Invacare DOLOMITE Jazz Series User manual

Dolomite®Jazz
Jazz510,Jazz610
enRollator
UserManual...............................3
deRollator
Gebrauchsanweisung........................21
esRollator
Manualdelusuario.........................39
frDéambulateur
Manueld'utilisation.........................57
itRollator
Manualed’uso..............................75
nlRollator
Gebruiksaanwijzing.........................93
ptAndarilho
Manualdeutilização........................111
ThismanualMUSTbegiventotheuseroftheproduct.
BEFOREusingthisproduct,thismanualMUSTbereadandsavedfor
futurereference.

©2019Invacare®Corporation
Allrightsreserved.Republication,duplicationormodicationinwholeorinpartisprohibited
withoutpriorwrittenpermissionfromInvacare.Trademarksareidentiedby™and®.Alltrademarks
areownedbyorlicensedtoInvacareCorporationoritssubsidiariesunlessotherwisenoted.
MakingLife'sExperiencesPossibleisaregisteredtrademarkintheU.S.A.

Contents
ThismanualMUSTbegiventotheuseroftheproduct.
BEFOREusingthisproduct,thismanualMUSTbereadandsaved
forfuturereference.
1General.........................................4
1.1Introduction..................................4
1.2SymbolsinthisDocument........................4
1.3Compliance...................................4
1.4ServiceLife...................................5
1.5WarrantyInformation...........................5
1.6LimitationofLiability............................5
2Safety..........................................6
2.1GeneralSafetyInformation.......................6
2.2LabelsandSymbolsontheProduct.................7
3ProductOverview.................................8
3.1ProductDescription.............................8
3.2IntendedUse.................................8
3.3IndicationsforUse.............................8
3.4Scopeofdelivery..............................8
3.5Accessories...................................8
4Usage..........................................9
4.1BeforeUse...................................9
4.2Unfoldingtooperatingposition....................9
4.3Folding......................................9
4.4Walking......................................10
4.5Sittingdownonachair..........................10
4.6Risingtoastandingposition......................10
4.7Sittingontherollator...........................10
4.8Transportingtherollator.........................11
4.9Adjustingthehandleheight.......................11
4.10UsingtheHeightAdjustmentMemory..............12
4.11Usingthehandbrakes..........................13
4.12Adjustingthebrakeeffect.......................13
4.13Usingthekerbclimber.........................13
4.14Attachingthebasket...........................14
4.15Removingtheseatcushions......................14
5Maintenance.....................................16
5.1GeneralMaintenanceInformation..................16
5.2InspectionChecklist.............................16
5.3CleaningandDisinfection........................16
5.3.1GeneralSafetyInformation.....................16
5.3.2CleaningIntervals............................17
5.3.3CleaningInstructions.........................17
6AfterUse........................................18
6.1Disposal.....................................18
6.2Reconditioning................................18
7TechnicalData....................................19
7.1Dimensionsandweights.........................19
7.2Material.....................................19

