Inside Weather ATLAS SHELF User manual

ATLAS SHELF

Gather Your Eggs...
Wood Screws
Dry Wall Anchors
L-Bracket
Screw Caps
Poles
Top (Holes do not go all the way through)
Shelves (Holes go all the way through)
Number of shelves depend on option chosen
Note: Please retain all boxes until you are certain that your product isn’t damaged and that you
do not wish to return it. Disposal of boxes may prevent/delay our ability to resolve your request.
Ratchet
Long Hex Bit

Step 1: Attach Top Shelf
Place cardboard on the ground to protect the floor and the back of the shelves. You can
use the box it came in.
Place the top on its back and insert one pole into the lower pocket. Tighten the connecting
screw. Place another pole into the other lower pocket and tighten.
Slide a second shelf over the poles to the desired position. Do not tighten yet.
Note: Make sure the
connecting screws are
retracted inside their
housing. Having the screw
out could obstruct the
pole fitting through.

Step 2: Place The Other Shelves
Place the other shelves
into position.
You can use a tape measure
to determine the distance of
each shelf.
Once the shelves are in their
desired positions, tighten the
connecting screws using the
provided ratchet and long
hex bit.
Connecting Screw Opening

Step 3: Add Remaining Poles
Place caps on each
screw opening after
they have all been
tightened.
Gently slide the remaining poles
through each shelf and secure
into the top shelf holes.
Tighten the connecting screws in
the top shelf.
Again, use a tape measure
to check the distance of
each shelf.
Tighten the connecting
screws.
Step 4: Add Caps

Step 5: Adjust Feet
Step 6: Mounting to Wall
If your shelving unit needs to be leveled, you
can adjust each foot by rotating them in or out
until it is just right.
Using two people, carefully lift the
completed shelf upright.
Next you’ll want to secure your shelving unit to the wall. Please note that ASTM standards require all case goods
over 30” tall to be affixed to a wall with an Anti-Tip Kit. Every order includes a complimentary, recommended
Anti-Tip Kit so that you can safely and discreetly fasten your shelving unit to the wall.
The provided L-Brackets
can be mounted either
on the top side or
underside of the top
shelf. It’s up to you to
choose your preferred
placement.
Measure and drill holes
into the shelf to match
the L-Bracket holes. Use
the wood screws.
Tigten the screws to ensure
your shelving unit is secure.
Drill two holes in the wall and
insert the plastic anchors. Then
place the L-Bracket over the
plastic anchors and insert the
screws through the L-Bracket
and into the plastic anchors.

DONE!
Step 7: Enjoy
