KW5262 Wireless VDSL Router
User Manual

VDSL Router User Manual
NOTICE
This document contains proprietary information protected by copyright, and this Manual
and all the accompanying hardware, software, and documentation are copyrighted. All
rights are reserved. No part of this document may be photocopied or reproduced by
mechanical, electronic, or other means in any form.
The manufacturer does not warrant that the hardware will work properly in all
environments and applications, and makes no warranty or representation, either
expressed or implied, with respect to the quality, performance, merchantability, or
fitness for a particular purpose of the software or documentation. The manufacturer
reserves the right to make changes to the hardware, software, and documentation
without obligation to notify any person or organization of the revision or change.
All brand and product names are the trademarks of their respective owners.
© Copyright 2013
All rights reserved.

VDSL Router User Manual
1
Content
1.1 FEATURES.............................................................................................................................2
1.1.1 Data rate......................................................................................................................2
1.1.2 DSL Compliant............................................................................................................2
1.1.3 Wireless.......................................................................................................................2
1.1.4 Network Protocol & Features.....................................................................................2
1.1.5 ATM Capabilities.........................................................................................................3
1.1.6 VoIP..............................................................................................................................3
1.1.7 FIREWALL...................................................................................................................4
1.1.8 Management Support.................................................................................................4
1.1.9 Operating System Support.........................................................................................4
1.1.10 Environmental.............................................................................................................4
1.2 PACKET CONTENTS .............................................................................................................4
1.3 SYSTEM REQUIREMENTS .....................................................................................................5
1.4 FACTORY DEFAULTS............................................................................................................5
1.5 WARNINGS AND CAUTIONS ..................................................................................................5
2 HARDWARE DESCRIPTION......................................................................................................7
3 HARDWARE INSTALLATION....................................................................................................9
4 PC CONFIGURATION GUIDE..................................................................................................10
4.1 LOCAL PC CONFIGURATION IN WINDOWS 95, 98, ME, XP,VISTA,7..................................10
4.2 LOCAL PC CONFIGURATION IN WINDOWS 2000.................................................................10
5 WEB-BASED MANAGEMENT GUIDE....................................................................................11
5.1 LANSETTING PAGE.............................................................................................................11
5.2 INTERNET ACCESS CONFIGURATION....................................................................................12
5.2.1 ADSL Setup..................................................................................................................12
5.2.2 VDSL Setup..................................................................................................................17
5.2.3 Router Mode Setup......................................................................................................22
5.2.4 LAN Settings.................................................................................................................27
5.2.4.1 IPv4 LAN Settings..................................................................................................... 27
5.2.4.2 IPv6 LAN Settings..................................................................................................... 29
5.3 WIRELESS SETTING .............................................................................................................31
5.3.1 Basic............................................................................................................................. 31
5.3.2 Advanced................................................................................................................. 33
5.3.3 Security...................................................................................................................... 36
5.4VOIP CONFIGURATION ........................................................................................................40
5.4.1 SIP Basic Setting.........................................................................................................40
5.4.2 SIP Advanced Setting..................................................................................................41
5.5PRINTER SERVER INSTALLATIONS ......................................................................................42
APPENDIX: FREQUENT ASKED QUESTIONS......................................................................45

VDSL Router User Manual
2
1 Overview
Thank you for choosing our product. The KW5262 is a Wireless VDSL router
combining an DSL modem, an 802.11n wireless router, a 4-port switch, a FXO port ,
two FXS ports and an USB port in one unit, bringing high-speed wireless Internet
connection to a home or office.
1.1 Features
1.1.1 Data rate
Downstream data rate up to 100 Mbps
Upstream data rate up to 50Mbps(100 Mbps upstream with
external AFE)
1.1.2 DSL Compliant
ITU G.992.1 (G.DMT)
ITU G.993.2 (G.vdsl2) (Profile 8a, 8b, 8c, 8d, 12a,12b and 17a;
30a optional)
ITU G.992.2 (G.Lite)
ITU G.994.1 (G.hs)
ITU G.992.3 (G.DMT.BIS)
ITU G.992.4 (G.lite.bis)
ITU G.992.5
Compatible with all T1.413 issue 2 (full rate DMT over analog
POTS), and CO DSLAM equipment
1.1.3 Wireless
Fully IEEE 802.11n compatible.
Wireless data rate up to 300Mbps
Operating in the unlicensed 2.4 GHz ISM band
Multi-SSID
Supports 64/128 bits WEP security and user authentication
1.1.4 Network Protocol & Features
Ethernet to ADSL Self-Learning Transparent Bridging

