IEI Technology ITG-100-AL User manual

ITG-100-AL Embedded System
Page i
User Manual
,
MODEL:
ITG-100-AL
Fanless Embedded System with Intel® Atom™ x5-E3930,
VGA , GbE, Two RS-232/422/485,
Two USB 3.0 and RoHS Compliant
Rev. 1.01 – 21 February 2019

ITG-100-AL Embedded System
Page ii
Revision
Date Version Changes
21 February 2019 1.01 Updated section 3.3.1: Hard Disk Drive (HDD) Installation
(ITG-100-AL-E1 only)
Updated section 3.10.1: Mounting the System with DIN Rail
Mounting Kit
4 December 2018 1.00 Initial release

ITG-100-AL Embedded System
Page iii
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

ITG-100-AL Embedded System
Page iv
Manual Conventions
WARNING
Warnings appear where overlooked details may cause damage to the
equipment or result in personal injury. Warnings should be taken
seriously.
CAUTION
Cautionary messages should be heeded to help reduce the chance of
losing data or damaging the product.
NOTE
These messages inform the reader of essential but non-critical
information. These messages should be read carefully as any directions
or instructions contained therein can help avoid making mistakes.
HOT SURFACE
This symbol indicates a hot surface that should not be touched without
taking care.

ITG-100-AL Embedded System
Page v
Table of Contents
1 INTRODUCTION........................................................................................................... 2
1.1 OVERVIEW................................................................................................................... 3
1.2 MODEL VARIATIONS..................................................................................................... 3
1.3 FEATURES................................................................................................................... 4
1.4 TECHNICAL SPECIFICATIONS........................................................................................ 4
1.5 SIDE PANEL................................................................................................................. 6
1.6 FRONT PANEL.............................................................................................................. 6
1.7 PHYSICAL DIMENSIONS................................................................................................ 8
1.7.1 ITG-100-AL-E1 Physical Dimensions ............................................................... 8
1.7.1 ITG-100-AL-E1/S Physical Dimensions ............................................................ 9
2 UNPACKING ................................................................................................................ 10
2.1 UNPACKING................................................................................................................11
2.2 PACKING LIST.............................................................................................................11
3 INSTALLATION........................................................................................................... 13
3.1 ANTI-STATIC PRECAUTIONS........................................................................................ 14
3.2 INSTALLATION PRECAUTIONS ..................................................................................... 14
3.3 INSTALLATION AND CONFIGURATION STEPS ................................................................ 15
3.4 HARD DISK DRIVE (HDD) INSTALLATION (ITG-100-AL-E1 ONLY)............................. 15
3.5 SO-DIMM INSTALLATION.......................................................................................... 17
3.6 WIRELESS LAN MODULE INSTALLATION (OPTIONAL).................................................. 19
3.7 ADDITIONAL BLOCK LAYER INSTALLATION .................................................................. 22
3.8 AT/ATX MODE SELECTION........................................................................................ 24
3.8.1 AT Power Mode................................................................................................ 25
3.8.2 ATX Power Mode............................................................................................. 25
3.9 RESET THE SYSTEM.................................................................................................... 25
3.10 POWERING ON/OFF THE SYSTEM ............................................................................. 26
3.11 MOUNTING THE SYSTEM........................................................................................... 26
3.11.1 Mounting the System with DIN Rail Mounting Kit ........................................ 26
3.12 RS-232/422/485 SERIAL PORT CONNECTION ........................................................... 28

