Jung SCHUKO 1520-15 Series User manual

Sockets with USB charger
29.05.20201 / 20024021900
Sockets with USB charger
SCHUKO® and French/Belgian system
Ref.-no.: .. 1520-15 .., .. 1520 F-15 ..
.. 1520-18 .., .. 1520 F-18 ..
Operating instructions
1 Safety instructions
Electrical devices may only be mounted and connected by electrically skilled persons.
Serious injuries, re or property damage possible. Please read and follow manual fully.
Danger of electric shock. Always disconnect before carrying out work on the devise or load.
These instructions are an integral part of the product, and must remain with the end customer.
2 Structure of the device
Fig. 1: Structure of the device
(1) Insert
(2) Frame
(3) Cover
3 Function
Intended purpose
- Socket with battery charging station for mobile devices with USB connection
- Installation in ush box according to DIN 49073
- Installation depth: 48 mm
Product characteristics
- with enhanced contact protection (shutter)
- screwless terminals for wires up to 2.5 mm²
- USB connections:
1 × type A (with quick charge function) or
1 × type C (with quick charge function) or
1 × type A and 1 × type C
1
2
3
1
2
3
GB

Sockets with USB charger
29.05.20202 / 20024021900
4 Information for electrically skilled persons
Installation and electrical connection
DANGER
Electric shock from touching live parts in the installation environment.
An electric shock can be fatal.
Before working on the device, disconnect the power and cover live parts in the area.
• Connect the device.
• Install the device.
• Install frame and cover onto the device.
• Supply voltage can be switched on.
5 Technical data
Rated voltage AC 220 ... 250 V ~
Mains frequency 50/60 Hz
Rated current, socket 16 A
Output voltage
USB type A or C DC 9 V / DC 5 V
USB type A and C DC 5 V
Output current
USB type A or C 2 A / 3 A
USB type A and C (total) 3 A
Standby consumption
USB type A ≤ 60 mW
USB type C ≤ 25 mW
USB type A and C ≤ 25 mW
Ambient temperature +5 ... +35 °C
Storage/transport temperature -20 ... +70 °C
Protection level IP 20
Connection screwless terminals
single wire 1,5 ... 2,5 mm²
stranded without ferrule 1.5 ... 2.5 mm²
6 Warranty
The warranty follows about the specialty store in between the legal framework as provided for by law.
