Impex CB-181 User manual

NOTE:
Please read all instructions
carefully before using this
product
Table of Contents
Safety Notice
Hardware Identifier
Assembly Instruction
Parts List
Warranty
Ordering Parts
Model
CB-181
Retain This
Manual for
Reference
08-12-09
OWNER'S
MANUAL
COMPETITOR
WEIGHT BENCH
CB-181
IMPEX®INC.
14777 DON JULIAN RD., CITY OF INDUSTRY, CA 91746
Tel: [phone] Fax: [phone]
www.impex-fitness.com
[email protected]

TABLE OF CONTENTS
BEFORE YOU BEGIN...................................................................................…. 1
IMPORTANT SAFETY NOTICES..................................................................…. 2
HARDWARE PACK…….....…....................................................................…… 4
ASSEMBLY INSTRUCTIONS........................................................................… 5
EXPLODED DIAGRAM……………………………………………………………… 9
PARTS LIST...............................................................................................…… 10
WARRANTY.................................................................................................…. 11
ORDERING PARTS.......................................................................................… 11
BEFORE YOU BEGIN
Thank you for selecting the COMPETITOR CB-181 Weight Bench by
IMPEX®INC. For your safety and benefit, read this manual carefully
before using the machine. As a manufacturer, we are committed to
provide you complete customer satisfaction. If you have any questions,
or find there are missing or damaged parts, we guarantee you complete
satisfaction through direct assistance from our factory. To avoid
unnecessary delays, please call our TOLL-FREE customer service
number. Our Customer Service Agents will provide immediate
assistance to you.
1
Toll-Free Customer Service Number
1-800-999-8899
Mon. - Fri. 9 a.m. - 5 p.m. PST
www.impex-fitness.com
[email protected]m

IMPORTANT SAFETY NOTICE
PRECAUTIONS
This exercise machine is built for optimum safety. However, certain
precautions apply whenever you operate a piece of exercise equipment. Be
sure to read the entire manual before you assemble or operate your machine.
In particular, note the following safety precautions:
1. Keep children and pets away from the machine at all times. DO NOT
leave children unattended in the same room with the machine.
2. Only one person at a time should use the machine.
3. If the user experiences dizziness, nausea, chest pain, or any other
abnormal symptoms, STOP the workout at once. CONSULT A
PHYSICIAN IMMEDIATELY.
4. Position the machine on a clear, leveled surface. DO NOT use the
machine near water or outdoors.
5. Keep hands and feet away from all moving parts.
6. Always wear appropriate workout clothing when exercising. DO NOT wear
robes or other clothing that could become caught in the machine. Running
or aerobic shoes are also required when using the machine.
7. Use the machine only for its intended use as described in this manual. DO
NOT use attachments not recommended by the manufacturer.
8. Do not place any sharp object around the machine.
9. Disabled person should not use the machine without a qualified person or
physician in attendance.
10. Before using the machine to exercise, always do stretching exercises to
properly warm up.
11. Never operate the machine if the machine is not functioning properly.
12. A spotter is recommended during exercise.
CARE AND MAINTENANCE
1. Inspect and tighten all parts before using the machine.
2. The machine can be cleaned using a damp cloth and mild non-abrasive detergent.
DO NOT use solvents.
3. Maximum weight on Upright Beams: 100 lbs.
4. Maximum User weight capacity: 200 lbs.
5. Maximum weight on Leg Developer: 100 lbs.
6. Maximum weight capacity (including user) : 300 lbs.
WARNING: BEFORE BEGINNING ANY EXERCISE PROGRAM, CONSULT
YOUR PHYSICIAN. THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS
OVER THE AGE OF 35 OR PERSONS WITH PRE-EXISTING HEALTH
PROBLEMS. READ ALL INSTRUCTIONS BEFORE USING ANY FITNESS
EQUIPMENT. IMPEX INC. ASSUMES NO RESPONSIBILITY FOR
PERSONAL INJURY OR PROPERTY DAMAGE SUSTAINED BY OR
THROUGH THE USE OF THIS PRODUCT.
SAVE THESE INSTRUCTIONS.
2

WARNING LABEL PLACEMENT
The Warning Label shown here has been placed on the Cross Brace. If the label is missing or
illegible, please call customer service at 1-800-999-8899 for replacement. Apply the label in
location shown.
3

HARDWARE PACK
NOTE: The following parts are not drawn to scale. Please use your own ruler or scale to measure the size.
4

ASSEMBLY INSTRUCTION
Tools Required for Assembling this Machine: Two Adjustable Wrenches and Allen
Wrenches. NOTE: It is strongly recommended that two or more people assemble
this machine to avoid possible injury.
STEP 1 (See Diagram 1)
A.) Do not tighten Nuts and Bolts until instructed to do so.
B.) Connect the Right & Left Upright Beam (#1 & #2) by a Cross Brace (#3) in the Mid-span.
Secure each end of the Cross Brace with two M8 x 2 ½” Hex Bolts (#21), one 1 ¾” x 2
¾” Bracket (#10), four ∅5/8” Washers (#27), and two M8 Aircraft Nuts (#29).
C.)Place the Backrest Adjustment Bar (#7) onto the selected on the Upright Beams to
obtain the desired backrest incline. DIAGRAM 1
5

STEP 2 (See Diagram 2)
A.) Attach the Main Seat Support (#4) to the Front Post (#5). Secure it with two M10 x
2 ¼” Hex Bolts (#22), one 1 ½” x 4 ½” Bracket (#11), four Ø ¾” Washers (#26), and
two M10 Aircraft Nuts (#30).
B.) Attach the Main Seat Support to the Cross Brace (#3). Secure it with two M10 x 2
¼” Hex Bolts (#22), one 1 ½” x 4 ½” Bracket (#11), four Ø ¾” Washers (#26), and
two M10 Aircraft Nuts (#30).
C.) Securely tighten all Nuts and Bolts installed in Step-1 and Step-2. DIAGRAM 2
6

STEP 3 (See Diagram 3)
A.) Attach the Leg Developer (#6) to the open bracket on the Front Post (#5). Secure it
with one M8 x 2 ¾” Hex Bolt (#23), two Ø 5/8” Washers (#27), and one M8 Aircraft
Nut (#29). Do not over tighten the Nut and Bolt. Make sure the Leg Developer
can swivel freely.
B.) Place the Seat Pad (#13) onto the bracket on the Main Seat Support (#4). Secure it
with four M6 x 5/8” Allen Bolts (#24) and four Ø ½” Washers (#28).
C.) Insert the Foam Tube (#9) halfway through the hole on the Leg Developer. Push
two Foam Rolls (#14) onto the Tube from both ends.
DIAGRAM 3
7

STEP 4 (See Diagram 4)
A.) Attach the bottom side-holes on Backrest Supports (#8) to the pivot on the Main Seat
Support (#4). Rest the other end against the Backrest Adjustment Bar (#7).
B.) Attach the Backrest Board (#12) to the Backrest Support. Secure it with four M6 x 1
½” Hex Bolts (#25) and four Ø ½” Washers (#28).
DIAGRAM 4
8

9
