IEI Technology PCIE-Q370 User manual

Full-size PICMG 1.3 CPU Card supports LGA1151 Intel® Core™
i7/i5/i3/ Pentium®/Celeron® CPU per Intel® Q370, DDR4, VGA,
DP, Dual Intel® PCIe GbE, SATA 6Gb/s, USB 3.1 Gen 1 (5Gb/s), M.2,
HD Audio, Intel® AMT and RoHS
PCIE-Q370
Quick Installation Guide
Version 1.1
June 10, 2019.
Package List
PCIE-Q370 package includes the following items:
1 x PCIE-Q370 single board computer
1 x SATA cable
1 x Mini jumper pack
1 x QIG (Quick Installation Guide)
©2019 Copyright by IEI Integration corp.
All rights reserved.

1
Specifications
CPU:
LGA1151 socket supports 8th generation Intel® Core® i7/i5/i3,
Pentium® or Celeron® processor
Chipset:Intel® Q370
Memory:
Four 288-pin 2666MHz dual-channel DDR4 SDRAM
unbuffered DIMMs support up to 64GB
BIOS: AMI UEFI BIOS
Graphic Engine:
Intel® HD Graphics Gen 9 Engines with Low power 16
execution unit, supports DX2015, OpenGL 5.X and
OpenCL2.x, ES 2.0
Display Output:
Dual display supported
1 x VGA (up to 1920x1200@60 Hz)
1 x Internal DisplayPort (up to 4096 x 2304@60Hz)
Ethernet:
LAN1: Intel® I219LM PHY
LAN2: Intel® I211-AT PCIe controller (Co-lay I210-AT)
External I/O Interface:
2 x USB 3.1 Gen 1 (5Gb/s) (Rear IO type A)
1 x USB 2.0 (Type A 180°)
Internal I/O Interface:
1 x KB/MS (1x6 pin)
1 x RS-422/485 (1x4 pin, P=2.0)
2 x USB 3.1 Gen 1 (5Gb/s) (2x10 pin)
3 x RS-232 (2x5 pin, P=2.54)
6 x SATA 6Gb/s (RAID 0/1/5/10 supported)
6 x USB 2.0 (2x4 pin, P=2.54)
Audio:
Support 7.1 channel HD audio by IEI AC-KIT-892HD kit

2
Front Panel: 1 x Front Panel (Power LED, HDD LED, Speaker,
Power Button, Reset Button)
LAN LED: 2 x LAN LED (1x2 pin)
TPM: 1 x TPM (2x10 pin)
SMBus: 1 x SMBus (1x4 pin)
I²C:1 x I²C (1x4 pin)
Expansion:
1 x M.2 M key
1 x PCIe x16 & 4 x PCIe x1 signal via golden finger
4 x PCI signal via golden finger
Watchdog Timer:
Software programmable support 1~255 sec. system reset
Digital I/O: 8-bit digital I/O (2x5 pin)
FAN Connector:
1 x CPU smart fan (1x4 pin)
1 x System smart fan (1x3 pin)
Power supply:
AT/ATX power supply
Support AT/ATX mode
ErP/EuP Compliant
Power Consumption:
[email protected], 1[email protected], 3.3[email protected], 5VS[email protected]
(4.0 GHz Intel® Core™ i7-8700K CPU with four 16 GB 2666
MHz DDR4 memory)
Operation Temperature: -20°C ~ 60°C
Operation Humidity: 5% ~ 95%, non-condensing
Dimensions: 338 mm x 126 mm
Weight GW/NW: 1000g / 500g
CE/FCC compliant

