Joie Litetrax User manual

litetrax™
使用說明書
組裝及使用本產品前
請先閱讀說明書全文

11
FIGURE 1 ~ 3
FIGURE 1 ~ 3
12
FIGURE 1 ~ 3FIGURE 1 - 5
FIGURE 7 - 12
FIGURE 12 - 16FIGURE 12 - 16FIGURE 12 - 16FIGURE 1 ~ 3FIGURE 1 - 6
34
11
22
6
11
22
7
11
22
11
8
10
11
22
11 12
5
9
12

FIGURE 13- 17
FIGURE 18 - 23
1514
3
1
A
2
B
13
112233
16 17
11
33
22
19
18
11
22
22
21
20
34
23

5
Accessories (May not be included in purchase)
Accessories may be sold separately or may not be available depending on region.
26 27
FIGURE 24- 27
25
24
6
FIGURE 28 - 33
28
22
11
29
22
1111
22
30 31
32 33

FIGURE 34 ~ 37
35
11
22
36
7
Care and Maintenance
37 NOISENOISE
34
22
11
8
NOTE

910
CH 謝謝您使用本產品
祝賀您加入巧兒宜大家庭! 您剛買了一台符合安全標準
CNS
12940:2013
和歐洲安全標準
EN 1888-1:2018
的高品質
litet-
rax
手推車。這台手推車適用於重量
15
公 斤 以 下 的 寶 寶。 台灣區
域使用請依照CNS 標 準 規 範。
請仔細閱讀本說明書並依照指示操作，這樣才能保障並提供您
的寶寶一個安全又舒適的行車旅程。
重要 - 請保留好說明書以便日後參考。
如需要了解更多信息，請您訪問joiebaby.com 網站下載說明
書或查看更多令人激動的Joie 產品!
目錄
參照圖示 1-7
緊急情況處理 10
產品資訊 11
產品組件及各部件名稱 12
警告 13
產品組裝 15
 打開手推車 15
 組裝&拆卸前輪 15
 組裝&拆卸後輪 15
 組裝&拆卸扶手 15
產品操作 16
 調整背靠角度 16
 使用安全扣 16
 使用肩帶和腰帶 17
 調節小腿靠支撐板 17
 前輪定向 17
 使用剎車踏板 18
 使用遮陽篷 18
 收合手推車 18
 使用配件 18
 使用雨篷 19
 使用置物盤 19
 使用汽車椅 19
保養常識 20
緊急情況處理
遇緊急事件或事故時，需迅速急救或送醫治療照顧您的寶寶是
非 常 重 要 的。

11 12
產品資訊
Allison Baby UK Ltd.
Venture Point, Towers Business Park,
Rugeley, Staffordshire, WS15 1UZ
www.joiebaby.com
產品名稱Litetrax 手推車
產品型號S2213A
最大體重15公斤
適用嬰幼兒年齡0-36個月
主要材質塑膠、合金、布
淨重9.47公斤
產品尺寸936mmx580mmx1040mm
製 造 日 期  詳見產品上貼紙日期(年/月/日)
專利號碼專利申請中
原 產 地中國
委製商巧兒宜國際股份有限公司
進口商巧兒宜國際股份有限公司
地址台北市內湖區瑞光路431號2樓
電話02-27973000
統一編號52603333
代理商奇哥股份有限公司Chickabiddy Co., Ltd
地址台北市南京東路四段186號5樓
服務專線0800-001-256 / 02-25781188
統一編號04222671
網址www.chick.com.tw
使用本產品前請先閱讀說明書全文，如果您對於使用本產品
還有任何疑問，請撥服務專線0800-001-256 / 02-25781188
7
5
6
8
910
11
12
1
3
2
4
12
17
18
15
13
14
16
3
產品組件及各部件名稱
組裝前請確認所有部件已經齊全，如有遺漏，請與代理商聯
繫。本產品無需工具進行組裝。
1 主體
2 扶手
3 前輪
4 後輪
5 遮陽篷
6 座布
7 扶手
8 小腿靠
9 前輪
10 前輪定向拉板
11 置物籃
12 肩帶
13 車手
14 天窗
15 後輪
16 剎車踏板
17 收合栓
18 收合鉤
配件 （可能不包含）
1雨篷
2置物盤
3連接器
因產品型號的不同，並非
所 有 手 推 車 均 附 以 上 配 件。

