ICP DAS USA PDS-220F Series User manual

PDS-220Fx Series User Manual (V1.2, Apr. 2015) 1
Service and usage information for
PDS-220Fx Series
User Manual
Version 1.2, April 2015
PDS-220FT
PDS-220FC
PDS-220FCS
PDS-220FCS-60
ГК Атлант Инжиниринг – официальный представитель вРФ иСНГ
[phone] [email protected] www.bbrc.ru

PDS-220Fx Series User Manual (V1.2, Apr. 2015) 2
Warranty
All products manufactured by ICP DAS are under warranty regarding defective materials
for a period of one year, starting from the date of delivery to the original purchaser.
Warning
ICP DAS assumes no liability for damages resulting from the use of this product. ICP DAS
reserves the right to change this manual at any time without notice. The information
furnished by ICP DAS is believed to be accurate and reliable. However, no responsibility is
assumed by ICP DAS for its use, nor for any infringements of patents or other rights of
third parties resulting from its use.
Copyright
Copyright © 2012 by ICP DAS. All rights are reserved.
Trademark
The names used for identification only may be registered trademarks of their respective
companies.
Contact US
If you have any question, please feel free to contact us.
We will give you quick response within 2 workdays.
Email: [email protected] , [email protected]
ГК Атлант Инжиниринг – официальный представитель вРФ иСНГ
[phone] [email protected] www.bbrc.ru

PDS-220Fx Series User Manual (V1.2, Apr. 2015) 3
Table of Contents
1. INTRODUCTION................................................................................................................................................6
1.1 WHY FIBER OPTIC SOLUTIONS?.........................................................................................................................7
1.2 WHY VXCOMM TECHNOLOGY?............................................................................................................................8
1.3 WHY WEB SERVER TECHNOLOGY?...................................................................................................................10
2. TYPICAL APPLICATIONS FOR THE PDS...................................................................................................11
2.1 RS-232/485/422 DEVICE NETWORKING ........................................................................................................11
2.2 FIBER I/O APPLICATIONS.................................................................................................................................12
2.3 CONFIGURABLE FIBER OPTIC DATA LOGGER .....................................................................................................12
3. HARDWARE INFORMATION .......................................................................................................................15
3.1 FEATURES........................................................................................................................................................15
3.2 PDS-220FX SERIES SELECTION GUIDE............................................................................................................15
3.3 SPECIFICATIONS ..............................................................................................................................................16
3.4 FRONT VIEW....................................................................................................................................................19
3.5 PIN ASSIGNMENTS ...........................................................................................................................................20
3.6 DIMENSIONS....................................................................................................................................................21
4. SETTING UP THE PDS-220FX MODULE....................................................................................................22
5. CONFIGURATION WITH WEB BROWSER................................................................................................29
5.1 CONNECTING TO THE PDS-220FX MODULE .....................................................................................................29
5.2 NETWORK SETTINGS........................................................................................................................................30
5.3 IP FILTER SETTINGS ........................................................................................................................................33
5.4 COM PORT SETTINGS......................................................................................................................................35
5.5 MODBUS GATEWAY SETTINGS ..........................................................................................................................41
5.6 MISCELLANEOUS SETTINGS ..............................................................................................................................43
5.7 PAIR CONNECTION SETTINGS...........................................................................................................................45
6. MODBUS TESTING AND PROTOCOL..........................................................................................................48
6.1 MODBUS/TCP TO MODBUS/RTU GATEWAY .....................................................................................................49
6.2 TESTING MODBUS DEVICE THROUGH VIRTUAL COM PORTS..............................................................................53
7. CONSOLE / TELNET COMMANDS LIST ....................................................................................................56
7.1 OPERATION FLOWCHART................................................................................................................................56
7.2 REGULATE INIT/NORMAL(RUN)MODE..............................................................................................................57
7.3 COMMAND LIST................................................................................................................................................58
7.3.1 IPFILTER ................................................................................................................................................59
7.3.2 IPCONF ..................................................................................................................................................60
7.3.3 SOCKET .................................................................................................................................................61
7.3.4 COM ........................................................................................................................................................62
7.3.5 Broadcast ...............................................................................................................................................63
7.3.6 SystemTimeout (ms) ...........................................................................................................................63
7.3.7 SocketTimeout (ms) ............................................................................................................................64
7.3.8 M .............................................................................................................................................................64
7.3.9 EchoCmdNo ...........................................................................................................................................65
7.3.10 EndChar ............................................................................................................................................66
7.3.11 IP .......................................................................................................................................................67
7.3.12 MASK .................................................................................................................................................67
7.3.13 GATEWAY .........................................................................................................................................68
ГК Атлант Инжиниринг – официальный представитель вРФ иСНГ
[phone] [email protected] www.bbrc.ru

