ASSEMBLY AND SIMPLE PLUMBING
THIS PRODUCT BUILD IS RATED SUITABLE FOR DIY PURPOSES PROVIDING THE
CUSTOMER IS OF ABOVE AVERAGE SKILLS AND FEELS CONFIDENT IN THEIR
ABILTY. ONLY YOU THE CUSTOMER WILL KNOW THIS SO BEFORE ANY ATTEMPT
IS MADE TO ASSEMBLY READ THROUGH THE FOLLOWING PAGES IN DETAIL
THEN DECIDE. IF YOU HAVE ANY DOUBT USE THE SERVICES OF A PROFESSIONAL.
IN PICKING SUCH, ALLOW THEM TO DECIDE IF THEY ARE CAPABLE OF BUILD BY
FIRST SHOWING THESE INSTRUCTIONS TO THEM. ALWAYS GET THREE QUOTES.
REMEMBER THE BEST IS NOT ALWAYS THE CHEAPEST!
REMEMBER PLUMBERS PLUMB! 90% OF THIS JOB IS NOT PLUMBING!
ELECTRICAL CONNECTION TO HOUSE MAINS
WHEN YOUR ITEM IS ASSEMBLED ALWAYS USE THE SERVICES OF A FULLY QUALI-
FIED ELECTRICAL COMPANY TO COMPLETE CONNECTION FROM SHOWER TO
HOUSE SUPPLY. LAWS DEMAND IN MANY CASES YOU DO THIS AND YOUR WAR-
RANTY IS VOID REGARDS ELECTRICAL ITEMS IF THIS IS NOT UNDERTAKEN.
YOURS AND OTHERS SAFETY IS PARAMOUNT. NEVER ATTEMPT THIS YOURSELF.
DUE TO THE NATURE OF THIS PRODUCT WE HIGHLY ADVISE THE PURCHASE
AND FITTING OF A WATER SOFTENER
PLEASE READ ON NOW AND CHECK AGAINST YOUR ABILTY
For the latest fitting instructions please visit www.insigniarange.co.uk
Thank you for your recent purchase of an Insignia steam shower.
Please read this booklet with great care to ensure you get the
best out of your build and have a shower that will last for many
years to come!
Like everything, in order to obtain a first class product that will
serve you well for many years, the effort and correctness put into
the assembly will reflect in the uality of your finish. First remem-
ber what you need from your new item then remember this as
you build. The result will only be as good as the assembly!
OUR BADGE RATING IN TERMS OF DIFFICULTY OF ASSEMBLY BASED
ON CLIENT FEEDBACK
1 Badge = Very easy
2 Badges = Easy
3 Badges = Moderate
4 Badges = Harder than average
5 Badges = Professional skills re uired
This shower is rated 3 Badges
3 4

For the latest fitting instructions please visit www.insigniarange.co.uk
For the latest fitting instructions please visit www.insigniarange.co.uk
5 6
REMEMBER:
These showers are designed to be free standing and movable
from their location should you have need to replace anything. AL-
WAYS USE Flexible braided water inlet pipes at least a metre long
(not central heating plastic type! ) from
house supply to the shower and again flexible waste pipe to join
to your house waste. NEVER fix with rigid pipes, never fix the unit
to the wall.
DURING BUILD, LIKE ALL SHOWERS CORRECT SEALING IS IMPERATIVE.
ALWAYS FIT EASY TO GET TO TAP VALVES ON BOTH HOT AND COLD WA-
TER. THE SAME AS A DISHWASHER OR WASHING MACHINE THIS PRODUCT
SHOULD BE ISOLATED WHEN NOT IN USE
NOTE: From time to time these showers may have small differ-
ences from that of these instructions. Due to continuous improve-
ments and upgrades, this should not cause you any inconvenience
just sometimes extra commonsense needs applying as changes
1. 2 People
2. Scissors
3. Silicone Gun
4. Knife
5. Tape Measure
6. Spirit Level
7. Phillips Screwdriver
8. Drill
YOU WILL NEED
TOTAL ELECTRICAL REQUIREMENTS
Voltage Rating 220 -240AC
Fre uency Rating 50HZ
Power Rating 3.0KW
Other than steam generator
Internal Circuit Voltage is 12V
Internal Current Rating 0.17A
Your electrical contractor should understand ALL legal re uire-
ments of connection before undertaking any work or installation.
UNDER NO CIRCUMSTANCES UNDERTAKE THIS YOURSELF!!!
Note for electrician. This product comes with 13 amp plug(s) fitted
with RCD unit. We leave the way you prefer to connect this to your-
self due to continued additions to current regulations. As at October
2010 we offered two following alternatives.
1) Connect within current laws and IP directives using plug and RCD
provided with steam version or supply one for non steam version
2) (Preferred) Wire into isolated fused feed connecting directly to
the house consumer / service box. Remove the plug / RCD fitted and
ensure the Consumer unit has capabilities to replace RCD feature.
Always use protection against electrical surge. Your shower should
be treated the same as a home computer. A surge protector should
eradicate the possibility of either the transformer or computer con-
trol being burnt out because of this reason.
Please note earth is re uired and found on chassis of shower tray. A
further earth is re uired from Steam Generator unit. Each earth
must ground through power supply line.
Tools required

