Inside Weather MESA User manual

MESA LOUNGE CHAIR

Gather Your Eggs...
More Eggs...
Back Pillow Seat Cushion
Arm
Seat Base
Front Brace
Back Brace
Seat Back
Legs (2x)
Note: Please retain all boxes until you are certain that your product isn’t damaged and that you
do not wish to return it. Disposal of boxes may prevent/delay our ability to resolve your request.
1x Allen Key 9x 65mm Socket Head Screw
4x 45mm Socket Head Screw
2x 25mm Socket Head Screw
4x Wooden Dowel
2x Cam Lock Screw
2x Cam Lock Nut
15x Washer

Step 1: Attach Seat to Leg
Before you begin, be sure that you’re
assembling on a non-abrasive surface,
such as carpet or flattened cardboard.
Identify the front of the leg, it will have
three holes on the front rail. Place the
seat so that the side with the rounded
corners is facing the front of the leg.
Use three 65mm socket head
screws and three washers to
attach the seat to the leg with
the included allen key. Keep
the screws loose for now as
adjustments may be necessary.

Step 2: Attach Front Brace
Start by inserting two dowels in the leg as
shown. Next screw in a cam lock screw in
the hole in between the dowels.
Place a cam lock nut in the large hole in
the face of the front brace. Make sure the
arrow on the cam nut is facing the outside
as shown.
Install the front brace to the
leg by making sure the cam
lock nut is facing inward so
it will not be visible when
complete.
Once the brace is fully seated,
use a phillips screwdriver
to turn the cam lock nut
clockwise until tight.

Step 3: Attach Back Brace
Next insall the back brace as shown. This attaches to
the back of the seat base oriented so that the screw
inserts are facing down and the base extends up to
prevent the cushion from slipping.
Secure with three 65mm socket head screws and
three washers with the allen key. Keep loose in case
adjustments are nessary.
Start by securing two dowels and a
cam lock nut in the remaining side of
the front brace. Remember to make
sure the arrow on the cam lock nut is
facing out. Next place the remaining
cam lock bolt in the center hole of the
remaining leg.
You are now ready to place the leg on
the seat base. Align the cam lock bolt
and dowels and push the leg in place.
Once the leg is fully seated, use a
phillips screwdriver to turn the cam lock
nut clockwise until tight.
Underside of Seat Back Brace
Step 4: Attach the Second Leg

Step 5: Attach the Back to the Arm
Place the arm upside down on a non-abrasive raised surface, such as
table with cardboard on it, and allow the rear to hang off the edge
making room for the back to be located. Place the back on the rear of
the arm as shown and secure with two 25mm socket head screws and
washers using the allen key.
Use three 65mm socket head screws
and three washers to attach the seat
to the leg. At this point you can make
any adjustments necessary to ensure
everything is straight. Once adjustments
have been made you can now go
around and tighten all the screws that
attach the seat to the legs using the
allen key.
Step 4: Attach the Second Leg (Continued)

DONE!
Put the seat cushion and
back pillow on and you
are ready to sit.
Step 7: Flip it Over and Set the Cushions
Step 6: Attach the Back to the Arm
With the arm still in place and upside down place the frame on it upside
down as shown. Using the 45mm socket head screws and washers attach
the frame to the arm using the allen key. You can now flip the chair over
and place it on the ground.

Fabric Care Instructions
Cleaning Codes
Machine Washable
Spot Cleaning
SOLVENT OR WATER CLEANABLE (S/W)
WATER CLEANABLE (W)
SOLVENT CLEANABLE (S)
SPOT CLEAN ONLY (SC)
Spot clean with upholstery shampoo, foam from a mild detergent, or a mild dry cleaning solvent.
Spot clean fabric with a water-based shampoo or foam upholstery cleaner. Avoid over-wetting the stain.
Must be cleaned with solvents (dry clean only). Spot treat stains with a water-free solvent or
dry-cleaning product.
Cleaning depends on the nature of the stain. For oil-based spots, do not apply water and use dry
cloth. Recommended use of leather-specific solvents & cleaners.
Each fabric type has a specific cleaning code which can be found on the Free Swatch Page.
Many of our fabrics are machine washable. If a fabric is machine washable, it’ll be noted in the
cleaning instructions on the Free Swatch page. It must be Machine Wash - Cold. Use Cold Water
and a mild detergent on a low/gentle cycle. Hang dry all covers. Please note that every machine
wash adds wear to the fabric so it’s recommended to opt for spot cleaning prior to machine
washing whenever possible.
We recommend spot cleaning with either an upholstery shampoo, foam from a mild detergent, or
a mild cleaning solvent. Always hang to dry. When spills happen, blot immediately to remove the
spilled material. Clean spots or stains from the outside to the middle of the affected area (this prevents
circling). To prevent overall soiling, frequent vacuuming to remove dust and grime is recommended.
