MP-802 PG+ Wireless PIR Motion Detector
Installation Guide
Installation guidelines
The reference to MP-802 PG+ throughout this manual includes the model MP-802 P9M0.
CAUTION: Only qualified personnel may install this equipment. Place this device in non-
hazardous indoor locations only.
Important: Check the device and the entire alarm system weekly to ensure optimal
performance.
Note: Tocomply with FCCandISED Canada RFexposure compliance requirements, locate
the device at a distance of at least 20 cm from all persons during normal operation. Do not
co-locate the antennas used for this product, or operate them in conjunction with any other
antenna or transmitter.
Figure 1: MP-802 PG+
Callout
Description
A
Lens
B
Battery pull-tab
C
Enroll button
D
Tamper switch
For more information refer to About MP-802 PG+.
*D-308439*
D-308439

D-308439 MP-802 PG+ Rev.0
Figure 2: Optimizing detection and avoiding false alarms
1. Do not install near high-voltage electrical lines.
2. Keep away from heat sources.
3. Do not install outdoors.
4. Avoid direct sunlight.
5. Do not expose to air drafts.
6. Do not install behind partitions.
7. Do not mount on an unstable surface.
8. Install on a solid and stable surface at a height of 1.8 m to 2.4 m (6 ft. to 8 ft.)
Warning! Do not obscure partially or completely the device's field of view.
2 MP-802 PG+ Wireless PIR Motion Detector Installation Guide

D-308439 MP-802 PG+ Rev.0
Enrolling the device
1. Refer to the control panel installation manual for the complete set of enrollment instructions
and testing procedures.
2. From the Installation menu, enter the Device enrollment menu and select the option to add
a new device.
3. Remove the battery pull-tab to power on the device and begin the auto-enrollment process.
If the battery pull-tab is not available or if the device does not automatically enroll, open the
device cover to trigger the enrollment. Alternatively, press the enroll button until the yellow
LED light turns on. See Figure 1 C.
4. If requested, enter the PIN code printed on the device label.
5. To manually enroll the device:
a. Scan the QR Code on the device box, using the IQ4 camera if available, or see step b.
b. Manually enter the device ID, printed on the product label, in the format ID:125-xxxx.
Note: If the device has been powered up for more than 2 hours it will be identified by
the system only after the device has been reset.
The MP-802 PG+ is enrolled with device ID 125-XXXX. In fall back mode it enrolls as MP-802
K9-85 PG2 with device ID 126-XXXX.
6. Select the desired zone.
7. Configure any device parameters that are required.
8. Mount and test the device. See Local diagnostics test for information on testing the device.
MP-802 PG+ Wireless PIR Motion Detector Installation Guide 3

D-308439 MP-802 PG+ Rev.0
Configuring the device parameters
1. Enterthe DEVICESETTINGS menu and select the required configuration asdescribed inthe
following table.
Table 1: Configuration options
Option
Action
Alarm LED
Define whether the alarm LED indication will be activated.
Optional settings: LED ON (default) and LED OFF .
Event counter
Define whether an alarm will be activated upon continued
motion (low sensitivity) or upon a single alarm event (high
sensitivity).
Optional settings: LOW sensitivity (default) and HIGH
sensitivity .
Disarm activity
Define whether the device is active when the system is
disarmed.
Optional settings: NOT Active (default), no delay , 5 s delay ,
15 s delay , 30 s delay , 1 min delay , 2 min delay , 5 min delay ,
10 min delay , 20 min delay and 60 min delay .
VERY HOT > 35°C [>95°F]
Define whether or not the control panel will report a very
hot alert when the temperature rises above the threshold
value for at least the Alert Delay duration value. Alert restore
will occur when the temperature drops 1°C (1.8°F) below the
threshold for at least the
Restore Delay duration.
Note: The default threshold value for very hot is 35°C
(95°F).
Optional settings: See Configuring the Temperature Alerts.
COLD < 19°C [<66°F]
Define whether or not the control panel reports a cold alert
when the temperature drops below the threshold value for at
least the
Alert Delay duration. Alert restore occurs when the
temperature rises 1°C (1.8°F) above the threshold for at least
the
Restore Delay duration.
Note: The default threshold value for cold is 19°C (66°F).
Optional settings: See Configuring the Temperature Alerts.
4 MP-802 PG+ Wireless PIR Motion Detector Installation Guide

