Intel PXA27x Series User manual

Intel®PXA27x Processor
Developer’s Kit
User’s Guide
April 2004
Revision 4.001
Order Number: 278827-005

ii
INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL® PRODUCTS. NO LICENSE, EXPRESS OR IMPLIED, BY
ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS GRANTED BY THIS DOCUMENT. EXCEPT AS PROVIDED IN
INTEL'S TERMS AND CONDITIONS OF SALE FORSUCH PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS
ANY EXPRESS OR IMPLIED WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR WARRANTIES
RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT OF ANY PATENT, COPYRIGHT OR OTHER
INTELLECTUAL PROPERTY RIGHT. Intel products are not intended for use in medical, life saving, life sustaining applications.
Intel may make changes to specifications and product descriptions at any time, without notice.
Designers must not rely on the absence or characteristics of any features or instructions marked “reserved” or “undefined.” Intel reserves these for
future definition and shall have no responsibility whatsoever for conflicts or incompatibilities arising from future changes to them.
The Intel®PXA27x Processor Developer’s Kit may contain design defects or errors known as errata which may cause the product to deviate from
published specifications. Current characterized errata are available on request.
This document and the software described in it are furnished under license and may only be used or copied in accordance with the terms of the
license. The information in this document is furnished for informational use only, is subject to change without notice, and should not be construed as a
commitment by Intel Corporation. Intel Corporation assumes no responsibility or liability for any errors or inaccuracies that may appear in this
document or any software that may be provided in association with this document. Except as permitted by such license, no part of this document may
be reproduced, stored in a retrieval system, or transmitted in any form or by any means without the express written consent of Intel Corporation.
Contact your local Intel sales office or your distributor to obtain the latest specifications and before placing your product order.
Intel, Intel logo, Intel XScale, Intel Mobile Scaleable Link, and Intel StrataFlash are trademarks or registered trademarks of Intel Corporation or its
subsidiaries in the United States and other countries.
*Other names and brands may be claimed as the property of others.
Copyright © Intel Corporation, 2004

iii
Contents
Contents
1 Introduction and Startup...............................................................................................................7
1.1 System Overview..................................................................................................................7
1.2 Document Organization........................................................................................................8
1.3 Getting Started......................................................................................................................8
1.4 Related Documents ..............................................................................................................8
2 Hardware Description .................................................................................................................11
2.1 User-Interface Panel...........................................................................................................12
2.2 Intel®PXA27x Processor Developer’s Kit Main Board.......................................................13
2.2.1 Power Input and Voltage Regulation .....................................................................21
2.2.2 System Reset ........................................................................................................21
2.2.2.1 Structure and Operation.........................................................................21
2.2.2.2 Initiating Reset .......................................................................................22
2.2.3 Flash Memory and Boot ROM ...............................................................................23
2.2.4 Main Board Registers and Interrupt Controller (FPGA).........................................23
2.2.5 Programmable Main Board Logic (CPLD2) ...........................................................24
2.2.6 LCD Panel and Interface .......................................................................................24
2.2.7 Universal Serial Bus Host and Client.....................................................................24
2.2.8 IrDA Infrared Transceiver ......................................................................................24
2.2.9 PCMCIA.................................................................................................................24
2.2.10 Audio Codecs ........................................................................................................25
2.2.10.1 Philips UCB1400* ..................................................................................25
2.2.11 Touch-Screen Controllers......................................................................................26
2.2.12 Keypad and Scroll-Wheel Interface .......................................................................26
2.2.13 MultiMediaCard* / Secure Digital* Card.................................................................27
2.2.14 Memory Stick* and Socket.....................................................................................27
2.2.15 USIM Connector ....................................................................................................28
2.2.16 Camera Header .....................................................................................................28
2.2.17 Bluetooth* UART / Radio Header ..........................................................................28
2.2.18 Baseband Header..................................................................................................28
2.2.19 Logic Analyzer Connectors....................................................................................28
2.2.20 Silent Alert* Motor Control .....................................................................................28
2.2.21 Custom Expansion Card Connector ......................................................................29
2.2.22 Ethernet* Controller ...............................................................................................29
2.2.23 Fault-Emulation Switches ......................................................................................29
2.2.24 General-Purpose Switches and LEDs ...................................................................29
2.2.25 Connectors ............................................................................................................30
2.2.26 Switches ................................................................................................................32
2.2.27 LED Indicators .......................................................................................................33
2.2.28 Test Points.............................................................................................................35
2.3 Intel®PXA27x Processor Developer’s Kit Daughter Card..................................................36
2.3.1 Power.....................................................................................................................39
2.3.1.1 Power Sources.......................................................................................39
2.3.2 SRAM ....................................................................................................................39
2.3.3 Programmable Daughter Card Logic (CPLD1)......................................................39
2.3.4 Stand-Alone I/O Interface ......................................................................................39

