User’s Manual
BPBIO210/220
BPBIO210/220 User's Manual for Measurement Guide and Setup
Thank you for purchasing the BPBIO210/220. This user’s manual describes all the features of the BPBIO210/220.
Please read before use and keep it in a safe place. By following the manual instructions, you will be able to use the
BPBIO210/220 more safely and eectively.

Please note the important information below before reading this manual.
Failure to comply with safety warnings and regulations can cause serious injury or death.
Warning
Le non-respect des consignes de sécurité et des règlements peut causer des blessures graves ou la mort.
Avertissement
Caution
Failure to comply with safety cautions and regulations can cause injury or property damage.
Attention
Le non-respect des consignes de sécurité et des règlements peut causer des blessures ou des dommages matériels.
Note
Referring to notes can help improve equipment use.
Remarque
Se référer aux notes peut aider à améliorer l'utilisation de l'appareil.
©2022 InBody Co., Ltd. All rights reserved. IM-ENG-K6-F-221101

InBody Co., Ltd. [HEAD OFFICE]
For product support or clinical questions, please contact us at the following:
625, InBody Bldg., Eonju-ro, Gangnam-gu, Seoul 06106 KOREA
TEL: [phone]
FAX: [phone]
Website: inbody.com
E-mail: [e-mail]
InBody Co., Ltd.
15, Heugam-gil, Ipjang-myeon, Seobuk-gu,
Cheonan-si, Chungcheongnam-do 31025 KOREA
TEL: [phone] FAX: [phone]
Website: inbody.com E-mail: [e-mail]
©2021 InBody Co., Ltd. All rights reserved.
Reproduction, adaptation, or translation of this manual is prohibited without prior written consent from InBody
Co., Ltd. under the copyright laws. This manual may be subject to change without notice. InBody Co., Ltd. shall
not be liable for any errors, incidental, or consequential damages that occurred by not complying with the content
of the User᾽s Manual.
Visit our website (inbody.com) to view and download additional information about the BPBIO220/210. InBody
Co., Ltd. reserves the right to modify the appearance, specifications, etc. of this product to improve its quality,
without prior notice.

Representative & Sponsor Information
InBody Europe[EUROPE]
InBody Europe B.V.
Gyroscoopweg 122, 1042 AZ, Amsterdam, The Netherlands
TEL: [phone] FAX: [phone] Website: nl.inbody.com E-mail: [email protected]
Australian Sponsor. [AUSTRALIA]
Emergo AUSTRALIA.
Level 20, Tower II, Darling Park, 201 Sussex Street, Sydney, NSW 2000, AUSTRALIA
USA CONTACT
BIOSPACE INC. dba INBODY 13850 CERRITOS CORPRT DR STE C, Cerritos, California, 90703
TEL: [phone]
Customer Service Information
InBody USA [USA]
13850 Cerritos Corporate Dr. Unit C Cerritos, CA 90703 USA
TEL: [phone] FAX: [phone] Website: inbody.com E-mail: [email protected]
InBody Japan [JAPAN]
InBody Japan Inc.
Tani Bldg., 1-28-6, Kameido, Koto-ku, Tokyo 136-0071 Japan
TEL: [phone] FAX: [phone] Website: www.inbody.co.jp E-mail: [e-mail]
InBody China [CHINA]
903/904, XingDiPlaza, No.1698 YiShanRoad, Shanghai 201103 China
TEL: [phone] FAX: [phone] Website: inbodychina.com E-mail: [email protected]
InBody India [INDIA]
57/57/ A, 1st Floor, Raj Industrial Complex, Military Road, Marol, Andheri (East). Mumbai-400059,
Maharashtra, India
TEL: [phone] Website: inbody.in E-mail: [e-mail]
InBody Asia [ASIA]
InBody Asia Sdn. Bhd.
Unit 3A-11, Oval Damansara, 685 Jalan Damansara Kuala Lumpur, WP KL 60000 Malaysia
TEL: [phone] FAX: [phone] Website: inbodyasia.com E-mail: [email protected]

