Jay-Lor 2425 User manual

“Putting the ‘Total’ into TMR”
JAY•LORFabricating Inc.
RR # 2 Orton, Ontario, Canada, L0N 1N0 Tel: [phone] Fax: [phone]
V1.0.1 – April 10, 2002 165-00-20
OPERATOR’S MANUAL
MODEL 2425

“Putting the ‘Total’ into TMR”
JAY-LORFabricating Inc.
RR # 2 Orton, Ontario, Canada, L0N 1N0 Tel: [phone] Fax: [phone]
165-00-20
OPERATOR’S MANUAL
MODEL 2425 TRAILER TYPE

JAY•LOROperator’s Manual - 1- Trailer Units - Model 2425
INTRODUCTION......................................................................................................................3
POLICY STATEMENT .............................................................................................................3
OWNER/OPERATOR’S RESPONSIBILITY............................................................................3
LIMITED WARRANTY.............................................................................................................4
CONTACT INFORMATION......................................................................................................5
SERIAL NUMBER LOCATIONS .............................................................................................5
CUSTOMER REFERENCE INFORMATION ...........................................................................6
SAFETY....................................................................................................................................7
SAFETY ALERT SYMBOL ..................................................................................................7
UNDERSTAND SIGNAL WORDS .......................................................................................7
SAFETY GUIDELINES.........................................................................................................8
GENERAL SAFETY.............................................................................................................8
OPERATING SAFETY .........................................................................................................9
MAINTENANCE SAFETY....................................................................................................9
HYDRAULIC SAFETY........................................................................................................10
TIRE SAFETY.....................................................................................................................11
TRANSPORT SAFETY ......................................................................................................11
STORAGE SAFETY...........................................................................................................11
SAFETY SIGNS..................................................................................................................11
SIGN-OFF FORM ...............................................................................................................12
SAFETY SIGN LOCATIONS..............................................................................................14
OPERATION ..........................................................................................................................18
MACHINE COMPONENTS ................................................................................................18
PRE-OPERATION CHECKLIST ........................................................................................20
BREAK-IN...........................................................................................................................20
EQUIPMENT MATCHING..................................................................................................21
CONTROLS........................................................................................................................23
WEIGHING......................................................................................................................23
RESTRICTOR BLADES..................................................................................................26
ATTACHING/UNHOOKING ...............................................................................................26
SHEAR BOLT PROTECTED DRIVELINE.........................................................................28
FRONT DOOR DISCHARGE CONFIGURATIONS...........................................................29
FRONT DOOR DISCHARGE..........................................................................................29
UNLOADING CONVEYOR .............................................................................................29
DUAL DISCHARGE – 8’ (96”) OR 9’-2” (110”) CONVEYORS .......................................30
RIGHT/LEFT DISCHARGE – 6’ FLAT W/ HEIGHT ADJUSTABLE WING CONVEYOR
.........................................................................................................................................31
CENTER SIDE DOOR DISCHARGE CONFIGURATIONS ...............................................33
REAR DOOR DISCHARGE CONFIGURATIONS .............................................................34
GEARBOX LUBRICATION................................................................................................35

JAY•LOROperator’s Manual - 2- Trailer Units - Model 2425
FIELD OPERATION ...........................................................................................................36
GENERAL .......................................................................................................................36
CUTTING AND MIXING PROCEDURES .......................................................................37
UNLOADING PROCEDURES.........................................................................................38
OPERATING HINTS .......................................................................................................40
TRANSPORTING ...............................................................................................................41
STORAGE ..........................................................................................................................42
TROUBLESHOOTING...........................................................................................................43
GENERAL TROUBLESHOOTING.....................................................................................43
DRIVELINE TROUBLESHOOTING...................................................................................44
STANDARD MODEL SPECIFICATIONS..............................................................................49

