JWA JARVIS 74675 User manual

ASSEMBLY INSTRUCTION
ITEM CODE 74675
JARVIS 4 Drawer Tall Chest
Imported by JWA Furniture Pty Ltd, Brisbane Qld, Australia.
For any assistance with assembly or for missing parts please refer to your receipt
1

Allow 6 0min For2person Additional toolsrequired
PRE-ASSEMBLY PREPARATION
Before you start:
1. Choose a clean, level, spacious assembly area. Avoid hard surfaces that may
damage the product
2. Take care when liing. Product should be assembled as near as possible to the
point of use
3. Ensure that you have all required contents for complete assembly
4. Always read the assembly instrucons carefully before beginning assembly.
5. Keep all hardware parts and packaging out of reach of small children.
6. Do not over ghten the screws and bolts as this may damage the threads
7. Assembly is to be carried out by a competent adult(s) ONLY
8. During assembly, children should be kept away from the product due to possible
risk to injury.
9. Do not use this item if any components are missing or damaged.
10. Please keep the instrucons for future reference.
2

8mm
3

PARTSLIST
A
21pcs
M6x40mm
BCEF
JO
21pcs
15x12mm
16pcs
8x30mm
1pc
M4 4pcs 4pcs
48pcs
40pcs
PZ1 Z2
8pcs
16pcs
1pc
GHN
40pcs
V1
M3.5x12 16pcs 16pcs
12x10.5mm
4
M6x34mm
M6x15mm

5

6
STEP 1: Fix dowel (B) and cam pin (A)to panel (1) (2) (3) (4).

STEP 2: Fix rails (N-1) to panel (3) (4) with screw (V1) .
7
N-1=8
N-1 N-2

STEP 3: Fix panel (5) (7) (8) to panel (3) (4) with cam lock (C)
8
12

9
STEP 4:
Insert panel (6) into grooves between panel (1) (2) (3)
(4) (5).

Fix panel (1) (2) to panel (3) (4) with cam lock (C) .
STEP 5:
10

STEP 6:Fix metal leg (J) to bottom panel (2) with bolt (G) ,
lock washer (Z1), washer (Z2). Using allen key ( ) to fix
100% as shown.
H
11

STEP 7-1:Fix cam pin (O) to panel (9) (10) (12) (13).
12
STEP 7-3:Fix rails (N-2) to panel (12) (13) with screw (V1)
STEP 7-2:
Fix panel (11) (12) (13) to panel (10) with cam lock (P).
Insert panel (14) into grooves between panel (9) (10) (12) (13).
Fix panel (11) (12) (13) to panel (9) with cam lock (P).

STEP 8: Adjust to proper position.
13

STEP 9:Insert the back panel hook (E) into the back and using
screw to fix , as shown.
14

15
SAFETY BRACKETS
INSTRUCTIONS
1. Attach one Mounting Plate to the wall with the Large Screws. Make sure to
attach the Mounting Plate into a stud. If mounting into brick or masonry you
will need to acquire wall anchors.
2. Attach the second Mounting Plate to the furniture frame with the Short
Screws.
3. Move the furniture to its final position. Thread a Wall Strap through the both
Mounting Plates and tighten until snug. Do not over tighten.
4. Make sure that the Mounting Plates are firmly attached to the wall and
furniture and that the Wall Strap is snug.
all Back side
Mounting Plate x 2 all Strap x 1 Large Screw x 2 Small Screw x 2
HARDARE

ASSEMBLY COMPLETE
16

17
To protect your furniture, we suggest the following:
•Avoid placing your furniture in direct sunlight.
•Do not place furniture directly under windows.
•Do not place sharp materials (knife, fork, etc.) directly onto
your furniture as sharp material may scrape and damage the
finish.
•Do not place material with high temperature directly onto the
surface of your furniture.
•Clean up spills quickly. Water left over a prolonged period of
time may cause damage. Alcohol, perfume, nail polishes,
aftershave and some medication may cause severe finish
damage if not cleaned immediately.
•Use a clean, soft, dry, lint free absorbent cloth to clean your
furniture. Do not use any detergent as they may contain
ingredients that may react and damage the finish.
NOTE: If the above care advise is not adhered to your product
warranty may become void
