Joie evalite duo User manual

evalite™duo
stroller
birth to 15kg/birth - 36 months
說明書
說明書

12
Stroller Assembly
5
FIGURE 1 ~ 3
FIGURE 7 ~ 11
6
4
17
FIGURE 1 - 6
1
2
3
2
89
10 11
1
2

34
FIGURE 12 ~ 17
FIGURE 18 ~ 23
12 13
14 15
19
23
20
16
18
17
21
22
1
2
1
2
2
2
1

56
27 33
24
25
30
34
29
32
Stroller Operation
2
1
FIGURE 24 ~ 28
FIGURE 29 ~ 34
28
31
26
2
1

78
41
42 43
38 39
40
1
3
2
44
FIGURE 35 ~ 39
FIGURE 40 ~ 44
1
2
3
36
37
3
1
A
2
35
B

910
45
47
46
53
48
Care and Maintenance
Accessories (May not be included in purchase)
Accessories may be sold separately or may not be available
depending on region.
Use with Joie Infant Child Restraint
1
2
FIGURE 45 ~ 48
FIGURE 49 ~ 53
50
49
51 52
1
2
3

11 12
GB Welcome to Joie™
Congratulations on becoming part of the Joie family!
We are so excited to be part of your journey with your
little one. While traveling with the Joie Evalite Duo,
you are using a high quality, fully certified stroller, ap-
proved to European safety standards EN 1888:2012.
This product is suitable for use with children weighing
under 15kg in each seat. Please carefully read this man-
ual and follow each step to ensure a comfortable ride
and best protection for your child.
IMPORTANT - Keep these instructions for future
reference.
Visit us at joiebaby.com to download manuals and see
more exciting Joie products!
For warranty information, please visit our website at
joiebaby.com
Contents
Figures 1-10
WARNING 15
Stroller Assembly 17
Open Stroller 17
Assemble & Detach Front Wheels 17
Assemble & Detach Rear Wheels 18
Assemble Storage Basket 18
Assemble & Detach Armbar 18
Assemble & Detach Hood 18
Stroller Operation 18
Adjust Recline 18
Use Hood 18
Adjust Calf Support 18
Use Buckle 19
Use Shoulder & Waist Harnesses 19
Use Front Swivel Lock 20
Use Brake 20
Fold Stroller 20
Use Accessories 21
Use with Joie Infant Child Restraint 21
Cleaning and Maintenance 22
Emergency
In case of emergency or accident, it is most important to have
your child taken care of with first aid and medical treatment
immediately.

13 14
Parts List
Make sure all parts are available before assembly. If any part is
missing, please contact local retailer. No tools are required
for assembly.
1 Stroller Frame
2 Front Wheel
3 Rear Wheel
4 Support Tube
5 Armbar
6 Hood
7 Front Armbar
8 3/5 Point Buckle
9 Footrest
10 Front Wheel
11 Front Swivel Lock
12 Rear Wheel
13 Storage Latch
14 Rear Armbar
15 Secondary Lock
16 One-Hand-Fold Handle
17 Storage Basket
1234
17
6
8
7
9
14
12
13
15
16
5
10 11
Accessories
(May not be included)
Rain Cover
Accessories may be sold separately
or may not be available depending
on region.
Product Information
Read all the instructions in this manual before using this
product. If you have any further questions, please consult the
retailer. Some features may vary depending on model.
Product Evalite Duo Stroller
Suitable for Child weighing under 15kg in each seat unit
This front seat unit is suitable for children
6 -36 months
This rear seat unit is suitable for children
birth -36 months
Materials Plastics, metal, fabrics
Patent No. Patents pending
Made in China
Brand Name Joie
Website www.joiebaby.com
Manufacturer Joie Children's Products (UK) Limited

