IEI Technology AFL3-W19A-AL User manual

AFL3-W19A-AL Panel PC
Page I
User Manual
AFL3-W19A-AL
MODEL:
Flat Bezel Panel PC with Intel® Celeron® J3455 CPU,
Touchscreen, Four USB, Dual GbE LAN, RS-232/422/485,
HD Audio, Wi-Fi 802.11a/b/g/n/ac and RoHS
Rev. 1.01 - December 7, 2018
User Manual

AFL3-W19A-AL Panel PC
Page II
Revision
Date Version Changes
December 7, 2018 1.01 Added anti-glare and anti-UV touchscreen feature
Added E-Window module support list
June 15, 2018 1.00 Initial release

AFL3-W19A-AL Panel PC
Page III
Safety Instructions
Warning! Read the user manual before connecting the system to the power
source.
Vorsicht! Bitte lesen Sie die Bedienungsanleitung, bevor Sie das System an eine
Stromquelle anschließen.
Attention! Avant de brancher le système à la source d'alimentation, consultez le
mode d'emploi.
Avvertenza! Consultare il manuale utente prima di collegare il sistema
all'alimentatore.
Atención! Lea atentamente este manual del usuario antes de operar la fuente de
alimentación.
警告！在將系統連接到電源之前，請仔細閱讀使用手冊。
警告！在将系统连接到电源之前，请仔细阅读使用手册。
Warning! To prevent the system from overheating, do not operate it in an area that
exceeds the maximum operating temperature described in the user manual.
Vorsicht! Um eine Überhitzung des Systems zu vermeiden, betreiben Sie es
ausschließlich im zulässigen Betriebstemperaturbereich. Dieser ist in der
Bedienungsanleitung vermerkt.
Attention! Pour éviter la surchauffe du système, ne l'utilisez pas dans une zone
dont la température dépasse les limites décrits dans le mode d'emploi.
Avvertenza! Per evitare che il sistema si surriscaldi, non utilizzarlo in aree che
superino la temperatura massima d'esercizio descritta nel manuale utente.
Atención! Para evitar el excesivo calentamiento del sistema, no opere en las
condiciones de temperatura superior a lo recomendado en este manual del
usuario.
警告！為防止系統過熱，不要在使用手冊上記載的產品工作溫度範圍之外操作此系
統。
警告！为防止系统过热，不要在使用手册上记载的产品工作温度范围之外操作此系
统。

AFL3-W19A-AL Panel PC
Page IV
Warning! Use only the adapter and power cord approved for this system. Use of
another type of adapter may risk fire or explosion. Please refer to the user manual
for the power adapter specifications.
Vorsicht! Nur zugelassene Netzteile und Netzkabel dürfen verwendet werden. Die
Benutzung von anderen Netzteilen kann einen Brand oder eine Explosion zur
Folge haben. Prüfen Sie die jeweiligen Spezifikationen in der
Bedienungsanleitung.
Attention! Utilisez exclusivement le câble d'alimentation et l’adaptateur
homologués pour ce système. L’utilisation d’un autre type d’adaptateur risquerait
de provoquer un incendie ou une explosion. Veuillez référer au mode d'emploi
pour les spécifications de l'adaptateur d'alimentation.
Avvertenza! Utilizzare solo l'adattatore e il cavo di alimentazione approvati per
questo sistema. L'uso di un altro tipo di adattatore può causare rischio d'incendio
o esplosione. Si prega di fare riferimento al manuale utente per le specifiche
sull'alimentazione.
Atención! Utilice solamente el adaptador de corriente alterna (CA) con Marcas
Conformidad otorgadas. Cualquier otro adaptador no otorgado aumenta el riesgo
de explosión o incendio. Por favor consulte el manual del usuario para las
especificaciones del adaptador de alimentación.
警告！只能使用經過認證、適用於本系統的電源變壓器與電源線。使用不適用的電
源變壓器將可能導致火災或爆炸。電源變壓器規格請參考使用手冊。
警告！只能使用经过认证，适用于本系统的电源适配器与电源线。使用不适用的电
源适配器将可能导致火灾或爆炸。电源适配器规格请参考使用手册。
Warning! Ultimate disposal of this product should be handled according to all
national laws and regulations.
Vorsicht! Die Entsorgung dieses Produkts sollte gemäß allen Bestimmungen und
Gesetzen des Landes erfolgen.
Attention! La mise au rebut ou le recyclage de ce produit sont généralement
soumis aux lois et/ou directives de respect de l'environnement. Renseignez-vous
auprès de l'organisme compétent.
Avvertenza! Lo smaltimento di questo prodotto deve essere eseguito secondo le
leggi e i regolamenti locali.
Atención! La disposición final de residuos de este producto se debe cumplir con
las normativas y leyes del país.
警告！本產品的廢棄處理應根據該國家的法律和規章進行。
警告！本产品的废弃处理应根据该国家的法律和规章进行。

