ITRON OpenWay Riva 500G User manual

OpenWay® Riva 500G ERT Module, Remote
Mount
Installation Guide
Technical
Communications
knowledge to shape your future

Identification
OpenWay Riva 500G ERT Module Installation Guide, Remote Mount
21 August 2018
TDC-1678-003
Copyright
© 2017-2018 Itron, Inc. All rights reserved.
Confidentiality Notice
The information contained herein is proprietary and confidential and is being provided
subject to the condition that (i) it be held in confidence except to the extent required
otherwise by law and (ii) it will be used only for the purposes described herein. Any third
party that is given access to this information shall be similarly bound in writing.
Trademark Notice
Itron is a registered trademark of Itron, Inc.
All other product names and logos in this documentation are used for identification purposes
only and may be trademarks or registered trademarks of their respective companies.
Suggestions
For more information about Itron or Itron products, see www.itron.com.
If you have questions or comments about the software or hardware product, contact Itron
Technical Support Services.
Contact
• Email: [email protected]
• Itron Access: https://support.itron.com
• Telephone Itron Technical Support North America: 1-877-487-6602
For technical support contact information by region, go to www.itron.com and select your
country and language.

Contents
Chapter 1 Important Safety and Compliance Information.............................. 1
U.S. and Canadian patent numbers..................................................................................................................... 1
USA, FCC Part 15 compliance............................................................................................................................. 1
Canada, ISED compliance.................................................................................................................................... 2
Transportation classication................................................................................................................................. 2
Modications, repairs, installation, and removal...................................................................................................2
Lithium battery safety........................................................................................................................................... 3
Equipment repairs.................................................................................................................................................3
Intrinsic safety.......................................................................................................................................................3
Electrostatic ignition hazard..................................................................................................................................3
ERT module cleaning............................................................................................................................................ 3
Do not drop ..........................................................................................................................................................3
Chapter 2 About the OpenWay Riva Remote 500G ERT Module.................... 4
Transmission modes............................................................................................................................................. 4
Gas Day Take........................................................................................................................................................ 5
High ow event/alarm........................................................................................................................................... 5
Local auditing........................................................................................................................................................5
Low battery event/alarm....................................................................................................................................... 6
Remote OpenWay Riva 500G ERT module and Itron Security Manager..............................................................6
OpenWay Riva remote 500G ERT module functional specications.................................................................... 6
OpenWay Riva 500G ERT module operational specications..............................................................................7
OpenWay Riva 500G ERT device rmware functionality...................................................................................... 7
Related documents...............................................................................................................................................8
Chapter 3 Mounting the Remote 500G ERT Module........................................ 9
Standard installation options................................................................................................................................ 9
Mounting the remote 500G ERT module on a pipe.............................................................................................. 9
Adapter plate mounting positions.......................................................................................................................11
Selecting and installing the module on a wall or at vertical mounting location................................................ 12
Chapter 4 OpenWay Riva Remote 500G ERT Module Programming........... 13
Standard 500G ERT module conguration......................................................................................................... 13
Programming the remote ERT module............................................................................................................... 14
Itron programs and software variables............................................................................................................... 14
Chapter 5 Specific Meter Manufacturer Installation......................................18
Eagle Research meter installation.......................................................................................................................18
Eagle Research installation overview.......................................................................................................18
Eagle Research 500G remote product mounting instructions................................................................. 19
Eagle Research mechanical and wiring installation instructions............................................................. 20
Connecting the 500G remote ERT module to the MPplus corrector................................................20
Connecting the 500G ERT module to the XARTU corrector.............................................................21
Eagle Research corrector programming and requirements notes........................................................... 22
Using Eagle Research Field Manager to change the MPplus settings.............................................23
OpenWay Riva 500G ERT Module Installation Guide, Remote Mount TDC-1678-003 iii
Proprietary and Confidential