iv
Contents
2.3.5 Full-Featured RS-232 Serial Port ..........................................................................39
2.3.6 JTAG Interface.......................................................................................................40
2.3.7 Logic-Analyzer Interface........................................................................................40
2.3.8 System Configuration Register..............................................................................40
2.3.9 Connectors ............................................................................................................40
2.3.10 Jumpers.................................................................................................................41
2.3.11 Switches ................................................................................................................42
2.3.12 LED Indicators.......................................................................................................42
2.3.13 Test Points.............................................................................................................43
2.4 Intel®PXA27x Processor Card...........................................................................................43
2.4.1 SDRAM..................................................................................................................43
2.4.2 Flash Memory........................................................................................................43
2.4.3 Clock Sources........................................................................................................44
2.5 Power Management............................................................................................................44
2.5.1 Core-Voltage Control and PWR_I2C .....................................................................44
2.5.2 PMIC Card Jumper Settings..................................................................................46
3 Programming Guide....................................................................................................................47
3.1 Memory Map and Chip Selects...........................................................................................47
3.2 Platform-Level Registers ....................................................................................................49
3.2.1 Virtual Configuration Registers..............................................................................50
3.2.1.1 System Configuration Register (SCR)...................................................51
3.2.1.2 System Configuration Register 2 (SCR2)..............................................52
3.2.2 Memory-Mapped Main Board Registers................................................................53
3.2.2.1 Hex LED Data Register 1 (LEDDAT1)...................................................53
3.2.2.2 Hex LED Data Register 2 (LEDDAT2)...................................................54
3.2.2.3 LED Control Register (LEDCTRL).........................................................55
3.2.2.4 General-Purpose Switch Register (GPSWR).........................................56
3.2.2.5 Miscellaneous Write Register 1 (MSCWR1)..........................................57
3.2.2.6 Miscellaneous Write Register 2 (MSCWR2)..........................................59
3.2.2.7 Miscellaneous Write Register 3 (MSCWR3)..........................................60
3.2.2.8 Miscellaneous Read Register 1 (MSCRD1)...........................................61
3.2.2.9 Platform Interrupt Mask/Enable Register (INTMSKENA).......................63
3.2.2.10 Platform Interrupt Set/Clear Register (INTSETCLR) .............................65
3.2.2.11 PCMCIA Socket 0/1 Status/Control Registers (PCMCIAx)....................67
3.2.2.12 FPGA Revision ID (REVID) ...................................................................68
3.2.2.13 Scratch Registers1/2/3 (SCRATCH1/2/3)..............................................69
3.3 Processor Registers ...........................................................................................................69
3.3.1 Memory-Control Registers.....................................................................................69
3.3.1.1 SDRAM Configuration Register (MDCNFG)..........................................71
3.3.1.2 SDRAM Mode Register Set Configuration Register (MDMRS) .............71
3.3.1.3 SLP SDRAM Mode Register Set Configuration Register (MDMRSLP).71
3.3.1.4 SDRAM Memory Device Refresh Register (MDREFR).........................72
3.3.1.5 Static Memory Control Register 0 (MSC0).............................................73
3.3.1.6 Static Memory Control Register 1 (MSC1).............................................74
3.3.1.7 Static Memory Control Register 2 (MSC2).............................................74
3.3.1.8 Expansion Memory Configuration Register (MECR) .............................74
3.3.1.9 Synchronous Static Memory Configuration Register (SXCNFG)...........75
3.3.1.10 Expansion Memory Timing Configuration Registers..............................75
3.3.2 LCD-Control Registers...........................................................................................76
3.3.2.1 LCD Controller Control Register 0 (LCCR0)..........................................76
3.3.2.2 LCD Controller Control Register 1 (LCCR1)..........................................77

