then
offering equivalent access to copy the source code from the same place counts as distribution of the source code,
even though third parties are not compelled to copy the source along with the object code.
4. You may not copy, modify, sublicense, or distribute the Program except as expressly provided under this
License. Any attempt otherwise to copy, modify, sublicense or distribute the Program is void, and will automatically
terminate your rights under this License. However, parties who have received copies, or rights, from you under this
License will not have their licenses terminated so long as such parties remain in full compliance.
5. You are not required to accept this License, since you have not signed it. However, nothing else grants you
permission to modify or distribute the Program or its derivative works. These actions are prohibited by law if you
do not accept this License. Therefore, by modifying or distributing the Program (or any work based on the
Program), you indicate your acceptance of this License to do so, and all its terms and conditions for copying,
distributing or modifying the Program or works based on it.
6. Each time you redistribute the Program (or any work based on the Program), the recipient automatically
receives a license from the original licensor to copy, distribute or modify the Program subject to these terms and
conditions. You may not impose any further restrictions on the recipients' exercise of the rights granted herein. You
are not responsible for enforcing compliance by third parties to this License.
7. If, as a consequence of a court judgment or allegation of patent infringement or for any other reason (not
limited to patent issues), conditions are imposed on you (whether by court order, agreement or otherwise) that
contradict the conditions of this License, they do not excuse you from the conditions of this License. If you cannot
distribute so as to satisfy simultaneously your obligations under this License and any other pertinent obligations,
then as a consequence you may not distribute the Program at all. For example, if a patent license would not permit

iconBIT XDS42GL English
14
royalty-free redistribution of the Program by all those who receive copies directly or indirectly through you, then
the only way you could satisfy both it and this License would be to refrain entirely from distribution of the Program.
If any portion of this section is held invalid or unenforceable under any particular circumstance, the balance of the
section is intended to apply and the section as a whole is intended to apply in other circumstances.
It is not the purpose of this section to induce you to infringe any patents or other property right claims or to
contest validity of any such claims; this section has the sole purpose of protecting the integrity of the free software
distribution system, which is implemented by public license practices. Many people have made generous
contributions to the wide range of software distributed through that system in reliance on consistent application of
that system; it is up to the author/donor to decide if he or she is willing to distribute software through any other
system and a licensee cannot impose that choice.
This section is intended to make thoroughly clear what is believed to be a consequence of the rest of this License.
8. If the distribution and/or use of the Program is restricted in certain countries either by patents or by copyrighted
interfaces, the original copyright holder who places the Program under this License may add an explicit
geographical distribution limitation excluding those countries, so that distribution is permitted only in or among
countries not thus excluded. In such case, this License incorporates the limitation as if written in the body of this
License.
9. The Free Software Foundation may publish revised and/or new versions of the General Public License from time
to time. Such new versions will be similar in spirit to the present version, but may differ in detail to address new
problems or concerns.
Each version is given a distinguishing version number. If the Program specifies a version number of this License
which applies to it and "any later version", you have the option of following the terms and conditions either of that
version or of any later version published by the Free Software Foundation. If the Program does not specify a
version number of this License, you may choose any version ever published by the Free Software Foundation.
10. If you wish to incorporate parts of the Program into other free programs whose distribution conditions are
different, write to the author to ask for permission. For software which is copyrighted by the Free Software
Foundation, write to the Free Software Foundation; we sometimes make exceptions for this. Our decision will be
guided by the two goals of preserving the free status of all derivatives of our free software and of promoting the
sharing and reuse of software generally.
NO WARRANTY
11. BECAUSE THE PROGRAM IS LICENSED FREE OF CHARGE, THERE IS NO WARRANTY FOR THE PROGRAM, TO
THE EXTENT PERMITTED BY APPLICABLE LAW. EXCEPT WHEN OTHERWISE STATED IN WRITING THE COPYRIGHT
HOLDERS AND/OR OTHER PARTIES PROVIDE THE PROGRAM "AS IS" WITHOUT WARRANTY OF ANY KIND, EITHER
EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE. THE ENTIRE RISK AS TO THE QUALITY AND PERFORMANCE OF THE
PROGRAM IS WITH YOU. SHOULD THE PROGRAM PROVE DEFECTIVE, YOU ASSUME THE COST OF ALL NECESSARY
SERVICING, REPAIR OR CORRECTION.
12. IN NO EVENT UNLESS REQUIRED BY APPLICABLE LAW OR AGREED TO IN WRITING WILL ANY COPYRIGHT
HOLDER, OR ANY OTHER PARTY WHO MAY MODIFY AND/OR REDISTRIBUTE THE PROGRAM AS PERMITTED ABOVE,
BE LIABLE TO YOU FOR DAMAGES, INCLUDING ANY GENERAL, SPECIAL, INCIDENTAL OR CONSEQUENTIAL
DAMAGES ARISING OUT OF THE USE OR INABILITY TO USE THE PROGRAM (INCLUDING BUT NOT LIMITED TO
LOSS OF DATA OR DATA BEING RENDERED INACCURATE OR LOSSES SUSTAINED BY YOU OR THIRD PARTIES OR
A FAILURE OF THE PROGRAM TO OPERATE WITH ANY OTHER PROGRAMS), EVEN IF SUCH HOLDER OR OTHER
PARTY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
END OF TERMS AND CONDITIONS

