SERVICE MANUAL
COPYRIGHT © 2005 Victor Company of Japan, Limited No.MA184
2005/4
DVD RECEIVER WITH MONITOR
MA18420054
KD-AV7010
TABLE OF CONTENTS
1 PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
2 SPECIFIC SERVICE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
3 DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
4 ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-35
5 TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-48
Area suffix
J ------------- Northern America
Detachable
AT T
MAIN SUB
ZOOM
ASPECT
MENU
VOLUME
TOPMENU
TUNER
564
231
897
11 / 012 /+1 0 10
DISC
OK
AV
GUI
SET UP
RETURN
DUAL
AVOUTVOL

1-2 (No.MA184)
SPECIFICATION
Main unit
AUDIO AMPLIFIER SECTION
Power Output Front and Rear 20 W RMS ×4 Channels at 4 Ωand [< or =] 1% THD+N
Center 18 W RMS ×1 Channel at 4 Ωand [< or =] 1% THD+N
Signal to Noise Ratio 80 dBA (reference: 1 W into 4 Ω)
Load Impedance 4 Ω(4 Ωto 8 Ωallowance)
Equalizer Control Range Frequencies 100 Hz, 300 Hz, 1 kHz, 3 kHz, 10 kHz
Level ±10 dB
Frequency Response 40 Hz to 20 000 Hz
TUNER SECTION
Frequency Range FM 87.5 MHz to 107.9 MHz
AM 530 kHz to 1 710 kHz
FM Tuner Usable Sensitivity 11.3 dBf (1.0 µV/75 Ω)
50 dB Quieting Sensitivity 16.3 dBf (1.8 µV/75 Ω)
Alternate Channel Selectivity (400 kHz) 65 dB
Frequency Response 40 Hz to 15 000 Hz
Stereo Separation 35 dB
Capture Ratio 1.5 dB
AM Tuner Sensitivity 20 µV
Selectivity 35 dB
DVD/CD PLAYER SECTION
Signal Detection System Non-contact optical pickup (semiconductor laser)
Number of channels 2 channels (stereo)
Frequency Response DVD, fs=48 kHz 16 Hz to 22 000 Hz
DVD, fs=96 kHz 16 Hz to 44 000 Hz
VCD, CD, MP3 16 Hz to 20 000 Hz
Dynamic Range 96 dB
Signal-to-Noise Ratio 98 dB
Wow and Flutter Less than measurable limit
MP3 Recording Format MPEG 1/2 Audio Layer 3
Max. Bit rate: 320 kbps

(No.MA184)1-3
Hideaway unit
Design and specifications are subject to change without notice.
REMOVABLE MONITOR
Screen Size 7 inch wide liquid crystal display
Number of Pixel 336 960 pixels (480 vertical ×234 horizontal ×3)
Drive Method TFT (Thin Film Transistor) active matrix format
Color System NTSC
Aspect Ratio 16:9 (wide)
Allowable Storage Temperature -10°C to +60°C (14°F to 140°F)
Allowable Operating Temperature 0°C to +40°C (32°F to 104°F)
Dimensions (W ×H ×D) 170 mm ×141 mm ×15 mm (6-3/4 in. ×5-5/8 in. ×5/8 in.)
Mass 475 g (1.1 lbs)
GENERAL
Power Requirement Operating Voltage DC 14.4 V (11 V to 16 V allowance)
Grounding System Negative ground
Allowable Operating Temperature 0°C to +40°C (32°F to 104°F)
Other Terminal Steering wheel remote input (OE REMOTE)
Dimensions (W ×H ×D) Installation Size 182 mm ×52 mm ×165 mm (7-3/16 in. ×2-1/16 in. ×6-1/2 in.)
(With sleeve-mounting plate Type B (standard))
182 mm ×52 mm ×160 mm (7-3/16 in. ×2-1/16 in. ×6-5/16 in.)
(With sleeve-mounting plate Type A)
Panel Size 188 mm ×58 mm ×14 mm (7-7/16 in. ×2-5/16 in. ×5/8 in.)
Mass 2.25 kg (5.1 lbs) (including monitor)
Input Terminals AV INPUT 1/2 Audio: 0.5 Vrms (Left/Right)
Video (composite): 1 Vp-p/75 Ω
Output Terminals (Level/Impedance) AV OUTPUT Audio: 2.0 V/20 kΩload (full scale)
Video (composite): 1 Vp-p/75 Ω
PRE OUT Audio: 2.0 V/20 kΩload (full scale)
Other Terminals System integration (TO MAIN UNIT)
FM/AM antenna (FM/AM ANTENNA)
AV bus (AV BUS)
CD changer (TO CHANGER)
Rear view camera/Center speaker
(BACKCAMERA REMOTE/CENTER SPEAKER)
Power cord (POWER)
Dimensions (W ×H ×D) 230 mm ×35 mm ×181 mm (9-1/16 in. ×1-7/16 in. ×7-3/16 in.)
Mass 1.3 kg (2.9 lbs)