JAY•LOROperator’s Manual - 3- Trailer Units - Model 2425
INTRODUCTION
Congratulations on your choice of a JAY•LORCutter-Mixer-Feeder to complement your
operation. This equipment has been designed and manufactured to meet the needs of the
discriminating buyer for efficient cutting, mixing and feeding.
Safe, efficient and trouble free operation of your mixer requires that you and anyone else
who will be operating or maintaining the machine, read and understand the Safety,
Operation, Maintenance and Troubleshooting information contained within the Operator's
Manual.
This manual covers the Model 2425 Trailer manufactured by JAY•LOR®. Keep this manual
readily available for reference and be sure to pass it on to new Operators or Owners.
Contact your nearest JAY•LOR®Dealer or Distributor if you need assistance or information.
OPERATOR ORIENTATION - The directions left, right, front, and rear, as mentioned
throughout the manual, are as seen from the tractor driver’s seat and facing forward.
POLICY STATEMENT
It is the policy of JAY•LORto improve its products where it is possible and practical to do
so. JAY•LORreserves the right to make changes or improvements in design and
construction at any time, without incurring the obligation to make these changes on
previously manufactured units.
OWNER/OPERATOR’S RESPONSIBILITY
It is the Owner/Operator’s responsibility to read the Operator’s Manual, to operate, lubricate,
maintain, and store the product in accordance with all instructions and safety procedures.
Failure of the operator to read the Operator’s Manual is a misuse of this equipment.
Like all mechanical products, JAY•LORproducts will require cleaning and upkeep. It is the
Owner/Operator’s responsibility to inspect the product and to have any part(s) and/or
assemblies repaired or replaced when continued operation would cause damage or
excessive wear to other components or cause a safety hazard.
It is the Owner/Operator’s responsibility to deliver the product to the authorized JAY•LOR
Dealer or Distributor, from whom it was purchased, for service or replacement of defective
parts which are covered by warranty. Repairs to be submitted for warranty consideration
must be made within thirty (30) days of failure. It is the Owner/Operator’s responsibility for
any cost incurred by the Dealer for travelling to or hauling of the product for the purpose of
performing a warranty obligation or inspection.

JAY•LOROperator’s Manual - 4- Trailer Units - Model 2425
LIMITED WARRANTY
JAY•LORFABRICATING INC. (the Seller) warrants the articles and units sold to be free
from defects in material and workmanship and to conform to applicable specifications.
These express warranties are the sole warranties of the Seller, and any other warranties,
express, implied in law or implied in fact, are hereby specifically excluded. Refer to the
Operator’s Manual content for any applicable warranties expressed otherwise.
Seller’s sole obligation under its warranties will be, at its option, to repair or replace any
article or part thereof which is proved to be other than warranted. Obligation under this
warranty will be limited to replacement or repair of parts found, upon Seller’s inspection, to
be defective. All warranties shall expire 12 months from the date the unit or article is placed
in service, or 12 months from the date the article or unit is delivered by the Seller, whichever
expires first.
NO ALLOWANCES WILL BE MADE TO THE BUYER FOR ANY TRANSPORTATION,
LABOUR CHARGES, PARTS ADJUSTMENTS OR REPAIRS, OR ANY OTHER WORK,
UNLESS THESE CHARGES ARE AUTHORIZED IN ADVANCE BY THE SELLER.
The Seller shall in no event be liable for special or consequential damages. If an article is
claimed to be defective in material or workmanship, or does not conform to specifications,
the Seller, upon notice promptly given, will either examine the article or unit at its site, or
issue shipping instructions to return to the Seller. The warranties shall not extend to any
articles, units, or parts thereof which have been installed, used, or serviced, otherwise than
in conformance with the Seller’s applicable instructions, manuals, service bulletins, or, if
none, which shall have been articles, units, parts thereof furnished by the Buyer or acquired
from others at the Buyer’s request and/or Buyer’s specifications.
The warranties are not applicable for expenses either direct or consequential that may arise
from the use or inability to use the articles and units sold by the Seller. The Seller shall in no
event be responsible for and will not be held liable for losses, injury, or damage caused to
persons or property by reason of operation of Seller’s products or their failure.
This warranty does not cover parts and accessories that are under separate guarantees
from the manufacturers and service can be obtained from their service facilities in USA and
Canada. No warranty is extended to regular service items such as fluid, paint, tires, knives
and the like.
This warranty pertains to components manufactured or installed by JAY•LORFabricating
Inc. only. This hereby excludes any warranties offered separately such as those offered by
the truck manufacturer. In this event, please refer to the appropriate Warranty Statements
offered by the separate manufacturer.
All claims for warranty must be directed to your dealer or distributor.
WARRANTY VOID IF NOT REGISTERED

