IEI Technology gKINO-R1000 Series User manual

gKINO-V/R1000 SBC
Page I
User Manual
Mini-ITX SBC supports AMD® Ryzen™ Embedded V1000/R1000
Series Onboard SoC, DDR4, Triple/Quadruple DP, Dual GbE, M.2,
SATA 6Gb/s, USB 3.2 Gen 1, COM, TPM 2.0, HD Audio and RoHS
Rev. 1.00 - September 1, 2020
MODEL:
gKINO-V/R1000
gKINO-V/R1000
MODEL:
gKINO-V/R1000 CPU Card

gKINO-V/R1000 SBC
Page II
Revision
Date Version Changes
September 1, 2020 1.00 Initial release

gKINO-V/R1000 SBC
Page III
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

gKINO-V/R1000 SBC
Page IV
Manual Conventions
WARNING
Warnings appear where overlooked details may cause damage to the
equipment or result in personal injury. Warnings should be taken
seriously.
CAUTION
Cautionary messages should be heeded to help reduce the chance of
losing data or damaging the product.
NOTE
These messages inform the reader of essential but non-critical
information. These messages should be read carefully as any directions
or instructions contained therein can help avoid making mistakes.

gKINO-V/R1000 SBC
Page V
Table of Contents
1 INTRODUCTION.......................................................................................................... 1
1.1 INTRODUCTION........................................................................................................... 2
1.2 MODEL VARIATIONS ................................................................................................... 3
1.3 FEATURES................................................................................................................... 3
1.4 CONNECTORS ............................................................................................................. 4
1.5 DIMENSIONS............................................................................................................... 5
1.6 DATA FLOW................................................................................................................ 7
1.7 TECHNICAL SPECIFICATIONS ...................................................................................... 8
2 UNPACKING................................................................................................................11
2.1ANTI-STATIC PRECAUTIONS...................................................................................... 12
2.2 UNPACKING PRECAUTIONS....................................................................................... 12
2.3 PACKING LIST........................................................................................................... 13
2.4 OPTIONAL ITEMS...................................................................................................... 14
3 CONNECTORS ........................................................................................................... 15
3.1 PERIPHERAL INTERFACE CONNECTORS..................................................................... 16
3.1.1 gKINO-V/R1000 Layout................................................................................... 16
3.1.2 Peripheral Interface Connectors ..................................................................... 17
3.1.3 External Interface Panel Connectors............................................................... 18
3.2 INTERNAL PERIPHERAL CONNECTORS...................................................................... 19
3.2.1 12 V DC-IN Power Connector......................................................................... 19
3.2.2 Audio Connector.............................................................................................. 20
3.2.3 Audio Amplifier Connectors............................................................................. 21
3.2.4 Battery Connector............................................................................................ 22
3.2.5 ccTalk Connectors............................................................................................ 23
3.2.6 Chassis Intrusion Connector............................................................................ 24
3.2.7 Digital I/O Connector...................................................................................... 25
3.2.8 EC Debug Connector....................................................................................... 26
3.2.9 Fan Connectors................................................................................................ 27
3.2.10 Front Panel Connector .................................................................................. 28