Representative & Sponsor Information
InBody Europe[EUROPE]
InBody Europe B.V.
Gyroscoopweg 122, 1042 AZ, Amsterdam, The Netherlands
TEL: [phone] FAX: [phone] Website: nl.inbody.com E-mail: [email protected]
Australian Sponsor. [AUSTRALIA]
Emergo AUSTRALIA.
Level 20, Tower II, Darling Park, 201 Sussex Street, Sydney, NSW 2000, AUSTRALIA
USA CONTACT
BIOSPACE INC. dba INBODY 13850 CERRITOS CORPRT DR STE C, Cerritos, California, 90703
TEL: [phone]
Customer Service Information
InBody USA [USA]
13850 Cerritos Corporate Dr. Unit C Cerritos, CA 90703 USA
TEL: [phone] FAX: [phone] Website: inbody.com E-mail: [email protected]
InBody Japan [JAPAN]
InBody Japan Inc.
Tani Bldg., 1-28-6, Kameido, Koto-ku, Tokyo 136-0071 Japan
TEL: [phone] FAX: [phone] Website: www.inbody.co.jp E-mail: [e-mail]
InBody China [CHINA]
903/904, XingDiPlaza, No.1698 YiShanRoad, Shanghai 201103 China
TEL: [phone] FAX: [phone] Website: inbodychina.com E-mail: [email protected]
InBody India [INDIA]
57/57/ A, 1st Floor, Raj Industrial Complex, Military Road, Marol, Andheri (East). Mumbai-400059,
Maharashtra, India
TEL: [phone] Website: inbody.in E-mail: [e-mail]
InBody Asia [ASIA]
InBody Asia Sdn. Bhd.
Unit 3A-11, Oval Damansara, 685 Jalan Damansara Kuala Lumpur, WP KL 60000 Malaysia
TEL: [phone] FAX: [phone] Website: inbodyasia.com E-mail: [email protected]
Intended Use:
The BPBIO210/220 is a digital device intended for use in measuring blood pressure and pulse rate
in user population with upper arm circumference ranging from 17cm to 42cm (7-inch to 17-inch).
This device should be used by medical professionals. The systolic blood pressure and diastolic
blood pressure shall be measured by the auscultatory method. Pulse rate will be shown on the LCD
screen after the examination is nished. This device may provide useful clinical information about
the current health status of not only the users who are diagnosed with hypertension but also those
who are not diagnosed with hypertension. Warnings and cautions described in the user’s manual
should be observed at all times.
* This device is designed for use in medical facilities only, such as hospitals, clinics, and
physicians’ oces. This device is not intended for use at home by non-medical professionals.

User’s Manual Contents
BPBIO210/220
1. BPBIO210
I. Introduction for the BPBIO210
A. Standard Components 8
B. Installation Environment 11
C. Installation Instructions 11
D. Features and Functions 16
II. Blood Pressure Measurement
A. Precautions before Measurement 18
B. Measurement Instructions 19
C. Storage 23
2. BPBIO220
I. Introduction for the BPBIO220
A. Standard Components 24
B. Installation Environment 27
C. Installation Instructions 27
D. Features and Functions 32
II. Blood Pressure Measurement
A. Precautions before Measurement 34
B. Measurement Instructions 35
C. Storage 39
3. BPBIO210/220 Common
I. FAQ
A. Error code 40
B. Regarding the Equipment 41
II. Others
A. Optional Equipment 42
B. Safety Information 43
C. Classication 45
D. Specications 46
E. EMC Declaration 47

8
1. BPBIO210
I. Introduction for the BPBIO210
This blood pressure monitor can be used by a medical professional to check blood pressure with
auscultatory method by using the pressure indicator bar on the LCD screen. The back-light
function allows blood pressure monitoring even under dark conditions.
A. Standard Components
❶ Main unit (1 EA)
❷ M-size cuff (1 EA) - for the use of 22 to 32 cm (9 to 13 in) in arm circumference
❸ Air bulb (1 EA)
❹ User's manual (1 EA)
❺ "AA" alkaline batteries 1.5V (4 EA)
ARTERY
M
22~32(cm), 9~13(inch)
RANGE
MIN MAX
BPBIO210/220/210T/220T
❷
ARTERY
M
22~32(cm), 9~13(inch)
RANGE
MIN MAX
BPBIO210/220/210T/220T
❹
ARTERY
M
22~32(cm), 9~13(inch)
RANGE
MIN MAX
BPBIO210/220/210T/220T
❺
ARTERY
M
22~32(cm), 9~13(inch)
RANGE
MIN MAX
BPBIO210/220/210T/220T
❸
ARTERY
M
22~32(cm), 9~13(inch)
RANGE
MIN MAX
BPBIO210/220/210T/220T
❶
*Optional Components (Sold Separately)
❻Cart
❼AC Adapter
- Input Power: AC 100-240V, 50/60Hz, 0.5A
- Output Power: DC 6.0V, 2.0A
❽ S, L size cuffs (S-size: Suitable for arm circumference between 17 to 22cm (7 to 9 in),
L-size: for the use of 32 to 42cm (13 to 17 in) in arm circumference.
❼ ❽
❻
[L]
ARTERY
L
32~42(cm), 13~17(inch)
RANGE
MIN MAX
ARTERY
S
17~22(cm),7~9(inch)
RANGE
MIN MAX
[S]
ARTERY
L
32~42(cm), 13~17(inch)
RANGE
MIN MAX
ARTERY
S
17~22(cm),7~9(inch)
RANGE
MIN MAX
<110V or 220V>

