Jura IMPRESSA C9 Assembly instructions

The IMPRESSA C9 Manual
The ‘IMPRESSA Manual’ has been awarded the seal of
approval by the independent German Technical Inspection
Agency, TÜV SÜD, due to its easy-to-understand style, its
thoroughness and coverage of safety aspects.

2
Your IMPRESSA C9
IMPORTANT SAFEGUARDS 4
Control elements 8
Proper use 10
For your safety 10
The IMPRESSA C9 Manual 13
Symbol description......................................................................................................................................14
Welcome to the world of JURA! 15
1 IMPRESSA C9 16
Connector System©....................................................................................................................................17
JURA on the Internet....................................................................................................................................17
Knowledge Builder.......................................................................................................................................17
2 Preparing and using for the first time 18
Supplied as standard...................................................................................................................................18
Set up .............................................................................................................................................................18
Filling the water tank...................................................................................................................................18
Filling the bean container...........................................................................................................................19
First-time use ................................................................................................................................................19
Using and activating filter .........................................................................................................................20
Determining water hardness and adjusting...........................................................................................22
Adjusting the grinder .................................................................................................................................23
Switching on ................................................................................................................................................24
Switching off (standby)..............................................................................................................................24
3 Familiarising yourself with the control options 25
Preparation at the touch of a button.......................................................................................................26
One-off settings before and during preparation...................................................................................26
Adjusting the default amount of water to suit the cup size................................................................27
Permanent settings in programming mode..........................................................................................28
Query information and maintenance status..........................................................................................30
4 Recipes 32
5 Preparation at the touch of a button 38
Barista tips....................................................................................................................................................38
Espresso........................................................................................................................................................39
Coffee............................................................................................................................................................40
Cappuccino...................................................................................................................................................40
Pre-ground coffee.......................................................................................................................................42
Table of contents

3
Table of contents
Foaming milk with the Easy Cappuccino Frother .................................................................................43
Foaming and heating milk with the Professional Cappuccino Frother.............................................43
Hot water......................................................................................................................................................44
6 Permanent settings in programming mode 45
Products........................................................................................................................................................45
Energy saving mode (E.S.M.©)..................................................................................................................47
Time ..............................................................................................................................................................48
Programmable switch-on time.................................................................................................................48
Automatic switch-off..................................................................................................................................49
Unit amount of water/Time format .........................................................................................................50
Language......................................................................................................................................................50
7 Maintenance 52
Maintenance tips.........................................................................................................................................52
Rinse machine..............................................................................................................................................52
Filter change.................................................................................................................................................53
Clean machine.............................................................................................................................................54
Descale machine .........................................................................................................................................56
Rinsing the Easy Cappuccino Frother......................................................................................................58
Cleaning the Easy Cappuccino Frother ...................................................................................................59
Disassembling and rinsing the Easy Cappuccino Frother....................................................................60
Rinsing the Professional Cappuccino Frother.........................................................................................61
Cleaning the Professional Cappuccino Frother......................................................................................62
Disassembling and rinsing the Professional Cappuccino Frother......................................................63
Cleaning the bean container.....................................................................................................................63
Descaling the water tank ...........................................................................................................................64
8 CLARIS plus filter cartridge – Water for perfect coffee 65
9 ‘The milk makes the difference’ 71
10 Accessories and Service 73
11 Display messages 83
12 Troubleshooting 85
13 Transport and environmentally neutral disposal 87
Transport / Empty system .........................................................................................................................87
Disposal.........................................................................................................................................................87
14 Technical data 88
15 Key technologies and IMPRESSA range of products 90
16 JURA contact details 95
Index 100

