J D Williams 2 Drawer Entertainment Center User manual

Product size:
H722 x W714 x D358
2 Drawer Console Table
Assembly instructions
Product Code : 054xx8547
MADE IN
GREAT BRITAIN

Warnings
2 Drawer Console Table Assembly Instructions
Before you start
Important: Retain these instructions for future reference.
Unwrap all packaging materials and place the components
on top of the carton box or on a clean oor to prevent it
from scratching.
This product should only be used on rm level ground.
Keep small parts out of reach of children.
Do’s
Dont’s
Follow each assembly step in order to prevent incorrect
assembly.
Assemble on a clean soft surface to avoid damage.
Check the pack and make sure you have all the parts listed.
Ensure that this product is fully assembled as illustrated
before use.
Make sure all screws are fully tightened before use.
When you are ready to start, make sure that you have the
right tools, plenty of space and a clean, dry area for
assembly.
We do not recommend the use of power tools to
construct this product.
Do not sit or stand on the product.
Do not overtighten screws or bolts.
Do not use this product if parts are missing, damaged or
worn.
Number of people required to assemble
One person to assemble the unit and two people to lift the
unit into position.
Time to assemble
Tools required
notsupplied
Pozi (large)
notsupplied notsupplied
notsupplied
Pozi (Small)
supplied
2
60 minutes.

2 Drawer Console Table Assembly Instructions
3
If you need help or have damaged or missing parts, call the Customer Helpline:
01709 534 123
Please have the following information to hand:
>> Unit Description
>> Product Code
>> Product Colour
>> Place of Purchase
>> Catalogue Ref. No.
>> Item Code
>> Assembly Instructions
You can also e-mail your requests to us at:
customer[email protected]
Alternatively, you can write to us at: Customer Service Department, Addspace Furniture Limited,
Braithwell Way, Hellaby Industrial Estate, Hellaby, Rotherham, South Yorkshire, S66 8QY.
We do have an answer machine should you contact us out of office hours, so in addition to
the above information could you leave your name, address, daytime telephone number and
the nature of your call on the answerphone. All calls will be actioned asap.
(by contacting the customer service line your statutory rights are not affected)

2 Drawer Console Table Assembly Instructions
Getting to know your product
4
1
2
6
3
5
4
7
8
11
12
13
10
14
11
12
13
10
9

2 Drawer Console Table Assembly Instructions
Components supplied (not actual size)
5
70
80
90
100
110
0
10
20
30
40
50
60
mm
140
150
160
170
120
130
180
190
200
210
220
230
240
250
260
270
280
714 x 358 x 22
(0740)
Ref Dimensions(mm) Visual Qty
1
1
1
1
1
1
1
330 x 157 x 15
668 x 348 x 15
288 x 298 x 3
276 x 100 x 12
300 x 100 x 12
330 x 157 x 15
300 x 100 x 12
12
14
(623
xx 7002)
(622
xx 7002)
(624
xx 7003)
1
2
2
2
1
2
1
1
668 x 354 x 15
(0741)
2
700 x 356 x 22
700 x 356 x 22
(0742)
3
160 x 322 x 15
(0744)
(0743)
4
668 x 76 x 15
(0746)
5
668 x 60 x 15
(0748)
6
9
(0747)
8
(0697)
7
10
11
(0745)
13
(4883)
(760 00 1103)
(760 00 3004)
(760 00 3005)
(700 00 3510)
(690 00 1008)
Ref Visual QtyQty
1
J
12.0 x 11
C4
16
2
15.0 x 12
A
Ref Dimensions Visual Qty
20
24
5.0 x 35
B
E8
1
5.5 x 8
F
D
G
3.5 x 12
Fixtures and ttings supplied (actual size)
Fixtures and ttings supplied (not actual size)
L1
R1
2
Pair
2
Pair
L2
R2
(760 xx 7000)
(760 xx 7000)
(760 xx 7000)
(760 xx 7000)
(690 00 1075)
3.5 x 45
3.5 x 13
(690 00 1099)
(760 00 1901)

2 Drawer Console Table Assembly Instructions
6
12
34
5
B
notsupplied
Pozi (large) 5.0 x 35
B x4
C
C
12.0 x 11
C x4
notsupplied
Pozi (large)
Your furniture is assembled using a cam lock and dowel
system. This system combines a quick and easy
assembly with strength and a clean nish. Screw the
cam dowel into the panel in the positions shown.
Take care to ensure that the dowel is straight,
and is inserted the full length of the threaded
section.
Insert the cam lock into the face of the panel in the
positions shown.
Ensure that the cam arrow points towards the edge
with the hole as shown; this allows the head of the
cam dowel to locate properly in the cam lock.
a
b
Using a hand screwdriver, turn the cam
clockwise until hand tight. This will take less
than one full turn and will tighten the cam on
the dowel, pulling the panels together
to create a tight joint.
C
B
B
Connect the drawer sections together by inserting
the wooden dowels (already located) in the back
drawer section to the left and right hand drawer
sections
C
B
10
11
10
11
12
8
SLIDE!
10
13
8
11
12
Plain chipboard
surface to the underside
REPEAT ON REMAINING DRAWER