AFL3-W19A-AL Panel PC
Page V
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

AFL3-W19A-AL Panel PC
Page VI
Manual Conventions
WARNING
Warnings appear where overlooked details may cause damage to the
equipment or result in personal injury. Warnings should be taken
seriously.
CAUTION
Cautionary messages should be heeded to help reduce the chance of
losing data or damaging the product.
NOTE
These messages inform the reader of essential but non-critical
information. These messages should be read carefully as any directions
or instructions contained therein can help avoid making mistakes.
HOT SURFACE
This symbol indicates a hot surface that should not be touched without
taking care.

AFL3-W19A-AL Panel PC
Page VII
Table of Contents
1 INTRODUCTION.......................................................................................................... 1
1.1 OVERVIEW.................................................................................................................. 2
1.2 FEATURES................................................................................................................... 3
1.3 FRONT PANEL............................................................................................................. 4
1.4 BOTTOM PANEL.......................................................................................................... 5
1.5 REAR PANEL............................................................................................................... 5
1.6 SIDE PANEL ................................................................................................................ 6
1.7 SYSTEM SPECIFICATIONS............................................................................................ 7
1.8 DIMENSIONS............................................................................................................. 10
2 UNPACKING................................................................................................................11
2.1 UNPACKING.............................................................................................................. 12
2.2 PACKING LIST........................................................................................................... 12
2.3 OPTIONAL ITEMS...................................................................................................... 14
3 INSTALLATION ......................................................................................................... 16
3.1ANTI-STATIC PRECAUTIONS...................................................................................... 17
3.2 INSTALLATION PRECAUTIONS................................................................................... 17
3.3 INSTALLATION AND CONFIGURATION STEPS ............................................................. 18
3.4 REMOVING THE BACK COVERS ................................................................................ 18
3.5 MSATA MODULE INSTALLATION.............................................................................. 19
3.5.1 PCIe Mini Slot Mode Selection........................................................................ 21
3.6 HDD INSTALLATION................................................................................................. 22
3.7 SERIAL PORT CONFIGURATION AND CONNECTION.................................................... 25
3.7.1 Serial Port Connection .................................................................................... 25
3.7.2 RS-232 Serial Port Pinouts.............................................................................. 26
3.7.3 RS-232/422/485 Serial Port Pinouts................................................................ 26
3.7.4 DB-9 Serial Port Pin 9 Selection..................................................................... 27
3.8AT/ATX MODE SELECTION...................................................................................... 28
3.8.1 AT Power Mode................................................................................................ 28
3.8.2 ATX Power Mode............................................................................................. 29

