kd frames Savannah 602/3919 User manual

602/3919
Assembly Instructions – Please keep for future reference
Important – Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 01799 513466
Issue 1 - 02/11/09
Savannah Dining Table
EXTENDED
CLOSED
Dimensions
Width - 200cm
Depth - 80cm
Height - 75cm
Width - 140cm
Depth - 80cm
Height - 75cm
Extended Closed
603/1217

Safety and Care Advice
Important – Please read these instructions fully before starting assembly
1
Glass safety
Care and maintenance
1
• This product complies with
BS7376: 2004.
• Imported by:
Justwise Group Ltd
6 The Shires
Shirehill Industrial Estate
Saffron Walden
Essex
CB11 3AP
• Product stock ref: DTSAV (Clear Glass)
DTSAVB (Black Glass)
• P/O No:
• If the glass is chipped or broken, stop using the product and
consult the Manufacturer of Supplier.
WARNINGS
a) Do not place very hot or very cold items on the glass surface(s) unless adequately thick table mats
are used to prevent such items from coming into contact with the glass..
b) Do not sit or stand upon the glass surface(s).
c) Do not use the glass as a chopping surface. Do not strike the glass with hard or pointed items.
d) When cleaning glass panels use a damp cloth or leather with washing up liquid or soft soap if
necessary, do not use washing powders or any other substance containing abrasives since these
substances scratch glass.
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on
this unit.
• This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
• Check you have all the
components and tools listed on
pages 2 and 3.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Make sure you have enough
space to layout the parts before
starting.
• Do not stand or put excessive
weight on the product, this
could cause damage.
• Assemble the item as close
to its final position (in the same
room) as possible.
• Parts of the assembly will be
easier with 2 people.
• Dispose of all packaging
carefully and responsibly.
• Place the product on flat and
steady surface during use.
• Assemble on a soft level
surface to avoid damaging the
unit or your floor.
• Keep these instructions for
further use.
• To ensure an easier assembly,
we strongly advise that all
fittings are only finger tightened
during initial assembly. Only
upon completion of the
assembly should all fixing points
be fully tightened.

Please check you have all the parts listed below
Components - Parts
2
Leg frame x 2
(70 x 12.6cm)
Top frame (138 x 60.7cm)
Glass extension leaves x 2 (80 x30cm)
3
5
4
1Leg x 4
(54.8 x Ø5.1cm)
2
Glass top (140 x 80cm)

Components - Fittings
A
0
Ruler – Use this ruler to help correctly identify the screws
3
510 2015 4035
30
25 80
75
7060 65
45 50 55 160155150140 145120 125 130 135
85 90 10095 115110105 165 170
Please check you have all the fittings listed below
Note: The quantities below are the correct amount to complete the assembly. In some cases more
fittings may be supplied than are required.
If you have damaged or missing components,
call the Customer Helpline: 01799 513466
0
0
10 20 40
30 80706050 150140120 130
90 100 110
1 2 4
356
Tools required
Ruler/tape
measure
B C
D E F
G
75mm Large stud x 4
Nut x 4
Spanner x 1
HJ
K L M
N O P
Q
Leg spacer x 4 13mm Allen screw x 16
Spring washer x 8 Ø16mm Plain washer x 8 68mm Medium stud x 4
Nut x 4 15mm Short stud x 8
10mm Threaded spacer x 4
Rubber washer x 8 14mm Threaded spacer x 8 Ø18mm Plain washer x 4
Rubber pad x 4 Allen key x 1

Step 1
Assembly Instructions
4
Step 2
Assembling leg frames
Place leg frame
upside down onto the
floor.
Screw large threaded
rods into leg frames
as shown.
Note: Screw the short
end in until it stops.
Locate leg spacers
over the threaded rods.
Screw legs onto
threaded rods and
tighten.
Repeat for other leg
frame.
A
Assembling side rails
Place top frame
upside down onto a
clean flat surface.
Assemble leg frames to
the top frame using
fixings and .
3
C
B
C D
3
1
1
2
25mm
B
AA
Upside down
D
E
3
D
E
C
1
2
E

Assembly Instructions
Step 3
5
Step 4
Preparing glass top
Place glass top
upside down onto a
clean flat surface.
Screw medium threaded
rods into the metal
discs on the underside of
glass top .
Screw nuts onto
threaded rods and use
the spanner to tighten
onto the metal discs.
Screw threaded spacers
half way onto the
threaded rods.
F
Preparing extension
leaves
G
5
4
4
4
5
G
F
H
H
F
G
4
Step 3
completed
Step 4
completed
L
K
J
H
Place extension leaves
upside down onto a
clean flat surface.
Screw short threaded
rods into the metal
discs on the underside of
extension leaves .
Locate rubber washers
over the rods.
Screw threaded spacers
onto the rods and
tighten.
J
5
K
L

Assembly Instructions
Step 5
6
Step 6
Attaching extension
leaves
With help, turn frame
over into it's standing
position.
Carefully align glass
extension leaves with
the brackets on the
frame.
Secure from underneath
using fixings .
Attaching main glass
top
C
5
5
With help, carefully lower
main glass top down
into position.
Warning:
The glass top is
heavy, lift with
care.
Following the extension
procedure described in
step 7, raise the
extension leaves into the
extended position.
a: Threaded spacers
can be turned to adjust
the height of the glass
top and achieve
alignment with the
extension leaves.
b: Once alignment is
achieved, secure main
glass top using fixings
and .
Small rubber pads can
be located onto the edge
of the extension leaves
to prevent direct glass to
glass contact.
4
H
M
N
O
Note: Do not fit
fixings and
until after height
alignment.
Turn spacer to align
top with extension
leaves .
a:
b:
M
N
M
N
H
4
M N
5
O
O
C
5
5
C
4
5

Assembly Instructions
Step 7
7
Extending and closing
TO EXTEND
Pull extension leaf out
from below the main
glass top until it stops.
Push down on the
handlebar to raise the
extension leaf.
Once raised, push the
extension leaf back in
until it touches the main
glass top.
TO CLOSE
Repeat the above in
reverse order, expect the
handlebar should be
raised to lower the
extension leaf.
Warning:
Keep fingers
clear of glass
contact area when
closing/extending the
leaves!
Assembly is complete.
If you need help or have damaged or missing parts, call the Customer Helpline: 01799 513466
Justwise Group Ltd., 6 The Shires. Shire Hill Industrial Estate. Saffron Walden. Essex. CB11 3AP