iconBIT XDS42GL English
15
5.3 Copyrights and Trademarks
Trademarks
Microsoft and Windows are registered trademarks of Microsoft Corporation.
All other trademarks are property of their respective holders.
Manufactured under license under U.S. Patent
#’s:5,451,942; 5,956,674; 5,974,380; 5,978,762;
6,487,535 & other U.S. and worldwide patents issued
& pending. DTS and DTS 2.0 + Digital Out are
registered trademarks and the DTS logos and Symbol
are trademarks of DTS, Inc. © 1996-2008 DTS, Inc.
All Rights Reserved
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby
Laboratories.
HDMI, the HDMI logo and High-Definition Multimedia
Interface are trademarks or registered trademarks of
HDMI Licensing LLC.
Copyrights
All rights reserved. No part of this manual may be reproduced, or transmitted in any form
or by any means, whether by electronically or mechanically, without the express written
permission from the copyright holder. Copyrighted materials, such as software, music files,
or movies, are protected by local law, and may not be illegally copied or used without
permission from the copyright owner.
Information furnished by iconBIT is believed to be accurate and reliable; however, no
responsibility is assumed by iconBIT for its use nor for any infringement of patents or other
rights of third parties which may result from its use. iconBIT reserves the right to change
specifications at any time without notice.
iconBIT – trademark of iconBIT Limited.
© 2011 iconBIT Limited. All rights reserved.
iconBIT Limited.
Suite 1604-5, Wilson House, 19-27 Wyndham Street, Central, Hong Kong.
Phone: [phone], Fax: [phone]
www.iconbit.com

iconBIT XDS42GL Русский
16
Содержание
1. Введение ...................................................................................................................................................17
1.1 Информация об устройстве................................................................................................... 17
1.2 Основные функции................................................................................................................... 17
1.3 Комплект поставки.................................................................................................................... 17
1.4 Инструкция по безопасности ............................................................................................... 18
2. О плеере....................................................................................................................................................20
2.1. Включение/выключение....................................................................................................... 20
2.2. Установка Жесткого диска 2.5"......................................................................................... 20
2.3 Подключение ............................................................................................................................... 20
2.4 Язык меню.....................................................................................................................................22
2.5 Форматирование внешнего жесткого диска.................................................................. 22
3. Обновление микропрограммы.........................................................................................................23
4. Часто задаваемые вопросы ..............................................................................................................24
5. Приложения .............................................................................................................................................25
5.1 Сведения о гарантии................................................................................................................ 25
5.2 Стандартная общественная лицензия GNU («GPL») ................................................. 25
5.3 Авторские права и торговые марки .................................................................................. 30

