Invacare Dolomite Jazz 510 User manual

Jazz510,Jazz610
ENRollator UserManual

Contents
1General......................................4
1.1Aboutthismanual..........................4
1.2Intendeduse..............................4
1.3ServiceLife...............................5
1.4Scopeofdelivery...........................5
1.5Warranty................................5
2Safety........................................6
2.1GeneralWarnings..........................6
2.2Labelsandsymbolsontheproduct..............6
3Usage........................................7
3.1Beforeuse................................7
3.2Unfoldingtooperatingposition.................7
3.3Folding..................................7
3.4Walking..................................7
3.5Sittingdownonachair.......................8
3.6Risingtoastandingposition...................8
3.7Sittingontherollator........................8
3.8Transportingtherollator.....................9
3.9Adjustingthehandleheight....................9
3.10UsingtheHeightAdjustmentMemory............10
3.11Usingthehandbrakes.......................11
3.12Adjustingthebrakeeffect.....................11
3.13Usingthekerbclimber.......................11
3.14Mountingthebasket.........................12
3.15Removingtheseatcushions...................13
4Maintenanceandcare..........................14
4.1Maintenance..............................14
4.2Care....................................14
5AfterUse.....................................15
5.1Disposal.................................15
5.2Re-use...................................15
6Technicaldata.................................16
6.1Dimensionsandweights......................16
6.2Material..................................16

Dolomite® Jazz
1General
1.1Aboutthismanual
ThisUserManualcontainsimportantinformationaboutyour
product.Inordertoensuresafetywhenusingtheproduct,readthe
UserManualcarefullyandfollowthesafetyinstructions.
Thepersonwhoprescribestheproductorwhoisotherwise
responsiblefortheusermustensurethattheproductissuitablefor
theuser.Theusershallbeinstructedhowtousetheproduct.This
includestheuseofthefeaturesandtherestrictionsinuse.Theuser
shallalsobenotifiedofthewarningsforusegivenintheusermanual.
Symbolsinthismanual
InthisUserManualwarningsareindicatedbysymbols.Thewarning
symbolsareaccompaniedbyaheadingthatindicatestheseverity
ofthedanger.
WARNING
Indicatesahazardoussituationthatcouldresultin
seriousinjuryordeathifitisnotavoided.
CAUTION
Indicatesahazardoussituationthatcouldresultin
minororslightinjuryifitisnotavoided.
IMPORTANT
Indicatesahazardoussituationthatcouldresultin
damagetopropertyifitisnotavoided.
TipsandRecommendations
Givesusefultips,recommendationsandinformation
forefficient,trouble-freeuse.
ThisproductcomplieswithDirective93/42/EEC
concerningmedicaldevices.Thelaunchdateofthis
productisstatedintheCEdeclarationofconformity.
1.2Intendeduse
Indications
Therollatorisintendedforsupportandimprovementofarestricted
walkingability.Theuser’sremainingwalkingabilityneedstobe
sufficientforleavingthehome,forusualdailyactivitiesandfor
participatinginsociallifewithoutendangeringthemselvesorothers.
Therollatorisintendedtosupportapersonduringwalkingandmay
alsoserveasarestingseat.Furthermoretherollatorisintendedto
carryaloadeitherinaspeciallydesignedbasketoronatray.
Themax.userweightis150kg.Thisweightlimitationincludesthe
weightoftheuser(whetherstandingorsitting)andthecontentof
thebasket.
Contraindications
TheRollatorisnotintendedforusebypersonswithsevere
equilibriumdisordersorfunctionalperceptualdisorders.
Permissibleoperatingconditionsandlocations
Therollatorisonlyintendedforuseindoorinlivingorpublicareas
oroutdoor.Itcanbeusedoutdoor,iftheuser’sremainingwalking
abilityissufficientforleavingthehome.Therollatorisnottobe
usedunderwaterine.g.poolsoropen-airbath,neitherinhotareas
ase.g.saunas.
4
1560692-A

General
1.3ServiceLife
Theexpectedservicelifeofthisproductisfiveyearswhenused
inaccordancewithsafetyinstructions,maintenanceintervalsand
correctuse,statedinthismanual.Theeffectiveproductlifecyclecan
varyaccordingtofrequencyandintensityofuse.
1.4Scopeofdelivery
•Rollatorwithstandardbasket1,seatcushion,kerbclimberand
backstrap2,fullyassembled.
•Usermanual
1
notinDenmark,Norway,FinlandandSweden. 2
onlyinUKandCanada.
1.5Warranty
Wesupplyatwoyearwarranty*fromthedateofdelivery.Damage
causedbyweartoitemssuchaswheels,handlesandbrakesisnot
coveredbythewarranty.Damagethatarisesduetoabnormaluseis
excluded.Damagecausedbyuserswhoweighmorethanmax.user
weightisexcluded.Maintenanceandoperatinginstructionsmustbe
observedforthewarrantytobevalid.
*Deviationsmayoccurduetolocalagreements.
1560692-A5