v
Contents
3.3.2.3 LCD Controller Control Register 2 (LCCR2)..........................................77
3.3.2.4 LCD Controller Control Register 3 (LCCR3)..........................................77
3.3.2.5 LCD Controller Control Register 4 (LCCR4)..........................................77
3.3.2.6 LCD Controller Control Register 5 (LCCR5)..........................................78
3.4 Developer’s Kit Platform-Level Interrupts ...........................................................................78
3.5 General Purpose Input/Output (GPIO) ...............................................................................81
3.6 Programming Flash Memory and Logic Devices................................................................85
3.6.0.1 Preparing the Hardware.........................................................................85
3.6.0.2 Preparing the Host Computer ................................................................85
3.6.0.3 Obtaining the Required Programming Files...........................................85
3.6.1 Flash Memory........................................................................................................86
3.6.2 CPLD1 (Processor Card).......................................................................................86
3.6.3 CPLD2 (Main Board) .............................................................................................86
3.6.4 FPGA Configuration EEPROM (Main Board) ........................................................87
Figures
1 Intel®PXA27x Processor Developer’s Kit Overview .................................................................12
2 Block Diagram, Intel®PXA27x Processor Developer’s Kit Main Board......................................15
3 Main Board and Daughter Card functionality..............................................................................16
4 Connectors, Intel®PXA27x Processor Developer’s Kit Main Board - Top .................................17
5 Connectors, Intel®PXA27x Processor Developer’s Kit Main Board - Bottom............................18
6 Switches, Intel®PXA27x Processor Developer’s Kit Main Board...............................................19
7 LEDs, Intel®PXA27x Processor Developer’s Kit Main Board ....................................................20
8 Intel®PXA27x Processor Developer’s Kit Reset Structure ........................................................22
9 PCMCIA Interface Structure.......................................................................................................25
10 Keypad diagram..........................................................................................................................27
11 Block Diagram, Intel®PXA27x Processor Developer’s Kit Daughter Card ................................37
12 Connectors, Intel®PXA27x Processor Developer’s Kit Daughter Card .....................................38
13 Intel®PXA27x Processor Developer’s Kit Interrupt Scheme A ..................................................79
14 Intel®PXA27x Processor Developer’s Kit Interrupt Scheme B ..................................................80
Tables
1 Supplemental Documentation.......................................................................................................8
2 Connectors, Intel®PXA27x Processor Developer’s Kit Main Board...........................................30
3 Switches and Settings, Intel®PXA27x Processor Developer’s Kit Main Board..........................32
4 LED Indicators, Intel®PXA27x Processor Developer’s Kit Main Board .....................................33
5 Test Points, Intel®PXA27x Processor Developer’s Kit Main Board...........................................35
6 Power Sources on the Intel®PXA27x Processor Developer’s Kit Daughter Card .....................39
7 Connectors, Daughter Card........................................................................................................40
8 Jumper Headers, for the Processor Card...................................................................................41
9 Switches and Settings, Daughter Card.......................................................................................42
10 LED Indicators, Daughter Card...................................................................................................42
11 Test Points, Daughter Card........................................................................................................43
12 Programmable DC_CORE Voltages...........................................................................................44
13 Processor Physical Addresses and Chip Selects.......................................................................47
14 Platform-Level Register Summary..............................................................................................49
15 Summary of Virtual Configuration Registers...............................................................................50
16 SCR Bit Definitions.....................................................................................................................51
17 SCR2 Bit Definitions...................................................................................................................52
18 LEDDAT1 Bit Definitions.............................................................................................................53

