IEI Technology KINO-CV-D25501 User manual

KINO-CV-D25501/N26001 SBC
Page i
User Manual
KINO-CV-D25501/N26001
MODEL:
Mini-ITX SBC with Intel
®
AtomD2550/N2600 Processor
Up to 4.0 GB DDR3, VGA, HDMI, Dual LVDS, Dual GbE,
SATA 3Gb/s, USB 3.0, microSD, PCIe Mini, RoHS
Rev. 1.04 – December 22, 2014

KINO-CV-D25501/N26001 SBC
Page ii
Revision
Date Version Changes
December 22, 2014 1.04 Deleted SMBus connector information
Modified Ethernet port information
September 22, 2014 1.03 Modified Figure 3-1: Connector and Jumper Locations
May 12, 2014 1.02 Modified Table 3-23: LAN1 Pinouts
October 8, 2013 1.01 Updated the dual USB cable information in the packing list.
July 23, 2012 1.00 Initial release

KINO-CV-D25501/N26001 SBC
Page iii
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

KINO-CV-D25501/N26001 SBC
Page iv
Table of Contents
1 INTRODUCTION.......................................................................................................... 1
1.1 INTRODUCTION........................................................................................................... 2
1.2 BENEFITS ................................................................................................................... 3
1.3 FEATURES................................................................................................................... 3
1.4 CONNECTORS ............................................................................................................. 4
1.5 DIMENSIONS............................................................................................................... 5
1.6 DATA FLOW................................................................................................................ 6
1.7 TECHNICAL SPECIFICATIONS ...................................................................................... 7
2 PACKING LIST........................................................................................................... 10
2.1ANTI-STATIC PRECAUTIONS.......................................................................................11
2.2 UNPACKING PRECAUTIONS........................................................................................11
2.3 PACKING LIST........................................................................................................... 12
2.4 OPTIONAL ITEMS...................................................................................................... 13
3 CONNECTOR PINOUTS........................................................................................... 14
3.1 PERIPHERAL INTERFACE CONNECTORS..................................................................... 15
3.1.1 Layout .............................................................................................................. 15
3.1.2 Peripheral Interface Connectors ..................................................................... 16
3.1.3 External Interface Panel Connectors............................................................... 17
3.2 INTERNAL PERIPHERAL CONNECTORS...................................................................... 17
3.2.1 Battery Connector............................................................................................ 18
3.2.2 Digital I/O Connector...................................................................................... 19
3.2.3 Fan Connectors................................................................................................ 20
3.2.4 Front Audio Connector.................................................................................... 20
3.2.5 Front Panel Connector .................................................................................... 21
3.2.6 Keyboard/Mouse Connector............................................................................ 22
3.2.7 LVDS Connector (LVDS1)............................................................................... 23
3.2.8 LVDS Connector (LVDS2)............................................................................... 24
3.2.9 LVDS Backlight Connectors ............................................................................ 26
3.2.10 microSD Card Slot......................................................................................... 26

KINO-CV-D25501/N26001 SBC
Page v
3.2.11 PCIe Mini Card Slot....................................................................................... 27
3.2.12 Power Connector (9 V–28 V)......................................................................... 29
3.2.13 Power Button ................................................................................................. 30
3.2.14 RS-232 Serial Port Connectors (COM3, COM5, COM6) ............................. 31
3.2.15 RS-422/485 Serial Port Connector (COM4).................................................. 32
3.2.16 SATA Drive Connectors ................................................................................. 33
3.2.17 SATA Power Connectors................................................................................ 34
3.2.18 SO-DIMM Connector..................................................................................... 35
3.2.19 SPDIF Connector........................................................................................... 36
3.2.20 SPI Flash Connector...................................................................................... 37
3.2.21 USB 2.0 Connectors....................................................................................... 38
3.3 EXTERNAL INTERFACE CONNECTORS....................................................................... 39
3.3.1 Audio Connector .............................................................................................. 39
3.3.2 Ethernet and USB 2.0 Combo Connector........................................................ 40
3.3.3 Ethernet and USB 3.0 Combo Connector........................................................ 41
3.3.4 HDMI Connector............................................................................................. 42
3.3.5 Power Connector (9 V–28 V, Power Adapter)................................................. 43
3.3.6 Serial Port Connectors (COM1, COM2)......................................................... 44
3.3.7 VGA Connector................................................................................................ 45
4 INSTALLATION ......................................................................................................... 46
4.1ANTI-STATIC PRECAUTIONS...................................................................................... 47
4.2 INSTALLATION CONSIDERATIONS.............................................................................. 48
4.3 SO-DIMM INSTALLATION ....................................................................................... 49
4.4 PCIE MINI CARD INSTALLATION .............................................................................. 50
4.5 JUMPER SETTINGS .................................................................................................... 51
4.5.1 AT/ATX Mode Selection................................................................................... 51
4.5.2 Clear CMOS Jumper........................................................................................ 52
4.5.3 LVDS1 Voltage Selection.................................................................................. 53
4.5.4 LVDS2 Voltage Selection.................................................................................. 54
4.5.5 LVDS2 Resolution Selection ............................................................................ 55
4.5.6 PCIe Mini/mSATA Mode Selection .................................................................. 56
4.6 CHASSIS INSTALLATION............................................................................................ 57
4.6.1 Airflow.............................................................................................................. 57
4.6.2 Motherboard Installation................................................................................. 57

