J D Williams Evesham Nest of Tables 052 7170 Series User manual

Assembly Instructions - Please keep for future reference
Width - 47cm
Nest of Tables
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123
Please turn to back page for important information when contacting Customer Helpline.
Dimensions
Depth - 38.8cm
Height - 40.6cm
Rev A - 26/09/2016
052 xx 7170

Important - Please read these instructions fully before starting assembly
Safety and Care Advice
Check you have all the
components and tools listed on
pages 2 and 4.
Remove all fittings from the
plastic bags and seperate them
into their groups.
Keep children and animals
away from the work area, small
parts could choke if swallowed.
Make sure you have enough
space to layout the parts before
starting.
Do not stand or put weight on
the product, this could cause
damage.
Assemble the item as close
to its final position (in the same
room) as possible.
Assemble on a soft level
surface to avoid damaging the
unit or your floor.
Parts of the assembly will be
easier with 2 people.
We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
Care and maintenance
Always lift furniture when
moving it (do not drag)
otherwise the joints may be
damaged.
From time to time check that
there are no loose screws on
this unit.
This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
1
Dust surfaces with a soft, dry,
lint free cloth.
More stubborn marks can be
removed using a damp
(not wet) cloth. Wipe the
surface dry immediately
using a soft lint free cloth.
Do not use detergants, abrasive
cleaning products or cleaning
products that contain ammonia,
solvents or silicone as these
may damage the surface finish.
To protect the furniture,
position the furniture out of
direct sunlight and away from
direct heat sources such as
radiators and fires.
Do not place the furniture in
excessively dry and humid
conditions.
Do not place hot or cold
objects on the surface, always
use protective mats to avoid
marking the furniture.
Clean spills up immediately
Dispose of all packaging
carefully and responsibly
when assembly complete.
Do Not dispose of packaging
until assembly complete.

Please check you have all the panels listed below
Components -Panels
Large left end panel (38.4x36cm)
Code -
2
Important - Thick lines indicate finished edges
6858
Large top (47x38.8cm)
0376
Code -
Grooved
edge
Trim x 2
(38.4cm long)
Code - 684xx6520
Large rail x 1 (39.8x16cm)
Code - 6860
Large right end panel (38.4x36cm)
Code - 6859
Grooved
edge
Small left end panel (33x30.2cm)
Code - 0032
Small top (36x33cm)
0377
Code -
Small rail x 1 (30.6x16cm)
Code - 0034
Small right end panel (33x30.2cm)
Code - 0033

6854
3
0377
Components -Exploded View
Important - Thick lines indicate finished edges
6858
0033
6859
684xx6520
Trim
684xx6520
Trim
0376
6860
0032
0034

70 80 90 100 110 120
0 10 20 30 40 50 60
mm
130 140 150 160 170
Ruler - Use this ruler to help correctly identify the screws
Please check you have all the fittings listed below
Components-Fittings
Note: The quantities below are the correct amount to complete the assembly, In some case more fittings
may be supplied than are required.
Tools required
If you have damaged or missing components, call the
Customer Helpline: 01709 534123 Please turn to back page
for important information when contacting Customer Helpline.
4
Cross headed screwdriver
(medium & large )
Small Hammer
Tape Measure
Eye protection
(when using a
hammer)
Large cam x 16 - Code 760001103 Metal dowel x 16 - Code 760003004
A B

Step 1
Assembly Instructions
5
Fittings you will need for this step:
B
B
(x8)
Note: Insert metal
dowels as far as
shown by arrows.
Do not over tighten.
B
Fittings you will need for this step:
A
(x8)
Note: Ensure cam
arrow points towards
the edge with hole.
A
Fittings you will need for this step:
A
(x8)
Fitting dowels to
large and small tops
Fitting cams to large
and small rails
Step 2
Step 3
Fitting cams and
dowels to large and
small end panels
Large
Large
0376
B
Note: Ensure cam
arrow points towards
the edge with hole.
A
B
B
Note: Insert metal
dowels as far as
shown by arrows.
Do not over tighten.
B
B
B
(x8)
Front grooved edge
B
B B
B
B
0377
6860 0034
A
A A
A
A
A A
A
A
B
B
A
A
B
B
A
A
B
B
A
A
B
B
A
6858 6859
0032 0033

Insert dowels in left
and right
end panels into cams
in rail then lock.
Now insert dowels in
top into cams
in left and right
end panels then
lock.
B
Turn cam 180 degrees
to lock
A
6
Assembly Instructions
Step 4
Step 5
6858
6860
A
6859
0376
6858
B
A
6859
Insert dowels in left
and right
end panels into cams
in rail then lock.
Now insert dowels in
top into cams
in left and right
end panels then
lock.
B
Turn cam 180 degrees
to lock
A
0032
0034
A
0033
0377
0032
B
A
0033
0376
6858
6859
6860
0377
0032
0033
0034
Assembly of large
table
Assembly of small
table
Front grooved edge
Front grooved edge

Assembly Instructions
Step 6 Fittings you will need for this step:
7
Cardboard
packing piece
DIAG 1
DIAG 2
Locate the notch on
trim into
groove on ends
and .
Ensure the
trims are positioned
correctly (DIAG 1).
To insert trims
use a hammer, place a
cardboard packing piece
between the hammer
and trims to
protect the
trims (DIAG 1).
Ensure trims
are inserted fully
(DIAG 2).
Attach trims
6858
Warning:
Lift with care.
6858
(x2)
Trims
If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123
Please have the following information: Unit Description, Product Code, Product Colour,
Place of Purchase, Catalogue Ref. No., Item Code, and have the assembly instructions close
to hand.
You can also e-mail your requests to us at: [e-mail]
Simply contact us on CUSTOMER HELPLINE : 01709 534123 Between 8am - 4.30pm
Monday to Thursday and 8am - 2.30p.m friday. Your statutory rights are not affected.
Alternatively Write to us at: Customer Service Department, Addspace Furniture Limited,
Braithwell Way, Hellaby Industrial Estate, Hellaby, Rotherham, South Yorkshire, S66 8QY.
We do have an answer machine should you contact us out of office hours, so in addition to
the above information could you leave your name, address, daytime telephone number and
the nature of your call on the answerphone. All calls will be actioned asap.
Important Information
Congratulations!
Your unit is complete.
6859
6858
6859
6859
Your trims may have a
protective film on. Please
remove this after assembly