PDS-220Fx Series User Manual (V1.2, Apr. 2015) 4
7.3.14 MAC ...................................................................................................................................................68
7.3.15 NAME .................................................................................................................................................69
7.3.16 ALIAS .................................................................................................................................................69
7.3.17 DHCP .................................................................................................................................................70
7.3.18 UDP ....................................................................................................................................................70
7.3.19 VER ....................................................................................................................................................71
7.3.20 SAVE ..................................................................................................................................................71
7.3.21 LOAD .................................................................................................................................................72
7.3.22 CONFIG .............................................................................................................................................74
7.3.23 RESET ................................................................................................................................................75
7.3.24 QUIT ..................................................................................................................................................75
APPENDIX A: LINKING TO A DEVELOPMENT PC ............................................................................................76
APPENDIX B: FRAME GROUND..............................................................................................................................80
GLOSSARY ....................................................................................................................................................................81
1. ARP (ADDRESS RESOLUTION PROTOCOL).....................................................................................................81
2. CLIENTS AND SERVERS .....................................................................................................................................81
3. ETHERNET ..........................................................................................................................................................82
4. FIRMWARE .........................................................................................................................................................82
5. GATEWAY ...........................................................................................................................................................82
6. ICMP (INTERNET CONTROL MESSAGES PROTOCOL).....................................................................................82
7. INTERNET...........................................................................................................................................................82
8. IP (INTERNET PROTOCOL)ADDRESS...............................................................................................................82
9. MAC (MEDIA ACCESS CONTROL)ADDRESS....................................................................................................83
10. PACKET ..........................................................................................................................................................83
11. PING ..............................................................................................................................................................83
12. RARP (REVERSE ADDRESS RESOLUTION PROTOCOL)..............................................................................83
13. SOCKET..........................................................................................................................................................83
14. SUBNET MASK...............................................................................................................................................84
15. TCP (TRANSMISSION CONTROL PROTOCOL).............................................................................................84
16. TCP/IP ........................................................................................................................................................84
17. UDP (USER DATAGRAM PROTOCOL)..........................................................................................................84
FAQ 85
1. HOW TO ACCESS THE REMOTE PDS-220FX THAT PLACED BEHIND AN NAT OR FIREWALL?......................................85
2. HOW TO OPEN A VIRTUAL COM PORT THAT LARGER THAN "COM 9" BY CALLING CREATEFILE() WIN32 API? ........86
3. DOES VXCOMM DRIVER (PC) SUPPORT AUTO-RECONNECTION AFTER FIXING A NETWORK BREAK?...........................87
4. WHY DOESN'T THE VXCOMM DRIVER (PC) RECEIVE DATA FROM THE PDS-220FX SERIES MODULE? ................87
5. DOES THE TRANSMISSION SPEED BECOME FASTER WHEN THE SERIAL DEVICE WORKING WITH SERIAL TO ETHERNET
DEVICE SERVERS?...........................................................................................................................................................88
6. WHY DOES THE PDS-220FX SERIES MODULE FAIL ON A (PUBLIC)INTERNET CONNECTION?....................................90
7. HOW MANY PCS CAN BE CONNECTED TO A SINGLE PDS-220FX DEVICE?................................................................92
8. CAN IUSE THE SETCOMMSTATE ()API TO CHANGES THE BAUD RATE/DATA FORMAT SETTINGS OF A VIRTUAL
COM PORT?..................................................................................................................................................................93
9. CAN ISEARCH OR CONNECT TO PDS-220FX WHEN MY PC’S IP ADDRESS IS NOT IN THE IP FILTER LIST OF PDS-
220FX?HOW CAN ISOLVE IT?.......................................................................................................................................93
10. WHY CANNOT COMPUTER PING OR SEARCH THE PDS-220FX SERIES MODULE?..................................................94
ГК Атлант Инжиниринг – официальный представитель вРФ иСНГ
[phone] [email protected] www.bbrc.ru

