IEI Technology ROCKY-558EV User manual

ROCKY-558EV
Pentium® ,VGA & 10/100Mbps
Ethernet SBC
@Copyright 1998
All Rights Reserved.
Manual first edition May 20,1998
The information in this document is subject to change without prior notice in
order to improve reliability, design and function and does not represent a
commitment on the part of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special,
incidental, or consequential damages arising out of the use or inability to use
the product or documentation, even if advised of the possibility of such
damages.
This document contains proprietary information protected by copyright. All
rights are reserved. No part of this manual may be reproduced by any
mechanical, electronic, or other means in any form without prior written
permission of the manufacturer.
Trademarks
ROCKY-558EV is registered trademarks of Acquire Inc.,IBM PC is a
registered trademark of International Business Machines Corporation. Intel is
a registered trademark of Intel Corporation. AMI is registered trademarks of
American Megatrends, Inc. Other product names mentioned herein are used
for identification purposes only and may be trademarks and/or registered
trademarks of their respective companies.

1
Contents
1. Introduction ..........................................................3
1.1 Specifications..............................................................................4
1.2 What You Have...........................................................................5
2. Installation............................................................6
2.1 ROCKY-558EV's Layout .............................................................6
2.2 Setting the CPU of ROCKY-58EV............................................... 8
2.3 Watch-Dog Timer......................................................................10
2.4 DiskOnChip™Flash Disk ............................................................11
2.5 BIOS Flash Type Setting............................................................12
3. Connection.........................................................13
3.1 Floppy Disk Drive Connector......................................................13
3.2 PCI E-IDE Disk Drive Connector................................................14
3.3 Parallel Port...............................................................................15
3.4 Serial Ports................................................................................15
3.5 Keyboard/Mouse Connector.......................................................16
3.6 External Switches and Indicators...............................................16
3.7 USB Port Connector ..................................................................17
3.8 IrDA Infrared Interface Port ……….………………………………17

2
3.9 VGA Connector ………………………………………………………….18
3.10 Lan RJ45 Connector …………………………………….18
3.11 CPU Fan Connector …………………………………….19
3.12 External Battery Connector ……………………………….19
4. AMI BIOS Setup.................................................20
4.1 Getting Start..............................................................................20
4.2 Standard CMOS Setup ..............................................................21
4.3 Advanced CMOS Setup.............................................................22
4.4 Advanced Chipset Setup............................................................23
4.5 Peripheral Setup .......................................................................24
4.6 Power Management Setup.........................................................25
4.7 PCI / Plug and Play Setup..........................................................26
5. E2Key Function..................................................27
Appendix A. Watch-Dog Timer..............................29

3
1
Introduction
Welcome to the ROCKY-558EV Pentium® w/ VGA &
10/100MBps Ethernet Single Board Computer. The ROCKY-
558EV board is an PICMG bus form factor board, which
equipped with high performance Pentium® CPU and advanced
high performance VGA and Ethernet, designed for the system
manufacturers, integrators, or VARs that want to provide all the
performance, reliability, and quality at a reasonable price.
This board built-in DiskOnChip™(DOC) Flash Disk for embedded
application. The DOC Flash Disk is 100% compatible to hard
disk. User can use any DOS command without any extra
software utility. The DOC currently is available from 2MB to
72MB.
An advanced high performance VGA chip –Winbond W9970CF
is used in the ROCKY-558EV board. The W9970CF integrated
Video Graphics Accelerator in a single chip.
In addition, the ROCKY-558EV provides two 168-pin DIMM
sockets for its on-board DRAM. DIMM module is 3.3V
SDRAM.and max. 128MB for one module.
The board’s RTL8139 network chipset provides 10MBps or
100MBps Ethernet with auto-sensing function.
ROCKY-558EV uses the advanced ALI Chipset Aladdin 4+
which is 100% ISA/PCI compatible chipset with PCI 2.1 standard.
1.1 Specifications :