D-308439 MP-802 PG+ Rev.0
Table 1: Configuration options
Option
Action
FREEZING < 7°C [<45°F]
Define whether or not the control panel will report a freezer
alert when the temperature drops below the threshold value
for at least the
Alert Delay duration. Alert restore will occur
when the temperature rises 1°C (1.8°F) above the threshold
for at least the Restore Delay duration.
Note: The default threshold value for freezing is 7°C
(45°F).
Optional settings: See Configuring the Temperature Alerts.
FREEZER > -10°C [<14°F
Define whether or not the control panel will report a freezer
alert when the temperature rises above the threshold value
for at least the Alert Delay duration. Alert restore will occur
when the temperature drops 1 °C (1.8 °F) below threshold for
at least the
Restore Delay duration.
Note: The default threshold value for freezer is -10°C
(14°F).
Optional settings: See Configuring the Temperature Alerts.
MP-802 PG+ Wireless PIR Motion Detector Installation Guide 5

D-308439 MP-802 PG+ Rev.0
Configuring the temperature alerts
You can configure the temperature alerts with the settings described in the following table.
Table 2: Temperature alert configuration options
Option
Action
Threshold
Displays the last saved threshold value and provides the
installer with the ability to change the value using the back or
next button.
Disable/Enable
Define whether the panel reports an alert or not.
Alert delay
Define the amount of time the panel waits before an alert is
reported when the temperature exceeds the defined default.
The alert delay time values are:
Immediately , 1 min , 2 min , 10
min
(default), 15 min , 20 min , 30 min .
Restore delay
Define the amount of time the panel waits before an alert is
reported when the temperature exceeds the defined default.
The restore delay time values are:
Immediately , 1 min , 2 min ,
10 min (default), 15 min , 20 min , 30 min .
6 MP-802 PG+ Wireless PIR Motion Detector Installation Guide

D-308439 MP-802 PG+ Rev.0
Installing the pet mask
Install the pet mask if you require pet immunity. The optimal installation height for pet immunity is
2.1 m (7 ft.). Pet immunity is for pets weighing up to 38 kg (85 lb).
Note: Pet immunity is not supported at heights of 2.4 m (7.87 ft.) and above. Do not install the
pet mask if you are mounting the device at this height or above.
1. To open the device cover, use a screwdriver to loosen the cover screw located on the
underside of the device. See A1 in the following figure. Press the snap to separate the base
from the cover. See A2 in the following figure.
Figure 3: Device cover removal
2. Insert the tabs at the base of the pet mask into the bottom holes and align the tabs on the
sides with the holes on both sides. See the following figure.
3. Press down gently to install the pet mask.
Figure 4: Installing the Pet Mask
4. To close the device cover, clip the cover onto the device base and tighten the cover screw. See
the following figure.
MP-802 PG+ Wireless PIR Motion Detector Installation Guide 7

D-308439 MP-802 PG+ Rev.0
Figure 5: Closing the device cover
8 MP-802 PG+ Wireless PIR Motion Detector Installation Guide

D-308439 MP-802 PG+ Rev.0
Removing the pet mask
Remove the pet mask if you do not require pet immunity.
1. Open the device cover. See Figure 3.
2. Remove the tabs at the side of the pet mask from both holes and gently lift the pet mask out
from the bottom holes. See the following figure.
Figure 6: Removing the Pet Mask
3. Close the device cover. See Figure 5.
MP-802 PG+ Wireless PIR Motion Detector Installation Guide 9

