kd frames 7903-TR-T User manual

Knockdown Frameworks, Inc. warrants all of its products for five years against any defects that are due to faulty materials or workmanship. We will promptly correct such
defects by repair or replacement, at our option, without charge. This warranty covers product defects only and will expire five years after date of purchase by the original
consumer purchaser, with proof of purchase required.
This warranty does not apply to damage caused by and resulting from misuse, neglect, accident, or improper operation, maintenance, storage, transportation, or
handling of the product. This warranty is for the original consumer purchaser for residential use only and does not apply if the product is used in any commercial application
(such as rental property). This warranty does not cover any incidental or consequential damages. If you feel that you have a claim under this warranty, please contact the
store from which it was purchased. If this is not possible,call 706-543-9397 for advice on handling your claim.
Instructions for
Trundle Bed
Twin
Manufactured by
(2) N-70 BED RAILS (70”)
(8) N-36 REGULAR SLATS (36”)
(2) N-36C CONNECTOR SLATS (36”)
(2) N-37 END CONNECTORS (37”)
Use 2-1/2” Bolts (H-21) and
Cross Dowels (H-3) to attach
Bed Rails (N-70) and
Connector Slats (N-36C).
Leave the bolts loose until Step 2.
2
Parts
H-21
H-3
HARDWARE LIST
1
H-10 HEX WRENCH
H-3 CROSS DOWEL
8
4
H-21 2 - 1/2” BOLT
4
H-1 3” BOLT
394 Dairy Pak Rd. • Athens, GA 30607
kdframes.com • [email protected]
WHEELS
H-W
4
H-34 3/4” WOOD SCREWS
8
Attach two Wheels (H-W) to one of the
the End Connectors (N-37) using four
of the the 3/4” Wood Screws (H-34).
Repeat for the other End Connector.
1
H-W
H-34
Tool Required: #2 Phillips-Head Screwdriver.
sku# 7903-TR-T

First, make sure that the Wheels are on
the lower edge of the End Connector
and then press it onto the Bed Rails.
Use 3” Bolts (H-1) and Cross Dowels (H-3)
to attach it as shown.
PLEASE RETIGHTEN
BOLTS
AFTER 30 DAYS
This futon frame is made with Tulip Poplar. Any green tint in the wood will change to light brown in a few weeks. This will happen in 20 to 30
minutes if placed in direct sunlight. Tulip Poplar can be left unfinished, clear finished, stained, or painted. I prefer the lighter stains over the darker
ones because the wood is fairly porous. My favorite is a clear finish with no stain. Satin polyurethane (oil or water based) works well.
Painting: It is best to start with an interior primer and lightly sand before painting.
Staining: Lightly sand before staining. Wipe stain on with a rag until you get the desired color. If you are going to use a top coat (such as
polyurethane), do not sand again until after the first coat, and then be careful not to sand away the stain.
Finishing: All finishes work well with Tulip Poplar. A simple wax finish over stain (Minwax for example) is easy. An oil finish such as Danish oil
can be used. Or a clear top coat such as polyurethane works well to seal the wood. With polyurethanes, the first coat acts as a sanding sealer.
So you should lighty sand (180 - 220 grit sandpaper) after the first coat, wipe the wood clean, and then build up coats for the desired effect.
ATTENTION!!
Make sure that the wheels
are on the lower edge of the
End Connector
4
H-3 H-1
3
Place Regular Slats (N-36)
into the pockets and
then tighten the bolts.
NOTE: Bolts should be just
loose enough to insert the
Regular Slats.
NOTE: When the Slats are
all in their pockets, tighten
the bolts.
