Johnson Controls LC-200 User manual

ISTISJCEBLC200 0.0 Installation Instructions
LC-200/BLC-200
1
2012/19/EU
LC-200/BLC-200
IR DETECTOR
1. INTRODUCTION
LC-200/BLC-200 detectors are the best choice for residential and commercial security installations: BLC-200 is not UL/ULC listed.
They only use digital PIRs which bypass the conversion that usually must be done with traditional detectors where an analog PIR is amplified and converted
to digital. The FULLY digital technology helps the detector more accurately detect intrusions and not be affected by alterations in white light, ultraviolet light,
temperature, air movement caused by heating/cooling systems, and it is fully immune to radiated and conducted electromagnetic interference. LC-200/BLC-200
detectors are equipped with lenses designed by Johnson Controls and are manufactured by Fresnel Technologies, Inc.
LODIFF®optic creation technology combined with POLY IR®materials make it a product of the highest quality and efficiency.
LC-200/BLC-200 detectors are pet immune (feature not evaluated by UL/ULC) and have a 15-meter range at a 100-degree angle.
2. INSTALLATION
- Using a thin screwdriver, loosen the bottom screw and open the cover (see Fig 1)
- Remove the board from the base by levering the ABS cover (see Fig 2)
- Drill the stopper on the base of the cover at the desired fastening location (or use the optional swivel that is not IMQ certified)
- Open the knockout for the removal protection and fix the anchor to the wall (see Fig 2)
- Recommended height is 2 m
- Slide the cable in through the back slot and out the top hole
- Wire the terminals following the connections shown in“Connection and Setup”
- Fig 1 -
- Fig 2 -
Ultraviolet Stabilization
POLY IR®4 Lens Material
The lens is printed with POLY IR®material.
This materials offers a better combination of
transmittance, environmental stability and color
than any other polymer on the market. Materials
are available for the 8-14 micron infrared region.
LODIFF®and POLY IR®are registered trademarks of
Fresnel Technologies, Inc.
LODIFF®Fresnel Lens Technology
This lens series is made by tiling LODIFF®lens pieces.
These lenses offer significantly improved performance
over the typical constant-bandwidth Fresnel lens.
LODIFF®and POLY IR®are registered trademarks of
Fresnel Technologies, Inc.
High RFI Protection
The detector has very high RFI immunity due to the
complete lack of traditional amplifiers.
White Light Protection
The detector digitally filters white light components.
Pet Immunity
Thanks to a new lens design and the digital analysis
system, all of our detectors are immune to pets
weighing up to 15 kg.
Fully Digital PIR
The detector has no analog components, and
the fully digital PIR interfaces directly with the
microprocessor.
NOTE: Do not partially or completely cover the detector's field of vision
NOTE: the pet function is not IMQ certified
Anchor
Jumpers DIP Switch