iconBIT XDS42GL Русский
17
1. Введение
1.1 Информация об устройстве
Уважаемый покупатель!
Мы благодарим вас за то, что вы выбрали устройство компании iconBIT. Надеемся, что
Вы будете довольны его использованием в качестве домашнего средства развлечения.
Мультимедийный HD-проигрыватель iconBIT позволяет воспроизводить
высококачественное цифровое видео, аудио и фото с различных источников на
аналоговый TV, HDTV (телевизор с поддержкой высокого разрешения), домашний
кинотеатр и другие устройства.
1.2 Основные функции
Данный мультимедийный HD-проигрыватель iconBIT имеет следующие функции:
Аудио/видео выходы
•HDMI V1.3 выход для передачи сигнала высокой четкости и цифрового звука
•Композитный и компонентный видео выход и стереофонический аудио выход для
аналогового подключения
•Оптический S/PDIF интерфейс для передачи высококачественного цифрового аудио
сигнала
•Возможность выбора желаемого разрешения видео (NTSC, PAL, 480p, 576p, 720p,
1080i, 1080p)
Воспроизведение мультимедиа-файлов
•Поддержка основных форматов звуковых и видео файлов, а также изображений
(поддерживается декодирование видео высокого разрешения 1080p)
•Поддержка форматов видео: AVI/MKV/TS/TP/TRP/M2TS/MPG/MP4/M4V/MOV/VOB/ISO
/IFO/WMV/RM/RMVB
•Поддержка звуковых форматов: MP3/OGG/AAC/WMA/WAV/FLAC/APE
•Поддержка форматов изображений: HD JPEG/BMP/GIF/PNG
•Режим слайдшоу с фоновой музыкой
Поддержка интерфейсов
•USB 2.0 HOST порт (для подключения внешних USB устройств хранения данных)
•USB 2.0 DEVICE port (для соединений с компьютером)
•Слот для карт памяти
Сетевые возможности
•Потоковое воспроизведение/передача аудио-видео файлов через сеть Ethernet
(10M/100M/1000M), Wi-Fi (802.11b/g/n, опционально)
•Общий доступ к файлам через сервер Samba
•Потоковое воспроизведение аудио-видео файлов с помощью UPnP Media Server
•Загрузка с помощью программы BitTorrent (контроль и управление через веб-
сервер)
•Цифровое радио (SHOUTcast)
Копирование файлов
•Поддержка копирования и перемещения файлов между картами памяти, USB
носителями, жестким диском и сетевыми устройствами.
Примечание: Вся информация, приведенная в данном руководстве актуальна на
момент публикации. Однако, наши инженеры постоянно обновляют и совершенствуют
устройство, поэтому программное обеспечение Вашего устройства может несколько
отличаться по функциям и внешнему виду от приведенного в данном руководстве.
1.3 Комплект поставки
Наименование
Количество
Мультимедийный плеер 1
Пульт дистанционного управления
1
Аудио/видео кабель
1
Сетевой адаптер AC/DC
1
Краткое Руководство пользователя (печатное)
1
Важно: Содержание комплекта поставки может отличаться от описания,
представленного в данном руководстве.

iconBIT XDS42GL Русский
18
1.4 Инструкция по безопасности
Пожалуйста, прочитайте внимательно инструкцию по безопасному
использованию, перед тем, как приступить к эксплуатации устройства.
Сохраните руководство в доступном месте для дальнейшего использования.
Предупреждающие знаки
Символ молнии в треугольнике
предупреждает пользователя о
наличии высокого напряжения
и опасности поражения
электрическим током.
ВНИМАНИЕ: Во избежание риска
поражения электрическим током не
вскрывайте корпус устройства ( или
заднюю крышку). Внутри прибора нет
компонентов, обслуживаемых
пользователем. Для ремонта устройства
обращайтесь в специализированный
сервис-центр.
Символ восклицательного знака
в треугольнике служит
указанием, что существуют
особые требования по
эксплуатации устройства.
Обратитесь к руководству
пользователя.
Предосторожности, связанные с электропитанием устройства:
- Не включайте много устройств в одну электрическую розетку. Это может привести к
перегрузке, пожару или поражению электрическим током.
- Не прикасайтесь к вилке питания мокрыми руками. Это может привести к удару
электрическим током, короткому замыканию и возгоранию.
- При подключении электрического кабеля убедитесь, что он защищен от повреждений
и не подвержен какому-либо давлению.
- Необходимо использовать только рекомендованный блок питания с характеристиками,
указанными в спецификации.
- Если вы не собираетесь использовать медиаплеер в течение длительного времени, то
в целях безопасности и экономии электроэнергии отсоедините его от сети переменного
тока. Помните, что даже в режиме ожидания устройство потребляет электроэнергию.
- Запрещается подключение плеера к электросети сразу после перемещения из холода
в тепло. Распакуйте устройство и оставьте его на 2-3 часа в теплом помещении, чтобы
испарился конденсат, появившийся на внутренних компонентах устройства.
Влияние радиопомех и магнитного поля:
- В случае отсутствия соответствующей экранировки практически все электронные
устройства будут подвержены влиянию радиопомех. В некоторых условиях радиопо-
мехи могут воздействовать на медиаплеер.
- Медиаплеер iconBIT разработан в соответствии со стандартом FCC/CE и следующими
положениями:
a. Этот плеер не является источником вредных помех и излучений;
b. Данный плеер может некорректно работать, находясь в непосредственной близости к
источникам сильных радиопомех.
- Не располагайте устройство рядом с источниками сильного магнитного поля. Оно мо-
жет повредить данные на вашем жестком диске. В данном случае мы не несем
ответственности за сохранность информации на вашем жестком диске.
Предосторожности при установке:
- Устройство предназначено для использования внутри жилых помещений. Не подвер-
гайте его прямому воздействию солнечных лучей, не устанавливайте устройство рядом
с источниками тепла, батареями отопления, радиаторами или холодильным оборудова-
нием. Температура окружающей среды должна быть в диапазоне от +5°С до +35°С.
- Не допускайте попадание жидкости на поверхность или внутрь корпуса плеера - это
может привести к пожару или поражению электрическим током.
- Не ставьте на плеер или рядом с ним емкости с жидкостью.
- Запрещается эксплуатация устройства в помещениях с повышенной влажностью,
например, ванная комната или бассейн.
- Если вы устанавливаете устройство в закрытом месте, необходимо обеспечить доста-
точно места вокруг него для надлежащего охлаждения путем свободного отвода тепла.
Не заслоняйте вентиляционные отверстия плеера, для обеспечения нормального дос-