4
The ROCKY-558EV Pentium® w/ VGA & 10/100MBps Ethernet
Single Board Computer provides the following specification:
•CPU : Pentium® MMX up to 233Mhz, AMD K6 up to 300MHz
processor,Cyrix 6x86MX,IDT C6 processor
•Bus : PICMG bus, meet PCI 2.1 standard
•DMA channels : 7
•Interrupt levels : 15
•Chipset : ALI Aladdin 4+
•VGA : Winbond W9970CF
Resolution : 1024x768,256 color
More information : www.winbond.com.tw
•Ethernet : Built-in the RTL8139 Chipset
IEEE 802.3u 100BASE-TX standard
Auto-sensing interface to 10MBps or 100MBps networks
Full duplex capability
More information : www.realtek.com.tw
•Real-time clock / calendar : backup by industrial Li Battery. .
•RAM memory : up to 256MB SDRAM
•Second Cache memory : 512KB Pipelined Burst SRAM on board
•Ultra DMA/33 IDE Interface : up to two PCI Enhance IDE hard
drives. The Ultra DMA/33 IDE can handle data transfer up to
33MB/s. The best of all is that is new technology is compatible with
existing ATA-2 IDE specifications. So there is no need to do any
change for customer’s current accessory.
•Floppy disk drive interface : two 2.88 MB, 1.44MB, 1.2MB, 720KB,
or 360KB floppy disk drives.
•Two high speed Series ports : NS16C550 compatible UARTs
• Standard/EPP/ECP Parallel Port

5
•IrDA port : Support Serial Infrared(SIR) and Amplitude Shift
Keyed IR(ASKIR) interface.
•USB port : Support USB port for future expansion.
•Watch-dog timer : can be set by 1,2,10,20,110 or 220 seconds
period. Reset or NMI was generated when CPU did not periodically
trigger the timer.
•Flash Disk - DiskOnChip™: The Flash Disk provides 100%
compatible with hard disk.
•Keyboard connector
•Mouse : PS/2 Mouse Port on-board.
•Power Consumption : +5V @ 5.5A
( Pentium® MMX-200,32MB SDRAM)
+12V @ 160mA , -12V@60mA
•Operating Temperature : 0°~ 55°C ( CPU needs Cooler)
1.2 What You Have
In addition to this User's Manual, the ROCKY-558EV package
includes the following items:
•ROCKY-558EV Pentium® w/ VGA &10/100MBps Ethernet
SBC
•RS-232/Printer Cable
•FDD/HDD Cable
•6-pin Mini-Din to Keyboard and Mouse Adapter Cable
If any of these items is missing or damaged, contact the dealer
from whom you purchased the product. Save the shipping
materials and carton in case you want to ship or store the
product in the future.

6
2
Installation
This chapter describes how to install the ROCKY-558EV. At first,
the layout of ROCKY-558EV is shown, and the unpacking
information that you should be careful is described. The
jumpers and switches setting for the ROCKY-558EV's
configuration, such as CPU type selection, system clock setting,
and watch dog timer, are also included.
2.1 ROCKY-558EV's Layout
< reference next page >

7

8
2.2 Setting the CPU of ROCKY-558EV
•CPU Clock Setting :
CPU Speed/Clock JP3
7-8 JP3 9-10 JP3 11-12
55MHz CLOSE CLOSE OPEN
60MHz CLOSE OPEN OPEN
66MHz OPEN OPEN OPEN
75MHz OPEN CLOSE CLOSE
83MHz CLOSE OPEN CLOSE
•CPU to Bus Multiple :
Multiplier JP3
1-2 JP3 3-4 JP3 5-6
1.5 x OPEN OPEN OPEN
2 x CLOSE OPEN OPEN
2.5 x CLOSE CLOSE OPEN
3 x OPEN CLOSE OPEN
3.5 x OPEN OPEN OPEN
4 x CLOSE OPEN CLOSE
4.5 x CLOSE CLOSE CLOSE
CPU Frequency = CPU Clock x Multiplier for example
Pentium® 200MHz = 66MHz CPU Clock x 3
•CPU Core Voltage Selection :
Please check the CPU Core Voltage before you install the
CPU. Right now new Intel MMX CPU is dual voltages for
core and I/O,the I/O is 3.3V but the core is 2.8V. This kind
of CPU design will enhance the low power consumption
capability. As for the general Pentium® CPU is one voltage for
I/O and Core - 3.3V,3.4V,or 3.5V
•JP4 CPU Core Voltage Setting :

