DOLOMITE®Legacy™
1General
1.1Introduction
Thisusermanualcontainsimportantinformationaboutthe
handlingoftheproduct.Toensuresafetywhenusingthe
product,readtheusermanualcarefullyandfollowthe
safetyinstructions.
Notethattheremaybesectionsinthisusermanual,which
arenotrelevanttoyourproduct,sincethismanualapplies
toallavailablemodels(onthedateofprinting).Ifnot
otherwisestated,eachsectioninthismanualreferstoall
modelsoftheproduct.
Allmodelsmaynotbeavailableinallcountries.
Invacarereservestherighttoalterproductspecications
withoutfurthernotice.
Beforereadingthismanual,makesureyouhavethelatest
version.YoundthelatestversionasaPDFontheInvacare
website.
Ifyoundthatthefontsizeintheprintversionofthe
usermanualisdifculttoread,youcandownloadthePDF
versionfromthewebsite.ThePDFcanthenbescaledon
screentoafontsizethatismorecomfortableforyou.
Formoreinformationabouttheproduct,forexample
productsafetynoticesandproductrecalls,contactyour
Invacarerepresentative.Seeaddressesattheendofthis
document.
1.2Intendeduse
WARNING!
Incorrectusecouldleadtohazardoussituations
–Invacareacceptsnoresponsibilityforuse,
changeorassemblyoftheproduct,otherthan
statedinthisusermanual.
IMPORTANT!
–Formaxuserweightseetableinsection
Technicaldata.
Indications
•Thewalkingaidisintendedforsupportand
improvementofalimitedwalkingability.
•Theuser’sremainingwalkingabilityneedstobe
sufcientforleavingthehome,forusualdailyactivities
andforparticipatinginsociallifewithoutendangering
themselvesorothers.
•Thewalkingaidisintendedtosupportapersonduring
walkingandmayalsoserveasarestingseat.
•Thewalkingaidcancarryaload,eitherinaspecially
designedbasketoronatray.
•Thewalkingaidissuitableforusebothindoorsand
outdoors.
Contraindications
Thewalkingaidisnotintendedforusebypersonswith
severeequilibriumdisordersorfunctionalperceptual
disorders.
482038-E

General
Permissibleoperatingconditionsandlocations
Thewalkingaidisnottobeusedunderwaterine.g.pools
oropen-airbath,neitherinhotareasase.g.saunas.
1.3ServiceLife
Theexpectedservicelifeofthisproductisveyearswhen
usedinaccordancewiththesafetyinstructions,maintenance
intervalsandcorrectuse,statedinthismanual.The
effectiveproductlifecyclecanvaryaccordingtofrequency
andintensityofuse.
1.4Scopeofdelivery
•Walkingaid,fullyassembled.
•Usermanual
Accessoriesassembledtoyourwalkingaid,aredepending
onthecongurationandmightdifferperregion.
1.5Warranty
Wesupplyatwoyearwarrantyfromthedateofdelivery.
Deviationsmayoccurduetolocalagreements.Damage
causedbynormalweartoe.g.wheels,handlesandbrakes
ordamagecausedbyabnormaluse(e.g.exceededmax.
userweight)isnotcoveredbythewarranty.Maintenance
andoperatinginstructionsmustbefollowedforthewarranty
tobevalid.
82038-E5

DOLOMITE®Legacy™
2Safety
2.1GeneralWarnings
WARNING!
Riskoffalling
–Exercisecautionwhenwalkingonsloping/
slipperygroundandonunevensurfaces.
–Donotusetherollatorasawheelchair.
–Becarefulwhenwalkingbackwardsover
obstacles.
–Neversitandpushwithyourfeet.
–Donotgoupordownstairswiththerollator.
–Donotusetherollatoronescalators.
–Donotunderanycircumstancesstandonthe
rollator.
–Becarefulwhenusinglongskirts,theclothes
mightgetstuckinthewheels.
–Loadsmustonlybetransportedinthebasket
oronthetray.Becarefulwhenthereisaheavy
loadinthebasket(forthemax.loadinthe
basketrefertothechapter“Technicaldata”).
WARNING!
Riskofinjury
–Donotletchildrenplaywiththerollator.
CAUTION!
Riskofrstdegreeburns
–Becarefulifthepushhandlesortheseatare
exposedtoextremetemperatures(above41°C
/106°F).
IMPORTANT!
Riskofcorrosion
–Therollatormustnotbestoredinwetor
humidenvironments.
Thepersonwhoprescribestheproductorwhoisotherwise
responsiblefortheusermustensurethattheproductis
suitablefortheuser.Theusershallbeinstructedhowto
usetheproduct.Thisincludestheuseofthefeaturesand
therestrictionsinuse.Theusershallalsobenotiedofthe
warningsforusegivenintheusermanual.
2.2Labelsandsymbolsontheproduct
A
BCD
EFGHI
X XXXXXX XXXXXX
XX cm
XXX kg
XXXXX-XX-XX
HMINR:XXXXX
G
O
0
0
0
-0
0
0
0
0
0
YYYY-MM
XXXXXXXX XXXXXX XXX
XXXXX-XXXXXX
Thelabelcontainsallimportanttechnicalinformation
regardingyourproduct.
682038-E