vi
Contents
19 LEDDAT2 Bit Definitions ............................................................................................................54
20 LEDCTRL Bit Definitions ............................................................................................................55
21 GPSWR Bit Definitions...............................................................................................................56
22 MSCWR1 Bit Definitions.............................................................................................................57
23 MSCWR2 Bit Definitions.............................................................................................................59
24 MSCWR3 Bit Definitions.............................................................................................................60
25 MSCRD Bit Definitions ...............................................................................................................61
26 INTMSKEN Bit Definitions High Bits...........................................................................................63
27 INTMSKEN Bit Definitions Low Bits ...........................................................................................63
28 INTSETCLR Bit Definitions High Bits .........................................................................................65
29 INTSETCLR Bit Definitions Low Bits..........................................................................................65
30 PCMCIA0/1 Bit Definitions..........................................................................................................67
31 FPGA Bit Definitions...................................................................................................................68
32 Scratch Register Bit Definitions..................................................................................................69
33 GPIO Map...................................................................................................................................81

Intel®PXA27x Processor Developer’s Kit - User’s Guide 7
Introduction and Startup 1
The Intel®PXA27x Processor Developer’s Kit (kit), constitutes a software-development kit based
on Intel®PXA270 Processor. This kit provides all of the system components necessary for
Microsoft Windows* CE, Symbian*, Palm*, Linux, and other full-featured, handheld operating
system.
Note: The kit comes with a factory installed the Intel®PXA270 Processor.
The Intel®PXA270 Processor is the third implementation of the Intel XScale®microarchitecture
family, featuring an improved LCD controller, expanded card interface, and more conservative
power management features. It is also the first processor in the family to include a baseband
interface, integrated SRAM, a camera capture interface, scalable core frequencies, USB On-the-Go
(OTG), full SDIO support, and an Intel coprocessor. The coprocessor extends the Intel XScale®
microarchitecture capabilities by adding MMX and SSE functionality and additional audio and
video processing operations.
1.1 System Overview
The kit provides access to most of the Intel®PXA270 Processor native input/output (I/O)
functions. The kit kit consists of:
•Intel®PXA27x Processor Developer’s Kit Main Board (main board), which contains
peripheral and expansion capability to aid in application software development
•Intel®PXA27x Processor Developer’s Kit Daughter Card (daughter card), which can either
dock with the main board or operate independently
•Intel®PXA27x Processor Card (processor card), which is a board to allow for field upgrades
to the kit system as new steppings of silicon arrive.
•Intel®PXA27x Processor Developer’s Kit Power Manager Integrated Circuit (Low DropOut)
Card (PMIC card) card, which supplies all the various power domains for the system
•Intel®PXA27x Processor Developer’s Kit UCB1400 Audio Module (audio module), which
allows for the changing of audio CODECs depending on system usage.
•AC-to-DC power supply
•Hinged, fold-out user-interface panel containing the following:
— LCD panel
— touch screen
— matrix keypad and scroll wheel
— microphone and speaker
— video camera
•Mounting chassis that integrates all kit components into a compact, accessible package