Using Eagle Research Field Manager to change the XARTU corrector settings..............................24
Eagle Research programming note.................................................................................................. 25
Elster American meter installation...................................................................................................................... 26
Elster American 500G installation overview ............................................................................................26
Elster American meter remote ERT module mounting instructions......................................................... 27
Elster American mechanical and wiring installation instructions............................................................. 28
Installing the remote module cable...................................................................................................29
Galvanic Gas Micro Installation.......................................................................................................................... 30
Galvanic installation overview.................................................................................................................. 30
Galvanic product mounting instructions.................................................................................................. 30
Galvanic mechanical and wiring installation instructions.........................................................................30
Programming the Galvanic Gas Micro electronic volume corrector........................................................ 31
GE Oil and Gas meter installation.......................................................................................................................31
GE Oil and Gas 500G installation overview............................................................................................. 32
GE Oil and Gas custom mounting options.............................................................................................. 32
GE Oil and Gas ES3 or ETC ordered with the AMR-ready mounting kit.......................................... 33
GE Oil and Gas IMC/W2, or MC2 with the GE mounting bracket kit............................................... 33
GE Oil and Gas mechanical and wiring installation instructions .............................................................35
D800/D1000 wiring and installation.................................................................................................. 35
GE Oil and Gas meters with pulse output wiring..............................................................................38
GE Oil and Gas meter programming and requirements notes ................................................................40
Honeywell Instrument 500G installation............................................................................................................. 40
Honeywell Instrument installation overview............................................................................................. 41
Honeywell product mounting instructions............................................................................................... 42
Honeywell mechanical and wiring installation instructions......................................................................43
Connecting the remote ERT modules to a Honeywell Mini-AT, Mini-Max, or EC-AT ...................... 43
Connecting the remote ERT module to the Honeywell TCI.............................................................. 45
Honeywell Instrument programming and requirements...........................................................................47
Honeywell software settings............................................................................................................. 47
Programming the Honeywell Instrument parameters....................................................................... 48
Itron meter installation........................................................................................................................................ 49
National meter installation.................................................................................................................................. 50
Romet meter installation..................................................................................................................................... 50
Romet installation overview..................................................................................................................... 51
Romet product mounting instructions..................................................................................................... 51
Romet mechanical and wiring installation instructions............................................................................52
Romet corrector programming and requirements notes..........................................................................56
Sensus meter installation....................................................................................................................................57
Sensus meter installation overview..........................................................................................................58
Sensus product mounting instructions.................................................................................................... 58
Sensus meter mechanical and wiring installation instructions................................................................ 59
Sensus meter programming and requirements notes .............................................................................60
Chapter 6 Diaphragm Meter Installation.........................................................61
Diaphragm meter installation overview...............................................................................................................61
Product mounting installation instructions......................................................................................................... 62
Diaphragm meter mechanical and wiring installation instructions..................................................................... 63
Remote ERT module programming and requirements notes............................................................................. 67
Appendix A Using gel-cap connectors to complete wiring connections.....68
OpenWay Riva 500G ERT Module Installation Guide, Remote Mount TDC-1678-003 iv
Proprietary and Confidential

Appendix B Optional sealant application instructions ..................................69
OpenWay Riva 500G ERT Module Installation Guide, Remote Mount TDC-1678-003 v
Proprietary and Confidential

Chapter 1 Important Safety and Compliance
Information
This section provides important information for your safety and product compliance.
U.S. and Canadian patent numbers
U.S. Patent numbers: 4,614,945; 4,753,169; 4,768,903; 4,799,059; 4,867,700
Canadian Patent numbers: 1,254,949; 1,267,936; 1,282,118
USA, FCC Part 15 compliance
This device complies with Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation.
Operation is subject to the following two conditions:
• This device may not cause harmful interference.
• This device must accept any interference that may cause undesirable operation.
This device must be installed to provide a separation distance of at least 20 centimeters (7.9
inches) from all persons to be compliant with regulatory RF exposure.
USA, FCC Class B-Part 15
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio or TV technician for help.
Modifications and Repairs
To ensure system performance, this device and antenna shall not be changed or modified
without the express approval of Itron. Per FCC rules, unapproved modifications or operation
OpenWay Riva 500G ERT Module Installation Guide, Remote Mount TDC-1678-003 1
Proprietary and Confidential

