J D Williams Aspen User manual

Assembly Instructions - Please keep for future reference
Width - 66.8cm
4 Drawer Chest
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123
Please turn to back page for important information when contacting Customer Helpline.
Dimensions
Depth - 35.2cm
Height - 72.4cm
Rev B - 01/02/2017
002 xx 6641
MADE IN
GREAT BRITAIN

Important - Please read these instructions fully before starting assembly
Safety and Care Advice
Check you have all the
components and tools listed on
pages 2 and 3.
Remove all fittings from the
plastic bags and seperate them
into their groups.
Keep children and animals
away from the work area, small
parts could choke if swallowed.
Make sure you have enough
space to layout the parts before
starting.
Do not stand or put weight on
the product, this could cause
damage.
Assemble the item as close
to its final position (in the same
room) as possible.
Assemble on a soft level
surface to avoid damaging the
unit or your floor.
Parts of the assembly will be
easier with 2 people.
We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
Care and maintenance
Always lift furniture when
moving it (do not drag)
otherwise the joints may be
damaged.
From time to time check that
there are no loose screws on
this unit.
This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
1
Dust surfaces with a soft, dry,
lint free cloth.
More stubborn marks can be
removed using a damp
(not wet) cloth. Wipe the
surface dry immediately
using a soft lint free cloth.
Do not use detergents, abrasive
cleaning products or cleaning
products that contain ammonia,
solvents or silicone as these
may damage the surface finish.
To protect the furniture,
position the furniture out of
direct sunlight and away from
direct heat sources such as
radiators and fires.
Do not place the furniture in
excessively dry and humid
conditions.
Do not place hot or cold
objects on the surface, always
use protective mats to avoid
marking the furniture.
Clean spills up immediately
Dispose of all packaging
carefully and responsibly
when assembly complete.
Do Not dispose of packaging
until assembly complete.

Please check you have all the panels listed below
Components -Panels
2
Important - Thick lines indicate finished edges
Top (66.8x35.2cm)
5385
End Panel x 2
(64.4x32.8m)
0314
Backpanel (67.0x66.0cm)
7225
Drawer Front x4
(66.0x15.6cm)
4717
Drawer Bottom x4
(61.2x29.8cm)
5671
Bottom (66.8x35.2cm)
5377
624xx7010
Left drawer side x 4
(30.0x10.0cm)
Drawer back x 4
(60.1x10.0cm)
Right drawer side x 4
(30.0x10.0cm)
622xx7002
623xx7002

3
70 80 90 100 110 120
010 20 30 40 50 60
mm
130 140 150 160 170
Ruler - Use this ruler to help correctly identify the screws
Please check you have all the fittings listed below
Components - Fittings
Note: The quantities below are the correct amount to complete the assembly, In some case more
fittings may be supplied than are required.
Tools required
If you have damaged or missing components, call the
Customer Helpline: 01709 534123 Please turn to back page
for important information when contacting Customer Helpline.
Cross headed screwdriver
(medium & large )
Small Hammer
Tape Measure
Eye protection
(when using a
hammer)
Large cam x 4
Code 760001103
Metal dowel x 12
Code 760003004
ABC
E
DF
Small cam x 8
Code 760003005
8mm screw x 16
Code 700003510
Panel pin x 25
Code 760001012
Panel pin guide x 1
Code 684004501
Runner x 8
Code 760001040
HJ
9mm bolt x 8
Code 690001078
K
LMN
OP
7/8” CSK Screw x 4
Code 690001018
M4x20 Bolt x 8
Code 700002006
Assembly Screw x 4
Code 690001075
Pine Glide Foot x 4
Code 720006001
Timber Knob x 8
Code 640031118
O
White Glide Foot x 4
Code 720365001
P
Ceramic Knob x 8
Code 640006001
IMPORTANT: Depending on the colour variation you purchased this unit in, you will have
one of the handles and glide feet shown above.
Wooden Dowel x 4
Code 770001006
Bradawl
R
Q
L Bracket x1
Code 760001901
Screw x 2
Code 690001099

Exploded View
4
0314
5671
Drawers x4
622xx7002
4717
624xx7010
623xx7002
0314
5385
7225
5377

Fitting cams and
dowels to the end
panels.
A
Insert 2 cams to the
end panels .
Insert 2 wooden dowels
into the inner holes in
end panels .
0314
Step 1
Assembly Instructions
5
B
x4
B
Fitting dowels to top
panel.
Step 2
B
A
5385
B
B
B
B
Insert 4 metal dowels
into the top panel 5385
Note: Tighten metal
dowels up fully against
the panel.
Do not over-tighten.
A
x4
K
0314
0314
0314
A
A
Important :-
Lay end panels out
as shown
A
A
Important :-
Lay end panels
out as shown
K
K
K
Use a hammer to
knock in wooden dowels
into inner holes.
K
K
x4
K
K

Assembly Instructions
6
0314
Step 3
H
H
EE
Important :-
Lay end panels out
as shown
Position the runner so
that the front hole
of the runner lines up
with the pre-drilled hole
nearest to the edge of
the panel.
Use screws to secure
the runner.
Slide the runner forward
revealing the back of the
runner. The third hole
to the back of the runner
should now line up with
the second pre-drilled
hole.
Repeat to add runners
to additional holes.
E
Front of runner
H
x8
E
x16
Attaching runners to
end panels
0314
Important :-
Lay end panels
out as shown

