Model 1000--FS
Hydraulic Powered Breaking Saw
EQUIPMENT
SELECTION Ordering No..............
®
Adjustable Handles
Chine Bone
Standard Tool

noticetoemployer
and safety director
Model 1000--FS page 2 of 16
®
JARVIS PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457--4926
UNITED STATES OF AMERICA
TEL. [phone] FAX. [phone]
6207001:::
NOTICE TO EMPLOYER AND SAFETY DIRECTOR
AVOID INJURY
1. Remove and repair any tool which malfunctions. All personnel must be instructed to remove any mal-
functioning equipment.
2. Ensure that all employees who use this tool are trained in the proper use of this tool and are aware of
the dangers that may arise if they do not follow procedures outlined in this brochure.
3. Ensure that all employees are instructed not to walk in front of the tool during its use.
4. Enclosed are four (4) copies of “NOTICE TO OPERATORS, MAINTENANCE AND CLEANUP
PERSONNEL.” Post one copy on the employees’ bulletin board; give one copy to the operator(s);
give one copy to the maintenance foreman; and give one copy to the sub--contract cleanup / internal
cleanup foreman. Additional copies will be provided upon request.
5. The tool is designed and intended to be powerful. This fact should be obvious to your employees, but
you must emphasize it to them.
6. Never make modifications or alterations to the tool. Replace any missing or illegible labels.
7. Ensure that proper procedures are established (in accordance with OSHA’s lockout/tagout procedures
29 CFR 1910.147) to prevent accidental startup or release of stored energy.
8. Ensure that employees wear eye protection in accordance with OSHA’s eye and face protection re-
quirements (29 CFR 1910.133) at all times.
9. Follow our installation and maintenance instructions for proper installation and care of the tool.
10. Avoid injury. Do not permit the tool to be misused.
11. If you resell or distribute a Jarvis product, you must provide the purchaser with the appropriate safety
sheets and tool brochure. Additional copies of safety sheets and tool brochures will be provided upon
request.

notice to operators, maintenance
and cleanup personnel
Model 1000--FS
page 3 of 16
®
JARVIS PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457--4926
UNITED STATES OF AMERICA
TEL. [phone] FAX. [phone]
6207001:::
NOTICE TO OPERATORS, MAINTENANCE AND CLEANUP PERSONNEL
REMOVE ANY MALFUNCTIONING TOOL FROM SERVICE
REPORT ANY PROBLEMS TO YOUR SUPERVISOR
1. Disconnect all hydraulic hoses and shut the power off in accordance with OSHA’s lockout/tagout pro-
cedures (29 CFR 1910.147) before making any blade changes.
2. Disconnect all hydraulic hoses and shut the power off in accordance with OSHA’s lockout/tagout pro-
cedures (29 CFR 1910.147) before performing any repair or maintenance.
3. Disconnect all hydraulic and hoses and shut the power off -- or have all hydraulic hoses disconnected
and the power shut off -- in accordance with OSHA’s lockout/tagout procedures (29 CFR 1910.147)
before performing any cleanup.
4. Disconnect all hydraulic hoses and shut the power off when the tool is not being used.
5. Clean up any spilled or leaked hydraulic fluid.
6. Always wear eye protection in accordance with OSHA’s eye and face protection requirement (29 CFR
1910.133).
7. Never put fingers, hands, or other parts of the body on the blade or within the cutting path of the tool.
8. Never allow people to walk in front of the tool during its use.
9. Never allow people to hold/restrain the carcass.
10. Test the tool prior to use or daily. Depress each trigger separately and the tool should not start. Depress
both triggers simultaneously and the tool should start. Release either trigger and the tool should stop.
If the tool malfunctions, remove it from service and report or repair it immediately.
11. Never depress the triggers unless you want to use the tool.
12. Never make modifications or alterations to the tool. Report or replace any missing or illegible labels.

