J2 615 User guide

J2 615
Integrated Touchscreen Computer
System Manual
March 2010

615 System Manual
Version 1.0 March 21, 2010
2
Copyright © 2009, 2010 J2 Retail Systems
Change history
Version 0.1 to Version 1.0
1: Fix cable pin out RJ45 to DB25 J2 Serial Cable, RTS DB25 pin wrong, DB25 SD and
RD signals marked wrong.
2: Fix cable “Pin-out when using 8 wire CAT5/6 cable”, RTS DB25 and DSR pin wrong,
DB25 SD and RD signals marked wrong.

615 System Manual
Version 1.0 March 21, 2010
3
Contents
Overview............................................................................................................................ 5
Specifications..................................................................................................................... 7
System ................................................................................................................................ 9
Front View...................................................................................................................... 9
Rear View ....................................................................................................................... 9
I/O Ports........................................................................................................................ 10
Atom Processor............................................................................................................. 10
System Memory............................................................................................................ 10
On /Off Button.............................................................................................................. 10
Solid State Drive / Hard Disk Drive............................................................................. 11
Touch Screen ................................................................................................................ 12
System Board................................................................................................................ 12
LCD Display................................................................................................................. 13
Secondary Display Port................................................................................................. 13
USB ports...................................................................................................................... 14
Ethernet Connection...................................................................................................... 14
Serial ports.................................................................................................................... 14
Audio............................................................................................................................. 17
Cash Drawer Port.......................................................................................................... 17
CMOS Reset ................................................................................................................. 19
Onboard SSD................................................................................................................ 19
Mini PCI-E.................................................................................................................... 20
Power Supply................................................................................................................ 20
Typical Power Consumption 615.................................................................................. 21
Packing List..................................................................................................................... 22
Standard Items .............................................................................................................. 22
System Installation.......................................................................................................... 23
Counter Top Base ......................................................................................................... 23
Optional VESA / Wall Mount Bracket Installation...................................................... 25
MSR Installation........................................................................................................... 26
SSD/HHD Access......................................................................................................... 27
Removing the Power Supply Adaptor .......................................................................... 28
BIOS Settings .................................................................................................................. 29
Starting the BIOS Setup................................................................................................ 29
When a Problem Occurs ............................................................................................... 29
BIOS Menus.................................................................................................................. 29
Driver Installation........................................................................................................... 31
Driver Download .......................................................................................................... 31
Additional Drivers/Utilities .......................................................................................... 31

615 System Manual
Version 1.0 March 21, 2010
4
Optional Items................................................................................................................. 32
Customer Display Option............................................................................................... 33
Connecting the Cable for a J2 615/580 customer display............................................. 33
Dip Switch and Software Setting.................................................................................. 33
J2 615/580 UPS................................................................................................................ 35
Specifications................................................................................................................ 35
Hardware....................................................................................................................... 35
Software Setup in XP.................................................................................................... 36
Status LED.................................................................................................................... 38

615 System Manual
Version 1.0 March 21, 2010
5
Overview
Featuring the Intel 1.6GHz Atom processor and Intel chipset the new J2 615 computer
provides outstanding price and performance. Designed with reliability and durability in
mind it incorporates a SanDisk 8GB Solid State Drive (SSD) as standard and with its
fanless convection cooled system, there are no moving parts to fail. Using ELO touch
controllers as well as an ELO resistive touch screen the 615 provides unmatched touch
responsiveness and reliability. For extremely high transaction applications an IR touch
screen version is also available, known in the industry because they have no known
“wear out” mechanism.
Full featured I/O ports include four serial, four USB, a 1gigabit Ethernet and a cash
drawer port. The J2 615 does not compromise quality and provides one of the most cost
effective integrated touch screen computer solutions available in the market today. It
supports all Microsoft®Windows®Embedded operating systems, including Windows XP
Pro for Embedded Systems, XP Pro, Windows XP Embedded, POSReady 2009,
Windows CE 6.0 plus MS-DOS®and Linux™.
The J2 615 comes standard with an 8GB SATA SSD and is more than capable of running
all the above mentioned operating systems, plus applications, with room to spare. This
makes this amazing computer perfect for either thick or thin client applications. With no
moving parts and a MTBF rated in tens of years, the SSD in the 615 is perfect for the
POS market and other touch screen applications. If required it can also be supplied with a
HDD or a larger size SSD, please contact your J2 sales person for more details.
The “all in the head” design means that the J2 615 can serve as a counter top, or as a wall
or a pole mounted unit all in the same computer. With the standard counter top base and
optional VESA/wall mount brackets, the versatile 615 can fit numerous touch screen
applications. The small footprint with the 15-inch LCD display is particularly compact
and makes it ideal for the space conscious retailer. The front swipe MSR can be mounted
side by side and fits easily in narrow niches.
Using the new Intel 1.6GHz Atom processor and Intel 945GSE/ICH7chipset the J2 615
computer is the ultimate system to handle most POS applications and is also extremely
cost effective.