VDSL Router User Manual
3
Internet Control Message Protocol (ICMP)
IP Static Routing
Routing Information Protocol (RIP, RIPv2)
Network Address Translation (NAT)
Virtual Server, Port Forwarding
Dynamic Host Configuration Protocol (DHCP)
DNS Relay, DDNS
IGMP Proxy
Simple Network Time Protocol (SNTP)
VPN pass-through (IPSec/PPTP/L2TP)
Parent control
1.1.5 ATM Capabilities
RFC 1483 Multi-protocol over ATM “Bridged Ethernet” compliant
RFC 2364 PPP over ATM compliant
RFC 2516 PPP over Ethernet compliant
ATM Forum UNI3.1/4.0 PVC - Up to 16 PVCs
VPI Range: 0-255
VCI Range: 32-65535
UNI 3.0 & 3.1 Signaling
ATM AAL5 (Adaption Layer type 5)
OAM F4/F5
1.1.6 VoIP
SIP
Voice codecs: G.711A/µ, G.723, G.726, G.729
Call waiting
Call forwarding

VDSL Router User Manual
4
1.1.7 FIREWALL
Built-in NAT
MAC Filtering
Packet Filtering
Stateful Packet Inspection (SPI)
Denial of Service Prevention (DoS)
DMZ
1.1.8 Management Support
Web Based GUI
Upgrade or update via FTP/HTTP
Command Line Interface via Telnet
Diagnostic Test
Firmware upgrade-able for future feature enhancement
1.1.9 Operating System Support
WINDOWS 98/98 SE
WINDOWS ME
WINDOWS 2000
WINDOWS XP
WINDOWS VISTA
WINDOWS 7
Macintosh
LINUX
1.1.10 Environmental
Operating humidity: 10%-90% non-condensing
Non-operating storage humidity: 5%-95% non-condensing
1.2 Packet Contents
The packet contents are as the following:

VDSL Router User Manual
5
DSL ROUTER x 1
External Splitter x 1
Power Adapter x 1
Telephone Line x 1
Ethernet Cable x 1
Antenna x 2
Base x 1
CD x 1
1.3 System Requirements
Before using this ROUTER, verify that you meet the following requirements:
Subscription for DSL service. Your DSL service provider should provide
you with at least one valid IP address (static assignment or dynamic
assignment via dial-up connection).
One or more computers, each contains an Ethernet 10/100M Base-T
network interface card (NIC).
A hub or switch, if you are connecting the device to more than one
computer.
For system configuration using the supplied web-based program: A web
browser such as Internet Explorer v5.0 or later, or Netscape v4.7 or
later.
1.4 Factory Defaults
The device is configured with the following factory defaults:
IP Address: 192.168.1.1
Subnet Mask: 255.255.255.0
User Name: admin
Password: adslroot
VPI/VCI: According to local information
1.5 Warnings and Cautions
Never install telephone wiring during storm. Avoid using a telephone
during an electrical storm. There might be a risk of electric shock from
lightening.

VDSL Router User Manual
6
Do not install telephone jacks in wet locations and never use the product
near water.
To prevent dangerous overloading of the power circuit, be careful about
the designed maximum power load ratings. Not to follow the rating
guideline could result in a dangerous situation.
Please note that telephone line on modem must adopt the primary line
that directly outputs from junction box. Do not connect Router to
extension phone. In addition, if your house developer divides a
telephone line to multi sockets inside the wall of house, please only use
the telephone that has connected with the splitter of DSL Router when
you access the Internet. Under the above condition, if you also install
telephone with anti-cheat-dial device, please pull out this kind of
telephone, otherwise DSL Router may occur frequently off-line.

VDSL Router User Manual
7
2 Hardware Description
Front Panel
LED
Color
Function
PWR
Green
On: Power on
Off: No power
LAN1,2,3,4
Green
On: LAN link established and active via LAN port
Blinking: DSL data activity occurs
Off: No LANlink via LAN port
WLAN
Green
On: The wireless module is ready and idle
Blinking: Data transmitting or receiving over WLAN
Off: The wireless is not installed.
DSL
Green
On: DSLlink established and active
Quickblinking: DSL is trying to establish a connection
Slow blinking: No DSL link
INET
Green
On: IP connected.
Blinking: IP connected and IP traffic is passing through
the device.
Off: DSL connnectionnot present.
VOIP1,2
Green
On:Atelephoneconnected to the phoneport has its
receiver off of the hook .
Off: The handset of telephoneconnected to thephone
port is on-hook.

VDSL Router User Manual
8
Rear panel
Side Panel
WIFI: The switch of wireless function
RESET: System reset or reset to factory defaults
WPS: A convenient way to set wireless security
Port
Function
DSL
Connect the device to an ADSL telephone jack or splitter
using a RJ-11 telephone cable
FXS0,1
Connect the deviceto your normal phone
USB
Connect the deviceto your printer
LAN1,2,3,4
Connect the device to your PC's Ethernet port, or to the
uplink port on your hub/switch, using a RJ-45 cable
ON/OFF
Switch it on or off
POWER
Connect to the supplied power adapter