parts diagram and list
Model 1000--FS page 4 of 16
®
JARVIS PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457--4926
UNITED STATES OF AMERICA
TEL. [phone] FAX. [phone]
6207001:::
1 1010074 Dowel Pin 4
2 3020018 Shaft and Pin Assembly 1
(includes item 1)
3 1519140 Woodruff Key 1
4 1055052 Flat Head Screw 3
5 1002107 Bearing Cover 1
6 1511045 Ball Bearing 1
7 3026021 Gear Set (bevel and pinion) 1
3026066 Gear Set (380 mm)
8 1029093 Spacer 1
9 1511035 Ball Bearing 1
10 1516032 Lock Nut 1
11 1050216 Pipe Plug 1
12 1038002 Grease Fitting 1
13 3016114 Gear Housing 1
3016323 Gear Housing, Left Side
14 1021116 Ball Bearing 1
15 1514304 Retaining Ring 1
16 1029094 Spacer 1
17 1021029 Ball Bearing 1
18 1013103 Threaded Ring 1
19 1014055 Spring 2
20 1018082 Trigger Lever 1
21 1063002 Magnet 1
22 1055452 Flat Head Screw 2
23 1061200 Magnet Housing 1
24 1055124 Set Screw 1
25 1004073 Lock Washer 2
26 1055084 Button Head Screw 2
27 1055026 Set Screw 1
28 1019075 Handle 1
29 1055482 Pan Head Screw 4
ITEM PART NO. PART NAME QTY
30 1017081 Danger Label 1
31 1024050 Blade Guard 9” 1
1024223 Blade Guard 9” Adj. Hdls.
1024178 Blade Guard 9”, LS
1024051 Blade Guard 101/2”
1024224 Blade Guard 101/2” Adj. Hdls
1024221 Blade Guard 101/2”, LS
1024052 Blade Guard 12”
1024225 Blade Guard 12” Adj. Hdls.
1024187 Blade Guard 12”, LS
1024275 Blade Guard 380 mm
32 1010172 Roll Pin 2
33 1005046 Reed Switch 1
34 1050241 Elbow 1
35 3059017 Hose Assembly (Elec.) 1
36 1055310 Flat Head Screw 2
37 1055049 Socket Head Screw 1
38 1070004 Blade Wiper, 9” 1
1070006 Blade Wiper, 9” LS
1070005 Blade Wiper, 101/2” and 12”
1070010 Blade Wiper, 380 mm
39 1055001 Flat Head Screw 2
40 1023102 Saw Blade 9” 72 Teeth 1
1023010 Saw Blade 9” 130 Teeth
1023228 Saw Blade 9” Noise Red.
1023111 Saw Blade 101/2”
1023112 Saw Blade 12”
41 1004025 Blade Retaining Flange 1
42 1004093 Lock Washer 1
43 1055045 Hex Head Screw 1
3019031 Front Handle Assembly (incl
items 19--24, 27, 28, 32--34)
3016115 Housing and Gear Assy.
3016322 Housing and Gear Assy, LS
(includes items 1--18 and
41--43)
ITEM PART NO. PART NAME QTY
Figure A
Note: Figure A above depicts the 1000--FS with standard front
handle assembly. Refer to Figure C on page 7 for front and
rear adjustable handle assemblies.

parts diagram and list
Model 1000--FS
page 5 of 16
®
JARVIS PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457--4926
UNITED STATES OF AMERICA
TEL. [phone] FAX. [phone]
6207001:::
44 1011059 Drive Coupling 1
45 1035113 O--ring 1
46 1055328 Hex Head Screw 10
47 1061198 Motor Adapter 1
1061915* Motor Adapter, Adj. Hdls.
1071057 Motor Adapter, 380 mm
48 1030031 Square Key 1
49 1020136 Splined Shaft 1
1020350* Splined Shaft, Adj. Handles
1020372 Splined Shaft, 380 mm
50 1513010 Set Screw 2
51 1011155 Shaft Coupling 1
52 1009076 Alignment Sleeve 1
53 1032154 Motor Mounting Plate 1
54 1008054 Hydraulic Motor 1
1008090 Hydraulic Motor, Left Side
55 1035169 O--ring 2
56 1061140 Hydraulic Motor Adapter 2
57 1013139 Back--up Ring 2
58 1035170 O--ring 2
59 1042116 Hanger 1
60 1017061 Name Plate Label 1
61 1055274 Drive Screw 4
62 1018077 Trigger Lever 1
63 1035123 Thread Boot Seal 1
64 1515009 Dowel Pin 1
ITEM PART NO. PART NAME QTY
ITEM PART NO. PART NAME QTY
65 1019073 Rear Handle 1
1019167 Rear Handle, Left Side 1
66 1513402 Button Head Screw 1
67 1055290 Flat Head Screw 2
68 1035212 Gasket 1
69 1002186 Switch Housing Cover 1
70 1011352 Strain Relief Coupling 1
71 3001006 Wire and Plug Assembly 1
72 1055280 Hex Head Screw 6
73 1005020 Electric Switch 1
74 1050241 Elbow 1
75 1050240 Swivel Connector 2
76 1055965 Plug 2
77 1016222 Motor Housing 1
78 1021233 Bearing Strip 1
79 3059008 Hydraulic Hose Assembly 2
80 1011107 Quick Connect Plug 1
81 1055324 Hex Head Screw 2
82 1011108 Quick Connect Socket 1
3035021 Repair Kit for item 75
3035013 Seal Kit for item 54
3019025 Rear Handle Assy (incl.
items 62--66 and 68--74)
Figure B
Note: Figure B above depicts the 1000--FS with standard
rear handle assembly. Refer to Figure C on page 7 for front
and rear adjustable handle assemblies.
* Used on 4027049 and 4027050 only.