KINO-CV-D25501/N26001 SBC
Page vi
4.7 INTERNAL PERIPHERAL DEVICE CONNECTIONS........................................................ 58
4.7.1 SATA Drive Connection ................................................................................... 58
4.7.2 USB Cable Connection.................................................................................... 59
4.7.3 Keyboard/Mouse Connector (Optional) .......................................................... 60
4.8 SOFTWARE INSTALLATION ........................................................................................ 61
5 BIOS.............................................................................................................................. 64
5.1 INTRODUCTION......................................................................................................... 65
5.1.1 Starting Setup................................................................................................... 65
5.1.2 Using Setup...................................................................................................... 65
5.1.3 Getting Help..................................................................................................... 66
5.1.4 Unable to Reboot After Configuration Changes.............................................. 66
5.1.5 BIOS Menu Bar................................................................................................ 66
5.2 MAIN........................................................................................................................ 67
5.3ADVANCED............................................................................................................... 68
5.3.1 ACPI Configuration......................................................................................... 69
5.3.2 RTC Wake Settings........................................................................................... 70
5.3.3 CPU Configuration.......................................................................................... 71
5.3.4 IDE Configuration........................................................................................... 73
5.3.5 USB Configuration........................................................................................... 74
5.3.6 F81866 Super IO Configuration...................................................................... 75
5.3.6.1 Serial Port n Configuration....................................................................... 76
5.3.7 F81866 H/W Monitor....................................................................................... 82
5.3.7.1 Smart Fan Mode Configuration................................................................ 83
5.3.8 Serial Port Console Redirection ...................................................................... 84
5.3.9 IEI Feature....................................................................................................... 85
5.4 CHIPSET ................................................................................................................... 86
5.4.1 Host Bridge...................................................................................................... 87
5.4.1.1 Intel IGD Configuration............................................................................ 88
5.4.2 South Bridge..................................................................................................... 89
5.5 BOOT........................................................................................................................ 91
5.6 SECURITY................................................................................................................. 93
5.7 EXIT......................................................................................................................... 93
A BIOS OPTIONS .......................................................................................................... 95

KINO-CV-D25501/N26001 SBC
Page vii
B TERMINOLOGY........................................................................................................ 98
C DIGITAL I/O INTERFACE..................................................................................... 102
C.1 INTRODUCTION...................................................................................................... 103
C.2ASSEMBLY LANGUAGE SAMPLE 1.......................................................................... 104
C.3ASSEMBLY LANGUAGE SAMPLE 2.......................................................................... 104
D HAZARDOUS MATERIALS DISCLOSURE....................................................... 105
D.1 HAZARDOUS MATERIALS DISCLOSURE TABLE FOR IPB PRODUCTS CERTIFIED AS
ROHS COMPLIANT UNDER 2002/95/EC WITHOUT MERCURY ..................................... 106