AFL3-W19A-AL Panel PC
Page VIII
3.9 MOUNTING THE SYSTEM .......................................................................................... 29
3.9.1 Wall Mounting.................................................................................................. 29
3.9.2 Panel Mounting................................................................................................ 32
3.9.3 Arm Mounting.................................................................................................. 35
3.9.4 Stand Mounting................................................................................................ 37
3.10 POWERING ON THE SYSTEM................................................................................... 38
3.11 RESET THE SYSTEM................................................................................................ 39
3.12 CLEAR CMOS........................................................................................................ 40
3.13 SOFTWARE INSTALLATION ...................................................................................... 40
3.13.1 Driver Download........................................................................................... 41
4 BIOS SETUP................................................................................................................ 43
4.1 INTRODUCTION......................................................................................................... 44
4.1.1 Starting Setup................................................................................................... 44
4.1.2 Using Setup...................................................................................................... 44
4.1.3 Getting Help..................................................................................................... 45
4.1.4 Unable to Reboot after Configuration Changes.............................................. 45
4.1.5 BIOS Menu Bar................................................................................................ 45
4.2 MAIN........................................................................................................................ 46
4.3ADVANCED............................................................................................................... 47
4.3.1 ACPI Settings................................................................................................... 48
4.3.2 F81866 Super IO Configuration...................................................................... 49
4.3.2.1 Serial Port n Configuration....................................................................... 49
4.3.2.2 Serial Port 1 Configuration....................................................................... 50
4.3.2.3 Serial Port 2 Configuration....................................................................... 51
4.3.3 iWDD H/W Monitor......................................................................................... 52
4.3.4 USB Configuration........................................................................................... 53
4.3.5 CPU Configuration.......................................................................................... 54
4.3.6 RTC Wake Settings........................................................................................... 56
4.3.7 Power Saving Configuration............................................................................ 57
4.3.8 Serial Port Console Redirection ...................................................................... 58
4.3.8.1 Legacy Console Redirection Settings....................................................... 59
4.3.9 IEI Feature....................................................................................................... 60
4.4 CHIPSET ................................................................................................................... 61
4.4.1 North Bridge Configuration............................................................................. 62

AFL3-W19A-AL Panel PC
Page IX
4.4.1.1 Intel IGD Configuration............................................................................ 62
4.4.1.2 LCD Control ............................................................................................. 65
4.4.2 South Bridge Configuration............................................................................. 66
4.4.2.1 HD-Audio Configuration.......................................................................... 67
4.4.2.2 PCI Express Configuration....................................................................... 68
4.4.2.2.1 M2_AKEY1........................................................................................ 69
4.4.2.2.2 MSATA1 ............................................................................................. 70
4.4.2.3 SATA Configuration.................................................................................. 71
4.5 SECURITY................................................................................................................. 72
4.6 BOOT........................................................................................................................ 73
4.7 SAVE &EXIT............................................................................................................ 75
5 SYSTEM MAINTENANCE ....................................................................................... 77
5.1 SYSTEM MAINTENANCE INTRODUCTION .................................................................. 78
5.2ANTI-STATIC PRECAUTIONS...................................................................................... 78
5.3 TURN OFF THE POWER.............................................................................................. 79
5.4 SO-DIMM MODULE REPLACEMENT........................................................................ 79
6 INTERFACE CONNECTORS................................................................................... 81
6.1 PERIPHERAL INTERFACE CONNECTORS..................................................................... 82
6.2 INTERNAL PERIPHERAL CONNECTORS...................................................................... 83
6.2.1 Battery Connector (BAT1) ............................................................................... 84
6.2.1 Chassis Intrusion Connector (CHASSIS1)....................................................... 84
6.2.2 Debug Connector (80PORT1) ......................................................................... 84
6.2.1 Debug Connector, EC (CN2) ........................................................................... 85
6.2.2 Digital I/O Connector (DIO1)......................................................................... 85
6.2.3 Inverter Connector (INV_CN1) ....................................................................... 86
6.2.1 LAN1 Link LED Connector (LED_LAN1)....................................................... 86
6.2.1 LAN2 Link LED Connector (LED_LAN2)....................................................... 86
6.2.2 LVDS Connector (LVDS1)............................................................................... 87
6.2.3 M.2 A-key Slot (M2_AKEY1)........................................................................... 88
6.2.4 Microphone Connector (DMIC1) .................................................................... 89
6.2.5 PCIe Mini Connector, Full-Size (MSATA1) ..................................................... 89
6.2.6 Power LED Connector (PW_LED1)................................................................ 90
6.2.7 SATA Connector (SATA1)................................................................................. 91