parts diagram and list
Model 1000--FS page 6 of 16
®
JARVIS PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457--4926
UNITED STATES OF AMERICA
TEL. [phone] FAX. [phone]
6207001:::
ITEM PART NO. PART NAME QTY
83 1010273 Threaded Pin 4
84 1014096 Spring 2
85 1021314 Bushing 2
86 1018113 Trigger Lever (incl. item 85) 2
87 1010297 Roll Pin 2
88 1013181 Retaining Ring 2
89 1055335 Hex Head Screw 2
90 1035282 O--ring 2
91 3005017 Switch Assembly 2
92 1002270 Switch Cover 1
93 1055592 Flat Head Screw 3
94 1011305 Strain Relief Connector 1
95 1001058 Electrical Cord 1
96 1042171 Handle Bracket 1
(includes 2 item 89)
97 1010274 Threaded Pin 2
98 1019128 Handle (incl. item 87) 2
ITEM PART NO. PART NAME QTY
99 1004182 Washer 2
100 1055296 Hex Head Screw 2
101 1055326 Hex Head Screw 2
102 1042224 Handle Adaptor Bracket 1
103 1042172 Handle Bracket 1
104 1012045 Clamp 1
105 1055688 Hex Head Screw 1
106 1011292 Strain Relief Connector 1
107 1002272 Cover 1
108 1055591 Flat Head Screw 3
109 1011169 Strain Relief Connector 1
110 1001014 Electrical Cord 6ft
111 1063209 Electrical Plug 1
3019074 Adj. Front Handle Assy (incl.
items 83--100)
3019226 Adj. Rear Handle Assy (incl.
items 83--88, 90, 91, 97--100,
103 and 106--111)
Figure C
Front and Rear
Chine Bone and Adjustable
Handle Assemblies
Note: Figure C above shows orientation of front and rear handle
assembly for left side 1000--FS model. Right side 1000--FS models
require installation of front handle assembly (items 83--100) to be
reversed 180°on opposite side of motor adapter and items 106 and
107 from rear handle assembly reversed 180°on handle bracket
(item 103).