Safety
AArticlenumberFSerialnumber
BProductnameGMax.userweight
CReferencetouser´s
manual
HMax.width
DIndoor/OutdooruseIManufacturer
EDateofproductionJHMI-number(notvalid
forallcountries)
Othersymbolsontheproduct
Allsymbolsmightnotbepresentonallproducts.
Refertotheusermanual.
ThisproductcomplieswithDirective93/42/EEC
concerningmedicaldevices.Thelaunchdateof
thisproductisstatedintheCEdeclarationof
conformity.
82038-E7

DOLOMITE®Legacy™
3Usage
3.1Beforeuse
Wedonotrecommendthattheproductisissuedtoanyone
withoutcarryingoutafullassessmentoftheirspecic
needrst.Theuser’sremainingwalkingabilityneedsto
besufcientforleavingthehome,forusualdailyactivities
andforparticipatinginsociallifewithoutendangering
themselvesorothers.Itisimportantthattheuserisgiven
thenecessarysupportbytheproductasprescribedbya
qualiedprofessional.Thisisbothforthesafetyoftheuser
andtherehabilitationprocess.
3.2Foldingandunfoldingthewalkingaid
WARNING!
Riskofinjury
–Neverlifttherollatorbythefoldinghandle.
Unfoldingtooperatingposition
A
A
1.Holdthewalkingaidwiththepushhandlesandmake
surethatallfourwheelsarestableontheground.
2.Pressbothpushhandlesdownwards.Makesurethat
theseatplateisfoldedcompletelydown(seepicture).
3.PushdownthesafetylatchAinthelockedposition.
WARNING!
–Beforeusingtheproduct,alwayscheckthatthe
safetylatchAisinlockedpositionindicatedby
aclearaudible“Click”.
Flipuptheseatplate
Theseatcanbefoldeduptoprovidealargerwalking
space,andinordertoincreaseaccessibility.
IMPORTANT!
Thewalkingaidmustbefullyunfoldedandlocked
withthefoldinghandlebeforeusingtheproduct.
–Thefoldinghandlelockswhenaclickingsounds
isheard.
882038-E

Usage
Folding
1.Liftup/loosenthesafetylatch.
2.Liftthehandlesinordertofoldthewalkingaidinto
foldedposition.
3.3Adjustingthehandleheight
Adjustonesideatatime.
1.
a.Turnthengerknobcounterclockwiseandremoveit.
b.Removethescrew.
2.Standbehindthewalkingaidwithrelaxedshoulders.
3.
Adjustthehandletosuitableheight.
Ifaspecicheighthasbeenrecommendedby
atherapist,thisshouldbefollowed.Otherwise
thehandlesshouldbepositionedatwristheight
(userstandingwithastraightposture).
4.
a.Insertthescrewandmountthengerknob.
b.Turnthengerknobclockwisetotighten.
WARNING!
Riskoffalling
–Makesurethatthehandlesaresecurelyxed
aftereachadjustment.
5.Repeattheprocedureontheotherside.
82038-E9