ITG-100-AL Embedded System
Page vi
3.12.1 DB-9 RS-232/422/485 Serial Port Connection.............................................. 28
3.12.2 RJ-45 RS-232/422/485 Serial Port Connection............................................. 29
4 SYSTEM MOTHERBOARD........................................................................................ 32
4.1 OVERVIEW................................................................................................................. 33
4.1.1 Layout .............................................................................................................. 33
4.2 INTERNAL PERIPHERAL CONNECTORS......................................................................... 34
4.2.1 Battery Connector (BT1).................................................................................. 34
4.2.2 BIOS Programming Connector (J_SPI1) ........................................................ 34
4.2.3 Debug Connector (DBG_PORT1)................................................................... 35
4.2.4 DIO Connector (J_DIO2)................................................................................ 35
4.2.5 EC ROM Flash Connector (EC_JP1).............................................................. 35
4.2.6 RS-232 Serial Port Connector (COM3)......................................................... 35
4.2.7 RS-232 Serial Port Connector (COM4)......................................................... 36
4.2.8 SMBUS/I2C Connector (J_SMB2)................................................................. 36
4.2.9 SATA 6Gb/s Drive Connectors (SATA1).......................................................... 36
4.2.10 SATA Power Connector (SATA_PWR1)......................................................... 36
4.2.11 Micro SD Connector (SD1)............................................................................ 37
4.3 EXTERNAL INTERFACE PANEL CONNECTORS................................................................ 37
4.3.1 Ethernet Connector (LAN1)............................................................................. 37
4.3.2 Ethernet Connector (LAN2)............................................................................. 38
4.3.3 Power Button (SW1) ...................................................................................... 38
4.3.4 DC-IN Connector (PWR1)............................................................................... 38
4.3.5 RS-232/422/485 Connector (COM1)............................................................ 39
4.3.6 RJ45 to RS-232/422/485 Connector (COM2)............................................. 39
4.3.7 USB 3.1 GEN 1 Connectors (CON1)............................................................... 39
4.3.8 VGA Connector (VGA1)................................................................................... 40
4.4 JUMPER SETTINGS..................................................................................................... 40
4.4.1 AT/ATX Mode Select Switch (J_ATX_AT1)...................................................... 40
4.4.2 Clear CMOS Button (J_CMOS1)..................................................................... 41
4.4.3 System Reset Button (RST1)............................................................................. 41
4.4.4 Flash Descriptor Security Override Jumper Settings (J_TXE1).................... 41
5 BIOS.............................................................................................................................. 42
5.1 INTRODUCTION ......................................................................................................... 43

ITG-100-AL Embedded System
Page vii
5.1.1 Starting Setup................................................................................................... 43
5.1.2 Using Setup...................................................................................................... 43
5.1.3 Getting Help..................................................................................................... 44
5.1.4 Unable to Reboot after Configuration Changes.............................................. 44
5.1.5 BIOS Menu Bar................................................................................................ 44
5.2 MAIN ........................................................................................................................ 45
5.3 ADVANCED................................................................................................................ 46
5.3.1 ACPI Settings................................................................................................... 47
5.3.2 F81866 Super IO Configuration...................................................................... 48
5.3.2.1 Serial Port n Configuration...................................................................... 48
5.3.3 Hardware Monitor ........................................................................................... 50
5.3.4 RTC Wake Settings........................................................................................... 51
5.3.5 Serial Port Console Redirection ...................................................................... 53
5.3.5.1 Console Redirection Settings .................................................................... 53
5.3.6 CPU Configuration.......................................................................................... 56
5.3.7 USB Configuration........................................................................................... 57
5.3.8 iEi Feature........................................................................................................ 58
5.3.9 SATA Configuration ......................................................................................... 59
5.4 CHIPSET.................................................................................................................... 60
5.4.1 North Bridge Configuration............................................................................. 61
5.4.1.1 Intel IGD Configuration ........................................................................... 61
5.4.2 Southbridge Configuration .............................................................................. 63
5.4.2.1 PCI Express Configuration....................................................................... 64
5.4.2.2 SCC Configuration.................................................................................... 65
5.5 SECURITY.................................................................................................................. 66
5.6 BOOT........................................................................................................................ 67
5.7 EXIT.......................................................................................................................... 69
6 SOFTWARE INSTALLATION .................................................................................... 71
6.1.1 Available Drivers ............................................................................................. 72
6.1.2 Driver Download ............................................................................................. 72
A REGULATORY COMPLIANCE ................................................................................. 74
B SAFETY PRECAUTIONS........................................................................................... 80
B.1 SAFETY PRECAUTIONS............................................................................................... 81