parts diagram and list
Model 1000--FS
page 7 of 16
®
JARVIS PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457--4926
UNITED STATES OF AMERICA
TEL. [phone] FAX. [phone]
6207001:::
1 1008210 Motor 460/230V, 60Hz 1
1008213 Motor 400/230V, 50Hz
2 3016195 Electric Control Box, 115v 1
3016222 Electric Control Box, 230v
3 1011348 Motor Half Coupling 1
4 1011344 Spider Center Coupling 1
5 1011349 Pump Half Coupling 1
6 1022119 Relief Valve Cartridge 1
7 1061758 Return Tubing 1
8 1061279 Supply Tubing 1
9 1034013 Breather Filler Cap 1
10 3008073 Hydraulic Pump 1
11 1025008 Hydraulic Pressure Gage 1
12 1034057 Filter Assembly, Triangular 1
1034059 Filter only, Triangular
1034005* Filter Assembly, Spin on 1
1034006* Filter only, Spin on 1
13 1022029 Dir. Control Valve, 115v 1
1022174 Dir. Control Valve, 220v
ITEM PART NO. PART NAME QTY
1063845 din/iso Coil for 115v Valve
1063846 din/iso Coil for 220v Valve
1063841 din/iso Connector
1063071* Coil, 115v Valve
1063303* Coil, 220v Valve
14 1513147 Socket Head Cap Screw 4
15 1050746 Hex Nipple, 4 inch 1
16 1050747 Hex Nipple, 6 inch 1
17 1050218 Elbow 2
18 1050221 Connector 2
19 3059010 Hose Assembly, 20 ft. 2
20 1022121 Sub Plate with item 6 1
21 1025021 Oil Level Gage 1
22 1034008 Suction Strainer 1
23 1054166 Drain Plug with Magnet 1
24 1011108 Quick Connect Socket 1
25 1011107 Quick Connect Plug 1
1034012* Tubing Kit for Spin on Filter 1
ITEM PART NO. PART NAME QTY
Figure D
Electric--Hydraulic
Power Unit
* Not used in current units

parts diagram and list
Model 1000--FS page 8 of 16
®
JARVIS PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457--4926
UNITED STATES OF AMERICA
TEL. [phone] FAX. [phone]
6207001:::
( ) TERMINAL ON P/C BOARD
(4) (5)
1 1016348 Electrical Enclosure 1
2 1063502 Wire Terminal Fork 7
3 1011240 Strain Relief Connector 3
4 1001153 Cord 1
5 1063208 Twist Lock Cord Outlet 1
6 1001014 Cord 3ft
7 1004211 Sealing Washer 3
8 1017116 Wiring Diagram, 115v 1
1017162 Wiring Diagram, 230v
9 1017012 Electric Warning Label 1
10 1007278 Locking Nut 3
11 1063079 Wire Terminal Ring 1
12 1063146 Circuit Board, 115v 1
1063296 Circuit Board, 230v
13 1032266 Circuit Board Panel 1
14 1063311 Replacement Fuse, 115v 1
1063312 Replacement Fuse, 230v
15 1029302 Plastic Spacer 4
16 1004244 Washer 4
3016195 Control Box Assy, 115v
3016222 Control Box Assy, 230v
ITEM PART NO. PART NAME QTY
Figure E
Electrical Control Box