KINO-CV-D25501/N26001 SBC
Page viii
List of Figures
Figure 1-1: KINO-CV-D25501/N26001............................................................................................2
Figure 1-2: Connectors ..................................................................................................................4
Figure 1-3: Dimensions (mm)........................................................................................................5
Figure 1-4: Data Flow Diagram......................................................................................................6
Figure 3-1: Connector and Jumper Locations...........................................................................15
Figure 3-2: Battery Connector Location.....................................................................................18
Figure 3-3: Digital I/O Connector Location ................................................................................19
Figure 3-4: Fan Connector Locations.........................................................................................20
Figure 3-5: Front Audio Connector Location.............................................................................21
Figure 3-6: Front Panel Connector Location .............................................................................22
Figure 3-7: Keyboard/Mouse Connector Location....................................................................23
Figure 3-8: LVDS1 Connector Location......................................................................................24
Figure 3-9: LVDS2 Connector Location......................................................................................25
Figure 3-10: LVDS Backlight Inverter Connectors....................................................................26
Figure 3-11: microSD Slot Location............................................................................................27
Figure 3-12: PCIe Mini Card Slot Location.................................................................................28
Figure 3-13: ATX Power Connector Location............................................................................30
Figure 3-14: Power Button Location...........................................................................................30
Figure 3-15: RS-232 Serial Port Connector Location................................................................31
Figure 3-16: RS-422/485 Serial Port Connector Location.........................................................32
Figure 3-17: SATA Drive Connector Location ...........................................................................34
Figure 3-18: SATA Power Connector Locations .......................................................................35
Figure 3-19: SO-DIMM Connector Location...............................................................................36
Figure 3-20: SPDIF Connector Location ....................................................................................36
Figure 3-21: SPI Flash Connector Location...............................................................................37
Figure 3-22: USB Connector Locations......................................................................................38
Figure 3-23: External Interface Connectors...............................................................................39
Figure 3-24: Audio Connector.....................................................................................................40
Figure 3-25: Ethernet Connector.................................................................................................40
Figure 3-25: Ethernet Connector.................................................................................................42

KINO-CV-D25501/N26001 SBC
Page ix
Figure 3-26: HDMI Connector......................................................................................................43
Figure 3-27: 4-pin Power DIN Connection..................................................................................44
Figure 3-28: Serial Port Pinout Locations..................................................................................44
Figure 3-29: VGA Connector .......................................................................................................45
Figure 4-1: SO-DIMM Installation................................................................................................49
Figure 4-2: PCIe Mini Card Installation.......................................................................................50
Figure 4-3: AT/ATX Mode Selection Jumper Location..............................................................52
Figure 4-4: Clear CMOS Jumper Location .................................................................................53
Figure 4-5: LVDS1 Voltage Selection Jumper Location ...........................................................54
Figure 4-6: LVDS2 Voltage Selection Jumper Location ...........................................................55
Figure 4-7: LVDS2 Resolution Selection Jumper Location......................................................56
Figure 4-8: PCIe Mini/mSATA Mode Selection Jumper Location ............................................57
Figure 4-9: SATA Drive Cable Connection.................................................................................58
Figure 4-10: Dual USB Cable Connection..................................................................................59
Figure 4-11: Keyboard/mouse Y-cable Connection..................................................................60
Figure 4-18: Introduction Screen................................................................................................62
Figure 4-19: Available Drivers.....................................................................................................62

KINO-CV-D25501/N26001 SBC
Page x
List of Tables
Table 1-1: Technical Specifications..............................................................................................9
Table 2-1: Packing List.................................................................................................................13
Table 2-2: Optional Items.............................................................................................................13
Table 3-1: Peripheral Interface Connectors...............................................................................17
Table 3-2: Rear Panel Connectors..............................................................................................17
Table 3-3: Battery Connector Pinouts........................................................................................18
Table 3-4: Digital I/O Connector Pinouts....................................................................................19
Table 3-5: Fan Connector Pinouts..............................................................................................20
Table 3-6: Front Audio Connector Pinouts................................................................................21
Table 3-7: Front Panel Connector Pinouts.................................................................................22
Table 3-8: Keyboard/Mouse Connector Pinouts .......................................................................23
Table 3-9: LVDS1 Connector Pinouts.........................................................................................24
Table 3-10: LVDS2 Connector Pinouts.......................................................................................25
Table 3-11: Backlight Inverter Connector Pinouts....................................................................26
Table 3-12: microSD Slot Connector Pinouts............................................................................27
Table 3-13: PCIe Mini Card Slot Pinouts ....................................................................................29
Table 3-14: Power Connector Pinouts........................................................................................30
Table 3-15: Serial Port Connector Pinouts ................................................................................31
Table 3-16: RS-422/485 Serial Port Connector Pinouts............................................................32
Table 3-17: D-sub 9 RS-422/485 Pinouts....................................................................................33
Table 3-18: SATA Drive Connector Pinouts...............................................................................34
Table 3-19: SATA Power Connector Pinouts.............................................................................35
Table 3-20: SPDIF Connector Pinouts........................................................................................37
Table 3-21: SPI Flash Connector Pinouts ..................................................................................37
Table 3-22: USB Port Connector Pinouts...................................................................................38
Table 3-23: LAN Pinouts ..............................................................................................................40
Table 3-24: Connector LEDs........................................................................................................41
Table 3-25: USB Port Pinouts......................................................................................................41
Table 3-26: HDMI Connector Pinouts .........................................................................................43
Table 3-27: Serial Port Pinouts....................................................................................................44