PDS-220Fx Series User Manual (V1.2, Apr. 2015) 5
Packing List
The package includes the following items:
One PDS-220Fx Series hardware module
One software utility CD
One Quick Start Guide
Note:
If any of these items are missed or damaged, contact the local distributors for more
information. Save the shipping materials and cartons in case you want to ship in the future.
More Information
Documentations
CD: Napdos\PDS\PDS-220Fx\Document
http://ftp.icpdas.com/pub/cd/8000cd/napdos/pds/pds-220fx/document/
VxComm Driver (Virtual COM)
CD: \NAPDOS\ Driver\VxComm_Driver
http://ftp.icpdas.com/pub/cd/8000cd/napdos/driver/vxcomm_driver/
Firmware
CD:\ Napdos\PDS\PDS-220Fx\VxComm\Server(PDS)\
http://ftp.icpdas.com/pub/cd/8000cd/napdos/pds/pds-220fx/vxcomm/server(pds)/
MiniOS7
CD:\NAPDOS\PDS\PDS-220Fx\OS_image
http://ftp.icpdas.com/pub/cd/8000cd/napdos/pds/pds-220fx/os_image/
QuickStart
ГК Атлант Инжиниринг – официальный представитель вРФ иСНГ
[phone] [email protected] www.bbrc.ru

PDS-220Fx Series User Manual (V1.2, Apr. 2015) 6
1. Introduction
The PDS-220Fx series is a family of Programmable Device Servers, also known as
"Serial-to-Ethernet gateway”, that are designed for adding optical fiber connectivity to RS-
232/422/485 devices.
The user-friendly VxComm Driver/Utility allows users to easily turn the built-in COM ports
of the PDS-220Fx series into standard COM ports on a PC. By virtue of its protocol
independence, a small-core OS and high flexibility, the PDS-220Fx series is able to meet
the demands of every network-enabled application.
The PDS-220Fx series includes a powerful and reliable Xserver programming structure
that allows you to design your robust Ethernet applications in one day. The built-in, high-
performance MiniOS7 boots the PDS-220Fx up in just one second and gives you fastest
responses.
The PDS-220Fx is equipped with 1 RS-232 port and 1 RS-485/422 port. The removable
on-board terminal block connector is designed for easy and robust wiring in industrial
situations.
ГК Атлант Инжиниринг – официальный представитель вРФ иСНГ
[phone] [email protected] www.bbrc.ru

PDS-220Fx Series User Manual (V1.2, Apr. 2015) 7
1.1 Why Fiber Optic Solutions?
The fiber-optic communications permits transmission over longer distances than other
forms of communications because of the signals travel along them with less loss and no
crosstalk. It has following important features: Immunity to electromagnetic interference
(EMI) —Motors, relays, welders and other industrial equipment generate a tremendous
amount of electrical noise that can cause major problems with copper cabling.
High electrical resistance, making it safe to use near high-voltage equipment or
between areas with different earth potentials.
No sparks —important in flammable or explosive gas environments.
Not electromagnetically radiating, and difficult to tap without disrupting the signal —
important in high-security environments.
Because of these reasons, optical fibers have largely replaced copper wire
communications in core networks in the developed world.
Because of these reasons, optical fibers have largely replaced copper wire
communications in core networks in the developed world.
ГК Атлант Инжиниринг – официальный представитель вРФ иСНГ
[phone] [email protected] www.bbrc.ru