13 14
警告
!本產品須由成人進行組裝。
!本手推車適合體重15公斤以下的寶寶使用，不符合使用條件
的寶寶會對手推車造成損壞。
!寶寶乘坐時應使用腰部及胯部的安全帶，並同時使用肩帶。
!請勿擺放超過4.5公斤的物件於置物籃內，以免導致手推車不
穩 定 而 產 生 危 險。
!不得將寶寶單獨留置於手推車上無人看護。
!不得附載其它的嬰幼兒、物品或附件於推車上。
!超載或不正確的折疊及使用非經核准的零附件都可能造成手
推 車 損 壞、故 障 或 不 安 全，請 務 必 閱 讀 說 明 書。
!使用前請仔細閱讀本說明書並請妥善保存供以後參照。如果
不按照本說明書可能會影響乘坐寶寶的安全。
!寶寶乘坐時，安全帶或束縛系統必須正確的扣合及使用。
!當調整手推車上之任何可活動配件時，必須確定寶寶與手推
車 保 持 安 全 距 離。
!
嬰幼兒可能會滑入足底部分的缺口或造成窒息。
!禁 止 在 樓 梯 上 使 用 手 推 車。
!使用時請遠離火源、高溫、水池或電源之附近範圍。
!不可讓寶寶站立或倒坐於手推車上。
!不可將手推車放置於馬路、坡道或危險場所。
!使用前應確實豎立及固定各機構以確保安全。
!請勿將任何繩索或索帶類物件懸掛於寶寶頸部附近，或扣在
產品及玩具上，以免導致意外窒息。
!請勿放置任何物品在車手、背靠後面或車台側面，以免影響
手 推 車 的 穩 定 性。
!寶寶乘坐於手推車內時，不可將整個手推車往上提。
!請 勿 將 寶 寶 放 到 置 物 籃 內。
!請不要讓寶寶攀爬手推車，以免翻覆。
!為避免手指夾傷問題，收合及展開手推車時，請務必小心。
!寶寶接近手推車前，請確認手推車已完全打開或收合。
!使用前請確定各部件安裝牢固以確保安全。
!保持嬰幼兒遠離此篷罩及雨篷以免造成窒息。
!停泊此手推車時務必確實使用所有之剎車裝置。
!當發現手推車損壞時，應立即停止使用。
!請勿使用其它廠商提供的零部件。
!本產品不適用於跑步和滑冰，只適合以步行速度使用。
!使用本產品前，請取掉PE袋和包裝材料並銷毀，並放到嬰兒
和兒童觸摸不到的地方。
!供新生兒使用時，應使用最斜躺位置。
!請勿允許您的寶寶將本產品當玩具玩耍。
!當放入和抱出寶寶時，應鎖定剎車裝置。
!當結合汽車椅使用時，本產品不可代替睡床使用。若您的寶
寶需要睡眠時，請讓寶寶睡在合適的睡床上。
!移動本產品時，輕放輕移，切忌硬拖猛推，以免造成產品結构
等松動或斷裂。
!任意放置未經製造商核可之物品於車台上將造成危險。
!六個月大以下的嬰幼兒應同時使用腰部及胯部的安全帶。
!置物盤最大載重為1.36公 斤。
!置物盤內不要放置任何會對小孩和嬰兒車造成傷害的物品。