KINO-CV-D25501/N26001 SBC
Page xi
Table 3-28: VGA Connector Pinouts...........................................................................................45
Table 4-1: Jumpers.......................................................................................................................51
Table 4-2: AT/ATX Mode Selection .............................................................................................52
Table 4-3: Clear CMOS Jumper Settings....................................................................................53
Table 4-4: LVDS1 Voltage Selection...........................................................................................54
Table 4-5: LVDS2 Voltage Selection...........................................................................................54
Table 4-6: LVDS2 Resolution Selection .....................................................................................56
Table 4-7: PCIe Mini/mSATA Mode Selection............................................................................56
Table 5-1: BIOS Navigation Keys................................................................................................66

KINO-CV-D25501/N26001 SBC
Page xii
BIOS Menus
BIOS Menu 1: Main.......................................................................................................................67
BIOS Menu 2: Advanced..............................................................................................................68
BIOS Menu 3: ACPI Configuration..............................................................................................69
BIOS Menu 4: RTC Wake Settings..............................................................................................70
BIOS Menu 5: CPU Configuration...............................................................................................71
BIOS Menu 6: IDE Configuration.................................................................................................73
BIOS Menu 7: USB Configuration...............................................................................................74
BIOS Menu 8: Super IO Configuration........................................................................................75
BIOS Menu 9: Serial Port n Configuration Menu.......................................................................76
BIOS Menu 10: Hardware Health Configuration........................................................................82
BIOS Menu 11: FAN 1 Configuration..........................................................................................83
BIOS Menu 12: Serial Port Console Redirection.......................................................................85
BIOS Menu 13: IEI Feature...........................................................................................................86
BIOS Menu 14: Chipset................................................................................................................87
BIOS Menu 15: Host Bridge Configuration................................................................................87
BIOS Menu 16: Intel IGD SWSCI OpRegion ...............................................................................88
BIOS Menu 17: Southbridge Chipset Configuration.................................................................90
BIOS Menu 18: Boot.....................................................................................................................91
BIOS Menu 19: Security...............................................................................................................93
BIOS Menu 20: Exit.......................................................................................................................94

KINO-CV-D25501/N26001 SBC
Page 1
Chapter
1
1 Introduction

KINO-CV-D25501/N26001 SBC
Page 2
1.1 Introduction
Figure 1-1: KINO-CV-D25501/N26001
The KINO-CV-D25501/N26001 is a Mini-ITX SBC with a Intel® Atomprocessor D2550
or N2600. The KINO-CV-D25501/N26001 is designed for fanless operation. The low
power CPUs don't require active cooling and stay within specified heat range using the
included heatsink.
Storage on the board is handled by a SATA 3Gb/s port for connecting a hard drive, optical
drive or SSD. The PCIe Mini slot allows an mSATA card to be installed. A bootable
microSD card can be installed into the on-board microSD slot.
The board has three types of graphics output. A VGA output connects to a traditional VGA
monitor, one HDMI connector supports HDMI display and two LVDS connectors support
18-bit/24-bit displays.
Other slots and connectors include a PCIe Mini cards slot, PCI slot, RS-232, RS-422/485,
Gigabit Ethernet, USB 3.0 ports, USB 2.0 ports and digital I/O.