1-4 (No.MA184)
SECTION 1
PRECAUTIONS
1.1 Safety Precautions
!Burrs formed during molding may be left over on some parts of the chassis. Therefore,
pay attention to such burrs in the case of preforming repair of this system.
!Please use enough caution not to see the beam directly or touch it in case of an
adjustment or operation check.

(No.MA184)1-5
1.2 Preventing static electricity
Electrostatic discharge (ESD), which occurs when static electricity stored in the body, fabric, etc. is discharged, can destroy the laser
diode in the traverse unit (optical pickup). Take care to prevent this when performing repairs.
1.2.1 Grounding to prevent damage by static electricity
Static electricity in the work area can destroy the optical pickup (laser diode) in devices such as CD players.
Be careful to use proper grounding in the area where repairs are being performed.
(1) Ground the workbench
Ground the workbench by laying conductive material (such as a conductive sheet) or an iron plate over it before placing the
traverse unit (optical pickup) on it.
(2) Ground yourself
Use an anti-static wrist strap to release any static electricity built up in your body.
(3) Handling the optical pickup
• In order to maintain quality during transport and before installation, both sides of the laser diode on the replacement optical
pickup are shorted. After replacement, return the shorted parts to their original condition.
(Refer to the text.)
• Do not use a tester to check the condition of the laser diode in the optical pickup. The tester's internal power source can easily
destroy the laser diode.
1.3 Handling the traverse unit (optical pickup)
(1) Do not subject the traverse unit (optical pickup) to strong shocks, as it is a sensitive, complex unit.
(2) Cut off the shorted part of the flexible cable using nippers, etc. after replacing the optical pickup. For specific details, refer to the
replacement procedure in the text. Remove the anti-static pin when replacing the traverse unit. Be careful not to take too long a
time when attaching it to the connector.
(3) Handle the flexible cable carefully as it may break when subjected to strong force.
(4) It is not possible to adjust the semi-fixed resistor that adjusts the laser power. Do not turn it.
1.4 Attention when traverse unit is decomposed
*Please refer to "Disassembly method" in the text for the CD pickup unit.
• Apply solder to the short land before the flexible wire is disconnected from the connector on the CD pickup unit.
(If the flexible wire is disconnected without applying solder, the CD pickup may be destroyed by static electricity.)
• In the assembly, be sure to remove solder from the short land after connecting the flexible wire.
1M
(caption)
Anti-static wrist strap
Conductive material
(conductive sheet) or iron plate
Front end board
CN101
Flexible wire
Short-circuit points

1-6 (No.MA184)
1.5 Important for laser products
1.CLASS 1 LASER PRODUCT
2.DANGER : Invisible laser radiation when open and inter
lock failed or defeated. Avoid direct exposure to beam.
3.CAUTION : There are no serviceable parts inside the
Laser Unit. Do not disassemble the Laser Unit. Replace
the complete Laser Unit if it malfunctions.
4.CAUTION : The CD,MD and DVD player uses invisible
laser radiation and is equipped with safety switches which
prevent emission of radiation when the drawer is open and
the safety interlocks have failed or are defeated. It is
dangerous to defeat the safety switches.
5.CAUTION : If safety switches malfunction, the laser is able
to function.
6.CAUTION : Use of controls, adjustments or performance of
procedures other than those specified here in may result in
hazardous radiation exposure.
REPRODUCTION AND POSITION OF LABELS
!
Please use enough caution not to
see the beam directly or touch it
in case of an adjustment or operation
check.
WARNING LABEL
CAUTION : Visible and Invisible
laser radiation when open and
interlock failed or defeated.
AVOID DIRECT EXPOSURE TO
BEAM. (e)
VARNING : Synlig och
osynling laserstrålning när
den öppnas och spärren är
urkopplad. Betrakta ej
strålen. (s)
VARO : Avattaessa ja suojalukitus
ohitettuna tai viallisena olet alttiina
näkyvälle ja näkymättömälle
lasersäteilylle. Vältä säteen
kohdistumista suoraan itseesi. (f)
ADVARSEL : Synlig og usynlig
laserstråling når maskinen er
åben eller interlocken fejeler.
Undgå direkte eksponering til
stråling. (d)
CLASS 1
LASER PRODUCT

(No.MA184)1-7
SECTION 2
SPECIFIC SERVICE INSTRUCTIONS
This service manual does not describe SPECIFIC SERVICE INSTRUCTIONS.