Dolomite® Jazz
2Safety
2.1GeneralWarnings
WARNING!
Riskoffalling
–Exercisecautionwhenwalkingonsloping/slippery
groundandonunevensurfaces.
–Donotusetherollatorasawheelchair.
–Becarefulwhenwalkingrearwardsoverobstacles.
–Neversitandpushwithyourfeet.
–Donotgoupordownstairswiththerollator.
–Donotusetherollatoronescalators.
–Donotunderanycircumstancesstandontherollator.
–Becarefulwhenusinglongskirts,theclothesmightget
stuckinthewheels.
–Loadsmustonlybetransportedinthebasketoron
thetray.Becarefulwhenthereisaheavyloadin
thebasket(forthemax.loadinthebasketreferto
chapter6Technicaldata,page16).
WARNING!
Riskofinjury
–Donotletchildrenplaywiththerollator.
–Ifthepushhandlesortheseatareexposedtoextreme
temperature(above41°C)theremightberiskforfirst
degreeburns.
IMPORTANT!
Riskofcorrosion
–Therollatormustnotbestoredoutsideinwetclimate
orinhumidenvironmentsforalongperiodoftime.
2.2Labelsandsymbolsontheproduct
HMI NR. xxxxx
(xx)xxxxxxxxxxxxxx(xx)12HXAxxxxxx
x x x x x x x x x x x x
x
XXXXXXX-XX-XX
XXXX-XXX
Xxxxxxxx Xxxxxxx x XX
xxxxxx xxxxx xxxxxx
XXXXXXxxxx
Xxxxxx
XXXXXXXXXXXX
xxxxxx xxxxx xxx
A
CB
D H I
J
K
L
M
GE
F
O
N
Thelabelcontainsallimportanttechnicalinformationregardingyour
rollator.
AArticlenumber
BProductname
CManufacturer’sname
DSerialnumber
EBarcode(Code128)
FBarcode(GSI-13)
GDateofmanufacture
HLocalIDnumber(DK)
IHeightadjustmentrange
JMax.userweight
KIn-andoutdoorrollator
LMax.widthofrollator
MRefertousermanual
NHeightadjustmentwarning
ODonotapplytheparking
brakeduringheightadjustment
61560692-A

Usage
3Usage
3.1Beforeuse
Wedonotrecommendthattheproductisissuedtoanyonewithout
firstcarryingoutafullassessmentoftheirspecificneeds.Itis
importantthattheuserisgiventhenecessarysupportbytheproduct
asprescribedbyaqualifiedprofessional.Thisisbothforthesafety
oftheuserandalsotheirrecoverypattern.
3.2Unfoldingtooperatingposition
WARNING!
–Alwaysmakesurethattherollatorisfullyunfolded
andthelockisengagedbeforeusingtherollator.
1.Releasetherollatorbypullingthepushhandlesoutwards.
2.Pressontheseatinordertolocktherollatorinoperating
position.
3.3Folding
1.Standtothesideoftherollator.
2.Liftthefoldingstrapontheseat.
3.Pressthepushhandlesinwardstofoldtherollator.
CAUTION!
–Neverlifttherollatorwiththefoldingstrapwhenit
isinuse.
3.4Walking
WARNING!
Riskoffalling
–Becarefulifthewheelturns90degreeandstops
againstanobstacle.
1560692-A7

Dolomite® Jazz
1.Placetherollatorabitinfrontofyouandtakeasteptowards
itwhilstusingthehandgripsforsupport.
3.5Sittingdownonachair
1.Standinfrontofthechairwiththerollator,thebackofthelegs
shouldtouchthechair.
2.Placethehandsonthearmsofthechair,leanforwardslightly
andsitdowncarefully.
3.6Risingtoastandingposition
WARNING!
Riskoftipping
–Neverusetherollatortopullyourselfupfroma
sittingposition.
–Theparkingbrakesmustbeinbrakedpositionwhen
therollatorisusedasasupportwhengettingup,from
achairforexample.
1.Placetherollatorinfrontofyou,usethearmrestsofthechairas
supportandrisecarefullytoastandingposition.
2.Oncesteadyinastandingposition,transferhandstothehand
gripsoftherollator.
3.7Sittingontherollator
WARNING!
Riskoffalling
Usetherollatorforstationaryseatingonly.Bothbrakes
mustbeinparkingpositionwhentherollatorisused
asaseat.
–Neversitandpushwithyourfeet.
–Neversitontherollatoronslopingground.
81560692-A