Dolomite®Jazz
1General
1.1Introduction
Thisusermanualcontainsimportantinformationaboutthe
handlingoftheproduct.Toensuresafetywhenusingthe
product,readtheusermanualcarefullyandfollowthe
safetyinstructions.
Notethattheremaybesectionsinthisdocument,whichare
notrelevanttoyourproduct,sincethisdocumentapplies
toallavailablemodels(onthedateofprinting).Ifnot
otherwisestated,eachsectioninthisdocumentreferstoall
modelsoftheproduct.
Themodelsandcongurationsavailableinyourcountrycan
befoundinthecountry-specicsalesdocuments.
Invacarereservestherighttoalterproductspecications
withoutfurthernotice.
Beforereadingthisdocument,makesureyouhavethe
latestversion.YoundthelatestversionasaPDFonthe
Invacarewebsite.
Ifyoundthatthefontsizeintheprinteddocumentis
difculttoread,youcandownloadthePDFversionfromthe
website.ThePDFcanthenbescaledonscreentoafont
sizethatismorecomfortableforyou.
Formoreinformationabouttheproduct,forexample
productsafetynoticesandproductrecalls,contactyour
Invacaredistributor.Seeaddressesattheendofthis
document.
Incaseofaseriousincidentwiththeproduct,youshould
informthemanufacturerandthecompetentauthorityin
yourcountry.
1.2SymbolsinthisDocument
Symbolsandsignalwordsareusedinthisdocumentand
applytohazardsorunsafepracticeswhichcouldresultin
personalinjuryorpropertydamage.Seetheinformation
belowfordenitionsofthesignalwords.
WARNING
Indicatesahazardoussituationthatcouldresult
inseriousinjuryordeathifitisnotavoided.
CAUTION
Indicatesahazardoussituationthatcouldresult
inminororslightinjuryifitisnotavoided.
IMPORTANT
Indicatesahazardoussituationthatcouldresult
indamagetopropertyifitisnotavoided.
TipsandRecommendations
Givesusefultips,recommendationsand
informationforefcient,trouble-freeuse.
1.3Compliance
Qualityisfundamentaltothecompany’soperation,working
withinthedisciplinesofISO13485.
ThisproductfeaturestheCEmark,incompliancewiththe
MedicalDeviceRegulation2017/745ClassI.Thelaunchdate
ofthisproductisstatedintheCEdeclarationofconformity.
41560692-E

General
Wearecontinuouslyworkingtowardsensuringthatthe
company’simpactontheenvironment,locallyandglobally,
isreducedtoaminimum.
WeonlyuseREACHcompliantmaterialsandcomponents.
1.4ServiceLife
Theexpectedservicelifeofthisproductisveyearswhen
useddailyandinaccordancewiththesafetyinstructions,
maintenanceintervalsandcorrectuse,statedinthismanual.
Theeffectiveservicelifecanvaryaccordingtofrequency
andintensityofuse.
1.5WarrantyInformation
Weprovideamanufacturer’swarrantyfortheproduct
inaccordancewithourGeneralTermsandConditionsof
Businessintherespectivecountries.
Warrantyclaimscanonlybemadethroughtheprovider
fromwhomtheproductwasobtained.
1.6LimitationofLiability
Invacareacceptsnoliabilityfordamagearisingfrom:
•Non-compliancewiththeusermanual
•Incorrectuse
•Naturalwearandtear
•Incorrectassemblyorset-upbythepurchaserora
thirdparty
•Technicalmodications
•Unauthorisedmodicationsand/oruseofunsuitable
spareparts
1560692-E5

Dolomite®Jazz
2Safety
2.1GeneralSafetyInformation
WARNING!
RiskofSeriousInjuryorDamage
Improperuseofthisproductmaycauseinjury
ordamage.
–Ifyouareunabletounderstandthewarnings,
cautionsorinstructions,contactahealthcare
professionalorproviderbeforeattemptingto
usethisequipment.
–Donotusethisproductoranyavailable
optionalequipmentwithoutrstcompletely
readingandunderstandingtheseinstructions
andanyadditionalinstructionalmaterialsuch
asusermanual,servicemanualorinstruction
sheetsuppliedwiththisproductoroptional
equipment.
WARNING!
RiskofSeriousInjury
Incorrectusecanleadtohazardoussituations.
–Donotuseonstairsoronescalators.
–Donotstandontheproduct.
–Becarefulwhenwalkingonslopingorslippery
groundoronunevensurfaces.
–Avoidwalkingagainstobstacles,bothforwards
andbackwards.
–Donotletchildrenplaywiththeproduct.
–Donotusetheproducttotransportaperson.
–Makesurethatnoclothes,suchaslongskirts,
cangetstuckinthewheels.
CAUTION!
RiskofInjury
Unbalancedorheavyloadmayleadto
overturning.
–Donothanganyloads,suchasbags,tothe
frame,thepushhandlesorhandknobs.
–Onlycarryloadswiththedesignated
equipment,likebasketortray.Donotexceed
themaximumloadfortheequipment.
–Thetotalload,includingtheweightoftheuser
andanyadditionalload,mustnotexceedthe
maximumuserweight.
–Refertochapter7TechnicalData,page19for
maximumuserweightandloadinformation.
61560692-E