9
*Main Unit Parts
Back-light button
Battery tray
AC adapter jack
Air bulb jack
Cu jack
ARTERY
M
22~32(cm), 9~13(inch)
RANGE
MIN MAX
BPBIO210/220/210T/220T
'MARK' button
On / O button
*Cuff Parts
ARTERY
M
22~32(cm), 9~13(inch)
RANGE
MIN MAX
BPBIO210/220/210T/220T
Checking mark for the available arm
circumference
Cu tube
Artery mark

10
Exhaust valve
Air bulb
Air bulb tube
*Air Bulb Parts
*Display Screen Parts
Pressure guide
Unit for pulse rate
Unit for pressure
Pressure display bar
AC adapter connection symbol
Pulse symbol Battery level indicator
Pressure/Pulse

11
B. Installation Environment
Please make sure the environment is appropriate for the BPBIO210 installation.
This equipment is designed for indoor use. If installing the equipment outdoors, the
following requirements must be met.
Temperature range 10 to 40ºC (50 to 104ºF)
Relative humidity 30 to 85% RH
Atmospheric pressure range 70 to 106kPa
• Do not inflict excessive force when opening the BPBIO210.
• The main unit cannot be bent over a certain angle. Opening the BPBIO210 with excessive
force may damage the device.
Caution
• Ne pas exercer de force excessive lors de l’ouverture de BPBIO210.
• L'unité principale ne peut pas être pliée sous un certain angle. Ouvrir le BPBIO210 avec une
force excessive peut endommager l'appareil.
Attention
C. Installation Instructions
(1) Unboxing the BPBIO210
After opening the BPBIO210 packaging box, take out the BPBIO210 from the bu er and
the protective vinyl package. Open the BPBIO210 and take out the cu and the air bulb from
the protective vinyl package.
Packing box
BPBIO210
Bu er
Protective vinyl package
Cu and air bulb

12
(2) Connecting cu and air bulb
1. Plug the cuff tube into the cuff jack of the main unit. ( ).
2. Plug the air bulb tube into the air bulb jack of the main unit. ( ).
3. Push the tubes all the way in to the end.
• Use the "AA" size alkaline or manganese batteries.
• Do not mix new and used batteries. Replace four batteries with all of the same brand and the
same model new batteries.
• Do not insert batteries with wet hands.
• Make sure that the polarities (+) and (-) are correct.
Warning
(3) Inserting / replacing batteries
1. Remove the battery cover.
2. Insert four (4) "AA" batteries in the right direction as indicated below.
3. Close the battery cover.

13
• Utilisez des piles alcalines ou au manganèse de taille AA.
• Ne combinez pas de nouvelles piles avec des piles usagées. Remplacez les quatre (4) piles en
même temps.
• N’insérez pas les piles si vos mains sont mouillées.
• Assurez-vous que la polarité (+) et (-) des piles est respectée.
• Retirez les piles du boitier lorsque l’appareil n’est pas utilisé pour une longue période de temps.
• Un mauvais usage des piles pourrait affecter le rendement de l’appareil BPBIO210,
et pourrait causer un incendie.
• Remove the batteries from the battery compartment when it will not be in use for long period.
• Dispose used batteries only in designated locations.
• Improper use of batteries may cause degradation of the performance of BPBIO210 and
may cause fire.
Avertissement
(4) Use of the AC adapter (Optional)
*Input Power: AC 100–240V, 50/60Hz, 0.5A
Output Power: DC 6.0V, 2.0A
❶Insert the AC adapter plug into the AC adapter jack on the side of the main unit
as shown in the image below.
❷Plug in the AC adapter to an electrical outlet.
❶
❷
AC adapter jack
AC adapter jack
❶
❷
<Plug Type F>
<Plug Type B>