Usage
CAUTION!
There’sariskofgettinghurtbytheholdersforthe
basket.
–Alwayssitontherollatorfromthecorrectside,i.e.
donotsitdownfromthefrontsideoftherollator.
3.8Transportingtherollator
CAUTION!
Riskofpinching
–Becarefulwhenfoldingtherollator.
1.Liftthefoldingstrapontheseatandpressthepushhandles
inwardstofoldtherollator.Seealsochapter3.3Folding,page7
2.ClosethelockingmechanismAtolocktherollatorinfolded
positionfortransporting.
3.Lifttherollatorattheframeandapushhandle.
3.9Adjustingthehandleheight
CAUTION!
–Alwaysmakesurethattheparkingbrakeisreleased
whenadjustingthehandleheight.
WARNING!
Anincorrectadjustmentofthehandleheightcan
suspendthebrakefunction.
–Afteranyadjustmentofthehandleheightandbefore
usingtherollator,youmustalwayscheckthebrake
function.
–Adjustthehandleheightcorrectly,ifneeded.
1.Standbehindtherollatorwithflatshoulders.
2.LoosenthehandlebarbypushingthelockingleverAupwards
andthenadjustthehandlestoasuitableheight.
1560692-A9

Dolomite® Jazz
Thehandlesshouldusually
bepositionedatwrist
height.Therapistmaysuggest
differentheightsdependingon
specificneedsoftheclient.
3.Lockthehandlebarbypushingthehandleslightlydownwards,a
distinct”click”isheardwhenthehandleislockedinitsposition.
4.Repeattheprocedureontheotherside.
3.10UsingtheHeightAdjustmentMemory
Whenadjustingthehandleheightforthefirsttime,thebuilt-inheight
adjustmentmemorycanbeused.
A
“Memory“
1.Toaccesstheheightmemoryforthefirsttime,raisethepush
handlestothehighestpositiontorevealtheadjustmentscrewA.
2.Loosenthescrewoftheheightadjustmentmemory,butdonot
removeit.Adjustthehandlestoasuitableheightandretighten
thescrew.
3.Pushthehandlesslightlydownwardstofixtheheight.
Suitabletooltouseisa1,5mmhexagonkey(notincluded).
IftheadjustmentscrewAisremovedbymistakeandthe
heightadjustmentmemorycannotbeaccessed,raisethe
handletothehighestpositiontomaketheheightadjustment
memoryvisibleagain.
101560692-A

Usage
3.11Usingthehandbrakes
WARNING!
Anincorrectadjustmentofthehandleheightcan
suspendthebrakefunction.
–Afteranyadjustmentofthehandleheightandbefore
usingtherollator,youmustalwayscheckthebrake
function.
–Adjustthehandleheightcorrectly,ifneeded.
Withthehandbrakes,theusercanpreciselycontrolthebrakeeffect
ontherearwheelsbypullingthebrakehandlemoreorlessfirmly.
1.2.
1.Applythebrakesbypullingbothbrakehandlesslowlyandsteady
upwards.
2.Toapplytheparkingbrakes,pressthebrakehandlescarefully
downwards.
Adistinctclickindicatesthatthebrakeisinthecorrectposition,
sothatthewheelsarelocked.
Itisimportantthatbothbrakesareputintoparking
position.
3.Toreleasetheparkingbrakepullthebrakehandleupwards.
3.12Adjustingthebrakeeffect
1.Ifbrakingeffectispooradjustthebrakecable.
Suitabletoolstousearefixedspanners,8mmforadjustment
and10mmforthelockingnut(notincluded).
2.Makesuretotightenthelocknutsafteradjustment.
3.13Usingthekerbclimber
Usethekerbclimbertomakeiteasiertomountpavementsetc.
CAUTION!
Riskoffalling
–Whenusingthekerbclimber,makesurethatthe
rollatordoesnotrollawayuncontrolledaftercrossing
overanobstacle.
1560692-A
11