beyond or in conflict with these instructions for use could void the user's authority to operate
the equipment.
Canada, ISED compliance
Compliance Statement Canada Déclaration de Conformité
This device complies with Innovation, Science
and Economic Development Canada (ISED)
license-exempt RSS standard(s). Operation is
subject to the following two conditions: (1) this
device may not cause interference, (2) this
device must accept any interference, including
interference that may cause undesired operation
of the device.
Under Innovation, Science and Economic
Development Canada (ISED) regulations, this
radio transmitter may only operate using an
antenna of a type and maximum (or lesser) gain
approved for the transmitter by Industry Canada.
To reduce potential radio interference to other
users, the antenna type and its gain should be so
chosen that the equivalent isotropically radiated
power (e.i.r.p.) is not more than that necessary
for successful communication.
Le présent appareil est conforme aux CNR
d'Industrie Canada applicables aux appareils
radio exempts de licence. L'exploitation est
autorisée aux deux conditions suivantes: (1)
l'appareil ne doit pas produire de brouillage, (2)
l'utilisateur de l'appareil doit accepter tout
brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le
fonctionnement.
Conformément à la réglementation d'Industrie
Canada, le présent émetteur radio peut
fonctionner avec une antenne d'un type et d'un
gain maximal (ou inférieur) approuvé pour
l'émetteur par Industrie Canada. Dans le but de
réduire les risques de brouillage radioélectrique à
l'intention des autres utilisateurs, il faut choisir le
type d'antenne et son gain de sorte que la
puissance isotrope rayonnée équivalente (p.i.r.e.)
ne dépasse pas l'intensité nécessaire à
l'établissement d'une communication
satisfaisante.
Transportation classification
The Federal Aviation Administration prohibits operating transmitters and receivers on all
commercial aircraft. When powered, the Itron device is considered an operating transmitter
and receiver and cannot be shipped by air. All product returns must be shipped by ground
transportation.
Modifications, repairs, installation, and removal
To ensure system performance, this device and antenna shall not be changed or modified
without the express approval of Itron. Any unauthorized modification will void the user's
authority to operate the equipment.
In the event of malfunction, all repairs should be performed by Itron. It is the responsibility of
users requiring service to report the need for service to Itron.
Important Safety and Compliance Information
OpenWay Riva 500G ERT Module Installation Guide, Remote Mount TDC-1678-003 2
Proprietary and Confidential

Lithium battery safety
Warning: Follow these procedures to avoid injury to avoid injury to yourself or
others:
• The lithium battery may cause a fire or chemical burn if it is not disposed of
properly.
• Do not recharge, disassemble, heat above 100° Celsius (212° Fahrenheit), crush,
expose to water, or incinerate the lithium battery.
• Keep the lithium battery away from children.
• Fire, explosion, and severe burn hazard.
Equipment repairs
Warning: Only authorized Itron personnel should attempt repairs on Itron
equipment. Attempts to do so by others might void any maintenance contract with
your company. Unauthorized service personnel might also be subject to shock
hazard on some Itron equipment if removal of protective covers is attempted.
Intrinsic safety
Warning: Substitution of components may impair intrinsic safety.
Electrostatic ignition hazard
Warning: Verify the area is not hazardous when installing, servicing, cleaning, or
touching the Itron device.
ERT module cleaning
Warning: Clean only with a damp cloth.
Do not drop
Warning: While Itron modules are designed to withstand a drop, dropping the
module may damage the device and void the warranty.
Important Safety and Compliance Information
OpenWay Riva 500G ERT Module Installation Guide, Remote Mount TDC-1678-003 3
Proprietary and Confidential

Chapter 2 About the OpenWay Riva Remote
500G ERT Module
Itron remote 500G ERT modules are radio-frequency (RF) IPv6 open standards-based gas
modules designed to be read under Itron’s multi-purpose OpenWay Riva Network Mode or
by legacy ChoiceConnect Mobile Mode. In OpenWay Riva Network Mode, the 500G ERT
module offers firmware download, sub-hourly interval data, and extended data storage. In
Mobile Mode, the ERT module operates identical to the 100G DLS Dataglogging ERT
module. Itron 500G ERT modules can be read by legacy handhelds and mobile or the new
Itron Mobile Radio readers. The 500G ERT module continues Itron's tradition of reliability,
accuracy, and long battery life while supporting the industry's standards for security and
intrinsic safety.
The remote ERT module features tilt and cut cable-event reporting and security seals to
indicate physical tampering and minimize theft. Cut cable is reported when communications
fail between the meter or instrument and the ERT module, possibly from a cut or
disconnected cable. The ERT module circuitry senses an electrical current break to report a
cut cable alarm or event.
Transmission modes
In OpenWay Riva Network Mode, the module provides 3,840 buckets of configurable
interval data. Interval options are 5, 15, or 30 minutes.
Note: Interval data options are dependent on the ERT module's firmware version. For more
information, see OpenWay Riva 500G ERT device firmware functionality on page 7.
Output power in OpenWay Riva Network Mode is +27 dBm (500 milliwatts. The module is
designed to transmit 3 times a day with a 20-year battery life.
In Mobile Mode, the module provides 960 buckets of hourly interval data and can be set to
transmit in mobile and handheld, hard to read mobile and handheld. Mobile Mode
transmission modes include the following transmission characteristics:
•Mobile High Power Mode. The 500G ERT module transmits a high-powered RF
message every 60 seconds. Output power in this mode is 250 milliwatts or +24dbm. In
Mobile High Power Mode, the expected battery life is 20 years.
•Mobile and Handheld Mode. The 500G ERT module transmits a medium-powered RF
message every 15 seconds. Output power in this mode is 10 milliwatts or +10dBm. In
Mobile and Handheld Mode, the expected battery life is 20 years.
•(Optional) Hard to Read Mode. The 500G ERT module transmits a high-powered RF
message every 30 seconds. Output power in this mode is 250 milliwatts or +24dBm. In
Hard to Read Mode, the expected battery life decreases to 15 years in this mode. The
hard to read mobile mode should only be used for exceptionally hard-to-read applications
(such as meters installed on rooftops or in sub-basements).
OpenWay Riva 500G ERT Module Installation Guide, Remote Mount TDC-1678-003 4
Proprietary and Confidential