PDS-220Fx Series User Manual (V1.2, Apr. 2015) 8
1.2 Why VxComm Technology?
In general, writing a TCP/IP program is more difficult than a COM port program, or the
COM port communication system was built many years ago.
As a result, a new technology, VxComm was developed to virtualize the COM ports of
the PDS to allow up to 256 COM Ports to be used on the central computer. The
VxComm driver saves time when accessing serial devices through the Ethernet without
the need for reprogramming the COM port software on the PC.
ГК Атлант Инжиниринг – официальный представитель вРФ иСНГ
[phone] [email protected] www.bbrc.ru

PDS-220Fx Series User Manual (V1.2, Apr. 2015) 9
The VxComm driver controls all the details of the Ethernet TCP/IP programming technique;
your COM port program will be able to access your serial devices through Ethernet in the
same way as through COM port with the assistance of PDS-220Fx and VxComm
technology.
ГК Атлант Инжиниринг – официальный представитель вРФ иСНГ
[phone] [email protected] www.bbrc.ru

PDS-220Fx Series User Manual (V1.2, Apr. 2015) 10
1.3 Why Web Server Technology?
Web server technology enables configuration of the PDS-220Fx series via a standard web
browser interface, e.g. Internet Explorer, FireFox or Mozilla, etc. This means that it is easy
to check the configuration of the PDS-220Fx series via an Ethernet network without
needing to install any other software tools; thereby reducing the user’s learning carve.
ГК Атлант Инжиниринг – официальный представитель вРФ иСНГ
[phone] [email protected] www.bbrc.ru

PDS-220Fx Series User Manual (V1.2, Apr. 2015) 11
2. Typical Applications for the PDS
2.1 RS-232/485/422 Device Networking
--- Using Virtual COM Technology ---
The PDS-220Fx series is designed to link RS-232/485/422 devices to an Ethernet network.
The VxComm utility allows the built-in PDS-220Fx COM Port to be virtualized to a
standard COM Port of the host PC as shown below:
In the configuration above, Meter-1 is virtualized to link to COM3 of the host PC. Therefore
a program original designed for the MS-COMM standard can access the meter without
any modification.
COM1/2 of the PDS-
220Fx is mapped to
COM3/4 of the host PC
The original COM1/2
of the host PC
COM1/2 of the PDS-
220Fx is mapped to
COM5/6 of the host PC
ГК Атлант Инжиниринг – официальный представитель вРФ иСНГ
[phone] [email protected] www.bbrc.ru

PDS-220Fx Series User Manual (V1.2, Apr. 2015) 12
2.2 Fiber I/O Applications
The PDS-220Fx series provides fiber optic I/O solution:
Linking to I-7000 series modules
The I-7000 series provides a variety of I/O operations, such as D/I, D/O, A/D, D/A, Counter
and Frequency Measurement, etc. The I-7000 series was originally designed to be used
with RS-485 networks, so COM2 on the PDS-220Fx can be used to link to I-7000 series
modules. They are very robust and work well under the harsh industrial environments.
By using VxComm technology, programs that on the host PC support serial devices can
be upgraded from a RS-485 network to a fiber optic network without requiring any
modifications to the program. Refer to Sec. 2.1 for more information.
2.3 Configurable Fiber Optic Data Logger
Using the VxComm driver, PDS-220Fx + I-7000 modules can be virtualized to become
COM Port + I-7000 modules located on the host-PC, and then the Data Logger in the
DCON Utility can be used to access data of I-7000 from the fiber optic. Signal data
originating from the I-7000 modules can be analyzed using MS-Excel without the need to
write any custom programs
1: The DCON utility includes a log function, as show below:
ГК Атлант Инжиниринг – официальный представитель вРФ иСНГ
[phone] [email protected] www.bbrc.ru