15 16
產品組裝（圖片請參閱說明書 1-7 頁）
組裝及使用手推車前，請先閱讀說明書全文，並按照說明書指
示 進 行 操 作。
打開手推車
見圖 1- 2
推開收合鉤 1，然 後 將 車 手 向 上 拉 起 2，聽到“咔噠”聲表示
車 架 已 打 開 到 位。
!使用手推車前務必確保車架已打開到位。
組裝&拆卸前輪
見圖 3- 4
組裝&拆卸後輪
見圖 5- 6
組裝&拆卸扶手
見圖 7- 9
產品操作
調整背靠角度
見圖10 - 11
背靠角度有4段可供調整。
1.調低背靠角度
按壓背靠調整拉桿，同時向下調整背靠到合適的角度10
! 如寶寶已坐在座椅內，請用另一隻手輕托背靠，以減少震盪。
2.調高背靠角度時，將背靠向上推即可11
使用安全扣
見圖12 - 13
鬆開安全扣
按下母扣上的按鈕，安全扣會自動鬆開12
扣合安全扣
將腰帶扣依次插入肩帶扣13 - 1
，
和母扣內13 - 2
，聽 到“ 咔 噠 ”
聲表示扣合到位13 - 3
!為防止寶寶摔跤，寶寶乘坐時必須繫上安全帶。
!請 牢 牢 地 繫 上 安 全 帶，並 注 意 寶 寶 與 安 全 帶 之 間 須 可以 放 
進 一 個 手 掌 的 厚 度。
!請勿交叉肩帶，以免對寶寶頸部造成壓迫。

17 18
使用肩帶和腰帶
見圖14 - 17
!寶寶坐進手推車後，請確認肩帶孔高度和肩帶及腰帶的長
度是否合適，以免寶寶於使用時意外跌出。
14 - 1 肩帶固定栓A
14 - 2 肩帶固定栓B
14 - 3 調整扣
較大的寶寶使用時，請使用肩帶固定栓A和最上方的肩帶孔；
較小的寶寶使用時，請使用肩帶固定栓B和最下方的肩帶孔。
調整肩帶固定栓位置時，將背靠後方的肩帶固定栓放置水平、
短邊朝前，從肩帶孔穿出15 ，再從背靠前方將肩帶固定栓穿過
最接近寶寶肩膀的肩帶孔16
將調整扣上下滑動，可調節肩帶長度17 - 1
。
按壓按鈕17 - 2
，同時往外拉安全扣內側或外側的腰帶，可調節
腰帶長度17 - 3
調節小腿靠支撐板
見圖18
依不同使用需求，小腿靠共有2個 段 位 可 供 調 節。
段位調高時，將小腿靠支撐板由下往上推即可。
段位調低時，按壓小腿靠兩側的調整按鈕18 - 1
，同 時 向 下 調 節
小腿靠支撐板18 - 2
前輪定向
見圖19
前輪鎖定或釋鎖如圖19
使用小秘訣 當在碎石路面或不平路面推行時，建議鎖定前
 車輪，便能更輕鬆地操控手推車。
使用剎車踏板
見圖20 -21
準備剎車時，踩下剎車踏板20
打開剎車時，再次踩下剎車踏板21
使用小秘訣 手推車停止前進時，請踩下剎車踏板。
使用遮陽篷
見圖22
打開或者收攏遮陽篷，將遮陽篷往前拉或往後翻即可。
防止寶寶被陽光直射，可以完全打開遮陽篷，拉開拉鏈22 ，將
遮 陽 篷 往 前 拉 即 可。
收合手推車
見圖23 -25
!收合手推車前，請先收攏遮陽篷。
按壓釋鎖按鈕23 再向上提起收合織帶，車架向後自動折疊24
收合鉤自動扣合收合栓，手推車收合完成後如圖25 所 示。手 推
車 收 合 後 可 站 立 如 所 示。
使用配件
因產品型號的不同，規格會有所不同。並非所有手推車均附以
下 配 件。