iconBIT XDS42GL Русский
19
тупа воздуха внутрь корпуса.
-Не ставьте устройство на неровную или неустойчивую поверхность. Не роняйте
устройство и не допускайте падения на него других предметов.
Замечания по работе с пультом дистанционного управления (ПДУ):
-Направляйте ПДУ строго на инфракрасный приемник устройства, иначе пульт может
работать некорректно.
-Бережно храните ПДУ. Если вы потеряли ПДУ, обратитесь в сервис центр для его за-
мены. Большая часть функций продукта доступна только при помощи ПДУ.
Предосторожности при эксплуатации:
- Коммутацию устройства и сопутствующей аппаратуры посредством аудио и видео
кабелей, необходимо осуществлять только в выключенном состоянии.
- Не эксплуатируйте устройство во время грозы во избежание его поломки.
- Не используйте с плеером любые неподдерживаемые устройства – это может привести
к поломке плеера.
- Не нажимайте на кнопки плеера слишком сильно.
-При отсоединении устройства от USB порта компьютера, необходимо использовать
функцию «Безопасное извлечение устройства» для предотвращения потери данных.
Меры предосторожности при работе с жестким диском (ЖД):
- Если устройство может быть оснащено внутренним жестким диском для хранения
данных, важно не подвергать устройство сильным внешним воздействиям. В этом
случае ЖД или сам плеер может выйти из строя.
- Прежде чем вынимать ЖД, убедитесь, что он остыл. Тепло, выделяемое ЖД, может
вызвать ожог.
- Производитель не несет ответственности за утерю персональной или иной
конфиденциальной информации, хранящейся на вашем жестком диске в результате,
физического воздействия, электрошока, скачков напряжения в электросети,
форматирования и т. д.
- Для предотвращения потери данных мы рекомендуем периодически осуществлять
резервное копирование.
- Вслучае снижения производительности ЖД или возникновения других проблем,
рекомендуется провести проверку ЖД на сбойные сектора и выполнить полную
дефрагментацию.
Уход за продуктом.
- При очистке устройства необходимо отсоединить кабель питания и протереть корпус
мягкой салфеткой из хлопка или аналогичной ткани, не вызывающей появления
статических разрядов.
- Никогда не чистите плеер бензином или прочими растворителями, так как они могут
повредить устройство.
- В случае сильного загрязнения используйте влажные салфетки для ухода за
компьютерным оборудованием.
Замечания по ремонту оборудования:
- Пользователю запрещено изменять конструкцию данного устройства. Не разбирайте
плеер. Самостоятельный ремонт плеера или его модификация, приводящие к поврежде-
ниям, лишают вас гарантийного и сервисного обслуживания.
- В случае возникновения неисправности, устройство необходимо доставить в авторизо-
ванный сервисный центр, для проведения квалифицированной диагностики и ремонта.
Не выбрасывайте устройство вместе с бытовым мусором. Продукт пред-
назначен для повторной переработки. Необходимо соблюдать правила
утилизации таких продуктов. В некоторых странах утилизация
электронных устройств регламентирована; для получения дополнитель-
ной информации обратитесь в соответствующие местные организации.

iconBIT XDS42GL Русский
20
2. О плеере
2.1. Включение/выключение
Включение
После присоединения шнура питания и нажатия кнопки на передней панели, плеер
через некоторое время покажет начальный экран, и индикатор питания загорится
синим цветом.
Выключение
Нажмите кнопку питания на передней панели, после чего плеер через некоторое
время войдет в режим ожидания, и индикатор питания загорится красным цветом.
После этого можно отсоединить плеер от сети.
2.2. Установка Жесткого диска 2.5"
Откройте отсек для жесткого диска, Вставьте 2.5" SATA HDD (лицевой стороной вверх)
и закройте отсек.
Для Вашей безопасности, перед установкой жесткого диска рекомендуется отключить
питание плеера (шнур питания).
2.3 Подключение
Передняя панель
(1) Y/Pb/Pr выход
(2) RJ-45 LAN разъем
(3) Композитный видео выход
(4) Аналоговый стерео выход
(5) S/PDIF оптический
(6) HDMI
(7) Разъем питания