8Intel
®PXA27x Processor Developer’s Kit - User’s Guide
1.2 Document Organization
This user’s guide contains the following chapters:
Chapter 2, “Hardware Description” describes the kithardware in detail.
Chapter 3, “Programming Guide” provides instructions for using the kit.
Note: Previous versions of this user’s guide included a chapter on using the Power-On Self Test (POST)
software. The description of the POST software and other diagnostic tools is now located in the
Diagnostics for Intel® PXA27x Processor Developer’s Kit User’s Guide.
1.3 Getting Started
The Intel®PXA27x Processor Developer’s Kit Quick Start Guide, packed with the kit, contains an
up-to-date packing list and instructions for setting up and starting the system. The Quick Start
guide also contains updates that became available after the publication of this User’s Guide.
The kit contents include:
•Chassis (Fastap* keypad + camera, QVGA display)
•Main Board
•Daughter Card
•Intel®PXA27x Processor Card
•PMIC LDO card
•Audio Module
•Intel®JTAG Cable1
•Basic accessory kit (keyboard, SD card)
1.4 Related Documents
Effective use of the kit frequently requires reference to the manufacturer’s data sheet for a device.
Table 1 lists the data items that might be required and the sources for obtaining them.
1. The Intel JTAG Cable that is provided with this kit can only be used with the Intel®PXA27x Processor Developer’s Kit.
Table 1. Supplemental Documentation (Sheet 1 of 2)
Item Source
Infineon Mobile-RAM* SDRAM memory devices
HYB25L356160AC - 7.5 http://www.infineon.com
Agilent IrDA infrared transceiver HSDL - 3600 #007 http://www.agilent.com
IrDA* infrared transceiver http://www.agilent.com
Agilent ADM-2650 VGA Camera module http://www.agilent.com
Intel®flash memory devices http://developer.intel.com

Intel®PXA27x Processor Developer’s Kit - User’s Guide 9
Intel®PXA270 Processor Electrical, Mechanical, and Thermal
Specification
Intel®PXA27x Processor Family Developer’s Manual
Intel®PXA27x Processor Developer’s Kit Quick Start Guidea
Intel®PXA27x Processor Developer’s Kit Parts List
Intel®PXA27x Processor Developer’s Kit Schematics
Diagnostics for Intel® PXA27x Processor Developer’s Kit User’s
Guide
For order numbers, see the Intel®
PXA27x Processor Developer’s Kit
Quick Start Guide
Liteon seven-segment hex LED displays http://www.liteon.com
Maxim MAX1602* data sheet http://www.maxim-ic.com
Open HCI - Open Host Controller Specification for USB. http://www.usb.org
Universal Serial Bus Specification http://www.usb.org
PCMCIA/JEIDA PC Card Standard, Volume 2, Electrical Specification http://www.pcmcia.org
Philips UCB1400* CODEC http://www.philipssemiconductor.com
Philips ISP1301 USB OTG transceiver http://www.philipssemiconductor.com
Standard Microsystems Ethernet controller LAN91C111 http://www.smsc.com
Toshiba LCD panel LTM035A776C http://www.toshiba.com
Xilinx* XPLA3 & Spartan II http://www.xilinx.com
Dialog Semiconductor Arava®PMIC http://www.dialog-
semiconductor.com
a. Refer to this document for additional information on socketed processor cards.
Table 1. Supplemental Documentation (Sheet 2 of 2)
Item Source

Intel®PXA27x Processor Developer’s Kit - User’s Guide 11
Hardware Description 2
This chapter describes the Intel®PXA27x Processor Developer’s Kit (kit) hardware.
•Section 2.1 — User-Interface Panel
•Section 2.2 — Intel® PXA27x Processor Developer’s Kit Main Board
The Intel®PXA27x Processor Developer’s Kit Main Board (main board) serves as the
docking station for an Intel®PXA27x Processor Developer’s Kit Daughter Card (daughter
card) to make it easier for you to develope many different types of applications. The main
board features peripheral devices, sockets for various expansion cards, extensive input/output
(I/O) capability, and user-interface aids.
•Section 2.3 — Intel® PXA27x Processor Developer’s Kit Daughter Card
The daughter card contains the Intel®PXA27x Processor Card (processor card), memory,
nominal I/O capability, and the required power circuitry Intel®PXA27x Processor
Developer’s Kit Power Manager Integrated Circuit (Low DropOut) Card (PMIC card) for two
modes of operation:
— When docked with the main board, the daughter card provides a complete development
and evaluation system.
— In self-contained (stand-alone) mode, the daughter card can boot and function
independently of the main board, although without the extensive I/O capability furnished
by the main board.
•Section 2.4 — Intel® PXA27x Processor Card
•Section 2.5 — Power Management
Figure 1 shows an overview of the kit.