KINO-CV-D25501/N26001 SBC
Page 3
1.2 Benefits
Some of the KINO-CV-D25501/N26001 motherboard benefits include:
Low power consumption
Wide range of I/O interfaces
Dual display support
1.3 Features
Some of the KINO-CV-D25501/N26001 motherboard features are listed below:
Mini-ITX form factor
Fanless design
RoHS compliant
Supports HDMI, LVDS and VGA interface for dual display
Wide range power input (9 V–28 V)
Eight USB ports (six USB 2.0, two USB 3.0)
Six serial ports
PCIe Mini card slot supports mSATASSD
microSD slot
Dual GbE

KINO-CV-D25501/N26001 SBC
Page 4
1.4 Connectors
The connectors on the KINO-CV-D25501/N26001 are shown in the figure below.
Figure 1-2: Connectors

KINO-CV-D25501/N26001 SBC
Page 5
1.5 Dimensions
The main dimensions of the KINO-CV-D25501/N26001 are shown in the diagram below.
Figure 1-3: Dimensions (mm)

KINO-CV-D25501/N26001 SBC
Page 6
1.6 Data Flow
Figure 1-4 shows the data flow between the system chipset, the CPU and other
components installed on the motherboard.
Figure 1-4: Data Flow Diagram

KINO-CV-D25501/N26001 SBC
Page 7
1.7 Technical Specifications
KINO-CV-D25501/N26001 technical specifications are listed in Table 1-1.
Specification KINO-CV-D25501/N26001
Form Factor Mini-ITX
On-board CPU 1.86 GHz Intel® AtomD2550 dual-core CPU
1.60 GHz Intel® AtomN2600 dual-core CPU
1.86 GHz Intel® AtomN2800 dual-core CPU (optional)
System Chipset Intel® NM10
Memory D2550 and N2800: One 204-pin 1066 MHz DDR3/DDR3L (1.35V)
SDRAM SO-DIMM (system max. 4.0 GB)
N2600: One 204-pin 800 MHz DDR3/DDR3L (1.35V) SDRAM
SO-DIMM (system max. 2.0 GB)
Graphics Engine D2550 and N2800: Intel® GMA3650 with 640 MHz graphic core speed
N2600: Intel® GMA3600 with 400 MHz graphic core speed
BIOS UEFI BIOS
Digital I/O 8-bit, 4-bit input/4-bit output
Ethernet Controllers Two Realtek RTL8111E PCIe GbE controllers
(LAN1 supports ASF 2.0)
Audio Realtek ALC662 HD Audio codec
Super I/O Controller Fintek F81866
Watchdog Timer Software programmable supports 1 sec–255 sec system reset
Expansions 1 x PCIe Mini slot supports mSATASSD ((SATA2 and mSATA share
SATA signal))
1 x PCI slot

KINO-CV-D25501/N26001 SBC
Page 8
I/O Interface Connectors
Display Output Ports
(Dual Display Supported)
One Analog CRT (up to 2048 x 1536 @ 75 Hz)
One HDMI (up to 1920 x 1200 @ 60 Hz)
One LVDS 1:
D2550: 24-bit single-channel LVDS up to 1440 x 900
N2600 and N2800: 18-bit single-channel LVDS up to 1366 x 768
One LVDS 2: 24-bit dual-channel LVDS by Chrontel CH7511 DP to
LVDS converter
Fan Connectors One 3-pin wafer for CPU fan
One 3-pin wafer for system fan
Keyboard/Mouse One internal 6-pin wafer connector
Serial Ports Five RS-232 COM connectors
One RS-422/485 COM connector
USB Ports Six USB 2.0 (four via pin header, two external ports)
Two external USB 3.0 ports
Storage
microSD microSD slot (bootable)
SATA Two independent SATAchannels with 3.0 Gb/s data transfer rates
(SATA2 and mSATA share SATA signal)
Environmental and Power Specifications
Power Supply Max. power input voltage range: 9 V–28 V
Recommended operating input voltage range: 12 V–24 V
Power Connector 1 x External 4-pin DIN jack
1 x Internal 4-pin (2x2) power connector
Power Consumption 12 V @ 2.8 A (1.86 GHz Intel® Atom™ processor D2550 with one
4 GB 1333 MHz DDR3 SO-DIMM)
12 V @ 2.4 A (1.6 GHz Intel® Atom™ processor N2600 with one 2 GB
1333 MHz DDR3 SO-DIMM)