gKINO-V/R1000 SBC
Page VI
3.2.11 I2C Connector................................................................................................. 29
3.2.12 LAN LED Connectors.................................................................................... 30
3.2.13 M.2 Slot.......................................................................................................... 31
3.2.14 PCIe x16 Slot ................................................................................................. 33
3.2.15 RS-232 Serial Port Connectors (COM3 ~ COM6)........................................ 33
3.2.16 SATA 6Gb/s Drive Connector ........................................................................ 35
3.2.17 SATA Power Connector.................................................................................. 36
3.2.18 SMBus Connector .......................................................................................... 37
3.2.19 S/PDIF Connector ......................................................................................... 38
3.2.20 SPI Flash Connector, BIOS............................................................................ 39
3.2.21 SPI Flash Connector, EC............................................................................... 40
3.2.22 TPM Connector.............................................................................................. 41
3.2.23 USB 2.0 Connector ........................................................................................ 42
3.3 EXTERNAL PERIPHERAL INTERFACE CONNECTOR PANEL ......................................... 43
3.3.1 Audio Jacks...................................................................................................... 44
3.3.2 DisplayPort Connectors................................................................................... 45
3.3.3 LAN and USB 3.2 Gen 1 Combo Connector.................................................... 46
3.3.4 LAN and USB 2.0 Combo Connector .............................................................. 47
3.3.5 Power Connector............................................................................................. 48
3.3.6 Serial Port Connectors (COM1, COM2)......................................................... 49
4 INSTALLATION ......................................................................................................... 50
4.1ANTI-STATIC PRECAUTIONS...................................................................................... 51
4.2 INSTALLATION CONSIDERATIONS.............................................................................. 51
4.3 SO-DIMM INSTALLATION ....................................................................................... 53
4.4 M.2 MODULE INSTALLATION.................................................................................... 54
4.5 SYSTEM CONFIGURATION......................................................................................... 55
4.5.1 AT/ATX Mode Select ........................................................................................ 55
4.5.2 Clear CMOS..................................................................................................... 56
4.6 CHASSIS INSTALLATION............................................................................................ 57
4.6.1 Airflow.............................................................................................................. 57
4.6.2 Motherboard Installation................................................................................. 57
4.7 SATA DRIVE CONNECTION ...................................................................................... 57
4.8AVAILABLE DRIVERS ................................................................................................ 59
4.8.1 Driver Download ............................................................................................. 59

gKINO-V/R1000 SBC
Page VII
5 BIOS.............................................................................................................................. 61
5.1 INTRODUCTION......................................................................................................... 62
5.1.1 Starting Setup................................................................................................... 62
5.1.2 Using Setup...................................................................................................... 62
5.1.3 Getting Help..................................................................................................... 63
5.1.4 Unable to Reboot after Configuration Changes.............................................. 63
5.1.5 BIOS Menu Bar................................................................................................ 63
5.2 MAIN........................................................................................................................ 64
5.3ADVANCED............................................................................................................... 65
5.3.1 Trusted Computing........................................................................................... 66
5.3.2 ACPI Settings................................................................................................... 67
5.3.3 IDE Configuration........................................................................................... 68
5.3.4 F81866 Super IO Configuration...................................................................... 69
5.3.4.1 Serial Port n Configuration....................................................................... 70
5.3.5 F81216 Sec. Super IO Configuration............................................................... 71
5.3.5.1 Serial Port n Configuration....................................................................... 71
5.3.6 iWDD H/W Monitor......................................................................................... 72
5.3.6.1 Smart Fan Mode Configuration................................................................ 73
5.3.7 RTC Wake Settings........................................................................................... 76
5.3.8 Power Saving Configuration............................................................................ 77
5.3.9 CPU Configuration.......................................................................................... 78
5.3.9.1 Node 0 Information................................................................................... 79
5.3.10 USB Configuration......................................................................................... 80
5.3.11 NVMe Configuration...................................................................................... 81
5.3.12 AMD CBS....................................................................................................... 82
5.3.12.1 NBIO Common Options......................................................................... 82
5.3.12.1.1 GFX Configuration.......................................................................... 83
5.3.12.2 FCH Common Options........................................................................... 84
5.3.12.2.1 SATA Configuration Options........................................................... 85
5.3.13 AMD PBS....................................................................................................... 86
5.4 CHIPSET ................................................................................................................... 86
5.4.1 South Bridge..................................................................................................... 87
5.4.2 North Bridge .................................................................................................... 88
5.5 SECURITY................................................................................................................. 89