15 16
WARNING
!WARNING Always use the restraint system. Safety belts and
restraint systems must be used correctly.
!WARNING Ensure that all the locking devices are engaged
before use.
!WARNING Do not let your child play with this product.
!WARNING check that the car seat attachment devices are
correctly engaged before use.
!Adult assembly required.
!This front seat unit is not suitable for children under 6
months. This rear seat unit is suitable for children under 6
months. This product is suitable for use with children weigh-
ing under 15kg in each seat. This product is designed to
carry a one or two children in an upright or reclined posi-
tion. it could cause damage to the stroller if the child is over
15kg.
!To prevent a hazardous, unstable condition, do not place
more than 4.5kg in the storage basket.
!Never leave your child unattended. Always keep child in
view while in stroller.
!
This stroller may be used with two children at a time. Do not
attach items to the handle, seat back or sides of the stroller.
Any additional load will affect the stability of the stroller and
could cause the stroller to tip.
!Never use accessories, parts or components not produced
or approved by the manufacturer. Please read the instruction
manual carefully.
!Only replacement parts supplied or recommended by the
manufacturer /distributor shall be used.
!Please read all the instructions in the manual before using
the product. Please save instruction manual for future use.
Failure to follow these warnings and instructions may result
in serious injury or death.
!To avoid serious injury from falling or sliding out, always use
hamess.
!To avoid injury, ensure that your child is kept away when
unfolding and folding this product.
!Child may slip into leg openings and be strangled if the harness
is not used.
!Never use stroller on stairs or escalators.
!Keep away from high temperature objects, liquids, and elec-
tronics.
!Never allow your child to stand on the stroller or sit in the
stroller with head toward front of stroller.
!Never place the stroller on roads, slopes or dangerous ar-
eas.
!Do make sure all mechanisms are fixed before using the
stroller.
!To avoid strangulation, do not place items with a string
around your child’s neck, suspend strings from this product,
or attach strings to toys.
!Any load attached to the handle or on the back of the back-
rest or on the sides of the stroller will affect the stability of
the stroller.
!DO NOT lift stroller while child is in stroller.
!DO NOT use storage basket as a child carrier.
!To prevent tipping, never let child climb the stroller. Always
lift the child in and out of the stroller.
!Be sure the stroller is fully open or folded before allowing
child near the stroller.
!To ensure your child’s safety, please make sure all parts are
assembled and fastened properly before using the stroller.
!To avoid strangulation, do make sure your child is clear from
the hood.

17 18
!Always engage the brakes when parking the stroller.
!Discontinue using stroller if it is damaged or broken.
!Stroller to be used only at walking speed. This product is
not intended for use while jogging.
!To avoid suffocation, remove plastic bag and packaging ma-
terials before using this product. The plastic bag and pack-
aging materials should then be kept away from babies and
children.
!This product is not suitable for running or skating.
!Pushchair designed to be used from birth shall recommend
the use of the most reclined position for new born babies.
!The parking device shall be engaged when placing and remov-
ing children.
!For infant child restraints used in conjunction with a chas-
sis, this vehicle does not replace a cot or a bed. Should your
child need to sleep, then it should be placed in a suitable
pram body, cot or bed.
Stroller Assembly
(Please refer to figures on page 1-10)
Please read all the instructions in this manual before
assembling and using this product.
Open Stroller
see images 1- 3
Push storage latch 1. Meanwhile, pull the stroller backward to
open. Latches should click into place.
!Check that the stroller is completely latched before
continuing to use.
Assemble & Detach Front Wheels
see images 4- 6
Assemble & Detach Rear Wheels
see images 7- 10
Assemble Storage Basket
see images 11 - 13
Assemble & Detach Armbar
see images 14 - 18
Assemble & Detach Hood
see images 20 - 26
The completely assembled stroller is shown as 27
Stroller Operation
Adjust Recline
see images 28 - 31
Use Hood
see images 32
Adjust Calf Support
see images 33 - 34
The calf support has 2 positions.
To raise the calf support, lift it upwards.