1-8 (No.MA184)
SECTION 3
DISASSEMBLY
3.1 Receiver unit section
3.1.1 Removing the detach panel assembly
(See Fig.1)
From the front side of the main body, slide the detach button in
the direction of the arrow and remove the detach panel assem-
bly.
Fig.1
Detach panel assembly
Detach button

(No.MA184)1-9
3.1.2 Removing the front panel assembly
(See Fig.2 to 4)
• Remove the detach panel assembly as required.
(1) From the both sides of the main body, remove the two
screw Aattaching the front panel assembly. (See Figs.2
and 3)
(2) From the bottom side of the main body, remove the FPC
cover. (See Fig.4.)
(3) Release the lock of the connector CN75 on the main board
and disconnect the card wire. (See Fig.4.)
(4) Release the joints aand remove the front panel assembly
from the main body in the direction of the arrow. (See
Fig.4.)
Fig.2
Fig.3
Fig.4
A
Front panel assembly
A
Front panel assembly
Main board CN75
FPC cover
a
aLock
Front panel assembly

1-10 (No.MA184)
3.1.3 Removing the top drive unit
(See Figs.5 to 8)
• Prior to performing the following procedures, remove the de-
tach panel assembly and front panel assembly.
(1) From the both sides of the main body, remove the four
screws Battaching the top drive unit. (See Figs.5 and 6.)
(2) From the rear side of the main body, remove the three
screws Cattaching the top drive unit. (See Fig.7.)
(3) Remove the top drive unit from the main body and turn it
inside out. (See Fig.8.)
(4) Remove the two screws Cattaching the F.P.C. guide on
the display drive unit. (See Fig.8.)
(5) Release the lock of the connector CN301 on the mecha-
nism board and disconnect the flexible wire. (See Fig.8.)
(6) Remove the two screws Dattaching the CN guide. (See
Fig.8.)
(7) Remove the three screws Eattaching the PWB base. (See
Fig.8.)
(8) Remove the screw Fattaching the connect board. (See
Fig.8.)
(9) Take out the connect board in the direction of the arrow.
(See Fig.8.)
(10) Release the lock of the connector CN391 on the connect
board and disconnect the flexible wire. (See Fig.8.)
Fig.5
Fig.6
Fig.7
Fig.8
B
Top drive unit
B
Top drive unit
Top drive unit
B
Lock
CN301
Motor board
Lock CN391
Connect board
F.P.C.guide Display drive unit
Top drive unit
CN guide
C
D
C
F
EE
PWB base

(No.MA184)1-11
3.1.4 Removing the rear bracket
(See Figs.9)
• Prior to performing the following procedures, remove the de-
tach panel assembly, front panel assembly and top drive unit.
From the rear side of the main body, remove the five screws G
attaching the rear bracket.
Fig.9
3.1.5 Removing the DVD mechanism assembly
(See Figs.10 and 11)
• Prior to performing the following procedures, remove the de-
tach panel assembly, front panel assembly and top drive unit.
(1) From the top side of the main body, release the lock of the
connector CN52 on the main board in an upward direction
and disconnect the flexible wire. (See Fig.10.)
(2) Remove the two screws Hand screw Jattaching the mech-
anism cover. (See Fig.10.)
(3) Release the lock of the connector CN101 on the main
board in an upward direction and disconnect the card wire.
(See Fig.11.)
Reference:
When connecting the card wire to the connector CN101, pass
it through the lower part of the mechanism bracket. (See
Fig.11.)
Fig.10
Fig.11
G
Rear bracket
J
CN52 Main board
HH
Mechanism cover
Flexible wire
DVD mechanism assembly
Mechanism bracket
CN101
Main board