9
CPU Core
Voltage JP4 1-2 JP4 3-4 JP4 5-6 JP4 7-8
3.5V(P54C/CS)
VRE CLOSE CLOSE CLOSE CLOSE
3.4V(P54C/CS)
STD OPEN CLOSE CLOSE CLOSE
3.3V CLOSE OPEN CLOSE CLOSE
3.2V OPEN OPEN CLOSE CLOSE
3.1V CLOSE CLOSE OPEN CLOSE
3.0V OPEN CLOSE OPEN CLOSE
2.9V CLOSE OPEN OPEN CLOSE
2.8V (P55C) OPEN OPEN OPEN CLOSE
2.7V CLOSE CLOSE CLOSE OPEN
2.6V OPEN CLOSE CLOSE OPEN
2.5V CLOSE OPEN CLOSE OPEN
2.4V OPEN OPEN CLOSE OPEN
2.3V CLOSE CLOSE OPEN OPEN
2.2V OPEN CLOSE OPEN OPEN
2.1V CLOSE OPEN OPEN OPEN
2.0V OPEN OPEN OPEN OPEN
•
JP1/JP2 Dual / Single CPU Voltage setting :
Vcore & VIO JP1
1-2 JP1 3-4 JP2 1-2 JP2 3-4
Pentium
(P54C)
IDT C6
OPEN OPEN CLOSE CLOSE
Pentium MMX
AMD K6
Cyrix 6x86MX
Dual Voltage
CLOSE CLOSE OPEN OPEN
•
Cyrix 6x86MX PR Rating Table

10
(Vcore : 2.9V ,dual voltage)
PR Rating Bus MHz CPU Core
MHz Clock Multiplier
6x86MX-PR150 60 120 2x
6x86MX-PR166 66 133 2x
6x86MX-PR166 60 150 2.5x
6x86MX-PR200 75 150 2x
6x86MX-PR200 66 166 2.5x
6x86MX-PR200 60 180 3x
6x86MX-PR233 75 188 2.5x
6x86MX-PR233 66 200 3x
6x86MX-PR233 83 166 2x
6x86MX-PR266 66 233 3.5x
6x86MX-PR266 75 225 3x
6x86MX-PR266 83 208 2.5x
•
AMD K6 MMX Rating Table(Dual Voltage)
Product Name Core Freq Vcore Bus MHz Multiplier
K6-233 model 6 233MHz 3.2V 66 3.5x
K6-200 model 6 200MHz 2.9V 66 3x
K6-166 model 6 166MHz 2.9V 66 2.5x
K6-300 model 7 300MHz 2.2V 66 4.5x
K6-266 model 7 266MHz 2.2V 66 4x
K6-233 model 7 233MHz 2.2V 66 3.5x
2.3 Watch-Dog Timer
The Watch-Dog Timer is enabled by reading port 443H. It should
be triggered before the time-out period ends, otherwise it will
assume the program operation is abnormal and will issue a reset
signal to start again, or activate NMI to CPU. The Watch-Dog
Timer is disable by reading port 043H.
•JP7 : Watch-Dog Active Type Setting
JP7 DESCRIPTION