DOLOMITE®Legacy™
3.4Usingthebrakes
Usingthehandbrakes
1.Pullbothbrakesupwardstobrake.
Usingtheparkingbrake
IMPORTANT!
–Makesuretoengagebothbrakeswhenusing
theparkingbrakes.
Lockthebrakes(parkingposition):
1.
Pressthebrakehandlesdownwardsuntilaclicking
soundisheard.
Unlockthebrakes:
1.Pullthebrakehandlesupwards.
3.5Adjustingthebrakes
WARNING!
Riskofinjury
Animproperadjustmentofthebrakescouldlead
toapoorbrakingeffect.
–Checkthebrakingeffectbyengagingthe
parkingbrakeandensurethatthewheelcan´t
rotate.
–Makesurethelocknutsareproperlytightened
afteradjustment.
Adjustingthebrakingeffect
Fordesirablebrakingeffect,adjustthebrakewire.
•Thewirecanbeadjustedintwoplaces-atthe
topunderthebrakehandleAoratthebottom
abovethebrakeclampB.
•Thebrakehandlemustbeinneutralposition,
whenadjusting.
1082038-E

Usage
8mm/0.3inchand10mm/0.4inchspanner(not
included).
3.6Flipupseatplate
Flipuptheseatplate
Forincreasedaccessibility,theseatcanbefoldedup
toprovidealargerwalkingspace.
3.7Walking
WARNING!
Riskoffalling
–Becarefulifthewheelsstopagainstan
obstacle.
1.Placethewalkingaidslightlyinfrontofyouandtakea
steptowardsitwhileusingthehandgripsforsupport.
3.8Sittingdownonachair
1.Standinfrontofthechairwiththewalkingaid,the
backofyourlegsshouldtouchthechair.
2.Placeyourhandsonthearmsofthechair,leanforward
slightlyandsitdowncarefully.
82038-E11

DOLOMITE®Legacy™
3.9Risingtoastandingposition
WARNING!
Riskoftipping
–Neverusethewalkingaidtopullyourselfup
fromasittingposition.
–Theparkingbrakesmustbeinbrakedposition
whenthewalkingaidisusedasasupport
whensittingdownorgettingup,fromachair
forexample.
1.Placethewalkingaidinfrontofyou,usethearmrests
ofthechairassupportandrisecarefullytoastanding
position.
2.Oncestableinastandingposition,transferhandstothe
handgripsofthewalkingaid.
3.10Sittingonthewalkingaid
WARNING!
Riskoffalling
Usethewalkingaidforstationaryseatingonly.
Bothbrakesmustbeinparkingpositionwhen
thewalkingaidisusedasaseat.
–Neversitandpushwithyourfeet.
–Neversitonthewalkingaidonslopingground.
3.11Accessories
Accessoriesarenotstandardonallmodels.Foralistof
availableaccessories,contactyourauthorizeddealerorthe
Invacarerepresentative(seerearpageofthismanual).
1282038-E

Usage
3.11.1Paddedbackreststrap(optionalformostversions)
Mountingthepaddedbackreststrap
1.
A
B
LoosenandremovethescrewandthenutA
2.
B
C
LoosenthebackreststrapBfromtheattachmentC
ononeside.
3.
B
D
SlidethepaddedbackreststrapDonthebackreststrap
B.
4.
B
C
A
Re-mountthebackreststrapBintheattachmentC
andtightenthescrewandnutA.
Screwdriver
82038-E13

DOLOMITE®Legacy™
3.11.2Paddedseat(optionalformostversions)
Mountingthepaddedseat
1.
A
FolduptheseatplateA.
2.
A
B
MountthepaddedseatBontheseatplateA.
3.
C
SlidetheattachmentstrapCbetweentheseatandthe
foldinghandle.
1482038-E

Usage
4.
C
SecurethepaddedseatwiththeattachmentstrapC.
5.
Folddowntheseat.
3.11.3Basket
IMPORTANT!
Donotexceedthemaximumallowedloadthat
canbetransportedinthebasket.
–SeechapterTechnicaldataformaximumload.
Mountingbasket
1.Attachthebaskettotheframewiththehooks.
2.Folditdownandmakesureitisproperlyattached.
3.11.4Tray
Mountingtray
1.Fittheplugsonthedownsideofthetrayintotheholes
ontheseat.
2.Pressdownthetray.
82038-E15