AFL3-W19A-AL Panel PC
Page X
6.2.1 Speaker Connector (SPEAKER1) .................................................................... 91
6.2.2 SPI Flash Connector (JSPI1)........................................................................... 91
6.2.1 SPI Flash Connector, EC (JSPI2).................................................................... 92
6.2.2 Touch Panel Connector (TOUCH1)................................................................. 92
6.2.3 TTL Serial Connector, COM4 (NFC_CN1) ..................................................... 93
6.2.4 USB 2.0 Connector (USB1~USB4).................................................................. 93
6.2.5 USB Power Connector (USB_PWR1).............................................................. 93
6.3 EXTERNAL INTERFACE PANEL CONNECTORS............................................................ 94
6.3.1 Ethernet Connectors (LAN1 & LAN2)............................................................. 94
6.3.2 HDMI Connector (HDMI1)............................................................................. 95
6.3.3 RS-232/422/485 DB-9 Serial Port (COM1)..................................................... 95
6.3.4 RS-232 RJ-45 Serial Port (COM2).................................................................. 95
6.3.5 USB 3.0 Connectors (USB3-1) ........................................................................ 96
6.4 PRECONFIGURED JUMPER SETTINGS......................................................................... 96
6.4.1 Backlight Voltage Selection Jumper (J_BKPWR1).......................................... 97
6.4.2 Flash Descriptor Security Override Jumper.................................................... 97
6.4.3 LVDS Panel Voltage Selection Jumper (J_VLVDS1)....................................... 98
6.4.4 LVDS Panel Resolution Selection Jumper (SW1)............................................ 98
A REGULATORY COMPLIANCE.............................................................................. 99
B SAFETY PRECAUTIONS....................................................................................... 105
B.1 SAFETY PRECAUTIONS........................................................................................... 106
B.1.1 General Safety Precautions........................................................................... 106
B.1.2 Anti-static Precautions .................................................................................. 107
B.1.3 Product Disposal........................................................................................... 108
B.2 MAINTENANCE AND CLEANING PRECAUTIONS ...................................................... 109
B.2.1 Maintenance and Cleaning............................................................................ 109
B.2.2 Cleaning Tools............................................................................................... 109
C BIOS MENU OPTIONS............................................................................................111
D WATCHDOG TIMER ...............................................................................................114
E HAZARDOUS MATERIALS DISCLOSURE ........................................................117

AFL3-W19A-AL Panel PC
Page XI
List of Figures
Figure 1-1: AFL3-W19A-AL Flat Bezel Panel PC .........................................................................2
Figure 1-2: Front View....................................................................................................................4
Figure 1-3: Bottom Panel...............................................................................................................5
Figure 1-4: Rear View.....................................................................................................................5
Figure 1-5: Side View......................................................................................................................6
Figure 1-6: Dimensions (mm)......................................................................................................10
Figure 3-1: Back Cover Retention Screws.................................................................................18
Figure 3-2: Aluminum Cover Retention Screws........................................................................19
Figure 3-3: mSATA Module Slot Location..................................................................................20
Figure 3-4: Installing an mSATA Module ...................................................................................20
Figure 3-5: Securing the mSATA Module...................................................................................21
Figure 3-6: PCIe Mini Slot Mode Switch Location.....................................................................21
Figure 3-7: HDD Bracket Retention Screws...............................................................................22
Figure 3-8: HDD Retention Screws.............................................................................................23
Figure 3-9: HDD Installation ........................................................................................................23
Figure 3-10: HDD Thermal Pad....................................................................................................24
Figure 3-11: Attach HDD Thermal Pad........................................................................................24
Figure 3-12: Serial Device Connection.......................................................................................25
Figure 3-13: DB-9 Serial Port Pin 9 Setting Jumper Locations................................................28
Figure 3-14: AT/ATX Switch Location.........................................................................................28
Figure 3-15: Wall-mounting Bracket...........................................................................................30
Figure 3-16: Chassis Support Screws........................................................................................31
Figure 3-17: Secure the Panel PC...............................................................................................32
Figure 3-18: Cutout Dimensions.................................................................................................33
Figure 3-19: Panel Mounting Kit Installation .............................................................................34
Figure 3-20: Securing Panel Mounting Brackets.......................................................................35
Figure 3-21: Arm Mounting Retention Screw Holes..................................................................36
Figure 3-22: Arm Mounting..........................................................................................................37
Figure 3-23: Stand Mounting (Stand-A/Bxx)..............................................................................38
Figure 3-24: Powering On the System........................................................................................39
Figure 3-25: Reset Button Location............................................................................................39