Caution: If you perform a Switch to OpenWay Riva Network Mode or Switch to
Mobile Mode operation, it results in a loss of interval data.
An FCC license is not required to read the 500G ERT modules.
Gas Day Take
Note: Gas Day Take functionality is dependent on the 500G ERT module firmware version.
For more information, see OpenWay Riva 500G ERT device firmware functionality on page
7.
Gas Day Take (GDT) is critical to many natural gas utilities. GDT allows utilities to manage
deregulated gas purchases. While daily GDT reads can be used for various operations
within the utility, the primary time constrained business operation is to daily balance
deregulated (transport) customers. GDT requires GDT data from a percentage (typically a
maximum of 10%) of the utility's customers at 9:00 a.m. Central Clock Time. All collected
data must be prepared and presented to deregulated marketers and customers by 11:00
a.m. CCT to support the gas utility's deregulated tariff. If a deregulated marketer of
customer under or over-burns what they nominated for a given day, they may pay a daily
penalty. Customers require the previous day's GDT data to make adjustments to their next
day nomination to avoid penalties.
High flow event/alarm
Note: High Flow event functionality is dependent on the 500G ERT module firmware
version. For more information, see OpenWay Riva 500G ERT device firmware functionality
on page 7.
High Flow is a configurable event/alarm that can alert a utility of an excessive flow of gas to
avoid potential hazardous events. The High Flow threshold can be configured using FDM
Tools or the OWOC CM.
Local auditing
Note: Local auditing functionality is dependent on the ERT module's firmware version. For
more information, see OpenWay Riva 500G ERT device firmware functionality on page 7.
The 500G ERT module supports local data auditing of installation programming. Local
auditing features the listed characteristics.
• Supports writing data (in both manufacturing and by FDM) to the module to support future
installation programming auditing.
• Reading the auditing data is supported locally.
• Auditing parameters include FDM User ID, number of dials, meter drive rate, unit of
measure, ERT count rate, rollover, and PComp.
About the OpenWay Riva Remote 500G ERT Module
OpenWay Riva 500G ERT Module Installation Guide, Remote Mount TDC-1678-003 5
Proprietary and Confidential

• Timestamping of auditing parameters.
• Log access via COSEM only.
Low battery event/alarm
Note: Low battery functionality is dependent on the module's firmware version. For more
information, see OpenWay Riva 500G ERT device firmware functionality on page 7.
The OpenWay Riva module low battery event is flagged when the device reaches a 10% of
battery life remaining state. The event triggers an alarm configurable for asynchronous
delivery to the head end system.
Remote OpenWay Riva 500G ERT module and Itron
Security Manager
The 500G ERT module is a component of Itron's OpenWay Riva system. The OpenWay
Riva system enhanced security, provided by Itron Security Manager (ISM), applies to the RF
communications between the collection device and the ERT module.
There are two fundamental security processes used in the Itron Security Manager to ensure
system communication confidentiality and validity.
•Authentication. Authentication is the process of confirming that an artifact is genuine or
valid. Authentication in the ERT module is the process of verifying a request is from a
valid source and in its original form.
•Encryption. Encryption is the process of transforming information to make it unreadable
to anyone who does not have a valid security key. There are two types of encryption:
symmetric and asymmetric. Symmetric encryption uses a shared key to decrypt or
encrypt information. Asymmetric encryption uses a private key to encrypt and a public
key to decrypt. Data transmissions over the network are protected using AES-256
encryption.
As a component of the Itron Openway Riva solution, the 500G module supports the security
model found in the OpenWay solution for both reading and programming. If the ERT
modules are shipped without enhanced security enabled (ready to secure), the utility can—
at a later date—configure the modules for ISM enhanced security.
Note: Enabling or working with Itron ISM enhanced security requires FDM Tools.
OpenWay Riva remote 500G ERT module functional
specifications
Functional specification Description
Power source Four "A" cell lithium batteries
About the OpenWay Riva Remote 500G ERT Module
OpenWay Riva 500G ERT Module Installation Guide, Remote Mount TDC-1678-003 6
Proprietary and Confidential