ITG-100-AL Embedded System
Page viii
B.1.1 General Safety Precautions............................................................................. 81
B.1.2 Anti-static Precautions .................................................................................... 82
B.1.3 Product Disposal............................................................................................. 83
B.2 MAINTENANCE AND CLEANING PRECAUTIONS............................................................ 84
B.2.1 Maintenance and Cleaning.............................................................................. 84
B.2.2 Cleaning Tools................................................................................................. 84
C BIOS MENU OPTIONS.............................................................................................. 86
D TERMINOLOGY ......................................................................................................... 89
E HAZARDOUS MATERIALS DISCLOSURE............................................................. 93

ITG-100-AL Embedded System
Page ix
List of Figures
Figure 1-1: ITG-100-AL...................................................................................................................3
Figure 1-2: ITG-100-AL Side Panel................................................................................................6
Figure 1-3: ITG-100-AL Front Panel..............................................................................................7
Figure 1-4: ITG-100-AL-E1 Physical Dimensions (mm) ..............................................................8
Figure 1-5: ITG-100-AL-E1/S Physical Dimensions (mm)...........................................................9
Figure 3-1: Remove the Bottom Panel........................................................................................16
Figure 3-2: HDD Bracket ..............................................................................................................16
Figure 3-3: Install the HDD...........................................................................................................17
Figure 3-4: SO-DIMM Socket .......................................................................................................18
Figure 3-5: SO-DIMM Installation ................................................................................................18
Figure 3-6: Knockout Holes for Wireless Antenna....................................................................19
Figure 3-7: M.2 A key Slot Location............................................................................................19
Figure 3-8: Inserting the WLAN Module.....................................................................................20
Figure 3-9: Securing WLAN Module and Connecting RF Cables............................................21
Figure 3-10: Securing SMA Connector and External Antenna Installation ............................21
Figure 3-11: Remove the Bottom Panel (ITG-100-AL-E1/S)......................................................22
Figure 3-12: Additional Block Layer Installation.......................................................................23
Figure 3-13: HDD Bracket Installation........................................................................................23
Figure 3-14: Reinstall the Bottom Panel (ITG-100-AL-E1)........................................................24
Figure 3-15: AT/ATX Switch Location.........................................................................................24
Figure 3-16: Reset Button Location............................................................................................26
Figure 3-17: Power Button Location...........................................................................................26
Figure 3-18: Mounting the DIN Rail.............................................................................................27
Figure 3-19: Mounting the Track to the DIN Rail.......................................................................27
Figure 3-20: Serial Device Connector.........................................................................................28
Figure 3-21: DB-9 RS-232/422/485 Serial Port Connector ........................................................29
Figure 3-22: Serial Device Connector.........................................................................................30
Figure 3-23: RJ-45 RS-232/422/485 Serial Port Connector.......................................................30
Figure 3-24: DB-9 RS-232/422/485 Connector Pinout Location...............................................31
Figure 4-1: System Motherboard (Front)....................................................................................33

ITG-100-AL Embedded System
Page x
Figure 4-2: System Motherboard (Rear).....................................................................................33
Figure 6-1: IEI Resource Download Center................................................................................72

ITG-100-AL Embedded System
Page xi
List of Tables
Table 1-1: ITG-100-AL Model Variations.......................................................................................3
Table 1-2: Technical Specifications..............................................................................................5
Table 2-1: Package List Contents...............................................................................................12
Table 3-1: RJ-45 RS-232/422/485 Serial Port Pinouts ...............................................................30
Table 3-2: DB-9 RS-232/422/485 Connector Pinouts.................................................................31
Table 4-1: Peripheral Interface Connectors...............................................................................34
Table 4-2: Battery Connector Pinouts (BAT1) ...........................................................................34
Table 4-3: BIOS Programming Connector Pinouts (J_SPI1)....................................................34
Table 4-4: Debug Connector Pinouts (DBG_PORT1)................................................................35
Table 4-5: DIO Connector Pinouts (J_DIO2) ..............................................................................35
Table 4-6: EC ROM Flash Connector Pinouts (EC_JP1)...........................................................35
Table 4-7: RS-232 Serial Port Connector Pinouts (COM3) .......................................................36
Table 4-8: RS-232 Serial Port Connector Pinouts (COM4) .......................................................36
Table 4-9: SMBUS/I2C Connector Pinouts (J_SMB2) ...............................................................36
Table 4-10: SATA 6Gb/s Drive Connectors Pinouts (SATA1) ..................................................36
Table 4-11: SATA Power Connector Pinouts (SATA_PWR1)...................................................36
Table 4-12: Micro SD Connector Pinouts (SD1) ........................................................................37
Table 4-13: Rear Panel Connectors............................................................................................37
Table 4-14: Ethernet Connector Pinouts (LAN1).......................................................................38
Table 4-15: Ethernet Connector Pinouts (LAN2).......................................................................38
Table 4-16: Power Button Pinouts (SW1)...................................................................................38
Table 4-17: DC-IN Connector Pinouts (PWR1)...........................................................................38
Table 4-18: RS-232/422/485 Connector (COM1).........................................................................39
Table 4-19: RS-232/422/485 Connector (COM2).........................................................................39
Table 4-20: USB 3.1 GEN 1 Connectors Pinouts (CON1)..........................................................40
Table 4-21: VGA Connector Pinouts (VGA1) .............................................................................40
Table 4-22: Buttons, Jumper and Switch...................................................................................40
Table 4-23: AT/ATX Mode Select Switch (J_ATX_AT1).............................................................40
Table 4-24: Clear CMOS Button (J_CMOS1)..............................................................................41
Table 4-25: System Reset Button (RST1)...................................................................................41