AFL3-W19A-AL Panel PC
Page XII
Figure 3-26: Clear CMOS Button Location.................................................................................40
Figure 3-27: IEI Resource Download Center..............................................................................40
Figure 5-1: SO-DIMM module Location ......................................................................................79
Figure 5-2: SO-DIMM Installation ................................................................................................80
Figure 6-1: Main Board Layout Diagrams ..................................................................................82

AFL3-W19A-AL Panel PC
Page XIII
List of Tables
Table 1-1: Supported E-Window Modules....................................................................................6
Table 1-2: System Specifications..................................................................................................9
Table 3-1: PCIe Mini Slot Mode Selection (J_SATA1)...............................................................21
Table 3-2: RS-232 RJ-45 Serial Port (COM2) Pinouts................................................................26
Table 3-3: RS-232 DB-9 Serial Port (COM2) Pinouts.................................................................26
Table 3-4: RS-232/422/485 RJ-45 Serial Port (COM1) Pinouts .................................................26
Table 3-5: RS-232/422/485 DB-9 Serial Port (COM1) Pinouts...................................................27
Table 3-6: COM1 Pin 9 Setting Jumper Settings (JP1) .............................................................27
Table 3-7: COM2 Pin 9 Setting Jumper Settings (JP2) .............................................................27
Table 6-1: Peripheral Interface Connectors...............................................................................83
Table 6-2: Battery Connector (BAT1) Pinouts ...........................................................................84
Table 6-3: Chassis Intrusion Connector (CHASSIS1) Pinouts.................................................84
Table 6-4: Debug Connector (80PORT1) Pinouts......................................................................84
Table 6-5: EC Debug Connector (CN2) Pinouts.........................................................................85
Table 6-6: Digital I/O Connector (DIO1) Pinouts........................................................................85
Table 6-7: Inverter Connector (INV_CN1) Pinouts.....................................................................86
Table 6-8: LAN1 Link LED Connector (LED_LAN1) Pinouts ....................................................86
Table 6-9: LAN2 Link LED Connector (LED_LAN2) Pinouts ....................................................86
Table 6-10: LVDS Connector (LVDS1) Pinouts..........................................................................87
Table 6-11: M.2 M-key Slot (M2_AKEY1) Pinouts......................................................................89
Table 6-12: Microphone Connector (DMIC1) Pinouts ...............................................................89
Table 6-13: PCIe Mini Connector (MSATA1) Pinouts................................................................90
Table 6-14: Power LED Connector (PW_LED1) Pinouts...........................................................90
Table 6-15: SATA Connector (SATA1) Pinouts .........................................................................91
Table 6-16: Speaker Connector (SPEAKER1) Pinouts..............................................................91
Table 6-17: SPI Flash Connector (JSPI1) Pinouts.....................................................................91
Table 6-18: SPI Flash Connector, EC (JSPI2) Pinouts..............................................................92
Table 6-19: Touch Panel Connector (TOUCH1) Pinouts...........................................................92
Table 6-20: TTL Serial Connector, COM4 (NFC_CN1) Pinouts ................................................93
Table 6-21: USB 2.0 Connector (USB1~USB4) Pinouts............................................................93
Table 6-22: USB Power Connector (USB_PWR1) Pinouts........................................................93

AFL3-W19A-AL Panel PC
Page XIV
Table 6-23: Rear Panel Connectors............................................................................................94
Table 6-24: Ethernet Connectors (LAN2 & LAN3) Pinouts.......................................................94
Table 6-25: HDMI Connector (HDMI1) Pinouts...........................................................................95
Table 6-26: RS-232/422/485 DB-9 Serial Port (COM1) Pinouts.................................................95
Table 6-27: RS-232 RJ-45 Serial Port (COM2) Pinouts..............................................................95
Table 6-28: USB 3.0 Connectors (USB3-1) Pinouts...................................................................96
Table 6-29: Preconfigured Jumpers ...........................................................................................96
Table 6-30: Backlight Voltage Selection Jumper (J_BKPWR1) Settings................................97
Table 6-31: Flash Descriptor Security Override Jumper Settings...........................................97
Table 6-32: LVDS Voltage Selection Jumper (J_VLVDS1) Settings ........................................98
Table 6-33: LVDS Resolution Selection Jumper (SW1) Settings.............................................98