4
Important Safeguards
These safeguards apply for machines with UL safety test (see rating
plate and chapter 14, ‘Technical data’).
When using electrical appliances, basic safety precautions should
always be followed, to reduce the risk of fire, electric shock, and/or
injury to persons, including the following:
Read all instructions.
Do not touch hot surfaces. Use handles or knobs.
To protect against fire, electric shock and injury to persons, do
not immerse cord, plugs, or body of machine in water or other
liquid.
Close supervision is necessary when any appliance is used by
or near children.
Unplug from outlet when not in use and before cleaning.
Allow to cool before putting or taking off parts, and before
cleaning the appliance.
Do not operate any appliance with a damaged cord or plug or
after the appliance malfunctions, or has been damaged in any
manner. Return appliance to the nearest authorized service
facility for examination, repair or adjustment.
The use of accessory attachement not recommended by the
appliance manufacturer may result in fire, electric shock, or
injury to persons.
Do not use outdoors.
Do not let the cord hang over the edge of a table or counter,
or touch hot surfaces.
Do not place on or near a hot gas or electric burner, or in a
heated oven.
Always attach plug to appliance first, then plug cord into the
wall outlet. To disconnect, turn any control to ‘OFF’ then
remove plug from wall outlet.
Do not use appliance for other than intented use.
Use extreme caution when dispensing hot steam.
For household use only.
Z
Z
Z
Z
Z
Z
Z
Z
Z
Z
Z
Z
Z
Z
Follow the basic safety
precautions
Follow the basic safety
precautions
IMPORTANT SAFEGUARDS
SAVE THESE INSTRUCTIONS

5
Important Safeguards
a. A short power supply cord is provided to reduce the risk
resulting from becoming entangled in or tripping over a long
cord.
Your IMPRESSA has a 3-pin grounded plug.
b. Longer extension cords are available and may be used if care
is exercised in their use.
c. If an extension cord is used,
1. the marked electrical rating of the extension cord should be
at least as great as the electrical rating of the appliance,
and
2. if the appliance is of the grounded type, the extension cord
should be a grounding type 3-wire cord, and
3. the longer cord shall be arranged so that it will not drape
over the counter top or tabletop where it can be pulled on
by children of tripped over.
As a safety feature, this plug will fit in a polarized outlet only
one way.
If the plug does not fit fully in the outlet, reverse the plug. If it
still does not fit, contact a qualified electrician.
Do not modify the plug in any way or attempt to defeat this
safety feature.
To reduce the risk of fire or electric shock, do not remove any service
covers. No user serviceable parts inside. Repair should be done by
authorized personnel only.
This appliance is for household use. Any servicing other than clean-
ing and user maintenance should be performed by an authorized
service representative:
Do not immerse base in water or try to disassemble.
To reduce the risk of fire or electric shock, do not remove the
base. No user serviceable parts inside. Repair should be done
by authorized service personnel only.
Check voltage to be sure that the voltage indicated on the
name plate agreees with your voltage.
Never use warm or hot water to fill the water container! Use
cold water only.
Z
Z
Z
Z
Z
Z
Z
Special cord set instructionsSpecial cord set instructions
WarningWarning
CautionCaution

6
Important Safeguards
Keep your hands and the cord away from hot parts of the
appliance during operation.
Never clean with scouring powders or hard implements.
Never fill instant coffee, chocolate mix etc. into the grinder or
ground coffee funnel (grunder by-pass). It will damage the
functioning of the brewing chamber.
Never fill sugar coated coffee beans into the bean hopper. In
case of doubt, call your dealer.
Never fill anything other than coffee beans into the bean con-
tainer (no chocolate, no rice, no nuts, no spices, nothing other
than roasted coffee beans).
Never do anything with the machine which is not described in
the User‘s Manual. In case of doubt, call your dealer.
Z
Z
Z
Z
Z
Z
NEVER DO
(or you will void your
warranty protection):
NEVER DO
(or you will void your
warranty protection):

7
Important Safeguards

8
Control elements
Figure: IMPRESSA C9 Piano Black
Control elements
1 Cover of filler funnel for pre-ground coffee
2 Filler funnel for pre-ground coffee
3 Water tank cover
4 Water tank
5 Power switch and power cable
(side of machine)
6 Coffee grounds container
7 Drip tray
8 Fineness of grind switch
9 Bean container cover
10 Bean container
with aroma preservation cover
11 Connector System©
for removable frothers
12 Easy Cappuccino Frother
13 Height-adjustable coffee spout
14 Cup platform
5
8
1
3
2
4
6
7
11
12
13
10
14
9

9
Control elements
Front left:
1 Plain text display
Q On/off button
c Maintenance button
i Espresso button
o Coffee button
v Pre-ground coffee button
2 Rotary Switch cover
3 Rotary Switch
Front right:
p Cappuccino button
ü Milk foam button
m Hot water button
4 Easy Cappuccino Frother
5 Professional Cappuccino Frother
6 Hot water nozzle
4
3
1
2
4 5 6
The Connector System©permits the use of different frothers. These are available from stockists.