Functional specification Description
Tamper detection Tilt and cut cable
FCC compliance Part 15 certified
Innovation, Science and Economic
Development Canada (ISED) compliance
RSS-247 certified
Intrinsically safe per Telemetering Equipment for use in Hazardous
Locations, for Cl I, Div 1, Gp D for Haz Loc,
Temp Code T2, -40°C ≤ Ta ≤ +70°C.
Product identification Numeric and bar coded ERT type and serial
number
Construction materials Gray polycarbonate housing and back plate with
encapsulated electronics
OpenWay Riva 500G ERT module operational
specifications
Operational specifications Description
Operating temperatures -40° to 158° F (-40° to +70° C)
Operating humidity 5 to 95 percent relative humidity
Program frequency 908 MHz
Transmit frequency Frequency hopping spread spectrum 903 to 926.85
MHz in the ISM band
Data integrity Verified in every data message
OpenWay Riva 500G ERT device firmware
functionality
This section lists the 500G ERT device firmware information and lists functionality by
version.
Firmware part
number
Global software
release (GSR)
version
FDM Check Endpoint
firmware version
Over-the-air
firmware part
number
Firmware
functionality
FWM-7000-006
(direct mount)
4.1 1.3.15.0 N/A
• Network topology
◦ Star
◦ Mesh
• IPv6 addressable
• 60-minute interval
data
• 100 DLS Mobile
Mode
FWM-7000-506
(remote mount)
About the OpenWay Riva Remote 500G ERT Module
OpenWay Riva 500G ERT Module Installation Guide, Remote Mount TDC-1678-003 7
Proprietary and Confidential

Firmware part
number
Global software
release (GSR)
version
FDM Check Endpoint
firmware version
Over-the-air
firmware part
number
Firmware
functionality
• Firmware
download
FWM-7002-008
(direct mount)
4.5 2.1.14.0 N/A
• GSR 4.1
functionality
•3,840 buckets of
configurable
interval data
◦ Interval options
are 5, 15, and
30-minute
intervals
• High flow alarm
• Low battery alarm
• Gas day take
• Local auditing
FWM-7012-008
(remote mount)
Note: For more information about alarms and events, see the OpenWay Riva Collection
Manager Device Interface Guide (TDC-1786-XXX).
Related documents
Document title Document part number
OpenWay Riva 500G ERT Module Installation Guide, Direct
Mount
TDC-1671-XXX
Customer setup to order secured OpenWay Riva modules TDC-1748-XXX
First article review form TDC-1749-XXX
OpenWay Riva Collection Manager Device Interface Guide TDC-1786-XXX
OpenWay Collection Manager Operational Guidelines
Itron Mobile Radio User Guide TDC-1719-XXX
Itron Mobile Radio Quick Reference Guide TDC-1720-XXX
Gas and Telemetry Module Meter Compatibility List PUB-0117-002
OpenWay Riva Gas Devices Ordering Guide PUB-0117-006
OpenWay Riva 500G ERT Module Specification Sheet 101510SP-0X
Field Deployment Manager Tools Application Guide TDC-1713-XXX
Field Deployment Manager Tools Configuration Guide TDC-1711-XXX
Field Deployment Manager Field Representative's Guide TDC-1714-XXX
Note: The last three digits of the user and installation guides represent the document's
revision level. The revision level is subject to change without notice.
About the OpenWay Riva Remote 500G ERT Module
OpenWay Riva 500G ERT Module Installation Guide, Remote Mount TDC-1678-003 8
Proprietary and Confidential