JAY•LOROperator’s Manual - 5- Trailer Units - Model 2425
CONTACT INFORMATION
Contact JAY•LORFabricating Inc. at:
R.R. #2
Orton, ON
Canada
L0N 1N0
Phone: [phone]
Toll Free: [phone]
Fax: [phone]
e-mail: [email protected]
on the web: www.jaylor.com
SERIAL NUMBER LOCATIONS
Always give your Dealer the
Model Number and Serial
Number of your JAY•LOR
Cutter-Mixer-Feeder when
ordering parts or requesting
service or other information.
Depending on the type of service,
the Serial Numbers of individual
components and/or assemblies
will be required.
The Serial Number location
required for servicing your
JAY•LORProduct is shown in
Figure 1.
For easy reference, please write
this information in the Customer
Reference Information section
that follows.
Figure 1– JAY••LOR Serial Number Location.

JAY•LOROperator’s Manual - 6- Trailer Units - Model 2425
CUSTOMER REFERENCE INFORMATION
JAY•LORModel Number:
JAY•LOR

Serial Number:
Discharge:
Date Purchased:
Dealer Name:
Dealer Phone:
Scale Indicator Model Number:
Scale Indicator Serial Number:
Remote Scale Indicator Serial Number:
Other Main Components:
(e.g. Gearboxes, Hydraulic Motors, etc.)

JAY•LOROperator’s Manual - 7- Trailer Units - Model 2425
SAFETY
All implements with moving parts are potentially hazardous. There is no substitute for a
cautious, safe-minded operator who recognizes the potential hazards and follows
reasonable safety practices. The manufacturer has designed this implement to be used with
all its safety equipment properly attached to minimize the chance of accidents.
BEFORE YOU START!
Read the safety messages on the implement and shown in your manual.
Observe the rules of safety and common sense!
SAFETY ALERT SYMBOL
UNDERSTAND SIGNAL WORDS
Note the use of the signal words DANGER, WARNING, and CAUTION with the safety
messages. The appropriate signal word for each message has been selected using the
following guidelines:
•DANGER – Indicates an imminently hazardous situation that, if not avoided, will result in
death or serious injury. This signal word is to be limited to the most extreme situations
typically for machine components which, for functional purposes, cannot be guarded.
•WARNING – Indicates a potentially hazardous situation that, if not avoided, could result
in death or serious injury, and includes hazards that are exposed when guards are
removed. It may also be used to alert against unsafe practices.
•CAUTION – Indicates a potentially hazardous situation that, if not avoided, could result
in death or serious injury, and includes hazards that are exposed when guards are
removed. It may also be used to alert against unsafe practice.
If you have any questions not answered in this manual or require additional copies or the
manual is damaged, please contact your dealer or manufacturer directly.
This Safety Alert Symbol means:
-ATTENTION!
-BECOME ALERT!
-YOUR SAFETY IS
INVOLVED!
The Safety Alert Symbol
identifies important safety
messages on your
JAY•LORCutter-Mixer-
Feeder and in your
manual. When you see
this symbol, be alert to
the possibility of personal
injury or death. Follow
the instructions in the
safety message.