What’s In The Boxes?
Please check with pictures, some of the items have been assem-
bled by ourselves in order for ease of recognition as to what they
are and can be used as reference in later construction
1. Shower tray with electric box + steam Generator attached to
the underside
2. Roof section
3. Shower waste (part of fitting kit if purchased)
4. Overhead shower head fitted (loosely)
5. Shower hand held
6. Ozone box
7. 2 x screw packs
8. Foot Spa
9. Glass shelf pack
10. Extractor fan (fitted)
11. Brass nut
12. Hand shower riser bar
13. Shower hose
14. Foot Spa flexi hose
15. Operations handbook (not re uired all contained in write up)
16. 90 degree elbow for hand shower feed
Note: Protective film should be removed
Before starting the installation!
For the latest fitting instructions please visit www.insigniarange.co.uk For the latest fitting instructions please visit www.insigniarange.co.uk
7 8

For the latest fitting instructions please visit www.insigniarange.co.uk
Glass pack
2 x curved doors
1 x door handle pack
Lengths of glass seal trim
2 x magnet trim
2 x front upright columns
2 x corner columns
2 x door seals
For the latest fitting instructions please visit www.insigniarange.co.uk
Rear glasses x2 and 2 x top and bottom curve supports
9 10
Centre control column,
grab handle and back
seat rest.
Please note your front columns could have light
inserts in them
Please note: The order in which your items are packed
may not necessarily be the same as pictures above Please check

For the latest fitting instructions please visit www.insigniarange.co.uk
For the latest fitting instructions please visit www.insigniarange.co.uk
VERY IMPORTANT
Have you got everything? If not please contact your supplying
dealer now. Remember NEVER book your tradesman until every-
thing has arrived, been checked and is present. No replacement /
missing parts can obtained free of charge during or after build only
within the timescale permitted (48 hours after delivery) and always
BEFORE build.
GOT EVERYTHING AS YOU SHOULD?
GREAT NOW FOR BUILD PLEASE READ ON!
TO START.
Make sure you have a clear space, remember when finished and in
place you need access to check your build and able to pull the
shower out should you need to replace anything!
Take the shower tray remove all protective wrapping and fit waste.
If you purchased the fitting kit it is possible this could have been
already been fitted in the tray hole but please note it will only have
been for transport and will need sealing correctly and alignment
for your house waste. In the side of the waste supplied in the op-
tional fitting kit you will notice a spigot not seen on an ordinary
waste. This item is for the steam generator waste and will be con-
nected in instructions later.
Now on the surface the shower is to finally rest take the tray and
place accordingly. Level tray with water run off slightly towards the
drain. This is done by adjusting the feet fitted underside
11 12
Check Levels both
Tray Feet