specifications and
installation instructions
Model 1000--FS
page 9 of 16
®
JARVIS PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457--4926
UNITED STATES OF AMERICA
TEL. [phone] FAX. [phone]
6207001:::
SPECIFICATIONS
Model 1000--FS
Motor Power 8 hp 5966 W
Blade Speed at 7.6 gpm or 28.8 Lpm 2150 rpm
Control Handle dual / electric
Blade Diameter 9.0 in 229 mm
10.5 in 267 mm
12.0 in 305 mm
Cutting Depth
with9.0inblade 3.0in 76mm
with 10.5 in blade 3.75 in 95 mm
with 12.0 in blade 4.5 in 114 mm
Overall Length (12.0 in bl.) 26 in 660 mm
Weight 41 lbs 18.6 kg
Vibration less than (<) 122 dB <1.26 m/sec2
Noise (one meter from tool) 88 dB
Hydraulic Power Unit
Motor Power 10 hp 7457 W
Operating Voltage 230/460 V std 3 ph, 60 Hz
other voltages and 50 Hz available
Hose Length 16 ft 5 m
Flow Rate 7.6 gal/min 28.8 L/min
Oil Capacity 30 gal 114 L
Oil Visc. at 100°F/40°C 200 SUS 46 ISO
Overall Dimensions (lxwx h) 37.6 x 27.2 x 31.5 in
955 x 691 x 800 mm
Weight (without oil) 408 lb 185 kg
INSTALLATION INSTRUCTIONS
ALWAYS DISCONNECT THE HYDRAULIC HOSES
AND SHUT THE POWER OFF IN ACCORDANCE
WITH OSHA’S LOCKOUT/TAGOUT PROCE-
DURES (29 CFR 1910.147) BEFORE PERFORM-
ING ANY REPAIRS OR MAINTENANCE.
Refer to Figure B on page 5 for referenced items unless
otherwise noted. Use Figure D on page 7 and Figure 1
on page 10 as a guide for wiring and hose connections
to the hydraulic power unit.
1 Install the hydraulic power unit overhead or on the
floor behind the work station.
1.1 Avoid excessive height and long pipe runs.
1.2 Locate the equipment in a clean, dry work area
and provide adequate space on all sides of the
unit for maintenance accessibility to all compo-
nents.
2 Remove breather filler cap (item 9, Figure D, page
7) and fill the power unit oil reservoir with a USDA
approved premium grade hydraulic fluid (viscosity
index 200 SUS at 100°F/46ISOat40°C). Never
run the power unit without oil.
3 Install the balancer, Jarvis part number 4042004,
above the work station.
3.1 If the operator has to move with the chain line,
install the balancer on a trolley. The trolley
should have sufficient travel to allow the opera-
tor to reach the entire work area.
4 Suspend the 1000--FS from the balancer.
4.1 Adjust the balancer to the operators preference.
5 Make all necessary wiring connections. All wiring
must be done in accordance with national, state
and local electrical codes. Refer to wiring diagram
inside the electrical control box cover.
5.1 Domestic power units require three--phase, 60
hertz, 230/460 volts to the motor and 115 volts,
single--phase to the electrical control box.
Please check the wiring diagram inside the cov-
er of your electrical control box for other volt-
ages and frequencies.
5.2 Equip the power unit with a switch at the opera-
tors station to facilitate shut down in case of
equipment failure.
5.3 Plug the wire and plug assembly (item 71) on the
1000--FS saw into the twist lock plug outlet
(item 5, Figure E, page 8) on the electrical con-
trol box.
6 Make all necessary hose connections. Connect the
hydraulic pressure and return lines.
6.1 Connect the quick connect socket (item 82) on
the 1000--FS saw to the return line quick connect
plug (item 25, Figure D, page 7) of the power
unit. Connect the the pressure line quick con-
nect socket (item 24, Figure D, page 7) on the
power unit, to the quick connect plug (item 80)
of the 1000--FS saw.

installation diagram
Model 1000--FS page 10 of 16
®
JARVIS PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457--4926
UNITED STATES OF AMERICA
TEL. [phone] FAX. [phone]
6207001:::
Return Line
Right Side Tools
or Pressure Line
Left Side Tools
Figure 1
Installation Diagram
Electrical
Control Box
Breather Filler Cap
Oil Level Gage
Oil Filter
Balancer
Cord to AC
Power Supply
Pressure Line
Right Side Tools
or Return Line
Left Side Tools
Twist
Lock Plug
Outlet

operation and
maintenance instructions
Model 1000--FS
page 11 of 16
®
JARVIS PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457--4926
UNITED STATES OF AMERICA
TEL. [phone] FAX. [phone]
6207001:::
OPERATION INSTRUCTIONS
1 Connect all hydraulic hoses.
2 Plug the 1000--FS saw into the electrical control box
twist lock plug outlet.
3Each day, before you begin operation, go through
the following checklist:
3.1 Make sure that the1000--FS moves freely on the
balancer.
3.2 Make sure that the dual anti--tie down control
handles (the front and rear handles) are working
correctly. Depress each trigger separately and
the tool should not start. Depress both triggers
simultaneously (within one second of each oth-
er) and the tool should start. Release either or
both triggers and the tool should stop. If the tool
malfunctions, remove it from service and report
the problem to your supervisor immediately.
Always use two hands when starting and stop-
ping the tool. Continue holding the tool firmly
with two hands until the saw blade comes to a
complete stop.
4 Making the cut:
4.1 Position the 1000--FS.
4.2 Depress both triggers simultaneously to start the
motor and make the cut. Always use two hands
when starting and stopping the tool.
4.2.1 Make the cut with a firm, steady motion. Do
not exert excessive pressure on the
1000--FS, but rather, guide the saw through
the cut.
4.2.2 The carcass should be supported by a back
board to stabilize and prevent it from turn-
ing while making the cut. RefertoFigure2
as a guide.
4.3 When the desired length of cut is reached, re-
lease either or both triggers. This will stop the
blade from rotating. Continue holding the tool
firmly with two hands until the saw blade
comes to a complete stop.
4.4 Withdraw the 1000--FS from the carcass.
4.5 Unplug the 1000--FS saw.
Place board to
support and prevent
carcass from turning
Rail
Figure 2
MAINTENANCE INSTRUCTIONS
Refer to Figures A -- C on pages 4 -- 6 for referenced items
unless otherwise noted.
IMPORTANT: ALWAYS DISCONNECT ALL HY-
DRAULIC HOSES AND SHUT THE POWER OFF
IN ACCORDANCE WITH OSHA’S LOCKOUT/TAG-
OUT PROCEDURES (29 CFR 1910.147) WHEN
INSTALLING AND REMOVING THE BLADE. AL-
WAYS DISCONNECT THE HYDRAULIC HOSES
AND SHUT THE POWER OFF IN ACCORDANCE
WITH OSHA’S LOCKOUT/TAGOUT PROCE-
DURES (29 CFR 1910.147) BEFORE PERFORM-
ING ANY REPAIRS OR MAINTENANCE.
IMPORTANT: IF YOU ARE PERFORMING MAIN-
TENANCE OR REPAIRS ON THE HYDRAULIC
SYSTEM, DISSIPATE OR RESTRAIN THE
STORED ENERGY.
1 DAILY MAINTENANCE:
Each day, before you begin operation, perform the fol-
lowing:
1.1 Inspect all hoses for abrasion and replace as nec-
essary.