JAY•LOROperator’s Manual - 8- Trailer Units - Model 2425
SAFETY GUIDELINES
YOU are responsible for the SAFE operation and maintenance of your JAY•LORCutter-
Mixer-Feeder. YOU must ensure that YOU and ANYONE else who is going to operate,
maintain, or work around the JAY•LORCutter-Mixer-Feeder be familiar with the operating
and maintenance procedures and related SAFETY information contained in this manual.
This manual will take you step-by-step through your working day and alerts you to safety
practices that should be adhered to while operating the machine.
Remember, YOU are the key to SAFETY. Good safety practices not only protect you but
also the people around you. Make these practices a working part of your safety program.
Be certain that EVERYONE operating this equipment is familiar with the recommended
operating and maintenance procedures and follows all the safety precautions. All accidents
can be avoided. Do not risk injury or death by ignoring good safety practices.
•Vertical Mixer owners must give operating instructions to operators or employees before
allowing them to operate the machine, and at least annually thereafter.
•The most important safety device on this equipment is a SAFE OPERATOR. It is the
operator’s responsibility to read and understand ALL Safety and Operating instructions
in the manual and to follow them.
•JAY•LORfeels that a person who has not read and understood all operating and safety
instructions is not qualified to operate the machine. An untrained operator exposes
himself and bystanders to possible serious injury or death.
•Do not modify the equipment in any way. Unauthorized modification may impair the
function and/or safety and could affect the life of the equipment.
•Think SAFETY! Work SAFELY!
GENERAL SAFETY
•Read and understand the Operator’s Manual and all safety signs before operating,
servicing, maintaining, adjusting, or unplugging the Vertical Mixer.
•Only trained competent persons shall operate the Vertical Mixer. An untrained operator
is not qualified to operate the machine.
•Have a first-aid kit available for use should the need arise and know how to use it.
•Provide a fire extinguisher for use in case of a fire. Store in a highly visible place.
•Do not allow riders on the Vertical Mixer.
•Wear appropriate protective gear. This list includes but is not limited to:
-A hard hat
-Protective footwear with slip resistant soles
-Protective eyewear
-Heavy gloves

JAY•LOROperator’s Manual - 9- Trailer Units - Model 2425
•Place controls in neutral, stop engine, disengage power source, set park brake, remove
ignition key and wait for all moving parts to stop before servicing, adjusting, repairing, or
unplugging.
•Do not drink and drive.
•Review safety related items annually with all personnel who will be operating or
maintaining the Vertical Mixer.
OPERATING SAFETY
•Read and understand the Operator’s Manual and all safety signs before using.
•Place controls in neutral, stop engine, disengage power source, set park brake, remove
ignition key and wait for all moving parts to stop before servicing, adjusting, repairing, or
unplugging.
•Stay away from unloading door and conveyor discharge when unloading or moving.
•Do not operate when any guards are damaged or removed. Install and secure guards
before starting.
•Keep hands, feet, clothing and hair away from all moving and/or rotating parts.
•Do not allow riders on the machine during operation or transporting.
•Clear the area of bystanders, especially small children, before starting.
•Attach securely to the tractor using a retainer on the drawbar pin and a safety chain.
•Stay out of the mixing chamber and away from the auger when engine is running. Keep
others away.
•Stay away from overhead power lines when loading. Electrocution can occur without
contact.
•Clean reflectors, lights, SMV signs, before transporting.
•Use hazard flashers on tractor when transporting. Follow all local laws and regulations
when transporting the machine on public roads and highways.
•Before applying pressure to the hydraulic system, make sure all components are tight
and that steel lines, hoses, and couplings are in good condition.
•Review safety instructions with all personnel annually.
MAINTENANCE SAFETY
•Follow ALL the operating, maintenance, and safety information in the manual.
•Support the machine with blocks or safety stands when changing tires or working
beneath.