Chapter 3 Mounting the Remote 500G ERT
Module
This chapter provides the instructions to mount the remote 500G ERT module on a pipe or
other flat vertical surface (wall).
Standard installation options
Mount the remote ERT module using the pipe mount or wall mount (flat vertical surface)
procedure.
•Pipe mount. Itron offers a pipe installation kit (CFG-0005-003) to mount the remote ERT
module on a pipe.
•Flat vertical (wall) mount. Installation using the wall mount option places the module on
a wall or other vertical surface.
Select the mounting option that will best work for your system. For example, your setup may
provide the location for a pipe mount but not a wall mount. The preferred mounting location
is near the meter or instrument, but some installations may require an extended cable
length. For example, your installation may require mounting the ERT module around a
corner to avoid RF interference. The remote ERT module supports cable lengths up to 300
feet with a recommended one-splice limitation. Installers must mount the remote ERT
module in a vertical position with the ERT label directional arrow pointed upward.
Warning: Do not mount the 500G remote ERT module in an orientation other than
vertical (remote ERT module label arrow pointed upward). Violating the mounting
orientation requirements may void the product warranty. Upright vertical positioning
is critical because:
• The 500G modules are optimized for communication and require upright
mounting. Any other mounting position could result in reduced RF performance.
• The remote module tilt tamper sensor requires upright mounting. Any other
mounting position can cause issues with the module's tilt tamper detection.
Mounting the remote 500G ERT module on a pipe
The following items are required to mount the remote ERT module on a pipe.
Itron part number Description
CFG-0005-003 Pipe mount kit contents:
2 band clamps, 2 tamper seals, pipe bracket, 2
cable ties, 1 adapter plate and the following
screws:
OpenWay Riva 500G ERT Module Installation Guide, Remote Mount TDC-1678-003 9
Proprietary and Confidential

Itron part number Description
1. SCR-0215-001 (2) #8-16 x ½ inch slotted
pan-head tapping screw, corrosion-resistant
steel. Attaches the adapter plate to the pipe
bracket.
2. SCR-0215-002 (2) #8-16 1-inch slotted pan-
head tapping screw, corrosion-resistant steel.
Attaches the ERT module to the adapter
plate.
Completing the installation
1. Remove the pipe bracket and clamp from the
kit.
2. Loosen the band clamp screw until the end of
the band releases.
3. Push the end of the clamp's band through the
holes in the pipe bracket as shown.
4. Place the band clamp around the pipe. The
band will loosely wrap around the pipe.
1. Push the end of the band through the band
clamp screw assembly.
2. Turn the band clamp's screw assembly to fit
into the pipe bracket opening.
3. Tighten the clamp screw until the band clamp
is secure on the pipe.
5. Place the adapter plate on the pipe bracket
with the mounting lug at the top. The adapter
plate screw bosses fit into the pipe bracket
recess.
Mounting the Remote 500G ERT Module
OpenWay Riva 500G ERT Module Installation Guide, Remote Mount TDC-1678-003 10
Proprietary and Confidential

6. Ensure that the adapter plate is positioned as
shown with the mounting lug (1) at the top.
1. Install the adapter plate on the pipe mounting
bracket, use the two shortest (½-inch) screws
from the pipe mount kit.
2. Place the mounting screws into the holes as
shown (2).
Tighten both screws in an alternating pattern to 9
to 12 inch-pounds torque.
7. Position the back of the remote module against the face of the adapter plate. The adapter plate
mounting lug must be positioned above the ERT module mounting lug recess.
8. Push up on the module until the adapter plate mounting lug is as far as possible inside the
module mounting lug recess.
9. Align the ERT module back-plate mounting
holes with the pipe mount adapter plate holes.
Install the two one-inch ERT module mounting
screws from the installation kit. Tighten the
module mounting screws evenly in an alternating
pattern. Tighten the screws to 9 to 12 inch-
pounds torque.
10. Insert the tamper seals.
11. Gather the excess ERT module cabling into a
loop and use the cable tie to secure the gathered
cable to the pipe.
Adapter plate mounting positions
Note: The notch at the top of the adapter plate (1) must always be at the top position. The
following illustrations show the various mounting configurations. The adapter plate mounting
screw locations are indicated (2).
45-degree angle with the
pipe running to the right
45-degree angle with the pipe
running to the left
Horizontal
Mounting the Remote 500G ERT Module
OpenWay Riva 500G ERT Module Installation Guide, Remote Mount TDC-1678-003 11
Proprietary and Confidential