ITG-100-AL Embedded System
Page xii
Table 4-26: Flash Descriptor Security Override Jumper Settings ( J_TXE1).......................41
Table 5-1: BIOS Navigation Keys................................................................................................44

ITG-100-AL Embedded System
Page 1
BIOS Menus
BIOS Menu 1: Main.......................................................................................................................45
BIOS Menu 2: Advanced..............................................................................................................46
BIOS Menu 3: ACPI Configuration..............................................................................................47
BIOS Menu 4: Super IO Configuration........................................................................................48
BIOS Menu 5: Serial Port 1 Configuration Menu.......................................................................48
BIOS Menu 6: Hardware Monitor.................................................................................................51
BIOS Menu 7: RTC Wake Settings..............................................................................................52
BIOS Menu 8: Serial Port Console Redirection.........................................................................53
BIOS Menu 9: Console Redirection Settings.............................................................................54
BIOS Menu 10: CPU Configuration.............................................................................................56
BIOS Menu 11: USB Configuration.............................................................................................57
BIOS Menu 12: iEi Feature...........................................................................................................58
BIOS Menu 13: IDE Configuration...............................................................................................59
BIOS Menu 14: Chipset................................................................................................................60
BIOS Menu 15: Northbridge Chipset Configuration..................................................................61
BIOS Menu 16: Integrated Graphics...........................................................................................62
BIOS Menu 17: Southbridge Chipset Configuration.................................................................63
BIOS Menu 18: PCI Express Configuration ...............................................................................64
BIOS Menu 19: PCI Express Configuration ...............................................................................65
BIOS Menu 20: Security...............................................................................................................66
BIOS Menu 21: Boot.....................................................................................................................67
BIOS Menu 22:Exit........................................................................................................................69

ITG-100-AL Embedded System
Page 2
Chapter
1
1 Introduction

ITG-100-AL Embedded System
Page 3
1.1 Overview
Figure 1-1: ITG-100-AL
The ITG-100-AL embedded system is a fanless system with one VGA port for display. It
accepts an Intel® Atom™ x5-E3930 processor and supports one 204-pin DDR3L
SO-DIMM module up to 8 GB (ITG-100-AL-E1/2GB/S and ITG-100-AL-E1/2GB SKUs are
pre-installed with 2 GB memory). Two RS-232/422/485 serial ports and two USB 3.1
GEN 1 ports ensure simplified connectivity to a variety of external peripheral devices.
1.2 Model Variations
The model variations of the ITG-100-AL series are listed below.
Model No. 2GB DDR3L Pre-installed Memory Flexible I/O Expansion
ITG-100-AL-E1 No Yes
TG-100-AL-E1/2GB Yes Yes
ITG-100-AL-E1/2GB/S Yes No
ITG-100-AL-E1/S No No
Table 1-1: ITG-100-AL Model Variations