1-12 (No.MA184)
3.1.6 Removing the main board
(See Figs.12 and 13)
• Prior to performing the following procedures, remove the de-
tach panel assembly, front panel assembly, top drive unit and
DVD mechanism assembly.
(1) From the rear side of the main body, remove the four
screws Kattaching the rear bracket. (See Fig.12.)
(2) From the top side of the main body, remove the two screws
Mattaching the mechanism bracket on the bottom chassis
assembly. (See Fig.13.)
(3) Remove the five screws Nand two screws Pattaching the
main board. (See Fig.13.)
(4) Take out the main board from the bottom chassis assem-
bly.
Reference:
When attaching the main board on the bottom chassis assem-
bly, align the projections bof the bottom chassis assembly in
the hole of the main board. (See Fig.13.)
Fig.12
Fig.13
3.1.7 Removing the front board
(See Fig.14)
• Prior to performing the following procedures, remove the de-
tach panel assembly and front panel assembly.
(1) From the inside of the front panel assembly, remove the
three screws Qand screw Q' attaching the front board.
(2) Take out the lock lever assembly from the front panel as-
sembly.
(3) Bend the hooks cin the direction of the arrow.
(4) Release the front board from the sections dand take out
the front board from the front panel assembly.
Reference:
When attaching the screw Q', attach the lock lever assembly
with it.
Fig.14
K
Rear bracket
Mechanism bracket Pb
b
b
Bottom chassis assembly
M
N
Main board
NP
N
M
Lock lever assembly
Front board
Front panel assembly
c
dcd
Q
Q'

(No.MA184)1-13
3.2 Top drive unit section
• Remove the top drive unit from the main body.
(See "3.1.4 Removing the top drive unit".)
3.2.1 Removing the display drive unit
(See Fig.1)
(1) From the both sides of the top drive unit, remove the two
screws Aattaching the display guides L/R and remove the
display guides L/R from the top chassis assembly.
(2) Slide the display drive unit by manual operation in the di-
rection of the arrow and remove it from the top chassis as-
sembly.
Fig.1
Top chassis assembly
Display drive unit
Display guide L
A
Display guide R
A

1-14 (No.MA184)
3.2.2 Removing the drive gears and forth gear
(See Figs.2 to 4)
• Remove the display drive unit.
(1) From the both sides of the display drive unit, remove the
four screws Battaching the guide rails (L)/(R). (See Figs.2
and 3.)
(2) From the top side of the display drive unit, pull the drive
gears out of a drive gear shaft in the direction of the arrow
while holding the drive gear shaft. (See Fig.4.)
Reference:
Remove the drive gear shaft as required. (See Fig.4.)
(3) From the left side of the display drive unit, remove the
E.ring fixing the forth gear. (See Fig.4.)
(4) Remove the forth gear toward this side. (See Fig.4.)
Fig.2
Fig.3
Fig.4
Display drive unit
Guide rail (L)
B
Display drive unit
Guide rail (R)
B
Drive gear Drive gearDrive gear shaft
Display drive unit
Forth gear
E.ring

(No.MA184)1-15
3.2.3 Removing the cover
(See Fig.5)
• Remove the display drive unit.
From the top side of the display drive unit, remove the two
screws Cattaching the cover.
Fig.5
Display drive unitCover
C

1-16 (No.MA184)
3.2.4 Removing the third gear, worm gear and double worm
(See Figs.6 to 11)
• Remove the display drive unit and cover.
(1) Remove the wire sheet with the wire from the motor. (See
Fig.6.)
Reference:
Disconnect the wire from the connector CN332 on the
motor board as required.
(2) Disconnect the wire from the connector CN312 on the mo-
tor board. (See Fig.7.)
(3) Remove the two screws Dattaching the motor bracket (S).
(See Fig.7.)
(4) Take out the motor bracket (S), worm guide, motor and
third gear together. (See Fig.7.)
(5) Pull the third gear out of the motor bracket (S) in the direc-
tion of the arrow. (See Fig.8.)
(6) Remove the two screws Eattaching the motor and remove
the motor from the motor bracket (S). (See Fig.9.)
(7) Pull the worm gear out of the motor. (See Fig.10.)
Reference:
When inserting the warm gear in the shaft of the motor,
insert it by a measurement of a rule. (See Fig.10.)
(8) From the top side of the display drive unit, pull the double
worm in an upward direction. (See Fig.11.)
Fig.6
Fig.7
Fig.8
Wire sheet Motor boardCN332 Motor
Wire
Third gear Motor boardCN312
Worm guide Motor bracket (S)
Motor
D
D
Motor bracket (S)
Third gear