PDS-220Fx Series User Manual (V1.2, Apr. 2015) 13
2: Configure the system connection as shown below and click the “Start” button to begin
logging data.
3: Open the log file in Excel to read the log data as shown in the example below:
ГК Атлант Инжиниринг – официальный представитель вРФ иСНГ
[phone] [email protected] www.bbrc.ru

PDS-220Fx Series User Manual (V1.2, Apr. 2015) 14
By using the I-7000 DCON utility and MS Excel in conjunction with the VxComm
technology, the signal data of I-7000 modules from the fiber optic network can be
analyzed without the need to write custom programs. For more information about the log
function refer to the online help feature (English and Traditional Chinese) of the DCON
utility.
ГК Атлант Инжиниринг – официальный представитель вРФ иСНГ
[phone] [email protected] www.bbrc.ru

PDS-220Fx Series User Manual (V1.2, Apr. 2015) 15
3. Hardware Information
3.1 Features
Adds optical fiber connectivity to serial devices
Virtual COM extends the PC COM Ports
Virtual COM supports Windows NT 4.0, 32-bit/64-bit 2000/XP/2003/Vista/7
Watchdog Timer suitable for use in harsh environments
Powerful programmable device server
Power reverse polarity protection
Serial Port +/-4 kV ESD Protection Circuit
Self-Tuner ASIC Controller on the RS-485 Port
RoHS Compliant with no Halogen
Built-in High Performance MiniOS7 from ICP DAS
10/100 Base-FX (SC/ST connectors)
Low power consumption
Made from fire-retardant materials (UL94-V0 Level)
ODM service is available
3.2 PDS-220Fx Series Selection Guide
Model
CPU
SRAM
Flash
Fiber Port
Mode
Distance
COM1
COM2
PDS-220FT
80
MHz
512
KB
512
KB
100 Base-FX,
ST Connector
Multi-
mode
2 km
5-wire
RS-232
RS-422
RS-485
PDS-220FC
100 Base-FX,
SC Connector
Multi-
mode
2 km
PDS-220FCS
100 Base-FX,
SC Connector
Single-
mode
30km
PDS-220FCS-60
100 Base-FX,
SC Connector
Single-
mode
60 km
5-wire RS-232: RxD, TxD, CTS, RTS, GND
4-wire RS-422: TxD+, TxD-, RxD+, RxD-
2-wire RS-485: Data+, Data-
ГК Атлант Инжиниринг – официальный представитель вРФ иСНГ
[phone] [email protected] www.bbrc.ru

PDS-220Fx Series User Manual (V1.2, Apr. 2015) 16
3.3 Specifications
System:
CPU
80186, 80MHz or compatible
SRAM
512 KB
Flash Memory
Flash ROM: 512 KB; Erase unit is one sector (64 KB); 100,000
erase/write cycles
Built-in
Watchdog Timer
Yes
LED Indicators
Sys, Link/Act
Init Pin
Yes
Serial Port:
COM1
Male DB-9, 5-wire RS-232 (RxD, TxD, CTS, RTS, GND)
Note: +/- 4 kV ESD Protection
COM2
Removable Terminal Block,
2-wire RS-485 (D+, D-, GND) with Self-tuner ASIC
or 4-wire RS-422 (TxD+, TxD-, RxD+, RxD-, GND)
Note: +/- 4 kV ESD Protection
COM Port Format:
UART
16c550 or compatible
Baud rate
115200 bps Max.
Data bits
7, 8
Parity
None, Odd, Even, Mark, Space
Stop bits
1, 2
LED Indicators:
Link/Act
Green
System
Red
ГК Атлант Инжиниринг – официальный представитель вРФ иСНГ
[phone] [email protected] www.bbrc.ru