JAY•LOROperator’s Manual - 10 - Trailer Units - Model 2425
•Follow good shop practices:
-Keep service areas clean and dry.
-Be sure electrical outlets and tools are properly grounded.
-Use adequate lighting for the job at hand.
•Use only tools, jacks, and hoists of sufficient capacity for the job.
•Place controls in neutral, stop engine, set park brake, remove ignition key, and wait for
all moving parts to stop before servicing, adjusting, repairing, or unplugging.
•Relieve pressure from the hydraulic circuit before servicing or disconnecting from the
tractor.
•Make sure all guards are in place and properly secured when maintenance work is
completed.
•Before applying pressure to a hydraulic system, make sure all lines, fittings, and
couplers are tight and in good condition.
•Keep hands, feet, hair, and clothing away from all moving and/or rotating parts.
•Maintain fasteners in running gear systems at their specified torque at all times.
•Clear the area of bystanders, especially small children, when carrying out any
maintenance and repairs or making any adjustments.
HYDRAULIC SAFETY
•Make sure that all components in the hydraulic system are kept in good condition and
are clean.
•Replace any worn, cut, abraded, flattened, or crimped hoses or metal lines immediately.
•Relieve pressure before working on hydraulic systems.
•Do not attempt any makeshift repairs to the hydraulic fittings or hoses by using tape,
clamps, or cements. The hydraulic system operates under extremely high pressure.
Such repairs will fail suddenly and create a hazardous and unsafe condition.
•Wear proper hand and eye protection when searching for a high-pressure hydraulic leak.
Use a piece of wood or cardboard as a backstop instead of hands to isolate and identify
a leak.
•If injured by a concentrated high-pressure stream of hydraulic fluid, seek medical
attention immediately. Serious infection or toxic reaction can develop from hydraulic
fluid piercing the skin surface.
•Before applying pressure to the system, make sure all components are tight and that
lines, hoses, and couplings are not damaged.

JAY•LOROperator’s Manual - 11 - Trailer Units - Model 2425
TIRE SAFETY
•Failure to follow proper procedures when mounting a tire on a wheel or rim can produce
an explosion, which may result in serious injury or death.
•Do not attempt to mount a tire unless you have the proper equipment and experience to
do the job.
•Have a qualified tire dealer or repair service perform required tire maintenance.
TRANSPORT SAFETY
•Make sure you are in compliance with all local regulations regarding transporting
equipment on public roads and highways.
•Make sure the SMV (Slow Moving Vehicle) emblem and all the lights and reflectors that
are required by the local highway and transport authorities are in place, are clean and
can be seen clearly by all overtaking and oncoming traffic.
•Attach securely to the tractor using a retainer on the drawbar pin and a safety chain.
•Do not allow anyone to ride on the machine or tractor during transport.
•Do not exceed 15 km/h (10 mph). Reduce speed on rough roads and surfaces.
•Always use hazard warning flashers on tractor when transporting unless prohibited by
law.
•Drive carefully and defensively at all times and especially when negotiating uneven or
hilly terrain.
•Watch for overhead obstructions. Stay away from power lines and low tree branches.
•Use only a tractor with adequate brakes to stop the tractor coupled with the machine and
payload.
STORAGE SAFETY
•Store unit in an area away from human activity.
•Do not permit children to play on or around the stored machine.
•Store the unit in a dry, level area. Support the machine with planks if required.
•Make sure the implement jack is properly pinned to the mounting bracket.
SAFETY SIGNS
•Keep safety signs clean and legible at all times.
•Replace safety signs that are missing or have become illegible.