D-308439 MP-802 PG+ Rev.0
Mounting the device using tape
1. Peel the release liners off the two strips of double-sided adhesive tape and attach the tape to
the back of the bracket.
See Figure 7 A for flat surface mounting and B for corner surface mounting.
Figure 7: Double-sided adhesive tape placement on the bracket
2. For corner surface mounting, ensure the corner mounting insert is attached to the back of
the corner bracket. See Figure 10 B.
3. Mount the bracket on the wall.
4. Align the device with the bracket. See A1 in the figure below.
5. Slide the device upward until a click is heard. See A2 and A3 in the figure below.
Figure 8: Attaching the device to the flat bracket
10 MP-802 PG+ Wireless PIR Motion Detector Installation Guide

D-308439 MP-802 PG+ Rev.0
Mounting the device using screws
Note:
Make sure to fasten the break-away segment to the frame. If the device is forcibly removed
from the wall, this segment will break away from the base, causing the tamper switch to open.
1. To mount the device on a flat surface, screw the flat bracket to the wall. See the following
figure.
Figure 9: Flat bracket screw installation
2. To mount the device on a corner surface, ensure the corner mounting insert is attached to
the back of the corner bracket. See B in the following figure.
Figure 10: Corner bracket screw installation
MP-802 PG+ Wireless PIR Motion Detector Installation Guide 11

D-308439 MP-802 PG+ Rev.0
Callout
Component
E
Stopper snap
F
Break-away segment
3. Screw the corner bracket to the wall. See C in the previous figure.
4. Optional: If the installation surface does not allow for mounting the bracket with screws
in the right side, screw the corner bracket using the two left side screw holes. See D in the
previous figure.
Important: When mounted like this, back tamper protection is not available.
5. Align the device with the bracket. See A1 in the following figure.
6. Slide the device upward until a click is heard. See A2 and A3 in the following figure.
Figure 11: Attaching the device to the corner bracket
12 MP-802 PG+ Wireless PIR Motion Detector Installation Guide

D-308439 MP-802 PG+ Rev.0
Disassembling the device from the bracket
1. Open the device cover. See Figure 3.
2. Remove the battery.
3. Use a screwdriver to press on the stopper snap to release the device base from the bracket.
See A1 in the following figure.
4. Slide the device downwards to remove it from the bracket. See A2 in the following figure.
Figure 12: Disassembling the device from the bracket
MP-802 PG+ Wireless PIR Motion Detector Installation Guide 13

D-308439 MP-802 PG+ Rev.0
Replacing the battery
CAUTION: Risk of explosion if battery is replaced by an incorrect type. Dispose of used
batteries according to the manufacturer's instructions and according to local rules and
regulations.
1. Open the device cover. See Figure 3.
2. Remove the battery. See A in the following figure.
Note: It is recommended to wait about 1 minute after battery removal before inserting the
new battery.
3. Insert the new battery while observing battery polarity. See B in the following figure.
Figure 13: Battery removal and insertion
4. Press down on the battery until it fits into place.
5. Close the device cover and fasten the cover screw. See Figure 5.
Note: After restoring a low battery, the system may take up to5 minutes toclear the
trouble.
14 MP-802 PG+ Wireless PIR Motion Detector Installation Guide

D-308439 MP-802 PG+ Rev.0
Local diagnostics test
After power-up or closing the cover, the device automatically enters Test Mode for 15 minutes. To
manually enter the devices into Test Mode refer to the Control Panel Installer Guide.
1. Before you start the test, remove the device cover from the base. See Figure 3.
2. Close the cover to return the tamper switch to its normal position.
3. The device enters a 2 minute stability period. During this time the red LED blinks.
4. Walk-test the coverage area. See the figure below. Walk across the far end of the coverage
pattern in both directions. The red LED lights each time your motion is detected followed by 3
LED blinks.
The following table indicates received signal strength indication:
Table 3: Signal strength indication
LED response
Reception
Green LED blinks
Strong
Orange LED blinks
Good
Red LED blinks
Poor
No blinks
No communication
Important: Reliable reception must be assured. Therefore, poor signal strength is not
acceptable. If you receive a poor signal from the device, relocate it and re-test until a
strong signal strength is received.
Note: It is recommended to have a strong signal strength and you must verify the
signal strength using the control panel's diagnostic test. For detailed Diagnostics Test
instructions, refer to the control panel installer guide.
MP-802 PG+ Wireless PIR Motion Detector Installation Guide 15

