IDK OPF-TH1000D User manual

HDMI Fiber Optic Cable Extender
OPF-TH1000D/OPF-RH1000D
<User Guide>
<Command Guide>
Ver.1.9.0
RS-232C
FG DC 5V 3A
L
AUDIO OUTPUT
R
POW ER
STA TUS
HDCP
HDM I INPUT
Tx
O PTIC AL DAISYCH AIN Tx for HDM I OPF-TH1000D
RX
OPTICAL
TX
C LASS 1 LASER PRO D U C T
クラス 1 レーザ製品
KE Y LOCK
－＋
SET
SIGNAL
RS-232C
FG DC 5V 3A
POW ER
STA TUS
HDCP
HDMI OUTPUT
Rx
O PTIC AL DAISYCH AIN Rx for HDM I OPF-RH1000D
RX
OPTICAL
TX
SIGNAL
DIP SW
C LASS 1 LASER PRO D U C T
クラス 1 レーザ製品
Thank you for choosing our product.
To ensure the best performance of this product, please read this user guide fully and carefully before
using it and keep this manual together with the product for future reference as needed.
IDK Corporation

OPF-TH1000D/OPF-RH1000D User Guide/Command Guide
2
Trademarks
Blu-ray Disc and Blu-ray are trademarks of Blu-ray Disc Association.
The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or
registered trademarks of HDMI Licensing Administrator, Inc. in the United States and other countries.
All other company and product names mentioned in this manual are either registered trademarks or
trademarks of their respective owners. In this manual, the “®” or “™” marks may not be specified.

OPF-TH1000D/OPF-RH1000D User Guide/Command Guide
3
Before reading this manual
All rights reserved.
Some information contained in this User guide such as exact product appearance, diagrams, menu
operations, and so on may differ depending on the product version.
This User guide is subject to change without notice. You can download the latest version from IDK’s
website at: http: //www.idkav.com
FCC STATEMENT
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference, in which case the user will be required to correct the interference
at his own expense.
CE MARKING
This equipment complies with the essential requirements of the relevant European health, safety and
environmental protection legislation.
WEEE MARKING
Waste Electrical and Electronic Equipment (WEEE), Directive 2002/96/EC
(This directive is only valid in the EU.)
This equipment complies with the WEEE Directive (2002/96/EC) marking requirement.
The left marking indicates that you must not discard this electrical/electronic equipment in
domestic household waste.
The lasers in this product meet Class 1 Laser Safety per FDA/CDRH and
EN (IEC) 60825 laser safety standards which specifies design safety.
クラス 1 レーザ製品
CLASS 1 LASER PRODUCT

OPF-TH1000D/OPF-RH1000D User Guide/Command Guide
4
Safety Instructions
Read and understand all safety and operating instructions before using this product. Follow all instructions
and heed all warnings/cautions.
Enforcement Symbol
Description
Indicates the presence of a hazard that may result in death or serious
personal injury if the warning is ignored or the product is handled
incorrectly.
Indicates the presence of a hazard that may cause minor personal
injury or property damage if the caution is ignored or the product is
handled incorrectly.
Symbol
Description
Example
Caution
This symbol is intended to alert the user. (Warning and caution)
Electrical
Hazard
Prohibited
This symbol is intended to prohibit the user from specified actions.
Do not
disassemble
Instruction
This symbol is intended to instruct the user.
Unplug
Warning
Caution

OPF-TH1000D/OPF-RH1000D User Guide/Command Guide
5
■For lifting heavy products:
Instruction
●Lifting must be done by two or more personnel.
To avoid injury: When lifting the product, bend your knees, keep your back straight and get close to it with two or
more persons.
■For installing and connecting products:
Prohibited
●Do not place the product upon a surface that may give way or that may become
unstable.
Install the product in a secure and stable place to prevent it from falling and possibly causing injury.
●Secure the product if installing in locations prone to vibration or movement.
Otherwise, it may move unexpectedly or it may fall and lead to injury.
Instruction
●Installation work must be performed by professionals.
The product is intended to be installed by skilled technicians. For installation, please contact a system integrator
or IDK. Improper installation may lead to the risk of fire, electric shock, injury, or property damage.
●Insert the power plug into an outlet that is unobstructed.
Unobstructed access to the plug enables unplugging the product in case of any extraordinary failure, abnormal
situation or for easy disconnection during extended periods of non-use.
●Insert the power plug into an appropriate outlet completely.
If the plug is partially inserted, arching may cause the connection to overheat, increasing the risk of electrical
shock or fire. Do not use a damaged plug or connect to a damaged outlet.
●Unplug the product from the AC power source during installation or service.
When connecting peripheral devices to this product, unplug all involved devices from outlets. Ground potential
differences may cause fire or other difficulties.
■For operating products:
Prohibited
●Keep out any foreign objects.
To avoid fire or electric shock, do not permit foreign objects, such as metal and paper, to enter the product from
vent holes or other apertures.
●For power cable/ plug:
・
Do not scratch, heat, or modify, including splicing or lengthening them.
・
Do not pull, place heavy objects on them, or pinch them.
・
Do not bend, twist, tie or clamp them together forcefully.
Misuse of the power cable and plug may cause fire or electric shock. If power cables/plugs become damaged,
contact your IDK representative.
Do not
disassemble
●Do not repair, modify or disassemble.
Since the product includes circuitry that uses potentially lethal, high voltage levels, disassembly by unauthorized
personnel may lead to the risk of fire or electric shock. For internal inspection or repair, contact your IDK
representative.
Do not touch
●Do not touch the product and connected cables during electrical storms.
Contact may cause electric shock
Instruction
●Clean the power plug regularly.
If the plug is covered in dust, it may increase the risk of firer.
Warning