10
Important information
The machine has been designed and built for domestic use. It should
only be used to prepare coffee and to heat milk and water. Use for
any other purpose will be deemed improper. JURA Elektroapparate
AG cannot accept any responsibility for the consequences of
improper use.
Before using the machine always carefully read and comply with all
these instructions. Keep this manual close to the IMPRESSA and, if
appropriate, pass it on to the next user.
Please read and note carefully the following important safety infor-
mation.
By doing this, you can avoid the life-threatening danger of electric
shock:
Never use a machine which has been damaged or with a
defective power cable.
For information on what to do in case of damage, for example
if there is a smell of burning, unplug the machine immediately
from the mains supply and contact the JURA service centre.
If the power cable for this machine is damaged, it must be
repaired either directly by JURA or by a JURA approved service
centre.
Make sure that the IMPRESSA and the power cable are not
located close to hot surfaces.
Be careful to ensure that the power cable does not get caught
and does not rub against sharp edges.
Never open and repair the machine yourself. Do not modify
the machine in any way that is not described in the IMPRESSA
Manual. The machine contains live parts. If opened, there is a
danger of serious injury. Repairs may only be carried out by
JURA approved service centres, using original spare parts and
accessories.
There is a risk of scalds or burns on the spouts or on the nozzle:
Place the machine out of the reach of children.
Do not touch any hot parts. Use the handles provided.
Z
Z
Z
Z
Z
Z
Z
Z
Proper useProper use
For your safetyFor your safety

11
Important information
Be careful to ensure that the appropriate nozzle is installed
and clean. The nozzle or parts of the nozzle might come off if
the parts are not assembled correctly or a blockage occurs.
A defective machine is not safe and could cause injury or fire. To
avoid damage and any associated risk of injury or fire:
Never allow the power cable to loosely hang down. The power
cable can be tripped over or damaged.
Protect your IMPRESSA from environmental influences such
as rain, frost and direct sunlight.
Do not put the IMPRESSA, cable or connections in water.
Do not put the IMPRESSA or any individual parts in the dish-
washer.
Turn your IMPRESSA off at the power switch before starting
any cleaning operation. Always wipe your IMPRESSA with a
damp cloth rather than a wet one, and protect it from pro-
longed water splash.
Only connect the machine to a power supply in accordance
with the information on the rating plate. The rating plate is
located on the underside of your IMPRESSA. Further technical
data is given in Chapter 14 ‘Technical Data’.
Use only original JURA care products. Use of accessories that
are not explicitly recommended by JURA could damage the
IMPRESSA.
Do not use any coffee beans treated with additives or caramel-
ised coffee beans.
Always fill the water tank with cold, fresh mains water.
If you will be absent for an extended period, turn the machine
off and unplug.
Risk to children and persons with limited capabilities in operating
machines:
The machine is not designed to be operated by children and
persons with limited capabilities.
The machine may only be used by persons who are able to
operate the machine safely.
Z
Z
Z
Z
Z
Z
Z
Z
Z
Z
Z
Z
Z

12
Important information
Safe handling of the CLARIS plus filter cartridges:
CLARIS plus filter cartridges should be kept out of the reach of
children.
Store them dry in the sealed package.
Protect them from heat and direct sunlight.
Do NOT use damaged CLARIS plus filter cartridges.
Do NOT open CLARIS filter cartridges.
Z
Z
Z
Z
Z

13
The IMPRESSA C9 Manual
You are holding the manual for your IMPRESSA C9 in your hand. It
will help you to familiarize yourself with your IMPRESSA safely and
quickly and teach you the full range of facilities it offers.
Chapter 2, ‘Preparing and using your IMPRESSA for the first time’,
explains step-by-step how to set up and prepare the IMPRESSA.
Chapter 3, ‘Familiarising yourself with the control options’ is impor-
tant for you to read as you are familiarising yourself with your
IMPRESSA. It invites you to actively explore all the different coffee
experiences that it offers.
As coffee and coffee specialities are very important to JURA, we have
compiled a selection of tasty suggestions for you in Chapter 4,
‘Recipes’.
All the other chapters are intended to help you when you have a
specific query.
If you use the IMPRESSA C9, you will become a master at preparing
exciting coffee specialities, you will be a Barista!
The IMPRESSA C9 ManualThe IMPRESSA C9 Manual

14
The IMPRESSA C9 Manual
Warnings
CAUTION
Always take note of any information marked
with the CAUTION or WARNING symbol. The
signal word WARNING points out potential risk
of serious injury, and the signal word CAUTION
potential risk of slight injury.
CAUTION
The CAUTION symbol is used to draw attention
to circumstances which could cause the
machine to become damaged.
Symbol descriptionSymbol description
Symbols used
EInformation and tips to make things easier for
you as you use your IMPRESSA.
@References to the online JURA website, where
you can find interesting further information:
www.jura.com.
TPrompt to take action. This symbol means that
you are being prompted to perform some
action.

