Inside Weather SOFETTE User manual

SOFETTE

Gather Your Eggs...
Note: Please retain all boxes until you are certain that your product isn’t damaged and that you
do not wish to return it. Disposal of boxes may prevent/delay our ability to resolve your request.
BACK PILLOWS
BACK PLATE
2 ARMS
SEAT CUSHIONS
INNER SUPPORT BRACE
FRONT PLATE
18 SLATS
A
A
B
B
C
CC
D
E
DE
F
F
G
G

You should have:
4x LEGS
4x CORNER BRACKETS
8x NEOPRENE
STICKY PADS
32x BUTTON HEAD HEX SCREW
(5 MM HEX BIT)
16x SOCKET HEAD CAP SCREW
DRILL + EXTENSION
5MM HEX BIT
4MM BALL HEAD BIT
USB CHARGER
Note: Drill may need to be charged before use
Note: Don’t be surprised if you find a few extra screws, washers and even an extra support brace
among your supplies. It’s just our way of being extra sure you have everything you need.

Stand the arm on its side.
Identify the corresponding hooks
located on the arm and back panel.
Align the arm and back panels
so that the wooden frames
meet at a right angle. Lean
the arm slightly away from the
back panel. Lift the top of the
back panel and gently lower
the hook until it connects.
Repeat on both sides.
Step 1: Connect the Arms
Connect the Hooks
This is how they connect.
The connection is the same
for both sides
Let’s start by connecting the arms to the back panel. Lay the back panel flat
on the floor, workbench or other stable surface with the metal strip is facing up.
The process is identical for both arms.

Connect the Arms (Continued)
Place a corner bracket to connect
the back and arm panels.
Put a 5mm button head socket cap
screw in each of the three holes in
the back panel. Losely hand tighten
only for now.
Screws will be tightened after they
have all been placed.
Connect the corner bracket to the
arm by hand-threading a button
head socket cap screw into each
of the three remaining holes.
Once all six screws have been
connected, use the drill to fasten
each bracket until secure.

Step 2: Install the Inner Support Brace
You’ll Need: 1x INNER SUPPORT BRACES
8x BUTTON HEAD SOCKET CAP SCREW (5 MM HEX BIT)

Install the Inner Support Brace (Continued)
Make sure the edges are flush
Hand tighten before finishing with
the drill to make sure everything is
properly aligned.
Line up the holes in the support
brace with the corresponding
holes on the frame.

Step 3: Attach the Front Plate
In this step we’ll be
adding the front plate.
But first let’s make sure
everything is ready!
FRONT PLATE
CORNER BRACKETS
5MM BUTTON HEAD SCREWS
1x
2x
12x
You’ll Need:
Set the front plate between the two
arms as shown. Make sure that the
flap of excess fabric is facing the top
of the couch and hanging toward the
inside of the frame.
This will ensure that the plate is
rotated correctly.

Attach the Front Plate (Continued)
Attach a corner bracket to
the front plate using 3 bolts.
Hand tighten only
Hold the corner bracket flat
against the front plate and
add 3 more bolts to attach
the bracket to the arm.
Use the drill to fasten each
bolt until secure. Repeat on
the other side.

Step 4: Install the Legs
Start by aligning the leg over the mounting holes. Insert
bolts into corresponding threaded holes as shown and
tighten by hand.
Note: if you have flared legs, make sure that each leg
points outward toward its respective corner.
Once each bolt is started by hand, use the
drill to finish securing the leg.
Repeat for all four legs.
4x LEGS
16x SOCKET HEAD CAP SCREW
You’ll Need: Note: Our legs are universal, and are used across
multiple products. All sofa and ottoman legs will
attach securely with 4 fasteners per leg.

Step 5: Add the Neoprene Pads
Slats should look like the
diagram after the pads
have been added.
To keep the cushions from sliding
add the non-slip neoprene pads.
2 pads will be stuck onto a slat.
Only 4 of the slats of the sofa will
need pads.
Please see diagram for correct
placement.

Step 6: Place the Slats
Step 7: Add the Cushions
DONE!
Lay a slat in each groove, as
shown. Be sure they arch upward.
NOTE: You may need to gently
coax some slats into place
depending on how tightly
everything has been assembled.