maintenance instructions
Model 1000--FS page 12 of 16
®
JARVIS PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457--4926
UNITED STATES OF AMERICA
TEL. [phone] FAX. [phone]
6207001:::
1.2 Check all fittings for leaks and tighten or replace
as necessary.
1.3 Inspect all electrical cords, cord connectors and
plug assemblies over their entire length for cuts
and abrasions and replace as necessary.
1.4 Check the oil level gage (item 21, Figure D, page
7) on the hydraulic power unit and fill oil reser-
voir if necessary.
1.4.1 Change hydraulic fluid and filter as neces-
sary. Fill the oil reservoir with USDA ap-
proved premium grade hydraulic fluid (vis-
cosity: 200 SUS at 110°F/46ISOat38°C).
Burnt smelling or foamy fluid should be re-
placed immediately.
1.5 The 1000--FS is equipped with dual anti--tie
down control handles (the front and rear han-
dles). Check for the correct operation of the dual
anti--tie down control handles daily:Depress
each trigger separately and the tool should not
start. Depress both triggers simultaneously
(within one second of each other) and the tool
should start. Release either or both triggers and
the tool should stop. If the tool malfunction, re-
pair it or remove it from service immediately.
Always use two hands when starting and stop-
ping the tool. Continue holding the tool firmly
with two hands until the saw blade comes to a
complete stop.
Note: The power supply must be connected to per-
form the above operation only.
1.6 Four times (4) per day, add Jarvis 1315 White
Grease to the grease fitting (item 12) located on
gear housing (item 13).
1.7 Thoroughly clean the tool at the end of the day/
shift and spray with an approved mineral oil for
overnight storage.
2 WEEKLY:
2.1 Disassemble, clean and inspect gear housing as-
sembly. Refer to sections 6 and 7 as a procedur-
al guide.
3 AS NECESSARY:
3.1 Clean and inspect circular blade. Refer to sec-
tions 4 and 5 for blade removal and installation
procedures.
3.2 Disassemble, clean and inspect motor housing
assembly and motor adapter. Refer to sections
8 and 9 as a procedural guide.
3.3 Replace the power unit oil filter (item 12, Figure
D, page 7) at regular intervals.
Note: The hydraulic motor will require only occasional
rebuilding. Do not rebuild the hydraulic motor -- send it
back to Jarvis to be rebuilt.
4 CIRCULAR BLADE REMOVAL:
4.1 Remove hex head screw (item 43) and lock
washer (item 42). Insert an allen wrench or
screwdriver through one of the outer holes in
blade to prevent blade from turning.
4.2 Remove blade retaining flange (item 41).
4.3 Remove circular blade (item 40).
4.4 Inspect all parts for wear and replace if neces-
sary.
4.4.1 Inspect circular blade for wear and sharpen
or replace as necessary.
5 CIRCULAR BLADE INSTALLATION:
5.1 Reverse steps and procedures outlined in section
4. See notes below. Refer to figure 3 on page 13
as a guide.
5.1.1 To ensure proper fit and safe operation, the
hub of the saw blade (item 40) must face to-
ward and fit securely on the extended lip of
the shaft and pin assembly (item 2).
5.1.2 The holes on the blade retaining flange
(item 41) must align with the four dowel
pins (item 1) on the shaft and pin assembly
(item 2). Make sure the notched areas on the
blade are aligned with dowel pins (item 1).