Safety
CAUTION!
RiskofInjury
Non-originalorwrongpartsmayaffectthe
functionandsafetyoftheproduct.
–Onlyuseoriginalpartsfortheproductinuse.
–Duetoregionaldifferences,refertoyour
localInvacarecatalogorwebsiteforavailable
optionsorcontactyourInvacaredistributor.
Seeaddressesattheendofthisdocument.
CAUTION!
RiskofFirstDegreeBurns
Partsoftheproductmayheatup,whenexposed
tohightemperatures(above41°C).
–Becarefuliftheproductisexposedtohigh
temperatures,e.g.directsunlight.
IMPORTANT!
Thereisariskofdamageduetowear,e.g.
corrosion.
–Donotusetheproductunderwater,e.g.in
pools.
–Donotusetheproductinhotareaslikesaunas.
–Donotstoretheproductinwetorhumid
environments.
2.2LabelsandSymbolsontheProduct
K
L
B
A
C E
F
D
G
I
J
H
APartnumber
BProductname
CManufactureraddress
DSerialnumber
EDateofmanufacture
FHeightadjustmentrange
GMaximumuserweight
HIndoor/Outdooruse
IMaximumwidth
JReadusermanual
KDonotapplytheparking
brakeduringheight
adjustment
LHeightadjustment
warning
Symbols
European
ConformityMedicalDevice
ManufacturerDateof
manufacture
1560692-E7

Dolomite®Jazz
3ProductOverview
3.1ProductDescription
Thefour-wheeledwalkingaidisequippedwithacentral
seatthatcanbefoldedupforstorageandtransportation.
Frontwheelsaresteeringwheels.Rearwheelsareprovided
withabrakesystemforslowingdownandforlockingthe
wheels.Thewalkingaidisavailableindifferentsizesand
canbeequippedwithawiderangeofaccessories.
3.2IntendedUse
Thewalkingaidisintendedtosupportduringwalkingand
mayalsoserveasarestingseat.
Thewalkingaidissuitableforindoorandoutdooruseon
evenground.
Theintendeduserisanadultwithamaximumuserweight
asstatedontheproductlabelandinchapter7Technical
Data,page19.
3.3IndicationsforUse
Indications
Personswithimpairedmusclestrengthand/orbalance,
whoneedadditionalsupportwhilstwalking.Theremaining
walkingandcognitiveabilitymustbesufcientforsafeuse
ofawalkingaid.
Contraindications
Personswithsevereequilibriumdisordersorfunctional
perceptualdisorders.
3.4Scopeofdelivery
•Rollatorwithstandardbasket1,seatcushion,kerb
climberandbackstrap2,fullyassembled.
•Usermanual
1notinDenmark,Norway,FinlandandSweden.
2onlyinUKandCanada.
3.5Accessories
Variousaccessories,likeabasket/bag,areavailablefor
thisproductandcanbefoundinthecountry-specicsales
documents.Dependingonthecongurationaccessories
maybepre-assembled.
81560692-E

Usage
4Usage
4.1BeforeUse
CAUTION!
RiskofInjuryorDamagetoProperty
–Beforeuse,verifythegeneralfunctionalityof
theproduct.
–Beforeuse,checktheproductforanydefect.
–Donotuseadefectiveproduct.
Invacarepresumeahealthcareprofessionalhasmadean
individualassessmentoftheusertodeterminehisrisklevel
ortherapyrequirements.Providersandcarershaveassessed
thattheproductgivestherequiredsupportandthatits
adjustmentsareappropriatefortheuser.Careranduser
havebeenappropriatelytrainedbyahealthcareprofessional
onhowtousetheproductcorrectlyandsafely.
4.2Unfoldingtooperatingposition
WARNING!
–Alwaysmakesurethattherollatorisfully
unfoldedandthelockisengagedbeforeusing
therollator.
1.Releasetherollatorbypullingthepushhandles
outwards.
2.Pressontheseatinordertolocktherollatorin
operatingposition.
4.3Folding
1.Standtothesideoftherollator.
2.Liftthefoldingstrapontheseat.
3.Pressthepushhandlesinwardstofoldtherollator.
CAUTION!
–Neverlifttherollatorwiththefoldingstrap
whenitisinuse.
1560692-E9