gKINO-V/R1000 SBC
Page VIII
5.6 BOOT........................................................................................................................ 90
5.7 SAVE &EXIT............................................................................................................ 92
A REGULATORY COMPLIANCE.............................................................................. 94
B PRODUCT DISPOSAL.............................................................................................. 96
C BIOS MENU OPTIONS............................................................................................. 98
D DIGITAL I/O INTERFACE..................................................................................... 101
E WATCHDOG TIMER............................................................................................... 104
F ERROR BEEP CODE............................................................................................... 107
F.1 PEI BEEP CODES .................................................................................................... 108
F.2 DXE BEEP CODES.................................................................................................. 108
G HAZARDOUS MATERIALS DISCLOSURE....................................................... 109
G.1 ROHS II DIRECTIVE (2015/863/EU) ......................................................................110
G.2 CHINA ROHS..........................................................................................................111

gKINO-V/R1000 SBC
Page IX
List of Figures
Figure 1-1: gKINO-V/R1000............................................................................................................2
Figure 1-2: Connectors ..................................................................................................................4
Figure 1-3: gKINO-V1000 Dimensions (mm)................................................................................5
Figure 1-4: gKINO-R1000 Dimensions (mm)................................................................................6
Figure 1-5: Data Flow Diagram......................................................................................................7
Figure 3-1: Connector and Jumper Locations...........................................................................16
Figure 3-2: DC-IN Power Connector Location ...........................................................................19
Figure 3-3: Audio Connector Location.......................................................................................20
Figure 3-4: Audio Amplifier Connector Locations....................................................................21
Figure 3-5: Battery Connector Location.....................................................................................22
Figure 3-6: ccTalk Connector Locations....................................................................................23
Figure 3-7: Chassis Intrusion Connector Location...................................................................24
Figure 3-8: Digital I/O Connector Location ................................................................................25
Figure 3-9: EC Debug Connector Location................................................................................26
Figure 3-10: Fan Connector Locations.......................................................................................27
Figure 3-11: Front Panel Connector Location ...........................................................................28
Figure 3-12: I2C Connector Location ..........................................................................................29
Figure 3-13: LAN LED Connector Locations .............................................................................30
Figure 3-14: M.2 Slot Location ....................................................................................................31
Figure 3-15: PCIe x16 Slot Location ...........................................................................................33
Figure 3-16: RS-232 Serial Port Connector Locations..............................................................34
Figure 3-17: SATA 6Gb/s Drive Connector Location ................................................................35
Figure 3-18: SATA Power Connector Location .........................................................................36
Figure 3-19: SMBus Connector Location...................................................................................37
Figure 3-20: S/PDIF Connector Location....................................................................................38
Figure 3-21: BIOS SPI Flash Connector Location.....................................................................39
Figure 3-22: EC SPI Flash Connector Location.........................................................................40
Figure 3-23: TPM Connector Location........................................................................................41
Figure 3-24: USB Connector Location........................................................................................42
Figure 3-25: External Peripheral Interface Connectors............................................................43
Figure 3-26: Audio Connector.....................................................................................................44

gKINO-V/R1000 SBC
Page X
Figure 3-27: DisplayPort Connector Pinout Locations.............................................................45
Figure 3-28: Ethernet Connector.................................................................................................46
Figure 3-29: Ethernet Connector.................................................................................................47
Figure 3-30: Power Connector ....................................................................................................48
Figure 3-31: Serial Port Pinouts..................................................................................................49
Figure 4-1: SO-DIMM Installation ................................................................................................53
Figure 4-2: Removing the M.2 Module Retention Screw ..........................................................54
Figure 4-3: Inserting the M.2 Module into the Slot at an Angle................................................54
Figure 4-4: Securing the M.2 Module..........................................................................................55
Figure 4-5: AT/ATX Mode Select Switch Location ....................................................................56
Figure 4-6: Clear CMOS Jumper Location .................................................................................56
Figure 4-7: SATA Drive Cable Connection.................................................................................58
Figure 4-8: IEI Resource Download Center................................................................................59