ITG-100-AL Embedded System
Page 4
1.3 Features
The ITG-100-AL features are listed below:
Intel® Atom™ x5-E3930 1.3GHz (up to 1.8 GHz)
Two GbE LAN ports
Two RS-232/422/485
Full-size PCIe Mini slot and M.2 A-key slot for expansion
1.4 Technical Specifications
The ITG-100-AL technical specifications are listed in Table 1-2.
Model Name ITG-100-AL-E1/S ITG-100-AL-E1
Chassis
Color Blue & Silver
Dimensions (WxDxH) 137 x 102.8 x 36.2 (mm) 137 x 102.8 x 56.2 (mm)
System Fan Fanless
C6 Extruded aluminum alloy
Motherboard
CPU Intel® Atom™ x5-E3930 1.3 GHz (up to 1.8GHz, dual-core, TDP=6.5W)
Chipset SoC
System Memory 1x 204-pin DDR3L SO-DIMM
slot (system max. 8 GB)
(ITG-100-AL-E1/2GB/S-R10
SKU is pre-installed with 2 GB
memory)
1x 204-pin DDR3L SO-DIMM slot
(system max. 8 GB)
(ITG-100-AL-E1/2GB-R10 SKU is
pre-installed with 2 GB memory)
Storage
Hard Drive N/A 1 x 2.5'' SATA 6Gb/s HDD/SSD bay
eMMC 1 x eMMC 5.0 support (up to 32GB optional)
Micro SD 1 x Micro SD Slot (optional)
I/O Interfaces
USB 3.1 GEN 1 2 x USB 3.1 GEN 1 ports

ITG-100-AL Embedded System
Page 5
USB
2
.0 2 x USB 2.0 ports by pin-header (optional)
Ethernet 2 x RJ-45 PCIe GbE by I211-AT controller
COM Port 2 x RS-232/422/485 (DB-9/RJ45)
2 x RS-232 by pin-header (optional)
Digital I/O 8-bit digital I/O, 4-bit input/4-bit output by pin-header (optional)
Display 1 x VGA
Resolution Up to 1920x1080@60Hz
Wireless 1 x 802.11a/b/g/n/ac (optional)
Others 1 x Power Button, 1 x Reset Button, 1 x AT/ATX Switch,
1 x LED for HDD (Yellow),1 x LED for Power (Green)
Expansions
M.2 1 x M.2 2230 (A key, PCIe by 1, USB2.0)
PCIe Mini 1 x Full-size PCIe Mini slot (supports mSATA, colay with SATA)
Power
Power Input 2-pin terminal block: 12 V DC
Power Consumption 12V @ 1A (Intel® Atom™ E3930 with 2GB memory)
Reliability
Mounting DIN-rail / Wall mounting
Operating Temperature -20°C ~ 60°C with air flow (SSD), 10% ~ 95%, non-condensing
Storage Temperature -30°C ~ 70°C with air flow (SSD), 10% ~ 90%, non-condensing
Operating Shock Half-sine wave shock 5G, 11ms, 100 shocks per axis, IEC68-2-27
Operating Vibration MIL-STD-810G 514.6C-1 (SSD)
Safety / EMC CE/FCC
Watchdog Timer Programmable 1~255 sec/min
OS
Supported OS Microsoft® Windows 10 / Linux
Table 1-2: Technical Specifications

ITG-100-AL Embedded System
Page 6
1.5 Side Panel
The side panel of the ITG-100-AL has the following features (Figure 1-2):
1 x 12V DC IN
1 x VGA connector
Figure 1-2: ITG-100-AL Side Panel
1.6 Front Panel
The front panel of the ITG-100-AL has the following features (Figure 1-3):
1 x AT/ATX Switch
1 x HDD LED
1 x Power button
1 x Power LED
1 x Reset button
2 x RJ-45 LAN connectors
2 x RS-232/422/485 serial port connectors (DB-9/RJ45)
2 x USB 3.1 GEN 1 connectors

ITG-100-AL Embedded System
Page 7
Figure 1-3: ITG-100-AL Front Panel

ITG-100-AL Embedded System
Page 8
1.7 Physical Dimensions
1.7.1 ITG-100-AL-E1 Physical Dimensions
The physical dimensions of the ITG-100-AL-E1 are shown below:
Figure 1-4: ITG-100-AL-E1 Physical Dimensions (mm)