OPF-TH1000D/OPF-RH1000D User Guide/Command Guide
6
■If the following problem occurs:
Unplug
●Unplug immediately if the product smokes, makes unusual noise, or produces a
burning odor.
If you continue to use the product under these conditions, it may cause electric shock or fire.
●Unplug immediately if the product is damaged by falling or having been dropped.
If you continue to use the product under these conditions, it may increase the risk of electrical shock or fire. For
maintenance and repair, contact your IDK representative.
●Unplug immediately if water or other objects are directed inside.
If you continue to use the product under these conditions, it may increase the risk of electrical shock or fire. For
maintenance and repair, contact your IDK representative.
Warning

OPF-TH1000D/OPF-RH1000D User Guide/Command Guide
7
■For installing and connecting products:
Prohibited
●Do not place the product in a location where it will be subjected to high
temperatures.
If the product is subjected to direct sunlight or high temperatures while under operation, it may affect the
product’s performance and reliability and may increase the risk of fire.
●Do not store or operate the product in dusty, oil smoke filled, or humid place.
If the product is placed near humidifiers or in a dusty area, it may increase the risk of fire or electric shock.
●Do not block the vent holes.
If ventilation slots are blocked, it may cause the product to overheat, affecting performance and reliability and
may increase the risk of fire.
●Do not place or stack heavy items on the product.
Failure to observe this precaution may result in damage to the product and other property and may lead to the
risk of personal injury.
●Do not exceed ratings of outlet and wiring devices.
Exceeding the rating of an outlet may increase the risk of fire and electric shock.
No wet hands
●Do not handle power plug with wet hands.
Failure to observe this precaution may increase the risk of electrical shock.
Instruction
●Use and store the product within the specified temperature/humidity range.
If the product is used outside the specified range for temperature and humidity continuously, it may increase the
risk of fire or electric shock.
●Do not place the product at elevations of 1.24 mi. (2,000 m) or higher above sea
level.
Failure to do so may shorten the life of the internal parts and result in malfunctions.
●When mounting the product into the rack, provide sufficient cooling space.
Mount the product in a rack meeting EIA standards, and maintain spaces above and below for air circulation. For
your safety as required, attach an L-shaped bracket in addition to the panel mount bracket kit to improve
mechanical stability.
●Never insert screws without the rubber feet into the threaded holes on the bottom
of the product.
Never insert screws without the rubber feet into the threaded holes on the bottom of the product. Doing so may
lead to damage when the screws contact electrical circuitry or components inside the product.
Reinstall the originally supplied rubber feet using only the originally supplied screws.
■For operating products:
Prohibited
●Use only the supplied power cable and AC adapter.
●Do not use the supplied power cable and AC adapter with other products.
If non-compliant adapter or power cables are used, it may increase the risk of fire or electrical shock.
Unplug
●If the product won’t be used for an extended period of time, unplug it.
Failure to observe this precaution may increase the risk of fire.
●Unplug the product before cleaning.
To prevent electric shock.
Instruction
●If cooling fan stops, power off the product and contact us.
Failure to do so may rise internal temperature and increase the risk of malfunction, fire, or electric shock.
●Clean the vent holes regularly.
If the vent holes of the cooling fan is covered in dust, internal temperature rises and it may increase the risk of
malfunction, fire, or electric shock.
Caution