Dolomite®Jazz
4.4Walking
WARNING!
Riskoffalling
–Becarefulifthewheelturns90degreeand
stopsagainstanobstacle.
1.Placetherollatorabitinfrontofyouandtakeastep
towardsitwhilstusingthehandgripsforsupport.
4.5Sittingdownonachair
1.Standinfrontofthechairwiththerollator,thebackof
thelegsshouldtouchthechair.
2.Placethehandsonthearmsofthechair,leanforward
slightlyandsitdowncarefully.
4.6Risingtoastandingposition
WARNING!
Riskoftipping
–Neverusetherollatortopullyourselfupfrom
asittingposition.
–Theparkingbrakesmustbeinbrakedposition
whentherollatorisusedasasupportwhen
gettingup,fromachairforexample.
1.Placetherollatorinfrontofyou,usethearmrestsofthe
chairassupportandrisecarefullytoastandingposition.
2.Oncesteadyinastandingposition,transferhandsto
thehandgripsoftherollator.
4.7Sittingontherollator
WARNING!
Riskoffalling
Usethewalkingaidforstationaryseatingonly.
Bothbrakesmustbeinparkingpositionwhen
thewalkingaidisusedasaseat.
–Neversitandpushwithyourfeet.
–Neversitonthewalkingaidonslopingground.
101560692-E

Usage
CAUTION!
There’sariskofgettinghurtbytheholdersfor
thebasket.
–Alwayssitontherollatorfromthecorrectside,
i.e.donotsitdownfromthefrontsideofthe
rollator.
4.8Transportingtherollator
CAUTION!
Riskofpinching
–Becarefulwhenfoldingtherollator.
1.Liftthefoldingstrapontheseatandpressthepush
handlesinwardstofoldtherollator.Seealsochapter
4.3Folding,page9
2.ClosethelockingmechanismAtolocktherollatorin
foldedpositionfortransporting.
3.Lifttherollatorattheframeandapushhandle.
4.9Adjustingthehandleheight
CAUTION!
–Alwaysmakesurethattheparkingbrakeis
releasedwhenadjustingthehandleheight.
WARNING!
Anincorrectadjustmentofthehandleheightcan
suspendthebrakefunction.
–Afteranyadjustmentofthehandleheightand
beforeusingtherollator,youmustalways
checkthebrakefunction.
–Adjustthehandleheightcorrectly,ifneeded.
1560692-E11

Dolomite®Jazz
1.Standbehindtherollatorwithatshoulders.
2.LoosenthehandlebarbypushingthelockingleverA
upwardsandthenadjustthehandlestoasuitable
height.
Thehandlesshouldusually
bepositionedatwrist
height.Therapistmay
suggestdifferentheights
dependingonspecic
needsoftheclient.
3.Lockthehandlebarbypushingthehandleslightly
downwards,adistinct”click”isheardwhenthehandle
islockedinitsposition.
4.Repeattheprocedureontheotherside.
4.10UsingtheHeightAdjustmentMemory
Whenadjustingthehandleheightforthersttime,the
built-inheightadjustmentmemorycanbeused.
A
“Memory“
1.Toaccesstheheightmemoryforthersttime,raise
thepushhandlestothehighestpositiontorevealthe
adjustmentscrewA.
2.Loosenthescrewoftheheightadjustmentmemory,
butdonotremoveit.Adjustthehandlestoasuitable
heightandretightenthescrew.
3.Pushthehandlesslightlydownwardstoxtheheight.
Suitabletooltouseisa1,5mmhexagonkey(not
included).
IftheadjustmentscrewAisremovedbymistake
andtheheightadjustmentmemorycannotbe
accessed,raisethehandletothehighestpositionto
maketheheightadjustmentmemoryvisibleagain.
121560692-E