C
Assembly Instructions
7
x8
C
Step 5
A
B
B
4717
Step 4
Fitting dowels to
drawer fronts.
B
Insert 2 metal dowels
into the the drawer
fronts .
Repeat on the remaining
drawers.
4717
x8
B
M
x8
P
x8
Assemble the drawer.
A: Insert small cams
into left
and right
drawer sides.
Note: Ensure cam arrow
points towards the edge
with hole.
Left hand side
Right hand side
622xx7002
623xx7002
622xx7002
623xx7002
C
C
B: Insert wooden dowels
in drawer back
into holes in
left
right hand
drawer sides.
Left hand side
622xx7002
623xx7002
624xx7010
622xx7002
B
Drawer Back
624xx7010
Right hand side
623xx7002

4717
Assembly Instructions
8
E
E:
M
P
Fit bolts through
the pre-drilled holes in
the drawer front
and connect to the handles
.
Repeat on the remaining
drawers.
M
P
4717
4717
C
C: Sit drawer bottom
into groove on
drawer front .
Ensure foil on the drawer
bottom is facing upwards.
624xx7010
Foil surface facing upwards.
Plain chipboard surface
to underside.
D:Locate grooves in left
and right drawer sides
around the drawer bottom
and slide down, locating
cams already inserted in
left and right drawer sides
onto dowels in drawer
front.
Turn cams 180 degrees
to lock.
D
622xx7002
623xx7002
5671
4717
4717
5671
5671
Step 5 - Continued
M
P

5385
Assembly Instructions
9
Step 6
Step 7
Connect the dowels in
the top panel to
the cams in the end panels
.
Turn cams 180 degrees to
lock.
Connect the top panel
to the left and right
end panels.
5385
0314
Locate the wooden dowels
in the end panels
into the inner holes in the
bottom panel .
Use screws to secure.
Connect the bottom
panel to the end panels.
0314
5377
Step 8
Squaring up the unit.
IMPORTANT!
Before securing the back
it is necessary to square
up the unit.
You can do this by
measuring between
XX - XX and YY - YY
ensuring these are the
same (DIAG 1).
If they are not (DIAG 2)
Apply slight pressure as
indicated (DIAG 3) until
they are the same.
Ensure a tape
measure is used
to square unit up.
DIAG 3
DIAG 1
XX
XX
YY
YY
XX
XX
YY
YY
0314
DIAG 2
XX
XX
XX
XX
YY
YY
YY
YY
0314
0314 5377
0314
Overhang
to the floor
Panels sit flush
Overhang
to the floor
Panels sit flush
N
x4
N
N
N
N
N

Assembly Instructions
10
Step 9
D
F
D
x25
F
x1
Attach the back panel
to the unit.
Use the panel pin guide
when locating the panel
pins. This will hold the
panel pins vertical and
ensure the correct
distance from the edge.
Stand the unit on its
top once this step is
complete.
7225
TAPED SIDE TO
BACK
Step 10
Attach feet to bottom
panel
L
x4
O
x4
Use 4 screws to attach
feet to bottom panel
.
L
5377
O
Use a bradawl to mark
the holes for the feet.
Stand the unit upright
once this step is
complete.
May require 2 people.
O
O
O
O
L
L
L
L
5377

Assembly Instructions
11
Step 11
Fit the drawers.
Stand the unit up.
For this step we
recommend you follow
the helpful hints on the
next page.
2nd Hole
J
x8
J

Assembly Instructions
12
Step 12
a: Pull sliding part of
drawer runners out
so they are fully
extended.
Locate drawers helpful
hints
H
b: Locate drawer onto
runners.
c: Locate screwdriver
into second threaded
hole in drawer runner .
d: Keeping screwdriver
in place push the drawer
in until the screwdriver
pushes against the
panel.
Remove the screwdriver.
e/f: Pull drawer out slowly
and line the front hole in the
drawer side with the 2nd
threaded hole in runner .
Holding runner and
drawer side together
insert bolts through the
drawer side and
into threaded hole in
runner .
J
J
Now repeat these
steps for the other
side of the drawer.
J
D
EF
AB
C
2nd Hole
H
2nd Hole
J
L
L
L
L
L
J
H
H
H
H
H
H

Assembly Instructions
13
Step 13
We recommend that this
unit is fixed to a suitable
wall to prevent possible
overbalancing. We have
included a fixing bracket
for this. No fixing screws
are provided as they will
need to suit the wall
type, and the length of
screw will depend on
the distance from the
back of the unit to the
wall. Please ensure
fixings used are
appropriate to your wall
type. Locate the bracket
to the top panel or to the
end panel as close to
top as possible. We do
not specify exact
location for the bracket,
this is left to the
customer’s discretion.
Fixing to wall
Please take care when
drilling into the wall,
avoiding any pipes and
wires. Wear safety
goggles when drilling.
The use of residual
current device (RCD) is
recommended when
working with tools.If in
doubt consult a
qualified person.
Warning:
2 people to lift.
Lift with care.
With help move the
unit into position.
Warning:
Q
x1
R
x2

Assembly Instructions
Congratulations! Your unit is complete.
Important Information
If you need help or have damaged or missing parts, call the Customer Helpline:
01709 534123 8am - 4.30pm (Monday toThursday)
8am - 2.30pm (Fridays)
Please have the following information to hand:
>> Unit Description
>> Product Code
>> Product Colour
>> Place of Purchase
>> Catalogue Ref. No.
>> Item Code
>> Assembly Instructions
You can also e-mail your requests to us at:
[e-mail]
Alternatively, you can write to us at: Customer Service Department, Addspace Furniture Limited,
Braithwell Way, Hellaby Industrial Estate, Hellaby, Rotherham, South Yorkshire, S66 8QY.
We do have an answer machine should you contact us out of office hours, so in addition to
the above information could you leave your name, address, daytime telephone number and
the nature of your call on the answerphone. All calls will be actioned asap.
(by contacting the customer service line your statutory rights are not affected)