19 20
使用雨篷
見圖26
將雨篷套到車架上，再粘合雨篷側面的粘扣帶和扣合雨篷下方
的 紐 扣。
!使用雨篷時，請確認汽車椅已正確固定和手推車背靠已調至
最低檔。
!使用雨篷時，請隨時注意並確認雨篷內有良好的通風。
!不使用雨篷時，請先確認雨篷已清潔並干燥，再收納。
!請勿收合已罩上雨篷的手推車。
!天氣炎熱時，請勿將幼童放在裝有雨篷的手推車內。
使用置物盤
見圖27 -29
!置物盤內不要放置任何會對小孩和嬰兒車造成傷害的物品。
使用汽車椅
見圖30 -36
當與Joie汽車椅gemm&i-Level&i-Jemini&i-Snug 2配合
使用時，請參考以下警告︰
!請將手推車背靠調至最平躺段位并收合遮陽篷。
!關於使用汽車椅有任何問題，請參考說明書。
!請勿收合已安裝汽車椅的手推車。
保養常識
見圖37
!清 洗 座 布 時，請 使 用 溫 水 清 洗，請 勿 漂 白。具 體 請 參 考 手 推 
車上洗滌標版內容。
!清洗車架︰僅能使用中性清潔劑及溫水洗滌，請勿使用漂白
劑。清洗後用吸水的布擦幹防止生鏽。
!隨時檢查您的手推車，並隨時更換或修理鬆弛磨損的零件、
脫落的材料或車縫線。
!過度曝晒於陽光下，可導致手推車老化或變形。
!手推車潮濕時，請打開手推車及遮陽篷，待干燥後再收合
起 來。
!如果輪子發出“吱吱”聲，可加油(WD-40，防鏽油或縫紉機
油)潤滑。請將潤滑油點入輪軸及軸孔37 之 間，此 步 驟 為 重 要
的 保 養 須 知。
!在海邊使用手推車時，務必於使用過後清除沙粒，以做好完
善 的 清 洗。
延長保固服務
請於購買起一個月內至奇哥官網進行登錄，登錄成功後即享有
商品延長一年保固服務。

21
litetrax™
Instruction Manual
Read these instructions
carefully before use and
keep them for future
reference. Your child’s
safety may be aected
if you do not follow these
instructions.
IMPORTANT - READ CAREFULLY AND
KEEP FOR FUTURE REFERENCE

23 24
GB Welcome to Joie™
Congratulations on becoming part of the Joie family!
We are so excited to be part of your journey with your
little one. While traveling with the Joie Litetrax, you are
using a high quality, fully certified stroller, approved to
European safety standards EN 1888-1:2018. This prod-
uct is suitable for children up to 15kg or 36 months
whichever comes first. Please carefully read this manual
and follow each step to ensure a comfortable ride and
best protection for your child.
IMPORTANT - READ CAREFULLY AND KEEP FOR
FUTURE REFERENCE.
Visit us at joiebaby.com to download manuals and see
more exciting Joie products!
For warranty information, please visit our website at
joiebaby.com
Contents
Figures 1-7
Emergency 24
Product Information 25
Parts List 26
WARNING 27
Stroller Assembly 28
Open Stroller 28
Assemble & Detach Front Wheel 28
Assemble & Detach Rear Wheel 28
Assemble & Detach Armbar 28
Stroller Operation 28
Adjust Backrest 28
Use Buckle 28
Use Shoulder & Waist Harnesses 29
Adjust Calf Support 29
Use Front Swivel Lock 29
Use Brake 29
Use Canopy 29
Fold Stroller 30
Use Accessories 30
Use Rain Cover 30
Use Parent Tray 30
Use with Joie Child restraint 30
Cleaning and Maintenance 31
Emergency
In case of emergency or accident, it is most important to
have your child taken care of with first aid and medical
treatment immediately.

