AURIX™ TC2xx Microcontroller Training
V1.0.0
STM_Interrupt_1
Interrupt generation via STM trigger
Please read the Important Notice and Warnings at the end of this document

Scope of work
The STM is configured to trigger an interrupt every 500 ms. The
interrupt toggles an LED.
The System Timer (STM) module counts up to a configured compare value,
when it reaches the specific value, it triggers an interrupt and resets its
counter value. The value is set to trigger the interrupt every 500 ms; at each
interrupt an LED is toggled.
2
2019-10-17 Copyright © Infineon Technologies AG 2019. All rights reserved.

Introduction
›The System Timer (STM) is a free running 64-bit counter that can be used
for timing applications requiring both high precision and long period.
›Among other features, the STM has the capability to generate interrupts
when its count reaches a predefined compare value.
›The comparison is flexible in terms of bit sets.
Any of the 64 bits of the STM can be selected for comparison.
3
2019-10-17 Copyright © Infineon Technologies AG 2019. All rights reserved.

Hardware setup
This code example has been
developed for the board
KIT_AURIX_TC297_TFT_BC-Step.
4
2019-10-17 Copyright © Infineon Technologies AG 2019. All rights reserved.

Implementation
Configure and control the LED
The LED is toggled by controlling the port pin to which it is connected using functions
from the iLLD header IfxPort.h.
Inside the function initPeripherals(), the port pin is configured to push-pull output
mode using the function IfxPort_setPinMode().
During program execution, inside the interrupt service routine isrSTM(), the LED is
switched on and off using the function IfxPort_setPinState().
5
2019-10-17 Copyright © Infineon Technologies AG 2019. All rights reserved.

Implementation
Configure the STM
Configuration of the STM is done inside the function initSTM() by initializing an
instance of the IfxStm_CompareConfig structure with default values through the
function IfxStm_initCompareConfig().
Then, the following parameters are modified:
›ticks –the total amount of ticks to count before the interrupt generation.
›triggerPriority –priority of the interrupt generated by the STM on compare match.
It can be a value from 0 to 255, with 0 meaning interrupt is disabled and 255 is the
highest priority.
›typeOfService –to define which service provider is responsible for handling the
interrupt. This can be any of the available CPUs or the DMA.
The above functions can be found in the iLLD header IfxStm.h.
6
2019-10-17 Copyright © Infineon Technologies AG 2019. All rights reserved.

Implementation
Configure the Interrupt Service Routine
The function implementing the ISR (isrSTM()) needs to be assigned a priority and a
core responsible for its execution.
This is done with the macro IFX_INTERRUPT(isr, vectabNum, priority).
When triggered, the ISR:
›Instructs the STM to raise the next interrupt after a certain amount of time by
updating its compare register with the function IfxStm_increaseCompare().
›Toggles the LED by changing the state of the port pin using the function
IfxPort_setPinState().
7
2019-10-17 Copyright © Infineon Technologies AG 2019. All rights reserved.

Run and Test
After code compilation and flashing the device, observe the LED D107 (1),
which should be blinking.
1
8
2019-10-17 Copyright © Infineon Technologies AG 2019. All rights reserved.

References
›More code examples can be found on the GIT repository:
›https://github.com/Infineon/AURIX_code_examples
›For additional trainings, visit our webpage:
›https://www.infineon.com/aurix-expert-training
›AURIX™ Development Studio is available online:
›https://www.infineon.com/aurixdevelopmentstudio
›Use the „Import...“ function to get access to more code examples.
›For questions and support, use the AURIX™ Forum:
›https://www.infineonforums.com/forums/13-Aurix-Forum
9