12 Intel®PXA27x Processor Developer’s Kit - User’s Guide
Figure 1. Intel®PXA27x Processor Developer’s Kit Overview
Note: Figure 1 does not show the camera module.
The instructions in this chapter and in Chapter 3, “Programming Guide” provide enough details to
start operating with minimal effort. In most cases, however, the optimal use of a device requires
detailed reference to the device manufacturer’s data sheet. To locate this information, refer to
Table 1, “Supplemental Documentation” on page 8.
Using this kit effectively requires a sound knowledge of the Intel XScale®technology and the
Intel®Micro Signal Architecture baseband processor. Refer to the Intel®PXA27x Processor
Family Developer’s Manual for items related to the applications processor.
Note: Most of the switches on the main board are SPDT slide switches with one of the positions
identified by a DOT. Switch positions are thus indicated as DOT or NO DOT. The switches on the
daughter card are DIP switches and are indicated as ON or OFF.
2.1 User-Interface Panel
The user-interface panel, shown in Figure 1, contains the following items:
•LCD Panel
The liquid-crystal display panel is mounted on an adapter board, which slides in and out of the
user-interface panel for operation in either landscape or portrait orientation. (Figure 1 shows
the LCD Panel in landscape orientation.) There is a separate connector for each orientation.
The LCD Panel connects from J2 on the keypad card to J17 on the main board by a ribbon
cable. For more information, see Section 2.2.6.
A9893-01
Speaker LCD Board
LCD Panel Landscape Connector
Scroll Wheel
I/O Baseboard
Microphone
Power Supply
Keypad

Intel®PXA27x Processor Developer’s Kit - User’s Guide 13
•Touch Screen
The touch-screen module, integrated with the LCD panel, connects from J2 on the keypad card
to J17 on the main board by a ribbon cable. For more information, see Section 2.2.11.
•Fastap* Keypad and Scroll Wheel
The Fastap keypad adapter board contains a 75-button, 7x7 matrix keypad (see Section 2.2.12)
and a rotary-encoded scroll wheel (see Section 2.2.12).
These items are connected from J4 on the keypad card to J11 on the main board by ribbon
cables.
•Microphone and Speaker
A speaker and a microphone, mounted on the keypad adapter board, interface with the audio
codecs on the main board (see Section 2.2.10).
These items are connected from J4 on the keypad card to J11 on the main board by ribbon
cables.
•Camera Module
A module that you can use to connect a camera.
2.2 Intel®PXA27x Processor Developer’s Kit Main
Board
The main board hosts a daughter card. The daughter card hosts a processor card and a PMIC card.
The main board provides the expansion and I/O functionality for a full-featured development
system. The main board includes these features:
•Transparent plastic cover and convenient layout for easy access to components
•Daughter card connectors
•2 programmable logic devices for platform-level control, registers, and interrupts
•32 Mbytes of Intel StrataFlash®memory
•Dual PCMCIA card cage and interfaces
•MultiMediaCard*, Secure Digital*, and SDIO connector
•Sony Memory Stick* connector
•Custom expansion-card connector
•Audio codec connectors and interfaces:
— Two line inputs, headset, and speaker/headphones
— Support for AC’97 or I2S CODEC line
— panel-mounted microphone and speaker
•Synchronous serial protocol (SSP) headers
•10/100 Mbps Ethernet* controller
•Universal Subscriber Identity Module* (USIM)
•Standard I2C header
•IrDA infrared transceiver, capable of fast (FIR) and slow (SIR) modes

14 Intel®PXA27x Processor Developer’s Kit - User’s Guide
•USB Host connector
•USB Client connector with software-controlled connection capability
•USB On The Go Transceiver and connector
•Bluetooth* UART / Radio header
•Baseband header
•LCD connector
•Camera Interface Header
•Matrix keypad and scroll-wheel connectors
•Silent Alert* motor-control header
•Logic-analyzer connectors
•8 discrete general-purpose switches
•8 discrete general-purpose LEDs
•2 hexadecimal-encoded rotary switches
•8-digit, seven-segment hex LED display
Figure 2 shows the main board’s organization in a block diagram.
Figure 3 through Figure 6 show the main board’s layout and the locations of all user-related items.