maintenance instructions
Model 1000--FS
page 13 of 16
®
JARVIS PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457--4926
UNITED STATES OF AMERICA
TEL. [phone] FAX. [phone]
6207001:::
Figure 3
Blade Installation
Blade
Screw
Blade Retaining
Flange
Dowel Pins (4)
Holes for
Dowel Pins
Shaft and Pin
Assembly
Lip
Holes for Dowel
Pins (4 places)
Washer
Notched
Area
Hub
6 HOUSING AND GEAR DISASSEMBLY:
6.1 Remove circular blade. Follow steps and proce-
dures outlined in section 4.
6.2 Remove button head screws (item 26) and lock
washers (item 25).
6.3 Remove the four (4) hex head screws (item 46)
connecting motor adapter (item 47) to gear
housing (item 13) and separate blade guard
(item 31), front handle assembly and motor
adapter (item 47) from gear housing (item 13).
6.3.1 For 1000--FS models with adjustable han-
dles, remove blade guard and then separate
front handle assembly and motor adapter
from gear housing. Adjustable front handle
assembly does not need to be removed from
hydraulic motor adapter.
6.4 Remove drive coupling (item 44) from splined
shaft (item 49).
6.5 Remove flat head screws (item 4).
6.5.1 Rotate shaft and pin assembly (item 2) so
that the flat end of shaft exposes screws
(item 4).
6.6 Remove the entire bearing and gear assembly
(items 1--3 and 5--10) from gear housing (item
13).
6.6.1 Lightly tap on the front of gear housing
(guard mounting area) with a nylon mallet
to dislodge the shaft, bearing, and gear as-
sembly if necessary.
6.7 Disassemble bearing and gear assembly.
6.7.1 Remove locknut (item 10) from shaft and
pin assembly (item 2). See notes below.
6.7.1.1 Clamp the outside diameter edge of
blade retaining flange (item 41) into
soft jaw vise.
6.7.1.2 Align dowel pins (item 1) with blade re-
taining flange holes and place shaft and
pin assembly (item 2) into blade retain-
ing flange.
6.8 Hold bearing cover (item 5) and lightly tap the
end of shaft and pin assembly (item 2) with ny-
lon mallet to separate ball bearings (items 6 and
9), spacer (item 8) and bevel gear (item 7). Use
an arbor press if necessary.
6.8.1 Separate bevel gear (item 7) from bearing
(item 6) with an arbor press.
6.9 Remove bearing cover (item 5) and woodruff
key (item 3).
6.10 Remove threaded ring (item 18). Note: Jarvis
special tool, part number 8030030, is available
for removal and installation of threaded ring.
Refer to Figure 4 below.
Figure 4
Jarvis Special Tool 8030030
Threaded Ring
Removal and
Assembly Wrench