Dolomite® Jazz
Mountthekerbclimberontheoppositeside
Thekerbclimbercanbemountedonboththeleftandtherightside.
AB
1.Tomountthekerbclimberontheoppositeside,loosenthe
screwandremovethekerbclimber(A).
2.Remountthekerbclimberontheoppositeside(B)andtighten
thescrewwitha4mmhexagonkey.
3.14Mountingthebasket
WARNING!
Riskofimbalance/falling
–Alwayslockthebrakesbeforemounting/removing
thebasket.
1.MountthebasketbypushingitontothetubesundertheseatA.
Whentheattachmentofthebasketcoverstheredmarkingon
thetubesB,thebasketiscorrectlymounted.
2.Toremovethebasketfromtherollator,liftthehandlesofthe
basketslightlyupwardsandpullthebasketoutwards.
12
1560692-A

Usage
3.15Removingtheseatcushions
Theseatcushionsontheseatcaneasilyberemovedifneeded.
WARNING!
Riskofimbalance/falling
–Iftheseatcushionsareremoved,becarefulnottoget
stuckwiththeclothesonthevelcro.
1.Toremovetheseatcushions,pullthecushionupwardsonthe
markingofthecushionA.
1560692-A13

Dolomite® Jazz
4Maintenanceandcare
4.1Maintenance
Maintenanceshouldbedoneatleastonceayear.
Toensuregoodperformanceandsafetyyoushouldregularlycheck
thatthefollowingiscarriedout:
•Ensurethatscrewsandadjustmentsareproperlytightened.
•Neveruseadefectiverollator.Donotattemptrepairsyourself!
•Ifhandgripsareloosedonotusetherollator.Changehand
gripsaccordingtotheserviceinstructionswhichcanbeobtained
fromyourInvacarerepresentative.
•Verifybrakeoperation.Ifbrakeadjustmentisrequired,see
chapter3Usage,page7
inthisusermanual.
•Periodicallyinspectthecastorstightness,wearanddamage.
•Makesurethatthewheelsarefreeofhair,lintandotherdebris.
•Checktheseatpadandbackrestpadregularlytoensurethat
therearenodamagesontheupholstery,ifso,changethepads.
4.2Care
Important!
–Donotuseanabrasivedetergent,cleanerorclothto
cleanordrytheproduct.
–Donotusehighpressurecleanerorsteamcleaner.
•Cleantherollatorwithsolvent-freehouseholdcleaner.
•Cleantheframewithdampclothandmilddetergent.
•Cleanthewheelswithabrush(nowirebrush!).
•Cleanthebackrest,seatandbasketwithmilddetergent.
14
1560692-A

AfterUse
5AfterUse
5.1Disposal
Whentheproductcannolongerbeused,itanditsaccessoriesas
wellasthepackagingmaterialshouldbesortedinthecorrectway.
Theindividualpartscanbeseparatedandhandledaccordingtotheir
material.
Pleasebeenvironmentallyresponsibleandrecyclethisproduct
throughyourrecyclingfacilityatitsendoflife.
5.2Re-use
Thisproductissuitableforre-useafterthefollowinghasbeen
performed:
•Inspection
•Cleaning
Fordetails,seechapter4Maintenanceandcare,page14.
WARNING!
Riskofinjury
–Alwaysinspecttheproductaccordingtotheservice
instructionsbeforetransferringtheproducttoa
differentuser.
–Ifanydamageisfounddonotusetheproduct.
Theusermanualbelongstotheproduct.Makesurethatthe
usermanualwillbehandedoverwiththeproduct.
1560692-A15

Dolomite® Jazz
6Technicaldata
6.1Dimensionsandweights
A
B
C
D
E
Jazz510Jazz610
Totalwidth(A)595mm
Totalheight(B)650–800mm750–1000mm
Seatwidth(C)450mm
Seatheight(D)510mm610mm
Totallength(E)690mm
Widthwhenfolded215mm
Front/rearwheel1
diameter
200mm
Front/rearwheel1 width33mm
1
Frontwheelsaresteeringwheels.Rearwheelsareprovidedwitha
brakesystemfordosedbreakingandforlockingthewheels.
Jazz510Jazz610
Weight2
7.5kg
7.8kg
Max.userweight3
150kg
Max.loadbasket7kg
Max.loadtray5kg
2
Totalweightexcludingequipment.
3
Weightlimitationincludingtheweightoftheuser(whetherstanding
orsitting)andthecontentofthebasket.
6.2Material
FramePolyesterpowdercoatedaluminium
Handlebars
Anodisedaluminium
HandgripsTPE
WheelsPolypropylenewithtreadsofTPE
Plasticparts
Materialaccordingtomarking(PA,PP,PE)
ScrewsSteel,rustprotected
161560692-A

Notes

Notes

Notes