JAY•LOROperator’s Manual - 12 - Trailer Units - Model 2425
•Replaced parts that displayed a safety sign should also display a safety sign.
•Safety signs are available from your dealer, distributor, or the factory.
How to Install Safety Signs:
•Be sure that the installation area is clean and dry.
•Be sure temperature is above 50°F (10°C).
•Decide on the exact position before you remove the backing paper.
•Remove the smallest portion of the split backing paper.
•Align the sign over the specified area and carefully press the small portion with the
exposed sticky backing in place.
•Slowly peel back the remaining paper and carefully smooth the remaining portion of the
sign in place.
•Small air pockets can be pierced with a pin and smoothed out using the piece of sign
backing paper.
SIGN-OFF FORM
JAY•LORFabricating Inc. follows the general Safety Standards specified by the American
Society of Agricultural Engineers (ASAE) and the Occupational Safety and Health
Administration (OSHA). Anyone who will be operating and/or maintaining the machine must
read and clearly understand ALL Safety, Operating, and Maintenance information presented
in this manual.
Do not operate or allow anyone else to operate this equipment until such information has
been reviewed. Annually review this information with personnel.
Make these periodic reviews of SAFETY and OPERATION a standard practice for all of your
equipment. We feel that an untrained operator is unqualified to operate this machine.
A sign-off sheet is provided for your record keeping to show that all personnel who will be
working with the equipment have read and understand the information in the Operator’s
Manual and have been instructed in the operation of the equipment.

JAY•LOROperator’s Manual - 13 - Trailer Units - Model 2425
SIGN-OFF FORM
DATE EMPLOYEE’S SIGNATURE EMPLOYER’S SIGNATURE

JAY•LOROperator’s Manual - 14 - Trailer Units - Model 2425
SAFETY SIGN LOCATIONS
The types of safety signs and typical locations on the equipment are shown in the
illustrations that follow. Good safety requires that you familiarize yourself with the various
Safety Signs, the type of warning and the area of particular function related to that area
which requires your SAFETY AWARENESS.
•Think SAFETY! Work SAFELY!
A
B
C
A
B
C
D
E
F
G
H
H
I
J
K
A
A
C
B
H
J
K
I
D
F

JAY•LOROperator’s Manual - 15 - Trailer Units - Model 2425
DECAL ‘A’
DECAL ‘B’
DECAL ‘C’
WARNING
Read and understand operator's manual before using. Review all safety precautions annually.
Place all controls in neutral, stop engine, set park brake, relieve hydraulic pressure, remove
ignition key and wait for all moving parts to stop before servicing, adjusting, repairing, or unplugging.
Do not allow riders.
Securely attach to towing unit using a proper towing pin with a retainer and an auxiliary attaching
device (e.g. safety chain).
Be sure all guards and locks are in place before starting.
Keep hands, feet, hair and clothing away from moving parts.
Stay out of mixing chamber and away from auger when engine is running. Keep others away.
Be sure reflectors, lights, and SMV are visible before transporting.
Do not exceed a safe transport speed.
Use harzard flashers on tractor when transporting.
When repairing or servicing equipment, refer to operator's manual.
To prevent serious injury or death:
ROTATINGAUGERHAZARD
Stay out of mixing chamber and away from auger when engine is running.
Keep others away.
Place all controls in neutral, stop the engine, set park brake, relieve
hydraulic pressure, remove ignition key and wait for all moving parts to
stop before servicing, adjusting, repairing, or unplugging.
Do not lean over mixing chamber when engine is running.
Do not remove twine and wrap from commodities above mixing chamber.
Remove all twine and wrap from commodities on ground.
To prevent serious injury or death:
DANGER
Stay out from unloading door and discharge
conveyor when unloading or moving.
Keep others away.
Place controls in neutral, stop engine, set park
brake, remove ignition key and wait for all
moving parts to stop before servicing, repairing,
adjusting or unplugging.
PINCH POINT HAZARD
To prevent serious injury or death:

JAY•LOROperator’s Manual - 16 - Trailer Units - Model 2425
DANGER
ROTATING DRIVELINE
CONTACT CAN CAUSE DEATH
KEEP AWAY!
ALL DRIVELINE, TRACTOR AND EQUIPMENT
SHIELDS IN PLACE
DRIVELINES SECURELY ATTACHED AT
BOTH ENDS
DRIVELINE SHIELDS THAT TURN FREELY
ON DRIVELINE
DO NOT OPERATE WITHOUT-
DANGER
ROTATING DRIVELINE
CONTACT CAN CAUSE DEATH
KEEP AWAY!
ALL DRIVELINE, TRACTOR AND EQUIPMENT
SHIELDS IN PLACE
DRIVELINES SECURELY ATTACHED AT
BOTH ENDS
DRIVELINE SHIELDS THAT TURN FREELY
ON DRIVELINE
DO NOT OPERATE WITHOUT-
DECAL ‘D’
DECAL ‘E’
NOT FOR HIGHWAY TRAVEL
DO NOT EXCEED 15 KM/H (10 MPH) MAX.
WHEN TRANSPORTING THIS EQUIPMENT. WATCH YOUR STEP
DECAL ‘F’
DECAL ‘G’
ROTATING PART HAZARD
KEEP AWAY
To prevent serious injury or death from rotating
parts:Place controls in neutral, stop engine, set
park brake, remove ignition key, and wait
for all moving parts to stop before servicing,
repairing, adjusting, or unplugging.
Close and secure guards before operating.
Keep hands, feet, hair, and clothing
away from moving parts.
DECAL ‘H’

JAY•LOROperator’s Manual - 17 - Trailer Units - Model 2425
REMEMBER – If Safety Signs have been damaged, removed, become illegible, or parts
replaced without signs, new signs must be applied. New signs are available
from your authorized dealer.
DECAL ‘K’
DECAL ‘J’
Relieve prssure on system before repairing or adjusting.
Wear proper hand and eye protection when searching
for leaks. Use wood or cardboard instead of hands.
Keep all components in good repair.
To prevent serious injury or death from high pressure fluid:
HIGH PRESSURE FLUID HAZARD
To Avoid Injury Or Machine Damage:
When servicing machine use proper
tools and equipment.
Refer to Operators Manual for
instructions.
Secure conveyor discharge with lock channel
and pin before servicing or transporting.
To prevent injury or equipment damage:
DECAL ‘I’

JAY•LOROperator’s Manual - 18 - Trailer Units - Model 2425
OPERATION
The JAY•LORCutter-Mixer-Feeder is specifically designed to cut and mix feed ingredients
into a total mixed ration (TMR). Many of the features incorporated into this machine are the
result of suggestions made by customers like you. Located at the back of this manual is a
suggestion/comments sheet that can be faxed or mailed to JAY•LOR.
Read this manual carefully to learn how to operate the machine safely and how to adjust it to
provide maximum efficiency. Following the operating instructions with a proper maintenance
program will extend the life of your machinery.
MACHINE COMPONENTS
The machine is designed with a PTO powered vertical auger. The vertical auger cuts and
mixes a variety of feed ration ingredients into an even, uniform mixture. Knives located on
the periphery of the auger flights cut material as the auger rotates in a clockwise rotation.
Restrictor blades located at the front left and rear right corners of the mixing chamber are
adjustable to regulate cutting action of feed rations. A planetary gearbox located under the
auger center post provides rotation to the auger.
The planetary gearbox is equipped with a remote oil reservoir to display oil level and
condition.
The input driveline is equipped with a shear bolt to protect the drivetrain against shock loads.
Some models may be equipped with a 2-speed transmission option which offer a selection
between High Gear and Low Gear.
On all models, a hydraulically powered unloading door is opened to allow the mixed feed
ration out of the mixing chamber. Discharge options include front door, left-center side door,
and right-center side door and rear door.
On front door discharge models, the feed ration is distributed onto a hydraulically powered
chain slat conveyor option. There are various conveyor options that are explained in the
sections that follow.
On left and right center side door discharge models, the feed ration is distributed onto a
chute and then onto the ground immediately below.
On rear door discharge models, the feed ration is distributed onto the ground immediately
below. This option is useful for customers desiring premixed rations that can be stocked and
used later.
Standard models include a 4-point weighing system to monitor the amount of feed ration
inside the mixing chamber. This system incorporates weighbars located below the floor of
the mixing chamber, and a scale indicator option usually located at the front of the machine.