maintenance instructions
Model 1000--FS page 14 of 16
®
JARVIS PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457--4926
UNITED STATES OF AMERICA
TEL. [phone] FAX. [phone]
6207001:::
6.11 Remove pinion gear and bearing assembly
(items 7, 14--17) from gear housing (item 13).
Lightly tap end of gear housing with a nylon
mallet to dislodge assembly. See note below.
6.11.1 If necessary, use a punch to drive gear and
bearing assembly out through motor end of
gear housing (item 13). RefertoFigure5
below.
Figure 5
Pinion Gear
Assembly Removal
Gear Housing
Motor End
of Housing
Pinion Gear and
Bearing Assembly
Bevel Gear
End of Housing
6.12 Disassemble pinion gear and bearing assembly.
Use an arbor press to remove bearings if neces-
sary.
6.12.1 Remove bearing (item 17) and spacer (item
16) from the assembly.
6.12.2 Remove retaining ring (item 15) from shaft
of pinion gear (item 7).
6.12.3 Remove bearing (item 14) from shaft of pin-
ion gear (item 7).
6.13 Clean and inspect all parts for wear and replace
if necessary.
7 GEAR HOUSING ASSEMBLY:
7.1 Reverse steps and procedures outlined in section
6. See special notes below. Refer to section 5 for
blade installation procedures.
7.1.1 Press ball bearings and bevel gear (items 6,
7 and 9) one at a time onto shaft and pin as-
sembly (item 2). This ensures proper align-
ment of bevel gear with the woodruff key
(item 3).
7.1.2 Fill the cavity of gear housing (item 13) with
Jarvis 1315 White Grease before installing
gear and bearing assemblies.
7.1.3 Make sure retaining ring (item 15) is seated
properly on shaft of pinion gear (item 7) be-
fore installing pinion gear and bearing as-
sembly into gear housing.
7.1.4 Jarvis special tool, part number 8030030, is
available for removal and installation of
threaded ring (item 18). Refer to Figure 3.
8 MOTOR HOUSING AND ADAPTER DISAS-
SEMBLY:
Note: The hydraulic motor will require only occasional
rebuilding. Do not rebuild the hydraulic motor -- send it
back to Jarvis to be rebuilt.
8.1 Remove circular blade (item 40). Follow steps
and procedures outlined in section 4.
8.2 Remove button head screws (item 26) and lock
washers (item 25).
8.3 Remove hex head screws (item 46).
8.4 Separate gear housing (item 13) from motor
adapter (item 47), blade guard (item 31) and
front handle assembly.
8.4.1 For 1000--FS models with adjustable han-
dles, remove blade guard and hex head
screws (item 89). Separate front handle
bracket (item 96) from motor adapter.
8.5 Remove drive coupling (item 44) from splined
shaft (item 49)

maintenance instructions
Model 1000--FS
page 15 of 16
®
JARVIS PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457--4926
UNITED STATES OF AMERICA
TEL. [phone] FAX. [phone]
6207001:::
8.6 Slide motor adapter (item 47) off splined shaft
(item 49).
8.7 Remove bearing strip (item 78) and hanger
(item 59).
8.8 Remove o--ring (item 45).
8.9 Loosen set screws (item 50).
8.10 Slide splined shaft (item 49) out of shaft cou-
pling (item 51).
8.11 Remove square key (item 48).
8.12 Remove shaft coupling (item 51).
8.13 Remove hex head screws (item 81).
8.14 Remove motor mounting plate (item 53) and
alignment sleeve (item 52).
8.15 Remove hydraulic motor (item 54).
8.15.1 Pull gently on shaft of hydraulic motor (item
54) and slide motor out of motor housing
(item 77).
8.16 Remove hydraulic motor adapters (item 56).
8.17 Remove o--rings (items 55 and 58) and back--up
ring (item 57).
8.18 Clean and inspect all parts for wear and replace
if necessary.
9 MOTOR HOUSING AND ADAPTER ASSEM-
BLY:
9.1 Reverse steps and procedures outlined in section
8. See notes below. Refer to section 5 for blade
installation procedures.
9.1.1 Make sure that backup rings (item 57) and
o--rings (item 58) are placed and seated
properly onto hydraulic motor adapters
(item 56). Refer to Figure 6 below.
9.1.2 Make sure motor end of splined shaft (item
49) aligns and fits properly with square key
(item 48) and shaft coupling (item 51).
9.1.3 Make sure coupling (item 44) aligns and fits
properly with splined shaft (item 49) and
splined end of pinion gear (item 7).
Figure 6
Back--up Ring and
O--ring Installation
O--ring
Back--up Ring
Hydraulic Motor
Adapter

Model 1000--FS page 16 of 16
®
JARVIS PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457--4926
UNITED STATES OF AMERICA
TEL. [phone] FAX. [phone]
6207001:::
PRODUCTS CORPORATION
PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457--4926
UNITED STATES OF AMERICA
TEL. [phone] •FAX. [phone]
®
JARVIS
6207001:::
