VOSS SIDEBOARD

Gather Your Eggs...
More Eggs...
3x Doors
2x Side Panels 2x Dividers
2x Back Panels
3x Middle Shelves
1x Top Panel
1x Bottom Panel
3x Door Handles
with 6x Screws
12x Shelf Pins
6x Hinge Connector Hardware
with 12x Screws
4x Legs
6x Door Hinges
with 12x Screws
(2x will be arced)
16x Leg Screws
Note: Please retain all boxes until you are certain that your product isn’t damaged and that you
do not wish to return it. Disposal of boxes may prevent/delay our ability to resolve your request.
3x Adhesive Plastic Bumpers
16x Screw Connector Covers
Ratchet
Long Hex Bit

Step 1: Attach the Hinge Connector Hardware
Grab your side panels, divider with
mounting holes, hinge connector
hardware and matching screws.
Identify the mounting holes in the side
panel. They look like vampire bites.
Repeat for divider.
• Check the orientation: the C-shaped groove
should face the nearest edge
• Fasten with screws. Use a Phillips Head Screwdriver
to tighten screws
• Each side panel should have 2 hinge connectors

Step 2: Attach Lower Back Panel to Bottom Panel
Bottom Panel
Lower Back Panel
Place your bottom panel with the leg holes
facing down.
Align and center the grooves of the lower
back panel to the corresponding grooves in
the bottom panel and press down.
Side View

Step 3: Attach Side Panels
Side Panels
Align the plastic connectors on the side
panel with the corresponding holes on
the bottom panel.
Fasten using provided ratchet.
Repeat for both sides.
Note: When fitting the pieces together,
make sure the connecting screws are
retracted inside their housing. Having the
screw out could damage your surfaces.

Step 4: Attach Upper Back Panel
Slide upper back panel between side panels
and onto lower back panel.
Step 5: Attach Inside Divider Panel
Door Hinge
Connectors
Press down divider panel into the corresponding holes.
Make sure the divider panel on the right has the door
hinge connectors facing out.
Fasten using provided ratchet.
Make sure connecting screws are visible on all pieces.

Step 6: Attach the Top Panel
Side View
Grab your Top Panel. Line up the connectors in the side panels
and center dividers with the holes on the top panel. Ensure the
back is aligned with the grove on the top.
Fasten using provided ratchet.

Step 7: Attach the Legs
Repeat for remaining legs
Flip the Sieboard back onto
its feet
Rotate the unit onto its back.
Attach the legs using the leg screws. There are
4 screws to each leg.
Note: flared legs should each point outward
towards their respective corners.

Add shelf pins to the desired height and place
the shelves groove side down on top of the pins
from above. Use four pins per shelf.
Shelf Pins
Step 8: Install the Shelves

Step 9: Install the Hinges
6x Door Hinges with 12x Screws
Place a hinge into each well on the inside of
the door panel.
Arced Hinge
Insert a screw into each mounting hole and
fasten. Repeat for the remaining hinges.
Note: Two of the hinges have an arc. The arced
hinges will be used for the center door.
Straight Hinge

Step 10: Attach the Doors
Step 11: Attach the Door Handles
Rest the hinges over their receiving hardware. Make sure the doors are right-side up.
Press the hinges into the hardware. They should just snap into place. See below.
Push end down onto
receiving hardware and
snap in place.
Insert the mounting screws from the
inside of the door. Fasten to the handle
on the other side.
Slide hinge up against
receiving hardware.

Step 12: Adjust the Hinges and Center the Doors
Adjustment 1: Move door to the left or right of the side panel.
Moves door left and right
Moves door left and right
Moves door
in and out
Moves door up/down
• Hinges are adjustable in 3 different locations.
• Each adjusts the position of the doors differently.
• Note the locations indicated in the image
TIPS:
• Coordinate your adjustments for top and bottom hinges
• Begin by maxing out each adjustment point
• Use manual screwdriver for fine-tune adjustments.
Use this adjustment to:
• Ensure a vertical center gap between doors
• Widen or narrow the center gap.
Note: The gap between the doors will taper, or slant, if the
top and bottom hinges are not equally adjusted
Door is adjusted too far to the right of
the side panel. This creates a larger gap
between the two doors.
Door is adjusted too far to the left of the
side panel. This creates a smaller gap
between the two doors

.
Adjustment 2: Move the door closer or farther away from the side panel.
Adjustment 3: Move the door up or down.
Use this adjustment to:
• Make the edges of the door parallel with the edges of the credenza.
• Widen or narrow the gap between the doors and credenza
Note: Check that the gap between the open door and side panel is
vertical and does not taper.
Use this adjustment to ensure that the doors are flush with the top
and bottom panels.
Tip: Leave the screws tight enough to hold the door in place, but
loose enough to remain adjustable.
Moves door
in and out
Moves door up/down
Door is adjusted to be farther away
from credenza.
Door is adjusted down and sits below
the top edge of the credenza
Door is adjusted up and sits above
the top edge of the credenza
Door is adjusted to be close to the credenza.

Step 13: Add Plastic Bumpers
Stick a small plastic bumper to the top corner of
each door. This will help with door adjustment
DONE!