14
• Do not connect or disconnect the AC adapter with wet hands.
• Do not put heavy objects on the AC adapter cable.
• Do not use the AC adapter if it is damaged.
• Évitez de brancher ou débrancher l'adaptateur secteur avec des mains mouillées.
• Ne posez pas d'objets lourds sur le câble de l'adaptateur secteur.
• N'utilisez pas l'adaptateur secteur s'il est endommagé.
Warning
Avertissement
• Plug the AC adapter into the electrical outlet securely.
• When unplugging the AC adapter, grasp the body of the adapter and pull out.
• To disconnect the AC adapter, unplug the AC adapter from the electrical outlet first and then
remove the AC adapter from the main unit.
• Do not apply excessive force to the AC adapter body and the plug.
• Keep the adapter away from foreign objects.
• Use only the AC adapter provided by InBody.
• Do not use the AC adapter for any other purposes other than for the operation of BPBIO210.
• Branchez correctement l’adaptateur secteur sur la prise secteur.
• Lorsque vous débranchez l'adaptateur secteur, saisissez-le par le corps et sortez-le.
• Débranchez l’adaptateur secteur en respectant l’ordre de la prise de courant, puis de l’unité
principale.
• N'exercez pas une force excessive sur l'adaptateur secteur et la prise.
• Gardez la prise de l'adaptateur secteur loin de tout corps étranger susceptible de l'endommager.
• Utilisez uniquement l’adaptateur secteur fourni par InBody.
• N'utilisez pas l'adaptateur secteur dédié à des fins autres que le fonctionnement de BPBIO210.
Caution
Attention
• The AC adapter is sold separately.
Note
• L’adaptateur secteur dédié est un accessoire optionnel qui peut être acheté séparément.
Remarque

15
(5) Installing the cart (Optional)
Screw the four bolts into the bracket by using a cross slot screwdriver to fasten the bracket
to the cart.

16
D. Features and Functions
(1) Automatic power o
• The BPBIO210 will automatically shut down after 5 minutes has elapsed without pressing
any buttons.
• The BPBIO210 will not shut down if it is connected to the AC adapter.
Main unit will switch off automatically if idle for more than 5 minutes to prevent battery
drain. Main unit will not switch off automatically if connected to the AC adapter.
The automatic power off function can be turned off by following the settings below.
❶Press the button to turn on the power.
❷ When the image below is displayed on the LCD, the power is on.
❸ Press and hold the button for about 5 seconds. If ‘OFF’ is displayed on the screen as
shown below, the automatic power o function is disabled.
❹ You can turn the automatic power o function back on by repeating the steps above.
ON / OFF button

17
(2) Protection from excessive pressurization
• If the pressure applied to the cuff exceeds 320mmHg, the BPBIO210 will automatically
exhaust the pressure from the cuff to protect the patient.
(3) Residual air detection
• If there is any remaining air left in the cuff, the error code 'E1' will appear on the screen
when the product power is switched on.
• For accurate measurement result, exhaust the air in the cuff entirely before switching the
power on.
(4) Pulse measurement
• Pulse is detected when the pressure applied to the cuff is greater than 50mmHg. The
pulse rate is measured only when the pulse is detected at least 5 times.
• If deflation is performed too quickly, pulse may not be detected. Deflate at the rate of
2 to 4mmHg/sec. to detect the pulse.
• The measured heart rate will be displayed when the pressure is less than 20mmHg.
• If pulse is not detected or is not constant, “- - -” will be displayed.
(5) Back-light
• The back-light is automatically turned on or off depending on the brightness of the
surrounding environment.
• The back-light function can also be manually operated by pressing the back-light button.
• If the back-light is operated manually with the back-light button, the back-light will not turn
on or off automatically. When the product is turned off and on, the back-light automatically
turns on or off again depending on the brightness of the surrounding environment.
(6) Mark
• Mark function allows to display the measured value on the screen momentarily once the
button is pressed.
• Up to five marks can be displayed.