3
Ordering Information
PCIE-Q370-R11:
Full-size PICMG 1.3 CPU Card supports LGA1151 Intel® Core™
i7/i5/i3/Pentium®/Celeron® CPU per Intel® Q370, DDR4, Dual
Intel® PCIe GbE, USB 3.1 Gen 1 (5Gb/s), SATA 6Gb/s, VGA,
DP, M.2, HD Audio, iAMT and RoHS
PCIE-Q370-HDMI-R11**:
Full-size PICMG 1.3 CPU Card supports LGA1151 Intel® Core™
i7/i5/i3/Pentium®/Celeron® CPU per Intel® Q370, DDR4, HDMI,
DP, Dual Intel® PCIe GbE, USB 3.1, SATA 6Gb/s, M.2, HD Audio,
iAMT and RoHS
**By order production, MOQ: 100
19800-000075-RS: PS/2 KB/MS cable with bracket, 220mm, P=2.0
32102-000100-200-RS: SATA power cable, MOLEX 5264-4P to
SATA15P
AC-KIT-892HD-R10:
7.1 channel HD Audio kit with Realtek ALC892 support dual
audio streams
CF-1150SA-R10: Special cooler kit for LGA1150, High-performance
compatible, 95W
CF-1150SB-R11: Special cooler kit for LGA1150, High-performance
All the drivers and One Key Recovery
utility for the PCIE-Q370 are available on
IEI Resource Download Center. Type
PCIE-Q370 and press Enter to find all
the relevant software, utilities, and
documentation. To install software from
the downloaded ISO file, mount the file
as a virtual drive to view its content.
IEI Resource Download Center
https://download.ieiworld.com

4
compatible, 65W
CF-1150SC-R20:
Special cooler kit for LGA1150, 1U chassis compatible, 65W
CF-1150SE-R11:
Special cooler kit for LGA1150, 1U chassis compatible, 95W
CF-1150SF-R10:
Special cooler kit for LGA1150, 1U chassis compatible, 54W
SAIDE-KIT01-R10:
SATA to IDE/CF Converter board

5
Jumpers setting and connectors
LABEL
FUNCTION
J_ATX_AT1
AT/ATX Power Mode Setting
J_CMOS2
Clear CMOS Button
PCIE x16 Power
PCIEX16 Channel Mode Setting
USB SW1 Power
USB SW2 Power
USB Power Setting
J_FLASH1
Flash Descriptor Security Override
F_PANEL1
Front Panel Connector
KB_MS1
6-pin header Keyboard/Mouse Connector
DIO1
Digital Input / Output Connector
CPU12V1
+12V power connector
CPU_FAN1
CPU Fan Connector
SYS_FAN1
System Fan Connector
J_AUDIO1
Audio Source Connector
VGA1
VGA Connector
HDMI1
HDMI Connector
DP1
Internal DisplayPort Connector
TPM1
TPM Connector
I2C1
I2C Connector
SMB1
SMBUS Connector
CN1
EC Debug Connector
MPCIE1
M-SATA Card Connector
USB3_1,USB3_2
External USB 3.0 Connectors
USB3_34
Internal USB 3.0 Connector
SATA1, SATA2, SATA3
SATA4, SATA5, SATA6
SATA 6Gb/s Drive Connectors
COM1, COM2, COM3
Internal RS-232 Serial Port Connectors
COM4
Internal RS-422/485 Serial Port Connectors
USB1, USB2, USB4
Internal USB 2.0 Connectors
USB3
External USB 2.0 Connector
LAN1, LAN2
RJ45 LAN Connectors
JSPI1
Flash SPI ROM Connector
JSPI2
Flash EC ROM Connector

6
LED_LAN1
LAN1 link LED Connector
LED_LAN2
LAN2 link LED Connector
CHASSIS1
Chassis Status Connector
PCIE x16 Power: PCIEX16 Channel Mode Setting
PCIE x16
DESCRIPTION
1 x16 PCIE
1 x16 PCIE (default)
2 x8 PCIE
2 x8 PCIE
1 x8 , 2x4 PCIE
1 x8 , 2x4 PCIE
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Chipset
Auto Power Button Status [Disabled(ATX)]
Restore AC Power Loss [Last State]
> PCI Express Configuration
> PCI Azalia Configuration
Power Saving Function(ERP) [Disabled]
PCIEX16 Power [1 x16 PCIE]
USB SW1 [+5V DUAL]
USB SW2 [+5V DUAL]
------------------
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
J_CMOS2: Clear CMOS Button
PIN NO.
DESCRIPTION
NC (default)
Keep CMOS Setup
(Normal Operation)
Press button
Clear CMOS Setup
J_ATX_AT1: AT/ATX Power Mode Setting
PIN NO.
DESCRIPTION
Short 1 - 2
ATX Mode (default)
Short 2 - 3
AT Mode