15
Welcome to the world of JURA!
Dear customer,
We thank you for the trust that you have placed in us by purchasing
a JURA IMPRESSA coffee machine. The machines, which are pro-
duced in Switzerland, have already impressed independent, critical
testers of goods and design award juries. We will do everything we
can to ensure that this fully automated, genuine 2-cup Espresso and
coffee machine continues to deliver perfect coffee specialities at the
press of a button to your family and your guests for years to come.
The IMPRESSA Manual will teach you everything you need to know
on the subject of operating and tailoring your IMPRESSA to your
particular preferences. Other subjects covered include how to solve
the problem of scale build-up and important tips on care. Our pri-
mary concern is to stimulate your imagination with attractive coffee
recipes and to invite you to put the wealth of possibilities offered by
the JURA fully automated machine to use on a daily basis.
We wish you many stimulating and enjoyable moments with your
IMPRESSA.
Yours sincerely,
Emanuel Probst
General Manager
Welcome to the world of JURA!Welcome to the world of JURA!

16
1 IMPRESSA C9
The new entry level model in the One Touch Cappuccino league is
sure to please all cappucino fans with its simple ’touch of a button’
function without having to move the cup. In elegant piano black and
with a new user interface, the high-quality IMPRESSA C9 is fully in
keeping with current trends and exudes an aura of superiority, dura-
bility and competence. It impressively demonstrates these attributes
with each coffee speciality that you enjoy.
One Touch Cappuccino: Your IMPRESSA C9 makes a cup of
cappuccino at the touch of a button, without you having to
move the cup. Hot milk foam, flowing into the cup and slowly
starting to fill it. Steam which rises, awakening the anticipa-
tion of a delicious speciality. Aromatic coffee, blending with
the milk, pushing up the milk foam topping. These are the
protagonists in a sensuous drama - the drama of perfect cof-
fee preparation.
Simple operation: With the clearly arranged control elements
and the easy-to-understand text and graphic display, opera-
tion of the IMPRESSA C9 is also simple for beginners. You can
navigate effectively through the individual programme steps
by simply turning and pressing the Rotary Switch. The focus
is on your personal taste. Simply select the coffee strength,
amount of water and temperature according to your individ-
ual preferences.
Energy saving mode (E.S.M.©): The IMPRESSA C9 actively
assists you in saving energy. With the Energy Saving Mode
you can adjust the energy saving potential to suit the way you
like to enjoy your beverages. The machine can be completely
disconnected from the power supply at the main switch - for
instance if you are going to be absent for some time.
Z
Z
Z
Coffee that fulfils your
wildest dreams
Coffee that fulfils your
wildest dreams
1 IMPRESSA C9

17
1 IMPRESSA C9
Height-adjustable coffee spout: The height of the coffee
spout, which can be adjusted within a range of 65 to 111 mm,
can be adapted to all cup sizes on a continuous scale. This pre-
vents coffee splashing on the machine and is your guarantee
for a rich, thick crema.
The Connector System©permits the use of different cappuccino
frothers:
Professional Cappuccino Frother
Cappuccino, latte macchiato
Hot milk and milk foam
Easy Cappuccino Frother
Cappuccino
Milk foam
Visit us on the Internet.
At www.jura.com you will find interesting and up-to-date
information on your IMPRESSA and on every aspect of cof-
fee.
You can familiarise yourself with your IMPRESSA C9 in a fun way on
the PC.
The Knowledge Builder awaits you at www.jura.com. The
interactive assistant, LEO, will support you and explain the
benefits of and how to use your IMPRESSA.
Z
Z
U
U
Z
U
U
@
@
Connector System©Connector System©
JURA on the InternetJURA on the Internet
Knowledge BuilderKnowledge Builder