OPF-TH1000D/OPF-RH1000D User Guide/Command Guide
8
Table of Contants
1Included items.......................................................................................................................................... 10
2Precautions for shipping .......................................................................................................................... 11
3Product outline ......................................................................................................................................... 12
4Features................................................................................................................................................... 13
5Part names and descriptions ................................................................................................................... 14
5.1 Transmitter.......................................................................................................................................... 14
5.2 Receiver.............................................................................................................................................. 16
6Precautions .............................................................................................................................................. 18
6.1 Installation........................................................................................................................................... 18
6.1.1 Installing on wall or ceiling .......................................................................................................... 18
6.2 Cabling................................................................................................................................................ 19
6.2.1 Cables ......................................................................................................................................... 19
6.2.2 Fiber optic cable.......................................................................................................................... 19
6.2.3 SFP optical transceiver ............................................................................................................... 20
6.2.4 RS-232C cable ............................................................................................................................ 20
6.2.5 AC adapter with screw locking mechanism ................................................................................ 21
6.3 Application example............................................................................................................................ 22
7Basic operation ........................................................................................................................................ 23
7.1 Menu operation buttons ...................................................................................................................... 23
7.2 Locking menu operation buttons......................................................................................................... 24
7.3 Initialization ......................................................................................................................................... 24
7.4 Setting transmitter and receiver using setting mode .......................................................................... 25
7.4.1 Setting transmitter ....................................................................................................................... 26
7.4.2 Setting receiver ........................................................................................................................... 27
8Menus ...................................................................................................................................................... 28
8.1 Menu list.............................................................................................................................................. 28
8.2 Setting input and output (Setup menu)............................................................................................... 30
8.2.1 [F10] EDID resolution.................................................................................................................. 30
8.2.2 [F16] No-signal input monitoring time ......................................................................................... 32
8.2.3 [F22] PCM Audio......................................................................................................................... 33
8.2.4 [F24] AC-3 Dolby Digital Audio ................................................................................................... 33
8.2.5 [F26] AAC Audio ......................................................................................................................... 33
8.2.6 [F28] Dolby Digital Plus Audio..................................................................................................... 34
8.2.7 [F30] DTS Audio.......................................................................................................................... 34
8.2.8 [F32] DTS-HD Audio ................................................................................................................... 34
8.2.9 [F34] Dolby TrueHD Audio.......................................................................................................... 35
8.2.10 [F36] Audio channel .................................................................................................................... 35
8.2.11 [F65] Audio output....................................................................................................................... 36
8.2.12 [F76] EDID WXGA ...................................................................................................................... 36
8.2.13 [F90] Version............................................................................................................................... 36
8.2.14 [F99] Maintenance/status display menu ..................................................................................... 36
8.3 Verifying operation (Maintenance menu)............................................................................................ 37
8.3.1 [C06] HDCP input setting............................................................................................................ 37
8.3.2 [C55] Forced color conversion output ......................................................................................... 38
8.3.3 [C90] RS-232C communication mode ........................................................................................ 38
8.4 Displaying I/O status (status display menu) ....................................................................................... 39
8.4.1 [L01 to L13] Displaying information about input.......................................................................... 39

OPF-TH1000D/OPF-RH1000D User Guide/Command Guide
9
8.4.2 [L50] Displaying information about output................................................................................... 42
9Command................................................................................................................................................. 43
9.1 Command outline................................................................................................................................ 43
9.2 Command list ...................................................................................................................................... 43
9.3 Command description......................................................................................................................... 44
9.3.1 Error status.................................................................................................................................. 44
9.3.2 Setting command ........................................................................................................................ 45
9.3.3 Status acquisition command ....................................................................................................... 46
10 Specification............................................................................................................................................. 48
10.1 Pin assignments.................................................................................................................................. 48
10.1.1 HDMI Type A connector.............................................................................................................. 48
10.1.2 RS-232C connector..................................................................................................................... 48
10.2 Product specification........................................................................................................................... 50
10.2.1 OPF-H1000D .............................................................................................................................. 50
10.2.2 SFP Specification........................................................................................................................ 50
11 Troubleshooting ....................................................................................................................................... 51

OPF-TH1000D/OPF-RH1000D User Guide/Command Guide
10
1 Included items
Make sure all items below are included in the package.
If any items are missing or damaged, please contact IDK.
“OPF-H1000D” mentioned in this manual refers to OPF-TH1000D and OPF-RH1000D set.
■Transmitter (OPF-TH1000D)
・OPF-TH1000D (main unit)x 1
・SFP optical transceiver x 1
・AC adapter with screw locking mechanism (5.9 ft. (1.8 m)) x 1
・Cable clamp x 1
■Receiver (OPF-RH1000D)
・OPF-RH1000D (main unit)x 1
・SFP optical transceiver x 1
・AC adapter with screw locking mechanism (5.9 ft. (1.8 m)) x 1
・Cable clamp x 1
RS-232C
FG DC 5V 3A
L
AUD I O OUTP UT
R
POWE R
STA T U S
HDC P
HDM I IN PUT
Tx
OPTICAL DAISYCHAIN Tx for HDMI
OPF-TH1000D
RX
OP TI CA L
TX
CLA S S 1 LA SER PRODUCT
クラス1 レーザ製品
KEY LOCK
－＋
SET
SIGN A L
OPF-TH1000D
RS-232C
FG DC 5V 3A
POWE R
STA T U S
HDC P
HD M I OU TP U T
Rx
OPTICAL DAISYCHAIN Rx for HDMI
OPF-RH1000D
RX
OP TI CA L
TX
SIGN A L
DIP SW
CLA S S 1 LA SER PRODUCT
クラス1 レーザ製品
OPF-RH1000D
SFP optical transceiver
AC adapter with screw
locking mechanism
(5.9 ft. (1.8 m))
Cable clamp
Included items
Tip:
Dust caps are attached to SFP optical transceiver and the connector.
These caps will be used for shipping or repairing the OPF-H1000D unit.