2 Drawer Console Table Assembly Instructions
7
7
7
L2
F
F
You will need to
repeat this step on
both sides of the
drawer section.
Pozi (large) 3.5 x 12
Fx12
notsupplied
R2 x2 &L2 x2
13
12
8
10
11
F
6
B
B
B
B
B
B
notsupplied
Pozi (large) 5.0 x 35
B x6
1
REPEAT ON REMAINING DRAWER

2 Drawer Console Table Assembly Instructions
8
8
9
15.0 x 12
A x2
3
notsupplied
Pozi (large) 5.0 x 35
B x7
2
14
6
5.5 x 8
E x2 L1 x1
3.5 x 12
Fx1
1ST
Wheel
E
1.
15.0 x 12
A x14
B
B
B
B
B
B
1ST
Wheel
E
1.
F
2.2.
A
A
Ensure you attach the runners into the correct holes, as shown on the illustration below.
Once you have attached the front of the runner, align the runner and attach the back of
the runner with another E screw into the corresponding hole.
L1
L1
7
B
A
A
A
A
A
A
A
A
A
A
A
A
A
A

2 Drawer Console Table Assembly Instructions
9
10
14
11
15.0 x 12
A x2
notsupplied
Pozi (large) 5.0 x 35
B x7 5.5 x 8
Ex2 R1 x1
3.5 x 12
Fx1
Ensure you attach the runners into the correct holes, as shown on the illustration below.
Once you have attached the front of the runner, align the runner and attach the back of
the runner with another E screw into the corresponding hole.
B
B
B
B
BB
B
1ST
Wheel
E
1.
F
2.
R1
R1
4
15.0 x 12
A x2
A
A
A
A
5

2 Drawer Console Table Assembly Instructions
10
12
14
13
notsupplied
Pozi (large)
notsupplied
Pozi (large)
Now turn divider panel over.
5.5 x 8
E x2 L1 x1
3.5 x 12
Fx1
1ST
Wheel
E
1.
1ST
Wheel
E
1.
F
2.2.
L1
L1
1ST
Wheel
E
1.
F
2.
R1
R1
5.5 x 8
Ex2 R1 x1
3.5 x 12
Fx1
5
5

notsupplied
Pozi (large)
notsupplied
Pozi (large)
2 Drawer Console Table Assembly Instructions
11
14
14
15
4
4
14
7
26
C
B

notsupplied
Pozi (large)
notsupplied
Pozi (large)
2 Drawer Console Table Assembly Instructions
12
16 17
14
18
3
5
1
1
4
3
7
14
26
Lay the unit on its front
Attach the top (1) to the end panels rst and secure the
cams.

Stand the unit upright.
Tilt the assembled drawer as shown
to attach the drawer to the already
located runners.
notsupplied
Pozi (large)
3.5 x 45
D x1
Stand the unit on its top
Insert screw D into the rail (7) and screw into
the divider panel (5). Use the groove in the divider
panel (5) as a guide for your screw.
D
2 Drawer Console Table Assembly Instructions
13
19
20
8
9
5
7

2 Drawer Console Table Assembly Instructions
14
21
23
19
19
REV. A
STAND THE UNIT UPRIGHT - TWO PEOPLE REQUIRED.
We recommend that this unit is xed to a suitable wall to prevent possible
overbalancing. We have included a xing bracket for this. No xing screws
are provided as they will need to suit the wall type, and the length of
screw will depend on the distance from the back of the unit to the
wall. Please ensure xings used are appropriate to your wall type. Locate the
bracket to the top panel or to the end panel as close to top as possible. We do
not specify exact location for the bracket,this is left to the customer’s discretion.
Please take care when drilling into the wall, avoiding any pipes and wires.
The use of residual current device (RCD) is recommended when
working with tools.If in doubt consult a qualied person.
Warning:
2 people to lift.
Lift with care.
Warning:
3.5 x 13
G x2 J x1
notsupplied
Pozi (large)
IN ORDER TO PREVENT OVERTURNING
THIS PRODUCT MUST BE USED WITH
THE WALL ATTACHMENT DEVICE
PROVIDED
Serious or fatal crushing injuries can occur from
furniture tipping over. To help prevent topple over:
An attachment device is provided with your
product. However you will need to source
suitable fixings for your wall type. If in doubt,
please consult a qualified trades person.
Always ensure the wall to be drilled is free
from hidden electrical wires, water and gas
pipes.
Use the wall attachment device provided.
Never allow children to climb or hang on
drawers, doors or shelves.
Place heaviest items in the lower drawers
or shelves.
Unless specifically designed to accomodate,
do not set TV’s or other heavy objects on
top of this product.
Never open more than one drawer at a time.
WARNING

2 Drawer Console Table Assembly Instructions
15
Notes

2 Drawer Console Table Assembly Instructions
16
Notes