615 System Manual
Version 1.0 March 21, 2010
6
J2 615 Intrgrated Touch Screen Computer

615 System Manual
Version 1.0 March 21, 2010
7
Specifications
Main board
Processor Intel N270 1.6GHz Atom processor
Chipset Intel945GSE/ICH7 chipset
System Memory SO-DIMM DDR 533HMz, 1GB Standard, 2 GB optional
LCD Touch Panel
LCD Size 15” TFT LCD
Brightness 250 nits
Resolution 1024 x 768
Touch Screen ELO Resistive 5-wire or optional ELO Infrared (IR)
Tilt Angle 0゜~ 90゜
Storage
SSD or HDD 8GB SATA SSD in a quick change slot or an 80GB SATA 2.5” HDD
Expansion
Mini-PCI-E Slot One, normally used for an internal 802.11n wireless card
I/O Ports
Rear I/O
USB 4 USB located in the cable well
SERIAL 4 Serial Ports, RJ 45, power on serial ports 3&4
LAN One Gigabit, RJ45 in cable well (Realtek RTL8111)
2nd VGA Optional 12” or 10.4”secondary customer-facing display, powered
from the J2 615 (or other external monitor), up to 2048 x 1536
Cash Drawer RJ 11 (24V or 12V) with status, can support two cash drawers
DC Jack Power in, 19VDC 3.42 amps
Audio Jack Line-out
Front I/O Indicator
Power LED Green - for system power on
Power
Power Adaptor 19VDC, 65W, 100-240 VAC, 1.8A MAX
Optional Peripheral
MSR 3 Track (on PS2 port, wedge type)
iButton Dallas Key iButton/MSR (on PS2 port, wedge type) or iButton only
Biometrics MSR/Finger Print Reader (Digital Persona) or Finger Print Reader
only
WIFI Optional internal 802.11n (a/b/g compatible) wireless LAN

615 System Manual
Version 1.0 March 21, 2010
8
Second Display 10.4" or 12” Second LCD display, with or without touch,
powered from the J2 615
Customer
Display Customer Side VFD display with 2 x20 characters, powered from 615
UPS 2 hour DC UPS, mounts in base of unit
Mounting
Standard Counter Top Base, Adjustable Viewing Angle 0-90°
Optional Wall Mount /VESA Mount Bracket
Optional Optional adjustable angle VESA/Wall Mount Bracket
Environment
EMC & Safety FCC, Class A, CE, LVD
Operating
Temperature 0 ~ 40℃
Storage
Temperature -20 ~ 55℃
Operating
Humidity 20% ~ 80% RH non-condensing
Storage
Humidity 20% ~ 85% RH non-condensing
Dimensions
(W x D x H) 370 x 250 x 340mm
Weight 7.45kg
OS Support XP Pro for Embedded, POSReady 2009, XP Embedded Standard,
Windows CE 6.0, Linux, DOS
* This specification is subject to change without prior notice.

615 System Manual
Version 1.0 March 21, 2010
9
System
The J2 615 uses the same dynamic design as the J2 580 and J2 650 computers. This
allows for different systems to be integrated at the same customer site, maintaining a well
balanced look and feel for your important installations.
Front View
Rear View
MS
R
I/O Ports
Power LED
SSD/HDD
Module
ON/OFF BUTTON

615 System Manual
Version 1.0 March 21, 2010
10
I/O Ports
The J2 615 has an integrated design with all the electronics “in the head”. I/O ports are
accessible in the cable well at the bottom of the unit (please see below):
,
Atom Processor
The J2 615 uses the new Intel Atom N270 processor which only requires 2.5 watts of
power. With a speed of 1.6GHz, a 512MB second level cache as well as an FSB speed of
533MHz, the 615 provides the performance necessary for thin as well as most thick POS
software applications. Used in conjunction with the Intel 94GSE chipset this processor
provides excellent video performance and is more than capable of running a secondary
monitor with full screen video at high resolution in addition to running a POS
application.
System Memory
The J2 615 comes standard with 1GB 533MHz of memory. The system has one memory
socket and uses SO-DIMM DDR2 533MHz type memory. The unit supports a maximum
of 2GB of memory.
On /Off Button
The On/Off button is located in the cable well, as shown above. This button is located
especially to prevent accidental powering down by the user. The function of the button
can be controlled by the OS; should the J2 615 hang for some reason, note that it can
always be powered off by holding the On /Off button in for six seconds.
The J2 615 also supports the following: Restore On AC power loss, Wake On LAN, and
Wake On RTC alarm features control the system’s power up. Please see the BIOS setup
section of this manual as well as the J2 white paper entitled “Reducing Your Carbon
Footprint in the POS Environment”.
DC-IN
LAN
Audio OutUSB
Cash Drawer
COM 1 2, 3, 4
VGA ON/OFF BUTTON