Intel®PXA27x Processor Developer’s Kit - User’s Guide 15
Figure 2. Block Diagram, Intel®PXA27x Processor Developer’s Kit Main Board
B1545-01
Switch Switch Switch Switch Switch Switch Switch Switch
Secondary Connector
PERIPHERAL_APP
USB
Host [0]
USB
Client
USIM /
UICC
SSP
Header
I2C
Header
USB
OTG
Camera
Header
HGO Marathon
Graphics
Accelerator
LCD / Backlight /
Touch Connector
SD / MMC
Memory Stick
Analog Mux Analog
Mux Analog
Mux
USB OTB
XCVR
XCVR
Buffer
XCVR
XCVR BUFFER XCVR BUFFER
BUFFER BUFFER
Expansion
Connector
Logic
Analyzer
Headers
USB Client /
ICAT
3.15V MSL
Baseband
Header
Keypad /
Camera / Misc /
Spkr Connector
FPGA
Header
RJ45
Audio Codec
Board and
Touchscreen
128/256 Mbit
@ 16/32
nCS1/0
UART
DB-9
PCMCIA
Slot 1
3.15/5.0V
PCMCIA
Slot 0
3.15/5.0V
nC95
Buffer Buffer
Bluetooth
Conector
DATA_APP_MAIN [31:0]
ADDRESS_APP_MAIN [25:0]
CONTROL_APP_MAIN CONTROL_APP_FPGA
EEPROM
EEPROM
Test Quest
Switch
Pads
Power Subsystem
Main_1.8V
2.5V (FPGA / CPLD core)
Main_3.15V
Main_5V (PCMCIA)
SIM 1.8 / 3V
Wall Supply Jack
Silent
Alert
Header
PCMCIA_CONTROL
PERIPHERAL_COMM
Primary Connector
IrDA
Controlled by
FPGA
RS-232 M
UART2/
UART3
I2S / I2C / SSP
I2S / I2C / SSP
AC'97 / I2S
I2C / SSP1 /
SSP2 / SSP3
CPLD2
PCMCIA Glue
PCMCIA xcvr control
Memory Bus xcvr control
UARTs mux
Audio Board Logic
3.15V l/0, 5V tolerant
FPGA
Flash
Platform Registers,
PCMCIA power control
nCS2L
Ethernet
10 / 100
nCS4
JTAG_BASEBOARD
For for FPGA reconfiguration
(and system reset)
For swapping App Processor
nCS0/nCS1
For
UART
mux
control
For shifting Address Bus
for 16/32bit access
PROM JTAG
I/OFPGA JTAGI/O
I/OI/O
I/O
I/O
I/O
RS-232 M
I/OI/O
CPLD JTAG
I/OI/OI/O
For EEPROM
control
Switch
Switch
For asserting App Processor
VDD_BATT_FLT
Switch Switch
Switch
Switch Switch Switch
Switch Switch Switch Switch
20 MHz
Osc
Hex
Rotary
Switch
Hex
Rotary
Switch
LEDLED LED LED LED LED LED LED LED
USBH0
USBHC
USIM
SSPI
I2C
SD/MMC
MS
SSP1 SSP1/
Camera
USIM/
Camera
Camera
L_DD / PWM0 Keypad &
Camera
LCD
Intel®PXA27x Processor
SSP2 PCM
Audio
Camera
USIM
SD/MMC/
MS
ADDRESS_APP_FPGA
DATA_APP_MAIN[31:0]
Baseband
USB