(No.MA184)1-17
Fig.9
Fig.10
Fig.11
Motor bracket (S)
E
Worm gear
16 ± 0.1 (mm)
Motor
Double worm
Display drive unit

1-18 (No.MA184)
3.2.5 Removing the worm gear, motor bracket (A) and third worm
(See Figs.12 to 16)
• Remove the display drive unit and cover.
(1) Disconnect the wire from the connector CN311 on the mo-
tor board. (See Fig.12.)
(2) Remove the screw Fattaching the motor bracket (A). (See
Fig.12.)
(3) Take out the motor bracket (A), worm guide and motor to-
gether. (See Fig.12.)
(4) Remove the two screws Gattaching the motor and remove
the motor from the motor bracket (A). (See Fig.13.)
(5) Pull the worm gear out of the motor. (See Fig.14.)
Reference:
When inserting the warm gear in the shaft of the motor,
insert it by a measurement of a rule. (See Fig.14.)
(6) Remove the screw Hattaching the worm guide to the motor
bracket (A). (See Fig.15.)
(7) From the top side of the display drive unit, pull the third
worm in an upward direction. (See Fig.16.)
Fig.12
Fig.13
Fig.14
Fig.15
Fig.16
Motor board CN311
Worm guideMotor bracket (A)
Motor
F
Motor bracket (A)
G
Motor
Worm gear
16 ± 0.1 (mm)
Motor
Worm guide
Motor bracket (A)
H
Third worm
Display drive unit

(No.MA184)1-19
3.2.6 Removing the second wheel and R.L.S. gear
(See Figs.17 to 24)
• Remove the display drive unit and cover.
(1) Disconnect the wire from the connector CN311 on the mo-
tor board. (See Fig.17.)
(2) Remove the screw Jattaching the motor bracket (A). (See
Fig.17.)
(3) Take out the motor bracket (A), worm guide and motor to-
gether. (See Fig.17.)
(4) Remove the two screws Kattaching the gear bracket as-
sembly. (See Fig.18.)
(5) Take out the gear bracket assembly with other parts from
the display drive unit.
(6) From the left side of the gear bracket assembly, remove the
two screws Lattaching the gear bracket cover. (See
Fig.19.)
(7) Pull out the joint gear in the direction of the arrow. (See
Fig.20.)
(8) Pull out the hex gear and second wheel together in the di-
rection of the arrow. (See Fig.20.)
(9) Pull the second wheel out of the hex gear. (See Fig.21.)
(10) Pull the third gear in an upward direction. (See Fig.22.)
(11) From the top side of the display drive unit, disconnect the
wire from the connector CN331 on the motor board. (See
Fig 22.)
(12) Remove the screw Mattaching the R.L.S. bracket. (See
Fig.22.)
(13) Take out the R.L.S. barcket with other parts from the dis-
play drive unit. (See Fig.22.)
Reference:
When attaching the R.L.S. bracket, pass the wire
through the sections aon the wire holder as before. (See
Fig.22.)
(14) From the back side of the R.L.S. bracket, remove the screw
Nattaching the R.L.S. spring to the R.L.S. barcket and re-
move the R.L.S. spring in the direction of the arrow. (See
Fig.23.)
Reference:
When attaching the R.L.S. spring, hang the torsion
spring (R.L.S.) on the R.L.S. spring as before. (See
Fig.23.)
(15) From the front side of the R.L.S. bracket, remove the
R.L.S. gear toward this side. (See Fig.24.)
Reference:
When attaching the R.L.S. gear, attach the torsion spring
(R.L.S.) with it as before. (See Fig.24.)
Fig.17
Fig.18
Fig.19
Motor board CN311
Worm guideMotor bracket (A)
Motor
J
Gear bracket assembly
Display drive unit K
K
Gear bracket assembly
Gear bracket cover
L

1-20 (No.MA184)
Fig.20
Fig.21
Fig.22
Fig.23
Fig.24
Joint gear
Hex gearSecond wheel
Hex gear Second wheel
Motor board CN331 R.L.S. bracket
Display drive unit Third gear
M
a
R.L.S. spring
Torsion spring (R.L.S.)
R.L.S. spring
R.L.S. bracket
N
Torsion spring (R.L.S.)
R.L.S. gear
R.L.S. bracket