7
F_PANEL1: Front Panel Connector
PIN
DESCRIPTION
PIN
DESCRIPTION
PWR
LED
1
+5V
2
BEEP_PWR
SPKR
3
NC
4
IPMI ID_LED+
IPMI LED
5
GND
6
IPMI ID_LED-
PWR
BTN
7
PWRBTN_SW#
8
PC_BEEP
SPKR
9
GND
10
NC
RESET
HDD
LED
11
+5V
12
EXTRST-
13
SATA_LED#
14
GND
USB SW1, USB SW2: USB Power Setting
PCIE x16
DESCRIPTION
+5V DUAL
5V DUAL (default)
+5V
+5V
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc.
Chipset
Auto Power Button Status [Disabled(ATX)]
Restore AC Power Loss [Last State]
> PCI Express Configuration
> PCI Azalia Configuration
Power Saving Function(ERP) [Disabled]
PCIEX16 Power [1 x16 PCIE]
USB SW1 [+5V DUAL]
USB SW2 [+5V DUAL]
------------------
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
J_FLASH1: Flash Descriptor Security Override
PIN NO.
DESCRIPTION
Short 1 - 2
Disabled (default)
Short 2 - 3
Enabled

8
SYS_FAN1: System Fan Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
FANIO
2
+12V (PWM)
3
GND
CPU_FAN1: CPU Fan Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
GND
2
+12V
3
FANIO
4
PWM
CPU12V1: +12V Power Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
GND
2
GND
3
+12V
4
+12V
DIO1: Digital Input / Output Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
GND
2
VCC
3
Output 3
4
Output 2
5
Output 1
6
Output 0
7
Input 3
8
Input 2
9
Input 1
10
Input 0
KB_MS1: 6-pin header Keyboard/Mouse Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
VCC
2
Mouse Data
3
Mouse Clock
4
Keyboard Data
5
Keyboard Clock
6
GND

9
HDMI1: HDMI Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
HDMI_DATA2-1
2
GND
3 HDMI_DATA2#-1 4 HDMI_DATA1-1
5
GND
6
HDMI_DATA1#-1
7
HDMI_DATA0-1
8
GND
9
HDMI_DATA0#-1
10
HDMI_CLK-1
11
GND
12
HDMI_CLK#-1
13
NA
14
NA
15
HDMI_SCL-DVI
16
HDMI_SDA-DVI
17 GND 18 +5V
19
HDMI_HPD-DVI
VGA1: VGA Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
RED
2
GREEN
3
BLUE
4
NC
5
GND
6
GND
7
GND
8
GND
9
VCC
10
GND
11
NC
12
DDCDA
13
HSYNC
14
VSYNC
15
DDCCLK
J_AUDIO1: Audio Source Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
HDA_SYNC
2
HDA_BIT_CLK
3
HDA_SDOUT
4
HDA_SPKR
5
HDA_SDIN
6
HDA_RST#
7
HDA_VCC
8
HDA_GND
9
HDA_+12V
10
HDA_GND

10
DP1: Internal DisplayPort Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
DPD_OB_LANE0_P_C
11
GND
2
GND
12
DPD_OB_LANE3_N_C
3
DPD_OB_LANE0_N_C
13
AUX_CTRL_DET_D
4
DPD_OB_LANE1_P_C
14
CONFIG2
5
GND
15
DPD_AUX_CTRL_P2
6
DPD_OB_LANE1_N_C
16
GND
7
DPD_OB_LANE2_P_C
17
DPD_AUX_CTRL_N2
8
GND
18
DDI2_HPD#
9
DPD_OB_LANE2_N_C
19
GND
10
DPD_OB_LANE3_P_C
20
DP PWR
I2C1: I2C Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
GND
2
PCH_GP38 (I2C_DAT)
3
PCH_GP39 (I2C_CLK)
4
+5V
TPM1: TPM Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
LCLK
2
GND
3
LFRAME#
4
KEY
5
LRERST#
6
+5V
7
LAD3
8
LAD2
9
+3.3V
10
LAD1
11
LAD0
12
GND
13
SCL
14
SDA
15
SB3V
16
SERIRQ
17
GND
18
GLKRUN#
19
LPCPD#
20
LDRQ#

11
USB3_34: Internal USB 3.0 Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
VCC
11
USB_DATA+
2
USB3_RX-
12
USB_DATA-
3
USB3_RX+
13
GND
4
GND
14
USB3_TX+
5
USB3_TX-
15
USB3_TX-
6
USB3_TX+
16
GND
7
GND
17
USB3_RX+
8
USB_DATA-
18
USB3_RX-
9
USB_DATA+
19
VCC
10
NC
CN1: EC Debug Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
EC_EPP_STB#
2
EC_EPP_AFD#
3
EC_EPP_PD0
4
NC
5
EC_EPP_PD1
6
EC_EPP_INIT#
7
EC_EPP_PD2
8
EC_EPP_SLIN#
9
EC_EPP_PD3
10
GND
11
EC_EPP_PD4
12
NC
13
EC_EPP_PD5
14
EC_EPP_BUSY
15
EC_EPP_PD6
16
EC_EPP_KSI5
17
EC_EPP_PD7
18
EC_EPP_KSI4
SMB1: SMBUS Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
GND
2
SMB_DATA
3
SMB_CLK
4
+5V