16 Intel®PXA27x Processor Developer’s Kit - User’s Guide
Figure 3. Main Board and Daughter Card functionality
B1546-01
I2S Audio *
BT UART/UART2 *
BT PCM (audio)
USB_C
AUDIO PCM
* This device interface can be muxed
(to Communication Processor or Application Processor)
** Other names and brands may be claimed as property of others.
Main Board JTAG
PCMCIA Ctrl
Power Daughter Card
PMIC
To main
connector
Communications
Portion Applications
Portion
Secondary Connector
I2S / AC97 Audio *
BT UART / UART2 *
Memory Stick
SD / MMC
Camera Connection
Touch Screen Digitizer
Ethernet
PCMCIA
Expansion Connector
IrDA
Asynchronous Flash
I2C Header
SSP Header
LCD Connector
USB Client
USB Host[0]
USB OTG
Keypad
UICC
Audio CPLD2
EEPROM
FPGA
Primary Connector
Buffers
JTAG ICE
RS232
XCVR
CPLD1/
JTAG
Isolate
Intel®
PXA27x
Processor
Intel®PXA27x
Processor Card
CPLD1
Flash
32MB @ 32
SDRAM
64MB @ 32
SRAM
1MB @ 32
CPU JTAG
Full Bandwidth MSL/PCMCIA
3.0V I2C
I2C Power
3.0V 12C
V
SRAM
1.8V
I2S
CODEC
AC97
CODEC
Line
in/out
Line
in/out
Linear
CODEC
V
PLL
1.2V
V
Core
1.2V
V
IO
2.8V
V
SRAM
1.3V
V
PLL
1.1V
V
Core
.8-1.3V
V
IO
3.0V
I2C
PCM
4x SPIO & USB_C
Application Peripheral Bus
UART1
Conn.
Memory Bus
From/To Mainboard
RF Module Conn.
JTAG PADS
HSL Conn.JTAG ICE
SIM1
AD6521
Analog Chip
13MHz OSC
32KHz OSC
RS232
XCVR
Quick
Switch
ISRAM
4MB @ 16
Flash
8MB @ 16
Linear
CODEC
Communication
Processor
CPU JTAG
RF
VCTCXO
Out
mic spk Hand
set Hand set
DSPJTAG
CPU JTAG
Memory Bus
Communication Peripheral Bus
UART1
Conn.
Bottom
Conn.
Digital InfAnalog I/O &Digital Cont
External Power Supply / Charger
5V / Charger
VBAT

Intel®PXA27x Processor Developer’s Kit - User’s Guide 17
Note: The “2” in J12 was inadvertently left off during the silkscreening of J12, causing it to appear as
“J1” in Circuit Revision 2.1 of the main board. J1 is the processor USB Client connector and is
located near the covered J4 USB host 0 connector, while J12 is a reserved USB Client connector,
and is located near the J13 USB On the Go (OTG) connector. While the J13 connector is visible,
the J13 silkscreening is covered with components and may be difficult to locate. Use Figure 4 to
locate these connectors.
Figure 4. Connectors, Intel®PXA27x Processor Developer’s Kit Main Board - Top
CPU
ECO Sticker
J11
J9
J18
J15
J25
J17
J20
J26
J40
J43
J21
J62
J61
J60
J23
J14
J8 J7J6J5 J2 J3 J4 J1
J12
J13
J22
J24 J54
J55
J57
J58
J59
J32
J47
J46
J45
J56
J41
J39
J44
J42
J33 J34 J35
J29 J30 J31
J38 J37
J36
J28
J27
J10

18 Intel®PXA27x Processor Developer’s Kit - User’s Guide
Figure 5. Connectors, Intel®PXA27x Processor Developer’s Kit Main Board - Bottom
J48
J49
J50
J51
J53
J52

Intel®PXA27x Processor Developer’s Kit - User’s Guide 19
Figure 6. Switches, Intel®PXA27x Processor Developer’s Kit Main Board
SW22
SW21
SW20
SW19
SW18
SW17
SW16
SW15
SW14
SW13
SW12
SW11
SW10
SW9
SW8
SW7
SW6
SW5
SW1 SW3 SW2 SW4

20 Intel®PXA27x Processor Developer’s Kit - User’s Guide
Figure 7. LEDs, Intel®PXA27x Processor Developer’s Kit Main Board
D1
D2
D3
D4
D5
D6
D7
D8
D9
D10
D11
D12
D20
D22
D23
D15D14
D18D17
D13
D16
D19
D21
D24
D25