Usage
4.11Usingthehandbrakes
WARNING!
Anincorrectadjustmentofthehandleheightcan
suspendthebrakefunction.
–Afteranyadjustmentofthehandleheightand
beforeusingtherollator,youmustalways
checkthebrakefunction.
–Adjustthehandleheightcorrectly,ifneeded.
Withthehandbrakes,theusercanpreciselycontrolthe
brakeeffectontherearwheelsbypullingthebrakehandle
moreorlessrmly.
1.2.
1.Applythebrakesbypullingbothbrakehandlesslowly
andsteadyupwards.
2.Toapplytheparkingbrakes,pressthebrakehandles
carefullydownwards.
Adistinctclickindicatesthatthebrakeisinthecorrect
position,sothatthewheelsarelocked.
Itisimportantthatbothbrakesareputinto
parkingposition.
3.Toreleasetheparkingbrakepullthebrakehandle
upwards.
4.12Adjustingthebrakeeffect
1.Ifbrakingeffectispooradjustthebrakecable.
Suitabletoolstousearexedspanners,8mmfor
adjustmentand10mmforthelockingnut(not
included).
2.Makesuretotightenthelocknutsafteradjustment.
4.13Usingthekerbclimber
Usethekerbclimbertomakeiteasiertomountpavements
etc.
1560692-E13

Dolomite®Jazz
CAUTION!
Riskoffalling
–Whenusingthekerbclimber,makesurethat
therollatordoesnotrollawayuncontrolled
aftercrossingoveranobstacle.
Mountthekerbclimberontheoppositeside
Thekerbclimbercanbemountedonboththeleftandthe
rightside.
AB
1.Tomountthekerbclimberontheoppositeside,loosen
thescrewandremovethekerbclimberA.
2.RemountthekerbclimberontheoppositesideBand
tightenthescrewwitha2,5mmallenkey.
4.14Attachingthebasket
WARNING!
Riskofimbalance/falling
–Alwayslockthebrakesbefore
attaching/removingthebasket.
A
B
C
D
A
1.AttachthebasketAbypushingtheadaptersBonto
theattachmentscrewsC.Pushthebasketdownwards
asmuchaspossible.
MakesurethatthetopoftheadaptersBarein
levelwiththetopoftheseatbracketsD.
2.Toremovethebasket,liftthebasketstraightupwards.
4.15Removingtheseatcushions
Theseatcushionsontheseatcaneasilyberemovedif
needed.
WARNING!
Riskofimbalance/falling
–Iftheseatcushionsareremoved,becareful
nottogetstuckwiththeclothesonthevelcro.
141560692-E

Usage
1.Toremovetheseatcushions,pullthecushionupwards
onthemarkingofthecushionA.
1560692-E15

Dolomite®Jazz
5Maintenance
5.1GeneralMaintenanceInformation
WARNING!
RiskofInjury
–Maintenanceshouldbedoneatleastoncea
year.
–Donotuseadefectiveproduct.
–Donotattemptrepairsyourself.Forrepairs
contactyourprovider.
5.2InspectionChecklist
Toensuregoodperformanceandsafety,inspectyour
productregularly.
qEnsurethatallscrewsandadjustmentsareproperly
tightened.
qEnsurethathandgripsaretight.
Ifhandgripsareloosedonotusethewalkingaid.
Instructionsonhowtochangehandgripscanbe
obtainedfromyourproviderorInvacaredistributor.
qVerifybrakeoperation.
Ifbrakeadjustmentisrequired,seechapter4Usage,
page9.
qInspecttheframeandloadedpartsforcracks.
qInspectthewheels’tightness,wearanddamage.
qMakesurethatthewheelsarefreeofhair,lintand
otherdebris.
5.3CleaningandDisinfection
5.3.1GeneralSafetyInformation
CAUTION!
RiskofContamination
–Takeprecautionsforyourselfanduse
appropriateprotectiveequipment.
IMPORTANT!
Wronguidsormethodscanharmordamage
theproduct.
–Allcleaningagentsanddisinfectantsusedmust
beeffective,compatiblewithoneanotherand
mustprotectthematerialstheyareusedto
clean.
–Neverusecorrosiveuids(alkalines,acidetc.)
orabrasivecleaningagents.Werecommend
anordinaryhouseholdcleaningagentsuchas
dishwashingliquid,ifnotspeciedotherwisein
thecleaninginstructions.
–Neveruseasolvent(cellulosethinner,acetone
etc.)thatchangesthestructureoftheplastic
ordissolvestheattachedlabels.
–Alwaysmakesurethattheproductis
completelydriedbeforetakingitintouseagain.
Forcleaninganddisinfectioninclinicalorlong-term
careenvironments,followyourin-houseprocedures.
161560692-E