PDS-220Fx Series User Manual (V1.2, Apr. 2015) 17
Interface:
Models
PDS-220FT
PDS-220FC
PDS-220FCS
PDS-220FCS-60
Fiber
Port
100 Base-FX,
(ST connector)
100 Base-FX,
(SC connector)
100 Base-FX,
(SC connector)
100 Base-FX,
(SC connector)
Mode
Multi-mode fiber cables:
50/125, 62.5/125 or 100/140 μm
Wavelength : 1300 or 1310nm
Min. TX Output:- 20 dBm
Max. TX Output: -14 dBm
Max. RX Sensitivity: -32 dBm
Max. RX Overload: -8 dBm
Budget: 12 dBm
Single-mode fiber
cables: 8.3/125,
8.7/125, 9/125 or
10/125μm
Wavelength: 1300 or
1310nm
Min. TX Output: - 15
dBm,
Max. TX Output: -8
dBm
Max. RX Sensitivity: -
34 dBm,
Max. RX Overload: -5
dBm
Budget: 19 dBm
Single mode fiber
cables: 8.3/125,
8.7/125, 9/125 or
10/125μm
Wavelength: 1300 or
1310nm
Min. TX Output: - 5
dBm,
Max. TX Output: 0
dBm
Max. RX Sensitivity: -
35 dBm,
Max. RX Overload: -5
dBm
Budget: 30 dBm
Distance
2 km, (62.5/125 μm
recommended)
for full duplex
30 Km, (9/125 µm
recommended) for
full duplex
60 Km, (9/125 µm
recommended) for
full duplex
Fiber Port Connector:
Models
PDS-220FT
PDS-220FC
PDS-220FCS
PDS-220FCS-60
Pictures
(ST connector)
(SC connector)
ГК Атлант Инжиниринг – официальный представитель вРФ иСНГ
[phone] [email protected] www.bbrc.ru

PDS-220Fx Series User Manual (V1.2, Apr. 2015) 18
Power:
Protection
Power reverse polarity protection
Input Range
+12 ~ +48 VDC (non-regulated)
Power Consumption
0.14A @ 24 VDC
Frame GND
Yes, for EMS Protection.
Mechanism:
Models
PDS-220FT
PDS-220FC
PDS-220FCS
PDS-220FCS-60
Flammability
Fire Retardant Materials (UL94-V0 Level)
Dimensions
(W x L x H)
31 mm x 121
mm x 157 mm
31 mm x 123 mm x 157 mm
Casing
Fire Retardant Plastic (UL94-V0 level)
Installation
DIN-Rail mounting
Environment:
Operating Temperature
-25°C ~ +75°C
Storage Temperature
-30 ~ +85°C
Humidity
10% ~ 90% RH, non-condensing
ГК Атлант Инжиниринг – официальный представитель вРФ иСНГ
[phone] [email protected] www.bbrc.ru

PDS-220Fx Series User Manual (V1.2, Apr. 2015) 19
3.4 Front View
PDS-220FT Front View:
PDS-220FC/PDS-220FCS/PDS-220FCS-60 Front View:
External Power Supply
External Power Supply
LED Indicator
LED Indicator
COM2: RS-485
COM1: RS-232
Robust insulated
and fire
retardant case
COM2: RS-485
COM1: RS-232
Robust insulated
and fire
retardant case
100 Base-FX
Fiber Port
(ST connector)
100 Base-FX
Fiber Port
(SC connector)
ГК Атлант Инжиниринг – официальный представитель вРФ иСНГ
[phone] [email protected] www.bbrc.ru

PDS-220Fx Series User Manual (V1.2, Apr. 2015) 20
3.5 Pin Assignments
Pin Assignments for PDS-220Fx Series models:
ГК Атлант Инжиниринг – официальный представитель вРФ иСНГ
[phone] [email protected] www.bbrc.ru
