KW9522 Wireless Router User Manual
NOTICE
This document contains proprietary information protected by copyright, and this
Manual and all the accompanying hardware, software, and documentation are
copyrighted. All rights are reserved. No part of this document may be photocopied or
reproduced by mechanical, electronic, or other means in any form.
The manufacturer does not warrant that the hardware will work properly in all
environments and applications, and makes no warranty or representation, either
expressed or implied, with respect to the quality, performance, merchantability, or
fitness for a particular purpose of the software or documentation. The manufacturer
reserves the right to make changes to the hardware, software, and documentation
without obligation to notify any person or organization of the revision or change.
All brand and product names are the trademarks of their respective owners.
© Copyright 2014
All rights reserved.

KW9522 Wireless Router User Manual
1
Content
1 INTRODUCTION ......................................................................................................................2
1.1 MAIN FEATURES .............................................................................................................. 2
1.1.1 Wireless ...............................................................................................................................2
1.1.2 Network Protocol and Features...........................................................................................2
1.1.3 Firewall ...............................................................................................................................2
1.1.4 Management Support...........................................................................................................2
1.1.5 Operating System Support ...................................................................................................3
1.1.6 Environmental......................................................................................................................3
1.2 PACKET CONTENTS ....................................................................................................... 3
1.3 SYSTEM REQUIREMENTS ................................................................................................. 3
1.4 FACTORY DEFAULTS...................................................................................................... 3
1.5 WARNINGS AND CAUTIONS............................................................................................. 3
2. HARDWARE INSTALLATION...............................................................................................5
3 PC CONFIGURATION GUIDE ..............................................................................................7
4 QUICK SETUP OF THE ROUTER ..........................................................................................9
5 WEB-BASED BASIC MANAGEMENT GUIDE..................................................................... 12
5.1 Home Page Basic Settings ....................................................................................................12
5.2 Home Network Settings.........................................................................................................13
5.2.1 LAN Settings ......................................................................................................................14
5.3 Wireless Settings...................................................................................................................15
5.4 Time setting...........................................................................................................................18
5.5 Password ..............................................................................................................................18
5.6 Backup/restore/reset.............................................................................................................19
5.7 Firmware update ..................................................................................................................20

KW9522 Wireless Router User Manual
2
1 Introduction
Thank you for choosing our product. The KW9522 LTE Router is fully complies
with IEEE802.11b/g/n standards. It will provide you with convenient Internet
everywhere.
1.1 Main Features
1.1.1 Wireless
Fully IEEE 802.11b /g /n compatible.
Wireless data rate up to 150 Mbps
Operating in the unlicensed 2.4 GHz ISM band
Supports 64/128 bits WEP, WPA, WPA2, WPA/WPA2-PSK,
802.1x
1.1.2 Network Protocol and Features
Internet Control Message Protocol (ICMP)
IP Static Routing
Routing Information Protocol (RIP, RIPv2)
Network Address Translation (NAT)
Dynamic Host Configuration Protocol (DHCP)
DDNS
1.1.3 Firewall
Built-in NAT
MAC Filtering
Packet Filtering
Stateful Packet Inspection (SPI)
Denial of Service Prevention (DoS)
1.1.4 Management Support
Web Based GUI
Upgrade or update via FTP/HTTP

KW9522 Wireless Router User Manual
3
Firmware upgrade-able for future feature enhancement
1.1.5 Operating System Support
WINDOWS 98/SE/ME/2000/XP/VISTA/6/8
Macintosh/IOS/Android/Blackberry
LINUX
1.1.6 Environmental
Operating temperature:0~40℃
Storage temperature:-40~60℃
Operating humidity: 10%-90% non-condensing
Non-operating storage humidity: 5%-95% non-condensing
1.2 Packet Contents
The packet contents are as the following:
LTE ROUTER x 1
USB data cable x 1
Battery x 1
Manual x 1
1.3 System Requirements
PCs with a working USB data cable connect to LTE router.
TCP/IP protocol on each PC
Web browser, such as Microsoft Internet Explorer, Mozilla Firefox or
Apple Safari
1.4 Factory Defaults
The device is configured with the following factory defaults:
IP Address: 192.168.0.1
Subnet Mask: 255.255.255.0
1.5 Warnings and Cautions
Never use the product near water.

KW9522 Wireless Router User Manual
4
To guarantee a better performance, don’t not use LTE router near
microwave, Bluetooth devices, cordless phone, other wireless network
devices.

KW9522 Wireless Router User Manual
5
2. Hardware Installation
This chapter introduces the Hardware interface, meanwhile shows you how to connect
Router.
Side Panel
Front Panel
Icon
Function
USB
Power supply and use USB data cable to surf Internet
WPS
Press WPS button to auto connect with wireless device
Reset
Reset to factory default

KW9522 Wireless Router User Manual
6
Back Panel
SD card slot SIM card slot
You can insert the LTE SIM card, SD card and battery. Then fasten battery cover.
How to connect the KW9522?
1. Using an USB data cable to connect the PC USB port and the router will auto
connect with your computer.
2. Connect the power cable to the PWR connector on ROUTER, then plug in
the power adapter to the AC power outlet, and then press the on-off button.
Icon
Function
Power on and Power off. View screen details.
Show signal strength
WiFi strength
Battery usage
Date rate of LTE
USB connection

KW9522 Wireless Router User Manual
7
3 PC Configuration Guide
For windows 7
1）Click “Start -> Control Panel-> Network and Internet -> View networks
status -> Change adapter settings”
2）Right-click Wireless Network Connection(or Local Area conncection), and
then click Properties.
3）Select Internet Protocol Version 4( TCP/IPv4), and then clcik Properties.
4）Select Obtain an IP address automatically and Obtain DNS Server
address automatically. Then click OK.
For Windows 8
1）Move your mouse to the lower right corner and click the Serch icon in the
popus.
2）Go to Apps, type Control Panel in the serche box and press enter.
3）Go to “Control Panel ->l View networks status-> Change adapter
settings”
4）Right-click Ethernet,select Properties, then double-click internet protocol
version 4( TCP/IPv4).
5）Select Otain an IP address automatically and Obtain DNS Server
address automatically. Then click OK.
For windows XP
1) Click “Start”-> Control Panel -> Network and Internet Connection ->
Network Connections”
2) Right-click Wireless Networks Connection (or Local Area Connection), and
then click Properties.
3) Select Internet Protocol (TCP/IP), and then click Properties.
4) Select Otain an IP address automatically and Obtain DNS Server address
automatically. Then click OK.

KW9522 Wireless Router User Manual
8
For Mac OS X
1) Click the Apple icon on the upper left corner of the screen.
2) Go to “System Preference” -> Network ”.
3) Select Airport on the left menu bar, and then click Advanced for wireless
configuration; or select Ethernet for wired configuration,
4) In the Configure IPv4 box under TCP/IP, select Using DHCP.
5) Click Apply to save the settings.