ISTISJCEBLC200 0.0 Installation Instructions
LC-200/BLC-200
2
3. CONNECTION AND SETUP
Dip PULSE --> off = 1 pulse - on = 2 pulses
Dip RANGE --> off = 7m - on = 15m range
Dip LED --> off = led off - on = led on
Jumpers T- A- EOL open = NC contacts without resistors (not for UL/ULC applications)
Jumpers T- A- EOL closed = DEOL supervision with internal resistors
SUPPLY: power supply 9-15 VDC / 25 mA. Note: For UL/ULC installations the detector shall be provided with minimum of 4 hours of standby power from either
a listed compatible control unit or power supply. Use only resistive loads on the outputs.
Installation must be carried out by trained personnel according to professional standards.
The manufacturer accepts no responsibility if the product is tampered with by unauthorized persons.
The alarm system should be checked for proper operation at least once a month. However, a reliable electronic alarm system does not prevent
intrusion, robbery, fire or anything else but merely decreases the risk of such situations occurring.
LC-200/BLC-200 complies with requirements EN 50131-2-2 Grade 2, EN 50131-2-2 Class II
Technical Characteristics
RANGE 15 m
HORIZONTAL COVERAGE 100°
LENSES LODIFF®Fresnel Lens
POLY IR®4 material
LED blue
ALARM DURATION 2 s
SELF-DIAGNOSTICS -
LED WALK TEST YES
MICROWAVE FREQUENCY -
SOLID STATE RELAY YES
EOL RESISTANCE YES
CREEP ZONE DEVICE YES
CASE TAMPER YES
BACK TAMPER YES
ANTI-MASKING -
PULSE COUNTER YES
RFI PROTECTION 30 V/m
HEAT COMPENSATION YES
FULLY DIGITAL YES
SWIVEL OPTION YES
POWER SUPPLY 9-15 VDC / 25 mA
COVER MATERIAL ABS
PET IMMUNITY YES
OPERATING TEMPERATURE
-10°C to +40°C
UL/ULC tested: 0°C to 49°C
HUMIDITY 93% RH
DIMENSIONS 114 x 63 x 40 mm
LC-200: DEOL supervision
(external resistors/
open jumpers)
NC (no EOL supervision/
open jumpers)
Not used on UL/ULC
listed installations
101W. MORNINGSIDE DR. FORT WORTH, TX 76110, U. S. A. [phone], FAX:[phone]
fresnel technologies inc.
2003
SIDE VIEW:
2.1m
(6.8ft)
TOP VIEW:
10m
(33ft)
(50ft)
15m
FRONT VIEW:
(50ft)
15m
5m
(16ft)
jay
WP 0.9 GI 6 T1
PET IMMUNE ARRAY
(28.2ft)
8.6m
(15.7ft)
4.8m
(6.8ft)
2.1m
35.6mm
(1.4 in)
49.8 mm
(1.96 in)
12.5 mm
(0.49 in)
95°
5m
(16ft)
10m
(33ft)
(50ft)
15m
0
Figure 7
101W. MORNINGSIDE DR. FORT WORTH, TX 76110, U. S. A. [phone], FAX:[phone]
fresnel technologies inc.
2003
SIDE VIEW:
2.1m
(6.8ft)
TOP VIEW:
10m
(33ft)
(50ft)
15m
FRONT VIEW:
(50ft)
15m
5m
(16ft)
jay
WP 0.9 GI 6 T1
PET IMMUNE ARRAY
(28.2ft)
8.6m
(15.7ft)
4.8m
(6.8ft)
2.1m
35.6mm
(1.4 in)
49.8 mm
(1.96 in)
12.5 mm
(0.49 in)
95°
5m
(16ft)
10m
(33ft)
(50ft)
15m
0
Figure 7
Zx COM
–+
EOL
A
T
EOL
SUPPLY ALARM TAMPER
–+EOL
TAMPER
LC-200
All 3 jumpers open
Negative connected tamper
5.6 kohm
5.6 kohm
Panel
COM Zx
–+
EOL
A
T
EOL
SUPPLY ALARM TAMPER
–+EOL
TAMPER
BLC-200
All 3 jumpers open
Negative connected
10 kohm
10 kohm
tamper
Panel
Zx COM
–+
EOL
A
T
EOL
SUPPLY ALARM TAMPER
–+EOL
TAMPER
LC-200/BLC-200
All 3 jumpers open
Negative connected tamper
Panel
10m
(33ft)
5m
(16ft)
5m
(16ft)
10m
(33ft)
2.1m
(6.8ft)
2.1m
(6.8ft)
4.8m
(15.7ft)
8.6m
(28.2ft)
15m
(50ft)
SIDE VIEW:
0
DEOL supervision
(internal resistors/closed jumpers)
Zx COM
–+
EOL
A
T
EOL
SUPPLY ALARM TAMPER
–+EOL
TAMPER
LC-200/BLC-200
COM
R1 R2
NC / NO TAMPER
All 3 jumpers closed
Zone ok = R1
Zone in alarm = R1 + R2
Tamper zones = open or short circuit
Negative connected tamper
Panel
LC-200: R1 = 5.6 kohm; R2 = 5.6 kohm
BLC-200: R1 = 5.0 kohm; R2 = 5.0 kohm
BLC-200: DEOL supervision
(external resistors/
open jumpers)

ISTISJCEBLC200 0.0 Installation Instructions
LC-200/BLC-200
3
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses
and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
– Reorient or relocate the receiving antenna
– Increase the separation between the equipment and receiver
– Connect the equipment into an outlet on a circuit different from that to which the receiver is connected
– Consult the dealer or an experienced radio/TV technician for help.
Warning! Changes or modifications to this equipment not expressly approved by the party responsible for compliance (Tyco Safety Products
Canada Ltd.) could void the user’s authority to operate the equipment.
This device complies with part 15 of the FCC rules. Operations are subject to the following two conditions: (1) This device may not cause harmful
interference and (2) This device must accept any interference received, including interference that may cause undesired operation.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numrique de la classe B est conforme a la norme NMB-003 du Canada.