11
2-3 RESET WHEN WDT TIME-OUT
1-2 ACTIVATE NMI TO CPU WHEN WDT TIME-
OUT
OPEN DISABLE WDT
•JP8: WDT Time-Out Period
PERIOD 1-2 3-4 5-6 7-8
1 sec. OPEN OPEN CLOSE OPEN
2 sec. OPEN OPEN CLOSE CLOSE
10 sec. OPEN CLOSE OPEN OPEN
20 sec. OPEN CLOSE OPEN CLOSE
110 sec. CLOSE OPEN OPEN OPEN
220 sec. CLOSE OPEN OPEN CLOSE
2.4 DiskOnChip™Flash Disk
The DiskOnChip™Flash Disk Chip(DOC) is produced by M-
Systems. Because the DOC is 100% compatible to hard disk and
DOC.Customer don‘t need any extra software utility. It is just
“plug
and play”,easy and reliable. Right now the DOC is available from
2MB to 72MB.The MD-2200-xMB series DOC will share only
8KB memory address.
•JP9 : DiskOnChip Memory Address Setting
JP9 Address
1-2 CE000 –CFFFF
3-4 D6000 –D7FFF
5-6 DE000 –DFFFF

12
2.5 BIOS Flash Type Setting
There have 12V or 5V programming Flash and 1MB or 2MB flash
BIOS possible to be used in the board. And each type flash need
a
specified jumper setting.
•JP6: BIOS Flash Type Setting
This jumper is by factory setting
JP6 DESCRIPTION
1-3
2-4 12V programming
1MB
3-5
2-4 5V programming
1MB
1-3
4-6 12V programming
2MB
3-5
4-6 5V programming
2MB

13
3
Connection
This chapter describes how to connect peripherals, switches and
indicators to the ROCKY-558EV board.
3.1 Floppy Disk Drive Connector
ROCKY-558EV board equipped with a 34-pin daisy-chain driver
connector cable.
•J7 : FDC CONNECTOR
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1GROUND 2REDUCE WRITE
3GROUND 4N/C
5GROUND 6N/C
7GROUND 8INDEX#
9GROUND 10 MOTOR ENABLE A#
11 GROUND 12 DRIVE SELECT B#
13 GROUND 14 DRIVE SELECT A#
15 GROUND 16 MOTOR ENABLE B#
17 GROUND 18 DIRECTION#
19 GROUND 20 STEP#
21 GROUND 22 WRITE DATA#
23 GROUND 24 WRITE GATE#
25 GROUND 26 TRACK 0#
27 GROUND 28 WRITE PROTECT#
29 GROUND 30 READ DATA#
31 GROUND 32 SIDE 1 SELECT#
33 GROUND 34 DISK CHANGE#

14
3.2 PCI E-IDE Disk Drive Connector
You can attach four IDE( Integrated Device Electronics) hard
disk drives to the ROCKY-558EV IDE controller.
Please note the IDE support Ultra DMA/33 high performance
interface.
•J5 : Primary IDE Interface Connector
J6 : Secondary IDE Interface Connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1RESET# 2GROUND
3DATA 7 4DATA 8
5DATA 6 6DATA 9
7DATA 5 8DATA 10
9DATA 4 10 DATA 11
11 DATA 3 12 DATA 12
13 DATA 2 14 DATA 13
15 DATA 1 16 DATA 14
17 DATA 0 18 DATA 15
19 GROUND 20 N/C
21 IDE DRQ 22 GROUND
23 IOW# 24 GROUND
25 IOR# 26 GROUND
27 IDE CHRDY 28 GROUND
29 IDE DACK 30 GROUND - DEFAULT
31 INTERRUPT 32 NC
33 SA1 34 N/C
35 SA0 36 SA2
37 HDC CS0# 38 HDC CS1#
39 HDD ACTIVE# 40 GROUND