Maintenance
5.3.2CleaningIntervals
IMPORTANT!
Regularcleaninganddisinfectionenhances
smoothoperation,increasestheservicelifeand
preventscontamination.
Cleananddisinfecttheproduct
–regularlywhileitisinuse,
–beforeandafteranyserviceprocedure,
–whenithasbeenincontactwithanybody
uids,
–beforeusingitforanewuser.
5.3.3CleaningInstructions
Theproductcanbewashedinawashingmachineorby
hand.
Whenusingahigh-pressurecleaneroranordinaryjetof
water,donotaimthejettowardsbearings,drainingholes
orlabels.
Themaximumcleaningtemperatureis60°C.Donotuse
asteamcleaner.
1.Cleanthewalkingaidwithadampclothandmild
detergent.
2.Cleanthewheelswithabrush(nowirebrush).
3.Afterwashing,wipetheproductdry.
Disinfection
•Wipedownallgenerallyaccessiblesurfaceswith
disinfectant.
Informationonrecommendeddisinfectants
andmethodscanbefoundonhttps://vah-
online.de/en/for-users.
1560692-E17

Dolomite®Jazz
6AfterUse
6.1Disposal
Beenvironmentallyresponsibleandrecyclethisproduct
throughyourrecyclingfacilityatitsendoflife.
Disassembletheproductanditscomponents,sothedifferent
materialscanbeseparatedandrecycledindividually.
Thedisposalandrecyclingofusedproductsandpackaging
mustcomplywiththelawsandregulationsforwaste
handlingineachcountry.Contactyourlocalwaste
managementcompanyforinformation.
6.2Reconditioning
Thisproductissuitableforreuse.Toreconditiontheproduct
foranewuser,carryoutthefollowingactions:
•Inspection
•Cleaninganddisinfection
Fordetailedinformation,see5Maintenance,page16and
theservicemanualforthisproduct.
Makesurethattheusermanualishandedoverwiththe
product.
Ifanydamageormalfunctionisdetected,donotreuse
theproduct.
181560692-E

TechnicalData
7TechnicalData
7.1Dimensionsandweights
A
B
C
D
E
[mm]Jazz510Jazz510HJazz610
Totalwidth(A)595
Totalheight(B)650–800770–900750–1000
Seatwidth(C)450
Seatheight(D)510510610
Totallength(E)690
Widthwhenfolded215
Front/rearwheel1
diameter200
Front/rearwheel1
width33
1Frontwheelsaresteeringwheels.Rearwheelsare
providedwithabrakesystemfordosedbreakingandfor
lockingthewheels.
[kg]Jazz510Jazz510HJazz610
Weight27.57.67.8
Max.userweight3150
Max.loadbasket7
Max.loadtray5
2Totalweightexcludingequipment.
3Weightlimitationincludingtheweightoftheuser(whether
standingorsitting)andthecontentofthebasket.
7.2Material
FramePolyesterpowdercoatedaluminium
HandlebarsAnodisedaluminium
HandgripsTPE
WheelsPolypropylenewithtreadsofTPE
PlasticpartsMaterialaccordingtomarking(PA,PP ,PE)
ScrewsSteel,rustprotected
1560692-E19

Notes