gKINO-V/R1000 SBC
Page XI
List of Tables
Table 1-1: Model Variations...........................................................................................................3
Table 1-2: Technical Specifications............................................................................................10
Table 3-1: Peripheral Interface Connectors...............................................................................18
Table 3-2: Rear Panel Connectors ..............................................................................................18
Table 3-3: DC-IN Power Connector Pinouts...............................................................................19
Table 3-4: Audio Connector Pinouts ..........................................................................................20
Table 3-5: Audio Amplifier Connector Pinouts (SPK_L1).........................................................21
Table 3-6: Audio Amplifier Connector Pinouts (SPK_R1)........................................................21
Table 3-7: Battery Connector Pinouts........................................................................................23
Table 3-8: ccTalk Connector Pinouts .........................................................................................23
Table 3-9: Chassis Intrusion Connector Pinouts......................................................................24
Table 3-10: Digital I/O Connector Pinouts..................................................................................25
Table 3-11: EC Debug Connector Pinouts .................................................................................26
Table 3-12: Fan Connector Pinouts............................................................................................27
Table 3-13: Front Panel Connector Pinouts...............................................................................28
Table 3-14: I2C Connector Pinouts..............................................................................................29
Table 3-15: LAN LED Connector Pinouts...................................................................................30
Table 3-16: M.2 M-Key Slot Pinouts............................................................................................32
Table 3-17: RS-232 Serial Port Connector Pinouts ...................................................................34
Table 3-18: SATA Drive Connector Pinouts...............................................................................35
Table 3-19: SATA Power Connector Pinouts.............................................................................36
Table 3-20: SMBus Connector Pinouts ......................................................................................37
Table 3-21: S/PDIF Connector Pinouts.......................................................................................38
Table 3-22: BIOS SPI Flash Connector Pinouts ........................................................................39
Table 3-23: EC SPI Flash Connector Pinouts ............................................................................40
Table 3-24: TPM Connector Pinouts...........................................................................................41
Table 3-25: USB Connector Pinouts...........................................................................................42
Table 3-26: DisplayPort Connector Pinouts ..............................................................................45
Table 3-27: LAN1 Ethernet Connector Pinouts .........................................................................46
Table 3-28: Connector LEDs........................................................................................................46
Table 3-29: USB 3.2 Gen 1 Port Pinouts.....................................................................................47

gKINO-V/R1000 SBC
Page XII
Table 3-30: LAN1 Ethernet Connector Pinouts .........................................................................47
Table 3-31: Connector LEDs........................................................................................................48
Table 3-32: USB 2.0 Port Pinouts................................................................................................48
Table 3-33: Serial Port Pinouts....................................................................................................49
Table 4-1: AT/ATX Mode Select Switch Settings.......................................................................55
Table 4-2: Clear BIOS Jumper Settings......................................................................................56
Table 5-1: BIOS Navigation Keys................................................................................................63