When you are happy the tray is set up correctly you can now move
this out to a better working position. Careful not to trap skirt light
fitting if fitted
Taking now the left hand (as you look from the front) rear wall
shiny side inwards, it will have the holes for the foot massage and
rack please check against original picture at the start of instruc-
tions. Also take the centre column with appliances attached to it
and place on the shower tray. Silicone seal where these butt to
tray. Critical this is a complete seal!! Now using screws provided
attach the centre column to the left hand wall 4x screws. Silicone
seal this joint completely making sure silicone is IN FRONT OF
SCREWS so as no water can reach these and work it’s way out of
the threads.
Having completed this, place a further
2 x screws through the rear of bottom
left hand panel into the tray. Please
note slots are cut into channel should
you need slight adjustment. When
complete repeat this operation taking
the right hand panel again marked as
the left was and repeat procedure you
have just undertaken. You now have
the tray, centre column and both back
walls attached. You will now have the
centre column and 2 x back walls
firmly silicone sealed on each surface
they butt to and screwed together.
For the latest fitting instructions please visit www.insigniarange.co.uk
2 x screws placed through bottom of glass frame into shower tray
Taking
For the latest fitting instructions please visit www.insigniarange.co.uk
13 14
Screw through pre-cut
Your shower will now look
like this

Moving on to the top and bottom curved rails and the two upright
aluminium columns. Columns fit on each end of the exposed rear
panel glasses and will form the front part of the shower support.
Take one column and the bottom curved rail, at the bottom of
each upright you will see two slots, screw the upright to the curve
with screws supplied through slots. Taking the second column
screw this to the opposite end of the curve. NOTE PLEASE CHECK
YOU HAVE THE CORRECT WAY ROUND curve will have the FLAT
EDGE TO THE BOTTOM You will now have two upright columns at-
tached to one curved rail
For the latest fitting instructions please visit www.insigniarange.co.uk
Column showing “UP”
Now offer your assembly onto the front of the shower tray (as pic-
ture 2
nd
up) The columns will now fit snug to the end of the glass
rear panels. Note screw holes pre-drilled. Taking appropriate
screws screw the column to the glass panel frame. Repeat this at
the other end.
For the latest fitting instructions please visit www.insigniarange.co.uk
15 16
Screw column to curve rail not as picture but before it is placed on
tray as the second hole will not be assessable otherwise.
With columns and bottom curved rail in place you now need to fit
the side glasses. Taking one glass place seals on them as picture
below:

NOTE: 2 x seals press onto glass
When you have placed the seals correctly over glass edges offer
one up to the upright column you have just fixed to the rear glass
frame. Now firmly press into the channel found on the front.
For the latest fitting instructions please visit www.insigniarange.co.uk
When this stage is complete repeat the same assembly with the
second glass and again firmly press into the other channel.
Now take the 2 x front columns with grey plastic clips attached and
lights. Press one into the opposite end of the glass panel you have
just fixed and over the seal. NOTE. Make sure this is firmly home
with seal in place, lights go towards top with wires coming from
them. When you are sure the front column is correct and seal fully
in place, repeat opposite side. You now need to fix the top curved
rail. NOTE: Curved section fits to lower side. Top side has flat lip for
roof to sit on. Place in position insert the top grey clips very care-
fully so as not to break them and screw both ends to the top of the
end columns as you did with the bottom curved rail.
For the latest fitting instructions please visit www.insigniarange.co.uk
17 18
Column seal and glass press
into channel (shown in red)
Upright front columns (yours will have lights) now fitted before
fitting top rail

Offering up the top rail to slot into clips
For the latest fitting instructions please visit www.insigniarange.co.uk
You now need to fix the two front columns into place. Align the pre
drilled holes and screw into place as the picture below shows:
Picture shows top fixing repeat both sides and at the bottom as
well
Now your assembly is almost complete. Just the doors and roof
need fitting. Take one door, now fix wheels on this top and bottom
but leave all four loose. Fit door handle also. On the leading edge
fit 1 x magnet strip. On trailing edge fit “L” shaped steam retaining
seal. When complete offer the door into the channel runners and
note the wheels are on cams adjust each until the door runs
smoothly. Repeat the same procedure on the second door. NOTE
get magnet round the correct way the two doors need to attract
not repel! NOTE. Any gap between the doors can now be adjusted
to close perfectly by adjusting the second door wheel cams to
align.
For the latest fitting instructions please visit www.insigniarange.co.uk
19 20
Screwing top curved rail
into place
Shower top curve
section will now look like
this