D-308439 MP-802 PG+ Rev.0
Figure 14: Coverage pattern walk test
Fresnel and cylinder type lens with optical attenuation (pet mask) in the lower pattern part of
the lens. Number of beams / curtains: 27 Fresnel far (54 sensitivity “beams”), 18 Cylinder mid,
10 Cylinder close.
Important! Instruct the user to walk test at least once a week to verify proper function of the
device.
16 MP-802 PG+ Wireless PIR Motion Detector Installation Guide

D-308439 MP-802 PG+ Rev.0
Specifications
Frequency band
912 to 919 MHz
Modulation
GFSK
Communication Protocol
PowerG
Battery Type
3 V Lithium CR-123A Panasonic, Duracell, and GP only
Battery Life
6 to 8 years with typical use at room temperature 25°C (77°F)
Low Battery Threshold
2.4 V at room temperature 25°C (77°F)
Operating Temperature
-10°C (14°F) to 50°C (122°F).
Storage Temperature
-20°C (-4°F) to 60°C (140°F)
Relative Humidity
Up to 95% non-condensing
Dimensions (LxWxD)
86 mm x 63 mm x 40 mm (3.4 in. x 2.5 in. x 1.6 in.)
Weight (including battery)
85 g (3 oz)
Max. coverage
12 x 12 m (39 x 39 ft) / 90°
Pet immunity
Up to 38 kg (85 lb)
Color
White
MP-802 PG+ Wireless PIR Motion Detector Installation Guide 17

D-308439 MP-802 PG+ Rev.0
FCC (915 MHz): 47CFR part 15.247
MP-802 P9M0
For information regarding the recycling of this product you must contact the
company from which you originally purchased it. If you are discarding this
product and not returning it for repair then you must ensure that it is returned
as identified by your supplier. This product is not to be thrown away with
everyday waste.
Directive 2012/19/EU Waste Electrical and Electronic Equipment.
Compliance with standards
MP-802 PG+ complies with the following standards:
FCC Compliance Statement
This device complies with FCC Rules Part 15 license-exempt standard(s). Operation is subject to two
conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
that may be received or that may cause undesired operation.
Note: The digital circuit of this device has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
WARNING: Changes or modifications to this equipment not expressly approved by the
party responsible for compliance (Visonic Ltd.) could void the user’s authority to operate the
equipment.
To comply with FCC RF exposure compliance requirements, the device should be located at a
distance of at least 20 cm from all persons during normal operation. The antennas used for this
product must not be co-located or operated in conjunction with any other antenna or transmitter.
Safety Instructions
Read the safety information before you install the equipment.
The detector shall be installed and used within an environment that provides the pollution degree
max 2 and over voltages category II in non-hazardous locations, indoor only. The equipment is
designed tobeinstalled bySERVICE PERSONS only; (SERVICE PERSON is definedas a person having
the appropriate technical training and experience necessary to be aware of hazards to which that
person may be exposed in performing a task and of measures to minimize the risks to that person
or other persons).
W.E.E.E Product recycling declaration
18 MP-802 PG+ Wireless PIR Motion Detector Installation Guide