DOLOMITE®Legacy™
4Maintenanceandcare
4.1Maintenance
Maintenanceshouldbedoneatleastonceayear.
Toensuregoodperformanceandsafetyyoushouldregularly
checkthatthefollowingiscarriedout:
•Ensurethatscrewsandadjustmentsareproperly
tightened.
•Neveruseadefectivewalkingaid.Donotattempt
repairsyourself!
•Ifhandgripsareloosedonotusethewalking
aid.Changehandgripsaccordingtotheservice
instructionswhichcanbeobtainedfromyourInvacare
representative.
•Verifybrakeoperation.Ifbrakeadjustmentisrequired,
seechapter3Usage,page8inthisusermanual.
•Periodicallyinspectthecastorstightness,wearand
damage.
•Makesurethatthewheelsarefreeofhair,lintand
otherdebris.
4.2Cleaning
Theproductcanbecleanedanddisinfectedusing
commerciallyavailabledetergents.
IMPORTANT
–Cleaningmustbedoneatleastonceayear.
–Donotuseanabrasivedetergentcleaner.
–Donotuseasteamcleaner.
–Neveruseacids,alkaliesorsolvents.
•Theproductcanbewashedinawashingmachineor
byhand.
•Thewashinganddryingtemperaturemaynotbehigher
than60ºC.
•High-pressurecleanerorordinaryjetofwatermaybe
used.However,donotaimthejettowardsbearings,
drainingholesorlabels.
•Cleanwithdampclothandmilddetergents.
•Cleanthewheelswithabrush(nowirebrush!).
•Afterwashing,wipetheproductdry.
Disinfection
Disinfecttheproductbywipingdownallgenerallyaccessible
surfaceswithdisinfectant.
1682038-E

AfterUse
5AfterUse
5.1Disposal
Whentheproductcannolongerbeused,itandits
accessoriesaswellasthepackagingmaterialshouldbe
sortedinthecorrectway.
Theindividualpartscanbeseparatedandhandledaccording
totheirmaterial.
Pleasebeenvironmentallyresponsibleandrecyclethis
productthroughyourrecyclingfacilityatitsendoflife.
5.2Re-use
Thisproductissuitableforre-useafterthefollowinghas
beenperformed:
•Inspection
•Cleaning
Fordetails,seechapter4Maintenanceandcare,page16.
WARNING!
Riskofinjury
–Alwaysinspecttheproductaccordingtothe
serviceinstructionsbeforetransferringthe
producttoadifferentuser.
–Ifanydamageisfounddonotusetheproduct.
Theusermanualbelongstotheproduct.Makesure
thattheusermanualwillbehandedoverwiththe
product.
82038-E17

DOLOMITE®Legacy™
6TechnicalData
6.1Dimensionsandweight
D
EA
F
C
B
Legacy450Legacy520Legacy600
TotalwidthA600mm/23,6"600mm/23,6"600mm/23,6"
TotalheightB715–800mm/28,1”–31,5"760–850mm/29,9”–33,5"835–920mm/32,9”–36,2"
SeatwidthC420mm/16,5"420mm/16,5"420mm/16,5"
SeatheightD470mm/18,5"540mm/21,3"620mm/24,4"
TotallengthE610mm/24"650mm/25,6"720mm/28,3"
Distancebetweenrearwheels
F
455mm/17,9"455mm/17,9"455mm/17,9"
Front/rearwheel1)diameter200mm/7,9"200mm/7,9"200mm/7,9"
1)Frontwheelsaresteeringwheels.Rearwheelsareprovidedwithabrakesystemfordosedbreakingandforlockingthewheel.
1882038-E

TechnicalData
Weights
Legacy450Legacy520Legacy600
Totalweight2)6,9kg/15,2Ibs7,2kg/15,9Ibs7,6kg/16lbs
Max.userweight3)150kg/330Ibs150kg/330Ibs150kg/330Ibs
Maxloadinbasket7kg/15Ibs9kg/20lbs9kg/20lbs
Maxloadontray5kg/11lbs5kg/11lbs5kg/11lbs
2)Totalweightexcludingequipment.
3)Thisweightlimitationincludestheweightoftheuserwhetherstandingorsitting.
6.2Material
Legacy
FramePolyester(PES)powdercoatedsteel
Handle
bars
Chromeplatedsteel
Hand
gripsRubberfoam
WheelsPolypropylene(PP)withtreadsofThermoplastic
Elastomers(TPE)
Plastic
parts
Materialaccordingtomarking;Polyamide(PA),
Polypropylene(PP),Polyethylene(PE)
ScrewsSteel,rustprotected(zincplated)
82038-E19

Notes