12
MPCIE1: M-SATA Card Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
GND
2
+3.3V
3
GND
4
+3.3V
5
PCIE_RXN3
6
N/C
7
PCIE_RXP3
8
N/C
9
GND
10
DAS/DSS#
11
PCIE_TXN3
12
+3.3V
13
PCIE_TXP3
14
+3.3V
15
GND
16
+3.3V
17
PCIE_RXN2
18
+3.3V
19
PCIE_RXP2
20
N/C
21
GND
22
N/C
23
PCIE_TXN2
24
N/C
25
PCIE_TXP2
26
N/C
27
GND
28
N/C
29
PCIE_RXN1
30
N/C
31
PCIE_RXP1
32
N/C
33
GND
34
N/C
35
PCIE_TXN1
36
N/C
37
PCIE_TXP1
38
DEVSLP
39
GND
40
N/C
41
PCIE_RXN0
42
N/C
43
PCIE_RXP0
44
N/C
45
GND
46
N/C
47
PCIE_TXN0
48
N/C
49
PCIE_TXP0
50
PERST#
51
GND
52
CLKREQ#
53
REFCLKN
54
PEWAKE
55
REFCLKP
56
N/C
57
GND
58
N/C
59
Notch
60
Notch
61
Notch
62
Notch

13
COM1, COM2, COM3: Internal RS-232 Serial Port Connectors
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
DCD
2
DSR
3
RXD
4
RST
5
TXD
6
CTS
7
DTR
8
RI
9
GND
10
GND
SATA1, SATA2, SATA3, SATA4, SATA5, SATA6: SATA 6Gb/s Drive
Connectors
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
GND
5
SATA_RX-
2
SATA_TX+
6
SATA RX+
3
SATA_TX-
7
GND
4
GND
8
N/C
USB3_1, USB3_2: External USB 3.0 Connectors
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
VBUS
2
D-
3
D+
4
GND
5
STDA_SSRX_N
6
STDA_SSRX_P
7
GND_DRAIN
8
STDA_SSTX_N
9
STDA_SSTX_P
63
Notch
64
Notch
65
Notch
66
Notch
67
N/C
68
SUSCLK
69
PEDET
70
+3.3V
71
GND
72
+3.3V
73
GND
74
+3.3V
75
GND

14
JSPI1: Flash SPI ROM Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
+3.3V
2
SPI_CS#
3
SPI_SO
4
NC
5
GND
6
SPI_CLK
7
SPI_SI
8
NC
LAN1, LAN2: RJ45 LAN Connectors
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
MDIA3-
5
MDIA1+
2
MDIA3+
6
MDIA2+-
3. MDIA2- 7 MDIA0-
4.
MDIA1-
8
MDIA0+
USB3: External USB 2.0 Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
VCC
2
DATA-
3
DATA+
4
GND
USB1, USB2, USB4: Internal USB 2.0 Connectors
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
VCC
2
GND
3
USB_DATA-
4
USB_DATA+
5
USB_DATA+
6
USB_DATA-
7
GND
8
VCC
COM4: Internal RS-422/485 Serial Port Connectors
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
RXD485#
2
RXD485+
3
TXD485+
4
TXD485#

15
CHASSIS1: Chassis Status Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
+3.3VSB
2
CHASSIS OPEN
LED_LAN2: LAN2 link LED Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
+3.3V
2
LAN2_LED_LNK#_ACT
LED_LAN1: LAN1 link LED Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
+3.3V
2
LAN1_LED_LNK#_ACT
JSPI2: Flash EC ROM Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
+3.3V
2
SPI_CS#
3
SPI_SO
4
NC
5
GND
6
SPI_CLK
7
SPI_SI
8
NC

16
Board Layout: Jumper and Connector Locations
PCIE-Q370-HDMI-R11 SKU

17

18
PCIE-Q370-R11 SKU

19
(Unit: mm)