gKINO-V/R1000 SBC
Page XIII
List of BIOS Menus
BIOS Menu 1: Main.......................................................................................................................64
BIOS Menu 2: Advanced..............................................................................................................65
BIOS Menu 3: Trusted Computing..............................................................................................66
BIOS Menu 4: ACPI Settings .......................................................................................................67
BIOS Menu 5: IDE Configuration.................................................................................................68
BIOS Menu 6: F81866 Super IO Configuration ..........................................................................69
BIOS Menu 7: Serial Port n Configuration .................................................................................70
BIOS Menu 8: F81216 SEC Super IO Configuration..................................................................71
BIOS Menu 9: Serial Port n Configuration .................................................................................71
BIOS Menu 10: iWDD H/W Monitor .............................................................................................72
BIOS Menu 11: Smart Fan Mode Configuration ........................................................................73
BIOS Menu 12: RTC Wake Settings ............................................................................................76
BIOS Menu 13: Power Saving Configuration.............................................................................77
BIOS Menu 14: CPU Configuration.............................................................................................78
BIOS Menu 15: Node 0 Information ............................................................................................79
BIOS Menu 16: USB Configuration.............................................................................................80
BIOS Menu 17: NVMe Configuration...........................................................................................81
BIOS Menu 18: AMB CBS ............................................................................................................82
BIOS Menu 19: NBIO Common Options.....................................................................................82
BIOS Menu 20: GFX Configuration.............................................................................................83
BIOS Menu 21: FCH Common Options.......................................................................................84
BIOS Menu 22: SATA Configuration Options ............................................................................85
BIOS Menu 23: AMB CBS ............................................................................................................86
BIOS Menu 24: Chipset................................................................................................................87
BIOS Menu 25: South Bridge.......................................................................................................87
BIOS Menu 26: North Bridge .......................................................................................................88
BIOS Menu 27: Security...............................................................................................................89
BIOS Menu 28: Boot.....................................................................................................................90
BIOS Menu 29: Save & Exit..........................................................................................................92

gKINO-V/R1000 SBC
Page 1
Chapter
1
1 Introduction

gKINO-V/R1000 SBC
Page 2
1.1 Introduction
Figure 1-1: gKINO-V/R1000
The gKINO-V/R1000 series is a Mini-ITX form factor single bard computer. It has an
on-board AMD®Ryzen™ Embedded V1000/R1000 series processor, and supports two
260-pin 2400 MHz dual-channel ECC DDR4 SO-DIMM slots with up to 64.0 GB of
memory.
The gKINO-V/R1000 series supports up to four external DisplayPort connectors for
quadruple 4K independent display. Expansion and I/O include one PCIe x16 slot (x8
mode) and one M.2 M-key slot for expansion; two USB 3.2 Gen 1 (5Gb/s) ports and two
USB 2.0 ports on the rear panel, two USB 2.0 connectors by pin header and one SATA
6Gb/s connector. Serial device connectivity is provided by two external RS-232
connectors, four internal RS-232 connectors and two ccTalk connectors. Two RJ-45 GbE
connectors provide the system with smooth connections to an external LAN.

gKINO-V/R1000 SBC
Page 3
1.2 Model Variations
The model variations of the gKINO-V/R1000 series are listed below.
Model No. SoC DisplayPort #
gKINO-V1605B AMD® Ryzen™ Embedded V1605B 4
gKINO-V1202B AMD® Ryzen™ Embedded V1202B 4
gKINO-R1606G AMD® Ryzen™ Embedded R1606G 3
gKINO-R1505G AMD® Ryzen™ Embedded R1505G 3
Table 1-1: Model Variations
1.3 Features
Some of the gKINO-V/R1000 motherboard features are listed below:
Mini-ITX motherboard supports AMD®Ryzen™ Embedded V1000/R1000
series on-board SoC
Quadruple/Triple independent display via DisplayPort
Two 2400 MHz DDR4 SO-DIMM slots support up to 64 GB of memory
One SATA 6Gb/s connector with 5 V and 12 V power output
M.2 2242/2280 M-key modules (SATAor PCIe) supported
One PCIe x16 (x8 mode) slot for expansions
Two external USB 3.2 Gen 1 (5Gb/s) connectors
Multiple RS-232 ports with ccTalk TTL support
Chassis intrusion detect pin and ECC support in gaming applications
TPM 2.0 hardware security function supported by TPM module

gKINO-V/R1000 SBC
Page 4
1.4 Connectors
The connectors on the gKINO-V/R1000 are shown in the figures below.
Figure 1-2: Connectors

gKINO-V/R1000 SBC
Page 5
1.5 Dimensions
The dimensions of the two models are listed below:
Figure 1-3: gKINO-V1000 Dimensions (mm)

gKINO-V/R1000 SBC
Page 6
Figure 1-4: gKINO-R1000 Dimensions (mm)