18
Blood Pressure Measurement
A. Precautions before Measurement
Caution
Attention
• The BPBIO210 must be operated by those who are well trained of the auscultatory method of
measuring the blood pressure.
• Do not operate the BPBIO210 immediately if it has been left for a long period of time in an
environment where the temperature is lower than 10ºC (50ºF) or higher than 40ºC (104ºF).
• Do not use the BPBIO210 in a highly humid environment.
• Do not use the BPBIO210 near any equipment which generates strong magnetic fields,
electrostatic, or high frequency.
• Patients with artificial heart or lungs may obtain inaccurate results.
• Le BPBIO210 doit être manipulé par un personnel qualifié et bien formé à la méthode
d’auscultation pour mesurer la pression artérielle.
• N'utilisez pas un BPBIO210 qui n'a pas été utilisé depuis longtemps dans un environnement \
où la température était inférieure à 10° C ou supérieure à 40° C.
• Ne pas utiliser le BPBIO210 dans des zones très humides.
• N'utilisez pas le tBPBIO210 à proximité d'équipements produisant des champs magnétiques,
électrostatiques puissants ou à haute fréquence.
• Les patients ayant un coeur ou des poumons artificiels peuvent obtenir des résultats inexacts.
• Do not wrap the cuff on an injured arm. Injury may worsen or can be infected.
• Do not wrap the cuff in an arm with the intravenous injection or IV plugged in.
• Please consult a doctor before using the blood pressure monitor if you have any
cardiovascular diseases.
• Do not wrap the cuff around your neck.
• Do not wrap the cuff tube around your neck.
• Do not wrap the air bulb tube around your neck.
Warning
• N'enroulez pas la manchette sur un bras blessé. Les blessures peuvent s'aggraver ou être
infectées.
• Ne pas envelopper la manchette dans un bras avec une injection intraveineuse ou une IV
branchée.
• Veuillez consulter un médecin avant d'utiliser le moniteur de pression artérielle si vous avez
des maladies cardiovasculaires.
• N'enroulez pas la manchette autour de votre cou.
• N'enroulez pas le tube à manchette autour de votre cou.
• N'enroulez pas le tube d'ampoule à air autour du cou.
Avertissement
II.

19
B. Measurement Instructions
(1) How to wear the cu
❶Wrap the cuff around the arm, about 2-3 cm
(1 in) above the elbow.
❷ Make sure that the index (▲) on the cuff is
located within the RANGE bar.
Replace the cuff with the right size if the index
deviates from the RANGE.
❸ Place the cuff so that the artery mark (▼) is
located on the artery.
❹ Do not wrap the cuff too tightly. Leave a margin
of a finger to get the best result.
ARTERY
INDEX(▲)
RANGE
CUFF
2-3 cm
(1 in)
• The cuff provided will be M-sized cuff which is suitable for individuals with an arm circumference
of 22 to 32cm (9 to 13 in). If the arm circumference exceeds 32cm (13 in), use the L-size cuff.
If the arm circumference is smaller than 22cm (9 in), use the S-size cuff.
• L-size or S-size cuff is sold separately.
Note
• La manchette fournie sera une manchette de taille M. qui convient aux personnes ayant une circonférence
de bras de 22 à 32 cm. Si la circonférence du bras dépasse 32 cm, utilisez la manchette de taille L. Si la
circonférence du bras est inférieure à 22 cm, utilisez la manchette taille S.
• La manchette de taille L ou taille S est vendue séparément.
Remarque
• For correct measurement, please wear the cuff properly.
• If the cuff is too loosely wrapped, the measured blood pressure values may not be correct.
Caution
• Portez la manchette correctement pour une mesure précise.
• Si la manchette est trop lâche, le résultat de la mesure peut ne pas être précis.
Attention

20
• The measurement posture may affect the blood pressure values.
• Please keep the proper measurement posture for accurate measurement.
Caution
• La posture de mesure peut affecter le résultat.
• Soyez conscient de votre posture pour chaque mesure.
Attention
Height of the heart
(2) Proper measurement posture
❶ Place the arm so that the middle of the cuff
is at the patient’s heart position.
❷ Be relaxed during the measurement.
(3) Turning the power on
❶ Press the button to turn on the power.
❷ The symbols on the screen and the back-light will be turned on and off with a beeping sound.
❸ When there are no changes detected in the pressure within the cuff, number "0" will be
displayed on the screen, which means it's ready for measurement. If the pressure
of the cuff is not stabilized within 20 seconds, the error code ‘E1’ will be displayed
in the pressure/pulse display column on the screen.
ON / OFF button