19 20
Use Buckle
see images 35 - 36
!To avoid serious injury from falling or sliding out, always se-
cure your child with harness.
!Make sure your child is snugly secured. The space between
the child and the shoulder harness is about the thickness of
one hand lay flat on child’s chest.
!Do not cross the shoulder belts. This will cause pressure on
a child’s neck.
Use Shoulder & Waist Harnesses
see images 37 - 40
!In order to protect your child from falling out, after your child
is placed into the seat, check whether the shoulder and
waist harnesses are at proper height and length.
37 - 1 Shoulder harness anchor A
37 - 2 Shoulder harness anchor B
37 - 3 Slide adjuster
For larger child, use shoulder harness anchor A and the high-
est shoulder slots.
For smaller child, use shoulder harness anchor B and the low-
est shoulder slots.
To adjust the position of the shoulder harness anchor, turn
the anchor to be level with the side facing forward. Thread
it through the shoulder harness slot from back to front. 38
Rethread it through the slot that is closest to child's shoulder
height. 39
Use slide adjuster to change the harness length.40 -1
Press the button 40 - 2, while pulling the waist harness to
proper length 40 - 3
Use Front Swivel Lock
see images 41
Pull up the front swivel locks to maintain the moving direction.
41
Tip It is recommended to use swivel locks on uneven
surfaces.
Use Brake
see images 42 - 43
To lock wheels, step the brake lever downwards. 42
To release wheels, just lift the brake lever upwards. 43
Tip Always set the parking brake when stroller is not
moving.
Fold Stroller
see images 44 - 47
!Please fold the hood before folding the stroller. 44
!Please do not lock swivel while folding to avoid folded
stroller unable to stand.
Push secondary lock 45
-1 and squeeze one-hand-fold handle
45
-2. Pull the armrest rearwards to fold stroller, then the
stroller can stand when folded. 47

21 22
4. To remove the infant child restraint, Open the infant child
restraint lock, squeeze the stroller release handle to release
the infant child restraint from armbar, and then lift infant
child restraint out of stroller. 52
! If you have any problems using the infant child restraint,
please refer to the infant child restraint instruction manual.
! Remove infant child restraint before folding.
Cleaning and Maintenance
see images 53
!Removable seat pad may be washed in cold water and drip-
dried. No bleach. Please refer to the care label for instructions
on cleaning the fabric parts of the stroller.
!To clean stroller frame, use only household soap and warm
water. No bleach or detergent. Periodically wipe clean plastic
parts with a soft damp cloth. Always dry the metal parts to
prevent the formation of rust if the stroller has come into
contact with water.
!From time to time, check your stroller for loose screws, worn
parts, torn material or stitching. Replace or repair the parts as
needed.
!Excessive exposure to sun or heat could cause fading or
warping of parts.
!If stroller becomes wet, open hood and allow to dry
thoroughly before storing.
!If wheels squeak, use a light oil (e.g. , Silicon Spray, antirust
oil, or sewing machine oil). It is important to get the oil into
the axle and wheel assembly. 53
!When using your stroller at the beach or other sandy/dusty
environments, completely clean your stroller after use to
remove sand and salt from mechanisms and wheel
assemblies.
Use Accessories
Accessories may be sold separately or may not be available
depending on region.
Use Rain Cover
see images 48
To assemble the rain cover, place it over the stroller, then
attach it on the handle by hook and loop fasteners and wrap
the webbings on the rain cover around the mounts, and then
snap buttons. 48
!When using the rain cover, please always check its
ventilation.
!When not in use, please check that the rain cover has been
cleaned and dried before folding.
!Do not fold the stroller after assembling the rain cover.
!Do not place your child into the stroller assembled with rain
cover during hot weather.
Use with Joie Infant Child Restraint
see images 49 - 52
When using with Joie infant child restraint gemm, please refer
to the following instructions.
!Recline the stroller rear seat to the lowest position.
1. Make sure the infant child restraint lock is open on the right
stroller handle. 49
2. Place infant child restraint into rear seat of stroller so
notches in rockers fit over edge of armbar. Then click the
infant child restraint into place. 50
3. Lock the infant child restraint lock. 51
! Pull up on the infant child restraint to check that it is fully
locked to the stroller.

P-IM0253D
Share the joy at joiebaby.com
Joie Children's Products (UK) Ltd,
Venture Point, Towers Business Park
Rugeley, Staffordshire, WS15 1UZ
2017/03/14