Selecting and installing the module on a wall or flat
vertical mounting location
Carefully select a mounting location free from electrical wires. The mounting location must
have the proper clearance to accommodate the 1-1/2-inch module mounting screws so
nothing is damaged by the drill or mounting screws. Use a compatible mounting screw.
1. Drill three pilot holes in the mounting surface.
The drilled pilot holes for the two bottom screws
must be on a horizontal line.
1. 3 inches
2. 1-11/16 inches
3. 3-3/8 inches
2. Screw the top mounting screw into the top pilot
hole drilled in step one, leaving enough of the
screw protruding so the ERT module lug recess
on the back plate slides over the screw head and
fits completely into the lug recess. Make
adjustments as necessary.
3. Install the two bottom mounting screws. Tighten the screws in an alternating pattern to secure
the module firmly in position.
4. Place a new tamper seal over each bottom
ERT module mounting screw as required.
Note: To reduce the risk of cable damage,
secure any excess ERT module cabling with a
cable tie.
Mounting the Remote 500G ERT Module
OpenWay Riva 500G ERT Module Installation Guide, Remote Mount TDC-1678-003 12
Proprietary and Confidential

Chapter 4 OpenWay Riva Remote 500G ERT
Module Programming
Caution: You must program the 500G remote ERT module before use.
Programming Itron gas ERT modules requires an understanding of:
• Your meter's drive rate and the number of dials
◦ The drive rate and number of dials is important for programming the module to count
correctly and roll over to zero at the correct time. For example, a four-dial, 2 cubic-feet
meter configuration will count two cubic-feet for each rotation and roll over to zero after
9999.99 where the ones place is equivalent to 100 cubic-feet.
• How your system interprets the meter reading
◦ Some systems modify the consumption reading with the collection software. Other
times, the billing system is used to make modifications. If modifications are made in
both systems, issues may cause consumption reading errors.
It is important to understand your system before the gas ERT modules are programmed.
Program the 500G ERT module in OpenWay Riva Network Mode mode using a compatible
programming device loaded with FDM version 4.1 or higher.
Program the 500G ERT module in Mobile Mode using an approved programming device
loaded with Field Deployment Manager (FDM) software version 4.0 or higher.
To enable enhanced security and for more complete programming information, see the Field
Deployment Manager Tools Mobile Application Guide (TDC-1713).
Standard 500G ERT module configuration
The OpenWay Riva 500G ERT module is capable of configurations that reduce battery life.
Standard battery life is based on the following configuration:
• Hourly interval data
• Interrogations of 3 times per day
• 60 second receiver wakeup
• Five firmware downloads over the life of the ERT module
• Network management and security overhead set to default timing
• RF at capacity (2,000 maximum per cell)
• Average of one two-way command/response per week
OpenWay Riva 500G ERT Module Installation Guide, Remote Mount TDC-1678-003 13
Proprietary and Confidential

Programming the remote ERT module
Program the meter drive rate into the remote ERT module using a compatible programming
device.
1. Verify that you have the correct programming mode (OpenWay Riva Network Mode or Mobile
Mode [mobile high power mode, mobile/handheld mode, or hard-to-read mode]) for your
application.
2. For all programming and Check Endpoint operations using a handheld computer, hold the
handheld as close to vertical as possible. For best success, keep the handheld within six feet of the
target ERT module.
3. Programming parameters are based on the configuration file loaded into the programming
device.
4. Read or Check the remote ERT module using a compatible handheld computer.
• If the read result is higher than the number programmed in step 1, the module is counting
correctly.
• If the read result is not higher than the number programmed in step 1, replace the remote ERT
module.
Itron programs and software variables
This section defines and clarifies possible system variables you may encounter in
programming 500G ERT modules.
Field Deployment Manager (FDM)
The following tables illustrate various FDM programming configurations and the endpoint
response to each setting.
OpenWay Riva Remote 500G ERT Module Programming
OpenWay Riva 500G ERT Module Installation Guide, Remote Mount TDC-1678-003 14
Proprietary and Confidential

OpenWay Riva Remote 500G ERT Module Programming
OpenWay Riva 500G ERT Module Installation Guide, Remote Mount TDC-1678-003 15
Proprietary and Confidential