25 26
17
18
15
13
14
16
7
5
6
8
910
11
12
132 4
Parts List
Make sure all parts are available before assembly. If any
part is missing, please contact local retailer. No tools are
required for assembly.
Accessories
(May not be included)
1 Rain cover (on certain models)
2 Parent Tray (on certain models)
3 Adaptor (on certain models)
Accessories may be sold separately or may
not be available depending on region.
1
2
3
Product Information
Read all the instructions in this manual before using this
product. If you have any further questions, please consult the
retailer. Some features may vary depending on model.
Product Litetrax Stroller
Suitable for This product is suitable for children up to
15 kg or 36 months whichever comes first
Materials Plastics, metal, fabrics
Patent No. Patents pending
Made in China
1 Stroller Frame
2 Armbar
3 Front Wheels
4 Rear Wheels
5 Canopy
6 Seat Pad
7 Armbar
8 Calf Support
9 Front Wheel
10 Swivel Lock
11 Storage Basket
12 Shoulder Harness
13 Handle
14 Window
15 Rear Wheel
16 Brake Lever
17 Storage Mount
18 Storage Latch

27 28
WARNING
!Always use the restraint system.
!Ensure that all the locking devices are engaged before use.
!Do not let the child play with this product.
!Check that the car seat attachment devices are correctly
engaged before use.
!Adult assembly required.
!This product is suitable for children up to 15kg or 3 years
whichever comes first.
!To prevent a hazardous, unstable condition, do not place
more than 4.5kg in the storage basket.
!Never leave the child unattended.
!Use the stroller with only one child at a time. Never place
purses, shopping bags, parcels or accessory items on the
handle or canopy.
!Accessories which are not approved by the manufacturer
shall not be used.
!Only replacement parts supplied or recommended by the
manufacturer shall be used.
!To avoid injury ensure that the child is kept away when un-
folding and folding this product.
!This product is not suitable for running or skating.
!Pushchair designed to be used from birth shall recommend
the use of the most reclined position for new born babies.
!The parking device shall be engaged when placing and
removing the children.
!For car seats used in conjunction with a chassis, this vehicle
does not replace a cot or a bed. Should your child need to
sleep, then it should be placed in a suitable pram body, cot
or bed.
!Any load attached to the handle and/or on the back of the
backrest and/or on the sides of the vehicle will affect the
stability of the vehicle.
!The maximum recommended weight of the parent tray is
3lbs (1.36kg).
Stroller Assembly(Please refer to figures on page 1-7)
Please read all the instructions in this manual before assembling and using this product.
Open Stroller
see images 1- 2
Separate storage latch from storage mount 1, and then lift the handle upwards 2, a click sound means the
stroller is open completely.
!Check that the stroller is completely latched before continuing to use.
Assemble & Detach Front Wheel
see images 3- 4
Assemble & Detach Rear Wheels
see images 5- 6
Assemble & Detach Armbar
see images 7- 9
Stroller Operation
Adjust Backrest
see images 10 - 11
There are 4 recline angles for the backrest.
Recline Backrest
To recline the backrest, squeeze the recline handle on the back of the seat, pull down on the backrest. 10
Raise Backrest
To raise the backrest, push up. 11
!Make sure the recline is set properly for use.
Use Buckle
see images 12 - 13
Release Buckle
Press the center button to release the buckle. 12
Lock Buckle
Match the waist belt buckle with the shoulder buckle 13 - 1, and click into the center buckle. 13 - 2
A “click” sound means the buckle is locked completely. 13 - 3
!To avoid serious injury from falling or sliding out, always secure your child with harness.
!Make sure your child is snugly secured. The space between the child and the shoulder harness is about the
thickness of one hand.
!Do not cross the shoulder belts. This will cause pressure on a child’s neck.