D-308439 MP-802 PG+ Rev.0
About MP-802 PG+
The MP-802 PG+ is a microprocessor-controlled wireless digital PIR detector, with optional pet
immunity.
The device has the following features:
• Fresnel and cylindrical lenses with uniform detection sensitivity throughout its operating
range, up to 12 meters (39 ft).
• Target Specific Imaging™ (TSI) technology is used for distinction between humans and pets
weighing up to 38 kg (85lb).
• Theadvanced True Motion Recognition™ algorithm (patented) distinguishes between the
true motion of an intruder and any other disturbances which may cause false alarms.
• No vertical adjustment is needed.
• Motion event counter determines whether one (high sensitivity) or two (low sensitivity)
consecutive motion events trigger an alarm.
• Very low current consumption.
• Microprocessor-controlled temperature compensation.
• Front and back tamper protection.
• Temperature sensing and reporting.
• Remote firmware upgrade.
MP-802 PG+ Wireless PIR Motion Detector Installation Guide 19

D-308439 MP-802 PG+ Rev.0
Warranty
Visonic Ltd. (“ Seller ”) warrants the Products to the original purchaser only (the “ Buyer ”) against
defective workmanship and materials under normal use of the Products for a period of twelve (12)
months from the date of shipment by the Seller.
This Warranty is absolutely conditional upon the Products having been properly installed,
m a i n t a i n e d a n d o p e r a t e d un d e r c o n d i t i o n s o f n o r m a l u s e i n a cc o r d a n c e w i t h t h e S e ll e r ' s
recommended installation and operation instructions. Products which have become defective
f o r a n y o t h e r r ea s o n , a cc o r d i n g t o t h e S e ll e r ' s d i sc r e t i o n , s u c h a s i m p r o p e r i n s t a ll a t i o n , f a il u r e t o
follow recommended installation and operational instructions, neglect, willful damage, misuse or
vandalism, accidental damage, alteration or tampering, or repair by anyone other than the Seller,
are not covered by this Warranty.
There is absolutely no warranty on software, and all software products are sold as a user license
under the terms of the software license agreement included with such Product.
The Seller does not represent that Products may not be compromised and/or circumvented or that
the Products will prevent any death and/or personal injury and/or damage to property resulting
from burglary, robbery, fire or otherwise, or that the Products will in all cases provide adequate
warning or protection. The Products, properly installed and maintained, only reduce the risk of such
events without warning and it is not a guarantee or insurance that such events will not occur.
Conditions to Void Warranty : This warranty applies only to defects in parts and workmanship
relating to normal use of the Products. It does not cover:
• damage incurred in shipping or handling;
• damage caused by disaster such as fire, flood, wind, earthquake or lightning;
• damage due to causes beyond the control of the Seller such as excessive voltage, mechanical
shock or water damage;
• damage caused by unauthorized attachment, alterations, modifications or foreign objects
being used with or in conjunction with the Products;
• damage caused by peripherals (unless such peripherals were supplied by the Seller;
• defects caused by failure to provide a suitable installation environment for the products;
• damage caused by use of the Products for purposes other than those for which they were
designed;
• damage from improper maintenance;
• damage arising out of any other abuse, mishandling or improper application of the Products.
Items Not Covered by Warranty : In addition to the items which void the Warranty, the following
items shall not be covered by Warranty: (i) freight cost to the repair centre; (ii) customs fees, taxes,
or VAT that may be due; (iii) Products which are not identified with the Seller's product label and lot
number or serial number; (iv) Products disassembled or repaired in such a manner as to adversely
affect performance or prevent adequate inspection or testing to verify any warranty claim. Access
cards or tags returned for replacement under warranty will be credited or replaced at the Seller's
option.
This warranty is exclusive and expressly in lieu of all other warranties, obligations
or liabilities, whether written, oral, express or implied, including any warranty of
merchantability orfitnessfora particularpurpose,orotherwise.In nocase shalltheSELLER
be liable to anyone for any consequential or incidental damages for breach of this warranty
or any other warranties whatsoever, as aforesaid.
The Seller shall in no event be liable for any special, indirect, incidental, consequential or
punitive damages or for loss, damage, or expense, including loss of use, profits, revenue, or
goodwill, directly or indirectly arising from Purchaser’s use or inability to use the Product,
or for loss or destruction of other property or from any other cause, even if Seller has been
advised of the possibility of such damage.
20 MP-802 PG+ Wireless PIR Motion Detector Installation Guide