AFL3-W19A-AL Panel PC
Page XV
List of BIOS Menus
BIOS Menu 1: Main.......................................................................................................................46
BIOS Menu 2: Advanced..............................................................................................................47
BIOS Menu 3: ACPI Settings .......................................................................................................48
BIOS Menu 4: F81866 Super IO Configuration ..........................................................................49
BIOS Menu 5: Serial Port n Configuration .................................................................................49
BIOS Menu 6: iWDD H/W Monitor ...............................................................................................52
BIOS Menu 7: USB Configuration...............................................................................................53
BIOS Menu 8: CPU Configuration...............................................................................................54
BIOS Menu 9: RTC Wake Settings..............................................................................................56
BIOS Menu 10: Power Saving Configuration.............................................................................57
BIOS Menu 11: Serial Port Console Redirection.......................................................................58
BIOS Menu 12: Legacy Console Redirection Settings .............................................................59
BIOS Menu 13: IEI Feature...........................................................................................................60
BIOS Menu 14: Chipset................................................................................................................61
BIOS Menu 15: North Bridge Configuration ..............................................................................62
BIOS Menu 16: Intel IGD Configuration......................................................................................63
BIOS Menu 17: LCD Control........................................................................................................65
BIOS Menu 18: South Bridge Configuration..............................................................................66
BIOS Menu 19: HD-Audio Configuration....................................................................................67
BIOS Menu 20: PCI Express Configuration ...............................................................................68
BIOS Menu 21: M2_AKEY1...........................................................................................................69
BIOS Menu 22: MSATA1...............................................................................................................70
BIOS Menu 23: SATA Configuration...........................................................................................71
BIOS Menu 24: Security...............................................................................................................72
BIOS Menu 25: Boot.....................................................................................................................73
BIOS Menu 26: Save & Exit..........................................................................................................75

AFL3-W19A-AL Panel PC
Page 1
1 Introduction
Chapter
1

AFL3-W19A-AL Panel PC
Page 2
1.1 Overview
Figure 1-1: AFL3-W19A-AL Flat Bezel Panel PC
The AFL3-W19A-AL series is a quad-core Intel®Celeron®J3455 powered flat bezel
touchscreen panel PC with a rich variety of functions and peripherals. The flat-bezel
design is ideal for easy and simplified integration into various applications.
The Intel®Celeron®J3455 is a System-on-Chip (SoC) that ensures optimal memory,
graphics, and peripheral I/O support. The system comes with 4.0 GB of DDR3L SO-DIMM
memory ensuring smooth data throughputs with reduced bottlenecks and fast system
access.
One RS-232/422/485 serial port, one RS-232 serial port and four external USB ports
ensure simplified connectivity to a variety of external peripheral devices. Wi-Fi capabilities
and two RJ-45 Ethernet connectors provide the system with smooth connection to an
external LAN.

AFL3-W19A-AL Panel PC
Page 3
1.2 Features
The AFL3-W19A-AL features are listed below:
Flat-bezel LCD with LED backlight
Intel®Celeron®J3455 processor
Preinstalled with 4 GB of DDR3L memory (system max. 8 GB)
Projected capacitive type touchscreen with anti-UV and anti-glare coating
Wi-Fi 802.11a/b/g/n/ac high speed wireless
Two PCIe GbE RJ-45 connectors
Two internal speakers
Two USB 3.0 ports and two USB 2.0 ports
One RS-232/422/485 serial port and one RS-232 serial port by RJ-45
connectors
Optional RFID reader
Optional magnetic stripe card reader
12 V–34 V wide range DC power input
IP 64 compliant front panel

AFL3-W19A-AL Panel PC
Page 4
1.3 Front Panel
The front side of the AFL3-W19A-AL is a flat-bezel panel with a TFT LCD screen
surrounded by a PC/ABS plastic frame (Figure 1-2).
Figure 1-2: Front View
There is a power LED indicator located on the front panel. The status descriptions of the
power LED indicator are listed below.
Off: power cord not attached or power supply failure
Solid amber: the system is connected to a power source and is ready to be
turned on.
Solid green: the system is turned on.