29
Use Shoulder & Waist Harnesses
see images 14 - 17
!In order to protect your child from falling out, after your child is placed into the seat, check whether the
shoulder and waist harnesses are at proper height and length.
14 - 1 Shoulder harness anchor A
14 - 2 Shoulder harness anchor B
14 - 3 Slide adjuster
For larger child, use shoulder harness anchor A and the highest shoulder slots. For smaller child, use shoulder
harness anchor B and the lowest shoulder slots.
To adjust the position of the shoulder harness anchor, turn the anchor to be level with the side facing forward.
Thread it through the shoulder harness slot from back to front. 15 Rethread it through the slot that is closest to
child's shoulder height. 16
Use slide adjuster to change the harness length. 17 - 1
Press the button 17 - 2, while pulling the waist harness to proper length. 17 - 3
Adjust Calf Support
see image 18
The calf support has 2 positions.
To raise the calf support, push it upwards. A "click" sound means the calf is locked completely.
To lower calf support, press the adjustment buttons on both sides of the calf support 18 - 1, and rotate the calf
support downwards. 18 - 2
Use Front Swivel Lock
see image 19
Front wheel locked or unlocked status as 19
Tip It is recommended to use swivel locks on uneven surfaces.
Use Brake
see images 20 - 21
To lock the rear wheels, step down on the brake lever. 20
To unlock the rear wheels, step down the brake lever again. 21
Tip Always set the parking brake when stroller is not moving.
Use Canopy
see image 22
The canopy can be opened or folded, pull it toward front or back.
The canopy can be opened completely to protect your child from the sun uttermostly, just unzip the hook 22 ,
and then pull the canopy toward front.
30
Fold Stroller
see images 23 - 25
!Please fold the canopy before folding the stroller.
1. Press the folding button. 23
2. Pull the folding webbing upward, the frame will automatically fold backward. 24
3. The storage latch will automatically hook onto the storage mount, then the stroller is folded and locked
completely. The stroller can stand when folded. 25
Use Accessories
Accessories may be sold separately or may not be available depending on region.
Use Rain Cover
see image 26
To assemble the rain cover, place it over the stroller, and then attach the 8 pairs of hook and loop fasteners on
the rain cover. 26
!Before using the rain cover, please make sure the backrest has been adjusted to the lowest position and the
infant child restraint has been fastened.
!When using the rain cover, please always check its ventilation.
!When not in use, please check that the rain cover has been cleaned and dried before folding.
!Do not fold the stroller after assembling the rain cover.
!Do not place your child into the stroller assembled with rain cover during hot weather.
Use Parent Tray
see images 27 -29
!Do not place any item that may do harm to the baby and stroller in the parent tray.
Use with Joie Child restraint
see images 30 - 36
When using with Joie child restraint gemm&i-Level&i-Jemini&i-Snug 2, please refer to the following
instructions.
! Before using the infant child restraint, please make sure the backrest has been adjusted to the lowest
position and the infant child restraint has been fastened.
! If you have any problems about using the infant child restraint, please refer to their own instruction manuals.
!Please don’t fold stroller when attaching the child restraint.

31
Care and Maintenance
see images 37
!Removable seat pad may be washed in cold water and drip-dried. No bleach.
!To clean stroller frame, use only household soap and warm water. No bleach or detergent.
!From time to time, check your stroller for loose screws, worn parts,torn material or stitching. Replace or
repair the parts as needed.
!Excessive exposure to sun or heat could cause fading or warping of parts.
!If stroller becomes wet, open canopy and allow to dry thoroughly before storing.
!If wheels squeak, use a light oil (e.g., Silicon Spray, antirust oil, or sewing machine oil). It is important to get
the oil into the axle and wheel assembly. 37
!When using your stroller at the beach, completely clean your stroller after use to remove sand and salt from
mechanisms and wheel assemblies.
NOTE

IM-000962B
Share the joy at joiebaby.com
Allison Baby UK Ltd,
Venture Point, Towers Business Park
Rugeley, Staffordshire, WS15 1UZ