18
2 Preparing and using your IMPRESSA for the first time
This chapter provides you with the information you need to use your
IMPRESSA without any problems. You will prepare your IMPRESSA
step-by-step for your first coffee experience.
The following items are supplied as standard:
Your JURA IMPRESSA fully automatic coffee machine
The Welcome Pack, which includes:
The IMPRESSA C9 Manual
IMPRESSA C9 – Quick Reference Guide
JURA cleaning tablets
Measuring spoon for pre-ground coffee
Aquadur® test strip
Hot water nozzle
Milk container with milk pipe
CLARIS plus filter cartridge
JURA Auto-Cappuccino Cleaner
Keep the packaging for your IMPRESSA. It should be used to protect
the machine during transportation.
When setting up your IMPRESSA, please note the following:
Set the IMPRESSA down on a horizontal surface that is not
sensitive to water.
Choose a spot for your IMPRESSA which is protected against
overheating.
To enjoy perfect coffee we recommend changing the water every
day.
Milk, mineral water or other liquids can damage the water tank or
the machine.
Only fill the water tank with fresh, cold water.
Remove the water tank and rinse it with cold water.
Fill the water tank with fresh, cold water and reinsert.
Z
Z
U
U
U
U
U
U
Z
Z
Z
Z
Z
T
T
T
Supplied as standardSupplied as standard
Set upSet up
Filling the water tankFilling the water tank
CAUTIONCAUTION
2 Preparing and using for the first time

19
2 Preparing and using your IMPRESSA for the first time
The bean container has an aroma preservation cover. This will ensure
that your coffee beans retain their aroma for longer.
Coffee beans which have been treated with additives (e.g. sugar),
pre-ground or freeze-dried coffee will damage the grinder.
Only use untreated coffee beans to refill the bean container.
Open the cover of the bean container and remove the aroma
preservation cover.
Remove any dirt or foreign objects inside the bean con-
tainer.
Fill the bean container with coffee beans, then close the
aroma preservation cover and the bean container cover.
If the machine is operated with a defective power cable, there is a
danger of electric shock.
Never use a machine which has a defective power cable.
Precondition: The water tank and bean container are full.
Insert the mains plug into a power socket.
3 T Switch on the IMPRESSA using the power switch on the back
of the machine.
The indicator light lights up (standby).
Q T Press the On/Off button to switch the IMPRESSA on.
The pre-set language appears on the display.
Open the cover of the Rotary Switch.
The Rotary Switch lights up.
g T Turn the Rotary Switch until the desired language is dis-
played. For Example: LANGUAGE ENGLISH
k T Press the Rotary Switch to confirm the language.
OK appears briefly on the display to confirm the setting.
PRESS RINSE, the maintenance button clights up.
Close the cover of the Rotary Switch.
T
T
T
T
T
T
T
T
Filling the bean con-
tainer
Filling the bean con-
tainer
CAUTIONCAUTION
First-time useFirst-time use
WARNINGWARNING

20
2 Preparing and using your IMPRESSA for the first time
Place a receptacle under the frother.
c T Press the maintenance button.
SYSTEM FILLING, the system fills up with water. A
small amount of water flows from the frother.
This operation stops automatically, the following appears on
the display:
HEATING.
PRESS RINSE, the maintenance button clights up.
Place a receptacle under the coffee spout.
c T Press the maintenance button.
RINSING, the machine rinses. The operation stops auto-
matically.
READY, your IMPRESSA is ready to use.
When a coffee speciality has been prepared for the first time,
it is possible that FILL BEANS is shown on the display as
the grinder has not yet been completely filled with coffee
beans. In this case prepare another coffee speciality.
Your IMPRESSA no longer has to be descaled if you are using CLARIS
plus filter cartridges.
You can also try out the ’Insert filter’ operation online. Visit the
Knowledge Builder at www.jura.com.
Further information on the CLARIS plus filter cartridge can be found
in Chapter 8, ’CLARIS plus filter cartridge – Water for perfect coffee’.
Perform the ’Insert filter’ operation without interruptions. This
will ensure that your IMPRESSA always produces at its best.
Precondition: READY is displayed.
Open the cover of the Rotary Switch.
k T Keep the Rotary Switch pressed until RINSE appears on
the display.
g T Turn the Rotary Switch until FILTER - is displayed.
k T Press the Rotary Switch to enter the programme item.
NO -
T
T
E
@
E
T
Using and activating
filter
Using and activating
filter