15
3.3 Parallel Port
This port is usually connected to a printer, The ROCKY-558EV includes
an on-board parallel port, accessed through a 26-pin flat-cable connector
J9.
•J9 : Parallel Port Connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1STROBE# 2DATA 0
3DATA 1 4DATA 2
5DATA 3 6DATA 4
7DATA 5 8DATA 6
9DATA 7 10 ACKNOWLEDGE
11 BUSY 12 PAPER EMPTY
13 PRINTER SELECT 14 AUTO FORM FEED #
15 ERROR# 16 INITIALIZE
17 PRINTER SELECT LN# 18 GROUND
19 GROUND 20 GROUND
21 GROUND 22 GROUND
23 GROUND 24 GROUND
25 GROUND 26 N/C
3.4 Serial Ports
The ROCKY-558EV offers two high speed NS16C550 compatible
UARTs with Read/Receive 16 byte FIFO serial ports.
•J15 : Serial Port DB-9 Connector( COMA )
PIN NO. DESCRIPTION
1DATA CARRIER DETECT (DCD)
2RECEIVE DATA (RXD)
3TRANSMIT DATA (TXD)
4DATA TERMINAL READY (DTR)
5GROUND (GND)
6DATA SET READY (DSR)
7REQUEST TO SEND (RTS)
8CLEAR TO SEND (CTS)
9RING INDICATOR (RI)
•J13 : Serial Port 10-pin Header( COMB)

16
Pin No. Description Pin No. Description
1 DCD 6. DSR
2 RXD 7 RTS
3 TXD 8 CTS
4 DTR 9 RI
5 GND 10 NC
3.5 Keyboard/Mouse Connector
The ROCKY-558EV provides keyboard and mouse connectors
on the bracket and board each.
•J1 : 5-pin Header Keyboard Connector
PIN NO. DESCRIPTION
1KEYBOARD CLOCK
2KEYBOARD DATA
3N/C
4GROUND
5+5V
•J14 : 5-pin Header Mouse Connector
PIN NO. DESCRIPTION
1MOUSE DATA
2N/C
3GROUND
4+5V
5MOUSE CLOCK
•J16 : 6-pin Mini-DIN Keyboard / Mouse Connector
PIN NO. DESCRIPTION
1KEYBOARD DATA
2MOUSE DATA
3GROUND
4+5V
5KEYBOARD CLOCK
6MOUSE CLOCK
3.6 External Switches and Indicators

17
There are many external switches and indicators for monitoring
and controlling your CPU board.
•
J2 : General Connectors
2 5V 1. Speaker Signal
4. NC 3. NC
6 GND 5 NC
8. KEYLOCK 7. 5V
10. GND 9. RESET
12. GND 11. GND
14. NC 13. HDD LED
16. Suspend Control 15. 5V
18. 5V Standby 17. Switch Control Signal
20. 5V Standby 19. GND
3.7 USB Port Connector
The ROCKY-558EV built-in dual USB ports for the future new
I/O bus expansion.
•
J8 : USB Connector
1 5V 2. GND
3. -DATA1 4. +DATA0
5. +DATA1 6. -DATA0
7. GND 8. 5V
3.8 IrDA Infrared Interface Port
The ROCKY-558EV built-in a IrDA port which support Serial
Infrared(SIR) or Amplitude Shift Keyed IR(ASKIR) interface.
When use the IrDA port have to set SIR or ASKIR model in the
BIOS’s Peripheral Setup’s COM2. Then the normal RS-232
COM2 will be disabled.
•JP10 : IrDA connector
PIN NO. DESCRIPTION

18
1VCC
2NC
3IR-RX
4Ground
5IR-TX
3.9 VGA Connector
The ROCKY-558EV built-in 15-pin VGA connector directly to
your CRT monitor.
•J11 : 15-pin Female Connector
1RED 2GREEN
3BLUE 4NC
5GROUND 6GROUND
7GROUND 8GROUND
9NC 10 GROUND
11 NC 12 DDC DAT
13 HSYNC 14 VSYNC
15 DDCCLK
3.10 Lan RJ45 Connector
The ROCKY-558EV built-in a RJ45 Lan connector..
•J12 : Lan RJ45 Connector
1TX+ 5. NC
2TX- 6. RX-
3. RX+ 7. NC
4. NC 8. NC
•CN1 LED Connector(2-pin header) for Lan
1. 5V
2. 10Mbps
3. 5V
4. 100Mbps
5. 5V
6. Active
3.11 CPU Fan Connector
The ROCKY-558EV provides a connector for CPU cooling fan.
.
